Coolit Systems 83000021 ESP WIRELESS MODULE User Manual ESP MODULE MANUAL
Coolit Systems, Inc. ESP WIRELESS MODULE ESP MODULE MANUAL
Users Manual
©2010 CoolIT Systems, Inc. 0
PRODUCT MANUAL
PRODUCT: ESP MODULE
PART NO: 830-00021
Figure 1 below shows a typical usage of the ESP Module, shown
installed on the USB Node I/O Board and the Fan Node I/O board.
Figure 1 – Typical Usage of the ESP Node
ESP Module Operation:
1. Plug the USB Node I/O board into the USB port of a Windows XP /
Vista / 7 computer.
2. Start the Freescale Zigbee Test Client software.
3. See the Freescale Zigbee Test Client manual for detailed
instructions on testing the wireless capabilities of the ESP Module.
Desktop Computer
USB Node Carrier Board
Fan Node Carrier Board
Motherboard
USB 2.0
ESP Module
USB Header
ESP Module
Chassis
Fans Temperature
Sensor
PWM
Tach
CPU Fan
Header
12V
PWM
Tach
Chassis
LED Lighting
PRODUCT MANUAL – 830-00021 12-Apr-10
©2010 CoolIT Systems, Inc. 1
FCC NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO
OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S
AUTHORITY TO OPERATE THE EQUIPMENT.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:1. This device may not cause harmful interference, and 2.
This device must accept any interference received, including interference that may
cause undesired operation.
FCC ID label on the final system must be labeled with "Contains
FCC ID: YIQ83000021" or "Contains transmitter module FCC ID:
YIQ83000021".
In the user guide, final system integrator must be ensure that
there is no instruction provided in the user guide to install or
remove the transmitter module.
The transmitter module must be installed and used in strict accordance
with the manufacturer's instructions as described in the user
documentation that comes with the product. This device complies with
the following radio frequency and safety standards.
