Features:
■Ice chest has 80 lb. capacity
■Foamed polyurethane insulation
■Key lock switch conveniently located on
tower
■Large, extended drip tray provides extra
room for cup staging and is removable for
ease in cleaning
■High capacity 9/12 circuit sealed in 19'' x 21''
aluminum cold plate
■Comes standard with 5, 6 or 8 UF-1 fast flow
electric valves (8 flavor requires two
ambient syrups)
■Six 3/8'' barb syrup fittings, one 3/8'' for
water, two 3/8'' for carbonated water
■Front inlet fitting location
■Available with or without lighted
merchandiser
■Available with a cabinet stand
CATG8514
2323 Universal
Drop-In Post-Mix Dispenser
2323 Universal
© 2001 IMI Cornelius
For more information or to
place an order, contact
your sales representative
or authorized distributor.
In the US:
Phone: 1-800-238-3600
Fax: 1-800-535-4235
Outside the US:
Phone: 1-763-421-6120
Fax: 1-763-422-3297
IMI Cornelius Inc.
One Cornelius Place
Anoka, MN 55303-6234
USA
Technical Specifications:
Drop-in Unit Countertop Cut-out: 23-1/4'' x 23-1/4''
Electrical Rating: Dispensing valves 24 VAC (power supply
requires 115V / 60 Hz / 1.5A)
Agency Listings:
Model No. Part No. Description Shipping Weight
CB2323-AK5 631100048 Drop-in dispenser with five fast flow UF-1 valves, 80 lb. bin 200 lbs. / 91 kgs.
CB2323-AK6 631100049 Drop-in dispenser with six fast flow UF-1 valves, 80 lb. bin 200 lbs. / 91 kgs.
CB2323-AK8 631100050 Drop-in dispenser with eight fast flow UF-1 valves, 80 lb. bin 201 lbs. / 92 kgs.
CB2323 162111002 Drop-in ice chest with sealed in nine circuit cold plate slotted rim for 145 lbs. / 66 kgs
mounting of Universal Tower
C-2123 162111004 Drop-in ice chest with sealed in nine circuit cold plate 145 lbs. / 66 kgs.
C-2123 162540000 Drop-in ice chest without sealed in cold plate 45 lbs. / 20 kgs.
165492000 Cabinet stand – turns 2323 drop-in into a freestanding unit 61 lbs. / 28 kgs.
