42" HIGH SPEED

LAWNSWEEPER

Model No's. 486.24266

Owner's Manual

CAUTION:

Before using this product, read

this manual and follow all Safety

Rules and Operating Instructions.

• Safety

• Assembly

• Operation

• Maintenance

• Parts

PRINTEDINU.S.A. FORMNO.41750(10/02/14)

SearsBrandManagementCorporation,HoffmanEstates,IL60179U.S.A.

www.craftsman.com

®

STOP

DO NOT RETURN TO STORE

For Missing Parts or Assembly

Questions Call 1-866-576-8388

Want more information

or assembly tips?

Scan for Video

Instruction Guide.

2

Anypowerequipmentcancauseinjuryifoperatedimproperlyoriftheuserdoesnotunderstandhowtooperatetheequipment.

Exercisecautionatalltimes,whenusingpowerequipment.

1. Read the vehicle and sweeper owners manuals and

knowhowtooperateyourvehicleandsweeperbefore

usingthissweeperattachment.Alwaysinstructother

usersbeforetheyoperatethesweeper.

2. Donotpermitchildrentooperatesweeper.

3. Donotpermitanyonetorideonsweeper.

4. Neverattachthehopperropetoanypartofyourbody

orclothing!Neverholdontotheropewhiletowingthe

sweeper!Attachtheropetothetowingvehicletokeep

it away from wheels and rotating parts.

5. Operate the sweeper at reduced speed on rough

terrain, near ditches and on hillsides to prevent loss

of control.

6. Vehiclebrakingandstabilitymaybeaffectedwith

theattachmentofthissweeper.Donotllsweeper

tomaximumcapacitywithoutcheckingthecapability

of the towing vehicle to safely pull and stop with the

sweeper attached. Stay off of steep slopes.

7.  Stop and inspect vehicle and sweeper for damage

afterstrikinganobject.Repairanydamagebefore

continuing operation.

8. Keepsweeperawayfromre.Excessiveheatcan

damagethebrushesandhopperbagandcould

causethebaganditscontentstoburn.

9. Before storing the sweeper, always empty the hopper

bagtoavoidspontaneouscombustion.

10. Followmaintenanceandlubricationinstructionsas

outlined in the maintenance section of this manual.

Lookforthissymboltopointoutimportantsafetyprecautions.Itmeans—Attention!!

Become alert!! Your safety is involved.

MaintenanceSchedule .................................................. 13

Storage .......................................................................... 13

ServiceandAdjustments ............................................... 14

Troubleshooting ............................................................. 14

RepairPartsIllustration ................................................. 15

RepairPartsList ............................................................ 16

PartsOrdering ...............................................BACKPAGE

Safety Rules ....................................................................1

Warranty ..........................................................................2

AccessoriesandAttachments..........................................3

CartonContents ..............................................................3

FullSizeHardwareChart .................................................4

SweeperAssemblyInstructions ....................................... 5

HopperAssemblyInstructions .........................................7

Operation ....................................................................... 12

MODELNUMBER: 486.24266

SERIALNUMBER: ____________________

DATEOFPURCHASE: ____________________

WARRANTY

TABLE OF CONTENTS

Themodelandserialnumberswillbefoundonadecal

attached to the lawnsweeper.

Youshouldrecordboththeserialnumberandthedateof

purchase and keep in a safe place for future reference.

SAFETY

CRAFTSMAN LIMITED WARRANTY

FORONEYEARfromthedateofsalethisproductiswarrantedagainstdefectsinmaterialorworkmanship.

WITHPROOFOFSALEadefectiveproductwillbereplacedfreeofcharge.

Forwarrantycoveragedetailstoobtainfreereplacement,visitthewebpage:www.craftsman.com/warranty

Toobtainwarrantycoverage,returnadefectiveproductwithproofofsaletotheretailerfromwhichitwaspurchasedforfree

replacement.

Thiswarrantyisvoidifthisproductiseverusedwhileprovidingcommercialservicesorifrentedtoanotherperson.

Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.

Sears Brands Management Corporation, Hoffman Estates, IL 60179

DONOTRETURNTOSTOREforMissingPartsorAssemblyQuestions

Call1-866-576-8388AttachmentHotline

3

ACCESSORIES AND ATTACHMENTS

TheFrontMountDethatcher,Model486.24219attaches

to the lawn sweeper to help loosen and remove dead

grass and thatch from the lawn while sweeping.

These accessories were available when the unit was purchased. They are also available at most Sears retail

outlets and service centers. Most Sears stores can order repair parts for you when you provide the model

numbers of your tractor and sweeper

1

2

3

5

6

7

2

16

9

4

10

11

13

14

10

12

11

12

15

8

REF PART NO. QTY DESCRIPTION

1– – – 1 SweeperHousingAssembly

2 49766 2 BagArmTube

346777 HitchTube,L.H.(LeftHand)

4 24192 1 HitchBracket

5 23687 1 HitchBracket,Bent

6 46776 1 HitchTube,R.H.(RightHand)

7– – – 1 BrushAssembly(RightHand)

8 – – – 1 BrushAssembly(LeftHand)

REF PART NO. QTY DESCRIPTION

9 49768 1 HopperBag

10 47477 2 RearHopperTube

11 49765 2 UpperHopperTube

12 48726 2 LowerHopperTube

13 46823 1 PivotRod

14 43938 2 HopperSupportRod

15 24189 1 Bag Frame Strap

16 43737 1 Rope

CARTON CONTENTS

4

REF PART NO. QTY DESCRIPTION

A 46782 2 HexBolt,5/16-18x3"Lg.

B43224 2 HexBolt,5/16-18x2-1/4"Lg.

C 43084 4 HexBolt,5/16-18x1-3/4"Lg.

D 43661 4 HexBolt,1/4-20x1"

E 43978 4 CurvedHeadBolt,1/4-20x1"

F47189 8NylockNut,1/4"

G 47810 8NylockNut,5/16"

H 44917 2 Palnut,3/8"

HARDWARE PACKAGE CONTENTS

REF PART NO. QTY DESCRIPTION

I23368 2 HitchSpacer,3/4"

J46867 2 ClevisPin,1/4"x1-3/4"

K48365 2 ClevisPin,1/4"x1-1/8"

L 48366 2 ClevisPin,3/8"x1/2"

M 43055 7 HairpinCotter,3/32"

N 23353 1 HitchPin

O44481 2 VinylCap

A B C ED

M

N

O

J

I

SHOWN FULL SIZE

NOT SHOWN FULL SIZE

KL

G

FH

5

TOOLS REQUIRED FOR ASSEMBLY

(1) Hammer

(2) 7/16"Wrenches

(2) 1/2"Wrenches

ASSEMBLY

STEP 2: (SEE FIGURE 1)

• Eachbrushassemblyhasonebrushretainer

markedwitheitherredorblackink.Layoutthebrush

assembliesasshownsothatthebrushretainers

markedwithinkareinthemiddlewiththeblackone

on your right and the red one on your left.

OVERLAP BRISTLES

BRUSH RETAINER

MARKED RED

BRUSH RETAINER

MARKED BLACK

• Attachthebrushassemblywiththeblackbrush

retainertotherightendofthebrushshaftusingtwo

hexbolts(D)andnylocknuts(F).Thebrushretainer

markedwithblackinkmustbeplacedtothemiddle

of the sweeper.

STEP 1 - REMOVE PARTS FROM CARTON

• Toprotectpaintedparts,laythemoncardboardora

mat.

• Remove the sweeper housing, the loose parts and

thehardwarepackagefromthecarton.Layoutthe

partsandhardwareasshownonpages3and4.

• Placethesheetofcardboardfrominsidethecarton

onto your work surface to prevent scratching the

sweeper.

FIGURE 1

FIGURE 3

NYLOCK NUT (F)

BRUSH

RETAINER

MARKED

BLACK

OVERLAP

BRISTLES

HEX BOLT (D)

WELDED BRACE

STEP 3: (SEE FIGURE 2)

• Tipthesweeperforwardtoaccessthebrushshaft.

FIGURE 2

STEP 4: (SEE FIGURE 3)

IMPORTANT:Besuretheoverlapbristlesfaceoutwhen

abrushisrotatedtothebottomposition.

6

STEP 5: (SEE FIGURE 4)

• Attachthebrushassemblywiththeredbrushretainer

totheleftendofthebrushshaftusingtwohexbolts

(D)andnylocknuts(F).Thebrushretainermarked

withredinkmustbeplacedtothemiddle of the

sweeper.

• Turnawheeltorotatethebrushes.(Thewheels

drivethebrushesinonedirectiononly.)Theoverlap

bristlesshouldbeonthebacksideofthebrushasit

rotates.

FIGURE 4

STEP 6: (SEE FIGURES 5 AND 6)

• Thehitchtubesarestampedwitha"77L"forthe

lefttubeanda"76R"fortherighttube.Thesweeper

housingismarkedwithan"L"ontheleftwithside

andan"R"ontherightside.

• Holdthelefthitchtubeagainsttheleftsideofthe

sweepersothatthe"77L"onthetubefacesaway

fromthesweeper.Attachthehitchtubeusingtwohex

bolts(C)andnylocknuts(G).Do not tighten yet.

HEX BOLT (C)

HITCH TUBE (L.H.)

NYLOCK NUT (G)

TUBE

MARKED

“77L”

HOUSING

MARKED “L”

FIGURE 5

FIGURE 6

HEX BOLT (C)

HITCH TUBE (R.H.)

NYLOCK NUT (G)

TUBE

MARKED

“76R”

HOUSING

MARKED “R”

STEP 7: (SEE FIGURE 6)

• Holdtherighthitchtubeagainsttherightsideofthe

sweepersothatthe"76R"onthetubefacestoward

thesweeper.Attachthehitchtubeusingtwohexbolts

(C)andnylocknuts(G).Do not tighten yet.

HEX BOLT (D)

NYLOCK NUT (F)

BRUSH RETAINER

MARKED RED

STEP 8: (SEE FIGURE 7)

• Fastenthehitchtubestogetherusingtwohexbolts

(A)andnylocknuts(G).Do not tighten yet.

HEX BOLT (A)

NYLOCK NUT (G)

FIGURE 7

7

FIGURE 9

STEP 10b: (SEE FIGURE 9)

• Ifthetractorhitchis10"ormoreabovetheground,

assemblethehitchbracketsasshowningure10.

Inserttwohexbolts(B)throughthebrackets,with

therearhexboltbetweenthecrossboltsinthehitch

tubes.Securethehexbolts(B)withtwonylocknuts

(G).Do not tighten yet.

• Assemblethetwospacers(I)ontothehitchpin(N)

andsecurethepinwiththehairpincotter(M).

FIGURE 8

STEP 10a: (SEE FIGURE 8)

• Ifthetractorhitchislessthan10"abovetheground,

assemblethehitchbracketsasshowningure9.

Inserttwohexbolts(B)throughthebrackets,with

therearhexboltbetweenthecrossboltsinthehitch

tubes.Securethehexbolts(B)withtwonylocknuts

(G).Do not tighten yet.

• Assemblethetwospacers(I)ontothehitchpin(N)

andsecurethepinwiththehairpincotter(M).

STEP 9

• Usethemarkalongthesideofthispagetomeasure

theheightofthetractorhitch.Themarkis10"from

thebottomofthepage.Ifthetractorhitchislessthan

10"abovetheground,gotoSTEP 10a. If the tractor

hitchis10"ormoreabovetheground,gotoSTEP 10b.

STEP 11

• Tightenthefourboltsassembledinsteps6and7.

• Tightenthetwoboltsassembledinstep9.

• Tightenthetwoboltsassembledinstep10aor10b.

10"

NYLOCK NUTS (G)

HITCH BRACKET

ASSEMBLY

BENT HITCH

BRACKET

HEX BOLTS (B)

HITCH PIN (N)

HAIRPIN COTTER (M)

SPACERS (I)

NYLOCK NUTS (G)

BENT HITCH

BRACKET

HITCH

BRACKET

ASSEMBLY

HEX BOLTS (B)

SPACERS (I)

HAIRPIN

COTTER (M)

HITCH PIN (N)

8

ASSEMBLY OF HOPPER BAG

STEP 12: (SEE FIGURE 10)

• Fittheendsofthetwoupperhoppertubesintothe

endsofarearhoppertube.Aligntheholesinthe

endsofthetubesandsecuretheminplaceusingtwo

curvedheadbolts(E)andnylocknuts(F).

• Fittheendsofthetwolowerhoppertubesintothe

endsofarearhoppertube.Aligntheholesinthe

endsofthetubesandsecuretheminplaceusingtwo

curvedheadbolts(E)andnylocknuts(F).

NOTE:Eithersideoftherearhoppertubecanfaceup.

FIGURE 10

FIGURE 11

UPPER

HOPPER

TUBE

HOPPER

BAG

BOTTOM

STITCHED SLEEVE

FIGURE 12

LOWER HOPPER TUBE

HOPPER BAG

BOTTOM

UPPER HOPPER

TUBE

CLEVIS PIN (L)

HAIR COTTER

PIN (M)

UPPER

HOPPER

TUBE

NYLOCK

NUT (F)

CURVED HEAD

BOLT (E)

REAR

HOPPER

TUBE

LOWER

HOPPER TUBE

REAR

HOPPER

TUBE

NYLOCK

NUT (F)

CURVED HEAD

BOLT (E)

STEP 13: (SEE FIGURE 11)

• Unfoldthehopperbag,reversethefoldofthemesh

windscreenandthenlaythebagoutatwiththe

wind screen on top.

• Inserttheendsoftheassembledupperhoppertubes

down through the stitched sleeves in the sides of the

hopperbagandthenslidethetubesbackunderneath

the wind screen.

STEP 14: (SEE FIGURE 12)

• Placetheassembledlowerhoppertubesintothe

bottomofthehopperbagandthenslidethetubesto

thebackofthebag.

• Attachtheendsofthelowerhoppertubestothe

insideoftheupperhoppertubesusingtwoclevis

pins(L)insertedfromtheinside,andtwohaircotter

pins(M).

9

STEP 17: (SEE FIGURE 15)

• Foldthebagapsaroundthelowerhoppertubesand

attachtothebagbottomusingthesnaps.

FIGURE 15

STEP 15: (SEE FIGURE 13)

• Insertthebagframestrapintothestitchedsleeveat

thefrontedgeofthebagbottom.

FIGURE 14

SNAP FLAP

BAG FRAME STRAP

STITCHED

SLEEVE

STEP 16: (SEE FIGURE 14)

• Assemblethebagframestraptotheholesinthe

lowerhoppertubesusingtwoclevispins(K)andhair

cotterpins(M).

FIGURE 13

STEP 18: (FIGURE 16)

IMPORTANT: Do notoverbendthesupportrods

duringthefollowingstep.Overbendingwillcausethe

steel rods to loose supporting tension.

• Tipthehopperontoit'sbacktoassemblethetwo

hoppersupportrods.Placetheendsofeachrodinto

theupperandlowerrearhoppertubes,bendingthe

rodjustenoughtotintotheholesinthetubes.

SUPPORT

RODS

FIGURE 16

CLEVIS PIN (K)

HAIR COTTER

PIN (M)

BAG FRAME STRAP

10

FIGURE 18

STEP 19: (SEE FIGURE 17)

• Slide the end of the pivot rod through the upper

hoppertube.Placeabagarmtubeontotherod.Slide

the rod through the stitched sleeve at the front edge

ofthewindscreen,andthenplaceanotherbagarm

tubeontotherod.Slidetherodthroughtheother

upperhoppertube.

STEP 22: (SEE FIGURE 20)

• Toattachthehopperbagtothesweeper,slidethe

endsofthebagarmtubesintotheendsofthehitch

tubesandsecurewithtwoclevispins(J)andhairpin

cotters(M).

STEP 21: (SEE FIGURE 19)

• Secure the rope to the center of the upper rear

hoppertube.

FIGURE 20

STEP 20: (SEE FIGURE 18)

• Assembleavinylcap(O)ontoeachbagarmtube.

• Assembletwopalnuts(H)ontotheendsofthepivot

rod using a hammer.

HINT: Toeaseassemblyofthepalnuts,placethebag

onitssideonasolidsurface.Withthebottomendofthe

pivot rod against the surface, tap a palnut onto the top

end of the rod. Repeat for other end of rod.

FIGURE 17

FIGURE 19

BAG ARM TUBE

HOPPER BAG

PIVOT ROD

MOUNTING CLAMP MOUNTING CLAMP

WIND SCREEN WIND SCREEN

MOUNTING CLAMP MOUNTING CLAMP

PALNUT (H)

CAP (O)

CLEVIS PIN (J)

BAG ARM TUBE

HAIRPIN

COTTER (M)

11

ATTACHING SWEEPER HITCH TO TRACTOR

BLACK LINE IS TRACTOR HITCH

HITCH BRACKET MOUNTED

BELOW HITCH TUBES

BLACK LINE IS TRACTOR HITCH

HITCH BRACKET MOUNTED

ABOVE HITCH TUBES

FIGURE 21

• Placethetractorandsweeperonaatlevelsurface.

• Setthesweeperheightadjustmenthandletoabout

themiddleofitsadjustmentrange.

• Attachthesweeperhitchtothetractorhitch,

arrangingthe3/4"spacersinoneofsixpossible

combinationsasshowninGROUPAandGROUPB

diagramsbelow.

IMPORTANT:Toobtainthebestperformancefromyour

sweeper,arrangethespacerssothatthesweeperbagis

approximatelylevelwiththegroundandapproximately5"to

7"offthegroundasshowningure21.

GROUP "B" - For vehicles with hitches

having 10" to 13" ground clearance.

GROUP "A" - For vehicles with hitches

having 8" to 10" ground clearance.

APPROXIMATELY LEVEL

(5" to 7" FROM SURFACE)

BRUSH HEIGHT ADJUSTED

APPROXIMATELY MID-WAY

12

KNOW YOUR SWEEPER

CAUTION:Keepsweeperawayfromre.

Excessiveheatcandamagethebrushesand

hopperbagandcouldcausethebagandits

contentstoburn.

CAUTION: Never attach the hopper rope

toanypartofyourbodyorclothing!Never

hold onto the rope while towing the sweeper!

Attach the rope to the towing vehicle to keep

it away from wheels and rotating parts.

DUMPING OF SWEEPER

• Yoursweepercanbedumpedeasilywithoutgetting

off of the rider or tractor. Simply pull the rope forward

todumpthehopper.Alwaysemptyhopperaftereach

use.

BRUSH HEIGHT ADJUSTMENT

• Toadjustyoursweeperbrushestothebestoperating

height,loosenthewingknobandpushdownonthe

heightadjustmenthandletoraisethebrush,orpush

uponthehandletolowerthebrush.Bestadjustment

iswhenthebrushsettingis1/2"downintothegrass.

Alwaysmowthegrasstoanevenheightbefore

sweeping.

SWEEPING SPEED

• Do not exceed 6 m.p.h.Tryastartingspeedof

approximately3m.p.h.(thirdgearonmosttractors).

Dependingontheconditions,itmaybenecessaryto

adjustthesweepingspeedinordertoachievebest

results.

OPERATION

HopperBag   Collectsgrassclippings,leavesanddebris.

HopperRope   Permitsdumpingofhopperbagfromdriver'sseat.

Windscreen   Helpspreventcollectedmaterialfrombeingblownoutofhopperbag.

BagArmTubes   Connectsthehopperbagtothesweeperhousing.

PivotRod   Allowshopperbagtotiltforwardtodumpmaterial.

HeightAdjustmentHandle Adjuststheoperatingheightofthesweeper.

HitchBracket   Connectsthesweepertothetowingvehicle.Adjustsforvariousheighttractorhitches.

WingKnob   Tightensthewheelinpositionafteradjustingheight.

HOW TO USE YOUR SWEEPER

HOPPER BAG

WINDSCREEN BAG ARM TUBE

PIVOT ROD

HEIGHT

ADJUSTMENT

HANDLE

HITCH

BRACKETS

HOPPER

ROPE

WING KNOB

CAUTION: Maximum towing speed is 6 m.p.h.

Drivingtoofastmaydamagewheelsandbearings.

13

MAINTENANCE

 MAINTENANCESCHEDULE

Fill in dates as you

complete regular service.

 Checkforloosefasteners   X

 Checkforwornordamagedparts   X   X

 Clean,inspect&lubricatewheelbearings    X

 CleanSweeper    X   X

 Clean,inspect&lubricategears      X 

FIGURE 23

CLEANING

• Cleansweeperhousingwithasoftbrushorcloth.

• Cleandebrisfromhopperbagwithabrushorbroom.

• Remove any material which has wrapped around

brushesorendsofbrushshaft.

CUSTOMER RESPONSIBILITIES

• Read and follow the maintenance schedule and the

procedures listed in the maintenance section.

Before each use

Aftereachuse

Twiceayear

Everyyear

Before storage

ServiceDates

SCHEDULED MAINTENANCE

• Cleanthesweeperaftereachuse.

• Inspectforwornordamagedparts,suchasbrushes

and wheels.

• Everyyear,removethewheelsandcleanthegear

teethandtheteethonthebacksideofthewheel.

Aftercleaning,lubricatetheaxle,andtheteethon

the gears and the wheel with a light coat of grease.

Toremovetherightwheel,unscrewthewingknob

andremovethewheelandwashers.Toremovethe

leftwheel,popoffthehubcapusingascrewdriver

andremovewheelalongwiththebolt,washers,step

spacerandnut.Seegures22and23.

FIGURE 22

• Cleanthesweeperandhopperbagthoroughlytohelp

prevent rust and mildew.

• Tocollapsethehopperbagforstorage,removethe

two hopper support rods from the rear of the hopper.

• Store in a dry area.

CAUTION: Before storing the

sweeper,alwaysemptythehopperbagto

avoidspontaneouscombustion.

STORAGE

WASHER

WING KNOB

REMOVING RIGHT SIDE WHEEL

BOLT

WASHER

HUB

CAP

WASHER

STEP

SPACER

NYLOCK

NUT

REMOVING LEFT SIDE WHEEL

14

GEAR AND PAWL SERVICE

IMPORTANT: Do notremovebothwheelsatthesame

timetoavoidmixingofparts.(TheR.H.andL.H.pinion

gearsarenotinterchangeable.)Make notes on the

positionofwashersandsnapringsduringdisassembly.

• Remove one wheel at a time, following the instructions

intheMAINTENANCEsection.

• Remove the retaining rings which hold the gears on the

brushshaftandthejackshaft.

• Remove the pinion gear, washer and drive pin from the

endofthebrushshaft.(Thedrivepinmayfalloutofthe

brushshaftwhenthepiniongearisremoved.)

• Removetheidlergearandwashersfromthejackshaft.

• Cleanallparts.

• Replace worn parts.

• Toreassemble,lightlygreasethejackshaftandthe

brushshaft.Insertthepinintotheholeinthebrush

shaft.Makesurethepinstaysintheshaft.

• Lightlygreasetheteethonbothgearsandllthe

recessofthepiniongearwithgrease.Assembleboth

gearsbackontotheshafts.

• Lightlygreasetheaxleandthenreassemblethewheel

ontoit.Thebrushesshouldrotateonly during forward

rotationofthewheel.Ifthebrushesaredriven(rotated)

bybothforwardandreverserotationofthewheel,the

drivepinisjamminginthepiniongear.Disassemble

andcleanandlubricatethedrivepinandpiniongear.

BRUSH REPLACEMENT

NOTE: Brushreplacementshouldbedoneonebrushat

a time.

• Removethehopperbagfromthesweeper.

• Loosenthehexboltsandlocknutsontwosingle

brushretainerswhichclamponebrushtothedouble

brushretainers.Do Not loosenorremovethebolts

whichfastenthedoublebrushretainerstothebrush

shaft.Seegure24.

• Slidethebrushoutoftheretainers,notingonwhich

sideofthebrushthebristlesoverlap.Seegure24.

• Installnewbrush,makingsurethebristlesoverlapon

thesamesideofthebrushasbefore.Seegure24.

FIGURE 25

BRUSH ROTATION

BRUSH ROTATION

OVERLAP

BRISTLES

OVERLAP

BRISTLES

SINGLE

BRUSH

RETAINERS

DOUBLE BRUSH RETAINER

BRUSH

SHAFT

FIGURE 24

• Brushessettoolow.

• Brushesarejammed

• Wheelsarejammed.

Wheels skid when sweeping. • Adjustheighttillbrushesare1/2"

down into grass.

• Stopsweeper.Removeobstruction.

• Remove one wheel at a time to check

forobstructionordamage.Referto

ServiceandAdjustmentssection.

SERVICE AND ADJUSTMENTS

TROUBLESHOOTING

IDLER

GEAR

WASHER WASHER

RETAINING

RING

WASHER

PINION

GEAR

DRIVE

PIN

15

NOTES

16

REPAIR PARTS

486.24266 42" HIGH SPEED LAWNSWEEPER

1

2

3

4

5

6

7

8

10

11

12

14

13

13

15

16

17

21

20

20

19

18

22 23

26

25 26

22 27

29

28 27

30

32

31

33

41

33

33

42

43

33

41

33

33

41

33

41

44

46

46

46

46

46

46

46

47

47

45

48

48

49

49

51

53

54

54

51

55

55

56

56

59

58

52

52

60

61

50

17

50

17

57

57

7

37

38

19

39

40

35

34

36

Toorderreplacementparts,callSearsPartsDirect1-800-252-1698orgotowww.searspartsdirect.com

17

ITEM PART NO. QTY DESCRIPTION

1 67105 1 HousingAssembly

2 68202 1 HeightAdjustmentTubeAss'y.

346776 1 HitchTube,R.H.

4 46777 1 HitchTube,L.H.

5 24192 1 Bracket,Hitch(Straight)

6 23687 1 Bracket,Hitch

7 41436 2 Wheel&TireAss'y.(withbearings)

841570 2 DustCover

9 67103 1 WheelDriveAssembly,L.H.(Not

Shown)

10 67102 1 WheelDriveAssembly,R.H.

11 27235 1 Brush Shaft

12 46780 4 Brush,42"

13 23581 8Retainer,Brush(Single)

14 23580 4 Retainer,Brush(Double)

15 43661 4 Bolt,Hex1/4-20x1"Lg.

16 43012 8Bolt,Hex1/4-20x3/4"Lg.

17 47189 16 Nut,Nylock1/4-20Thread

18 43720 1 WingKnob

19 141 2 Washer,.378x1.25x.061

20 45088 4 Wheel Bearing

21 44008 2 Washer,1-1/8"x.78"x.025"

22 1650-1 4 Ring,Retaining(E-type)

23 48652 1 Gear,PinionR.H.

24 48651 1 Gear,PinionL.H.(notshown)

25 47046 2 DowelPin(Drive)

26 R19212016 4Washer,.656x1.25x.025

27 44137 4 Washer,1/2"x1"x.02"

28 41434 2 IdlerGear,27T.

29 23520 2 Spacer,.660IDx.250ODx.25

30 44232 2 Ball Bearing

31 41437 2 Bearing Retainer

ITEM PART NO. QTY DESCRIPTION

32 43182 4 Bolt,Hex5/16-18x3/4"Lg.

33 47810 12 Nut,Nylock5/16-18Thread

34 27234 1 Retainer,CarriageBolt

35 42425 1 Bolt,Carriage5/16-18x3-1/2"

36 43943 1 Grip,HeightAdjust

37 41017 1 HubCap

38 43932 1 Bolt,Hex3/8-24x3-1/2"Lg.

39 26538 1 Spacer, Step

40 1038 1 Nut,Nylock3/8-24Thread

41 43084 4 Bolt,Hex5/16-18x1-3/4"Lg.

42 46782 2 Bolt,Hex5/16-18x3"Lg.

43 43224 2 Bolt,Hex5/16-18x2-1/4"Lg.

44 23353 1 Pin,Hitch

45 23368 2 Tube,HitchSpacer

46 43055 7 HairpinCotter,3/32"#3

47 46867 2 Pin,Clevis1/4"x1-1/2"Lg.

48 48365 2 Pin,Clevis1/4"x1-1/8"

49 48366 2 Pin,Clevis3/8"x1/2"

50 43978 4 CurvedHeadBolt,1/4-20x1"

51 44917 2 Palnut,3/8"

52 44481 2 Cap,Vinyl

53 46823 1 PivotRod,HopperBag

54 49766 2 Tube,BagArm

55 47477 2 Tube,RearHopperFrame

56 48726 2 Tube,LowerHopperFrame

57 49765 2 Tube,UpperHopperFrame

58 43938 2 HopperSupportRod

59 24189 1 Strap, Bag Frame

60 41751 1 HopperBag

61 43737 1 HopperRope

41750 1 OwnersManual

REPAIR PARTS

486.24266 42" HIGH SPEED LAWNSWEEPER

Toorderreplacementparts,callSearsPartsDirect1-800-252-1698orgotowww.searspartsdirect.com

18

19

® Registered Trademark /

TM

Trademark of KCD IP, LLC in the United States, or Sears Brands, LLC in other countries

® Marca Registrada /

TM

Marca de Fábrica de KCD IP, LLC en Estados Unidos, o Sears Brands, LLC in otros países

Product questions or problems?

1-888-331-4569

Customer Care Hot Line

Get answers to questions, troubleshoot problems,

order parts, or schedule repair service.

Para respuestas a preguntas o problemas, y ordenar

piezas o pedir servicio para la reparación de su equipo.

To help us help you, register your product at www.craftsman.com/registration

Para poderte ayudar mejor, registra tu producto en www.craftsman.com/registration

Join the Craftsman Club today!

Receive exclusive member benefits including special pricing and offers,

project sharing, expert advice, and SHOP YOUR WAY REWARDS!

Como miembro exclusivo, recibe diversos beneficios como ofertas, precios especiales, proyectos

nuevos, consejos de expertos y nuestro programa de puntos SHOP YOUR WAY REWARDS!
