Corbin Russwin CR Parts Price List 2014 Book Russwin2014Parts

User Manual: Corbin Russwin Corbin Russwin 2014 Parts Price Book Price Book

Open the PDF directly: View PDF .
Page Count: 80

2014 Parts

Price List

Number 26

Effective January 1, 2014

Table of Contents

January 1, 2014

SECTION PAGES

TERMS AND CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TAC-1, 2, 3

SERVICE CENTER BUSINESS HOURS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TAC-4

PART NUMBER INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .A-L

KEY SYSTEMS

PlugsandShells .........................................................................................1

CylinderParts ........................................................................................2-3

StandardDiameterCylinderCollars .........................................................................4

MasterRingCylinderCollars ..............................................................................5

Tools ..................................................................................................5

MORTISE LOCKSETS AND TRIM

ML2000 and ML2000HS Series

MortiseLocks ........................................................................................6-9

MortiseTrim .......................................................................................10-18

SECURITY BOLT LEVER LOCKSETS

CL3200Series ..........................................................................................19

EXTRA HEAVY-DUTY CYLINDRICAL LEVER LOCKSETS

CL3300Series ......................................................................................20-23

HEAVY-DUTY CYLINDRICAL LEVER LOCKSETS

CL3500Series.......................................................................................24-25

CL3600Series.......................................................................................26-27

GRADE 2 KEY-IN-LEVER

CL3800Series ......................................................................................28-29

CL3900Series.......................................................................................30-31

HEAVY-DUTY CYLINDRICAL KNOB LOCKSETS

CK4200Series ......................................................................................32-34

STANDARD-DUTY CYLINDRICAL KNOB LOCKSETS

CK4400Series ..........................................................................................35

CK4700Series ..........................................................................................35

PRE-ASSEMBLED UNIT LOCKSETS

UT5200Series ......................................................................................36-37

PADLOCKS, DEADLOCKS AND PUSH-PULL LATCHES

Padlocks ..............................................................................................38

DL3000SeriesDeadlocks .................................................................................38

DL4000SeriesDeadlocks .................................................................................39

HL10SeriesPush-PullLatches .............................................................................39

PUSHPAD EXIT DEVICES AND TRIMS

ED8000Series ......................................................................................40-42

ED5000 AND ED4000 SERIES

DeviceParts........................................................................................50-52

TrimParts..........................................................................................52-55

CROSSBAR EXIT DEVICES AND TRIMS

ED7000andED6000Series............................................................................43-49

DOOR CLOSERS

DC8000Series ..........................................................................................56

DC6000Series ..........................................................................................57

DC3000Series ..........................................................................................58

DC4600Series ..........................................................................................58

DC5000Series ..........................................................................................59

ELECTRONIC HARDWARE PARTS

DC46900Series .........................................................................................60

DC62900Series .........................................................................................60

Access 800®AC2Series ...................................................................................60

Terms and Conditions

ACCEPTANCE

Corbin Russwin reserves the right to decline an order, in whole or in part, when the type or quantity of goods or credit worthiness of the

Purchaser is not satisfactory to us in our sole and absolute discretion.

Purchase Orders, Quote Requests, Acknowledgements or the like issued by the Purchaser that have contrary standard terms and conditions are

not binding on Corbin Russwin, unless such terms and conditions are approved in a separate written agreement by Corbin Russwin's authorized

representatives. In the event of an acceptance of Purchaser’s Purchase Order by Corbin Russwin, the Purchaser agrees that such acceptance is

solely conditioned on Purchaser’s acceptance of the terms and conditions set forth in this instrument, regardless of the terms and conditions

specified in Purchaser’s Purchase Order. The te rms and conditions in Purchaser’s Purchase Order which conflict with the terms and conditions of

this instrument shall be disregarded and are hereby rejected, and this instrument shall constitute the entire agreement between Corbin

Russwin and the Purchaser.

In the event that Corbin Russwin does not enforce or require strict performance of any term or condition hereof, or of any other document,

instrument or other agreement relating to goods sold, such lack of enforcement or requirement of strict performance will not waive, affect or

diminish any right of Corbin Russwin to enforce or require strict performance of such term or condition in the future.

PRICES

All prices are subject to change without notice and are not guaranteed. All shipments will be made at prices in effect at the time of shipment.

Possession of this price list does not constitute an agreement to sell.

We reserve the right to correct clerical, stenographic and other obvious errors at any time.

TERMS

Invoices dated the 1st through the 15th will be due for 2% discount on the *10th of the following month. Invoices dated the 16th through the

31st will be due for 2% discount on the *25th of the following month. *Net immediately thereafter. (Corbin Russwin retains the right to sell or

to decline to sell to any Customer for any reason whatsoever when in its judgment is deemed sufficient.)

It is understood that Corbin Russwin may impose and charge a finance charge which is the lesser of one and one-half percent (1-1/2%) per

month or the highest rate allowed by law on any amount which becomes past due and delinquent. Additionally the Customer shall be

responsible for all collection costs, court costs and reasonable attorney’s fees (where allowed by law) in connection with the recovery of any

delinquent amount.

FREIGHT

All orders are shipped FOB factory/warehouse, except as expressly provided below. When delivered to the Transportation Company, the

Purchaser assumes the risk of loss or damage in transit. Customer orders with net product value in excess of $12,000.00 will be shipped prepaid

by Corbin Russwin’s carrier of choice to a single destination point in the United States.

Customer orders with net product value less than $12,000.00 will be shipped prepaid by Corbin Russwin’s carrier of choice and freight and

handling charges will be added to the customer's invoice. A minimum freight and handling charge of $15.00 will be charged on orders with

net product value of $400.00 or less. The minimum freight and handling charge will not apply to orders for only Cut (bitted) keys of any type,

Master Keys, Master keyed cylindres or padlocks and factory generated bitting lists that do not have any other product types included on the

order. Freight on these orders will be charged as the percentage of invoice value. For orders with net product value greater than $400.00 and

less than $12,000.00, freight charges will be calculated as a percentage fo the net invoice value and will be added to Customer's invoice. The

percentage is based on the National U.S. Average On Highway Diesel Fuel Prices as reported by the US Department of Energy in effect at the

beginning of each quarter. On the first Monday of each quarter, the new rate will be published on the Corbin Russwin and Door Security

Solutions extranet and will go into effect on the 2nd Monday of the quarter. Please refer to the extranet for the rate chart and information on

the current freight charge percentage. The percentage in effect at the time of shipment of the order will be charged. Great Grand Master keys,

Grand Master keys, Master keys, Construction Master keys, Control Keys, Lot Day Keys which are shipped separate from customer order for

security reasons, on orders with total net product value in excess of $12,000.00 will be shipped prepaid by Corbin Russwin’s carrier of choice. If

the total order value is less than $12,000.00, the shipping charges will be added to Customer’s invoice. If a customer provides their own freight

account # for the freight charges, Corbin Russwin will apply a handling fee of $25.00 to the invoice.

Quick Ship Orders – All 1-Week Quick Ship orders are guaranteed to ship from Corbin Russwin 5 working days after receipt of all information

necessary to process order or Corbin Russwin will pay freight costs. If Quick Ship is held for credit reasons Corbin Russwin will not be

responsible for freight costs.

Expedited shipping options – If the customer requests an expedited method of shipment such as “Next Day Air” the charges will be prepaid by

Corbin Russwin and the full rate for the service, as published by the carrier, will be added to the customer’s invoice.

Packing – Corbin Russwin will pack, mark and ship the products according to its standard procedures for shipment, unless the parties agree, in

writing, that Corbin Russwin will comply with any special instructions provided by the customer. Special instructions must be submitted, in

writing, at time of order placement. Compliance with special instructions may result in an increased price.

MINIMUM ORDER

Minimum order value for complete product is $250.00 net product value. The minimum order value for parts orders is $100.00 net product

value. In the event that the net product value does not meet the required net minimum, Corbin Russwin may, at its sole discretion (a) apply a

mimium order charge, (b) reject the order or (c) waive the minimum requirement provided that the waiver of the requirement for one order

shall not constitute a waiver of the requirement for any future orders. The following products are exempt from this policy: Cut (bitted) Keys of

any type, Master Keyed Cylinders, Master Keyed Padlocks and Factory Generated Bitting Lists.

QUOTATIONS

If Corbin Russwin elects to offer a quote, such quote will be valid until the expiration date on that quote. Complete shipment of the order must

be accepted by Purchaser within standard manufacturing lead times.

The quote number must be referenced on the order. Any invoiced order that has the incorrect discount applied to it and did not have the

quote number written on the order will have a service fee of $75.00 net DEDUCTED from any sales credit issued for the difference in discount.

The quote is null and void if the Purchase Order does not include ALL product lines listed on the quote or if the quantities for any item covered

by the quote deviate by 10% or more.

With the issuance and acceptance of a quote for the purchase of products, the Purchaser agrees that products so purchased will not be resold

or transferred to any Distributor not authorized by Corbin Russwin to sell its products. This would be inclusive of branches of the quoted

Distributor. Failure to abide by this restriction may result in the Distributor’s ineligibility for Quotations, or other actions in Corbin Russwin’s

discretion Corbin Russwin and its sales representatives reserve the right, in their sole discretion and for any reason, to refuse a Distributor’s

request to quote a price other than Corbin Russwin’s standard list price and regardless of whether Corbin Russwin or its sales representatives

have previously quoted discounted prices to the Distributor on some or all of its orders.

NON-CATALOGED PRODUCTS

Products not cataloged or listed in this price book will be considered as special products, and will not be manufactured without prior written

approval from Corbin Russwin.

A minimum special handling charge of $50.00 will be added for non-cataloged product. Any additional labor or material required will be

charged accordingly.

Terms and Conditions

January 1, 2014Parts Price List. TAC-1

Terms and Conditions

Terms and Conditions continued

Special products require special handling, and therefore standard lead times may not apply. Please consult with your Sales Representative for

further details.

CHANGES/CANCELLATION OF ORDERS

Changes or cancellations to an order will result in a charge of costs for material and labor expenses that have been incurred prior to

notification from Customer. If products have already been made and or are located in the shipping room, the 45% restocking fee will apply.

Handling charges are billed on Customer’s original order.

All Non-Cataloged Goods and Corbin Russwin Quick Ship Orders may not be changed or cancelled.

All change requests for goods, other than for the reasons stated above, must be submitted in writing to Customer Service within two (2)

business days of receipt of acknowledgment of the order.

ADD-ON ORDERS TO QUOTE

Any new order requesting special pricing to match an existing quote number, which has already been ordered, will be accepted up to sixty

(60) days after the acknowledgement of the original order. All add-on orders must reference the original factory order number, and the

corresponding quote number to receive the quoted pricing discount. Add-on orders for stock will not be accepted.

PACKAGING

Many items are defined as to Case Lot Packaging or Minimum Order. The Case Lot policy does not apply to hardware to be used on a specific

hardware project.

DELIVERY

Orders will be acknowledged and given a scheduled delivery date based on estimated manufacturing lead times. Complete information is

required to process all orders. Orders with insufficient information for processing (i.e. keying information, door sizes, handing, etc.) may be

subject to extended lead times which are relative to the time required in obtaining the necessary information for order processing.

Manufacturing lead time will begin once all information is received to process an order. Corbin Russwin will use reasonable efforts to deliver

products as estimated, but makes no guarantees as to delivery dates.

Corbin Russwin will not be liable for back charges incurred based on availability of product or as a result of delays in delivery caused by

insufficient information required to process an order.

Corbin Russwin will not be held responsible for delays in delivery caused by strikes, fires, floods or any other causes beyond our control,

including the delivery of material to us. Under no circumstances shall Corbin Russwin be liable or accountable for consequential damages due

to failure of delivery.

CLAIMS

In the event of Company or Customer error, claims for shortages, pricing errors and/or incorrectly filled orders must be submitted in writing to

Customer Service within thirty (30) days from receipt of material.

Any claims for shortages or damage by the Carrier must be made by the Customer directly to the Carrier.

INVOICE DEDUCTION

A Corbin Russwin Sales Representative or Customer Service Representative must be notified of any disputed invoices within sixty (60) days from

the date of invoice. Deductions should only be taken for the disputed amount and the balance of the invoice is due and payable within

standard payment terms.

RETURNED GOODS

It is the policy of Corbin Russwin to not accept returns of any materials that are correctly furnished as per the Distributor’s Purchase Order.

Return of product due to customer order error or accommodation must be pre-arranged with Corbin Russwin and approved in writing by Sales

Management.

All products returned as “Goodwill” must meet the following criteria to be considered a return:

• Be in original, unmarked and undamaged cartons.

• Be valued in excess of $250.00 net.

• Shipped and invoiced within the previous one hundred twenty (120) days.

• Custom, non-cataloged goods, master-keyed or Corbin Russwin Quick Ship product is not returnable.

AMINIMUM restocking fee of 45% will be charged. Upon receipt and verification by Corbin Russwin that the returned merchandise meets the

foregoing conditions, a credit will be issued for the original invoice amount less the MINIMUM 45% restocking fee.

Defective goods and “Goodwill” products that meet the foregoing criteria may be returned by fulfilling the following conditions:

• Send an RGA request in writing to the Corbin Russwin Sales Representative serving the Purchaser’s area.

• Ensure the RGA labels that are sent to Purchaser by Corbin Russwin are visible on return goods shipment.

• Ensure that the RGA number appears on the return shipment label and is legible.

• Return the authorized merchandise within sixty (60) days from the date of RGA issuance date.

• Return shipments must be freight prepaid to the location specified on the RGA.

• Corbin Russwin is not liable for damages to product during shipping.

No credit may be taken or issued prior to RGA approval and receipt of product.

All defective goods within the terms of our limited warranty may be returned for credit or replacement.

TAXES

Prices do not include any present or future Federal, State, or Local property, license, privilege, sales, use, excise, gross receipts or other like

taxes or assessments, which may result from transactions or any services performed in connection herewith.

GOVERNING LAW

The rights and obligations of the parties shall be governed by the laws of the State of North Carolina, excluding any conflicts of law provisions.

The United Nations Convention on Contracts for the International Sale of Goods shall not apply to this Agreement.

LIMITED WARRANTY

The Terms and Conditions outlined above are subject to Corbin Russwin’s Limited Warranty, which is included in this Price List and incorporated

herein by reference.

TECHNICAL INFORMATION AND ADVICE

(a) All designs, data, and specifications provided by Company are proprietary and will not be disclosed or reused by Customer without the prior

written consent of Company; (b) Company assumes no obligation or liability for any advice given by Company, the results obtained, or

damages incurred, and all such advice is given and accepted at Customer’s risk.

PRODUCT MODIFICATIONS

Corbin Russwin products are not designed or intended for aftermarket modification. The warranty on Corbin Russwin products becomes void

if the product is modified in any way, regardless of whether the modification causes or contributes to any alleged defect. Warranty voiding

modifications include, but are not limited to, third-party electrification of non-electric products and/or the installation of non-approved or

non-Corbin Russwin components.

If a Corbin Russwin product is modified it no longer meets industry certification and quality control standards applicable to the original

January 1, 2014Parts Price List. TAC-2

Terms and Conditions

January 1, 2014Parts Price List. TAC-3

Terms and Conditions continued

product and is no longer a genuine Corbin Russwin product. A modified product may not be sold as a Corbin Russwin product and the Corbin

Russwin and Design®trademark or certification marks based on the original Corbin Russwin product, such as U.L. or ANSI/BHMA marks, may

not appear anywhere on the modified product or on any packaging, literature, or instructions sold with the modified product.

All original Corbin Russwin packaging and literature carries the Corbin Russwin and Design®trademark and must be destroyed if the original

Corbin Russwin product is modified. Portions of the product that carry the Corbin Russwin and Design®trademark or certification mark must be

discarded and/or replaced by the party making the modification. U.L. and other certification testing and marking are also the responsibility of

the party making modification. The use of the Corbin Russwin and Design®trademark on modified products constitutes trademark

infringement.

FIRE RATED OPENINGS

Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the opening, and Corbin Russwin, Inc.

makes no representations or warranties concerning what such impact may be in any specific situation. When retrofitting any portion of an

existing fire-rated opening, or specifying and installing a new fire-rated opening,please consult with a code specialist or local code official

(Authority Having Jurisdiction) to ensure compliance with all applicable codes and ratings.

LIMITED WARRANTY

Corbin Russwin, Inc. (Company) warrants that its products sold under the Corbin Russwin and Design®trade name in the United States of

America are free from defects in workmanship and materials under normal use and service. This warranty does not cover defects or damage

arising from improper installation, lack of or improper maintenance, improper storage, shipping and handling, corrosion, erosion, ordinary

wear and tear, misuse, abuse, accident, unauthorized service, or use with unauthorized non-Corbin Russwin products or parts. This warranty is

void if any modification is made to the warranty product, regardless of whether the modification causes or contributes to the alleged defect.

All modifications are made at the risk of the party making the modification.

The only liability of the Company in tort or contract whether under this warranty or otherwise shall be limited to the repair or replacement of

any product or component part which shall prove defective as covered by this warranty, within the stated time frame listed below, after

delivery to the original purchaser.

PyramidCylinders ..................................................................................5years

CL3100SeriesCylindricalLocksets ....................................................................10years

CL3300 Series, CL3500 Series and CL3800 Series Cylindrical Locksets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 years

ML2000SeriesMortiseLocksets .....................................................................10years

ElectrifiedLocksets .................................................................................2years

ED6000,ED7000,ED8000SeriesExitDevices&Trim .......................................................1year

ED4000, ED5000 Series Exit Devices & 900 Series Trim . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 years

AllOtherExitDeviceTrim ............................................................................1year

ElectrifiedExitDevices ..............................................................................2years

FE5400S ..........................................................................................7years

FE6700 ...........................................................................................7years

FE6800 ...........................................................................................7years

Access 800®CL33800 x TCAC2 Cylindrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 years (mechanical), 2 years (electrical)

Access 800®ML20800 x TCAC2 Mortise Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 years (mechanical), 2 years (electrical)

Access 800®ED5000 x 9800 x TCAC2 Exit Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 years (mechanical), 2 years (electrical)

DC3000SeriesClosers .............................................................................15years

DC5000SeriesClosers ..............................................................................10years

DC6000SeriesClosers ..............................................................................25years

DC8000SeriesClosers .............................................................................25years

AllOtherCorbinRusswinProducts .....................................................................1year

Infini-T®Finish ....................................................................................Lifetime

MicroShield®Finish ..................................................................................1year

Finishes:

Corbin Russwin finishes are covered by a limited warranty period of one year after invoice date. Infini-T®finish is warranted against

corrosion and tarnishing for lifetime of the product.

Warranty Requirements for Cylinders Factory or Field Combinated:

Cylinders are lubricated at the factory with a petroleum based lubricant (Medeco KeyLube). Cylinders should be lubricated

periodically depending upon environmental conditions. Petroleum based lubricant is recommended. Never mix petroleum based

lubricants with dry lubricants. Corbin Russwin cylinder and/or core warranty will be voided if used in non-Corbin Russwin locking devices.

Warranty Requirements for Cylinders Field Combinated:

1. Keys shall be cut to the Corbin Russwin key bitting specifications required for the particular keyway and depth system.

2. All pin lengths shall be selected according to prevailing factory standards.

3. Original Corbin Russwin cylinders and cylinder components, including pin tumblers and key blanks, shall be used. We reserve the right to

void the warranty if we deem that a malfunction is a result of non-original components which do not conform to Corbin Russwin standards.

Keying Systems:

All bittings shall be originated or authorized by the Corbin Russwin Key Systems Department to be compatible with one another in a specific

type of cylinder (Pyramid, conventional, security, master ring, interchangeable core) and within a particular keying system.

All components of electromagnetic products are covered by a limited warranty period of one year after invoice date thereof of the original

purchaser from us. Product repair or replacement, or associated charges, will not be accepted under this warranty unless prior authorization

from Corbin Russwin has been given. Upon receipt of products returned for repair or replacement, we will determine whether products qualify

for repair or replacement under this warranty. If they do not, we will obtain authorization prior to proceeding. We have no liability to pay any

costs of repair performed by anyone other than qualified personnel authorized by Corbin Russwin prior to the work being done.

The Company will not pay for the cost of repair performed other than in accordance with this warranty. Written notice of a product or

component part believed to be defective as covered by this warranty should be sent to Corbin Russwin, Inc. 225 Episcopal Road, Berlin, CT

06037, and should include your name and address, an identification of the product or component part and a brief description of the defect.

Upon receipt of such notice, the Company will inform you where to ship such product or component part, shipping charges prepaid, for

examination and, in the event such examination reveals defect covered by this warranty, the product will be repaired or replaced. The

Company reserves the right to replace discontinued product with an equivalent product as deemed by the Company.

THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES. TO THE EXTENT PERMITTED BY LAW, ALL IMPLIED WARRANTIES ARE

LIMITED TO THE DURATION OF THIS WARRANTY. CORBIN RUSSWIN, INC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL

DAMAGES. NO AGENT, SALES REPRESENTATIVE OR DEALER HAS THE AUTHORITY TO INCREASE OR ALTER THE OBLIGATIONS OF THIS

WARRANTY. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR LIMITATION

OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES

YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.

Service Center Business Hours

January 1, 2014Parts Price List. TAC-4

ASSA ABLOY Door Security Solutions®Customer Service Center

8:00 a.m. – 4:30 p.m. (Eastern)

1902 Airport Road

Monroe, NC 28110

Telephone Number: (800) 543-3658

Fax Number: (800) 447-6714

Technical Product Support

8:00 a.m. - 4:30 p.m. (Eastern)

225 Episcopal Road

Berlin, CT 06037

Telephone Number: (888) 607-5703

Fax Number: (800) 659-7293

Technical Electrified Product Support

8:00 a.m. - 4:30 p.m. (Eastern)

Telephone Number: (800) 810-WIRE (9473)

Fax Number: (203) 603-5981

The ASSA ABLOY Door Security Solutions Service Center and Electrified Technical Product Support, Monroe, NC will be

CLOSED on the following dates:

January 1, 2014

April 18, 2014

May 26, 2014

July 4, 2014

September 1, 2014

November 27, 2014

November 28, 2014

December 24, 2014

December 25, 2014

December 31, 2014

* Dates subject to change.

Technical Product Support, Berlin, CT will be CLOSED on the following dates:

January 1, 2014

April 18, 2014

May 26, 2014

July 4, 2014

September 1, 2014

November 27, 2014

November 28, 2014

December 24, 2014

December 25, 2014

December 26, 2014

December 29, 2014

December 30, 2014

December 31, 2014

* Dates subject to change.

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

018F91 33

018F92 34

019F01 33

019F10 34

019F11 34

019F11 37

019F13 33

019F13 36

019F14 33

019F15 37

019F30 33

019F31 33

019F32 33

021F68 3

021F71 3

022F72 34

022F72 37

022F80 33

022F80 36

024F86 33

024F92 33

024F93 33

025F29 33

025F72 2

025F85 25

025F85 29

026F75 2

039F19 34

040F70 33

041F47 3

049F94 34

055F67 34

055F68 33

060F05 37

060F33 36

060F42 36

060F91 37

065F36 2

067F00 33

067F42 36

069F78 37

070F42 36

070F43 36

071F62 36

071F63 36

071F67 37

072F44 33

077F19 49

078F07 36

078F08 36

079F00 7

079F02 7

079F75 33

081F77 36

082L67 37

083L96 37

092F78 37

095F35 44

102F19 37

102F27 37

102F37 37

103F44 37

103F45 37

105F70 2

107F93 37

111F55 2

114F67 37

118F29 16

118F29 55

118F48 10

120F55 44

120F76 8

120F76 23

120F76 25

120F76 29

120F76 31

120F76 34

120F76 35

121F01 2

121K10 1

121K11 1

121K12 1

121K13 1

121K14 1

121K15 1

121K16 1

121K85 1

121K86 1

122F18 44

122F24 44

122F41 44

122F50 44

122F51 44

122F56 44

122F57 44

122F59 44

122F60 44

122F61 44

122F63 44

122F64 44

123F22 43

123F53 40

123F53 44

129F49 44

129F84 3

129F84 44

131F27 36

133F41 37

134F05 4

134F05 44

135F10 3

135F19 2

135K04 1

135K05 1

138F88 36

140F52 44

140F97 36

141F41 44

141F84 44

141F86 44

141F87 44

141L54 44

141L59 44

142F16 44

142F43 43

142F44 44

142F92 33

143F24 44

143F25 44

143F26 44

143F42 44

143F43 44

143F52 44

143F83 44

144F29 33

144F29 37

144F30 37

144F33 36

144F34 36

144F88 37

144F89 37

145F32 37

145F54 44

146F78 3

146K80 1

147F07 36

147F08 37

147F42 33

147F77 2

147F83 44

147F84 44

147F87 44

147F88 44

148F15 44

148F17 44

148F22 44

148F36 44

148F44 44

154F96 44

156F36 37

156F43 36

156F64 37

156F65 37

156F83 36

157F11 33

157F11 36

158F06 3

158F52 44

158F53 44

158F54 44

158F55 44

159F36 2

164F32 44

166F34 44

168F58 33

168F71 33

168F74 34

168F75 34

168F77 33

168F79 33

168F81 33

168F81 37

168F92 33

171F46 2

171F79 36

171F89 44

171F90 44

172F21 2

173F44 44

173F45 44

173F69 44

173F72 44

173F79 3

174F79 44

174F80 44

175F51 44

176F65 43

176F85 39

176F86 39

176F87 39

176F88 39

183F74 44

183F75 44

183F85 43

184F57 44

184F82 44

184F94 44

184F97 44

185F55 44

186F23 44

186F74 3

186K75 1

187F07 37

187F21 44

187F88 44

187F89 44

188F03 57

188F03 58

188F03 60

188F19 57

188F19 58

188F19 60

188F41 56

188F41 57

188F41 58

188F62 56

188F62 57

188F62 58

188F63 56

188F63 57

188F63 58

188F65 57

188F65 58

188F73 37

188F75 37

193F94 39

193K09 1

193K10 1

193K11 1

194F22 36

195F67 44

195K68 1

197F32 5

197F34 3

197F35 3

197F52 2

197F87 34

197F88 34

197K51 1

198F71 36

199F70 44

200F16 45

201F18 37

202F33 37

205F61 33

206F53 16

206F57 39

207F55 44

207F64 44

207F68 44

207F69 44

208F80 36

209F55 44

213F10 44

213F11 45

216F38 33

217F42 2

217F43 2

217F43 3

217F44 2

217F44 3

217L13 23

217L13 25

217L13 27

217L13 29

217L13 31

217L13 34

217L13 35

218F08 37

219F80 34

Part Number Index

January 1, 2014Parts Price List. A

Part Number Index

January 1, 2014Parts Price List. B

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

219F88 3

219F89 33

220F49 45

220F72 45

220F75 45

220F77 45

220F82 45

220F84 45

220F85 45

221F08 49

221F51 39

221F94 45

222F71 45

222F76 39

222F85 37

223F29 37

224F00 34

224F34 45

224F39 45

224F44 45

224F50 45

225F99 45

227F85 33

228F18 45

228F34 38

228F38 39

228F49 45

228F51 45

228F52 45

228F54 16

228F55 45

228F68 45

228F80 45

228F81 45

228F84 45

233F64 39

236L70 8

236L72 8

236L73 9

236L74 9

236L75 37

240L50 43

240L51 43

240L53 35

240L72 39

242F48 38

242F50 37

243F76 45

243F79 45

243F80 45

243F85 45

244F17 56

244F17 57

244F17 58

244F64 38

245K37 1

249F33 45

249F76 37

249F77 37

250F08 3

251F19 37

252F82 4

253F11 45

253F75 3

253F76 3

253F77 3

253F85 3

253F97 4

253K66 1

253K67 1

254F73 45

255F41 45

255F53 4

255F54 5

261F11 37

261F28 45

261F29 38

261F29 45

261F30 41

261F31 45

261F54 4

261F54 45

261F55 5

261F65 45

261F68 39

261F95 57

261F95 60

262F90 45

262F94 39

264F69 13

264F95 45

266F34 2

267F34 45

267F97 4

268F64 45

268F84 45

268F87 45

269F04 45

269F05 45

269F08 45

269F09 45

269F12 45

269F31 45

269F32 45

269F33 45

269F34 45

269F35 45

269F36 45

269F37 45

269F39 45

269F40 45

269F41 45

269F42 45

269F46 45

269F47 45

269F48 45

269F49 45

269F52 45

269F53 45

269F54 45

269F55 45

269F56 45

269F57 45

269F58 45

269F60 45

269F65 43

269F66 43

269F67 43

269F68 43

269F69 43

269F70 43

269F71 43

269F72 43

269F73 43

269F74 43

269F75 43

269F76 43

269F91 45

269F92 45

270F01 45

270F02 45

270F11 45

270F13 41

270F15 4

270F24 33

281F27 2

282F32 45

282F35 45

283F81 38

284F13 3

284F67 45

284F68 46

284F69 46

284F70 46

284F76 46

284F78 46

284F79 46

284F97 46

286F50 36

286F91 46

286F92 46

287F60 37

287F96 46

288F71 39

291F49 46

291F57 46

292F41 46

292K95 1

292K96 1

292K97 1

292K98 1

292K99 1

293F18 46

293K00 1

293K01 1

293K02 1

293K03 1

293L14 37

294F05 2

294F38 57

294F40 57

294F44 57

294F45 57

300F68 5

300F68 17

300F68 34

300F71 43

301F56 36

301F59 5

301F61 5

301F62 5

301F65 5

303F18 17

303F19 17

303F20 17

303F24 38

303F25 4

304F33 43

304F34 43

304F65 46

304F66 46

305F07 46

305F72 46

305F73 46

306F06 46

306F07 46

306F15 46

306F20 46

306F22 46

308F78 2

310F48 3

312F23 34

312F24 34

312F25 33

312F26 33

312F34 33

314F52 46

314F71 46

314F88 2

314F98 2

314F99 3

315F93 23

315F93 34

315F94 23

315F94 34

317F64 33

317F68 36

317F71 32

318F64 9

318F65 9

318F66 9

318F67 9

318F68 9

318F69 9

320F44 3

320F44 34

320F44 37

321F23 40

321F24 40

321F24 49

321F90 46

326F73 46

328F80 41

329F75 46

329F76 46

329F99 3

330F10 58

333F51 46

333F85 39

333F86 39

333F99 3

334F12 3

334F13 2

334F23 3

334F99 49

334K00 1

334K01 1

335F97 34

335F98 37

336F04 33

340F27 16

340L60 9

340L61 9

340L62 9

340L63 9

341F31 46

342F03 34

342F03 37

342F05 36

349F01 33

349F06 46

351F50 46

351F51 46

351F52 46

351F55 46

351F56 46

351F57 46

351F72 46

351F73 46

351F79 46

Part Number Index

January 1, 2014Parts Price List. C

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

351F80 46

351F82 46

351F83 46

351F84 46

351F85 46

351F86 46

351F87 46

351F88 46

351F89 46

351F90 46

351F98 46

352F02 46

352F03 46

352F04 43

352F05 43

352F06 46

352F07 46

353F86 3

354F19 3

361F30 46

361F91 43

362F15 3

362F15 38

362F42 2

362F43 2

362F49 46

362F50 2

362F91 46

364F22 46

364F27 46

364F28 46

364F30 46

364F36 46

364F37 46

364F38 46

364F39 46

365F00 46

365F01 46

365F03 46

365F95 3

365F96 3

365F98 46

366F70 5

368F91 3

370F29 4

370F31 4

370F33 5

370F35 5

370F55 46

370F56 46

370F63 46

376F37 44

376F42 46

377F30 14

377F80 12

377F81 33

378F32 22

378F74 46

378F84 36

378K18 1

379F25 46

379F26 46

379F80 3

381F30 36

381F94 39

382F63 46

382F68 46

382F69 47

382F72 47

382F78 47

382F79 47

382F80 47

382F81 47

382F82 47

382F85 47

382F86 47

382F87 47

382F88 47

382F91 48

382F92 48

382F93 48

382F95 47

382F98 47

383F35 39

383F65 32

383F66 32

383F67 32

383F68 32

383F69 32

383F70 32

383F82 12

384F03 16

384F11 12

385F54 40

386F15 47

386F45 41

387F21 40

387F24 40

387F27 40

387F30 40

387F40 57

387F40 58

387F40 60

387F63 40

387F66 40

387F69 40

387F72 40

387F93 34

387F95 34

389F54 47

389F62 47

391F57 41

391F64 40

391F65 5

391F65 14

391F65 33

391F88 47

391F90 47

391F91 47

391F94 47

391F96 47

391F99 47

392F02 47

392F05 47

392F08 47

392F10 47

392F11 47

392F14 47

392F22 43

392F23 47

392F24 43

392F27 47

392F28 43

392F29 43

392F30 47

392F72 3

392F73 3

392L19 47

392L20 47

393L13 47

393L14 47

394F19 38

394F31 39

397F91 47

397F99 47

398F43 33

398F43 36

398F57 33

398F58 33

398F59 33

398F64 32

398F65 32

398F66 32

398F69 33

398F69 47

398F70 33

398F71 32

398F72 32

398F75 32

398F85 34

398F87 32

398F88 32

398F89 47

398F91 47

398F94 47

398F95 47

398F99 47

399F00 47

399F01 47

399F02 47

399F05 47

399F06 47

399F07 47

399F10 47

399F12 47

399F13 47

399F17 49

399F18 47

399F21 47

399F22 47

399F23 47

399F25 47

399F45 34

399F48 4

399F50 34

399F51 34

399F58 47

399F61 32

399L11 47

400F07 33

400F17 32

401F00 32

401F08 37

402F29 7

402F30 7

402F31 7

402F33 7

402F34 7

402F35 7

402F61 8

402F73 7

402F98 49

402F99 47

402F99 49

403F03 47

403F15 43

403F16 43

403F17 43

403F18 43

403F30 47

403F56 8

403F66 8

403F67 7

404F67 33

404F85 8

404F86 7

405F09 33

405F10 33

405F42 47

405F45 47

405F46 47

405F47 47

405F49 47

405F77 38

405L13 9

405L14 9

406F22 32

406F32 32

406F33 32

406F34 32

406F35 32

406F36 32

406F37 32

406F43 2

406F88 34

407K63 1

407K64 1

407K65 1

407T31 2

407T32 2

407T33 2

407T41 2

407T42 2

407T43 2

408F25 49

409F19 39

409F33 39

409F34 39

409F83 47

410F13 47

410F14 47

410F20 47

410F66 33

411F92 5

411F96 47

411F98 47

411L62 9

411L62 43

411L63 9

411L63 43

412F03 47

412F06 47

412F07 47

412F08 47

412F09 47

412F11 47

412F13 47

412F15 48

412F16 48

412F30 48

412F31 48

412F32 48

412F45 48

413F20 39

413F21 39

413F22 2

413F25 39

413F31 39

413F48 3

413F49 3

Part Number Index

January 1, 2014Parts Price List. D

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

413F60 33

414F36 39

414F81 43

414F82 43

414F91 39

415F15 36

415F16 36

415F27 36

415K73 1

415K74 1

416F35 43

416F38 38

416F39 4

416F49 8

416F81 48

416F84 8

416K07 1

416K08 1

418F08 34

418F28 48

418F30 48

418F35 48

418F36 48

418F37 48

420F04 48

420F05 48

420F08 48

420F09 48

420F12 48

422F88 4

422L84 38

423F49 3

423F54 7

423F55 7

423F57 7

423F58 7

423L71 38

424F42 43

424F43 43

424F50 43

424F51 43

424F52 43

424F83 38

425F86 7

427F06 10

427F07 10

427F36 11

427F37 11

427F39 11

427F43 11

427F45 11

427F47 11

428F32 10

428F33 10

428F34 10

428F66 4

429F08 8

429F18 39

429F19 39

429F31 16

429F41 8

429F52 39

429F70 58

429F71 58

429F72 58

429F72 60

429F73 58

430F47 13

430F79 39

431F25 33

431F26 33

431F27 33

431F28 33

431F29 33

432F86 17

433F48 12

433F49 12

433F50 12

433F76 17

433F77 17

433F78 17

433F97 48

433F98 48

433F99 48

434F00 48

434F02 48

434F04 48

434F05 48

434F20 48

434F21 48

434F22 48

434F23 48

434F24 48

434F25 48

434F26 48

434F27 48

435F00 13

435F57 58

435F69 58

435F70 58

436F03 43

436F17 8

436F25 40

436F29 40

436F41 40

436F42 40

436F43 40

436F44 40

436F80 41

436F81 41

436F82 41

436F83 41

436F85 40

436L32 40

437F16 10

437F26 10

437F28 10

437F40 10

437F41 10

437F42 10

438F37 10

438F38 10

438F41 3

438F42 3

438F79 32

438F90 13

439F25 10

439F26 10

439F27 10

439F31 10

439F33 17

439F34 17

439F35 17

439F63 11

442F95 36

444F74 3

444F75 3

444K87 1

444K88 1

444K89 1

444K94 1

444K96 1

444K97 1

444K98 1

444K99 1

445F31 17

445F38 14

445F41 17

445F43 14

445F82 16

445F83 16

445F84 16

445F85 17

445F86 16

446F10 58

446F20 41

446F21 41

446F22 41

446F23 40

446F57 3

446F58 3

446K68 1

447F14 56

447F14 57

447F24 16

447F25 16

447F41 4

447F42 4

447F43 4

447F44 5

447F45 5

447F46 5

449F82 41

461F10 3

461F84 58

461F85 58

463F91 43

463F92 41

464F02 48

464F91 48

464K97 1

465F57 8

466F22 8

466F27 39

466F40 10

466F41 10

466F42 10

466F45 10

466F46 10

466F47 10

466F50 10

466F51 10

466F52 10

466F65 10

466F66 10

466F67 10

466F70 10

466F71 10

466F72 10

466F73 10

466F74 10

466F75 10

467F01 17

467F33 38

467F34 38

467F35 38

467F36 38

467F37 38

467F73 43

467F94 48

467F95 48

468F02 48

468F03 48

468F12 48

468F13 48

468F14 48

468F15 48

468F16 48

468F17 48

468F20 48

468F21 48

468F24 48

468F25 48

468F26 48

468F27 48

468F30 41

468F34 57

468F34 58

468F35 48

468K87 1

469F27 32

469F28 32

469F29 32

469F30 32

469F31 32

469F32 32

469F33 32

469F34 32

469F35 32

469F36 32

469F37 32

469F38 32

469F67 41

469F68 41

480F06 2

480F12 48

480F13 48

480F18 48

480F19 48

480F20 48

480F28 48

480F30 48

480F33 48

480F37 48

480F68 21

480F68 34

480F69 38

480F70 19

480F70 37

480F70 38

480F70 39

482F37 10

482F44 48

482F49 48

482F73 48

482F75 32

482F79 40

483F11 14

483F30 10

483F34 10

483F35 10

483F36 10

483F44 58

483F79 16

483F80 16

483F81 16

483F82 16

483F83 16

483F84 16

483K01 1

Part Number Index

January 1, 2014Parts Price List. E

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

484F20 41

484F21 41

484F41 48

484F74 8

484F76 13

484F89 48

484F91 3

484F92 3

484F93 3

484F94 3

484F95 3

484F96 3

485F29 39

485F49 40

486F83 32

486F84 32

486F89 32

486F90 32

487F08 16

487K10 1

487K11 1

487K12 1

487K13 1

487K14 1

487K15 1

487K16 1

487K17 1

487K18 1

487K19 1

487K20 1

487K21 1

487K22 1

487K23 1

487K24 1

487K25 1

487K38 1

487L04 41

487M04 41

487M04 43

488F00 13

488F01 13

488F03 12

488F04 12

488F05 12

488F07 12

488F08 3

488F08 10

488F09 8

488F10 3

488F10 10

488F27 10

488F30 10

488F31 10

488F32 10

488F33 10

488F82 39

488F83 39

488F92 3

488F97 57

488F97 58

488K84 1

488K85 1

488K98 1

488K99 1

489F02 3

489F88 36

489F89 36

489K49 1

490F55 3

492F19 48

492F20 41

492F21 41

492F59 41

492F76 57

492K90 1

492K91 1

492K92 1

493F29 2

493F31 16

493F34 16

493F76 1

493F77 1

493F78 1

493F99 33

493F99 36

494F72 60

494F74 60

494F75 60

494F76 60

494F77 60

494F83 60

494F86 60

494F92 60

494F93 60

494F94 60

496F32 36

496F33 36

496F34 36

496F59 19

496F68 41

496F69 41

496F71 38

496F78 19

496F80 3

496F84 19

496F89 19

496F97 19

496F98 19

496F99 19

496L90 19

497F00 19

497F01 19

497F02 19

497F19 19

497F20 19

497F22 19

497F23 19

497F24 19

497F25 19

497F26 19

497F41 19

497F52 16

497F79 19

497F80 19

497F81 19

497F82 19

497F83 19

497F86 19

497F87 19

497L91 19

498F79 19

498F84 17

498F85 17

498F86 14

498F87 14

498F92 17

499F30 56

499F43 19

499F46 19

499F49 43

499F50 43

499F53 43

499F54 43

499F57 43

499F58 43

499F59 43

499F60 48

499F82 16

499F83 16

499F84 16

499F86 16

499F87 16

499F88 16

499F90 16

499F91 16

499F92 16

501F08 19

501F09 19

502F10 14

502F27 14

502F29 14

502F39 43

502F40 43

502F46 43

502F47 43

502F62 14

502F68 43

502F70 43

502F75 43

502F77 43

502F80 43

502F88 43

559F20 43

502F89 43

502F96 43

503F15 14

503F34 43

503F35 43

503F36 43

503F37 43

503F52 43

503F53 43

503F53 49

503F55 49

503F56 49

506F57 5

507F01 14

507F51 43

507F52 43

507F55 43

507F56 43

507F59 43

507F60 43

507F61 43

507F62 43

507F67 43

507F68 43

509F49 56

509F49 57

509F49 58

509F54 19

510F64 19

510F65 19

510F67 19

510F69 19

510F71 19

511F51 10

511F52 10

511F73 14

518F06 41

518K73 1

518K74 1

519F09 17

519F09 39

519F10 17

519F10 39

519F11 17

519F11 39

519F12 17

519F12 39

520F35 3

522F93 3

522K76 1

522K91 1

523F03 41

523K21 1

525F99 40

526F16 40

526F32 40

526F47 19

526F49 19

526F52 41

526F53 41

526F66 2

526L51 40

526L92 41

534F00 41

534K25 1

535F21 41

535F22 41

535F27 41

536F54 10

540F10 58

540F11 58

540F12 58

540F13 58

540F27 58

540F40 56

544F13 13

544F14 13

544F38 13

544F39 13

544F40 13

544F41 13

544F42 13

544F43 12

544F44 13

544F45 13

544F46 12

544F76 12

544F77 12

544F79 12

544F80 12

544F82 12

544F83 12

544F84 12

544F85 12

544F87 12

544F88 12

544F89 12

544F91 12

544F92 12

544F93 12

544F94 12

544F95 12

544F96 12

544F97 12

544F98 12

544F99 12

545F00 12

Part Number Index

January 1, 2014Parts Price List. F

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

545F42 12

545F43 12

545F44 12

545F45 12

545F69 11

545F79 11

545F80 11

545F82 11

545F83 11

545F84 11

545F85 11

545F86 11

545F87 11

545F88 11

545F89 11

546F97 2

547F98 22

549F14 19

549F15 19

549F35 36

549F36 36

549F52 4

550F50 3

552F36 40

552F41 40

552F46 40

552F47 40

552F59 40

552F60 40

553F48 2

553F49 2

553F50 2

556F55 34

557F29 12

557F92 41

557F93 41

557F94 41

557F95 41

557L30 19

557L31 19

557L36 19

557L37 19

558F52 40

558F80 43

558F81 43

558F86 43

558F87 43

559F30 43

559F33 43

559F60 43

559F61 43

559K94 1

559K95 1

561F19 32

561F29 48

562F40 2

562F42 3

563F01 3

563F88 20

563F88 42

563F89 20

563F89 42

563F90 20

563F90 42

563F94 20

563F94 42

563F95 20

563F95 42

563F96 20

563F96 42

564F11 40

564F12 41

564F34 40

564F37 40

564F40 40

564F43 40

564F68 40

564F88 40

564F89 40

564F90 40

564F91 40

564K52 1

564K53 1

564K60 1

565F04 8

566F50 55

566F51 55

568F11 14

568F12 14

569F45 16

574F15 5

574F25 35

574F26 35

574F29 35

574F30 35

574F55 35

574F56 35

574K05 1

574K07 1

575F57 32

575F58 32

575F59 32

575F60 32

575F61 32

575F62 32

575F63 32

575F64 32

575F65 32

575F66 32

575F67 32

575F68 32

577F54 32

577F59 32

578F43 20

578F43 42

579F11 35

579K14 1

580F37 35

580F38 35

580K99 1

581F96 17

581F96 39

582F05 39

582F11 36

582F12 36

582F13 36

582F14 36

582F29 3

583F79 19

584F46 16

584F77 22

584F85 22

584F89 22

584F90 22

584F91 22

584F93 22

585F31 3

585F32 2

585F33 3

585F35 3

585F36 3

585F37 3

585F38 3

585F39 2

585F40 3

585F70 20

585F70 42

585F71 20

585F71 42

585F72 21

585F72 42

585F76 22

585F76 24

585F76 26

585F76 28

585F77 22

585F77 24

585F77 26

585F77 28

585F78 22

585F79 22

585F79 26

585F79 28

585F81 22

585K24 1

585K25 1

585K26 1

585K27 1

586F16 21

586F17 21

586F18 21

586F51 23

586F51 27

586F51 29

586F62 22

586F80 21

586F81 21

586F82 21

586F83 22

586F86 21

586F87 21

586F88 21

586L19 23

586L19 27

586L19 29

586L19 31

586L19 34

586L19 35

590F28 3

596F54 23

596F61 21

596F61 34

596F62 21

596F62 34

596F63 34

596F66 21

596F67 21

596F68 21

596F80 22

596F82 20

596F82 42

596F87 3

596F89 3

596K29 1

596K30 1

596K31 1

596K32 1

597F24 58

597F35 58

597F52 56

597F52 57

597F52 58

597F58 57

597F58 58

597F59 57

597F78 57

597F78 58

597F78 60

597F92 56

597F92 57

597F93 56

597F93 57

597F94 57

597F94 58

597F95 57

597F95 58

597F96 57

597F96 58

597F97 57

597F97 58

598F20 21

598F21 21

598F22 21

598F27 29

598F29 27

598F54 27

598F59 23

598F59 25

598F59 26

598F59 29

598F71 26

598F80 25

598F80 26

598F81 25

598F81 26

598F81 29

598F82 25

598F82 26

598F82 29

598F83 25

598F83 29

598F84 26

598F85 26

598F86 26

598F90 25

598F90 26

598F90 29

598F91 26

598F94 26

598F97 26

599F21 26

599F22 26

599F23 26

599F24 26

599F25 26

599F26 26

599F27 26

599F27 29

599F28 26

599F29 26

599F30 26

599F31 26

599F32 26

599F37 26

599F38 3

599F91 24

599F91 26

599F91 28

599F92 24

599F92 26

Part Number Index

January 1, 2014Parts Price List. G

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

599F92 28

599F93 24

599F93 26

599F93 28

599F94 24

599F94 26

599F94 28

599F95 24

599F95 26

599F95 28

599F96 24

599F96 26

599F96 28

599F97 24

599F97 26

599F97 28

599F98 24

599F98 26

599F98 28

599F99 24

599F99 26

599F99 28

600F03 24

600F03 26

600F03 28

600F04 24

600F04 26

600F04 28

600F05 24

600F05 26

600F05 28

600F06 24

600F06 26

600F06 28

600F07 24

600F07 26

600F07 28

600F08 24

600F08 26

600F08 28

600F09 24

600F09 26

600F09 28

600F10 24

600F10 26

600F10 28

600F11 24

600F11 26

600F11 28

600F41 20

600F41 42

600F42 20

600F42 42

600F62 24

600F62 26

600F62 28

600F63 24

600F63 26

600F63 28

600F64 24

600F64 26

600F64 28

600F68 24

600F68 26

600F68 28

600F69 24

600F69 26

600F69 28

600F70 24

600F70 26

600F70 28

601F22 3

601F24 21

601F25 21

601F26 21

601F28 23

601F28 34

601F69 21

601F82 23

602F15 41

602F17 41

602F18 41

602F19 7

603F20 2

603F55 57

603F55 60

603F57 57

603F57 60

603F64 41

604F22 21

604F22 25

604F22 26

604F22 29

604F22 31

604F22 34

604F23 21

604F23 26

604F23 34

604F24 21

604F24 26

604F24 34

604F25 26

604F25 34

604F26 21

604F26 25

604F26 26

604F26 29

604F26 31

604F26 34

604F27 21

604F27 26

604F27 34

604F28 21

604F28 26

604F28 34

604F29 26

604F29 34

605F42 10

605F43 4

605F76 37

605F77 37

605F80 37

605F81 37

605F90 36

605F91 36

606F01 37

606F02 37

606F03 36

606K73 1

606K74 1

606K75 1

606K76 1

606K77 1

606K78 1

606K79 1

607F76 27

607F91 3

607K17 1

609F36 4

609F37 4

609F38 4

610F01 4

610F02 4

610F49 1

610K46 1

610K48 1

610L43 37

610L44 37

612K88 1

612K90 1

612K91 1

612K93 1

612K94 1

613F02 36

613F10 36

613F11 36

613F12 36

613F13 36

613F14 36

613F15 36

613F16 36

613F17 36

613F22 36

613F23 36

613F24 36

613F25 36

613F35 36

613F42 36

613F43 36

615F27 57

615F29 57

615F31 57

615F32 57

615F33 57

615F37 57

615F39 57

615F51 56

615F51 57

615F52 56

615F52 57

615F53 56

615F53 57

615F54 56

615F54 57

615F55 56

615F55 57

615F56 56

615F56 57

615F58 56

615F58 57

615F59 56

615F59 57

615F60 56

615F60 57

615F61 57

615F62 57

615F63 57

615F64 57

616F07 16

616F08 16

616F12 8

616F20 3

616F21 3

622F29 3

622F30 3

622F30 20

622F30 24

622F30 28

622F32 3

622F68 48

622F69 3

622F72 3

624F42 8

624F43 8

624F44 8

624F45 8

624F47 8

624F48 7

624F49 7

624F53 7

626F07 2

628F10 2

628F82 3

628F83 3

628F89 2

628F91 2

628F92 2

628F96 2

628K85 1

628K87 1

628K88 1

628K90 1

628K95 1

628K97 1

628K99 1

629F07 2

629F96 2

629K00 1

629K01 1

629K02 1

629K03 1

629K04 1

630F48 2

630K47 1

649F99 50

650F00 50

650F01 50

650F02 50

650F03 50

650F04 50

650F05 50

650F06 50

650F07 50

650F08 50

650F09 52

650F10 52

650F11 50

650F12 50

650F13 50

650F14 50

650F15 50

650F16 50

650F18 50

650F21 50

650F22 50

650F23 50

650F24 50

650F27 51

650F28 51

650F29 51

650F30 51

650F31 51

Part Number Index

January 1, 2014Parts Price List. H

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

650F35 50

650F36 50

650F37 50

650F38 50

650F39 50

650F40 50

650F41 50

650F42 50

650F43 50

650F44 50

650F45 50

650F46 50

650F48 52

650F49 52

650F50 51

650F51 51

650F52 50

650F53 51

650F54 52

650F55 52

650F56 52

650F57 51

650F58 50

650F59 50

650F60 52

650F62 51

650F63 51

650F64 50

650F67 51

650F69 51

650F71 52

650F72 52

650F73 52

650F77 50

650F79 50

650F80 52

650F81 52

650F82 51

650F87 51

650F88 51

650F93 50

650F95 51

650F96 50

650F97 51

650F99 50

650L65 51

651F00 54

651F01 54

651F04 54

651F06 54

651F08 54

651F09 54

651F10 54

651F28 55

651F36 55

651F37 55

651F38 55

651F39 55

651F40 55

651F41 55

651F42 55

651F43 55

651F44 55

651F47 55

651F49 55

651F50 55

651F53 55

651F54 55

651F55 55

651F56 55

651F57 55

651F58 55

651F60 55

651F61 55

651F62 55

651F63 55

651F64 55

651F65 55

651F67 55

651F70 55

651F71 55

651F73 55

651F75 55

651F77 55

651F78 55

651F79 55

651F82 55

651F83 55

651F84 55

651F85 55

651F86 55

651F87 55

651F88 55

651F89 55

651F92 55

651F93 55

651F94 55

651F96 55

651F97 55

651F98 55

652F04 55

652F05 55

652F06 55

652F07 55

652F08 55

652F09 55

652F10 55

652F11 55

652F12 55

652F13 55

652F14 55

652F15 55

652F19 55

652F21 55

652F22 55

652F23 55

652F29 51

652F57 52

652F58 52

652F58 53

652F59 52

652F59 53

652F60 52

652F61 52

652F61 53

652F62 52

652F62 53

652F63 52

652F64 52

652F64 53

652F65 52

652F65 53

652F66 52

652F67 52

652F67 53

652F68 52

652F68 53

652F69 52

652F70 52

652F70 53

652F71 52

652F71 53

652F72 52

652F73 52

652F73 53

652F74 52

652F74 53

652F75 52

652F76 52

652F76 53

652F77 52

652F77 53

652F78 52

652F79 52

652F79 53

652F80 52

652F80 53

652F81 52

652F82 52

652F82 53

652F83 52

652F83 53

652F84 52

652F85 52

652F86 52

652F87 52

652F88 52

652F89 52

652F90 52

652F91 52

652F92 52

652F93 52

652F94 52

652F95 52

652F96 52

652F97 52

652F98 52

652F99 52

653F00 52

653F01 52

653F02 52

653F03 52

653F04 52

653F05 52

653F06 52

653F07 52

653F08 52

653F09 52

653F10 52

653F12 50

653F13 50

653F14 50

653F50 52

653F50 53

653F51 52

653F51 53

653F52 52

653F52 53

653F53 52

653F53 53

653F54 52

653F54 53

653F55 52

653F55 53

653F56 52

653F56 53

653F57 52

653F57 53

653F58 52

653F58 53

653F59 52

653F59 53

653F60 52

653F60 53

653F61 52

653F61 53

653F62 52

653F62 53

653F63 52

653F63 53

653F64 52

653F64 53

653F65 52

653F65 53

653F66 52

653F66 53

653F67 52

653F67 53

653F68 52

653F68 53

653F69 52

653F69 53

653F70 52

653F70 53

653F71 52

653F71 53

653F72 52

653F72 53

653F73 52

653F73 53

653F74 52

653F74 53

653F75 52

653F75 53

653F76 52

653F76 53

653L15 51

653L16 51

653L18 51

654F07 4

654F08 4

654F20 51

654F21 51

655F02 55

655F15 51

655F16 51

655F17 51

655F48 51

655F54 55

655F55 55

655F69 55

655F70 55

655F71 51

656F40 51

656F41 51

656F44 52

656F45 52

656F46 52

656F47 52

656F48 52

656F49 52

656F50 52

656F51 52

656F52 52

656F53 52

656F55 54

656F56 54

656F57 54

656F58 54

656F59 54

Part Number Index

January 1, 2014Parts Price List. I

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

656F60 54

656F61 54

656F62 54

656F63 54

656F64 55

656F65 55

656F66 51

670F30 15

670F31 15

670F32 15

670F33 15

670F34 15

670F35 15

670F36 15

670F37 15

670F38 15

670F57 15

670F58 15

670F59 15

670F60 15

670F61 15

670F62 15

670F63 15

670F64 15

670F65 15

670F66 15

670F67 15

670F68 15

670F69 15

670F70 15

670F71 15

670F72 15

670F73 15

670F74 15

671F02 15

671F03 15

671F04 15

671F05 15

671F06 15

671F07 15

671F08 15

671F09 15

671F10 15

676F03 54

676F04 54

677F00 54

677F01 54

677F04 53

677F05 53

677F09 55

677F13 53

677F14 53

677F15 53

677F16 53

677F26 53

677F27 53

677F28 53

677F42 1

677F51 30

677F52 30

677F63 30

677F64 30

677F76 55

677F77 55

678F00 51

678F02 55

678F24 23

678F24 25

678F24 29

678F25 23

678F25 25

678F25 29

678F25 42

678F28 22

678F30 22

678F35 22

678F36 22

678F37 22

678F38 22

678F41 22

678F42 22

678F49 23

678F49 29

678F54 7

678F67 7

678F81 30

678F82 30

678F84 30

678F85 30

678F86 30

678F87 30

678F88 30

678F89 30

678F91 30

678F92 30

678F94 30

678F95 30

678F96 30

678F97 30

678F98 30

678F99 30

679F04 30

679F05 30

679F06 30

679F07 30

679F12 30

679F13 30

679F14 30

679F15 30

679F16 30

679F17 30

679F30 30

679F80 31

679F81 31

680F03 30

680F04 30

680F34 17

680F35 17

680F36 17

680F40 30

680F41 30

680F42 30

680F43 30

680F48 30

680F49 30

680F56 31

680F57 31

680F58 31

680F60 31

680F64 3

680F85 30

680F86 30

680F93 30

680F94 30

680L50 29

680L50 31

680L51 29

680L51 31

680L52 29

680L52 31

681F06 31

681F20 31

681F30 7

681F31 7

681F36 7

681F37 7

681F44 8

681F48 7

681F56 31

681F57 31

681F60 50

681F61 50

681F62 50

681F63 50

681F70 52

681F71 52

681F75 51

681F76 52

681F77 52

682F01 8

682F21 22

682F22 22

682F23 22

682F24 22

682F25 22

682F26 22

682F28 22

682F29 3

682F29 20

682F29 24

682F29 28

682F32 22

682F33 22

682F37 22

682F38 22

682F39 3

682F39 20

682F39 26

682F40 20

682F41 20

682F42 20

682F44 20

682F45 20

682F46 20

682F47 20

682F48 20

682F49 20

682F50 20

682F56 20

682F57 20

682F60 22

682F61 22

682F62 22

682F62 27

682F63 22

682F64 22

682F65 22

682F67 22

682F68 22

682F71 20

682F74 20

682F75 20

682F76 20

682F77 20

682F78 23

682F78 25

682F78 29

682F79 20

682F80 20

682F86 22

682F87 22

682F91 3

682F91 20

682F91 24

682F91 28

682F91 42

682F95 20

682F95 24

682F95 28

682F96 20

682F96 24

682F96 28

684F05 8

684F06 8

684F09 8

684F10 8

684F11 8

684F12 8

684F14 8

684F42 51

684F44 22

684F44 25

684F44 29

684F45 22

684F46 22

684F52 22

684F52 25

684F52 29

684F53 29

684F55 7

684F77 21

684F78 21

684F79 21

684F80 21

684F81 21

684F82 20

684F83 20

684F84 20

684F85 20

684F86 20

684F87 20

684F88 20

685F09 3

685F38 8

685F41 22

685F42 22

685F44 22

685F50 42

685F51 42

685F52 42

685F53 42

685F54 42

685F55 42

686F85 20

686F85 24

686F85 28

686F86 20

686F86 26

686F88 23

686F88 29

687F53 7

687F54 7

687F55 7

687F56 7

687F60 31

687F60 35

687F61 31

687F61 35

687F62 31

687F62 35

Part Number Index

January 1, 2014Parts Price List. J

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

687F63 31

687F63 35

687F64 31

687F64 35

687F65 31

687F65 35

687F66 31

687F66 35

687F71 31

687F71 35

687F94 31

687F94 35

687F95 31

687F95 35

687F96 31

687F96 35

688F01 8

688F03 8

688F14 7

688F17 8

688F77 56

688F77 57

688F92 56

688F95 56

688F95 57

688F98 56

688F99 56

689F01 56

689F01 57

689F01 58

689F02 56

689F02 57

689F02 58

689F03 56

689F03 57

689F03 58

689F04 56

689F04 57

689F04 58

689F12 57

689F12 60

689F13 57

689F14 57

689F15 57

689F16 57

689F17 57

689F18 57

689F19 57

689F25 56

689F28 14

689F30 14

689F31 14

689F33 14

689F37 14

689F39 14

689F50 14

689F51 14

689F52 14

689F53 14

689F54 14

689F55 14

689F58 14

689F60 14

689F62 14

690F44 42

690F82 8

690F97 20

690F98 20

691F24 30

691F25 30

691F29 24

691F29 28

691F52 57

691F53 57

691F54 57

691F55 57

691F56 57

691F57 57

691F72 56

691F72 57

691F74 56

691F74 57

691F75 56

691F78 57

691F85 58

691F89 57

691F90 57

691F92 56

691F93 57

691F94 57

691F95 57

691F96 56

691F96 57

691F98 58

691F99 58

692F00 57

692F01 57

692F02 57

692F02 58

692F03 57

692F03 58

692F04 56

692F04 57

692F05 56

692F05 57

692F06 58

692F07 58

692F14 59

692F14 60

692F15 59

692F15 60

692F16 59

692F16 60

692F17 60

692F18 60

692F19 60

692F20 60

692F21 60

692F22 60

692F23 60

692F24 60

692F25 60

692F26 60

692F27 60

692F28 60

692F29 60

692F63 18

692F64 18

692F65 18

692F66 18

692F67 18

692F68 18

692F75 18

692F76 18

692F86 18

692F93 18

692F94 18

692F95 18

692F96 18

693F20 38

694F31 18

694F32 18

694F33 18

694F35 18

694F39 18

694F44 18

694F48 18

694F52 18

694F56 18

694F60 18

694F68 18

694F72 18

694F76 54

694F80 18

695F04 2

695F05 2

695F07 20

695F18 54

695F22 40

695F23 40

695F24 2

695F25 2

695F51 30

695F52 30

695F68 31

696F05 42

696F31 40

696F42 3

696F47 2

696F49 2

696F50 2

696F51 3

696F57 17

696F58 17

696F59 17

696K43 1

696K45 1

696K46 1

696K48 1

696K52 1

697F33 51

697F34 51

697F35 51

697F36 51

697F40 22

697F41 22

697F42 22

697F44 22

697F45 22

697F46 22

697F47 22

697F49 20

697F50 2

697F50 3

697F52 20

697F53 20

697F55 22

697F86 50

697F94 20

697F98 40

697F99 21

698F03 50

698F31 53

698F32 53

698F33 53

698F34 53

698F43 42

698F44 42

698F45 42

698F46 42

698F51 42

698F52 42

698F53 42

698F64 53

698F65 53

698F66 53

698F67 53

698F68 53

698F69 53

698F70 53

698F71 53

698F99 30

699F00 30

699F02 30

699F03 30

699F04 30

699F05 30

699F06 30

699F07 30

699F08 30

699F20 22

699F21 22

699F22 22

699F23 22

699F24 22

700F01 6

700F02 6

700F03 6

700F04 6

700F05 6

700F07 6

700F08 6

700F09 6

700F10 6

700F11 6

700F12 6

700F13 6

700F14 6

700F15 6

700F16 17

700F17 6

700F18 6

700F19 6

700F20 6

700F21 7

700F22 7

700F25 8

700F27 7

700F29 6

700F36 17

700F37 17

700F39 6

700F40 13

700F41 13

700F42 13

700F43 13

700F44 13

700F45 13

700F46 13

700F47 13

Part Number Index

January 1, 2014Parts Price List. K

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

700F51 6

700F57 3

700F58 6

700F65 17

700F66 17

700F67 17

700F70 8

700F74 8

700F75 6

700F76 6

700F77 6

700F80 13

700F81 13

700F81 21

700F82 13

700F83 13

700F84 13

700F85 6

700F86 13

700F87 13

700F90 7

700F95 8

701F01 6

701F02 6

701F03 6

701F04 6

701F05 6

701F07 6

701F08 6

701F09 6

701F10 6

701F11 6

701F12 6

701F18 6

701F19 6

701F22 7

701F23 2

701F29 6

701F36 6

701F39 6

701F52 6

701F59 6

701F60 51

701F61 51

701F62 51

701F63 51

701F70 8

701F75 6

701F78 6

701F79 6

701F85 6

702F98 7

703F01 6

703F02 6

703F03 6

703F04 6

703F05 6

703F07 6

703F08 6

703F09 6

703F10 6

703F15 6

703F29 6

703F46 51

703F75 6

703F997 8

704F26 50

704F27 50

704F47 50

704F48 50

704F56 50

704F57 50

704F58 50

704F59 50

704F62 51

704F63 51

704F64 51

704F65 51

704F66 51

706F00 55

706F01 55

706F03 50

706F04 50

706F05 50

706F06 50

706F07 50

706F08 50

706F09 50

706F10 50

706F11 50

706F12 50

706F13 50

706F14 50

706F15 50

706F16 50

706F70 17

707F57 17

707F57 39

707F58 17

707F58 39

707F59 17

707F59 39

707F60 17

707F60 39

707F70 39

707F95 22

708F36 22

709F85 60

709F86 60

709F87 60

709F88 60

709F89 60

709F95 60

710F01 7

710F02 7

710F04 7

710F05 7

710F07 7

710F08 7

710F09 7

710F31 51

710F32 51

710F33 51

710F61 23

710F62 23

710F63 20

710F64 20

710F65 22

710F66 22

710F75 7

711F01 7

711F02 7

711F04 7

711F05 7

711F07 7

711F08 7

711F09 7

711F29 7

711F39 8

711F75 7

711F80 60

711F81 60

711F82 60

711F83 60

711F84 60

711F85 60

711F86 60

711F87 60

711F88 60

712F20 20

712F21 20

712F22 20

712F23 20

712F24 20

712F25 20

712F26 20

712F27 20

712F30 21

712F31 21

712F32 21

712F33 21

712F34 21

712F35 21

712F36 21

712F37 21

712F38 20

712F39 20

712F40 20

712F41 20

712F42 20

712F43 20

712F44 21

712F45 21

712F46 21

712F47 21

712F48 21

712F49 21

712F50 20

712F51 20

712F52 20

712F53 20

712F54 20

712F55 20

712F56 20

712F57 20

712F60 21

712F61 21

712F62 21

712F63 21

712F64 21

712F65 21

712F66 21

712F67 21

712F68 20

712F69 20

712F70 20

712F71 20

712F72 20

712F73 20

712F74 21

712F75 21

712F76 21

712F77 21

712F78 21

712F79 21

713F51 51

713F52 51

713F90 51

713F93 51

713F94 51

713F95 51

713F98 51

713F99 51

714F00 20

714F03 20

714F06 20

714F12 20

714F15 21

714F18 21

714F21 20

714F27 20

714F30 20

714F31 20

714F36 20

714F37 20

714F42 20

714F43 21

714F45 20

714F49 21

714F54 20

714F55 20

714F60 20

714F63 20

715F10 3

715F11 3

715F12 3

715F15 2

715F89 3

715K14 1

716K16 1

716K43 1

716K45 1

716K46 1

716K48 1

744F20 51

744F25 51

744F66 2

751F16 12

751F17 12

754F02 60

754F03 60

754F04 60

754F05 60

754F09 56

754F09 59

754F10 56

754F10 59

754F12 56

754F13 56

754F14 56

754F14 59

754F15 56

754F15 59

754F16 56

754F17 56

754F18 56

754F19 56

754F20 56

754F21 56

754F22 56

754F23 56

754F24 56

754F25 56

754F26 56

754F28 56

754F29 56

754F30 56

754F33 56

754F34 56

Part Number Index

January 1, 2014Parts Price List. L

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

PART

NUMBER

PAGE

NUMBER

754F35 56

754F36 56

754F37 56

754F37 58

754F39 60

754F40 60

754F41 60

754F42 60

754F46 56

754F52 60

754F53 60

754F54 60

754F55 60

754F56 60

754F57 60

754F58 60

754F59 60

754F61 60

754F62 60

754F63 60

754F64 60

754F65 59

754F66 60

754F68 59

754F69 59

754F70 59

754F71 60

754F72 60

754F73 60

754F78 59

754F79 59

754F80 59

754F81 59

792F01 6

792F02 6

792F03 6

792F04 6

792F05 6

792F07 6

792F08 6

792F09 6

792F10 6

792F20 6

794F50 60

794F51 60

794F52 60

794F53 60

796F10 22

796F11 25

796F11 27

796F11 29

796F20 24

796F21 24

796F22 24

796F23 24

796F24 24

796F25 24

796F26 24

796F31 24

796F32 24

796F33 24

796F35 24

796F36 24

796F37 24

796F37 28

796F38 24

796F39 24

796F39 28

796F40 24

796F40 28

796F47 20

796F48 20

796F49 22

797F37 24

797F61 24

797F61 28

797F62 24

797F62 28

797F63 24

797F63 28

797F64 24

797F64 28

797F65 24

797F65 28

797F66 24

797F66 28

797F67 24

797F67 28

797F68 24

797F68 28

797F69 24

797F69 28

797F70 24

797F70 28

797F71 24

797F71 28

797F72 24

797F72 28

797F73 24

797F73 28

797F74 24

797F74 28

797F75 24

797F75 28

797F76 24

797F76 28

797F77 24

797F77 28

797F78 24

797F78 28

797F80 24

797F80 28

797F81 29

797F82 25

797F82 29

797F83 29

797F84 25

797F84 29

797F85 25

797F85 29

797F86 25

797F86 29

797F87 25

797F87 29

797F91 25

797F91 29

797F92 25

797F92 29

797F93 25

797F93 29

797F94 25

797F94 29

798F11 25

798F11 29

798F12 25

798F12 29

798F13 25

798F13 29

798F14 25

798F14 29

798F15 25

798F15 29

798F16 25

798F16 29

798F17 25

798F17 29

798F18 25

798F18 29

798F21 29

798F22 29

798F23 29

798F24 29

798F25 29

798F26 29

798F27 29

798F28 29

798K91 1

798K92 1

799F50 20

799F51 20

799F52 20

799F53 20

799F54 20

799F55 20

799F56 20

799F57 20

799F58 20

799F59 20

799F60 21

799F61 21

799F62 21

799F63 21

799F64 21

799F65 21

799F66 21

799F67 21

799F68 21

799F69 21

799F80 20

799F81 20

799F82 20

799F83 20

799F85 21

799F86 21

799F87 21

SECURITY PLUGS (USE IN SECURITY SHELLS ONLY)

PART NO. DESCRIPTION LIST PRICE

407K63 1-1/8" Mortise $47.00

407K64 1-1/4" and 1012 (Blockout)

415K73 1-3/8" Mortise $53.00

415K74 1-1/2" Mortise

518K73 1-3/4" Mortise $63.00

518K74 2" Mortise $65.00

518K75 2-1/4" Mortise

518K76 2-1/2" Mortise $67.00

518K77 2-3/4" Mortise

409K12* 1011 Mortise Hotel $47.00

481K19 1014 Brink Mortise $49.00

481K28 1015 Brink Mortise

408K45 CK4200, UT5200 $43.00

585K46 CL3300 Non-Hotel $53.00

444K97 2210-001 and -009 $53.00

444K98 2210-002 $47.00

444K96 2210-008 $53.00

444K99 2210-054 $47.00

407K65 3010 Rim Cylinder $43.00

483K01 3012 Rim (Blockout) $51.00

446K68 8010 Interchangeable Core $39.00

PYRAMID STANDARD PLUGS

696K43 Used with 1020 †Order 10-

$39.00

798K912 x Fin Used with 1020 -112 †Order 10-

696K45 Used with 3020 †Order 10-

696K46 Used with 2020 †Order 10-

696K48 Used with 2020 †Order 10-

696K52 Used with 8020, 8027 †Order 10-

715K14 Used with 2220 †Order 10- $41.00

PYRAMID SECURITY PLUGS

716K43 Used with 1027 †Order 10-

$39.00

798K922 x Fin Used with 1027 -112 †Order 10-

716K45 Used with 3027 †Order 10-

716K46 Used with 2027 KIL †Order 10-

716K48 Used with 2027 KIK †Order 10-

716K16 Used with 2227 †Order 10- $41.00

PYRAMID SIDE PIN PLUGS

628K852 x Fin Used with 1020-114 †Order 10-

$41.00

628K972 x Fin Used with 1020-112 †Order 10-

628K872 x Fin Used with 3020 †Order 10-

628K902 x Fin Used with 2020-052 †Order 10-

628K882 x Fin Used with 2020-03x †Order 10-

628K952 x Fin Used with 2220 †Order 10- $43.00

629K032 x Fin Used with 8020, 8027 †Order 10-

$41.00

628K992 x Fin Used with 1027-114 †Order 10-

630K472 x Fin Used with 1027-112 †Order 10-

629K002 x Fin Used with 3027 †Order 10-

629K022 x Fin Used with 2027-052 †Order 10-

629K012 x Fin Used with 2027-03x †Order 10-

629K042 x Fin Used with 2227 †Order 10- $43.00

6-PIN LOADED SHELLS, BULK PACKS

Finishes available for rim and mortise shells: 605, 606, 612, 613, 625, 626

493F76 25 Pack for 1000-118 Mortise

$1,092.00

677F42 25 Pack for 1000-114 Mortise

493F77 25 Pack for 3000 Rim

493F78 50 Pack for CK4200, UT5200 $1,092.00

610F49 50 Pack for CL3300, CL3900, CL3700

*Not available in D1, D2, L1, L2, 752, 852 or A class keyways.

Key Systems

January 1, 2014Parts Price List. 1

6-PIN PLUGS, BULK PACKS 606, 626

PART NO. DESCRIPTION LIST PRICE

These packages are priced at a savings over individual plug prices.

Keyway availability is limited to L4, D1, Hl, 60, 59A1 and 981.

492K90 25 Pack for 1-1/8" Mortise $585.00

492K91 25 Pack for 3000 Rim

492K92 50 Pack for CK4200, UT5200 $1,170.00

610K48 50 Pack for CL3300

5- AND 6-PIN INDIVIDUAL PLUGS 606, 626

X CLASS STANDARD USED IN LIST PRICE

487K10 121K10 1" Mortise (5-pin) $29.00

487K11 121K11 1-1/8" Mortise

606K73 193K09 3-1/4" Mortise $52.00

606K74 193K10 3-1/2" Mortise $54.00

606K75 193K11 3-3/4" Mortise $56.00

487K38 197K51* 1001 Hotel Mortise $31.00

559K94 464K97 1004 Brink Mortise $33.00

559K95 468K87 1005 Brink Mortise

488K99 488K98 CK4200, UT5200 (.552") and

2000-051 $29.00

564K53 574K05 CK4400, except below

564K60 564K52 CK4429 Hotel, old tailpiece $38.00

564K59 579K14 CK4429, new tailpiece

580K99 574K07 CK4455, CK4482, before 8/93

$29.00

596K29 585K24 CL3300, CL3500, CL3600,

CL3700, CL3800, CL3900

596K31 585K26 CL3329, CL3629 Hotel $40.00

489K49 186K75 2001-051 (1429/3433EM) $40.00

534K25 245K37 2100/2160 (large head)

$38.00

612K90 444K87 2200-001 and -009

612K91 444K89 2200-002

612K88 444K94 2200-008

612K93 444K88 2200-054

612K94 523K21 2200-076

488K84 253K66 3000 Rim Cylinder $29.00

610K46 146K80 4200-002 for AR Pull $38.00

195K68 4266 for MR Exit Operators $46.00

334K01 334K00 8000-6 Interchangeable Core $29.00

n/a 378K18 Fox Police Rim Cyl. (5-pin) $46.00

†Sold only in multiples of the number indicated. Price is each.

PLUGS AND SHELLS

7-PIN PLUGS 606, 626

X CLASS STANDARD USED IN LIST PRICE

487K13 292K95 1-1/4" Mortise

$31.00487K15 292K96 1-3/8" Mortise

487K17 292K97 1-1/2" Mortise

487K19 292K98 1-3/4" Mortise $43.00

487K21 292K99 2" Mortise

$45.00

606K76 293K00 2-1/4" Mortise

606K77 293K01 2-1/2" Mortise

606K78 293K02 2-3/4" Mortise

606K79 293K03 3" Mortise $47.00

596K30 585K25 CL3300 Non-Hotel $39.00

596K32 585K27 CL3329 Hotel $43.00

488K85 253K67 3000-7 Rim Cylinder $31.00

416K08 416K07 8000-7 Core $39.00

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

SECURITY MASTER PINS

407T31-4097 2L

$3.80 20†

407T32-4097 2R

407T33-4097 2S

407T31-4125 3L

407T32-4125 3R

407T33-4125 3S

407T31-4153 4L

407T32-4153 4R

407T33-4153 4S

SECURITY TOP PINS

407T43-4193 Size 1 Long $3.50 20†

407T43-4158 Size 2 Short

BUMP-RESISTANT TOP SPOOL PINS (VIAL OF 100 PINS)

628F10-7-171 Conventional $42.00 1

628F10-7-142 Pyramid A $92.00 1

628F10-7-236 Pyramid C $100.00 1

SPRINGS AND SPRING COVERS

172F21-7 Spring,interchangeable core $0.06 100†

493F29-7 Replaced by 603F20-7

603F20-7 Spring, security and convent $0.06 100†

026F75-7 Spring, hotel mortise blocking pin

585F32-7 Spring, cylinder cap pin for 2000-034 type $0.12 100†

314F98-7 Spring for 2001-034 indicator $0.04 100†

217F42-2 Spring Cover, 5-pin brass $0.22 100†

217F44-2 Spring Cover, 6-pin brass $0.20 100†

314F88-7 Spring Cover, 6-pin stainless for

most 2000 Series $0.40 50†

217F43-2 Spring Cover, 7-pin brass $0.22 100†

585F39-7 Spring Cover for 2000-034-7 $1.00 10†

171F46-8 Spring for 1100 Series Cyl. Head $0.06 100†

697F507 Spring for all Pyramid Cyls $0.06 100†

CAMS

CONVENTIONAL AND SECURITY

701F237 A01 Cloverleaf (was #11) $2.20 20†

147F77-2 A02 Straight, brass (was #1) $3.40 10†

147F77-8 A02 Straight, steel (was #1) $2.10 20†

111F55-8 A03 (was A) $2.70 10†

413F22-8 A04 (was J) $2.80 10†

105F70-2 A05 AR4070 (was B) $3.40 10†

626F077 A06 $5.00 1

480F06-2 A91 $4.60 5†

266F34-2 A92 $3.60 10†

281F27-2 A93 (was C) $6.20 5†

406F43-8 Cam for O5 Exit trim $9.70 1

IC VERSION

701F237 A01 Cloverleaf (was #11) $2.20

10†

334F13-8 A02 Straight (was #1)

$3.80362F42-8 A03 (was A)

423F49-8 A04 (was J)

362F50-2 A05 AR4070 (was B) $4.60 5†

626F077 A06 5.00 1

744F662 A62 Straight $14.00 1

294F05-2 A63 MR adaptation $4.60 5†

308F78-2 A64 MR adaptation $6.90 5†

526F66-2 A65 MR adaptation $7.90 5†

362F43-2 A93 (was C) $7.90 5†

MASTER RING

562F40-2 A61 New Cloverleaf

(locks after 5/93) $3.80 10†

065F36-2 A62 Straight (was 1A) $13.50 10†

121F01-2 A63 (was 1MR) $3.90 5†

135F19-2 A64 (was 2MR) $6.90 5†

025F72-2 A65 Old Cloverleaf (was 11A) $4.80 5†

PART NO. DESCRIPTION LIST

PRICE SOLD IN

MULT. OF

PYRAMID SHELLS

695F042 x Fin Used with 1020-114, 1027-114,

3020-058, 3027-058 $52.00

10†

695F052 x Fin Used with 3020, 3027 (Slotted)

696F502 x Fin Used with 8020, 8027

696F472 Used with 2020, 2027 (KIL)) $44.00

696F499 Used with 2020, 2027 (KIK)

715F152 Used with 2220, 2227 $45.00

PYRAMID SHELLS - SIDE PINS

628F922 x Fin Used with 8020, 8027

$44.00

629F062 x Fin Used with 1020-114, 1027-114,

3020-058, 3027-058

630F482 x Fin Used with 1020-112, 1027-112

628F912 Used with 2020-052, 2027-052

628F892 Used with 2020, 2027 (Levers)

628F962 Used with 2220, 2227 (Competitors) $45.00

629F072 x Fin Used with 3020, 3027 (Slotted) $44.00

PYRAMID SIDE PINS (VIAL OF 20 PINS)

630F494 Pyramid Side Pins - Vial Of 20 Pins $16.00

PYRAMID HIGH SECURITY PINS (VIAL OF 100 PINS)

TOP PINS

$36.00 1

695F257031 - .031" 695F257173 - .173"

695F257047 - .047" 695F257189 - .189"

695F257063 - .063" 695F257204 - .204"

695F257078 - .078" 695F257220 - .220"

695F257094 - .094" 695F257236 - .236"

695F257110 - .110" 695F257252 - .252"

695F257126 - .126" 695F257267 - .267"

695F257141 - .141" 695F257283 - .283"

695F257157 - .157" 695F257299 - .299"

BOTTOM PINS

695F247139 - .139" 695F247218 - .218"

695F247155 - .155" 695F247234 - .234"

695F247171 - .171" 695F247250 - .250"

695F247187 - .187" 695F247265 - .265"

695F247202 - .202" 695F247281 - .281"

PYRAMID SECURITY PINS (VIAL OF 100 PINS)

TOP PINS

$29.00 1

695F252031 -. 031" 695F252173 - .173"

695F252047 - .047" 695F252189 - .189"

695F252063 - .063" 695F252204 - .204"

695F252078 - .078" 695F252220 - .220"

695F252094 - .094" 695F252236 - .236"

695F252110 - .110" 695F252252 - .252"

695F252126 - .126" 695F252267 - .267"

695F252141 - .141" 695F252283 - .283"

695F252157 - .157" 695F252299 - .299"

BOTTOM PINS

695F244139 - .139" 695F244218 - .218"

695F244155 - .155" 695F244234 - .234"

695F244171 - .171" 695F244250 - .250"

695F244187 - .187" 695F244265 - .265"

695F244202 - .202" 695F244281 - .281"

PINS (SPECIFY SIZE WHERE APPROPRIATE)

553F48-4 Vial of 100 bottom pins (L Pins)

$16.50 1553F50-2 Vial of 100 spool top pins (J Pins)

553F49-2 Vial of 100 top pins (= master & Bu) (M Pins)

546F97-8 Vial of 1500 construction balls $15.50 1

197F52-7 Pin, blocking of 1001, 1011 (hotel) $0.88 50†

159F36-7 Ball bearing for wear resistance $0.14 100†

SECURITY BOTTOM PINS

407T41-4242 2L

$3.60 20†

407T42-4242 2R

407T41-4270 3L

407T42-4270 3R

407T41-4298 4L

407T42-4298 4R

407T41-4326 5L

407T42-4326 5R

407T41-4354 6L

407T42-4354 6R

Key Systems

January 1, 2014Parts Price List. 2

CYLINDER PARTS

†Sold only in multiples of the number indicated. Price is each.

Key Systems

January 1, 2014Parts Price List. 3

CYLINDER PARTS (CONT'D)

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

RETAINERS

173F79-8 .020" Plug Retainer-3300/5600,1400/4300 $0.70 50†

368F91-8 .030" Plug Retainer-3000 and 3010

rim cylinders $1.30 20†

488F92-8 .032" Plug Retainer-2000-052, -044

and -051 $1.00 20†

333F99-8 Plug Retainer, IC, CK4400,

2200-008, 2020 KIK $0.16 100†

334F23-8 Retainer, IC rim tailpiece $2.90 10†

365F95-8 Retainer, Fox Police rim cylinder $3.90 10†

250F08-8 Retainer for flex head cylinder $0.06 100†

680F64-5 Cap for 2000-033, 034 $3.70 10†

585F31-2 Cap Pin for 2000-034 $0.06 100†

219F88-8 Plug Retainer for 2060-052 $0.16 100†

TAILPIECES

444F74-8 A21 $1.50 20†

461F10-8 A22 $2.00 10†

520F35-8 A23 $3.90 10†

444F75-8 A24 $2.00 10†

365F96-8 A38 (Fox square) $3.00 5†

329F99-8 A39 (Fox round) $5.20 5†

484F95-8 A41 $1.70 10†

484F92-8 A42

484F91-8 A43 $1.20 20†

484F96-8 A44 $3.50 10†

484F93-8 A45 $2.20 10†

484F94-8 A46 $3.30 10†

146F78-8 A47 $13.50 1

585F33-7 For 2001-034-6 $1.50 20†

585F35-8 For 2001-034-7 $2.20 10†

622F29-8 For 2000-034-6 $2.90 10†

596F89-8 For 2000-038

622F30-8 For 2000-033-6, 2000-034-7 $1.60 20†

489F02-8 For 2000-051

682F298 For 2000-033-7 $1.50 20†

186F74-8 For 2001-051 $1.40 20†

622F328 For 2400-033

$5.90 1682F398 For 2400-034

685F098 For 2400-037

616F208 For 2400-039 $6.70 1

616F218 For 2400-039L

490F55-8 For 3000-138 $2.70 10†

253F76-8 For 3000-200 $1.60 20†

413F48-8 For 3000-200-V $2.60 10†

253F77-8 For 3000-312 $1.60 20†

413F49-8 For 3000-312-V $2.90 10†

582F29-8 For 3080-114 for

exit alarm options M61 & M62 $3.30 10†

253F85-8 For 3080-178 $3.20 10†

284F13-8 For 3080-318 $2.50 10†

599F38-9 Kit for Sargent®in CL3600 $9.00 1

601F22-9 Kit for Sargent in CL3400 $9.50 1

622F32-8 For Schlage®cyl. in CL3400/CL3600 $6.50 5†

715F108 P21

$4.10 10†715F118 P22

715F128 P23

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

IC THROW MEMBERS

715F892 CK4200, UT5200 $3.50 1

320F44-2 CK4200, UT5200 Best®knob $5.10 1

496F80-8 CL3200 Series (except CL3255) $2.60 10†

622F728 CL3400, CL3600 Series packet

(before 6/2000) straight $3.10 10†

682F91-8 CL3300, CL3600 series packet

(after 6/2000) twisted $4.70 10†

379F805 Used with 1030-134, 1037-134 $35.50 1

628F825 Used with 1030-114, 1037-114,

1030-138, 1037-138, 3030, 3037 $8.20 1

628F835 Used with 1030-112, 1037-112 $12.00 1

362F15-3 Padlock $6.50 10†

OTHER IC PARTS

353F86-8 Inner cam for 1071 (hotel) $6.70 5†

446F57-2 Control Sleeve for 8000 core $11.00 5†

446F58-2 Control Sleeve for 8010 core $13.50 5†

438F42-8 Mortise Cylinder Cam Screw $0.24 100†

334F12-8 Mortise Cylinder Cam Plate

$1.70 20†622F69-8 Security disk for CL3400, CL3600

607F91-9 Spacer for 6-pin Best type core

OTHER MASTER RING CYLINDER PARTS

522F93-2 Adapter Bushing for MR $60.00 1

135F10-8 Backplate, MR rim $3.30 10†

158F06-2 Cam Spacer for A61, A62, A65 $1.20 20†

700F575 Thumbturn Hub for A61 MR cam $26.00 1

562F42-2 Kit, A61 cam / hub conversion

488F10-8 Mortise Cylinder Set Screw Pkt $1.60 20†

354F19-8 Thumbturn disk, A64 cam $71.00 1

197F35-7 Wave Washer for collar $3.20 10†

OTHER MORTISE/RIM CYLINDER PARTS

253F75-8 Backplate, rim cylinder $1.30 20†

438F41-8 Cam Screw $0.22 100†

488F08-8 Mortise Cylinder Set Screw Pkt $0.52 20†

021F68-8 Screw, rim cyl. mounting, 2-9/32" $0.52 20†

021F71-8 Screw, rim cyl. mounting, 3-1/8" $3.80 10†

197F34-7 Wave Washer for collar $2.50 20†

129F84-8 Cylinder Nut $6.50 1

310F48-8 Thumbturn Disk, A02 cam $29.00 1

OTHER KNOB/LEVER CYLINDER PARTS

596F87-9 Obsolete by new design

585F38-7 2001-034 Indicator fork $1.10 20†

585F37-7 2001-034 Stabilizer Pin $2.10 20†

314F99-7 2001-034-6 Indicator Pin $3.90 20†

585F40-7 2001-034-7 Indicator Pin $7.00 1

585F36-7 Tailpiece Anchor, 2001-034 $1.40 20†

041F47-8 Key, hotel shut-out 50†

PYRAMID CYLINDER PARTS

696F42 Blocking plate $3.50 20†

697F50 Tumbler spring $0.04 100†

217F43 Spring cover $0.22 100†

217F44 IC Spring cover $0.20 100†

696F51 Control sleeve $22.00 10†

628F932 Control sleeve - Used with 8020, 8027 $24.00 10

†Sold only in multiples of the number indicated. Price is each.

Key Systems

January 1, 2014Parts Price List. 4

STANDARD DIAMETER CYLINDER COLLARS

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

STAMPED COLLARS

253F97

Spring collar

10†618, 619, 626 $4.50

605, 606, 612, 613, 622, 625 $5.80

428F66

2-Piece (was 574 1/2, H)

5†

618, 619, 626 $5.30

605, 606, 612, 613, 622, 625 $9.90

549F52

.219" Straight (was 154 1/2, H1)

10†618, 619, 626 $3.40

605, 606, 612, 613, 622, 625 $5.40

605F43

.350 Tapered spring collar

618, 619, 626 $3.50

605, 606, 612, 613, 622, 625 $5.70

SPACER FOR FLEXIBLE HEAD CYLINDER

370F29 .125" (1/8") $28.00 1

370F31 .250" (1/4") $29.00 1

252F82 .312" (5/16") $30.00 1

SOLID, RECESSED FOR CYLINDER HEAD

447F41

.031" (was 575 1/4, 910)

1618, 619, 626 $12.00

605, 606, 612, 613, 622, 625 $14.00

270F15

.156"

1622, 626, 630 $15.50

605, 606, 612, 613, 622, 625 $18.50

447F42

.172" (was 575 3/8, 910-6)

1618, 619, 626 $11.50

605, 606, 611, 612, 613, 625 $13.30

610F01

.221" (was 5574 3/4, C)

1611, 612, 613, 625, 626 $21.50

605, 606, 618, 619 $25.50

610F02

.289" (was 5574 1/4, L)

1611, 612, 613, 625, 626 $21.50

605, 606, 618, 619 $25.50

654F07

.356" for ED4000/ED5000

606, 626, 630 $13.00

612, 622, 629 $16.50

605, 611, 613, 625 $17.50

447F43

.375" (was 575 9/16, 910-9)

1612, 619, 626 $11.80

605, 606, 611, 613, 618, 625 $14.80

609F36

.500"

1605, 606, 611, 612, 613 $27.50

618, 619, 625, 626

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

SOLID, RECESSED FOR CYLINDER HEAD (Cont’d)

654F08

.556" for ED4000/ED5000

606, 622, 626 $13.40

605, 625, 630 $15.50

611, 612, 613, 629 $19.50

609F37

.650"

1605, 606, 611, 612, 613 $29.50

618, 619, 625, 626

609F38

.850"

1605, 606, 611, 612, 613 $29.50

618, 619, 625, 626

134F05

With lip, .510" ED6800, ED7400, ED7800

1606, 619, 622, 626 $27.50

605, 611, 612, 613, 618, 625 $29.50

267F97

With lip, .635"

1606, 619, 622, 626 $28.50

605, 611, 612, 613, 618, 625 $30.50

399F48

With lip, .750" ED6800 x 01, 02 x 1-1/4"

1606, 619, 622, 626 $30.50

605, 611, 612, 613, 618, 625 $32.50

OTHER CYLINDER COLLARS

416F39

Security .172" (was 95)

1605, 606, 625, 626 $17.50

611, 612, 613, 618, 619 $22.50

303F25

Solid .312" (was 571/J)

605, 606, 625, 626 $24.50

611, 612, 618, 619 $24.50

613 $28.50

261F54

Solid .094" x 2-1/4" OD for ED6000 Series T5,

T6, T9, T9M, T10, T10M 1

606, 611, 612, 626 $22.50

605, 613, 629, 630 $24.50

RIM CYLINDER COLLARS

255F53

Flush Mount (was 151/ R1290)

606, 612, 619, 626 $7.80 10†

605, 611, 622, 625 $9.70 10†

613, 618 $10.90 1

422F88

Surface Mount

605, 606, 611, 612, 619, 622, 626 $9.80 5†

613, 618, 625 $12.20 1

†Sold only in multiples of the number indicated. Price is each.

Key Systems

January 1, 2014Parts Price List. 5

MASTER RING CYLINDER COLLARS

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

SOLID, RECESSED FOR CYLINDER HEAD

447F44

.031" (was 576 1/4, MR910)

606, 626

$17.40605, 611, 612

613, 618, 619, 625

447F45

.172" (was 576 3/8, MR910-6)

1605, 611, 612, 613, 625 $23.40

606, 618, 619, 626

447F46

.375" (was 576 9/16, MR910-9)

1606, 618, 619, 626 $27.40

605, 611, 612, 613, 625

261F55

Solid .094" x 2-1/4" 0D for ED6000 x T5, T6,

T9, T10 1

606, 611, 612, 626 $27.40

605, 613, 629, 630 $29.40

SPACERS FOR FLEXIBLE HEAD CYLINDERS

366F70 .090" tapered $7.50 5

370F33 .094"

370F35 .281" $9.50 1

RIM CYLINDER COLLARS

255F54

(was 151 3/4, T)

1605, 619, 625 $13.50

606, 612, 613, 626 $11.50

PART NO. DESCRIPTION LIST

PRICE

CYLINDER SERVICE TOOLS

See main price book

LOCKSET INSTALLATION TOOLS

300F68-8 CK4200 Series Spanner Wrench for thimble $3.40

574F15-8 CK4400 Series Knob Removal Tool $1.80

506F57 CK4400 Series Knob Cover

Removal Tool $5.40

391F65-8 Knob Release Tool, CK4200, ML2200

†Order 100- $0.30

OTHER LOCKSET SERVICE TOOLS

301F65-8 Waldes Pliers CR28 for UT5200 Series $71.00

301F59-8 Waldes Ring Applicator E15 for UT5251 $85.00

301F62-8 Waldes Ring Applicator E18 for UT5255 $69.00

301F61-8 Waldes Ring Applicator E25 for UT5200 $85.00

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 6

LOCK BODY ONLY

PART NO. DESCRIPTION LIST PRICE

LOCK BODY ASSEMBLY

1-3/4" Minimum door - Conventional Deadlocks No Finish

701F06-8 ML2011, ML2012, ML2013 $208.00

701F26-8 ML2017

1-3/4" Minimum door - High Security Deadlocks

792F06-8 ML2013HS $270.00

1-3/4" Minimum door - Master Ring Deadlocks

711F06-8 ML2011, ML2012, ML2013 $290.00

1-3/8" Door - Conventional Deadlocks

701F16-8 ML2011, ML2012, ML2013 $208.00

701F36-8 ML2017

LOCK BODY ASSEMBLY - CONVENTIONAL: LEVER

1-3/4" Minimum door No Finish

700F01-8 ML2067

$293.00700F02-8 ML2030, ML2065

700F75-8 ML2072, ML2075

700F03-8 ML2029 $314.00

700F04-8 ML2048 $293.00

700F05-8 ML2020, ML2022, ML2024

700F07-8 ML2051

$255.00700F08-8 ML2042, ML2055

700F09-8 ML2057

700F10-8 ML2010 $225.00

700F29-8 ML2032

$255.00700F51-8 ML2069

700F76-8 ML2060

1-3/8" Door No Finish

700F11-8 ML2067

$293.00700F12-8 ML2030, ML2065

700F85-8 ML2072, ML2075

700F13-8 ML2029 $313.00

700F14-8 ML2048 $293.00

700F15-8 ML2020, ML2022, ML2024

700F17-8 ML2051

$255.00700F18-8 ML2042, ML2055

700F19-8 ML2057

700F20-8 ML2010 $225.00

700F39-8 ML2032

$255.00700F58-8 ML2069

700F77-8 ML2060

LOCK BODY ASSEMBLY - CONVENTIONAL: KNOB

1-3/4" Minimum door No Finish

701F01-8 ML2067

$281.00701F02-8 ML2030, ML2065

701F75-8 ML2072, ML2075

701F03-8 ML2029 $301.00

701F04-8 ML2048 $281.00

701F05-8 ML2020, ML2022, ML2024

PART NO. DESCRIPTION LIST PRICE

LOCK BODY ASSEMBLY - CONVENTIONAL: KNOB (Cont'd)

1-3/4" Minimum door No Finish

701F07-8 ML2051

$267.00701F08-8 ML2042, ML2055

701F09-8 ML2057

701F10-8 ML2010 $237.00

701F29-8 ML2032

$267.00701F52-8 ML2069

701F78-8 ML2060

LOCK BODY ASSEMBLY - CONVENTIONAL: KNOB

1-3/8" Door No Finish

701F11-8 ML2067

$281.00701F12-8 ML2030, ML2065

701F85-8 ML2072, ML2075

701F13-8 ML2029 $301.00

701F14-8 ML2048 $281.00

701F15-8 ML2020, ML2022, ML2024

701F17-8 ML2051

$267.00701F18-8 ML2042, ML2055

701F19-8 ML2057

701F20-8 ML2010 $237.00

701F39-8 ML2032

$267.00701F59-8 ML2069

701F79-8 ML2060

LOCK BODY ASSEMBLY - HIGH SECURITY: KNOB

1-3/4" Minimum door No Finish

792F01-8 ML2067HS $364.00

792F02-8 ML2030HS, ML2065HS

792F03-8 ML2029HS $384.00

792F04-8 ML2048HS $364.00

792F05-8 ML2020HS, ML2022HS, ML2024HS

792F07-8 ML2051HS

$212.00792F08-8 ML2042HS, ML2055HS

792F09-8 ML2057HS

792F10-8 ML2010HS $182.00

Less Armored Front, Strike, Cylinder, Cylinder Set Screw & Front Screw

For Non-ferrous lock, change “-8” to “-2” on part no. and add $150.00 (Not available for High Security, Master Ring, or Exit Locks)

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 7

LOCK BODY ONLY (Cont'd)

PART NO. DESCRIPTION LIST PRICE

LOCK BODY ASSEMBLY - MASTER RING: KNOB

1-3/4" Minimum door No Finish

711F01-8 Master Ring - ML2067

$361.00

711F02-8 Master Ring - ML2065

711F04-8 Master Ring - ML2048

711F05-8 Master Ring - ML2022, ML2024

711F75-8 Master Ring - ML2072, ML2075

711F07-8 Master Ring - ML2051

$347.00

711F08-8 Master Ring - ML2042, ML2055

711F09-8 Master Ring - ML2057

711F29-8 Master Ring - ML2032

LOCK BODY ASSEMBLY - MASTER RING: LEVER

1-3/4" Minimum door No Finish

710F01-8 Master Ring - ML2067

$393.00

710F02-8 Master Ring - ML2065

710F04-8 Master Ring - ML2048

710F05-8 Master Ring - ML2022, ML2024

710F75-8 Master Ring - ML2072, ML2075

710F07-8 Master Ring - ML2051

$381.00710F08-8 Master Ring - ML2042, ML2055

710F09-8 Master Ring - ML2057

ARMORED FRONT

Finish: 605, 606, 611, 612, 612, 613, 619, 625, 626, 629**, 630**

Deadbolt

079F00 Armored front, 1-1/4" standard $27.00

079F02 Armored front, 1-1/8"

Deadbolt, latchbolt, aux. latch, toggle

402F29 Armored front, 1-1/4" standard $27.00

402F33 Armored front, 1-1/8"

Deadbolt, latchbolt, auxiliary latch

402F30 Armored front, 1-1/4" standard $27.00

402F34 Armored front, 1-1/8"

Deadbolt, latchbolt, toggle

402F31 Armored front, 1-1/4" standard $27.00

402F35 Armored front, 1-1/8"

Latchbolt, auxiliary latch, toggle

681F31 Armored front, 1-1/4" standard

$27.00

681F30 Armored front, 1-1/8"

681F41 LHB, 1-1/4"

681F40 LHB, 1-1/16"

Blank Front

720F43 Armored front, 1-1/4"

720F46 Armored front, 1-1/16"

Filler Plate

334F998 USP Filler, 8" x 1-1/4"

Deadbolt, latchbolt

423F54 Armored front, 1-1/4" standard $27.00

423F57 Armored front, 1-1/8"

PART NO. DESCRIPTION LIST PRICE

ARMORED FRONT (Cont'd)

Finish: 605, 606, 611, 612, 612, 613, 619, 625, 626, 629**, 630**

Latchbolt only

423F55 Armored front, 1-1/4" standard $27.00

423F58 Armored front, 1-1/8"

Latchbolt, auxiliary latch

624F49 Armored front, 1-1/4" standard $27.00

624F53 Armored front, 1-1/8"

AUXILIARY LATCH

403F67-7 Auxiliary latch $12.00

AUXILIARY LATCH LEVER

678F54-8 Auxiliary latch lever $4.00

Auxiliary Latch Lever Spring

678F67-7 Auxiliary latch lever spring. †Order 100- $0.20

CAP

700F278 Cap $18.00

CASE & FRONT SA

687F53-8 1-1/4" wide front - all functions except 60, 69

$60.00

687F55-8 1-1/4" wide front - functions 60, 69

687F54-8 1-1/8" wide front - all functions except 60, 69

687F56-8 1-1/8" wide front - functions 60, 69

CYLINDER LATCH LEVER SA

688F14-8 Cylinder latch lever $0.90

700F22-8 Cylinder latch lever (functions 72, 75 )

CYLINDER LATCH LEVER STOP

681F48-9 Cylinder latch lever stop $1.50

CYLINDER SET SCREW BRACKET

402F73-8 Cylinder set screw bracket $4.40

DEADBOLT

702F98-7 Deadbolt $32.00

DEADBOLT SPRING

701F22-8 Deadbolt spring †Order 50- $0.86

DEADLOCKING LEVER

602F19-8 Functions 29, 51, 67

$3.00624F48-8 Functions 42, 55, 57, 69

700F21-8 Functions 72, 75

DEADLOCKING LEVER SPRING

700F90-7 Deadlocking lever spring $0.26

FIXED STOP

684F55-9 Fixed stop $3.50

HUB ALIGNMENT BRACKET

404F86-8 Hub alignment bracket $4.60

HUB ALIGNMENT BRACKET SCREW

425F86-8 FHUM-PH #8-32 X 3/8" Screw †Order 20- $0.10

HUB LEVER

681F36-8 Functions 67, 30, 65, 29 $4.00

681F37-8 All functions except 29, 30, 65, 67

†Sold only in multiples of the number indicated. Price is each.

**618, 619 finish provided to match 629, 630.

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 8

PART NO. DESCRIPTION LIST PRICE

HUB LEVER SPRING

565F04-8 Hub lever spring †Order 10- $1.50

HUB SPACER

684F11-9 Hub spacer $1.50

KNOB HUB

684F14-7 Knob hub $16.50

LATCHBOLT

688F17-7 Latchbolt $38.00

LATCH LEVER SPRING

700F95-7 Latch lever spring $0.60

LEVER HUB

684F09-8 Cap side $9.30

684F10-8 Case side

LEVER RETURN SPRING

404F85-8 Lever return spring †Order 20- $1.10

LOCKING LEVER

403F66-8 Locking lever $17.00

OCCUPANCY INDICATOR, ML2029

605, 606, 611, 612, 613, 618, 619, 625, 626

416F84 1-3/4" door, sectional $64.00

429F08 1-3/8" door, sectional $66.00

484F74 2-1/4" door, sectional $68.00

416F49 Escutcheon trim - 1-3/4" door $48.00

RETAINING RING

436F17-7 Retaining ring †Order 100- $0.56

RETRACTOR

688F03-8 Retractor †Order 100- $1.40

RETRACTOR SPRING

690F82-7 Retractor spring †Order 100- $0.10

SCREW PACKETS

Finish: 606, 612, 613, 619

429F41 Mounting screw pack, standard $3.10

488F09 Mounting screw pack, MR option $6.50

465F57 Mounting screw pack, M04 (VR, HS) $19.00

616F12 Mounting screw pack, MR x M04

SEAT SPRING

402F617 Seat spring †Order 20- $1.00

SPACER

466F22-9 Spacer

$0.26624F43-9 Spacer

624F44-9 Spacer

SPACER SPRING

684F12-9 Spacer spring 0.20

SPRINGS

403F56-8 Spring $6.60

688F01-7 Spring, kickoff $1.10

624F42-7 Spring $2.10

PART NO. DESCRIPTION LIST

PRICE

STOP

684F05-5 Stop $3.30

STOP CYLINDER LEVER

701F70-5 Stop cylinder lever $4.50

STOP LEVERS

700F70-8 Stop lever $1.40

624F47-8 Stop lever $4.60

681F44-8 Stop lever $0.74

682F01-8 Stop lever $4.60

700F74-8 Stop lever $1.40

700F25-8 Stop lever

STOP SCREW

684F06-8 Stop screw $0.44

STOP SPRING

685F38-7 Stop spring $0.34

703F997 Stop spring $1.10

THUMBTURN LEVER HUB

624F45-5 Thumbturn lever hub $5.60

TURNPIECE HUB

711F395 Turnpiece hub $2.10

WROUGHT STRIKE BOX

120F76-8 ANSI wrought strike box $3.20

STRIKES

605, 606, 611, 612, 613, 619, 625, 626, 629**, 630**

Latchbolt & Deadbolt - Straight Lip

236L72014 7/8" Lip Length

$26.00

236L72018 1-1/8" Lip Length

236L72020 1-1/4" Lip Length

236L72022 1-3/8" Lip Length

236L72024 1-1/2" Lip Length

236L72028 1-3/4" Lip Length

236L72032 2" Lip Length

236L72036 2-1/4" Lip Length

236L72040 2-1/2" Lip Length

236L72044 2-3/4" Lip Length

236L72048 3" Lip Length

†Sold only in multiples of the number indicated. Price is each.

**618, 619 finish provided to match 629, 630

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 9

†Sold only in multiples of the number indicated. Price is each.

**618, 619 finish provided to match 629, 630, except on 1-1/4" length curved lip strike

PART NO. DESCRIPTION LIST PRICE

STRIKES (Cont'd)

605, 606, 611, 612, 619, 613, 625, 626, 629**, 630**

Latchbolt - Straight Lip

236L73014 7/8" Lip Length

$26.00

236L73018 1-1/8" Lip Length

236L73020 1-1/4" Lip Length

236L73022 1-3/8" Lip Length

236L73024 1-1/2" Lip Length

236L73028 1-3/4" Lip Length

236L73032 2" Lip Length

236L73036 2-1/4" Lip Length

236L73040 2-1/2" Lip Length

236L73044 2-3/4" Lip Length

236L73048 3" Lip Length

Deadbolt - Straight Lip

236L74014 7/8" Lip Length

$26.00

236L74018 1-1/8" Lip Length

236L74020 1-1/4" Lip Length

236L74022 1-3/8" Lip Length

236L74024 1-1/2" Lip Length

236L74028 1-3/4" Lip Length

236L74032 2" Lip Length

236L74036 2-1/4" Lip Length

236L74040 2-1/2" Lip Length

236L74044 2-3/4" Lip Length

236L74048 3" Lip Length

Latchbolt & Deadbolt - Curved Lip (RH)

340L60020 1-1/4" Lip Length RH

$30.00

340L60022 1-3/8" Lip Length RH

340L60024 1-1/2" Lip Length RH

340L60028 1-3/4" Lip Length RH

340L60032 2" Lip Length RH

340L60036 2-1/4" Lip Length RH

340L60040 2-1/2" Lip Length RH

340L60044 2-3/4" Lip Length RH

340L60048 3" Lip Length RH

Latchbolt & Deadbolt - Curved Lip (LH)

340L61020 1-1/4" Lip Length LH

$30.00

340L61022 1-3/8" Lip Length LH

340L61024 1-1/2" Lip Length LH

340L61028 1-3/4" Lip Length LH

340L61032 2" Lip Length LH

340L61036 2-1/4" Lip Length LH

340L61040 2-1/2" Lip Length LH

340L61044 2-3/4" Lip Length LH

340L61048 3" Lip Length LH

PART NO. DESCRIPTION LIST PRICE

STRIKES (Cont'd)

605, 606, 611, 612, 613, 619, 625, 626, 629**, 630**

Latchbolt - Curved Lip (RH)

340L62020 1-1/4" Lip Length RH

$30.00

340L62022 1-3/8" Lip Length RH

340L62024 1-1/2" Lip Length RH

340L62028 1-3/4" Lip Length RH

340L62032 2" Lip Length RH

340L62036 2-1/4" Lip Length RH

340L62040 2-1/2" Lip Length RH

340L62044 2-3/4" Lip Length RH

340L62048 3" Lip Length RH

Latchbolt - Curved Lip (LH)

340L63020 1-1/4" Lip Length LH

$30.00

340L63022 1-3/8" Lip Length LH

340L63024 1-1/2" Lip Length LH

340L63028 1-3/4" Lip Length LH

340L63032 2" Lip Length LH

340L63036 2-1/4" Lip Length LH

340L63040 2-1/2" Lip Length LH

340L63044 2-3/4" Lip Length LH

340L63048 3" Lip Length LH

STRIKE - MORTISE EXIT DEVICE - ED6600 & ED7600

689, 690, 691

405L138018 1-1/8" Lip Length LHR

$25.00

405L138020 1-1/4" Lip Length LHR

405L138022 1-3/8" Lip Length LHR

405L148018 1-1/8" Lip Length RHR

405L148020 1 1/4" Lip Length RHR

405L148022 1 3/8" Lip Length RHR

STRIKE - OPEN BACK

605, 606, 611, 612, 613, 619, 625, 626, 629**, 630**

411L63M016 1-3/4" Door RHR $88.00

411L62M016 1-3/4" Door LHR

411L63M018 2" Door RHR

$130.00

411L62M018 2" Door LHR

411L63M020 2 1/4" Door RHR

411L62M020 2-1/4" Door LHR

STRIKE - RABBETED FRONT

605, 606, 611, 612, 613, 619, 625, 626, 629**, 630**

318F64 Latch RH/LHR

$150.00

318F65 Deadbolt RH/LHR

318F66 Latch and Deadbolt RH/LHR

318F67 Latch LH/RHR

318F68 Deadbolt LH/RHR

318F69 Latch and Deadbolt LH/RHR

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 10

PART NO. DESCRIPTION LIST PRICE

TRIM ALIGNMENT (ADAPTER) PACKETS

Finish: 605, 606, 611, 612, 613, 619, 625, 626, 629**, 630**

“P” Escutcheon

Knob or Lever Trim

466F73 1-3/8" door $45.00

466F74 1-3/4" door

466F75 2-1/4" door $53.00

Half Working Trim

439F25 1-3/8" door

$27.00439F26 1-3/4" door

439F27 2-1/4" door

Lever Half Dummy Trim

488F31 “P” Escutcheon $57.00

Knob Half Dummy Trim

437F28 “P” Escutcheon $57.00

Wrought Knob Half Dummy Trim

511F52 “P” Escutcheon $49.00

Cast Knob Half Dummy Trim

“M” and “N” Escutcheons

Regularly Furnished with Working Trim

466F50 1-3/8" door $38.00

466F51 1-3/4" door $42.00

466F52 2-1/4" door $44.00

Half Working Trim

428F32 1-3/8" door

$27.00428F33 1-3/4" door

428F34 2-1/4"door

Half Dummy Trim

437F26 Knob $48.00

438F37 Cast Knob $54.00

488F32 Lever $48.00

PART NO. DESCRIPTION LIST PRICE

TRIM ALIGNMENT (ADAPTER) PACKETS (Cont'd)

Knob or Lever Trim Outside & Blank Escutcheon Inside

466F45 1-3/8" door $31.00

466F46 1-3/4" door

466F47 2-1/4" door $33.00

Full Escutcheon Knob Trim & Sectional Lever or Knob Trim

Regularly Furnished with Working Trim No Finish

466F40 1-3/8" door $20.00

466F41 1-3/4" door $18.00

466F42 2-1/4" door $20.00

Half Working Trim

437F40 1-3/8" door

$22.00437F41 1-3/4" door

437F42 2-1/4" door

Half Dummy Trim

438F38 Cast Knob $56.00

488F30 Lever $34.00

511F51 Wrought Knob $38.00

Full Dummy Trim

437F16 Lever $9.50

Inside Adapter Only - Lockbody

427F06 Knob Half Working Trim $22.00

488F27 Lever Half Working Trim $41.00

Adjustable Locknut Assembly No Finish

482F37 Adjustable Locknut Assembly $6.00

Adjusting Bolt for Half Lever Trim No Finish

483F34 1-3/8" door $6.00

483F35 1-3/4" door $7.00

483F36 2-1/4" door $8.00

Adjusting Nut No Finish

118F48-8 Adjusting Nut for Cast Knob $3.40

Cylinder Set Screw Packet No Finish

488F08-8 Standard †Order 20 $0.52

488F10-8 Master Ring $1.60

Cylinder Collar

See page 4 & 5

Dowel Screw No Finish

483F30 for Inside Lever $2.20

Emergency Key Finish: 619

605F42 for ML2020, ML2030, ML2060 $4.10

E-Ring No Finish

427F07-8 for working half trim adapter. †Order 100- $0.10

†Sold only in multiples of the number indicated. Price is each.

**618, 619 finish provided to match 629, 630.

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 11

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630, 722

“R” ESCUTCHEON - CAST

Blank

426F52 Outside $170.00 $178.00

545F79 Inside - - - $178.00

For Cylinder only

427F45 Outside - - - $178.00

545F88 Inside - - - $178.00

For Grip only

427F43 Outside - - - $178.00

545F87 Inside - - - $178.00

For Cylinder & Grip

427F39 Outside - - - $178.00

545F80 Inside - - - $178.00

For Thumbturn Lever only

545F84 Inside-1-3/8" door $170.00 $178.00

545F86 Inside-2-1/4" door $170.00 $178.00

545F85 Inside-1-3/4" door - - - $178.00

For Thumbturn Lever & Grip

545F81 Inside-1-3/8" door $170.00 $178.00

545F83 Inside-2-1/4" door $170.00 $178.00

545F82 Inside-1-3/4" door - - - $178.00

For Grip & Emergency Key

427F47 Outside - - - $178.00

For Cylinder, Grip & Indicator

427F37 Outside-1-3/4" door - - - $178.00

427F36 Outside-1-3/8" door $170.00 $178.00

485F74 Outside-2-1/4" door $170.00 $178.00

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 12

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630, 722

“N” ESCUTCHEON - WROUGHT

Blank

544F93 Inside or Outside $97.00 $99.00

For Cylinder only

544F80 Inside or Outside $97.00 $99.00

For Grip only

544F76 Inside or Outside $97.00 $99.00

For Cylinder & Grip

544F77 Inside or Outside $97.00 $99.00

For Thumbturn Lever only

544F89 Inside-1-3/4" door

$97.00 $99.00544F92 Inside-1-3/8" door

544F91 Inside-2-1/4" door

For Thumbturn Lever & Grip

544F85 Inside-1-3/4" door

$97.00 $99.00544F87 Inside-2-1/4" door

544F88 Inside-1-3/8" door

For Grip & Emergency Key

544F79 Outside $97.00 $99.00

For Cylinder, Grip & Indicator

544F82 Outside-1-3/8" door

$97.00 $99.00544F83 Outside-1-3/4"door

544F84 Outside-2-1/4" door

“M” ESCUTCHEON - WROUGHT

Blank

383F82 Outside $97.00 $99.00

545F45 Inside

For Cylinder only

488F07 Outside

$97.00 $99.00

751F16 Outside - Master Ring

545F00 Inside

751F17 Inside - Master Ring

For Grip only

488F04 Outside $97.00 $99.00

544F95 Inside

For Cylinder & Grip

488F05 Outside - Conventional

$97.00 $99.00

557F29 Outside - Master Ring

544F96 Inside - Conventional

377F80 Inside - Master Ring

For Thumbturn Lever only

545F42 Inside-1-3/8"door

$97.00 $99.00545F43 Inside-1-3/4" door

545F44 Inside-2-1/4" door

For Thumbturn Lever & Grip

544F97 Inside-1-3/8" door

$97.00 $99.00544F98 Inside-1-3/4" door

544F99 Inside-2-1/4" door

For Grip & Emergency Key

544F94 Outside $97.00 $99.00

For Cylinder, Grip & Indicator

433F48 Outside-1-3/8" door

$97.00 $99.00433F49 Outside-1-3/4" door

484F90 Outside-2-1/4" door

“P” ESCUTCHEON - WROUGHT

Blank

544F46 Inside $97.00 $99.00

384F11 Outside

For Cylinder only

488F03 Outside $97.00 $99.00

544F43 Inside

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 13

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630, 722

“P” ESCUTCHEON - WROUGHT

For Grip only

488F00 Outside $97.00 $99.00

544F39 Inside

For Cylinder & Grip

488F01 Outside $97.00 $99.00

544F40 Inside

For Thumbturn Lever only

544F14 Inside-1-3/8" door

$97.00 $99.00544F44 Inside-2-1/4" door

544F45 Inside-1-3/4" door

For Thumbturn Lever & Grlp

544F13 Inside-1-3/8" door

$97.00 $99.00544F41 Inside-2-1/4" door

544F42 Inside-1-3/4" door

For Grlp & Emergency Key

544F38 Outside $97.00 $99.00

For Cylinder, Grip & Indicator

430F47 Outside-1-3/8" door

$97.00 $99.00435F00 Outside-1-3/4" door

484F76 Outside-2-1/4" door

PART NO. DESCRIPTION 613E, 630

“V” ESCUTCHEON - CAST

Blank

700F80 Outside $200.00

700F40 Inside

For Cylinder only

700F83 Outside $200.00

700F43 Inside

For Grip only

700F81 Outside $200.00

700F41 Inside

For Cylinder & Grip

700F82 Outside

$200.00

700F87 Outside - 7P & C6 (Use when collar is required)

700F42 Inside

700F47 Inside - 7P & C6 (Use when collar is required)

For Thumbturn Lever only

700F45 Inside $200.00

For Thumbturn Lever & Grip

700F44 Inside $200.00

For Grlp & Emergency Key

700F84 Outside $200.00

For Cylinder, Grip & Indicator

700F86 Outside $200.00

700F46 Inside

PART NO. DESCRIPTION LIST PRICE

Hex Wrench No Finish

264F69-8 Hex Wrench $0.62

Key Plate Packet

438F90 Key Plate Packet 612, 619, 625, 626 $19.00

605, 606, 611, 613, 619, 629**, 630** $20.00

**618, 619 finish provided to match 629, 630.

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 14

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630, 722

KNOBS – WROUGHT AND CAST

“YW” KNOB - WROUGHT

Inside Knob

502F62 $131.00 $137.00

Outside Knob & Spindle Assembly

689F33 for 1-3/4" door

$131.00 $137.00689F30 for 1-3/8" door

689F39 for 2-1/4" door

“GS” KNOB - CAST

Inside Knob

503F15 $216.00 $222.00

Outside Knob & Spindle Assembly

689F37 for 2-1/4" door

$216.00 $222.00689F31 for 1-3/4" door

689F28 for 1-3/8" door

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 625

“SS” KNOB - CAST

Inside Knob

445F38 $216.00 $222.00

Outside Knob & Spindle Assembly

445F43 for 1-3/4" door

$216.00 $222.00498F86 for 2" door

498F87 for 2-1/4" door

“GW” KNOB - WROUGHT

Inside Knob

568F11 $131.00 $137.00

Outside Knob & Spindle Assembly

689F60 for 1-3/4" door

$131.00 $137.00689F58 for 1-3/8" door

689F62 for 2-1/4" door

“BW” KNOB - WROUGHT

Inside Knob

568F12 $131.00 $137.00

Outside Knob & Spindle Assembly

502F10 for 1-3/4" door

$131.00 $137.00507F01 for 1-3/8" door

511F73 for 2-1/4"door

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 625, 629, 630

“GR” KNOB - WROUGHT REINFORCED

Inside Knob

502F27 $141.00 $147.00

Outside Knob & Spindle Assembly

689F52 for 1-3/4" door

$141.00 $147.00689F50 for 1-3/8" door

689F54 for 2-1/4" door

“BR” KNOB - WROUGHT REINFORCED

Inside Knob

502F29 $141.00 $147.00

Outside Knob & Spindle Assembly

689F53 for 1-3/4" door

$141.00 $147.00689F51 for 1-3/8" door

689F55 for 2-1/4" door

PART NO. DESCRIPTION LIST PRICE

Knob Release Tool No Finish

391F65-8 Knob Release Tool See page 5

Knob Shank Adapter No Finish

483F11-8 Knob Shank Adapter $6.00

Spring Clip

377F30-8 Spring Clip $1.50

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 15

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630, 722

“AS” LEVER - CAST

Inside Lever

670F37 $150.00 $156.00

Outside Lever & Spindle Assembly

670F64 for 1-3/8" door

$150.00 $156.00670F73 for 1-3/4" door

671F09 for 2-1/4" door

“CS” LEVER - CAST

Inside Lever

670F30 $150.00 $156.00

Outside Lever & Spindle Assembly

670F57 for 1-3/8" door

$150.00 $156.00670F66 for 1-3/4" door

671F02 for 2-1/4" door

“DS” LEVER - CAST

Inside Lever

670F32 LH/LHR $150.00 $156.00

670F31 RH/RHR

Outside Lever & Spindle Assembly

670F59 for 1-3/8" door RH/RHR

$150.00 $156.00

670F68 for 1-3/4" door RH/RHR

671F04 for 2-1/4" door RH/RHR

670F58 for 1-3/8" door LH/LHR

670F67 for 1-3/4" door LH/LHR

671F03 for 2-1/4" door LH/LHR

“ES” LEVER - CAST

Inside Lever

670F33 $150.00 $156.00

Outside Lever & Spindle Assembly

670F60 for 1-3/8" door

$150.00 $156.00670F69 for 1-3/4" door

671F05 for 2-1/4" door

“LS” LEVER - CAST

Inside Lever

670F34 $150.00 $156.00

Outside Lever & Spindle Assembly

670F61 for 1-3/8" door

$150.00 $156.00670F70 for 1-3/4" door

671F06 for 2-1/4" door

“NS” LEVER - CAST

Inside Lever

670F36 $150.00 $156.00

Outside Lever & Spindle Assembly

670F63 for 1-3/8" door

$150.00 $156.00670F72 for 1-3/4" door

671F08 for 2-1/4" door

“PS” LEVER - CAST

Inside Lever

670F38 $150.00 $156.00

Outside Lever & Spindle Assembly

670F65 for 1-3/8" door

$150.00 $156.00670F74 for 1-3/4" door

671F10 for 2-1/4" door

“RS” LEVER - CAST

Inside Lever

670F35 $150.00 $156.00

Outside Lever & Spindle Assembly

670F62 for 1-3/8" door

$150.00 $156.00

670F71 for 1-3/4" door

671F07 for 2-1/4" door

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 16

PART NO. DESCRIPTION 613E, 630 605, 606, 611, 612, 613, 618, 619, 625, 626, 629, 722

“LW” LEVER - WROUGHT

Inside Lever

493F31 $125.00 $131.00

Outside Lever & Spindle Assembly

483F79 for 1-3/8" door

$125.00 $131.00483F80 for 1-3/4" door

483F81 for 2-1/4" door

“RW” LEVER - WROUGHT

Inside Lever

493F34 $125.00 $131.00

Outside Lever & Spindle Assembly

483F82 for 1-3/8" door

$125.00 $131.00483F83 for 1-3/4" door

483F84 for 2-1/4" door

PART NO. DESCRIPTION LIST PRICE

LOCK CONVERSION KIT

See Main Price book, See ML2000 Section - Lock Body Only

NYLON BUSHING NO FINISH

118F29-9 Nylon Brushing †Order 100- $0.14

O-RING NO FINISH

340F27-9 for YW, GS inside knob †Order 100- $0.30

ROLL PIN NO FINISH

228F54-8 Roll Pin for knob $0.30

ROSE PACKET

445F82

Wrought Rose Packet- (Qty 2) 2-7/8" dia. (C)

606, 612, 619, 626, 630 $44.00

605, 611, 613, 625, 629 $60.00

445F83

Wrought Rose Packet- (Qty 2) 3-1/2" dia. (D)

606, 612, 619, 626, 630 $44.00

605, 611, 613, 625, 629 $60.00

445F84

Wrought Rose Packet- (Qty 2) 3" square (E)

606, 612, 619, 626, 630 $44.00

605, 611, 613, 625, 629 $60.00

447F24

Cast Rose Packet - (Qty 2) 2-7/8" dia. (F)

612, 619, 625, 626 $126.00

605, 606, 613 $132.00

611, 629, 630 $142.00

447F25

Cast Rose Packet- (Qty 2) 2-1/4" dia. (B)

612, 619, 625, 626 $62.00

605, 606, 613 $68.00

611, 629, 630 $78.00

487F08

Wrought Rose Packet- (Qty 2) 2-1/4" dia. (A)

612, 619, 625, 626 $38.00

605, 606, 613 $46.00

611, 629, 630 $52.00

PART NO. DESCRIPTION LIST PRICE

ROSE REINFORCEMENT PACKET NO FINISH

445F86-9 Rose Reinforcement Packet $5.00

SCREW PACKET

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

569F45 For M & P half dummy trim $4.50

429F31-7 Screw Packet for “N” Surface Mounted

Escutcheon $6.30

616F08-8 Lock mounting, spanner $6.70

584F46 Escutcheon for 1-3/4" door, spanner $4.30

384F03 Escutcheon for 2" - 2-1/4" door, spanner

616F07-8 T20 Torx®bit $9.70

SLEEVE

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

206F53 Sleeve for Cast Knob $10.50

SPACER NO FINISH

497F52-8 Spacer for Cast Knob $2.50

SPINDLES NO FINISH

33L (Lever x Lever) Spindle

499F82-8 1-3/8" door $25.00

499F83-8 1-3/4" door

499F84-8 2-1/4" door $27.00

33LK (Lever x Knob) Spindle

499F86-8 1-3/8" door $25.00

499F87-8 1-3/4" door

499F88-8 2-1/4" door $27.00

33KL (Knob x Lever) Spindle

499F90-8 1-3/8" door $25.00

499F91-8 1-3/4" door

499F92-8 2-1/4" door $27.00

†Sold only in multiples of the number indicated. Price is each.

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 17

PART NO. DESCRIPTION LIST PRICE

SPINDLE (Cont’d)

32 (Knob x Knob) Spindle

696F59-8 2-1/4" door $25.00

696F57-8 1-3/8" door $24.00

696F58-8 1-3/4" door

SPINDLE FOR KNOB HALF TRIM

303F18 1-3/8" door $24.00

303F19 1-3/4" door

303F20 2-1/4" door $25.00

INSIDE SPINDLE FOR HALF LEVER TRIM

680F34-8 1-3/8" door $14.00

680F35-8 1-3/4" door $4.20

680F36-8 2-1/4" door $8.40

HIGH SECURITY SPINDLE

445F41 1-3/4" door $23.00

498F84 2" door $24.00

498F85 2-1/4" door $25.00

VANDAL RESISTANT SPINDLE & SCREW PACK

700F65 1-3/4" door

$12.00700F66 2" door

700F67 2 -1/4" door

THIMBLE PACKET

432F86

(Qty 2) for wrought escutcheon knob trim designs

605, 606, 611, 612, 613, 619, 625, 626 $23.00

629, 630 $28.00

445F85

(Qty 2) for sectional knob trim designs

605, 606, 611, 612, 619, 625, 626 $31.00

613 $36.00

467F01* (Qty 2) for levers x large rose

605, 606, 611, 612, 619, 625, 626, 613 $17.00

THIMBLE WRENCH NO FINISH

300F68-8 Thimble Wrench See page 5

PART NO. DESCRIPTION LIST PRICE

THROUGHBOLT PACKET

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

“M” and “P” Escutcheons

433F76 1-3/8" door

$6.20433F77 1-3/4" door

433F78 2-1/4" door

“R” Escutcheon

439F33 1-3/8" door

$6.20439F34 1-3/4" door

439F35 2-1/4" door

“T” Escutcheon (spanner head)

445F31-8 1-3/4" door $10.50

498F92-8 2" to 2-1/4" door

THUMBTURN LEVER PACKET

605, 606, 611, 612, 613, 625, 626, 629, 630

519F09 for 1-3/8" door

$38.00519F10 for 1-3/4" door

519F11 for 2-1/4" door

519F12 for up to 3" door $50.00

581F96 for up to 3-1/2" door

696F39 Blank Plate $50.00

ERGONOMIC THUMBTURN LEVER PACKET FOR SECTIONAL TRIM

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

707F57 for 1-3/8" door

$54.00707F58 for 1-3/4" to 2" doors

707F59 for 2-1/4" door

707F60 for up to 3" door $54.00

706F70 for up to 4" door

ERGONOMIC THUMBTURN KIT FOR ESCUTCHEON TRIM

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

711F002 for up to 4" door (must be field cut to size) $54.00

WASHER FOR VANDAL RESISTANT TRIM

700F37-8 Washer $2.00

RETAINING RING FOR VANDAL RESISTANT TRIM

700F16-8 Retaining ring $0.60

LEVER SPINDLE SPRING FOR VANDAL RESISTANT TRIM

700F36-7 Lever spindle spring $0.78

*Note: Recommend Rose Reinforcement packet

(445F86-9) with this item.

ML2000/ML2000HS Mortise Lock Series

January 1, 2014Parts Price List. 18

VINEYARD™ COLLECTION TRIM

†Sold only in multiples of the number indicated. Price is each.

Notes: 1. Kit contains lock parts only. Order knobs, spindles, escutcheons, cylinders and collars separately.

2. Kit contains armored front, specify finish.

PART NO. DESCRIPTION 613E, 626 *605E , *606E, 619, 625

INSIDE LEVERS

692F632 Frascati LH/LHR

$196.00 $206.00

692F642 Frascati RH/RHR

692F682 Tuscany

692F662 Zinfandel LH/LHR

692F672 Zinfandel RH/RHR

692F652 Merlot $180.00 $190.00

OUTSIDE LEVERS

692F762 Frascati for 1 3/4" door LH/LHR

$196.00 $206.00

692F752 Frascati for 1 3/4" door RH/RHR

692F962 Tuscany for 1 3/4" door

692F952 Zinfandel for 1 3/4" door LH/LHR

692F942 Zinfandel for 1 3/4" door RH/RHR

692F932 Merlot for 1 3/4" door $180.00 $190.00

L ESCUTCHEON - CAST

Blank

$160.00 $170.00

692F862 Inside

For Cylinder Only

694F322 Inside

694F522 Outside

For Grip Only

694F312 Inside

694F442 Outside

For Cylinder & Grip

694F332 Inside

694F562 Outside

For Thumbturn Lever Only

694F352 Inside

For Thumbturn Lever & Grip

694F392 Inside

For Grip & Emergency Key

694F482 Outside

For Cylinder, Grip & Indicator

694F602 Outside

For Grip x Plug Only

694F682 Outside

For Grip x Plug Only x Indicator

694F722 Outside

ROSES (PAIR)

694F802 G-Rose

(All functions) $181.00 $191.00

CL3200 Cylindrical Lock Series Bolt

January 1, 2014Parts Price List. 19

PART NO. DESCRIPTION LIST

PRICE

480F70-8 ANSI Strike Screw Packet $1.60

496F59-8 Emergency key (20 function) $9.00

496F78-3 Front (dead locking latch) $46.00

496F84-8 Outside Rack $9.00

496F89-3 Front (plain latch) $46.00

496F97-7 Lever, NSD cylinder, stainless $260.00

496F97 Lever, NSD cylinder, std. $227.00

496F98-7 Lever, NSD plain, stainless $260.00

496F98 Lever, NSD plain, std. $227.00

496F99 Lever, NSD button std. $245.00

496F99-7 Lever, NSD button, stainless $279.00

497F00 Lever, NSD privacy, std. $245.00

497F00-7 Lever, NSD privacy, stainless $279.00

497F01-2 Rose Outside $106.00

497F01-7 Rose Outside, stainless $156.00

497F02-2 Rose Inside $106.00

497F02-7 Rose Inside, stainless $156.00

497F19 Turn Button CL3220, 40, 61 $63.00

497F19-7 Turn Button, stainless $67.00

497F20 Inside Cassette, except CL3255 $168.00

497F22-5 Outside Cassette $164.00

497F23-8 Retaining Ring $0.54

497F24 Screw Packet for 1-3/8" to 1-3/4" door $22.00

497F25 Screw Packet for 2" to 2-1/4" door $22.00

497F26-8 Emergency Key $1.30

497F41 Outside Cassette, CL3232, CL3257 $158.00

497F79-7 Turn Button CL3251, stainless $53.00

LOCKSET PARTS

PART NO. DESCRIPTION LIST

PRICE

497F79 Turn Button CL3251 $47.00

497F80-8 Latch RH/LH for CL3220, 30, 40, 61

$86.00

497F81-8 Latch RHR/LHR for CL3220, 30, 40, 61

497F82-8 Latch RH/LH for CL3232, 51, 55, 57

497F83-8 Latch RHR/LHR for CL3232, 51, 55, 57

497F86-8 Latch RH/LH for CL3210

497F87-8 Latch RHR/LHR for CL3210

498F79-5 Inside Cassette $158.00

499F43-9 Turn Button Cam $3.60

499F46 Emergency Release Turn Button, CL3230 $32.00

501F08-8 Rack Spring $0.80

501F09-5 Outside Cassette Sub Assembly $158.00

509F54-8 Tru-Arc Plier $80.00

510F64-2 Lever, NSD CL3255, std. $222.00

510F64-7 Lever, NSD CL3255, stainless $272.00

510F67-8 Curved Spring Washer $0.80

510F69-8 Drive Pin Assembly $9.00

510F71-5 Outside Cassette, CL3255 $158.00

526F47-5 Inside Cassette $100.00

526F49-5 Inside Cassette $102.00

549F14-8 Lazy Cam Driver (Used on CL3255 only) $32.00

583F79 Cylinder Driver (Throw Member)

For all locking functions except CL3255 $2.60

549F15-8 Lazy Cam Sub Assembly $38.00

557L30* ANSI Curved Lip Strike

(for doors without silencers)

$26.00

557L31* ANSI Curved Lip Strike

(for doors with heavy weather stripping)

557L36* Curved Lip Box Strike

(for doors without silencers)

557L37* Curved Lip Box Strike

(for doors with heavy weather stripping)

*Lip Length for 557L30, 31, 36 & 37 is as follows -1", 1-1/8", 1-1/4", 1-3/8", 1-1/2", 1-3/4", 2", 2-1/2", 3"

PART NO. DESCRIPTION 613E, 626 605, 606, 611, 612, 613, 618, 619, 625, 629, 630

MISCELLANEOUS STRIKES FOR CL3200 SERIES LOCKSETS

496L90 ANSI Curved Lip Strike $17.00 $19.00

497L91 Curved Lip Box Strike $12.00 $19.00

CL3300 Cylindrical Lock Series

Extra Heavy-Duty Lever Lockset

January 1, 2014Parts Price List. 20

LOCKSET PARTS

PART NO. DESCRIPTION LIST PRICE

CHASSIS ASSEMBLY STANDARD

682F408 for CL3310 $129.00

682F508 for CL3320, CL3361 $137.00

682F468 for CL3329 $165.00

682F458 for CL3332 $159.00

682F428 for CL3340 $155.00

682F418 for CL3340NT, CL3351, CL3357, CL3393 $139.00

697F528 for CL3352, CL3355 $165.00

796F478 for CL3359 $139.00

682F448 for CL3362 $159.00

682F478 for CL3372

682F488 for CL3380, CL3390 $127.00

682F498 for CL3381, CL3391 $149.00

CHASSIS ASSEMBLY, IC

682F808 for CL3361 $155.00

682F768 for CL3329 $173.00

682F758 for CL3332 $167.00

682F718 for CL3351, CL3357, CL3393 $151.00

697F538 for CL3352 $167.00

697F498 for CL3355

796F488 for CL3359 $151.00

682F748 for CL3362 $167.00

682F778 for CL3372

682F798 for CL3381, CL3391 $159.00

CYLINDER PARTS

622F308 Tailpiece 6-pin $1.60

682F298 Tailpiece 7-pin $1.50

682F918 Corbin Russwin IC core kit $4.70

682F958 SFIC (Best®) IC tailpiece kit $4.70

682F969 Sargent®tailpiece kit $15.00

697F942 Schlage®IC tailpiece kit $19.00

682F398 Schlage®tailpiece kit $5.90

HOUSING ASSEMBLIES

682F568 Spring housing O/S $28.00

710F638 Spring housing I/S 1 3/4"-2" $24.00

710F648 Spring housing I/S 2 1/4" $24.00

682F578 Spring housing CL3380, CL3381 $26.00

686F858 Dummy housing I/S $90.00

686F868 Dummy housing O/S $79.00

LEVERS 1-3/4" TO 2" DOORS

563F945 NZD - Plain

$83.00

563F955 NZD - Cylinder button

714F065 NZD - CL3352 inside

563F965 NZD - Emergency key hole

585F715 NZD - IC cylinder - 6 pin

$85.00

714F365 NZD - IC cylinder - 6 pin CL3352 inside

600F415 NZD - IC cylinder - 7 pin

714F375 NZD - IC cylinder - 7 pin CL3352 inside

596F825 NZD - SFIC (Best®) cylinder

$87.00

714F425 NZD - SFIC (Best®) cylinder CL3352 inside

690F975 NZD - Schlage®IC cylinder

714F455 NZD - Schlage®IC cylinder CL3352 inside

563F885 AZD - Plain

$83.00

563F895 AZD - Cylinder or button

714F005 AZD - CL3352 inside

563F905 AZD - Emergency key hole

585F705 AZD - IC cylinder - 6 pin

$85.00

714F305 AZD - IC cylinder - 6 pin CL3352 inside

600F425 AZD - IC cylinder - 7 pin

714F315 AZD - IC cylinder - 7 pin CL3352 inside

695F075 AZD - Sargent®cylinder

714F035 AZD - Sargent®cylinder CL3352 inside

PART NO. DESCRIPTION LIST PRICE

LEVERS 1-3/4" TO 2" DOORS (Cont'd)

799F505 PZD - plain

$83.00

799F515 PZD - Cylinder or button

799F535 PZD - CL3352 inside

799F525 PZD - Emergency key hole

799F565 PZD - IC Cylinder - 6 pin

$85.00

799F575 PZD - IC Cylinder - 6 pin CL3352 inside

799F585 PZD - IC Cylinder - 7 pin

799F595 PZD - IC Cylinder - 7 pin CL3352 inside

799F805 PZD - SFIC (Best®) cylinder

$87.00

799F815 PZD - SFIC (Best®) cylinder CL3352 inside

799F825 PZD - Schlage®IC cylinder

799F835 PZD - Schlage®IC cylinder CL3352 inside

799F545 PZD - Sargent®cylinder $85.00

799F555 PZD - Sargent®cylinder CL3352 inside

712F205 FZD - LH plain

$85.00

712F215 FZD - LH cylinder or button

712F385 FZD - LH CL3352 inside

712F225 FZD - LH emergency key hole

715F245 FZD - LH IC cylinder - 6 pin

$87.00

712F405 FZD - LH IC cylinder - 6 pin CL3352 inside

714F255 FZD - LH IC cylinder - 7 pin

712F415 FZD - LH IC cylinder - 7 pin CL3352 inside

712F265 FZD - LH SFIC (Best®) cylinder

$89.00

712F425 FZD - LH SFIC (Best®) cylinder CL3352 inside

712F275 FZD - LH Schlage®IC cylinder

712F435 FZD - LH Schlage®IC cylinder CL3352 inside

712F235 FZD - LH Sargent®cylinder $87.00

712F395 FZD - LH Sargent®cylinder CL3352 inside

712F505 FZD - RH plain

$85.00

712F515 FZD - RH cylinder or button

712F685 FZD - RH CL3352 inside

712F525 FZD - RH emergency key hole

712F545 FZD - RH IC cylinder - 6 pin

$87.00

712F705 FZD - RH IC cylinder - 6 pin CL3352 inside

712F555 FZD - RH IC cylinder - 7 pin

712F715 FZD - RH IC cylinder - 7 pin CL3352 inside

712F565 FZD - RH SFIC (Best®) cylinder

$89.00

712F725 FZD - RH SFIC (Best®) cylinder CL3352 inside

712F575 FZD Schlage®IC cylinder

712F735 FZD Schlage®IC cylinder CL3352 inside

712F535 FDZ - RH Sargent®cylinder $87.00

712F695 FDZ - RH Sargent®cylinder CL3352 inside

LEVERS 2 1/4" DOORS

684F825 NZD - Plain

$83.00

684F835 NZD - Cylinder or button

714F215 NZD - CL3352 inside

684F845 NZD - Emergency key hole

684F865 NZD - IC cylinder - 6 pin

$85.00

714F545 NZD - IC cylinder - 6 pin CL3352 inside

685F875 NZD - IC cylinder - 7 pin

714F555 NZD - IC cylinder - 7 pin CL3352 inside

684F885 NZD - SFIC (Best®) cylinder

$87.00

714F605 NZD - SFIC (Best®) cylinder CL3352 inside

690F985 NZD - Schlage®IC cylinder

714F635 NZD - Schlage®IC cylinder CL3352 inside

684F855 NZD - Sargent®cylinder $85.00

714F275 NZD - Sargent®cylinder CL3352 inside

CL3300 Cylindrical Lock Series

Extra Heavy-Duty Lever Lockset

January 1, 2014Parts Price List. 21

LOCKSET PARTS

PART NO. DESCRIPTION

LIST PRICE

LEVERS 2 1/4" DOORS (Cont'd)

684F775 AZD - Plain

$83.00

684F785 AZD - Cylinder or button

714F155 AZD - CL3352 inside

684F795 AZD - Emergency key hole

684F805 AZD - IC cylinder - 6 pin

$85.00

714F435 AZD - IC cylinder - 6 pin CL3352 inside

684F815 AZD - IC cylinder - 7 pin

714F495 AZD - IC cylinder - 7 pin CL3352 inside

697F995 AZD - Sargent®cylinder

714F185 AZD - Sargent®cylinder CL3352 inside

799F605 PZD - Plain

$83.00

799F615 PZD - Cylinder or button

799F635 PZD - CL3352 inside

799F625 PZD - Emergency key hole

799F665 PZD - IC cylinder - 6 pin

$85.00

799F675 PZD - IC cylinder - 6 pin CL3352 inside

799F685 PZD - IC cylinder - 7 pin

799F695 PZD - IC cylinder - 7 pin CL3352 inside

799F845 PZD - SFIC (Best®) cylinder

$87.00

799F855 PZD - SFIC (Best®) cylinder CL3352 inside

799F865 PZD - Schlage®IC cylinder

799F875 PZD - Schlage IC cylinder CL3352 inside

799F645 PZD - Sargent®cylinder $85.00

799F655 PZD - Sargent®cylinder CL3352 inside

712F305 FZD - LH plain

$85.00

712F315 FZD - LH cylinder or botton

712F445 FZD - LH CL3352 inside

712F325 FZD - LH emergency key hole

712F345 FZD - LH IC cylinder - 6 pin

$87.00

712F465 FZD - LH IC cylinder - 6 pin CL3352 inside

712F355 FZD - LH IC cylinder - 7 pin

712F475 FZD - LH IC cylinder - 7 pin CL3352 inside

712F365 FZD - LH SFIC (Best®) cylinder

$89.00

712F485 FZD - LH SFIC (Best®) cylinder CL3352 inside

712F375 FZD - LH Schlage®IC cylinder

712F495 FZD - LH Schlage®IC cylinder CL3352 inside

712F335 FZD - LH Sargent®cylinder $87.00

712F455 FZD - LH Sargent®cylinder CL3352 inside

712F605 FZD - RH plain

$85.00

712F615 FZD - RH cylinder or button

712F745 FZD - RH CL3352 inside

712F625 FZD - RH emergency key hole

712F645 FZD - RH IC cylinder - 6 pin

$87.00

712F765 FZD - RH IC cylinder - 6 pin CL3352 inside

712F655 FZD - RH IC cylinder - 7 pin

712F775 FZD - RH IC cylinder - 7 pin CL3352 inside

712F665 FZD - RH SFIC (Best®) cylinder

$89.00

712F785 FZD - RH SFIC (Best®) cylinder CL3352 inside

712F675 FZD - RH Schlage®IC cylinder

712F795 FZD - RH Schlage®IC cylinder CL3352 inside

712F635 FZD - RH Sargent®cylinder $87.00

712F755 FZD - RH Sargent®cylinder CL3352 inside

PART NO. DESCRIPTION

LIST PRICE

LEVER INSERT

585F729 Lever insert (black) $0.20

LATCH ASSEMBLY

2 3/4" Backsets

586F16 Plain, square corner $59.00

596F66 Plain, round corner

586F17 Deadlocking square corner

$67.00

596F67 Deadlocking round corner

586F18 Throw-Off square corner

596F68 Throw-Off round corner

601F69 3/4" Through deadlocking fire latch

square corner $96.00

3 3/4" Backsets

586F80 Plain, square corner $112.00

586F86 Plain, round corner

586F81 Deadlocking square corner

$120.00

586F87 Deadlocking round corner

586F82 Throw-Off square corner

586F88 Throw-Off round corner

5" Backsets

598F20 Plain, square corner $91.00

601F24 Plain, round corner

598F21 Deadlocking square corner

$99.00

601F25 Deadlocking round corner

598F22 Throw-Off square corner

601F26 Throw-Off round corner

LATCH & STRIKE SCREW PACKS

604F228 Fin Latch & ANSI (4 7/8") strike - phillips head $3.90

604F238 Fin Latch & ANSI (4 7/8") strike - spanner head $11.00

604F248 Fin Latch & ANSI (4 7/8") strike - Torx head $11.00

604F268 Fin Latch & T (2 3/4") strike - phillips head $3.80

604F278 Fin Latch & T (2 3/4") strike - spanner head $11.00

604F288 Fin Latch & T (2 3/4") strike - Torx head $11.00

480F688 Fin Rabbetted Strike - phillips head $3.90

596F618 Fin Rabbetted Strike - spanner head $11.00

596F628 Rabbetted Strike - Torx head $11.00

January 1, 2014Parts Price List. 22

CL3300 Cylindrical Lock Series

Extra Heavy-Duty Lever Lockset

LOCKSET PARTS

PART NO. DESCRIPTION LIST PRICE

MOUNTING SCREW PACKS

682F608 1 3/4" - 2" doors (pre June 2004) $4.50

710F658 1 3/4" - 2" doors (after June 2004)

682F618 Over 2" (pre June 2004) $8.60

710F668 Over 2" (after June 2004)

682F628 CL3380, CL3381 1 3/4" - 2" doors $4.50

682F638 CL3380, CL3381 over 2" doors $8.60

682F64 Fin CL3390, CL3391 1 3/4" - 2" phillips head $6.50

682F67 Fin CL3390, CL3391 1 3/4" - 2" spanner head $11.00

682F68 Fin CL3390, CL3391 1 3/4" - 2" Torx head $11.00

682F65 Fin CL3390, CL3391 over 2" phillips head $35.00

682F86 Fin CL3390, CL3391 over 2" spanner head $38.00

682F87 Fin CL3390, CL3391 over 2" Torx head $40.00

684F44 Fin CL3350 Half Dummy Trim - phillips head $8.60

684F45 Fin CL3350 Half Dummy Trim - spanner head $38.00

684F46 Fin CL3350 Half Dummy Trim - Torx head $40.00

684F528 CL3370 Half Dummy Trim $4.50

BUTTONS

585F76 Fin Turnbutton CL3351 $15.50

585F77 Fin Pushbutton CL3320, CL3340, CL3361

$13.50585F78 Fin Hotel button CL3329

585F79 Fin Slotted button CL3393

CHASSIS PARTS

682F255 Flange O/S $3.70

682F265 Flange I/S $3.10

796F105 Flange I/S $3.70

682F225 Retractor $3.70

678F417 Spring Retractor $0.10

682F218 Frame $1.60

685F418 Rollback SA, Non-Locking $4.00

685F428 Rollback SA, (for std. cylinder only)

685F448 Rollback SA, (for IC core cylinder only) $11.50

682F328 Rollback SA, (for std. cylinder only)

$9.00682F378 Rollback SA, (for IC core cylinder only)

682F388 Rollback SA, Outside

678F325 Rollback, Auxiliary $3.70

682F235 Rollback, Auxiliary $2.70

682F335 Rollback, Auxiliary SA $4.00

682F245 Rollback, Auxiliary $2.70

796F495 Rollback, Auxiliary $15.00

682F288 Dog, Locking $0.60

584F779 Insert, Locking Dog $0.32

586F628 Spring, Chassis $0.10

596F808 Spring, Chassis $0.44

678F355 Follower, Cam $1.20

678F288 Catch, Linkage Bar $1.20

699F238 Catch, Linkage Bar

$4.00

586F838 Bar SA, Linkage

584F918 Bar SA, Linkage

699F247 Bar SA, Linkage

708F368 Housing Chassis $2.50

678F428 Ring, Retaining $0.40

585F819 Insert, Support Cylinder

(for std. cylinder only) $0.10

678F368 Staff, Apartment $1.50

678F378 Staff (Utility)

678F388 Staff (Communication) $2.50

584F898 Staff $3.10

678F308 Staff $1.70

584F938 Tailpiece, Patio $4.00

699F207 Spring $0.10

PART NO. DESCRIPTION LIST PRICE

CHASSIS PARTS (Cont'd)

584F858 Sleeve (institution) $4.00

699F218 Insert, Hotel, Standard Cylinder

$5.00699F228 Insert, Hotel, IC Cylinder

697F555 Cam & Tub Assembly

584F908 Driver, Thumbturn $6.00

547F988 Spring, Lever $0.10

697F425 Direct, Outside $1.70

697F409 Spacer $0.22

697F468 Dog, Locking $0.84

697F412 Tube $1.10

697F448 Bar, Locking $0.84

697F455 Follower, Cam $1.10

697F475 Cam & Tube Assembly $5.00

707F958 Plate, Armer $1.10

January 1, 2014Parts Price List. 23

CL3300 Cylindrical Lock Series

Extra Heavy-Duty Lever Lockset

LOCKSET PARTS

ROSES

678F25 Fin Rose $22.00

598F59 Fin Blank Rose $24.00

710F618 Rose liner I/S 1 3/4" - 2" after June 2004 $3.60

710F628 Rose liner I/S over 2" after June 2004 $4.30

678F248 Rose liner O/S 1 3/4" - 2"

678F498 Rose liner O/S over 2" $5.00

586F51 Fin Thumbturn ass'y 1 3/4" - 2" $72.00

686F88 Fin Thumbturn ass'y over 2"

682F788 Rose liner CL3380, CL3381 $20.00

STRIKES - 4 7/8" ANSI CURVED LIP

217L13M016 1" Lip Length

$16.00

217L13M018 1 1/8" Lip Length

217L13M020 1 1/4" Lip Length

217L13M022 1 3/8" Lip Length

217L13M024 1 1/2" Lip Length

217L13M028 1 3/4" Lip Length

217L13M032 2" Lip Length

$17.00

217L13M036 2 1/4" Lip Length

217L13M040 2 1/2" Lip Length

217L13M044 2 3/4" Lip Length

217L13M048 3" Lip Length

STRIKES - 2 3/4" T- CURVED LIP

586L19M016 1" Lip Length

$17.00

586L19M018 1 1/8" Lip Length

586L19M020 1 1/4" Lip Length

586L19M022 1 3/8" Lip Length

586L19M024 1 1/2" Lip Length

586L19M028 1 3/4" Lip Length

586L19M032 2" Lip Length

$19.00

586L19M036 2 1/4" Lip Length

586L19M040 2 1/2" Lip Length

586L19M044 2 3/4" Lip Length

586L19M048 3" Lip Length

STRIKE BOX

120F768 4 7/8" ANSI strike box $3.30

RABBETTED STRIKE

Front Plate Rabbetted Strike

315F93 Fin 606, 612, 619, 626 $46.00

605, 611, 613, 625 $48.00

Rabbetted Strike

315F94 Fin 606, 612, 619, 626 $46.00

605, 611, 613, 625 $48.00

601F283 Fin Rabbetted Strike& Front $77.00

EMERGENCY RELEASE TOOL

596F548 Emergency Release Tool (CL3320) $1.00

601F829 Emergency Release Label (CL3320)

PART NO. DESCRIPTION

LIST PRICE

PART NO. DESCRIPTION

LIST PRICE

CL3500 Cylindrical Lock Series

Heavy-Duty Lever Lockset

January 1, 2014Parts Price List. 24

PART NO. DESCRIPTION LIST PRICE

BUTTONS ALL FINISH

585F762 CL3551 (Turn Button) $15.50

585F772 CL3520, 61 (Push Button) $13.50

CASSETTE HOUSING O/S NO FINISH

796F378 Standard $24.00

686F858 CL3550, 70 $90.00

CASSETTE HOUSING I/S NO FINISH

796F408 CL3580, 81 $17.00

686F868 CL3570 $79.00

796F398 Standard I/S Spring Housing $11.00

CHASSIS ASSEMBLY, STANDARD NO FINISH

796F208 CL3510 $67.00

796F218 CL3520, 61 $91.00

796F248 CL3580 $93.00

796F228 CL3551, 57 $93.00

796F238 CL3555 $97.00

796F258 CL3581 $112.00

796F268 CL3582 $136.00

CHASSIS ASSEMBLY, IC NO FINISH

796F318 CL3561 $97.00

796F328 CL3551, 57 $99.00

796F338 CL3855 $103.00

796F358 CL3581 $118.00

796F368 CL3582 $142.00

CYLINDER PARTS NO FINISH

622F308 Tailpiece 6-Pin $1.60

682F298 Tailpiece 7-pin $1.50

682F398 M06 - Schlage® tailpiece kit $5.90

682F969 M09 - Sargent® tailpiece kit $15.00

682F918 C6/C7 - IC tailpiece kit $4.70

682F958 M08 - small format IC kit $4.70

691F292 M69 - Schlage® IC tailpiece kit $19.00

HOUSING ASSEMBLIES

796F388 Housing Assembly, I/S, D134 $17.00

796F398 Housing Assembly, I/S, D138 $13.00

PART NO. DESCRIPTION LIST

PRICE

LATCHES ALL FINISH

Deadlatches

599F92 2-3/8" backset x 1" front

$52.00

599F95 2-3/8" backset x 1" round corner

599F98 2-3/8" backset x 1-1/8" front

600F01 2-3/8" backset x 1-1/8" round corner

600F04 2-3/4" backset x 1" front

600F07 2-3/4" backset x 1" round corner

600F10 2-3/4" backset x 1-1/8" front

600F13 2-3/4" backset x 1-1/8" round corner

600F63 3-3/4" backset x 1-1/8" front $76.00

600F66 3-3/4" backset x 1-1/8" round corner

600F69 5" backset x 1-1/8" front $78.00

600F72 5" backset x 1-1/8" round corner

Deadlatches with release (CL3620 & 29)

599F93 2-3/8" backset x 1" front

$52.00

599F96 2-3/8" backset x 1" round corner

599F99 2-3/8" backset x 1-1/8" front

600F02 2-3/8" backset x 1-1/8" round corner

600F05 2-3/4" backset x 1" front

600F08 2-3/4" backset x 1" round corner

600F11 2-3/4" backset x 1-1/8" front

600F14 2-3/4" backset x 1-1/8" round corner

600F64 3 3/4" backset x 1 1/8" front $76.00

600F67 3-3/4" backset x 1-1/8" round corner

600F70 5" backset x 1 1/8" front $78.00

600F73 5" backset x 1-1/8" round corner

Spring Latches (CL3610)

599F91 2-3/8" backset x 1" front

$46.00

599F94 2-3/8" backset x 1" round corner

599F97 2-3/8" backset x 1-1/8" front

600F00 2-3/8" backset x 1-1/8" round corner

600F03 2-3/4" backset x 1" front

600F06 2-3/4" backset x 1" round corner

600F09 2-3/4" backset x 1-1/8" front

600F12 2-3/4" backset x 1-1/8" round corner

600F62 3-3/4" backset x 1-1/8" front $66.00

600F65 3-3/4" backset x 1-1/8" round corner

600F68 5" backset x 1-1/8" front $68.00

600F71 5" backset x 1-1/8" round corner

CL3500 Cylindrical Lock Series

Heavy-Duty Lever Lockset

January 1, 2014Parts Price List. 25

PART NO. DESCRIPTION LIST PRICE

LEVERS ALL FINISH

598F815 AZD x plain $69.00

598F825 AZD x cylinder or button $69.00

598F835 AZD x emergency hole $69.00

598F905 AZD x C6 IC 6-pin $71.00

599F275 AZD x C7 IC 7-pin $71.00

797F845 NZD x plain $69.00

797F855 NZD x cylinder or button $69.00

797F865 NZD x emergency hole $69.00

797F875 NZD x M09 Sargent® cylinder $71.00

797F915 NZD x C6 IC 6-pin $71.00

797F925 NZD x C7 IC 7-pin $71.00

797F935 NZD x M69 Schlage IC $73.00

797F945 NZD x M08 small format IC $73.00

798F115 PZD x plain

$69.00798F125 PZD x cylinder or button

798F135 PZD x emergency hole

798F145 PZD x M09 Sargent® cylinder

$71.00798F155 PZD x C6 IC 6-pin

798F165 PZD x C7 IC 7-pin

798F175 PZD x M69 Schlage® IC $73.00

798F185 PZD x M08 small format IC

LEVER INSERT ALL FINISH

598F809 Standard $0.12

MOUNTING SCREW PACK

796F118 Standard $3.20

797F828 Standard - CL3580, 81 $10.00

684F448 CL3550 (ALL FINISH) $8.60

684F528 CL3570 $4.50

ROSES ALL FINISH

678F252 Standard $22.00

598F592 Blank - CL3580, 81 $24.00

ROSE LINER O/S NO FINISH

678F248 Standard $4.30

682F788 CL3580, 81 $20.00

SCREW PACKS FOR LATCH & STRIKE

604F228 For Latch & ANSI Strike $3.90

604F268 For Latch & (T strike) $3.80

PART NO. DESCRIPTION LIST PRICE

STRIKES NO FINISH

ANSI Curved Lip Strike

217L13M016 1" Lip Length

$16.00

217L13M018 1-1/8" Lip Length

217L13M020 1-1/4" Lip Length

217L13M022 1-3/8" Lip Length

217L13M024 1-1/2" Lip Length

217L13M028 1-3/4" Lip Length

217L13M032 2" Lip Length

$17.00

217L13M036 2-1/4" Lip Length

217L13M040 2-1/2" Lip Length

217L13M044 2-3/4" Lip Length

217L13M048 3" Lip Length

STRIKE BOX NO FINISH

120F768 M17 - ANSI wrought $3.30

025F858 Curved lip (T strike) $2.40

CL3600 Cylindrical Lock Series

Heavy-Duty Lever Locksets

January 1, 2014Parts Price List. 26

PART NO. DESCRIPTION LIST

PRICE

BUTTONS ALL FINISHES

585F77 CL3620 $13.50

585F76 CL3651 $15.50

LATCHES 605, 606, 611, 612,

613, 619, 625, 626

Deadlatches

599F92 2-3/8" backset x 1" front

$52.00

599F95 2-3/8" backset x 1" round corner

599F98 2-3/8" backset x 1-1/8" front

600F01 2-3/8" backset x 1-1/8" round corner

600F04 2-3/4" backset x 1" front

600F07 2-3/4" backset x 1" round corner

600F10 2-3/4" backset x 1-1/8" front

600F13 2-3/4" backset x 1-1/8" round corner

600F63 3-3/4" backset x 1-1/8" front $76.00

600F66 3-3/4" backset x 1-1/8" round corner

600F69 5" backset x 1-1/8" front $78.00

600F72 5" backset x 1-1/8" round corner

Deadlatches with release (CL3620 & 29)

599F93 2-3/8" backset x 1" front

$52.00

599F96 2-3/8" backset x 1" round corner

599F99 2-3/8" backset x 1-1/8" front

600F02 2-3/8" backset x 1-1/8" round corner

600F05 2-3/4" backset x 1" front

600F08 2-3/4" backset x 1" round corner

600F11 2-3/4" backset x 1-1/8" front

600F14 2-3/4" backset x 1-1/8" round corner

600F64 3 3/4" backset x 1 1/8" front $76.00

600F67 3-3/4" backset x 1-1/8" round corner

600F70 5" backset x 1 1/8" front $78.00

600F73 5" backset x 1-1/8" round corner

Spring Latches (CL3610)

599F91 2-3/8" backset x 1" front

$46.00

599F94 2-3/8" backset x 1" round corner

599F97 2-3/8" backset x 1-1/8" front

600F00 2-3/8" backset x 1-1/8" round corner

600F03 2-3/4" backset x 1" front

600F06 2-3/4" backset x 1" round corner

600F09 2-3/4" backset x 1-1/8" front

600F12 2-3/4" backset x 1-1/8" round corner

600F62 3-3/4" backset x 1-1/8" front $66.00

600F65 3-3/4" backset x 1-1/8" round corner

600F68 5" backset x 1-1/8" front $68.00

600F71 5" backset x 1-1/8" round corner

PART NO. DESCRIPTION LIST

PRICE

LEVERS

598F82-5 AZD cyl. or button $69.00

599F22-5 AZD cyl. or button, knurled $89.00

598F81-5 AZD plain $69.00

599F21-5 AZD plain, knurled $89.00

598F83-5 AZD privacy key hole CL3620 $69.00

599F23-5 AZD privacy key hole, knurled $89.00

598F90-5 AZD IC 6-pin $71.00

599F30-5 AZD IC 6-pin, knurled $91.00

599F27-5 AZD IC 7-pin $71.00

599F28-5 AZD IC 7-pin, knurled $91.00

ROSES 605, 606, 611, 612,

613, 619, 625, 626

598F59 blank $24.00

598F712 standard $22.00

ROSE LINERS

678F248 All except CL3650, 70, 80, 81 $4.30

682F788 CL3680, 81 $20.00

SCREW PACKS FOR LATCH & STRIKE 605, 612,

613, 619, 626

604F22-8 ANSI x standard screws $3.90

604F23-8 ANSI x spanner head screws $11.00

604F24-8 ANSI x Torx®screws $11.00

604F25-8 ANSI x hex socket screws $3.50

604F26-8 Curved lip box strike x standard $3.80

604F27-8 Curved lip box strike x spanner head $12.00

604F28-8 Curved lip box strike x Torx $11.00

604F29-8 Curved lip box strike x hex socket $6.20

CL3600 Cylindrical Lock Series

Heavy-Duty Lever Locksets

January 1, 2014Parts Price List. 27

PART NO. DESCRIPTION LIST PRICE

SCREW PACKS, LOCK MOUNTING 605, 606, 611,

612, 613, 619, 625, 626

796F118 All except CL3650, 70, 80, 81 $3.20

682F628 CL3680, 81 $4.50

STRIKE ALL FINISHES

ANSI Curved Lip Strike

217L13M016 1" Lip Length

$16.00

217L13M018 1-1/8" Lip Length

217L13M020 1-1/4" Lip Length

217L13M022 1-3/8" Lip Length

217L13M024 1-1/2" Lip Length

217L13M028 1-3/4" Lip Length

217L13M032 2" Lip Length

$17.00

217L13M036 2-1/4" Lip Length

217L13M040 2-1/2" Lip Length

217L13M044 2-3/4" Lip Length

217L13M048 3" Lip Length

PART N.O. DESCRIPTION LIST

PRICE

CURVED LIP BOX STRIKE ALL FINISHES

586L19M016 1" Lip Length

$17.00

586L19M018 1-1/8" Lip Length

586L19M020 1-1/4" Lip Length

586L19M022 1-3/8" Lip Length

586L19M024 1-1/2" Lip Length

586L19M028 1-3/4" Lip Length

586L19M032 2" Lip Length $19.00

586L19M036 2-1/4" Lip Length

$19.00

586L19M040 2-1/2" Lip Length

586L19M044 2-3/4" Lip Length

586L19M048 3" Lip Length

FULL LIP STRIKE

607F76 1-1/8" lip to center $7.00

THUMBTURNS & LINER 605, 606, 611,

612, 613, 619, 625, 626

586F51 thumbturn, CL3690 & 91 $72.00

598F29 thumbturn, CL3691 lead lined $82.00

598F54-8 thumbturn liner, CL3690 & 91 $8.20

CL3800 Cylindrical Lock Series Grade 2

Key-In-Lever Lockset

January 1, 2014Parts Price List. 28

PART NO. DESCRIPTION LIST PRICE

BUTTONS ALL FINISH

585F762 CL3851 (Turn Button) $15.50

585F772 CL3820, 40, 61 (Push Button) $13.50

585F792 CL3893 (Slotted Turn Button) $13.50

CASSETTE HOUSING O/S NO FINISH

796F378 Standard $24.00

686F858 CL3850, 70 $90.00

CASSETTE HOUSING I/S NO FINISH

796F398 Standard - 1-3/8" to 1-7/8" door $13.00

797F808 D214 - 2" to 2-1/4" door $17.00

796F408 CL3880, 81 $17.00

686F868 CL3870 $79.00

CHASSIS ASSEMBLY, STANDARD NO FINISH

797F618 CL3810 $45.00

797F628 CL3820, 61 $51.00

797F648 CL3840 $51.00

797F788 CL3840NT $51.00

797F658 CL3880, 90 $45.00

797F668 CL3851, 57, 93 $55.00

797F688 CL3855 $55.00

797F708 CL3881, 91 $55.00

797F728 CL3832 $59.00

797F748 CL3862 $59.00

797F768 CL3872 $59.00

CHASSIS ASSEMBLY, IC NO FINISH

797F638 CL3861 $53.00

797F678 CL3851, 57, 93 $57.00

797F698 CL3855 $57.00

797F718 CL3881, 91 $57.00

797F738 CL3832 $61.00

797F758 CL3862 $61.00

797F778 CL3872 $61.00

PART NO. DESCRIPTION LIST PRICE

CYLINDER PARTS NO FINISH

622F308 Tailpiece 6-Pin $1.60

682F298 Tailpiece 7-pin $1.50

682F969 M06 - Schlage®tailpiece kit $15.00

682F969 M09 - SARGENT®tailpiece kit $15.00

682F918 C6/C7 - IC tailpiece kit $4.70

682F958 M08 - small format IC kit $4.70

697F942 M69 - Schlage®IC tailpiece kit $19.00

LATCHES ALL FINISH

Deadlatches

599F92 2-3/8" backset x 1" front

$52.00

599F95 2-3/8" backset x 1" round corner

599F98 2-3/8" backset x 1-1/8" front

600F01 2-3/8" backset x 1-1/8" round corner

600F04 2-3/4" backset x 1" front

600F07 2-3/4" backset x 1" round corner

600F10 2-3/4" backset x 1-1/8" front

600F13 2-3/4" backset x 1-1/8" round corner

600F63 3-3/4" backset x 1-1/8" front $76.00

600F66 3-3/4" backset x 1-1/8" round corner $76.00

600F69 5" backset x 1-1/8" front $78.00

600F72 5" backset x 1-1/8" round corner $78.00

Deadlatches with release (CL3620 & 29)

599F93 2-3/8" backset x 1" front

$52.00

599F96 2-3/8" backset x 1" round corner

599F99 2-3/8" backset x 1-1/8" front

600F02 2-3/8" backset x 1-1/8" round corner

600F05 2-3/4" backset x 1" front

600F08 2-3/4" backset x 1" round corner

600F11 2-3/4" backset x 1-1/8" front

600F14 2-3/4" backset x 1-1/8" round corner

600F64 3 3/4" backset x 1 1/8" front $76.00

600F67 3-3/4" backset x 1-1/8" round corner $76.00

600F70 5" backset x 1 1/8" front $78.00

600F73 5" backset x 1-1/8" round corner $78.00

Spring Latches (CL3610)

599F91 2-3/8" backset x 1" front

$46.00

599F94 2-3/8" backset x 1" round corner

599F97 2-3/8" backset x 1-1/8" front

600F00 2-3/8" backset x 1-1/8" round corner

600F03 2-3/4" backset x 1" front

600F06 2-3/4" backset x 1" round corner

600F09 2-3/4" backset x 1-1/8" front

600F12 2-3/4" backset x 1-1/8" round corner

600F62 3-3/4" backset x 1-1/8" front $66.00

600F65 3-3/4" backset x 1-1/8" round corner $66.00

600F68 5" backset x 1-1/8" front $68.00

600F71 5" backset x 1-1/8" round corner $68.00

CL3800 PARTS

CL3800 Cylindrical Lock Series Grade 2

Key-In-Lever Lockset

January 1, 2014Parts Price List. 29

PART NO. DESCRIPTION LIST PRICE

LEVER INSERT ALL FINISH

598F809 Standard - 1-3/8" to 1-7/8" door $0.12

684F539 D214 - 2" to 2-1/4" door $34.00

MOUNTING SCREW PACK

796F118 Standard - 1-3/8" to 1-7/8" door $3.20

797F818 D214 - 2" to 2-1/4" door $13.00

797F828 Standard - CL3880, 81, 90, 91 $10.00

797F838 D214 - CL3880, 81, 90, 91 $13.00

684F448 CL3850 (ALL FINISH) $8.60

684F528 CL3870 $4.50

ROSES ALL FINISH

678F252 Standard $22.00

598F592 Blank - CL3880, 81 $24.00

ROSE LINER O/S NO FINISH

678F248 Standard - 1-3/8" to 1-7/8" door $4.30

678F498 D214 - 2" to 2-1/4" door $5.00

682F788 CL3880, 81 $20.00

SCREW PACK FOR LATCH & STRIKE ALL FINISH

604F228 For Latch & ANSI Strike $3.90

604F268 For Latch & 'T' or Full Lip Strike $3.80

STRIKES ALL FINISH

217L13 ANSI Curved Lip Strike $16.00

680L52 ANSI Curved Lip Blank Strike

586L19 T-Strike $17.00

680L50 Full Lip Strike

$11.00

680L51 Full Lip Strike 1/4" Radius

(Available Only 1-1/4" Lip)

STRIKE BOX NO FINISH

120F768 M17 - ANSI wrought $3.30

025F858 Curved lip (T strike) $2.40

THUMBTURNS ALL FINISH

586F512 Standard - CL3890, 91 $72.00

686F882 D214 - CL3890, 91 $72.00

LEVERS 2" to 2-1/4" Doors - D214 ALL FINISH

684F775 AZD x plain $83.00

684F785 AZD x cylinder or button $83.00

684F795 AZD x emergency hole $83.00

684F805 AZD x C6 IC 6-pin $85.00

684F815 AZD x C7 IC 7-pin $85.00

684F825 NZD x plain $83.00

684F835 NZD x cylinder or button $83.00

684F845 NZD x emergency hole $83.00

684F855 NZD x M09 Sargent®cylinder $85.00

684F865 NZD x C6 IC 6-pin $85.00

684F875 NZD x C7 IC 7-pin $85.00

690F985 NZD x M69 Schlage®IC $87.00

684F885 NZD x M08 small format IC $87.00

798F215 PZD x plain $83.00

798F225 PZD x cylinder or button $83.00

798F235 PZD x emergency hole $83.00

798F245 PZD x M09 Sargent®cylinder $85.00

798F255 PZD x C6 IC 6-pin $85.00

798F265 PZD x C7 IC 7-pin $85.00

798F275 PZD x M69 Schlage®IC $87.00

798F285 PZD x M08 small format IC $87.00

PART NO. DESCRIPTION LIST PRICE

LEVERS 1-3/8" to 1-7/8" Doors ALL FINISH

598F815 AZD x plain $69.00

598F825 AZD x cylinder or button $69.00

598F835 AZD x emergency hole $69.00

598F905 AZD x C6 IC 6-pin $71.00

599F275 AZD x C7 IC 7-pin $71.00

797F845 NZD x plain $69.00

797F855 NZD x cylinder or button $69.00

797F865 NZD x emergency hole $69.00

797F875 NZD x M09 Sargent® cylinder $71.00

797F915 NZD x C6 IC 6-pin $71.00

797F925 NZD x C7 IC 7-pin $71.00

797F935 NZD x M69 Schlage IC $73.00

797F945 NZD x M08 small format IC $73.00

798F115 PZD x plain $69.00

798F125 PZD x cylinder or button $69.00

798F135 PZD x emergency hole $69.00

798F145 PZD x M09 Sargent® cylinder $71.00

798F155 PZD x C6 IC 6-pin $71.00

798F165 PZD x C7 IC 7-pin $71.00

798F175 PZD x M69 Schlage® IC $73.00

798F185 PZD x M08 small format IC $73.00

CL3800 PARTS

CL3900 Cylindrical Lock Series Grade 2

Key-In-Lever Lockset

January 1, 2014Parts Price List. 30

LOCKSET PARTS

PART NO. DESCRIPTION LIST

PRICE

CHASSIS FOR 1-3/8" - 1-3/4" DOOR NO FINISH

678F818 CL3910 Passage $64.00

678F828 CL3920/CL3940 Privacy/Patio $70.00

678F848 CL3951 Entrance

$74.00

678F858 CL3955 Classroom

678F868 CL3957 Storeroom

691F248 CL3975 Dormitory

678F878 CL3962 Communicating $78.00

678F888 CL3980 Passage x Blank Plate $64.00

678F898 CL3981 Keyed x Blank Plate $74.00

CHASSIS FOR 2" - 2-1/4" DOOR NO FINISH

678F918 CL3910 Passage $68.00

678F928 CL3920/CL3940 Privacy/Patio $74.00

678F948 CL3951 Entrance

$78.00

678F958 CL3955 Classroom

678F968 CL3957 Storeroom

691F258 CL3975 Dormitory

678F978 CL3962 Communicating $82.00

678F988 CL3980 Passage x Blank Plate $68.00

678F998 CL3981 Keyed x Blank Plate $78.00

LEVER ALL FINISHES

677F515 NZD x Cylinder/Button

$59.00

698F995 NZD x Emergency Key Hole

699F005 NZD x Plain

677F635 NZD x Plain (Patio Function)

677F525 AZD x Cylinder/Button

699F075 AZD x Emergency Key Hole

699F085 AZD x Plain

677F645 AZD x Plain (Patio Function)

680F945 PZD x Cylinder/Button

699F025 PZD x Emergency Key Hole

699F035 PZD x Plain

680F935 PZD x Plain (Patio Function)

Corbin Russwin, Best®and Schlage®IC levers available

as a lever/rose ass'y only. Specify lever design, cyl option,

dr thick. and finish.

$102.00

PART NO. DESCRIPTION LIST

PRICE

SPRING LATCHES ALL FINISHES

679F05 Beveled, 1-1/8" Front, 2-3/4" Backset, 1" Dia. Sleeve

$32.00679F12 Flat, 1" Front, 2-3/8" Backset, 7/8" Dia. Sleeve

680F03 Flat, 1" Front, 2-3/4" Backset, 7/8" Dia. Sleeve

680F40 Flat, 1" Front, 3-3/4" Backset, 7/8" Dia. Sleeve $38.00

680F41 Beveled, 1-1/8" Front, 3-3/4" Backset, 1" Dia. Sleeve

DEADLOCKING LATCHES

679F06 Beveled, 1-1/8" Front, 2-3/4" Backset, 1" Dia. Sleeve

$36.00679F13 Flat, 1" Front, 2-3/8" Backset, 7/8" Dia. Sleeve

680F04 Flat, 1" Front, 2-3/4" Backset, 7/8" Dia. Sleeve

680F42 Flat, 1" Front, 3-3/4" Backset, 7/8" Dia. Sleeve

$42.00

680F43

Beveled, 1-1/8" Front, 3-3/4" Backset, 1" Dia. Sleeve

680F43 is only available in the following finishes:

626, 606, 612, 613, 722

BACKSET EXTENSION LINKS

680F488 5" Backset for 2-3/4" Backset, 1" Dia. Sleeve $23.00

680F498 5" Backset for 2-3/8" Backset, 7/8" Dia. Sleeve

ROSES AND PARTS

679F04 Blank Rose Assembly (Specify Finish) $28.50

679F148 Standoffs $2.30

680F858 Lever Catch R/C $2.00

680F868 Retaining Ring

679F07 Rose (Specify Finish) $14.50

679F158 Set Screw for Lever Handle $0.50

679F308 Spring, Lever Recore $3.30

679F165 Push Button Assembly $26.50

679F175 Turn Button Assembly $26.50

699F048 I/S Rose SA $24.50

695F518 I/S Rose Support, CL3962

695F528 O/S Rose Support $23.50

699F058 O/S Rose SA, CL3910

699F068 O/S Rose SA, CL3950 $21.50

CL3900/CL3700 Cylindrical Lock Series Grade 2

Key-In-Lever Locksets

January 1, 2014Parts Price List. 31

CL3900 SERIES

PART NO. DESCRIPTION LIST

PRICE

MOUNTING SCREW ALL FINISHES

695F688 Screw Pack for 1-3/8" - 1-3/4" Door $2.30

679F808 Screw Pack for 2" - 2-1/4" Door

680F568 Screw Pack for Dummy Trim $3.50

SCREW PACK FOR LATCH & STRIKE

604F228 Screw Pack for ASA Strike & Latch (All Finishes) $3.90

604F268 Screw Pack for T Strike & Latch

(606, 612, 613, 619, 626) $3.80

CYLINDER PARTS

680F579 Adaptor Sleeve $4.60

680F588 Schlage®Cylinder Adapter Kit for 1-3/4" Door $7.70

681F208 Schlage Cylinder Adapter Kit for 2-1/4" Door

681F562 Best®Cylinder Tailpiece 1-3/4" Door $15.50

681F572 Best Cylinder Tailpiece 2-1/4" Door

680F608 Tailpiece 1-3/4" Door $3.30

681F068 Tailpiece 2-1/4" Door

STRIKES* ALL FINISHES

217L13 ANSI Curved Lip Strike $16.00

680L52 ANSI Curved Lip Blank Strike

586L19 T-Strike $17.00

680L50 Full Lip Strike

$11.00

680L51 Full Lip Strike 1/4" Radius

(Available Only 1-1/4" Lip)

120F768 ANSI Wrought Box $3.30

PART NO. DESCRIPTION LIST

PRICE

UL LATCH ASSEMBLY 605, 612, 613, 626

2-3/4" BACKSET

687F63 2-1/4" x 1-1/8" square corner front $17.50

2-3/8" BACKSET

687F64 2-1/4" x 1" square corner front $17.50

687F65 2-1/4" x 1" x 1/4" rounded corner front

Note: All CL3700 latches are deadlocking

LATCH SLEEVE

687F71 1" Latch sleeve $0.62

STRIKES

687F60 Curved lip "T" $5.70

687F61 Full lip square corner $6.10

687F62 Full lip radius corner

687F94 Dust box for 687F60 strike $3.60

687F95 Dust box for 687F61, 687F62 strikes

217L13 ANSI curved lip $16.00

120F76-8 Dust box for 679L25 strike $3.20

MISCELLANEOUS

687F96 Screw pack $4.60

687F66 UL Fire cup $6.90

679F818 Emergency key $1.90

CL3700 SERIES

*Specify length and finish

CK4200 Series Heavy-Duty Cylindrical Locksets

January 1, 2014Parts Price List. 32

PART NO. DESCRIPTION LIST

PRICE

398F75-8 CK4210 $178.00

398F75-7 CK4210 non-ferrous $236.00

398F64-8 CK4220, CK4230, CK4275 $214.00

398F64-7 CK4220, CK4230, CK4275 non-ferrous $276.00

398F66-8 CK4229 $214.00

398F66-7 CK4229 non-ferrous $276.00

398F87-8 CK4251, CK4272 $214.00

398F87-7 CK4251 and CK4272 non-ferrous $276.00

398F88-8 CK4255 $210.00

398F88-7 CK4255 non-ferrous $276.00

398F65-8 CK4261 & discontinued 442 and 462 $214.00

398F65-7 CK4261 non-ferrous $276.00

401F00-8 CK4232 $214.00

401F00-7 CK4232 non-ferrous $276.00

400F17-8 CK4282 $214.00

400F17-7 CK4282 non-ferrous $276.00

399F61-8 CK4257 $214.00

399F61-7 CK4257 non-ferrous $276.00

KNOBS

605, 606, 612, 613, 619, 625, 626, 629, 630

DESIGN FUNCTION STANDARD

PART NO. LIST PRICE M26 OPTION NON-

FERROUS PART NO. LIST PRICE

Regular

Global Cylinder or Button 383F65

$82.00

383F68 $90.00

Global IC 6-Pin 482F75 n/a

Global Plain 383F66 383F69

$90.00Global Privacy Key Hole 383F67 383F70

Belmont Cylinder or Button 406F32 406F35

Belmont IC 6-Pin 438F79 n/a

Belmont Plain 406F33 406F36 $88.00

Belmont Privacy Key Hole 406F34 406F37

Best®IC Knob Knob assembly to accept Best type core

(S15950) 561F19-3 $90.00

Knob only (Best) 317F71-3 $84.00

Knurled

Global Cylinder or Button 575F57

$136.00

575F60 $144.00

Global IC 6-Pin 577F54 n/a

Global Plain 575F58 575F61

$144.00Global Privacy Key Hole 575F59 575F62

Belmont Cylinder or Button 575F63 575F66

Belmont IC 6-Pin 577F59 n/a

Belmont Plain 575F64 575F67 $144.00

Belmont Privacy Key Hole 575F65 575F68

PART NO. DESCRIPTION 606, 612,

626, 630

605, 611,

613, 625,

629

398F71 C Design (2-7/8" dia.) $20.00 $24.00

398F72 D Design (3-1/2" dia.)

406F22 E Design (3" sq.) $22.00 $26.00

LATCHES

PART NO. DESCRIPTION LIST

PRICE

(2-1/4" X 1-1/8" SQUARE CORNER FRONT)

605, 606, 611, 612, 613, 618, 619, 625, 626

- 2-3/4" Backset

486F83* Plain, beveled $48.00

486F84* Plain, flat front $44.00

486F89* Deadlocking, beveled $58.00

486F90* Deadlocking, flat front $54.00

- 3-3/4" Backset

469F27* Plain, beveled $62.00

469F28* Plain, flat front $58.00

469F29* Deadlocking, beveled $72.00

469F30* Deadlocking, flat front $70.00

- 5" Backset

469F31* Plain, beveled $71.00

469F32* Plain, flat front $69.00

469F33* Deadlocking, beveled $81.00

469F34* Deadlocking, flat front $79.00

- 7" Backset

469F35* Plain, beveled $77.00

469F36* Plain, flat front $73.00

469F37* Deadlocking, beveled $87.00

469F38* Deadlocking, flat front $83.00

LOCKSET PARTS CHASSIS ASS'Y. ROSES

*For M26 non-ferrous option, change "-8" to "-7". Contact factory for prices

CK4200 Series Heavy-Duty Cylindrical Locksets

January 1, 2014Parts Price List. 33

PART NO. DESCRIPTION LIST

PRICE

ADAPTER PLATE NO FINISH

400F07-8 Adapter Plate, CK4250 $15.50

BUTTON ASSEMBLY

606,612 605,611,613

619,626 618,625

022F80 Push for CK4220, 30, 61, 75 $15.00 $24.00

336F04 Push for CK4229 $27.00 $34.00

157F11 Turn for CK4251 $20.00 $30.00

CHASSIS CAP ASSEMBLY NO FINISH

019F32-8* Chassis Cap Assembly $17.00

024F93-8* Chassis Cap Assembly $23.00

CHASSIS CASE NO FINISH

398F57-8* Chassis case $23.00

398F58-8* Chassis case $21.00

398F59-8* Chassis case $23.00

COUPLING NO FINISH

019F14-8* Coupling $3.10

EMERGENCY KEY NO FINISH

398F43-8 Emergency Key †Order 50- $1.50

FRAME & RETRACTOR ASSEMBLY NO FINISH

142F92-8* Frame & Retractor Assembly $32.00

HUB NO FINISH

147F42-8* Hub $1.70

025F29-8* Hub $1.90

040F70-8* Hub $1.80

024F86-8* Hub $1.90

055F68-8* Hub $4.40

079F75-8* Hub $3.20

168F79-8* Hub & Coupling Assembly $5.30

405F09-8* Hub & Coupling Assembly $6.90

168F77-8 Hub & Coupling Assembly, CK4232 $6.90

INSTRUCTION LABEL NO FINISH

410F66-9 Instruction Label †Orders 50- $0.60

KNOB FILLER (M01 OPTION) NO FINISH

493F99-9 Knob Filler (black) †Order 50- $0.50

KNOB RELEASE TOOL NO FINISH

391F65-8 Knob Release Tool See page 5

KNOB SHANK NO FINISH

317F64-8* CK4220 outside $37.00

072F44-8* CK4229 inside $47.00

405F10-8* CK4229 outside $55.00

PART NO. DESCRIPTION LIST

PRICE

KNOB SHANK (Cont’d)

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

377F81-8* CK4230 outside assembly with button $45.00

No Finish

168F71-8* CK4232, 82 inside $20.00

024F92-8* CK4251 outside, CK4272 inside $21.00

019F31-8* CK4255, 61, 75 outside $21.00

270F24-8* CK4282 outside $22.00

019F30-8* Various $18.00

LEAD LINER (M28 OPTION) NO FINISH

431F25-5 C Rose 2-7/8" dia. $2.20

431F26-5 D Rose 3-1/2" dia. $3.50

431F27-5 E Rose 3" Square $3.50

431F29-5 Knob †Order 100- $0.40

431F28-5 Rose Liner $6.00

LOCKING BALL NO FINISH

227F85-8* Locking Ball, CK4282 †Order 100- $0.10

O-RING NO FINISH

216F38-9 O-Ring †Order 50- $0.30

PLUG DRIVER NO FINISH

144F29-8* Plug Driver, A $12.00

349F01-8* Plug Driver Assembly, CK4255 $17.00

312F34-8* Plug Driver Assembly, CK4261 $20.00

168F81-8* Plug Driver Assembly, CK4272 $22.00

168F92-8* Plug Driver Assembly, CK4282 $27.00

584F81* Plug Driver Assembly Follower, CK4251, 72 $2.00

PIN, SPINDLE NO FINISH

019F13-7 Pin, Spindle †Order 50- $1.00

REINFORCEMENT NO FINISH

413F60-8 for CK4250 E Rose ONLY $1.60

RETAINER NO FINISH

168F58-3 Retainer in Knob Shank †Order 100- $0.04

067F00-3 Retainer, Coupling †Order 100- $0.10

219F89-8* Retainer, Hub for CK4282 †Order 100- $0.16

018F91-8* Retainer, Knob $1.60

019F01-8* Retainer, Outside Knob

for CK4232, 82 †Order 50- $2.00

RETRACTOR INSERT NO FINISH

312F26-8* for CK4261 $3.00

312F25-8* for various functions $5.30

ROSE LINER NO FINISH

398F70-8 Rose Liner, inside $2.50

398F69-8* Rose Liner, outside $2.80

404F67-8 Rose Liner, outside (2-1/8" - 2-1/2" dia.) $30.00

†Sold only in multiples of the number indicated. Price is each.

*For M26 non-ferrous option, change "-8" to "-7". Contact factory for prices

CK4200 Series Heavy-Duty Cylindrical Locksets

January 1, 2014Parts Price List. 34

PART NO. DESCRIPTION LIST PRICE

SCREW PACKET

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

556F55-8 for CK4250 †Order 50- $1.10

604F26-8 for curved lip strike $3.80

604F29-8 for curved lip strike x hex head (M04) $6.20

604F27-8 for curved lip strike x spanner head (M02) $12.00

604F28-8 for curved lip strike x Torx®head (M04) $11.00

604F25-8 for hex head (M04) $3.50

604F23-8 for spanner head (M02) $11.00

480F68 for SR118 $3.90

596F63-8 for SR118 & hex head (M04) $5.60

596F61-8 for SR118 & spanner head (M02) $6.60

596F62-8 for SR118 & Torx head (M04)

604F22-8 standard $3.90

604F24-8 for Torx head (M04) $11.00

224F00-8* Screw, Sems Assembly

#8 -32 X 1-1/4" †Order 100- $0.28

SHANK RETAINER NO FINISH

219F80-8* Shank Retainer †Order 20- $1.30

SPINDLE NO FINISH

168F74-8* Spindle, CK4232 $13.00

168F75-8* Spindle, CK4251, 72 $6.00

387F93-8* Spindle & Hub Assembly $38.00

387F95-8* Spindle & Hub Assembly, CK4255 $34.00

335F97-8* Spindle & Roll Pin Assembly $12.50

197F87-8* Spindle Assembly, long solid for CK4282 $24.00

197F88-8* Spindle Assembly, short hollow for CK4282 $43.00

SPRING NO FINISH

418F08-8 Spring †Order 100- $0.44

018F92-3 Spring, Knob Retainer †Order 100- $0.50

022F72-3 Spring, Push Button †Order 100- $0.22

312F24-7 Spring, Retractor Insert †Order 100- $0.06

049F94-7 Spring, Spindle †Order 100- $0.20

019F10-3 Spring, Spindle †Order 100- $0.30

312F23-3 Spring, Spindle for

CK4230, 55, 61, 75 †Order 100- $1.00

SPRING SEAT NO FINISH

019F11-8* Spring Seat †Order 50- $0.80

055F67-8* Spring Seat, CK4282 †Order 50- $1.20

STRIKE

605, 606, 611, 612, 613, 619, 625, 626

ANSI Curved Lip Strike

217L13M016 1" Lip Length

$16.00

217L13M018 1-1/8" Lip Length

217L13M020 1-1/4" Lip Length

217L13M022 1-3/8" Lip Length

217L13M024 1-1/2" Lip Length

217L13M028 1-3/4" Lip Length

217L13M032 2" Lip Length

$17.00

217L13M036 2-1/4" Lip Length

217L13M040 2-1/2" Lip Length

217L13M044 2-3/4" Lip Length

217L13M048 3" Lip Length

PART NO. DESCRIPTION LIST

PRICE

STRIKE (Cont’d)

Curved Lip Box Strike

586L19M016 1" Lip Length

$17.00

586L19M018 1-1/8" Lip Length

586L19M020 1-1/4" Lip Length

586L19M022 1-3/8" Lip Length

586L19M024 1-1/2" Lip Length

586L19M028 1-3/4" Lip Length

586L19M032 2" Lip Length

$19.00

586L19M036 2-1/4" Lip Length

586L19M040 2-1/2" Lip Length

586L19M044 2-3/4" Lip Length

586L19M048 3" Lip Length

ANSI Wrought Strike Box No Finish

120F76-8 ANSI Wrought Strike Box (M17) $3.20

Rabbeted Strike

315F93

Front Plate for Rabbeted Strike

606, 612, 619, 626 $46.00

605, 611, 613, 625 $48.00

315F94

Rabbeted Strike

606, 612, 619, 626 $46.00

605,611,613,625 $48.00

601F28-3 Rabbeted Front & Strike Packet $77.00

THIMBLE 605, 606, 611, 612, 613,

619, 625, 626, 629, 630

406F88 Thimble, CK4250 $5.50

399F51 Thimble, inside $7.50

399F50 Thimble, outside

THROW MEMBER, IC NO FINISH

399F45-2 M26 option $8.00

342F03-2 standard $4.50

320F44-2 for Best - type core $5.10

WASHER NO FINISH

039F19-2 Washer, CK4232 †Order 100- $0.08

WRENCH, THIMBLE NO FINISH

300F68-8 Wrench, Thimble See page 5

YOKE NO FINISH

398F85-8* Yoke $2.90

LOCKSET PARTS

†Sold only in multiples of the number indicated. Price is each.

*For M26 non-ferrous option, change "-8" to "-7". Contact factory for prices

CK4400/CK4700 Series Standard

Cylindrical Locksets

January 1, 2014Parts Price List. 35

PART NO. DESCRIPTION LIST

PRICE

STRIKES AND WROUGHT BOX

ANSI TYPE 605, 606, 611, 612,

613, 619, 625, 626

240L53M016 1" Lip to Center

$16.00

240L53M018 1-1/8" Lip to Center

240L53M020 1-1/4" Lip to Center (standard)

240L53M022 1-3/8" Lip to Center

240L53M024 1-1/2" Lip to Center

240L53M028 1-3/4" Lip to Center

240L53M032 2" Lip to Center

$17.00

240L53M036 2-1/4" Lip to Center

240L53M040 2-1/2" Lip to center

240L53M044 2-3/4" Lip to Center

240L53M048 3" Lip to Center

ANSI WROUGHT STRIKE BOX NO FINISH

120F76-8 Box only $3.20

CURVED LIP BOX TYPE STRIKE 605, 606, 611,

612, 613, 619, 625, 626

586L19M016 1" Lip Length

$17.00

586L19M018 1-1/8" Lip Length

586L19M020 1-1/4" Lip Length

586L19M022 1-3/8" Lip Length

586L19M024 1-1/2" Lip Length

586L19M028 1-3/4" Lip Length

586L19M032 2" Lip Length

$19.00

586L19M036 2-1/4" Lip Length

586L19M040 2-1/2" Lip Length

586L19M044 2-3/4" Lip Length

586L19M048 3" Lip Length

ROSE NO FINISH

579F11 Screw Packet & Strike Box $4.30

580F38-7 Rose Sub Assembly, stainless I/S $12.50

580F38 Rose Sub Assembly I/S $11.00

LATCHES

574F29 2-3/8" deadlatch

$30.00

574F30 2-3/8" deadlatch with throw-off

574F55 2-3/4" deadlatch

574F56 2-3/4" deadlatch with throw-off

574F29 x574F25 3-3/4" deadlatch

$53.00

574F30 x574F25 3-3/4" deadlatch with throw-off

574F29 x574F26 5" deadlatch

574F30 x574F26 5" deadlatch with throw-off

BACKSET EXTENDER KIT

574F25-8 Extender ONLY (No Latch Unit) -

Must be added to 2-3/8" Latch Unit $23.00

574F26-8 Extender ONLY (No Latch Unit) -

Must be added to 2-3/8" Latch Unit

PART NO. DESCRIPTION LIST

PRICE

UL LATCH ASSEMBLY 605 ,612, 613, 626

2-3/4" Backset

687F63 2-1/4" x 1-1/8" square corner front $17.50

2-3/8" Backset

687F64 2-1/4" x 1" square corner front $17.50

687F65 2-1/4" x 1" x 1/4" rounded corner front

Note: All CK4700 latches are deadlocking

LATCH SLEEVE

687F71 1" Latch sleeve $0.62

STRIKES

687F60 Curved lip 'T' $5.70

687F61 Full lip square corner $6.10

687F62 Full lip radius corner

687F94 Dust box for 687F60 strike $3.60

687F95 Dust box for 687F61, 687F62 strikes

217L13 ANSI curved lip $16.00

120F76-8 Dust box for 679L25 strike $3.20

MISCELLANEOUS

687F96 Screw pack $4.60

687F66 UL Fire cup $6.90

CK4400 SERIES CK4700 SERIES

UT5200 Series Pre-Assembled Unit Locksets

January 1, 2014Parts Price List. 36

PART NO. DESCRIPTION LIST PRICE

BUSHING NO FINISH

194F22-8 Bushing $2.60

BUTTON ASSEMBLY 612,619,626 613,625

022F80 for UT5220 $21.00 $27.00

157F11 for UT5251 $25.00 $23.00

156F43 for UT5261 $43.00 $47.00

CHASSIS COVER NO FINISH

138F88-8 Chassis Cover $5.00

CHASSIS 612,619,626 613, 625

496F33 for UT5210 $222.00 $234.00

496F34 for UT5220 $230.00 $242.00

496F32 for UT5251, 55, 57, 72 $236.00 $248.00

198F71 for UT5261 $236.00 $248.00

381F30 for UT5282 $236.00 $248.00

CORE HOUSING NO FINISH

342F05-2 for 6-pin IC $10.00

442F95-2 for 7-pin IC

613F35-2 for 6/7 pin Best-type IC $7.70

COUPLING NO FINISH

131F27-8 Coupling $41.00

EMERGENCY KEY NO FINISH

398F43-8 for UT5220 $1.50

ESCUTCHEON 612,619,626 613, 625

415F15 for inside knob

$84.00 $90.00

144F33 for inside lever

415F16 for outside knob

144F34 for outside lever

605F91 for inside knob, lead lined $94.00 $102.00

605F90 for inside lever, lead lined

415F27-7 for outside knob, ext. lip 630 only $128.00

301F56-7 for outside lever, ext. lip 630 only

GRIP RETAINER NO FINISH

078F07-8 Grip Retainer †Order 50- $0.30

GRIP RETAINER RING NO FINISH

078F08-8 Grip Retainer Ring †Order 100- $0.16

HUB NO FINISH

060F42-8 for all but UT5255 $2.30

071F62-8 for UT5210 $3.60

081F77-8 for UT5220 $3.90

147F07-8 for UT5251, 55, 72 $2.00

140F97-8 for UT5251, 57, 72 $1.80

071F63-8 for UT5257 $1.90

208F80-8 for UT5261 $3.90

PART NO. DESCRIPTION LIST

PRICE

HUB SPACER NO FINISH

060F33-8 for UT5210, 61 †Order 50- $1.40

070F42-8 for UT5220 †Order 50- $1.40

070F43-8 for UT5220 †Order 50- $3.00

606F03-8 for UT5255 $0.80

067F42-8 for UT5257 $2.30

KNOB SEE PAGE 28

KNOB FILLER 612, 619, 626, 613, 625

378F84 for Best - type style IC $19.00

No Finish

493F99-9 for Corbin Russwin, Delrin †Order 50- $0.50

KNOB PLATE NO FINISH

317F68-8 for Best - type IC $4.00

LEVER 612, 619, 626 613, 625

582F12-2 cyl/button LH $142.00 $150.00

582F11-2 cyl/button RH

582F14-2 cyl/button LH tactile $150.00 $158.00

582F13-2 cyl/button RH tactile

489F89-2 IC 6-pin LH $148.00 $156.00

489F88-2 IC 6-pin RH

549F36-2 IC 6-pin LH tactile $154.00 $162.00

549F35-2 IC 6-pin RH tactile

613F23-2 IC 7-pin LH $148.00 $156.00

613F22-2 IC 7-pin RH

613F25-2 IC 7-pin LH tactile $156.00 $164.00

613F24-2 IC 7-pin RH tactile

613F11-2 plain LH $142.00 $150.00

613F10-2 plain RH

613F15-2 plain LH tactile $150.00 $158.00

613F14-2 plain RH tactile

613F13-2 priv. key hole LH $142.00 $150.00

613F12-2 priv. key hole RH

613F17-2 priv. key hole LH tactile $150.00 $158.00

613F16-2 priv. key hole RH tactile

613F43-2 Best - type core prep LH $168.00 $176.00

613F42-2 Best - type core prep RH

LEVER INSERT NO FINISH

613F02-9 Lever Insert †Order 50- $0.60

LEVER SPRING ANCHOR NO FINISH

171F79-8 Lever Spring Anchor $12.50

PIN NO FINISH

019F13-7 Pin, Spindle Drive †Order 50- $1.00

156F83-7 Pin, UT5261 shank †Order 50- $0.42

286F50-7 Pin, UT5282 spindle †Order 50- $0.60

LOCKSET PARTS

†Sold only in multiples of the number indicated. Price is each.

UT5200 Series Pre-Assembled Unit Locksets

January 1, 2014Parts Price List. 37

PART NO. DESCRIPTION LIST

PRICE

PLUG DRIVER NO FINISH

144F88-8 Plug Driver & Spindle Assembly UT5282 $30.00

168F81-8 Plug Driver Assembly $22.00

144F29-8 Plug Driver UT5251, 57, 72 $12.00

606F01-8 Plug Driver UT5255 $10.00

145F32-8 Plug Driver UT5282 $30.00

RETAINING RING NO FINISH

251F19-8 Retaining Ring for

UT5282 Spindle †Order 100- $0.12

SCREW 612, 619, 626, 613, 625

480F70 Screw Pkt. (strike mount’g) †Order 20- $1.60

No Finish

249F76-8 Screw, Fixed Escutcheon †Order 50- $0.32

092F78-9 Screw,

Strike Adjustment (nylon) †Order 50- $0.60

SHANK, KNOB NO FINISH

060F91-8 for UT5210, 57 outside $20.00

133F41-8 for UT5220 inside $20.00

202F33-8 for UT5220 outside $22.00

187F07-8 for UT5251, 57, 72 outside $20.00

147F08-8 for UT5251, 72 inside $22.00

605F81-8 for UT5255 inside $22.00

605F80-8 for UT5255 outside $24.00

144F89-8 for UT5282 inside $34.00

069F78-8 for UT5282 outside $22.00

SHANK, LEVER NO FINISH

102F19-8 for UT5210, 57 outside

$36.00

102F37-8 for UT5220 inside

114F67-8 for UT5220 outside

188F75-8 for UT5251, 57, 72 outside

188F73-8 for UT5251, 72 inside $42.00

605F76-8 for UT5255 inside $38.00

605F77-8 for UT5255 outside $38.00

156F65-8 for UT5261 inside $72.00

156F64-8 for UT5261 outside $46.00

102F27-8 for UT5282 inside $38.00

287F60-8 for UT5282 outside $60.00

SHANK RETAINER NO FINISH

219F80-8 for knob †Order 20- $1.00

242F50-8 for lever †Order 50- $0.60

PART NO. DESCRIPTION LIST

PRICE

SLEEVE, SHANK NO FINISH

019F15-2 Sleeve, Shank †Order 50- $0.60

SPINDLE NO FINISH

201F18-8 for UT5220 $6.00

144F30-8 for UT5251, 72 $5.50

606F02-8 for UT5255 $5.60

335F98-8 for UT5257 $9.00

156F36-8 for UT5261 $39.00

SPRING NO FINISH

107F93-8 Spring for UT5261 $7.10

022F72-3 Spring, Button UT5220, 61 †Order 50- $0.22

103F45-8 Spring, Lever Return LH $6.70

103F44-8 Spring, Lever Return RH $6.70

060F05-3 Spring, Shoe UT5220, 61 †Order 100- $0.26

071F67-3 Spring, Spindle for UT5220 †Order 100- $0.20

249F77-3 Spring, Spindle for UT5251,

55, 57,72 †Order 100- $0.20

218F08-8 Spring, Spindle for UT5261 †Order 100- $0.12

261F11-8 Spring, Spindle for UT5282 †Order 100-

SPRING SEAT NO FINISH

019F11-7 Spring Seat 1.60

SLEEVE, KNOB 612, 626 613, 625

401F08 Sleeve, Knob $8.00 $9.00

STRIKE 612, 626 613, 625

236L75M020 ANSI curved lip

$16.00 $18.00

610L44 ANSI straight lip

610L43 ANSI straight lip for ext. esc.

083L96M032 curved lip box, 2"

083L96M036 curved lip box, 2-1/4"

083L96M034 curved lip box, 2-1/8" (std)

083L96M040 curved lip box, 2-1/2"

083L96M048 curved lip box, 3"

293L14 curved lip box for ext. lip esc.

082L67 pairs of doors

THROUGHBOLT 12, 626 613, 625

222F85 Regular $4.00 $3.70

223F29 Spanner head $3.80 $3.20

THROW MEMBER NO FINISH

320F44-2 for Best®style core $5.10

342F03-2 for Corbin Russwin core $4.50

† Sold only in multiples of the number indicated. Price is each.

Padlocks and Deadlocks

January 1, 2014Parts Price List. 38

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

422L84-2144 Chain & clevis, 9" brass $16.50 1

422L84-8144 Chain & clevis, 9" steel $14.50 1

303F24-2 Pin chamber cap $0.40 100

242F48-2 Plug and shackle retainer screw $0.50 100

228F34-8 Plug retainer, oversize Spirol pin $0.30 100

244F64-7 Plug retainer, standard solid pin $1.18 20

405F77-2 Security disc $0.60 50

362F15-3 Throw member, IC models $6.50 10

PART NO. DESCRIPTION LIST

PRICE

SOLD IN

MULT. OF

261F29-8 Allen wrench 5/64" $2.10 10

467F36 Bolt front $12.50 1

467F34-5 Cylinder housing $41.00 1

467F33-8 Cylinder housing screw $1.00 20

480F70-8 Screw pack for ANSI strike $1.60 20

480F69 Screw pack for strikes 424F83 and

394F19 $2.50 20

283F81 Collar Base / Rose $37.00 1

424F83-8

Strike, 2-3/4" x 1-1/8

611, 613 $23.00 1

619, 625, 626 $12.00 1

605, 606, 612, 618 $16.00 1

394F19-8 Strike, 3-1/2" x 1-1/8" $15.50 1

423L71

Strike, ANSI

611,613 $22.50 1

All other finishes $15.50 1

416F38 Security collar $33.00 1

467F35-8 Bolt, less front -2-3/4" B.S. $34.00 1

693F20-8 Bolt, less front -2-3/8" B.S. $34.00 1

467F37-8 Strike box $4.50 1

496F71-8 Strike box $3.70 1

PADLOCKS DL3000 SERIES DEADLOCKS

Deadlocks and Push-Pull Latches

January 1, 2014Parts Price List. 39

PART NO. DESCRIPTION LIST

PRICE

MULT.

394F31 Armored front $17.00 1

413F31-2 Bolt $54.00 1

413F25-8 Bolt lever $9.50 1

413F20-8 Bolt spring $2.50 10

383F35-8 Lock mounting screw $1.20 20

221F51 Screw for armored front $1.20 50

480F70-8 Screw pack for ANSI strike $1.60 20

206F57-8 Screw for strike, comb. type $1.20 20

519F09 Thumbturn assembly for D138

$38.00 1519F10 Thumbturn assembly for D134

519F11 Thumbturn assembly for D214

519F12 Thumbturn assembly for D300 $50.00 1

581F96 Thumbturn assembly for D312

707F57 Ergonomic Thumbturn assy. for D138

$47.00 1707F58 Ergonomic Thumbturn assy. for D134

707F59 Ergonomic Thumbturn assy. for D214

707F60 Ergonomic Thumbturn assy. for D300 $46.00 1

706F70 Ergonomic Thumbturn assy. for D312

429F528 Lock Body

696F39 Blank Plate $50.00 1

429F18-8 Thumbturn disk for DL4013 $36.00 1

429F19-8 Thumbturn disk for DL4017

ANSI STRIKE

240L082014 7/8" Lip Length

$16.00 1

240L082018 1-1/8" Lip Length

240L082020 1-1/4" Lip Length

240L082022 1-3/8" Lip Length

240L082024 1-1/2" Lip Length

240L082028 1-3/4" Lip Length

240L082032 2" Lip Length

240L082036 2-1/4" Lip Length

240L082040 2-1/2" Lip Length

240L082044 2-3/4" Lip Length

240L082048 3" Lip Length

381F94 Standard Strike 3-1/2" x 1-1/8" $14.00 1

466F27-9 Wrought Box for 381F94 $1.40 10

PART NO. DESCRIPTION 612, 625,

626

176F85-3 Pull Escutcheon Sub Assembly for HL11 $380.00

176F86-3 Pull Escutcheon Only for HL11 $160.00

176F87-3 Lever Pull Only for HL11 $162.00

176F88-8 Spring $2.20

193F94-9 Insert $2.80

222F76-3 Screw OHM-PH 10-24 x 1-3/4" $4.80

228F38-8 Roll Pin $0.32

233F64-9 Escutcheon Pad $2.40

261F68-8 Finger $5.50

288F71-8 Hex Key $2.90

333F85-3 Pull Lever Only for HL12 $180.00

333F86-3 Pull Escutcheon Sub Assembly for HL12 $380.00

409F19-3 Push Lever Only for HL11 $130.00

409F33-1 Plunger $3.20

409F34-3 Push Lever Sub Assembly for HL11, HL12 $130.00

414F36-3 Push Escutcheon Only for HL11, HL12 $160.00

414F91-3 Push Escutcheon Sub Assembly for HL11 $380.00

430F79-8 Button Head Rivet $1.00

488F82 Latch Assembly (Beveled) $160.00

488F83 Latch Assembly (Flat) $160.00

582F05-8 Groove Pin $3.00

262F94-2 Regular Strike 612 $25.00

625, 626 $21.00

485F295 Lead Washer (M39) $60.00

DL4000 SERIES DEADLOCKS HL10 SERIES PUSH-PULL LATCHES

ED8000 Pushpad Exit Devices

January 1, 2014Parts Price List. 40

PART NO. DESCRIPTION LIST

PRICE

ALARM DELAY SWITCH

696F318 for M62 option $43.00

BAR 689, 690, 691

436F41-8 for ED8400, 30" door width, with dogging

$274.00436F42-8 for ED8400, 36" door width, with dogging

436F43-8 for ED8400, 42" door width, with dogging

436F44-8 for ED8400, 48" door width, with dogging $298.00

387F21-8 for ED8200, 30" door width, with dogging

$254.00387F24-8 for ED8200, 36" door width, with dogging

387F27-8 for ED8200, 42" door width, with dogging

387F30-8 for ED8200, 48" door width, with dogging $276.00

387F63-8 for ED8200, 30" door width, less dogging

$248.00387F66-8 for ED8200, 36" door width, less dogging

387F69-8 for ED8200, 42" door width, less dogging

387F72-8 for ED8200, 48" door width, less dogging $270.00

564F888 for ED8400, 30" door width, less dogging

$268.00564F898 for ED8400, 36" door width, less dogging

564F908 for ED8400, 42" door width, less dogging

564F918 for ED8400, 48" door width, less dogging $292.00

564F378 for ED8400A, 30" door width, less dogging

$268.00564F408 for ED8400A, 36" door width, less dogging

564F438 for ED8400A, 42" door width, less dogging

564F688 for ED8400A, 48" door width, less dogging $292.00

BOTTOM ROD

436L32-

8557

for ED8400, 40-5/16" Pushbar Height, for

Door 7’6" high $145.00

526L51-

8540 for ED8400A

BRACKET 605, 606, 611, 612,

613, 619, 622, 625, 626

321F23 LHR Bracket for P3 trim $99.00

321F24 RHR Bracket for P3 trim

FRAME PLATES

552F59-8 for ED8400 - RHR $130.00

552F60-8 for ED8400 - LHR

552F468 for ED8400A - RHR $188.00

552F478 for ED8400A - LHR

PART NO. DESCRIPTION LIST

PRICE

FRONT COVER

564F345 for ED8400 (A) (not handed) $37.00

385F54-5 for ED8200(B) (not handed) $45.00

564F115 for ED8200A (not handed) $57.00

KNOB 605, 606, 611, 612,

613, 619, 625, 626

695F22 for G10 Trim, plain $92.00

695F23 for G10 Trim, with cylinder hole $90.00

LATCH

436F25-8 for ED8400, Top No Finish $150.00

436F29-8 for ED8400, Bottom No Finish $80.00

552F36-8 for ED8200(B) 626 $96.00

552F41-6 for ED8200A $220.00

525F99-8 for ED8400A, top $160.00

526F16-8 for ED8400A, bottom $184.00

LATCH COVER 689, 690, 691

526F32-1 for ED8400A, Top or Bottom Latches $72.00

446F23-1 for ED8400, Top or Bottom Latches $60.00

MISCELLANEOUS

650F27-9 Dogging Hole Plug $0.70

697F98-8 Sex Nut Pack (M54) $14.00

436F858 Latch Assembly Screw $0.52

558F52-8 Mounting packet for F1 and P8 Trim

689, 690, 691 $18.00

482F79-8 ANSI fastening plate packet for G3 Trim

No Finish $7.40

123F53-8 Dogging Key, 3/16" hex No Finish $2.70

ED8000 Pushpad Exit Devices

January 1, 2014Parts Price List. 41

PART

NO. DESCRIPTION LIST

PRICE

MOUNTING PACKET 605, 606, 611, 612,

613, 619, 622, 625, 626

469F67 for F157, P157, P857 trim $21.00

469F68 for F150, P150, P850 trim (dummy) $12.00

496F68 for P257 trim $23.00

496F69 for P250 trim (dummy) $21.00

PLATES AND PULLS 689, 690, 691

436F82-8 for F1 Trim, plate - no cylinder hole $32.00

436F83-8 for F1 Trim, plate - with cylinder hole

436F80-1 for P8 Trim, pull - no cylinder hole $38.00

436F81-1 for P8 Trim, pull - with cylinder hole

602F15-1 Pull Grip (Black) for P2 622 Only $45.00

605, 606, 611, 612, 613, 619, 622, 625, 626

270F13 Escutcheon for P3 trim without cylinder hole $85.00

492F20 Offset Pull for P1 trim without cylinder hole $105.00

492F21 Offset Pull for P1 trim with cylinder hole $124.00

602F18-1 Pull Base for P2 trim plate without cylinder hole $165.00

602F17-1 Pull Base for P2 trim plate with cylinder hole $183.00

328F80 Pull Tube for P3 trim $83.00

REAR COVER 689, 690, 691

603F64 for ED8000 devices purchased AFTER

Nov. 1, 1993 $22.00

ROD GUIDE PACKET SCREW PACKET

446F20-8 Rod guide packet $28.50

523F03-8 for ED8200(B) and ED8400(A), Packet for

mounting bar & active case with SNB $28.50

484F20-8 for ED8400, Packet for mounting top latch $46.00

484F21-8 for ED8400, Packet for mounting bottom latch $19.00

261F30-8 for ED8200, Latch & Frame Plate Attachment

Screw †Order 20- $2.10

PART NO. DESCRIPTION LIST

PRICE

ROD GUIDE PACKET SCREW PACKET (Cont'd)

449F82-8 for ED8200(B) and ED8400 for bar & active case $19.00

492F59 Rear Side Screw Packet for P1 trim $4.10

564F128 for ED8200A, Packet for mtg. bar & active

case with SNB $34.00

534F008 for ED8400A, Packet for mtg. Top &

bottom latch $42.00

SHIM KITS

557F92-8 for ED8200 (B) $68.00

557F93-8 for ED8200A $68.00

557F94-8 for ED8400 $112.00

557F95-8 for ED8400A $112.00

STRIKE PACKET

391F57-5 for ED8200, Shim used with 1/2" Stop $23.50

446F21M for ED8400, Packet for Top Latch.Strike

605, 606, 611, 612, 613, 622, 625, 626 $39.50

446F22-8 for ED8400, Packet for Bottom Latch

(Surface Mounting) 625 only $29.50

463F92-8 for ED8400, Packet for Bottom Latch

(Flush Mounting) 625 only $25.50

386F45-3 for ED8200(B) Strike Packet

612, 613, 626 $35.50

468F30-5

Packet for Rim by Vertical Rod

605, 606, 612, 613, 622,

625, 626, 689, 690, 691

$29.50

518F06-7 for ED8200A $56.00

526F52-7 for ED8400A, Packet for Top Strike $40.50

526F53-3 for ED8400A, Packet for Bottom Strike $36.50

TOP ROD

487L048-

697

for ED8400, 40-5/16" Pushbar Height, for

Door 7’6" high $80.00

487M048-

589

for ED8400, 40-5/16" Pushbar Height, for

Door 7’6" high to 10' high $108.00

526L928759 for ED8400A $66.00

†Sold only in multiples of the number indicated. Price is each.

ED8000 Pushpad Exit Devices

January 1, 2014Parts Price List. 42

PART NO. DESCRIPTION LIST PRICE

CHASSIS, 1-3/4" TO 2-1/4" DOORS NO FINISH

690F44 Dummy (50) $76.00

698F43 Passage (10)

698F44 Classroom (55)

$84.00698F45 Nightlatch (57)

698F46 Storeroom (59)

698F51 Classroom - I/C

$90.00698F52 Nightlatch - I/C

698F53 Storeroom - I/C

MISCELLANEOUS 605, 606, 611, 612,

613,619, 625, 626

678F25 Rose for X6 trim $22.00

585F72 Lever Insert for X6 trim $1.10

682F91 Recore Driver Packet $4.70

696F05 Mounting Packet $3.10

PART NO. DESCRIPTION LIST PRICE

LEVERS ALL FINISHES

STANDARD 1-3/8" TO 2-1/4" DOORS

563F955 N6 design x cylinder or button

$83.00563F965 N6 design x emergency key hole

563F945 N6 design x plain

578F435 N6 x Sargent®cylinder cutout $85.00

563F895 A6 design x cylinder or button

$83.00

563F905 A6 design x emergency key hole

563F885 A6 design x plain

685F515 P6 design x cylinder or button

685F525 P6 design x emergency key hole

685F505 P6 design x plain

LEVERS ALL FINISHES

IC, 1-3/8" TO 2-1/4" DOORS

585F715 N6 x cylinder (IC core 6-pin) $85.00

600F415 N6 x cylinder (IC core 7-pin)

596F825 N6 x Best®cylinder cutout $87.00

585F705 A6 x cylinder (IC core 6-pin)

$85.00

600F425 A6 x cylinder (IC core 7-pin)

685F535 P6 x cylinder (IC core 6-pin)

685F545 P6 x cylinder (IC core 7-pin)

685F555 P6 x Best cylinder cutout $87.00

ACTIVE & INACTIVE CASES STRIKES FOR CROSSBAR EXIT DEVICES

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 43

PART NO. DESCRIPTION LIST

PRICE

502F46 ED6200 / ED6600 / ED6600A LHR

$468.00

558F86 ED6200 / ED6600 / ED6600A RHR

507F59 ED6800 LHR

507F60 ED6800 RHR

507F61 ED6800A LHR

507F62 ED6800A RHR

269F73 ED7000 LHR with dogging $684.00

269F74 ED7000 RHR with dogging

269F75 ED7000 LHR less dogging $638.00

269F76 ED7000 RHR less dogging

VERTICAL ROD STRIKES 605, 606, 612, 613,

622, 626, 629

392F24 Top $75.00

392F22 Top $58.00

392F28 Bottom flush $47.00

392F29 Bottom surface $39.00

176F65-3 Top bracket $39.00

304F33-7 Bottom 630 only $26.00

304F34-7 Bottom 630 only $39.00

352F04-2 Bottom $26.00

352F05 Top $47.00

361F91-3 Bottom flush

$47.00123F22 Bottom

183F85-7 Top 630 only

502F75 Bottom mortised $27.00

502F96 Surface $37.00

CONCEALED VERTICAL ROD STRIKES 605, 606, 612,

613, 622, 626

503F52 Bottom Strike $47.00

503F53-3 Fire Rated Bottom Strike $47.00

RIM EXIT DEVICE STRIKES 605, 606, 612,

613, 622, 626

142F43 Adj. Packet $111.00

467F73-3 Pack, rim vert. rod $69.00

300F71 Packet $92.00

499F59-8 Adj. $63.00

MORTISE STRIKES 605, 606, 612, 613,

619, 622, 625, 626

240L50 Stainless Mortise - LHR 629, 630 only $40.00

240L51 Stainless Mortise - RHR 629, 630 only

411L63 Open Back - RHR See page 10

411L62 Open Back - LHR See page 10

LOW PROFILE EXIT DEVICE STRIKES

416F35-5 Strike 622 689, 690, 691 $37.00

436F03-8 Strike, bottom $14.00

487M048-589 Top Rod (for 10’ Doors) $108.00

463F91-8 Flush Bottom Strike $17.00

PART NO. DESCRIPTION LIST

PRICE

ACTIVE CASE ASSEMBLIES, COMPLETE

502F77 ED6200 RHR with dogging $674.00

559F60 ED6200 LHR with dogging

502F80 ED6200 RHR less dogging $628.00

559F61 ED6200 LHR less dogging

499F49 ED6200A RHR

$984.00

499F50 ED6200A LHR

499F53 ED6257A RHR

499F54 ED6257A LHR

502F68 ED6400A RHR

$674.00

559F30 ED6400A LHR

502F88 ED6400 RHR

559F20 ED6400 LHR

502F89 ED6410 RHR

559F60 ED6410 LHR

502F70 ED6410A RHR

559F33 ED6410A LHR

502F39 ED6600 RHR

558F80 ED6600 LHR

502F40 ED6600A RHR

558F81 ED6600A LHR

507F67 ED6800A RHR with dogging

507F68 ED6800A LHR with dogging

507F55 ED6800A RHR less dogging

$638.00507F51 ED6800A RHR

507F52 ED6800A LHR

269F65 ED7200 x M66 RHR with dogging

$784.00

269F66 ED7200x M66 LHR with dogging

269F67 ED7200 x M66 RHR less dogging

269F68 ED7200 x M66 LHR less dogging

269F69 ED7200 RHR with dogging

269F70 ED7200 x LHR with dogging

269F71 ED7200 RHR less dogging

269F72 ED7200 LHR less dogging

403F15 ED7600 RHR with dogging $674.00

403F16 ED7600 LHR with dogging

403F17 ED7600 RHR less dogging $638.00

403F18 ED7600 LHR less dogging

414F81 ED7600A RHR

$674.00

414F82 ED7600A LHR

503F34 ED7800 RHR

503F35 ED7800 LHR

503F36 ED7800A LHR

503F37 ED7800A RHR

INACTIVE CASE ASSEMBLIES, COMPLETE

499F57 ED6200A LHR

$468.00

499F58 ED6200A RHR

502F47 ED6400A / ED6410A LHR

558F87 ED6400A / ED6410A RHR

LOCK BODY ASSEMBLY - CROSSBAR SPECIFY HAND

No Finish

424F42-8 MLE08 (ED 7600)

$469.00424F43-8 MLEO9 (ED7600A)

424F50-8 MLE03, MLE04 (ED6600)

424F51-8 MLE06, MLE07 (ED6600A) $479.00

424F52-8 MLE05 $469.00

DEVICE PARTS

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 44

PART NO. DESCRIPTION LIST

PRICE

095F35-1 Strap/Stabilizer for Mullion $24.00

120F55-8 Screw $2.20

122F18-8 Mounting Bracket $24.00

122F24-8 Washer †Order 100- $0.08

122F41-3 Lower Rod Guide $8.80

122F50-8 Lower Bolt Tube Sub Assembly $67.00

122F51-8 Bottom Guide Sub Assembly $63.00

122F56-8 Locking Lever $17.00

122F57-8 Locking Lever $13.00

122F59-3 Locking Lever Spring $20.00

122F60-8 Locking Hub $10.00

122F61-8 Locking Hub $5.00

122F63-9 Spacer Washer (Nylon) $1.50

122F64-3* Handle Lever $94.00

123F53-8 Dogging Key, 3/16" hex $2.70

129F49-9 Sound Deadener $6.30

129F84-8 Cylinder Nut $6.50

134F05 Cylinder Collar See page 4

140F52-8 Stud †Order 20- $0.80

141F41-8 Springwasher †Order 20-

141F84* Case housing, active & inactive $118.00

141F86* Case (Active - No Bot. Rod)

141F87* Active Case $99.00

141L54-8 Reinforcing Tube $114.00

141L59

Crossbar

605, 606, 611, 612, 613, 619, 622, 625, 626 $212.00

629, 630 $268.00

142F16* Case Sub Assembly $160.00

142F44* Adj. Strike $60.00

143F24-8 Spring †Order 50- $0.58

143F25 Rollback $12.00

143F26-5 Slide $42.00

143F42* Thumbpiece

$40.00143F43* Thumbpiece

143F52* Thumbpiece

143F83-3 Stud $5.40

145F54-3* Strike Plate $66.00

147F83-8 Lazy Cam $2.20

147F84-9 Washer (White Nylon) $2.60

147F87-8 Cam $2.90

147F88-8 Slide Spring †Order 50- $0.70

148F15-7 Release Pkg. 613, 630 $12.00

148F17

Cover Retaining Screw

606, 612, 613, 619, 622, 626 $5.20

611, 625, 629, 630 $9.30

148F22-8 Pin $2.20

148F36-7 Release Plunger Sub Assembly $18.00

148F44-8 Mounting Wrench $4.10

PART NO. DESCRIPTION LIST

PRICE

154F96-6 Clamp $18.00

158F52-8 Cylinder Retainer, MR $10.00

158F53-8 Cylinder Retainer, regular $4.10

158F54-8 Washer $2.10

158F55-8 Stud $5.80

164F32-9 Nylon Washer †Order 50- $0.30

166F34-7 Latch Pin $4.20

171F89-6 Top Plate Sub Assembly $63.00

171F90-9 Insert $16.00

173F44-6 Bottom Plate $28.00

173F45-6 Bottom Filler Plate $24.00

173F69-8 Stud $1.50

173F72-8 Nut $4.00

174F79-7 Top Plate & Stud Sub Assembly $165.00

174F80-7 Top Plate & Stud Sub Assembly

175F51-8 Rod Insert $16.00

183F74 Top Latch Sub Assembly

(with top rod doors 6’4" to 8’6") $300.00

183F75 Top Latch Sub Assembly

(with top rod door 8’6" to 10’8") $300.00

184F57 Thumbpiece $34.00

184F82-5 Shim $15.00

184F94-8 Jam Nut $5.20

184F97* Thumbpiece $37.00

185F55-8 Lifting Lever $12.00

186F23 Cyl. Collar $30.00

187F21-3

Latch

605, 606, 611, 613, 619, 622, 625, 626 $72.00

629, 630 $124.00

187F88-7 Latch Spring RH $1.40

187F89-7 Latch Spring LH

Ø 195F67 Cylinder Housing (for master ring)

605, 606, 611, 612, 613, 619, 622, 625, 626 $74.00

199F70 Case Housing, ED6600A active $66.00

207F55-8 Screw Packet $31.00

207F64* Screw Packet

207F68* Screw Packet $38.00

207F69* Screw Packet $48.00

376F37* Sex Nut (For 1-3/4 & 2" doors) $5.50

209F55* Screw Packet $42.00

213F10-7 Top Strike Ass’y (reveal 5-1/2" - 8")

629, 630 $61.00

*Specify Finish. Ø Subject to availability.

† Sold only in multiples of the number indicated. Price is each.

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 45

DEVICE PARTS (Cont'd)

PART NO. DESCRIPTION LIST

PRICE

213F11-7 Top Strike S/A (reveal less 5-1/2") $74.00

629, 630

200F16-8 Screw 12-24 x 1/2" FHMS $2.00

220F49-8 Screw 1/4-20 x 2" FHMS $1.70

220F72-2 Screw 12-24 x 1/2" FHMS-PH †Order 20- $1.60

220F75

Screw 1/4-20 x 5/8" FHMS-PH

606, 619, 622, 625, 626, 630 $1.60

605, 611, 512, 613, 629 $2.60

220F77-8 Screw 622, CDC, MTD, 613 $1.70

220F82-7 Screw 1/4-20 x 1" FHMS-PH $2.70

220F84-8 Screw 12-24 x 1-1/4" FHMS-PH $0.40

220F85* Screw 1/4-20 x 1-1/4" FHMS-PH x Anchor $2.50

221F94-8* Mounting Screw $2.60

222F71* Throughbolt

224F34-8 Screw 12 x 1" FHWS †Order 20- $0.62

224F39-2 Screw 14 x 1-1/4" FHWS †Order 20-

224F44-8 Screw 14 x 1-1/2" FHWS $2.50

224F50-8 Screw 14 x 2" FHWS †Order 20- $0.62

225F99-8 Screw 12 x 1-1/2" OHWS-PH $1.90

228F18-8 Roll Pin †Order 100- $0.10

228F49-7 Roll Pin (79-028-125-0343) $0.86

228F51-7 Roll Pin (79-028-125-0500 St’d) †Order 100- $0.16

228F52-8 Roll Pin †Order 100- $0.14

228F55-8 Roll Pin 1/8 x 3/4" †Order 100- $0.16

228F68-7 Roll Pin 156 x 9/16" †Order 50- $0.38

228F80-8 Roll Pin 187 x 3/4" †Order 100- $0.20

228F81-7 Roll Pin 187 x 1-15/16" †Order 20- $0.64

228F84-7 Roll Pin 187 x 1-3/8" †Order 20- $0.60

243F76-9 Stop Nut †Order 20- $0.70

243F79-8 Spring Lock Washer †Order 100- $0.14

243F80-8 1/4-20 x 5/8" FRMS-PH $2.50

243F85

Top Cover Sub Assembly

606, 612, 619, 626, 630 $88.00

605, 611, 613, 625, 629 $126.00

249F33* 1/4-20 NC-2A x 1-1/4" Lg. Phillips OHMS $3.00

253F11-8 Drive Screw †Order 100- $0.14

254F73 Screw 8-32 x 3/8" OHMS-PH

605, 606, 611, 612, 613, 619, 625, 626, 630 $1.80

255F41* Screw 12-24 x 2" FHMS-PH $3.90

261F28-8 Screw 8-32 x 3/8" HSS Cone-SOC $2.30

261F29-8 Hex Key 5/64" †Order 10- $2.10

261F31-8 Screw 5/16-24 x 1-1/2" FHMS-SOC

605, 611, 612, 613, 619, 625, 626, 630 $2.90

261F54 Cylinder Collar See page 4

261F65-8 Screw 1/4-20 x 1/2" PHMS $2.10

262F90-1 River 3/32" x 5/32" †Order 100- $0.14

PART NO. DESCRIPTION LIST

PRICE

264F95-8 Screw 12-24 x 7/8" RHMS-PH

$0.60(Metal Doors) †Order 20-

267F34-8* Mounting Screw †Order 20-

268F64-7 Washer †Order 50- $0.50

268F84-8 Screw 6-32 x 5/8" RHMS †Order 20- $0.60

268F87-8 Retainer Ring †Order 20-

269F04-8 Cotter Pin †Order 50- $0.50

269F05-8 Lockwasher †Order 100- $0.14

269F08 Screw 8-32 x 3/8" FHUMS-PH

605, 606, 611, 613, 619, 625, 626, 630 $0.60

269F09-8 Screw 1-32 x 1/4" OHMS-PH †Order 100- $0.26

Lever

269F31 605, 606, 611, 612, 619, 613, 619, 625, 626 $245.00

269F32 605, 606, 611, 612, 619, 613, 619, 625, 626

COVER

269F33 606, 612, 619, 626, 630 $232.00

605, 611, 613, 625, 629 $258.00

269F34 606, 612, 619, 626, 630 $232.00

605, 611, 613, 625, 629 $258.00

269F35 606, 612, 619, 626, 630 $232.00

605, 611, 613, 625, 629 $258.00

269F36

Active Case Less Cover, ED7200 RHR & LHR

606, 612, 619, 626, 630 $250.00

605, 611, 613, 625, 629 $282.00

269F37-8 Hub $34.00

269F39-3 Latch Retractor $30.00

269F40-3 Latch Retractor $34.00

269F41-3 Slide $42.00

269F42

Inactive Case S/A, all ED7000

606, 612, 619, 626, 630 $248.00

605, 611, 613, 625, 629 $280.00

269F46-8 Hold Back Sleeve $34.00

269F47-9 Nyliner $2.60

269F48-8 Lever Pivot $2.20

269F49-9 Bushing $3.40

269F52-8 Hub Shank $4.60

269F53-8 Latch Spring $2.60

269F54-9 Button $0.70

269F55-9 Washer †Order 50- $0.38

269F56-9 Washer †Order 50-

269F57-8 Spring Washer $5.50

269F58-7 Latch Pin $2.30

269F60-8 Inner Spring $5.50

269F91* Screw Packet $74.00

269F92* Screw Packet $51.00

270F01* Screw Packet $74.00

270F02* Screw Packet $53.00

270F11* Through Bolt $3.00

282F32-5 Caulking Anchor $3.70

282F35-7 Caulking Anchor $2.60

284F67* Lever RH $100.00

*Specify Finish. Ø Subject to availability.

† Sold only in multiples of the number indicated. Price is each.

DEVICE PARTS (Cont'd)

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 46

PART NO. DESCRIPTION LIST

PRICE

284F68* Lever LH

$100.00284F69* Lever RH

284F70* Lever LH

284F78 Lifting Finger RH $8.00

284F79 Lifting Finger LH

284F97-7 Roll Pin †Order 50- $0.38

286F91 Lever S/A LH (Inactive)

605, 606, 611, 612, 613, 619, 625, 626 $172.00

286F92 Lever S/A RH (Inactive)

605, 606, 611, 612, 613, 619, 625, 626 $172.00

287F96-8 1/4-20 x 13/16" FRMH-PH $3.30

291F49-8 Stop Plate $20.00

291F57-8 Screw 10-31 x 1" FHM-PH †Order 50- $0.50

292F41-3* Strike $96.00

293F18-3 Slide Assembly $88.00

304F65-7 Screw 12-24 x 7/8" OHU-MS-PH (1-3/4”, 2" Doors)

622, 629, 630 $1.40

304F66-7 Screw 12-24 x 1-1/8" OHU-MS-PH (2-1/4" Doors) $4.00

305F07 Screw 12-24 x 3/4" FRHMS-PH †Order 20- $0.70

305F72-8 Lower Bolt Sub Assembly - includes Bottom Rod $360.00

305F73-8 Guard Plate $26.00

306F06-8 Screw 10-24 x 5/16" RHMS-PH †Order 20- $0.80

306F07-8 Spring Lockwasher †Order 100- $0.10

306F15-8 Plate $1.70

306F20-8 Backplate Sub Assembly $135.00

306F22-8 Center Rod $6.80

314F52-8 Screw HS-O-SK 3/8" - 16 x 1/2" †Order 50- $0.80

314F71-8 Screw 1/4-20 x 2-3/8" FHMS $2.00

321F90-7 Dogging Device Sub Assembly $36.00

Ø 326F73-7 Set Screw $4.20

329F75 Screw Packet $74.00

329F76 Screw Packet $57.00

333F51-9 Screw $1.80

341F31-8 Shim $16.50

349F06-8 Lifting Finger (Inactive Case) $22.50

351F50*

Active Case - less cover, ED7400 standard

606, 612, 619, 622, 626 $138.00

605, 611, 613, 625, 629, 630 $176.00

351F51*

Active Case - less cover, ED74000, ED7401, no bottom rod

606, 612, 619, 622, 626 $138.00

605, 611, 613, 625, 629, 630 $176.00

351F52-8 10-32 x 7/16" FHUMS-PH Screw †Order 100- $0.40

351F55-3 Slide Sub Assembly $124.00

351F56* Active Case Sub Ass'y, ED7400 with dogging -RHR $700.00

351F57* Active Case Sub Ass'y, ED7400 with dogging -LHR

PART NO. DESCRIPTION LIST

PRICE

351F72

Bottom Latch Cover

606, 612, 619, 626, 630 $140.00

605, 611, 613, 625, 629 $192.00

351F73

Top Latch Cover

606, 612, 619, 626, 630 $152.00

605, 611, 613, 625, 629 $204.00

351F79-7 Top Latch Sub Assembly $44.00

351F80-7 Roll Pin †Order 50- $0.50

351F82-3 Top Latch Backplate $80.00

351F83-3 Top Latch Slide

351F84-9 Spacer $8.00

351F85* Top Latch Sub Assembly No Cover $309.00

351F86-7 Bottom Latch $80.00

351F87-3 Latch Link $78.00

351F88-3 Bottom Latch Backplate $80.00

351F89-7 Spring †Order 20- $0.60

351F90-7* Bottom Latch Sub Assembly $278.00

351F98-8 Rod Connector Sub Assembly $4.00

352F02-1 Drive Rivet †Order 20- $0.70

352F03-8 Pin $3.70

352F06-8 1/4-20 x 3/4" BHUMS-PH Screw †Order 20- $0.60

352F07* 2-1/2" x 14 OHWS-PH Screw $0.84

361F30-8 Anchor $4.70

362F49-8 Nut $18.00

362F91-8 Plate $6.00

364F22-8 Washer $5.00

364F27-2 Locking Slide $22.00

364F28-8 Locking Lever Sub Assembly $30.00

364F30-8 Lifting Lever $24.00

364F36* Escutcheon Assembly RHR, C4, D4, E4 - std. $235.00

364F37* Escutcheon Assembly LHR, C4, D4, E4 - std.

364F38* Escutcheon Assembly RHR, C4, D4, E4 - MR $247.00

364F39* Escutcheon Assembly LHR, C4, D4, E4 - MR

365F00-3 Slide Extension S/A Door 1-3/4"

$39.00365F01-3 Slide Extension S/A Door 2-1/4"

365F03-3 Slide Extension S/A Door 1-3/4" or Lever Trim

365F98* 1/4-20 x 2" OHTS-F-PH Metal Door $4.80

370F55-8 Spindle 1-3/4" door

370F56-8 Spindle 2" door $17.00

370F63-8 Spindle Sub Assembly $6.00

376F42

Latch Sub Assembly

611, 612, 613, 619, 625, 626 $42.00

605, 606, 629, 630 $52.00

378F74-5 Tenon Sub Assembly $33.00

379F25

Lever Sub Assembly RH

605, 606, 619, 625, 626 $120.00

611, 612, 613 $210.00

379F26

Lever Sub Assembly LH

605, 606, 619, 625, 626 $120.00

611, 612, 613 $210.00

382F63-6 Backplate Sub Assembly Active $116.00

382F68-6 Slide $39.00

*Specify Finish. Ø Subject to availability.

† Sold only in multiples of the number indicated. Price is each.

DEVICE PARTS (Cont'd)

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 47

PART NO. DESCRIPTION LIST

PRICE

382F69-8 Compensator $16.00

382F72-9 Flanged Nyliner $4.10

382F78/8 Cam $20.00

382F79-8 Clip †Order 50- $0.40

382F80-8 Bushing $2.70

382F81-8 Cam Driver $5.00

382F82-8 Cam Driver $5.00

382F85-8 Pivot $2.40

382F86-5 Half Case $16.00

382F87-8 Lever Assembly $20.00

382F88-8 Lever Assembly $22.00

382F95-6 Backplate Assembly $282.00

382F98-6 Backplate Assembly (Active) $235.00

386F15-8 Cover Screw 8-31 x 1/2" FHMS-PH $0.40

389F54* Grip $98.00

389F62 Grip $94.00

391F88-2* Top Latch Assembly $80.00

Ø 391F90-9 Pad †Order 20- $1.84

391F91* Latch Cover Assembly, ED6400 $70.00

391F94-8 Frame $24.00

391F96-8* Frame & Yoke Assembly $78.00

391F99* Bushing Retainer Assembly $16.00

392F02 Top Latch S/A

605, 606, 611, 612, 613, 619,625, 626, 629, 630 $237.00

392F05* Latchbolt Assembly $80.00

392F08-8 Bottom Slide Assembly $22.00

392F10 Bottom Latch Assembly $190.00

392F11 Bottom Latch S/A

605, 606, 611, 612, 613, 619, 625, 626, 629, 630 $300.00

392F14-8 Adjusting Bolt $20.00

392F23* Adjusting Top Strike $76.00

392F23-7* Adjusting Top Strike, stainless $110.00

392F27-9 Rod Guide Sub Assembly $5.00

392L19* Adj. Bottom Rod Assembly $190.00

392L20 x 547

Adjusting Bottom Rod S/A Flush Strike

605, 606, 619, 626 $176.00

611, 612, 613, 625, 630 $214.00

392L20 x 568

Adjusting Bottom Rod S/A

Regular Strikes 605, 606, 619, 626 $176.00

611, 612, 613, 625, 630 $214.00

393L13-M672* Top Rod $140.00

393L14 x 672

Top Rod S/A (Standard)

605, 606, 611, 612, 619, 625, 626 $176.00

613, 629, 630 $214.00

397F91-8 Backplate Sub Assembly $94.00

397F99

Active Case S/A, ED6200 RHR, LHR

606, 612, 619, 622, 625, 626, 630 $238.00

605, 611, 613, 629 $270.00

PART NO. DESCRIPTION LIST

PRICE

398F69-8 Rose Liner $3.00

398F89

Case Cover

606, 612, 619, 626, 630 $50.00

605, 611, 613, 625, 629 $75.00

398F91-9 Bumper $4.60

398F94-8 Connecting Pin $3.40

398F95-7 Trip $4.60

398F99-7 Top Pusher Assembly $87.00

399F00* Case Cover $61.00

399F01

Top Pusher Cover Assembly, ED6400

606, 612, 619, 626, 630 $46.00

605, 611, 613, 625, 629 $56.00

399F02-7 Bridge $36.00

399F05-7 Case $60.00

399F06-7 Top Latch Sub Assembly $177.00

399F07-7 Bottom Bolt $75.00

399F10-8 Frame and Bridge Assembly $89.00

399F12* Top Pusher Assembly $332.00

399F13* Bottom Bolt Assembly $302.00

399F18-8 Lower Bolt Assembly $270.00

399F21* Grip $87.00

399F22* Grip

399F23* Escutcheon $176.00

399F25* Escutcheon $97.00

Ø 399F58-8 Washer $4.00

399L11 x 563

Bottom Rod

606, 612, 619, 626 $128.00

605, 611, 613, 625, 629, 630 $186.00

402F99* Thumbpiece $37.00

403F03-5 Slide x4M Trim $74.00

403F30* Washer $2.80

405F42-8 Anchor $5.60

405F45-8 Mullion (507) 7’2" door $190.00

Ø 405F46-6 Bottom Plate $86.00

405F47-6 Top Plate

$74.00

405F49-6 Bottom Plate Assembly

Ø 409F83-6 Top Plate Assembly

410F13* Escutcheon

410F14* Escutcheon x cyl.

410F20* Escutcheon

411F96-4 Spring $9.40

411F98-7 Plunger Spring †Order 100- $2.70

412F03-7 Retractor Spring †Order 20- $1.60

412F06-7 Latch Bushing $6.30

412F07-8 Latch Pivot Screw $2.90

412F08-7 Latch Spring $2.70

412F09-1 Spacer $3.30

412F11-7 Spring $2.70

412F13-3* Screw, 8-32 x 5/16"

*Specify Finish. Ø Subject to availability.

† Sold only in multiples of the number indicated. Price is each.

DEVICE PARTS (Cont'd)

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 48

PART NO. DESCRIPTION LIST

PRICE

464F02-8 Mullion (508) 8' door $186.00

464F91-5 Active Case Casting only $37.00

467F94-2 Thumbpiece Lever RH $66.00

467F95-2* Thumbpiece Lever LH

468F02-2* Lever, inactive RH $106.00

468F03-2* Lever, inactive LH

468F12-2 Thumbpiece Lever Assembly RH $170.00

468F13-2 Thumbpiece Lever Assembly LH

468F14-7 Latch Pin Assembly RH $66.00

468F15-7 Latch Pin Assembly LH

468F16-2 Lever Assembly RH $62.00

468F17-2 Lever Assembly LH

468F20-2* Lever Assembly RH $156.00

468F21-2* Lever Assembly LH

468F24-6 Active Backplate Assembly, RH

$646.00

468F25-6 Active Backplate Assembly, LH

468F26-6 Active Backplate Assembly, RH

468F27-6 Active Backplate Assembly, LH

468F35-5 Cylinder housing $8.30

480F12-8 Inactive Backplate Assembly $86.00

480F13* Lever $218.00

480F18-8 Spindle $35.00

480F19-8 Nut $8.30

480F20-8 Rollback $8.80

480F28* Lever & Spindle Assembly $202.00

480F30* Lever & Spindle Assembly $202.00

480F33* Lever & Spindle Assembly $206.00

480F37-5 Slide $41.00

482F44-2 *Bushing $45.00

482F49* Escutcheon $200.00

482F73* Escutcheon & Bushing $206.00

484F41-8 Rollback $14.00

484F89-8 Knob Shank Sub Assembly $25.00

492F19-5 Slide $72.00

499F60-8* Tenon Packet $46.00

622F68 Screw Pack for 2"-2-1/4" door 613, 626 $42.00

CASSETTES FOR VERTICAL ROD EXIT DEVICES

382F91-5 for ED6410, ED6410A $48.00

382F92-5 for ED6457, ED6457A $56.00

382F93-5 for ED6458 $48.00

BLANK PLATE FOR STOCK HOLLOW METAL DOORS

561F29

Bank Plate 14" x 3-1/2" Used on the outside of stock

cut-out hollow metal doors where no trim is desired

605, 606, 612, 619, 625, 626, 630 $102.00

613 $108.00

PART NO. DESCRIPTION LIST

PRICE

412F15-7 Lever Pivot $8.50

412F16-7 Deadlocking Plunger $16.00

412F30

Active Cover, ED6200A - RHR

606, 612, 619, 626, 630 $152.00

605, 611, 613, 625, 629 $177.00

412F31

Active Cover, ED6200A - LHR

606, 612, 619, 626, 630 $152.00

605, 611, 613, 625, 629 $177.00

412F32

Inactive Cover, ED6200A

606, 612, 619, 626, 630 $136.00

605, 611, 613, 625, 629 $156.00

412F45-1 Inactive Backplate Assembly $84.00

416F81-8 Stud $6.70

418F28-8 Dogging Screw $5.50

418F30-8 Rivet $3.00

418F35-2 Hub $40.00

418F36-8 Lever, RH $4.10

418F37-8 Lever, LH

420F04-8 Screw Packet (regular) for ED6200A $25.00

420F05

Screw Packet (w/SNB) for ED6200A

606, 612, 619, 625, 626, 630 $76.00

605, 611, 613, 629 $114.00

420F08-8 Screw Pkt (reg.) for ED6200A $17.00

420F09-8

Screw Pkt (s/SNB) for ED6200A

606, 611, 612, 619, 630 $25.00

605, 613, 625, 629 $50.00

420F12-8* Screw Packet $36.00

433F97-8 Lever Pivot $34.00

433F98-8 Lever Pivot

434F00-8 Lever Pivot $20.00

434F02-8 Screw 1/4-20 x 3/4" BUHC-SK $0.50

434F04-2

Top Casting Assembly, ED6200 w/dogging - RH

606, 612, 619, 626 $190.00

605, 611, 618, 625 $214.00

434F05-2

Top Casting Assembly, ED6200 w/dogging - LH

606, 612, 619, 626 $190.00

605, 611, 618, 625 $214.00

INSIDE CASTING

434F20-2* ED6600 inactive

$208.00

434F21-2* ED6600 inactive

434F22-2* ED6600 inactive

434F23-2* ED6600 inactive

434F24-2* ED6600 active

434F25-2* ED6600 active

434F26-2* ED6600A active

434F27-2* ED6600A active

*Specify Finish. Ø Subject to availability.

DEVICE PARTS (Cont'd)

ED7000/ED6000 Series Crossbar Exit Devices

January 1, 2014Parts Price List. 49

PART NO. DESCRIPTION LIST

PRICE

BLANK FRONTS AND STRIKES FOR STOCK HOLLOW

METAL DOORS AND FRAMES Steel, USP

077F19-8 Front, 2-1/4" x 1-1/8" $7.20

334F99 Front, 8" x 1-1/4" $16.00

Ø 236L718018 Strike, 4-7/8" x 1-1/4" $7.20

ED68000 SERIES CONCEALED VERTICAL ROD PARTS

221F08-3 Screw $3.20

PART NO. DESCRIPTION LIST

PRICE

321F24* RHR Bracket for P3 trim $86.00

393L13-M672* Top Rod $140.00

Ø 399F16-8 Spindle Adapter $41.00

399F17-8 Lower Rod Assembly $140.00

402F98-3 Extension Slide $27.00

402F99* Thumbpiece $37.00

408F25-8 Guide Spring $0.56

503F53-3 Bottom Strike $47.00

503F55-7 Top Strike $43.00

503F56-7 Top Strike - Fire Rated

*Specify Finish. Ø Subject to availability.

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 50

PART NO. DESCRIPTION LIST PRICE

ACTIVE HEAD (FIELD REVERSIBLE, WHERE HANDED) NO FINISH

650F37-8 ED4200 $192.00

681F61-8 ED4200S $208.00

650F41-8 ED4400 LHR $204.00

650F40-8 ED4400 RHR

650F46-8 ED4800 LHR $214.00

650F45-8 ED4800 RHR

650F35-8 ED5200 $192.00

650F36-8 ED5200A $204.00

706F03-8 ED5202 RHR $232.00

706F04-8 ED5202 LHR

706F05-8 ED5202A RHR $244.00

706F06-8 ED5202A LHR

681F60-8 ED5200S(A) $208.00

706F07-8 ED5202S(A) RHR $248.00

706F08-8 ED5202S(A) LHR

650F39-8 ED5400(A) LHR $204.00

650F38-8 ED5400(A) RHR

650F42-8 ED5600(A) $192.00

706F09-8 ED5602(A) RHR $232.00

706F10-8 ED5602(A) LHR

650F44-8 ED5800(A) LHR $214.00

650F43-8 ED5800(A) RHR

ARMORED FRONT 605, 606, 611, 612, 613, 619, 625, 626, 629, 630

650F06 ED5600 $14.00

BAR & CARRIER ASSEMBLY NO FINISH

650F24-8 All 48" $224.00

650F23-8 ED4000 36" $210.00

650F22-8 ED5000 36"

BAR CAP NO FINISH

650F18-9 Black nylon †Order 10- $3.60

BOTTOM BOLT CASE NO FINISH

650F58-8 ED4400, ED5400 $34.00

650F59-8 ED5400A $38.00

BOTTOM BOLT PACKET NO FINISH

650F77-8 ED4800 $104.00

698F03-8 ED5800(A) $90.00

BOTTOM RAIL

650F21

48"

606, 612, 630 $110.00

605, 613 $138.00

611, 625, 626, 629 $148.00

BOTTOM ROD & COUPLER ASSEMBLY NO FINISH

650F79-8 ED4800, ED5800(A) $76.00

BOTTOM ROD & END PIN ASSEMBLY 605, 606, 611, 612 613, 618, 619,

625, 626, 629, 630, 722

649F99 fin Surface devices $124.00

CARRIER BAR NO FINISH

650F99-8 Internal $12.00

COVER, ACTIVE HEAD 605, 606, 611, 612, 613, 619, 625, 626, 629, 630

650F03 ED4200

$164.00

681F63 ED4200S

650F04 ED4400

650F05 ED4800

650F00 ED5200(A)

681F62 ED5200S(A)

706F11 ED5202(A) RHR

$174.00

706F12 ED5202(A) LHR

706F13 ED5202S(A) RHR

706F14 ED5202S(A) LHR

650F01 ED5400(A) $164.00

650F02 ED5600(A), ED5800(A)

706F15 ED5602 RHR $174.00

706F16 ED5602 LHR

PART NO. DESCRIPTION LIST PRICE

DELAYED EGRESS PC BOARDS

704F269 DEED PC BD SA 36"NFPA-15

$1,082.00

704F279 DEED PC BD SA 36"NFPA-30

704F479 DEED PC BD SA 36"BOCA-15

704F489 DEED PC BD SA 36"BOCA-30

704F569 DEED PC BD SA 48"NFPA-15

704F579 DEED PC BD SA 48"NFPA-30

704F589 DEED PC BD SA 48"BOCA-15

704F599 DEED PC BD SA 48"BOCA-30

COVER, BAR 605, 606, 611, 612, 613, 619, 625, 626, 629, 630

650F07 36" $39.00

650F08 48" $43.00

COVER, END

650F93

ED5000DB

606, 612, 630 $237.00

605, 613 $257.00

611, 619, 625, 626, 629 $287.00

650F14

ED4000 36" cyl. dogging

606, 612, 630 $90.00

605, 613 $110.00

611, 619, 625, 626, 629 $124.00

650F13

ED4000 36" standard

606, 612, 630 $88.00

605, 613 $108.00

611, 619, 625, 626, 629 $122.00

650F12

ED5000 36" cyl. dogging

606, 612, 630 $90.00

605, 613 $110.00

611, 619, 625, 626, 629 $124.00

650F11

ED5000(A) 36" standard

606, 612, 630 $88.00

605, 613 $108.00

611, 619, 625, 626, 629 $122.00

650F15

All 48" standard

606, 612, 630 $100.00

605, 613 $120.00

611, 619, 625, 626, 629 $134.00

650F16

All 48" cyl. dogging

606, 612, 630 $102.00

605, 613 $122.00

611, 619, 625, 626, 629 $136.00

COVER, TOP & BOTTOM LATCH

650F64

ED4400, ED5400(A)

606, 612, 630 $57.00

605, 613 $65.00

611, 619, 625, 626, 629

CYLINDER DOGGING KIT

653F13

ED4000 36" bar

606, 612, 630 $84.00

605, 613 $110.00

611, 619, 625, 626, 629 $122.00

653F12

ED5000 36" bar

606, 612, 630 $84.00

605, 613 $110.00

611, 619, 625, 626, 629 $122.00

653F14

All 48" bar

606, 612, 630 $92.00

605, 613 $118.00

611, 619, 625, 626, 629 $130.00

DOGGING ASSEMBLY NO FINISH

650F96-8 Cylinder type $34.00

650F52-8 Hex Key type $30.00

DOGGING CYLINDER NUT NO FINISH

697F862 Dogging Cylinder Nut $11.50

†Sold only in multiples of the number indicated. Price is each.

DEVICE PARTS

DEVICE PARTS (Cont'd)

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 51

PART NO. DESCRIPTION LIST PRICE

DOGGING CYLINDER SLEEVE

650F959 Dogging Cylinder Sleeve $6.80

DOGGING HOLE PLUG

650F27-9 Dogging Hole Plug †Order 50- $0.70

DOGGING KEY, HEX

656F40-8 5/32" $2.60

END CAP RETROFIT KIT

704F66 End Cap Retrofit Kit $64.00

END CAP

704F62 End Cap $48.00

710F00M Flush End Cap Retrofit Kit (M110)

END CLAMP PACKET

704F658 ED4200(S), ED5200S(A) $9.50

704F64-8 ED4000, ED5000(A)

FLUSH STRIKE TRANSOM BRACKET

650F87-8 Flush strike transom brkt., ED5400(A) $42.00

LATCH PACKET

654F21-8 Latch pkt, ED4400, ED5400 †Order 10- $3.00

MORTISE LOCK BODY

655F48-8RR ED5610 knob - RHR $255.00

655F48-8LR ED5610 knob - LHR

650F69-8RR ED5602, ED5610, ED5655 lever - RHR $261.00

650F69-8LR ED5602, ED5610, ED5655 lever - LHR

678F00-8RR ED5610, ED5655 thumbpiece - RHR $265.00

678F00-8LR ED5610, ED5655 thumbpiece - LHR

650F67-8RR ED5650,57 knob, lever/thumbpiece - RHR

$261.00

650F67-8LR ED5650,57 knob, lever/thumbpiece - LHR

710F31-8LR ED5634L - LHR

710F31-8RR ED5634L - RHR

710F32-8LR ED5634L - LHR - M91 $472.00

710F32-8RR ED5634L - RHR - M91

710F33-8LR ED5634L - LHR - M93 $459.00

710F33-8RR ED5634L - RHR - M93

ADAPTER ASSEMBLY, MORTISE

706F46-2 ED5602(A) $30.00

MOUNTING PACKET

650F57-8 ED4400, ED5400(A) $70.00

654F20-8 Non-rated, wood door †Order 20- $2.30

900, WS700 & FE700 SERIES MULLION PACKETS

TOP RETAINER AND SCREW PACKET

713F518 907, 908, 910, 907A, 908A $164.00

713F938 FE707A , FE708A $170.00

713F948 907BKM, 908BKM, 910KM $164.00

713F958 WS707AKM, WS708AKM $170.00

BOTTOM RETAINER AND SCREW PACKET

713F528 907, 908, 910, 907A, 908A $107.00

713F998 FE707A,FE708A $170.00

713F988 907BKM, 908BKM, 910KM $107.00

713F908 WS707AKM, WS708AKM $170.00

LOCKING MECHANISM PACKET

744F258 907BKM, 908BKM, 910KM $351.00

744F208 WS707AKM, WS708AKM $367.00

1-1/4" CYLINDER COLLAR PACKET1

447F43 907BKM2, 908BKM2, 910KM2See page 4

610F01 WS707AKM2, WS708AKM2See page 4

1-1/2" IC CYLINDER COLLAR PACKET1

609F37 907BKM2, 908BKM2, 910KM2See page 4

609F36 WS707AKM2, WS708AKM2See page 4

Notes: 1. Cylinder collar packets contain a collar & spring washer.

2. Specify finish when ordering packets.

PILLOW BLOCK PACKET

650F97-8 Pillow Block packet, ED4400 $38.00

POPPER KIT

681F758 for ED5470, ED5860 M55 $73.00

ROD & YOKE ASSEMBLY

650F82-8 Rod & Yoke Assembly, concealed $90.00

PART NO. DESCRIPTION LIST PRICE

ROD EXTENSION KIT (CONCEALED VERTICAL)

684F427 Rod Extension Kit, 24" $68.00

ROD EXTENSION KIT (SURFACE VERTICAL)

655F15

Rod Extension Kit, 2"

606, 612, 630 $58.00

605, 613 $62.00

611, 619, 625, 626, 629 $68.00

655F16

Rod Extension Kit, 6"

606, 612, 630 $70.00

605, 613 $74.00

611, 619, 625, 626, 629 $80.00

655F17

Rod Extension Kit, 12"

606, 612, 630 $74.00

605, 613 $78.00

611, 619, 625, 626, 629 $84.00

684F42

Rod Extension Kit, 24"

606, 612, 630 $76.00

605, 613 $80.00

611, 619, 625, 626, 629 $86.00

ROD GUIDE COVER

650F63

Rod Guide Cover

606, 612, 630 $22.00

605, 613 $26.00

611, 619, 625, 626, 629 $27.00

ROD GUIDE PACKET

650F62

Rod Guide Packet

626 $11.00

606, 612 $14.00

613 $17.00

SCREWS

605, 606, 611, 612, 613,619, 625, 626, 629, 630

429F41 Pack, Armored Front†Order 20-

606, 612, 613, 619 $3.10

704F63 Packet, Cover 606,612,613,630 finish $2.70

656F66-8 #10-24 x 1/4" PH †Order 100- $0.32

650F53-8 Dogging Assembly †Order 50- $0.44

650F51-8 Latch head to carrier†Order 50- $0.44

650F28-8 Touch bar caps (622 only) †Order 50- $0.54

650F50-8 Trim slide †Order 100- $0.14

SCREW PACK, TORX®PIN

701F60 ED4200(S), ED4800, ED5200(S), ED5800 $13.50

701F61 ED4400, ED5400, ED5470 $13.50

701F62 ED5600 $14.50

701F63 ED5860 $13.50

SEX NUT PACKET no finish

652F29-8 Sex Nut Packet (4 sex nuts) $15.00

SHIM KIT no finish

697F33-8 ED5200(S)(A), ED5600(A), ED5800(A) $88.00

697F34-8 ED5400(A) $108.00

697F35-8 ED4200(S), ED4800 $88.00

697F36-8 ED4400 $108.00

SPRING, TOUCH PAD no finish

656F41 Spring, Touch Pad $2.20

STRIKE PACKET 622 FINISH ONLY

650F88-8 bottom for 1/2" threshold (S09) $48.00

650F31-8 ED4200(S), ED4800 $46.00

650F29-8 ED5200, ED5202 $46.00

650F30-8 ED5200(S)(A), ED5202(S)(A) $70.00

650L65 ED5600 $29.00

650L65-7020 Mortise strike for ED5602(A) $29.00

653L15-7014 Mortise strike for doors with astragal $26.00

655F71-8 ED5200 x S02 $48.00

653L16-3016 open back straight lip for 1-3/4" door $78.00

653L16-3020 open back straight lip for 2-1/4" door $108.00

653L18-3016 open back curved lip for 1-3/4" door $78.00

653L18-3020 open back curved lip for 2-1/4" door $108.00

†Sold only in multiples of the number indicated. Price is each.

DEVICE PARTS (Cont'd)

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 52

PART NO. DESCRIPTION LIST

PRICE

TOP LATCH

650F73-8 Top Latch & Bracket Assembly. ED4800 $150.00

650F71-8 Top Latch & Bracket Assembly, ED5800 $152.00

650F72-8 Top Latch & Bracket Assembly, ED5800A $164.00

650F55-8 Top Latch, ED4400, ED5400, ED5470 $138.00

650F56-8 Top Latch, ED5400A, ED5470B $148.00

681F76-8 Top Latch, ED5860B $174.00

681F71-8 Top Mtg. Plate for ED5470B $42.00

TOP ROD NO FINISH

650F81-8 Top Rod Tube, concealed $76.00

650F80-8 Top Rod, concealed $62.00

650F60 fin

Top Rod, surface

606, 612, 630 $86.00

605, 613 $106.00

611, 619, 625, 626, 629 $106.00

PART NO. DESCRIPTION LIST

PRICE

TOP STRIKE PACKET

650F54-8 Top strike packet $63.00

681F70-8 Top strike packet for ED5470B $24.00

681F77-8 Top strike for ED5860B $28.00

TOUCH PAD CAP 622 ONLY

650F10-5 Touch Pad Cap, front $28.00

650F09-5 Touch Pad Cap, rear $22.00

TRIM SLIDE NO FINISH

650F49-8 Trim Slide Retainer †Order 10- $3.00

650F48-9 Trim Slide, ED4000 $5.00

TRIM PARTS, GRIPS

DESIGN STANDARD PART NO. STANDARD PRICE

606, 612, 630

STANDARD PRICE

605, 611, 613, 619

625, 626, 629

KNURLED PART

NO. ADD $65.00

TO STD. PRICE

ABRASIVE PART

NO. ADD $42.00

TO STD. PRICE

A7 652F78

$133.00 $151.00

652F79 652F80

C7 652F66 652F67 652F68

D7 RHR 652F69 652F70 652F71

D7 LHR 652F72 652F73 652F74

E7 652F57 652F58 652F59

G7 656F45 656F48 656F51

L7 652F60 652F61 652F62

N7 652F75 652F76 652F77

PR7 652F81 652F82 652F83

R7 652F63 652F64 652F65

A7M 653F71 653F72 653F73

C7M 653F59 653F60 653F61

D7M RHR 653F62 653F63

D7M LHR 653F65 653F66

E7M 653F50

G7M 656F44 656F47 656F50

L7M 653F53 653F54 653F55

N7M 653F68 653F69 653F70

PR7M 653F74 653F75 653F76

R7M 653F56 653F57

A8 653F05

C8 652F93 652F95

D8 RHR 652F96

D8 LHR 652F99

E8 652F84 652F85 652F86

G8 656F46 656F49 656F52

L8 652F87 652F88 652F89

N8 653F02 653F03 653F04

PR8 653F08 653F09 653F10

R8 652F90 652F92

08, 014 656F53 n/a n/a

†Sold only in multiples of the number indicated. Price is each.

TRIM PARTS, GRIPS (Cont'd)

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 53

DESIGN STANDARD PART NO. STANDARD PRICE

606, 612, 630

STANDARD PRICE

605, 611, 613, 619,

625, 626, 629

KNURLED PART

NO. ADD $65.00

TO STD. PRICE

ABRASIVE PART

NO. ADD $42.00

TO STD. PRICE

A9 677F16

$133.00 $151.00

652F79 652F80

677F15 652F67 652F68

D9 RHR 677F26 652F70 652F71

D9 LHR 677F27 652F73 652F74

E9 677F13 652F58 652F59

L9 677F04 652F61 652F62

N9 677F05 652F76 652F77

PR9 677F28 652F82 652F83

R9 677F14 652F64 652F65

A9M 653F71 653F72 653F73

C9M 653F59 653F60 653F61

D9M RHR 653F62 653F63

D9M LHR 653F65 653F66

E9M 653F50

L9M 653F53 653F54 653F55

N9M 653F68 653F69 653F70

PR9M 653F74 653F75 653F76

R9M 653F56 653F57

DESIGN PART NO. LIST PRICE

606

LIST PRICE

605, 613, 625, 626

FR9 RHR 698F64

$153.00 $163.00

FR9 LHR 698F66

TS9 698F31

Z9 RHR 698F68

Z9 LHR 698F70

M9 698F33 $137.00 $143.00

FR9M RHR 698F65

$153.00 $163.00

FR9M LHR 698F67

TS9M 698F32

Z9M RHR 698F69

Z9M LHR 698F71

M9M 698F34 $137.00 $143.00

TRIM PARTS, ESCUTCHEONS (Cont'd)

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 54

PART NO. DESCRIPTION 630, 606, 612 605, 613 611, 619, 625, 626, 629

656F58 x8 cyl. x knob $99.00 $105.00 $111.00

656F59 x8 cyl. x lever $107.00 $113.00 $119.00

656F60 x8 plain x knob or thumbturn $99.00 $105.00 $111.00

656F61 x8 plain x lever $107.00 $113.00 $119.00

677F00 x9 blank x lever

$141.00 $147.00 $153.00677F01 x9 cylinder x lever

695F18 x957 cylinder x lever

651F00 F450 $94.00 $100.00 $106.00

651F01 F457

676F04 F950

$141.00 $147.00 $153.00676F03 F957

694F76 F9M57

651F10 O14, T14 bottom $38.00 $44.00 $50.00

656F62 O1410 top $94.00 $100.00 $106.00

656F63 O1455/59 top

651F09 T1410 top $83.00 $89.00 $95.00

651F06 T1450 top $79.00 $85.00 $91.00

651F08 T1455, T1459 top $83.00 $89.00 $95.00

651F04 T1457 top $79.00 $85.00 $91.00

†Sold only in multiples of the number indicated. Price is each.

TRIM PARTS (Cont'd)

ED5000/ED4000 Series Pushpad Exit Devices

January 1, 2014Parts Price List. 55

PART NO. DESCRIPTION LIST

PRICE

BUSHING, NYLON NO FINISH

652F23-9 Bushing, Nylon †Order 20- $3.10

CLUTCH LEVER NO FINISH

651F53-8 Clutch Lever †Order 20- $2.60

COTTER PIN NO FINISH

677F09-8 Cotter Pin †Order 100- $0.28

COVER PLATE NO FINISH

651F85-8 Cover Plate, x8, O14, T14 $11.00

CYLINDER COLLAR

various see page 4

GEAR & BLACK HOUSING ASSEMBLY NO FINISH

651F63-8 Gear & Black Housing Assembly (all but x750) $13.00

651F64-8 Gear, levers $5.20

655F54-8 Gear, dummy lever

HEX NUT/BUSHING NO FINISH

651F39-8 Hex Nut/Bushing for spring $3.70

HOUSING NO FINISH

651F67-5 Housing & Cam Assembly, x755, T1355 $35.00

651F96-5 Housing & Cam Assembly, x855, x859, O/T1455/59 $28.00

651F42-5 Housing, Cylinder, F2, F3, T1357, O/T1457 $6.20

651F54-5 Housing, Tailpiece Assembly $22.00

706F01-5 Housing, Cylinder ED5202(S)(A), ED5602(A) $8.00

706F00-5 Housing, Cylinder, Trim, ED5202(S)(A), ED5602(A) $38.00

HUB NO FINISH

652F22-8 Hub $20.00

651F65-5 Hub, lever $6.20

656F64 Hub, G knob $6.60

LOCK WASHER NO FINISH

651F44-8 for screw post †Order 50- $0.30

NUT NO FINISH

651F88-8 Nut, Cover Plate †Order 50- $0.38

651F92-8 Nut, Spring Post $4.00

PIN NO FINISH

651F83-8 Pin, Clutch Lever †Order 50- $1.00

651F98-8 Pin, Groove, 5/32" x 1-1/8"

for T1410, T1455, T145 †Order 50- $0.60

651F58-7 Pin, Thumbpiece, T13M †Order 20- $0.98

PULL

651F37-2 Pull, Offset - 606, 612, 619, 626, 630 $104.00

605, 611, 613, 625, 629 $114.00

651F36-2 Pull, Straight - 606, 612, 619, 626, 630 $82.00

605, 611, 613, 625, 629 $90.00

RACK & TAILPIECE ASSEMBLY NO FINISH

651F82-8 x810, x855, x859, O14, T14 $76.00

652F21-8 x850 $64.00

RETAINER, CLUTCH LEVER PIN NO FINISH

651F89-8 Retainer, Clutch Lever Pin †Order 100- $0.18

RETAINING RING NO FINISH

651F60-8 Retaining Ring, T13M †Order 50- $0.30

ELECTRIFIED LOCKBODY USED WITH

“SAF” & “SEC” ED5600L DEVICES:

677F768LR 626 LOCK SA-L5 MORT.SAFE LHR $608.00

677F768RR 626 LOCK SA-L5 MORT.SAFE RHR $608.00

677F778LR 626 LOCK SA-L5 MORT.SEC. LHR $608.00

677F778RR 626 LOCK SA-L5 MORT.SEC. RHR $608.00

SCREW NO FINISH

655F02-8 Screw, Cylinder Mounting †Order 100- $0.24

651F87-8 Screw, FHM-PH #8-32 x 7/16" †Order 50- $0.26

PART NO. DESCRIPTION LIST

PRICE

SCREW (CONT'D) NO FINISH

656F65-8 Screw, Function $0.36

651F41-8 Screw, RHM-PH #1/4-20 x 5/8" †Order 50- $0.28

651F50-8 Screw, Tailpiece Plate,

PHT-T-PH #6 x 3/8 †Order 50- $0.36

SCREW PACKET, MOUNTING

652F12-8 1-3/4" - 2" door - 606, 612, 613, 619, 626 $6.60

652F10-8 1-3/4" - 2" door - 606, 612, 613, 619, 626 $4.50

652F11-8 2-1/4" door - 606, 612, 613, 619, 626 $4.50

652F13-8 2-1/4" door - 606, 612, 613, 619, 626 $6.60

652F14-8 F3, T13 for 1-3/4" -2 door - 606, 612, 613, 619, 626 $9.20

652F15-8 F3, T13 for 2-1/4" door - 606, 612, 613, 619, 626 $9.20

SCREW POST NO FINISH

651F43-8 Screw Post $5.20

SLIDER, THUMBPIECE NO FINISH

651F49-8 Slider, Thumbpiece $4.80

SPINDLE BRACKET NO FINISH

652F04-8 Spindle Bracket, lever $4.90

SPINDLE NUT NO FINISH

651F73-8 Spindle Nut, x7 †Order 20- $1.50

652F09-8 Spindle Nut, x7M lever †Order 50- $0.44

SPINDLE WASHER NO FINISH

652F06-8 Spindle washer, G Knob $3.00

652F05-8 Spindle Washer, Levers $3.40

SPRING NO FINISH

651F94-8 Spring, Extension $1.50

651F75-8 Spring, Grip Return, knob †Order 10- $3.00

651F61-8 Spring, Grip Return, lever, LHR (red) $3.10

651F62-8 Spring, Grip Return, lever, RHR (blue)

651F93-8 Spring, Rack, lever †Order 50- $1.40

651F47-8 Spring, Thumbpiece, T13 $3.50

678F02-8 Spring, Thumbpiece T13M $5.50

651F40-8 Spring, various trim †Order 20- $1.50

651F86-8 Spring, various trim †Order 50- $1.40

TAILPIECE ASSEMBLY NO FINISH

677F06-8 1-3/4" door without shim kit $31.00

655F69-8 2" - 2-1/4" door or 1 3/4" door with shim kit -

TH9 series trims $31.00

655F70-8 2" - 2-1/4" door or std. door with shim kit -

All trims except TH9 series $31.00

THIMBLE INSERT no finish

651F38-9 Knob & thumbturn †Order 50- $0.40

118F29-9 Lever †Order 100- $0.14

THUMBPIECE BRACKET no finish

651F57-8 Thumbpiece Bracket, T13M $16.00

THUMBPIECE TAB NO FINISH

651F56-8 Thumbpiece Tab, T13M $2.00

THUMBPIECE

605, 606, 611, 612, 613, 619, 625, 626, 629, 630

566F50 Thumbpiece, T13, T14 $38.00

566F51 Thumbpiece, T13M $44.00

WASHER NO FINISH

651F70-8 Washer under tailpiece †Order 50- $0.46

651F84-8 Washer, Grip †Order 20- $1.90

DC8000 Series Door Closers

January 1, 2014Parts Price List. 56

PART

NO. DESCRIPTION LIST

PRICE

BRACKET

754F18 Quik-Install™$14.50

188F41 Parallel arm $4.30

509F49 Parallel arm with hold-open $30.00

188F63 Parallel arm for flush transom $30.00

188F62 Parallel arm offset $20.00

244F17 Regular arm mortise $38.00

447F14 Angle support $30.00

499F30 Heavy duty parallel arm flush transom

bracket $19.00

COVERS

754F19 Full PVC cover $32.00

754F84 Full ABS cover

754F22 Full metal cover RH/LHR $46.00

754F23 Full metal cover LH/RHR

754F17 Cover screw pack $3.40

DROP PLATES

754F20 For DC8200 (regular) $64.00

754F24 For DC8200 (with concealed holder) $64.00

For DC8220 (top jamb)

754F25

For DC8210 (parallel)

$64.00For DC8230 (pull side track)

For DC8240 (push side track)

BLADE STOP SPACER

597F92 1/2" Spacer block $18.00

597F93 5/8" Spacer block $31.00

SCREW PACKETS

754F37

754F29

Standard screw pack

Standard screw pack (includes sex nuts) $9.00

754F30 SNB for 1-3/4" door $12.00

754F38 Torx®screw pack $29.00

$3.90

754F34

597F24

Torx screw pack (includes sex nuts)

Torx®tool kit

754F35 Main arm screw & washer

RETROFIT PLATES

754F28 To Replace 4040/4041 (Reg. & Par. Arm) $52.00

754F36 To Replace DC6000 (Reg. Arm) $68.00

754F46 To Replace DC6000 (Par. Arm or Top Jamb) $68.00

CLOSER PARTS

PART

NO. DESCRIPTION LIST

PRICE

CLOSER BODIES

754F21 Closer body for DC8200 $376.00

754F26 Closer body for DC8200 x M71 $411.00

ARMS

688F95

Regular arm, consists of: $53.00

688F99 main arm & tube assembly $34.00

688F98 rod & shoe assembly $14.00

688F92 hex screw pkg. $5.00

688F77

Regular arm with hold-open (A1),

consists of: $80.00

691F92 main arm & rod assy $32.00

540F40 hold open bracket assembly $48.00

689F02 Heavy-duty parallel arm (A3) $84.00

689F01 Heavy-duty parallel arm with hold-open (A2) $104.00

597F52 Heavy-duty regular arm (A10) $84.00

689F03 Heavy-duty parallel arm with backstop (A4) $92.00

689F04 Heavy-duty parallel arm with backstop &

hold-open (A5) $131.00

615F52 Unitrol®- Dr. width 28"-32" (A11)

$135.00615F54 Unitrol®- Dr. width 33"-41" (A11)

615F56 Unitrol®- Dr. width 42"-48" (A11)

615F51 Unitrol®w/ Hold Open - Dr. width 28"-32" (A12)

$155.00615F53 Unitrol®w/ Hold Open - Dr. width 33"-41" (A12)

615F55 Unitrol®w/ Hold Open - Dr. width 42"-48" (A12)

691F96 Heavy-duty offset arm (A13) $90.00

692F04 Heavy duty friction hold open, RH (A14) $83.00

692F05 Heavy duty friction hold open, LH (A14) $83.00

754F09 Pull side track only, non-hold open $136.00

754F10 Pull side track only, hold open $206.00

754F12 Push side track & arm, non-hold open $202.00

754F13 Push side track & arm, hold open $275.00

754F14 Push side track only, non-hold open $136.00

754F15 Push side track only, hold open $206.00

754F16

Slide track assembly (non-hold open or hold open)

$73.00

691F72

Deep reveal arm (7 1/4" max) consists of: $48.00

688F99 main arm and arm tube assy $34.00

691F75 rod & shoe assembly $11.00

691F74

Deep reveal arm with hold-open (7 1/4" max),

consists of: $77.00

691F95 main arm & rod assy- deep reveal $26.00

540F40 hold open bracket assy. $48.00

615F58 Reinforcing bracket $26.00

615F59 Deep reveal reinforcing kit $36.50

615F60 Flush partition bracket $25.00

CLOSER PARTS

DC6000 Series Door Closers

January 1, 2014Parts Price List. 57

PART NO. DESCRIPTION LIST

PRICE

CLOSER BODIES 600, 689, 690, 691, 693, 696

689F12 Closer body for DC6200 $306.00

689F13 Closer body for DC6200 x M71 $331.00

689F14 Closer body for DC6401

$306.00

689F15 Closer body for DC6402

689F16 Closer body for DC6403

689F17 Closer body for DC6404

689F18 Closer body for DC6405

689F19 Closer body for DC6406

691F52 Closer body for DC6401 x M71

$331.00

691F53 Closer body for DC6402 x M71

691F54 Closer body for DC6403 x M71

691F55 Closer body for DC6404 x M71

691F56 Closer body for DC6405 x M71

691F57 Closer body for DC6406 x M71

M71 = Delayed action

ARMS 600, 689 690, 691, 693, 696

688F95

Regular arm, consists of: $53.00

688F99 main arm & tube assembly $34.00

688F98 rod & shoe assembly $14.00

688F92 hex screw pkg. $5.00

688F77

Regular arm with hold-open (A1), consists of: $80.00

691F92 main arm & rod assy $32.00

540F40 hold-open bracket assembly $48.00

689F02 Heavy duty parallel arm (A3) $84.00

689F01 Heavy duty parallel arm with hold-open (A2) $104.00

597F52 Heavy duty regular arm (A10) $84.00

689F03 Heavy duty parallel arm with backstop (A4) $92.00

689F04 Heavy duty parallel arm with backstop &

hold-open (A5) $131.00

615F52 HD Spring stop for Dr. wdth. 28"-32" (A11)

$135.00615F54 Unitrol®for Dr. wdth. 33"-41

615F56 Unitrol®for Dr. wdth. 42"-48"

615F51 Unitrol®/HO for Dr. wdth. 28"-32" (A12)

$155.00615F53 Unitrol®/HO for Dr. wdth. 33"-41"

615F55 Unitrol®/HO for Dr. wdth. 42"-48"

691F96 Heavy-duty offset arm (A13) $90.00

754F16 DC6230, DC6430 pull side - arm only $73.00

754F10 DC6230, DC6430 - track only (hold-open) $206.00

754F09 DC6230, DC6430 - track only (non hold-open) $136.00

754F44 DC6230, DC6430 pull side track assembly, non-hold open $306.00

754F45 DC6230, DC6430 pull side track assembly, hold open $382.00

754F12 DC6240, DC6440 push side track & arm

(non hold open) $202.00

754F14 DC6240, DC6440 - track only (non hold-open) $136.00

754F13 DC6240, DC6440 track & arm (hold-open) $275.00

754F15 DC6240, DC6440 - track only (hold-open) $206.00

754F16 DC6240, DC6440 - arm only (hold-open) $73.00

691F72

Deep reveal arm (7-1/4" max), consists of: $48.00

688F99 main arm and arm tube assy $34.00

691F75 rod & shoe assembly $11.00

PART NO. DESCRIPTION LIST PRICE

ARMS 600, 689 690, 691, 693, 696

691F74

Deep reveal arm w/hold-open (7-1/4" max), $77.00

consists of: $77.00

691F95 main arm & rod assy- deep reveal $26.00

540F40 hold-open bracket assy. $48.00

615F58 Reinforcing bracket $26.00

615F59 Deep reveal reinforcing kit $36.50

615F60 Flush partition bracket $25.00

692F04 Friction, Hold Open Arm RH $83.00

692F05 Friction, Hold Open Arm LH $83.00

692F00 Reg. Secondary Arm Assy. $31.00

692F01 Top Jamb Secondary Arm Assy. $32.00

692F02 Reg. H.D. Secondary Arm Assy. $120.00

692F03 Deep Reveal HD. Secondary Arm Assy. $206.00

BRACKETS 600, 689, 690, 691, 693, 696

188F03 Quik-Install™ $13.50

188F41 Parallel arm $4.30

509F49 Parallel arm with hold-open $30.00

188F63 Parallel arm for flush transom $30.00

188F62 Parallel arm offset $20.00

244F17 Regular arm mortise $38.00

447F14 Angle support $30.00

499F30 Flush transom $19.00

691F78 Spacer $3.00

COVERS 600, 689, 690, 691, 693, 696

597F78 Full cover and insert pkt. (standard) $29.00

603F55 Full metal cover RH/LHR $34.00

603F57 Full metal cover LH/RHR

261F95 Cover screw pack $2.90

DROP PLATES 600, 689, 690, 691, 693, 696

188F65 For DC6220 x full cover $46.00

For DC6420 x full cover

597F58 For DC6210, DC6410, DC6240, DC6440 x full cover $52.00

597F59 For DC6230, DC6240, x full cover $46.00

For DC6430, DC6440 x full cover

BLADE STOP SPACER

597F92 1/2" Spacer block $18.00

597F93 5/8" Spacer block $31.00

RETROFIT KITS

615F61 To Replace 4040 (Reg. or Par. Arm)

$52.00615F64 To Replace 4110 EDA

615F62 To Replace 4010 Reg

SCREW PACKETS 600, 689, 690, 691, 693, 696

691F93 Standard Screw Pack $8.50

691F94 Standard Screw Pack w/ Sex Nuts $15.00

468F34 SNB for 1-3/4" door $8.10

691F89 Torx®Screw Pack $21.00

691F90 Torx Screw Pack with Sex Nuts $25.00

597F24 Torx®tool kit $73.00

754F43 Screw pack (push or pull track) $14.00

PAINT (PER CAN)

597F94 Silver Aluminum - 689

$39.00

597F95 Dark Bronze - 690

597F96 Light Bronze - 691

597F97 Satin Brass - 696

CLOSER PARTS

PART NO. DESCRIPTION LIST PRICE

TOOLS

330F10 Hex wrench for closer valve, 3/32" $2.60

597F24 Torx tool kit $73.00

CLOSER BODIES 600, 689, 690, 691, 693, 696

540F27 Closer body for DC3200 $260.00

597F35 Closer body for DC3200 x M71 $295.00

M71 = Delayed action

ARMS 600, 689, 690, 691, 693, 696

688F95 Regular arm $53.00

688F77 Regular arm with hold-open $80.00

688F95 Top jamb $53.00

688F77 Top jamb with hold-open $80.00

689F02 Heavy-duty parallel arm $84.00

689F01 Heavy-duty parallel arm with hold-open $104.00

597F52 Heavy-duty regular arm $84.00

689F03 Heavy-duty parallel arm with backstop $92.00

689F04 Heavy-duty parallel arm with backstop &

hold-open $131.00

691F98 Reg. secondary arm assy. $23.00

691F99 Deep reveal secondary arm assembly $24.00

692F02 Reg. H.D. secondary arm assembly $120.00

692F03 Deep reveal H.D. secondary arm assembly $206.00

BRACKETS 600, 689, 690, 691, 693, 696

188F03 Quik-Install™$13.50

188F41 Parallel arm $4.30

509F49 Parallel arm with hold-open $30.00

188F62 Parallel arm offset $20.00

188F63 Parallel arm for flush transom $30.00

244F17 Regular arm mortise $38.00

447F14 Angle Support Bracket and Spacer $30.00

DROP PLATES 600, 689, 690, 691, 693, 696

188F65 For DC3220 x full cover $46.00

597F58 For DC3210 x full cover $52.00

PART NO. DESCRIPTION LIST PRICE

COVERS 600, 689, 690, 691, 693, 696

597F78 Full cover and insert packet (standard) $29.00

PAINT (PER CAN)

597F94 Silver Aluminum - 689

$39.00

597F95 Dark Bronze - 690

597F96 Light Bronze - 691

597F97 Satin Brass - 696

DC3000 Series Door Closers

January 1, 2014Parts Price List. 58

DC5000 Series Cam Action Closers

January 1, 2014Parts Price List. 59

CLOSER PARTS

PART NO. DESCRIPTION LIST PRICE

CLOSER BODY 600, 689, 690, 691, 693, 696

754F68 Closer Body Only $331.00

ARMS 600, 689, 690, 691, 693, 696

754F09 Pull Side Slide Track Assy., Non-Hold Open $136.00

754F10 Pull Side Slide Track Assy., Hold Open $206.00

754F14 Push Side Slide Track Assy., Non-Hold Open $136.00

754F15 Push Side Slide Track Assy., Hold Open $206.00

754F65 Track Arm Package $32.80

692F15 Arm Stud Clip $6.40

692F14 Slider Assembly $71.40

692F16 End Cap (2 required) $5.30

COVER

754F79 Plastic Cover $30.00

DROP PLATE

754F80 Push side, drop plate $36.00

RETROFIT KIT

754F81 Retrofit plate for 4040 $60.00

SCREW PACKETS

754F69 Closer Screw Pack $7.80

754F70 Spline Screw Pack $19.90

754F78 Track Screw Pack $10.60

Electromechanical

January 1, 2014Parts Price List. 60

PART NO. DESCRIPTION LIST PRICE

DC62900 SERIES ELECTROMECHANICAL CLOSERS

689F12 DC6000 Closer Body $306.00

188F03 Quik-Install Bracket $13.50

597F78 Full Cover $29.00

603F55 Full Metal Cover RH $34.00

603F57 Full Metal Cover LH $34.00

692F24 Standard Arm Assembly $66.00

692F25 Adjusting Head and Tube Assembly $82.00

692F14 Slide Assembly $71.40

692F15 Arm Stud Clip $6.40

692F16 Track Assembly End Cap $5.30

692F17 Solenoid Block Assembly, 24V $210.00

692F19 Adjusting Rod Assembly $34.00

692F20 Arm Stud $4.10

692F21 Retaining Ring $2.00

692F23 Arm Length Adjusting Screw $1.30

754F02 Double Egress Arm, RH $120.00

754F03 Double Egress Arm, LH $120.00

754F04 Adjusting Head and Tube

Assembly, RH $80.00

754F05 Adjusting Head and Tube

Assembly, LH $80.00

754F52 Track Assy. (Hinge Side) Master or

support units $262.00

754F53 Track Assy. (Stop Side) Master or

support units

754F54 Hook-Up Board, Master or Support,

24V $86.00

754F55 Hook-Up Board, Master or Support,

120V $128.00

754F56 Hook-Up Box, Master unit, 24V,

push side $226.00

754F57 Hook-Up Box, Master unit, 120V,

push side

754F58 Hook-Up Box, Support unit, 24V,

push side $218.00

754F59 Hook-Up Box, Support unit, 120V,

push side

754F61 Hook-Up Box, Master unit, 24V,

pull side $226.00

754F62 Hook-Up Box, Master unit, 120V,

pull side

754F63 Hook-Up Box, Support unit, 24V,

pull side $226.00

754F64 Hook-Up Box, Support unit, 120V,

pull side

754F66 Fuse $12.50

754F71 Hook-Up Box Cover Kit (included

cover & screws), Master $226.00

754F72 Hook-Up Box Cover Kit (included

cover & screws), Support $39.00

754F73 Smoke Detector Board $338.00

PART NO. DESCRIPTION LIST PRICE

DC46920 SERIES

ELECTROMECHANICAL DOOR HOLDER AND CLOSER

494F77 Arm Assembly "Pull side" $138.00

494F76 Arm Assembly "Push side"

494F74 Holder - 120VAC $292.00

494F75 Holder - 24VAC/DC $292.00

494F72 Holder cover - Non Detector $112.00

494F86 System plug - 120VAC/24VAC $68.00

494F92 System plug - 24VDC

494F93 Wire harness - 120VAC/24VAC $53.00

494F94 Wire harness - 24VDC

PART NO. DESCRIPTION LIST PRICE

Access 800®AC2 Series

794F509 Gaskets Exit device - Reader $13.40

794F519 Gaskets Exit device trim $13.40

794F529 Gaskets Cylindrical lock $6.60

794F539 Gaskets Mortise lock $6.60

Notes

January 1, 2014Parts Price List. 61

For more information regarding Corbin Russwin Locksets,

Exit Devices, Door Controls and Key Systems, contact your

authorized Corbin Russwin Distributor or Sales Representative.

Corbin Russwin Architectural Hardware

225 Episcopal Road

Berlin, CT 06037

Phone 800-543-3658

Fax 800-447-6714

www.corbinrusswin.com

Notice: This price book takes precedence over the catalog as to

the correctness and availability of items in our entire line.

Corbin Russwin and Design®, and Infini-T®and Access 800®, are registered trademarks of Corbin Russwin, Inc., an ASSA ABLOY Group company.

Unitrol®is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Quik-Install™ and Vineyard™ are trademarks of Corbin Russwin, Inc., an ASSA ABLOY Group company.

These materials are protected under US copyright laws. All contents current at time of publication.

Corbin Russwin Inc., an ASSA ABLOY Group company reserves the right to change availability of any item in this catalog, its design, construction, and/or its materials.

Other products' brand names may be trademarks or registered trademarks of their respective owners and are mentioned for reference purposes only.

Reproduction in whole or in part without the express written permission of Corbin Russwin, Inc. is prohibited.

45201-4/13

Corbin Russwin CR Parts Price List 2014 Book Russwin2014Parts

Navigation menu

Versions of this User Manual:

Views

Navigation
