Wireless Outlet Switch
The Wireless Outlet Switch enables easy control of just about any plug-in device in
the home, immediately making it a part of the Control4® home automation sys-
tem. With intelligent power-sensing abilities, the Wireless Outlet Switch enables
increased control of audio/video devices as well as plug-in lighting and motorized
devices. What’s more, it communicates wirelessly with the home controller to trig-
ger and interact with other devices and systems throughout the home.
It’s all part of the Control4 vision. We bring the benets of a truly automated home
to more people with solutions that are affordable, easy to install and designed to
adapt to any home or lifestyle.
Looks Small, Thinks Big
Features and Benets
Drop a disc into your DVD player and
watch the TV automatically turn on and
tune to the correct input while the home
theater screen comes down.
Congure the lights in the backyard
pond to come on every evening at sunset.
Intelligent From Front To Back
• Built-in power sensing — From turning on the TV to turning off the game console, the Wireless
Outlet Switch learns a device’s power level and can automatically trigger relevant commands.
• Anytime control — Lights can be switched on or off based on the time of day or other activities
in the home.
• Anywhere control — Intelligent, reliable, wireless connectivity using the ZigBee™ (802.15.4)
mesh networking standard.
• Energy efcient — By automating plug-in devices, electricity is only used when needed.
Smart Design
• Low prole — Small form factor ts easily behind furniture.
• Dual outlets — Two independently switched outlets give added capacity.
• Secure mounting — Special screw tab design allows for the Outlet Switch to be securely
attached to the wall outlet so it won’t accidentally be unplugged.
Easy To Install and Use
• Wireless control — No special control cables to pull through the home.
• Easy recognition — Just plug it in, press a button, and it’s immediately recognized in the system.
• Integrated control — Immediately controllable from any Control4 interface in any room
Control4 • 11734 South Election Road • Salt Lake City, Utah 84020 • p: 801.523.3100/1.888.400.4070 • f: 801.523.3199 • www.control4.com
Technical Specications
Model Number
• LOZ-5S1-W
Power requirements
• Power Requirements: 120 VAC, 50/60 Hz, 1.7 W
• Power sensing range: 690 mA
• Power sensing resolution: 52 mA (5W)
Load Ratings (total across both outlets)
• 120 VAC, 1000 VA, Inductive, Total
• 120 VAC, 1/3 HP (7.2 FLA), Total
• 120 VAC, 7.2 A, Ballast, Total
Communications
• Wireless ZigBee (802.15.4) mesh networking
Environmental
• Operational 0°C to 40°C
• Humidity 5% to 95% Non-Condensing
• Storage -20°C to 70°C
Dimensions & Weight
• H x W x D: 4.5” x 2.6” x 1.6” (115mm x 67mm x 42mm)
• Weight: 8 oz (227 g)
Available Colors
• White
In addition to the Wireless Outlet
Switch, Control4 offers:
Wireless Outlet Dimmer — Ideal for
dimmable plug-in devices rated up to
400 watts.
Wireless Outlet Switch
Wireless Dimmer — For new or retrot
home automation solutions using
ZigBee wireless connectivity.
Related Control4 Products
