Quick Setup Guide | NS-CAHBTEP01/NS-CAHBTEP01-C
Bluetooth Earpods
PACKAGE CONTENTS
• Bluetooth earpods
• USB charging cable
• Quick Setup Guide
FEATURES
• Bluetooth 4.1
• Inline control, built in mic
• Up to six hours battery life for music
playback
• MicroUSB charging
CHARGING YOUR EARPODS
• When the red indicator LED blinks three
times a second, the battery is low. To
charge the battery, plug the microUSB
charging cable into your computer and
into the microUSB port on your earpods.
The red LED turns on to indicate that the
battery is charging and turns o when
fully charged.
Final flat size: 419.1 × 139.7 mm
Final fold size: 69.85 × 139.7 mm
FIND YOUR USER GUIDE ONLINE!
Go to www.insigniaproducts.com, then
click Support & Service.
Enter NS-CAHBTEP01 in the box under
Manual, Firmware, Drivers & Product
Information, then click ►.
# DESCRIPTION
1 + Volume Up
Next Track
2 Multi-function
Button (MFB)
(Power/Talk/Play/
Pause/Pairing)
3 Indicator LED
4 - Volume Down
Previous Track
5 Cable clamp
6 Micro USB port
7 Microphone
FUNCTION
Press + to increase the volume.
Press + to skip to the next track.
Press to turn on your earpods. If you
receive a phone call, press to talk.
Press to turn o your earpods.
Shows the current status of the
earpods.
Press - to decrease the volume.
Press - to skip to the previous track.
Use to clamp the cable to your
collar.
Plug the micro USB connector into
this port to charge your earpods.
Allows you to talk on the telephone.
USING YOUR EARPODS
Turning your earpods on and o
1 Place the earpod cable around your neck, then
clip the cable clamp to your collar. The inline
control falls naturally in front of your right
shoulder.
2 Press and hold the MFB for three seconds. The
LED blinks blue (when turned on) or red (when
turned o) and the voice prompt says “Power
on”, or “Power o.”
BLUETOOTH BASIC INDICATION
Bluetooth function indication
PAIRING YOUR EARPODS
Notes:
• Range is 33 feet (10 meters)
• Supports easy pairing
• Prompts you by saying “Device Connected,” when
connected
• Supports a battery indicator icon on an iOS device
Pairing with a cell phone or MP3 player
1 With your earpods turned o, press and hold
MFB for four seconds. The blue and red LEDs
blink alternately.
2 On your phone or MP3 player, select
INSIGNIA NS-CAHBTEP01 from the list of
discovered devices, then enter the password
0000 (four zeros) (if required) to pair your
earpods.
For more information on pairing Bluetooth
devices to your cell phone or MP3 player, see
the device’s documentation.
Note: After the earpods have been successfully paired
with the cell phone or MP3 player, the earpods will
automatically reconnect to the phone or MP3 player.
ACTION
Power on
Power o
Pairing mode
Play/Pause
Volume Up/Down
Next Track/Previous Track
Incoming call
Answer call
Reject call
Redial
Reset device list
OPERATION
Press and hold MFB more than two seconds
Press and hold MFB more than three seconds
Press and hold MFB more than four seconds in
power o mode
Press and release MFB button
Press and release + / - button
Press and hold + / - button
Press and release MFB when a call is incoming
Press and hold MFB when a call is incoming
Double press MFB
Press and hold MFB more than 10 seconds in
power o mode
LED INDICATION
Blue LED on 1.5 seconds
Red LED on 1.5 seconds
Blue and red LED blinking alternately
Blue LED blinks three times every
ve seconds when a call is received
All LEDs turn o
SOUND
“power on”
“power o”
Two short beeps
Two high beeps for maximum
volume. Two low beeps for
minimum volume
Ring tones
One short beep
One long beep
Two short beeps
Before using your new product, please read these instructions to prevent any damage.
v1
R2
V1 ENGLISH 16-0044
Pairing with a computer running Windows
Note: Before you pair the earpods with the computer,
make sure that the computer is equipped with
Bluetooth. Refer to the computer’s documentation or
contact the computer manufacturer for more
information. If your computer is not Bluetooth
compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For
instructions, see the computer’s
documentation or contact the computer
manufacturer.
2 Double-click the Bluetooth icon in the system
tray, then click Add a device (Add Wireless
Device using Windows Vista).
3 With the earpods turned o, press and hold
MFB for four seconds. The LED blinks blue and
red alternately. Pairing mode is activated.
4 Double-click the INSIGNIA NS-CAHBTEP01
icon on the computer or highlight the icon,
then click Next.
Note: If you are unable to locate the INSIGNIA
NS-CAHBTEP01 icon, click the Search Again button.
5 If required, enter 0000 (four zeros) in the
Bluetooth security code eld, then click Next.
6 After the earpods have been paired, click
Close. If you are using Windows XP, continue
with steps 7 through 9.
7 Select one of the Bluetooth hands-free types
shown on the Add a Bluetooth Device Wizard
screen, then click Next.
8 Select the services shown on the wizard screen
to use with your Bluetooth earpods, then click
Finish.
9 To connect the device, double-click the
INSIGNIA NS-CAHBTEP01 Hands-Free Unit
icon or the INSIGNIA NS-CAHBTEP01 Stereo
Audio icon.
Note: The earpods should be automatically selected
as the default playback device (Windows® 8,
Windows® 7, or Windows Vista®) or the default
recording and playback device (Windows XP). To
make those settings manually, refer to the User Guide.
Pairing with a Mac computer
Note: Before you pair the headphones with the
computer, make sure that the computer is Bluetooth
compatible. Refer to the computer’s documentation or
contact the computer manufacturer for more
information. If your computer is not Bluetooth
compatible, install a Bluetooth USB adapter (dongle).
1 Turn on Bluetooth on the computer. For
instructions, see the computer’s documentation
or contact the computer manufacturer.
2 Click the Bluetooth status menu.
3 Click Set up Bluetooth Device. The Bluetooth
Setup Assistant opens.
4 Click Continue.
5 Select Headset as the device type, then click
Continue.
6 With the earpods turned o, press and hold
MFB for four seconds. The LED blinks blue and
red alternately. Pairing mode is activated.
7 Select INSIGNIA NS-CAHBTEP01, then click
Continue. The computer gathers information.
8 Click Continue.
9 Enter 0000 (four zeros) into the Passkey eld,
then click Continue.
10 Click Quit to nish.
Note: To use the earpods, they must be selected as
the defualt input and output device on the
computer.
11 Click System Preferences, then click Sound.
12 Under Input, select INSIGNIA
NS-CAHBTEP01, then under Output, select
INSIGNIA NS-CAHBTEP01.
For more information on using your headphones
with Skype, refer to your User Guide.
RESETTING YOUR EARPODS
• To reset your earpods, with your earpods
turned o, press and hold MFB for 10 seconds.
Bluetooth version:
Supported proles:
Frequency spectrum:
Working distance:
Operating
temperature:
Operating time:
Standby time:
Weight:
Average charging
time:
Bluetooth 4.1+EDR
A2DP, AVRCP, HFP, HSP
2.4 ~ 2.4835 GHz ISM Band
Up to 33 ft. (10 m)
23 ~ 122° F (-5 ~ 50° C)
Talk: 6 hours
Music: 6 hours, playback music track
100 hours
0.423 oz (12g)
2 hours
SPECIFICATIONS
TROUBLESHOOTING
• Reset your BT headphone
• Plug microUSB cable for charging
LEGAL NOTICES
FCC statement:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution:
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, maybe cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent form
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ONEYEAR LIMITED WARRANTY
Visit www.insigniaproducts.com for details.
CONTACT INSIGNIA:
1-877-467-4289 (U.S. and Canada)
01-800-926-3000 (Mexico)
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its aliated companies.
Distributed by Best Buy Purchasing, LLC
©2016 Best Buy. All rights reserved.
Made in China
