PIVOT TABLE
1 With assistance of another adult, attach legs
onto tabletop frame with 2 leg bolts, 2 spring
washers, and 2 flat washers per leg as shown.
Secure with Phillips head screwdriver, but do not
over tighten bolts. Cover all exposed bolt holes
with the wood plugs.
NOTE: Do not over
tighten the bolts.
Phillips head screwdriver
Made in China r03 Page 1 of 2
Thank you for purchasing the Pivot Table. This page
lists all the contents included in the box. Please take the
time
to identify the hardware as well as the individual
components
to this product. As you unpack and
prepare for assembly, place the contents on a carpeted
or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
TOOLS REQUIRED
Missing hardware?
Please call 800.606.6387 for replacements.
HARDWARE
COMPONENTS
1 - tabletop
4 - legs
1 - tabletop frame
8 - wood
plugs
9 - flat
washers
8 - spring
washers
8 - leg
bolts
1 - wing
bolt
Customer Service 800.967.6696 | www.crateandbarrel.com
Made in China r03 Page 2 of 2
PIVOT
TABLE
2 With assistance of another adult, place table
top on top of assembled unit. Underneath
tabletop, insert 1 wing bolt and 1 flat washer, and
turn clockwise to secure.
3 With assistance of another adult, carefully turn
tabletop counter clockwise 90 degrees as shown.
4 Carefully unfold tabletop 180 degrees as
shown. Assembly is now complete.
Underneath
tabletop
INSTRUCTIONS TO EXPAND TABLETOP
CLEANING AND CARE
Clean surfaces with a dry or damp soft cloth.
Do not use abrasive cleaners. Do not use
furniture wax or polish as the wood is finished
with a protective clear lacquer.
