Continental Conair ICT400 Double Induction Cooktop User Manual

Continental Conair Limited Double Induction Cooktop Users Manual

Users Manual

ICT400
Professional
induction cooktoP
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.
2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. READ ALL INSTRUCTIONS.
2. Unplug from outlet when not in use and before cleaning. Allow
surface to cool before putting on or taking off parts.
3. Use unit only on a level surface.
4. Use only with induction-compatible cookware.
5. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
6. Dry outside of pan before use.
7. Do not heat empty pan.
8. Don’t spill any liquids into vent areas.
9. To protect against electrical shock do not immerse cord, plugs
or housing unit in water or other liquids.
10. This appliance should not be used by or near children or
individuals with certain disabilities.
11. Do not leave appliance unattended when it is on.
12. Do not touch hot surfaces. Use handles or knobs.
13. Do not cook on a broken cooktop – If cooktop should break,
cleaning solutions and spillovers may penetrate the broken
cooktop and create a risk of electric shock.
14. Clean cooktop with caution – If a wet sponge or cloth is used
to wipe spills on a hot cooking area, be careful to avoid steam
burn. Some cleaners can produce noxious fumes if applied to
a hot surface.
15. Do not operate any appliance with a damaged cord or plug,
after the appliance malfunctions or has been damaged in any
manner. Call the nearest authorized Waring customer service
center (see Warranty) to return for examination, repair or
adjustment.
16. A short power-supply cord is supplied to reduce the risk
resulting from becoming entangled in or tripping over a longer
cord.
17. Extension cords are available and may be used if care is
3
exercised in their use. The marked electrical rating of the
extension cord should be at least as great as the electrical
rating of the appliance.
18. The cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or
tripped over unintentionally.
19. The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
20. Do not use outdoors or while standing in a damp area.
21. Do not place on or near a hot gas or electric burner, or in a
heated oven.
22. Extreme caution must be used when moving any pot or pan
containing hot oil or other hot liquids from this appliance.
23. When using this appliance provide at least 4–6 inches of air
space above and on all sides for air circulation.
24. Do not use this appliance for anything other than its intended
use. This appliance is for household use only.
25. Always attach plug to appliance rst, then plug cord into the
wall outlet. To disconnect, turn the unit off, then remove plug
from wall outlet.
26. Do not operate your appliance in an appliance garage or under
a wall cabinet. When storing in an appliance garage, always
unplug the unit from the electrical outlet. Not doing so could
create a risk of re, especially if the appliance touches the
walls of the garage or the door touches the unit as it closes.
27. This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is
intended to t into a polarized outlet only one way. If the plug
does not t fully into the outlet, reverse the plug. If it still does
not t, contact a qualied electrician. Do not attempt to modify
the plug in any way.
This device complies with Part 18 of the FCC Rules.
This appliance is for 120 volts only and should not be used
with a converter.
4
CAUTION
To reduce the risk of electric shock, burns, re or injury:
1. Always unplug cooktop from the electrical outlet immediately
after using.
2. Do not use while bathing or in a shower.
3. Do not place or store unit where it can fall or be pulled into a
tub or sink.
4. Do not place or drop into water or other liquids.
5. Do not reach for unit that has fallen into water. Unplug it
immediately.
6. Care should be taken so that objects do not fall and liquids are
not spilled onto the unit.
• TOREDUCETHERISKOFELECTRICSHOCK,DONOT
REMOVECOVERORBACK.THEREARENOUSER-
SERVICEABLEPARTSINSIDE.
• TOREDUCETHERISKOFFIREORELECTRICSHOCK,DONOT
EXPOSETHISUNITTOWATERORMOISTURE.
SAVE THESE INSTRUCTIONS
FOR HOUSEHOLD USE ONLY
CONTENTS
Important Safeguards .................................................................. 2
HowInductionCookingWorks .................................................... 5
Selecting Cookware for Induction Cooktops .............................. 5
Safety Functions and Features .................................................... 5
Using Your Induction Cooktop .................................................... 6
CleaningandMaintenance .......................................................... 7
YournewWaringPro®ProfessionalDoubleInductionCooktopwas
an exceptionally smart choice. Induction heat technology not only
uses less energy, it also heats and cools faster than conventional
burners. You may end up using your new cooktop more often than
your stovetop!
5
HOW INDUCTION COOKING WORKS
Induction cooking uses electromagnetism to transfer energy into
the bottom of your cookware. The surface of the cooktop does not
work the same way as conventional cooktops – it sends the energy
directly to the cookware. As long as the energy is transferring
intothecookware,thecookwarewillstayhot.Oncetheenergyis
removed or reduced, the cookware begins to cool instantly.
SELECTING COOKWARE FOR INDUCTION
COOKTOPS
Use only induction-ready cookware
Selecting the proper induction-ready cookware is very important
to the efciency of your induction cooktop. As a general rule,
copper, aluminum and glassware will not work on an induction
cooktop. Waring highly recommends using magnetic stainless steel,
enamel, porcelain on steel, or cast iron. If you are not careful in
your selection of cookware for your cooktop, the cookware may not
work efciently or possibly may cause damage to the electronics.
As a general rule, if a magnet sticks to the bottom of the cookware,
it will work on an induction cooktop. If a magnet does not stick to
the cookware, it will not work on an induction cooktop. If you are
unsure, it is best to check with your local merchant to make sure you
are purchasing compatible cookware.
Note: Not for use with pans smaller than 4.7" diameter.
SAFETY FUNCTIONS AND FEATURES
• Pollutionfree:noburning,smokeorharmfulgaseslikecarbon
monoxide and sulde
• Safe:noame,noexhaust
• Easytoclean:high-rigidityglassfaceplate
• Energyefcient:usesupto70%lessenergythanconventional
cooktops
• Automaticshutoff:cooktopturnsoff30secondsafterpanis
removed
• Protectionagainstoverheating
6
USING YOUR INDUCTION COOKTOP
1. Operation
Oncetheunitispluggedintoanelectricaloutlet,placeyour
cookwareontheglasstopandpressON/OFFtoturnonleftburner,
right burner or both.
Note: If the unit is turned on and no cookware is put on the cooking
surface, the unit will beep and turn off after 30 seconds. If you
remove the cookware from the cooking surface during the operation
mode, the unit will beep and will automatically turn off after 30
seconds.
2. Heat Settings
Left Burner:Cooktophaseightheatsettings,fromLow(1)toHigh
(8).Tooperatetheheatcontrol,pressthebuttonlabeledHEAT
(IndicatorlightlabeledHEATwillilluminate).Toincreaseheat,press
uparrowtothedesiredsetting.Pressdownarrowtolowerthe
setting. The screen will indicate the current setting.
Right Burner:Cooktophasveheatsettings,fromLow(1)to
Medium/moderate(5).Tooperatetheheatcontrol,pressthe
buttonlabeledHEAT(IndicatorlightlabeledHEATwillilluminate).
Toincreaseheat,pressuparrowtothedesiredsetting.Press
down arrow to lower the setting. The screen will indicate the
current setting.
7
3. Timer Function
To operate the timer for each burner, press that burner’s button
labeledtimer.(IndicatorlightlabeledTIMERwillilluminate).Pressto
set the timer to your desired cooking time. If you press and hold the
up or down arrow, the timer will advance rapidly. The timer can be
adjusted to a maximum time of 150 minutes. At the end of the timed
cycle, the timer will beep four times.
NOTE: Your induction cooktops can run simultaneously for 180
minutes per use.
The timer runs for 150 minutes per use. If the cooktop has been
operating for more than 30 minutes and you set the timer for 150
minutes (for a total cooking time of more than 180 minutes), the
timer function will be shortened. The cooktop will turn itself off after
180minutesofuseandthedisplaywillreadOFF.
4. Cookware detection: Unit will automatically turn off after 30
seconds if cookware is not compatible.
5. Unit automatically turns off when cookware exceeds temperature
limit. This prevents burning empty pots.
6. When the unit is off, the fan may continue running for a minute or
more.
If your cookware overheats, the unit will give a long beeping
sound and will automatically turn off.
Note: The cooking surface will be hot after use, and care
should be taken when adding on or removing cooking utensils
from the cooktop to avoid burns.
CLEANING AND MAINTENANCE
Becauseitdoesnotgenerateitsownheat,theinductioncooktop
has no grates or carbon buildup to clean. Since you don’t have
scorching heat going up the sides of your cookware, the cookware
stays cleaner longer.
Use a damp cloth with mild soap on the control panel, or use a
nonabrasive cooktop cleaning product (specically made for smooth
tops and available in most grocery stores).
Any other servicing should be performed by an authorized service
representative.
Trademarks or service marks of third parties used herein are
the trademarks or service marks of their respective owners.
©2012 Waring Consumer Products
150 Milford Road
East Windsor, NJ 08520
www.waringpro.com
Printed in China
ICT40 0 IB
12WR134003
IB -11629
