User Manual
介绍 按键操作说明
蓝牙无线通信的技术介绍
蓝牙是一种支持设备短距离通信（通常在10M内）的
无线电技术。能在包括手机、无线耳机、电脑等众多IT
数码设备之间进行无线信息交换。利用“蓝牙”技术能
有效地简化设备之间的通信，数据传输从而变得更加迅
速高效。
蓝牙耳机使用方法
非常感谢您使用AWEI无线运动立体声蓝牙耳挂，在
使用本产品之前，请详细阅读本手册。
音量+/下一首
多功能按键
USB充电接口音量-/上一首
磁控开关蓝牙耳机
2 3 4 5 6
蓝牙版本 V4.1
支持协议 HFP、 HSP、 A2DP、 AVRCP、CVC
输出功率 5mw
有效距离 10米（无障碍空间）
工作时间 通话时间约12小时，播放音乐时间约10
小时
待机时间 240小时
充电时间 2小时
充电电压 DC 5V
电池容量 130mAh
蓝牙耳机产品规格
Magnetic Switch Bluetooth Headset
2 3
Volume+ / next track
Multi-function button
USB charging port
Volume+ / next track
Multi-function button
USB charging port
Volume -
Previous track
Volume -
Previous track
456
Introduction
Bluetooth Earphone Specifications
Thank you for purchasing the model AWEI Wireless
Sports Stereo Earhook. Pls read this manual before use.
Bluetooth is a kind of wireless technology which support
short distance communications (work normally within a
distance of 10M) with it you can exchange information by
wireless between many IT digital devices like mobile
phones / wireless earphones / computers ect. Bluetooth
technology effectively and simplify to the communications
which makes device and data transmission quickly and off
effectively.
Bluetooth wireless communications Technology
introduction
Overview Of Headset How To Use How To Use How To Use
Bluetooth Version V4.1
Bluetooth Protocol HFP、 HSP、 A2DP、 AVRCP
CVC
Output Power 5mw
Workable Distance 10m(Barrier-free Space)
Working Hours 8-10 hours for talking time, 6-8 hours
for playing music
Stand-by Time 240 hours
Charging Time 2 hours
Charging Voltage DC 5V
Battery Capacity 130mAh
您好!
Hello!
USER MANUAL
使用说明
1
尊敬的AWEI用户：
感谢您选用AWEI产品！您的选择对于我们至关重
要，这意味着AWEI又增加了一名新用户。希望通
过我们的产品和服务，为您带来上佳的体验。也
希望您在产品体验过程中，通过官方客户热线、
微博、微信、等提出好的意见和建议，帮助AWEI
不断完善产品和服务。
如果您在产品使用过程中遇到任何问题，请参照
服务流程，方便、快捷地获取帮助。您的支持是
我们成长的动力，您的每一次认可和评价都是对
AWEI莫大的鼓励。谢谢！
用维营销团队
1
Dear AWEI User,
Thank you for choosing AWEI product. Your choice is
crucial for us,which means AWEI has added a new
user. Hope that we will bring you a good experience
through our products and services. Also hope you will
put forward the good advice and suggestions by
official customer hotline, Weibo and Wechat in the
process of product experience,which can help AWEI
to constantly improve product and service.
If you meet any problems in the using product, please
refer to service process. Your support is our strongest
power, also your recognition and evaluation are a
great encouragement to AWEI. Thank you!
AWEI sales team
蓝牙耳机使用方法
在使用时，请阅读以下建议有助于您遵守保修条款，并
延长产品的使用寿命。
声明：为提高产品性能我们会进行产品升级，本说明内容
可能会有所变更，恕不另行通知，敬请见谅。感谢您的选
购！
如产品不能正常工作，请将其送至AWEI的授权维修机
构，工作人员会热心帮您解决问题。
安全与保养
★保持产品干燥，勿将产品放在潮湿的地方，以免影响
产品内部电路；
★不要将产品放置在太阳晒射或者高温的地方，高温会
缩短电子部件的使用寿命损坏电池，使某些塑料部件
变形；
★ 不要将产品放在过冷的地方，以免损坏内部电路板
★不要试图拆开产品，尤其是非专业人员，可能会损坏
产品；
★不要跌落、强烈震动、用硬体撞击产品，以免损坏内
部电路；
★ 不要使用烈性化学制品、清洁剂清洁机器；
★不要用尖体在产品表面上乱划，以免损坏外壳和影响
外观；
★ 不要对机器连续充电超过10小时，以免影响使用寿命；
7
一、七天包退细则
A.包退原则：用户在AWEI直属专营店或经AWEI授权的分销
店所购买的产品，自购买之日起7天内，产品未受到任
何人为或外力的损害而发生的产品质量问题，厂家包
退货。
B.退货流程：用户将产品、包装和票据完整地拿到（或自
费邮寄到）购买地点给卖家检测——卖家按质保鉴定
规则检测，鉴定该产品实属产品质量问题——卖家退
还用户购买产品时所付的费用。
二、十五天包换细则
A.包换原则：用户在AWEI直属专营店或经AWEI授权的分销
店所购买的产品，自购买之日起15天内，产品未受到
任何人为或外力的损害而发生的产品质量问题，厂家
包换货。
B.换货流程：用户将产品、包装和票据完整地拿到（或自
费邮寄到）购买地点给卖家检测——卖家按质保鉴定
规则检测，鉴定该产品实有产品质量问题——卖家为
用户更换货品并开具新票据。
产品售后服务指南
9
@2017年保留AWEI所有权，其LOGO “AWEI”“AWEI 用维
”“AIVEI”“AWEI”属深圳市雅乐电子有限公司在中国
及其他国家和地区注册的商标，仿冒必究！
产品执行标准：Q/YL 001-2015
香港雅乐国际有限公司 监制
深圳市雅乐电子有限公司 出品
厂址：中国深圳市龙华新区大浪裕景泰科技工业园
消费者服务热线/传真：
电话：+86-755-82999998
传真：+86-755-83777998
合作邮箱：yale@awei.hk
售后服务 : service@awei.hk
获取更多信息请访问:
www.awei.hk
国外社区:
twitter : https://www.twitter.com/aweiearphone
facebook : https://www.facebook.com/aweiproducts
instagram : http://www.instagram.com/aweiearphone
8
AWEI
三、十二个月包修细则
A.包修原则：用户在AWEI直属专营店或经AWEI授权的
AWEI用维产品保修卡（请认真填写完整）产品售后服务指南
10
分销店所购买的产品，自购买之日起十二个月内，产
品未受到任何人为或外力的损害而发生的产品质量问
题，厂家包修。
B.包修流程：用户将产品、包装和票据完整地拿到（或自
费邮寄到）购买地点给卖家检测——卖家按质保鉴定
规则检测，鉴定该产品有产品质量问题——卖家填写
产品质保卡并盖公章——卖家将产品邮寄给厂家维修
—
四、质保鉴定规则
A.无质保产品：包装盒、收纳袋、耳机夹、耳套等附属部
件；不在三包期内的产品；非AWEI授权或非正规渠道
所购买的产品；非AWEI正品；赠品；被人为损害的产
品；被外力损害的产品。
B.质保鉴定：查三包期（以票据为证）——查正品（进
AWEI官方网站查防伪编码）——查产品损坏情况（有
无明显人为造成的破损、有无被水、火、化学物品或
重物损害的痕迹）——查产品质量（在符合产品使用
的情况下测试效果是否与产品描述相符）——查购买
渠道（限厂家查证)。
产品型号 条形码
用户名字 用户电话
用户住址
商家名称 商家电话
商家地址
购买日期 报修日期
损坏情况 维修时间
备注
Please read suggestions below in order to helping prolong
the product lifespan and clearly understand the warranty
clauses.
★Keep the product dry, do not put it in humid circumstance
to avoid short circuit.
★Do not expose it to the sun or high heat. High heating will
short lifespan of electronic components, damage battery
and deform some plastic parts.
★Do not put it in cold circumstance to avoid damage to
PCB board.
★Do not attempt to take apart the product, especially
non-professionals.
★Do not fall, vibrate strongly,strike with hard objects, to
avoid damage to inner electronic circuit.
★Do not use high chemical products,detergent to clean the
item.
★Do not scratch the surface with sharp items to avert
damaging the case and appearance.
★Do not make it charging 10 hours continuously for the
sake of lifespan.
7
If the product can not work properly, please send it to
AWEI authorized maintenance agents. Our staff will help
to solve the problems for you.
Statement: In order to improve product performance
we will upgrade products, the content may change
without notice,pls forgive! Thank you for your
purchase.
Safety And Maintenance
8
@2017 AWEI Electronics All rights reserved by AWEI.The
trademark of Shenzhen Yale Electronics Co.,Ltd
registered in China and other countries,Counterfeit will
investigate!
Product Execution Standard: Q/YL 001-2015
Supervised by H.K. Yale International Co., ltd
Produced by Shenzhen Yale Electronics Co., ltd
Factory Add: 4th Floor, Buidling 2, Yujingtai Industrial Park,
Huaxing Road,Longhua New district,shenzhen, China.
Customer service hotline/ Fax:
Tel：+86-755-82999998
Fax：+86-755-83777998
Cooperation mailbox：yale@awei.hk
After-sales service：service@awei.hk
For more information please visit:
www.awei.hk
Contact:
twitter : https://www.twitter.com/aweiearphone
facebook : https://www.facebook.com/aweiproducts
instagram : http://www.instagram.com/aweiearphone
AWEI
AWEI Warranty Card (please fill this carefully)
Model No. Barcode
User Name TEL
Address
Seller Seller Tel
Seller Add
Date of
purchase
Date for
Maintenance
Damage
situation
Maintenance
time
Remark
9
A. Guarantee of Refund: Within 7 days since the date of
purchase, the manufacturer promises to refund if the
product bought from AWEI immediate store or
authorized distributor shops is in quality problem
(artifical and external force damage excluded).
B. Refund Procedure: Please take the product, whole set of
package and original invoice to (or please freight
pre-paid to) the shop you bought the product for
checking. The seller will check by Quality
AssuranceIdentification Rules to clarify the problem. If
yes, the seller should refund the money the user paid for
the product.
1. 7 Days Refund Policy
A. Guarantee of Replacement: Within 15 days since the
date of purchase, the manufacturer promises to replace
if the product bought from AWEI immediate store or
authorized distributor shops is in quality problem
(artifical and external force damage excluded).
B. Replacement Procedure: Please take the product, whole
set of package and original invoice to (or please freight
pre-paid to) the shop you bought the product for
checking. The seller will check by Quality Assurance
Identification Rules to clarify the problem. If yes, the
seller should replace the product and issue a new
invoice to the user. Freight arrangements please check
with the shop you contact.
2. 15 Days Replacement Policy
Products after-sales service Products after-sales service
10
A. Quality Assurance is NOT applicable to those items:
accessories like packing box, pouch, ear clip and
earmuffs; product beyond warranty period; product got
from unauthorized agents or informal channels; fake
AWEI product; AWEI premium; arificial damaged
product; external force damaged product.
B. Quality Assurance Identification Procedure: Check
warranty period (by original invoice) —— confirm
original product (check security code on AWEI offical
website) —— check product damage (clarity artifical
damage and external force like water, fire, chemicals or
weight crush damages) —— check product quality ( to
confirm if the testing result is conform to description)
——check buying channel (subject to manufacturer’s
verification).
4. Quality Assurance Identification Rules
A. Guarantee of Maintenance: Within twelve months since
the date of purchase, the manufacturer promises to offer
maintenance service if the product bought from AWEI
immediate store or authorized distributor shops is in
quality problem (artifical and external force damage
excluded).
B. Maintenance Procedure: Please take the product, whole
set of package and original invoice to (or please freight
pre-paid to) the shop you bought the product for
checking. The seller will check by Quality Assurance
Identification Rules to clarify the problem. If yes, the
seller should fill warranty card with offical stamp and
send back to manufacturer. After repairing,
manufacturer sends the product to the seller and the
seller should inform the user to collect it. Freight
arrangements please check with the shop you contact.
3. Twelve-Month Warranty Policy
官方微信查真伪
AWEI WeChat
蓝牙耳机使用方法
4
电源开关
开机：关机状态下,磁控拉开，并伴有“开机”提示音
。
关机：磁控对碰, 红灯长亮1秒, 并伴有“关机 ”提示
音。
(备注：开机后，5分钟未连接设备，自动关机）。
普通配对步骤如下：
1. 关机状态下,磁控拉开，红蓝灯交替闪烁, 并伴
有提示音。进入配对状态。
2. 开启手机蓝牙功能。
3. 搜索蓝牙设备。
4. 选择“AWEI AK-MUSIC”耳机。（如需输入密码
，请输入“0000”）。
5. 配对成功后，伴有提示音，蓝灯慢闪。
6. 在连接的状态下，磁控对碰，自动断开，磁控
拉开，自动回连。
配對
通话
接听/挂断电话：短按多功能键接通/挂断当前电话。
拒接来电：长按多功能键2秒。
重拔电话：双击多功能键。
通话切换：通话时，短按多功能键挂断当前电话，接通
等待的电话。双击多功能键，接听第二个来电，以及两个
通话之间切换。短按多功能键，可以逐一挂断电话。
产品特征
• IPX4级防水
• 防汗防溅功能
• CVC智能降噪
• 音乐播放时间约10小时
• 通话时间约12小时
• 手机电量显示
• 智能一拖二
在配对模式的状态下（红蓝灯交替闪烁），双击“V+”
键即可完成语音切换（中英韩文互换）。
语音提示切换
关机：磁控对碰
开机：磁控拉开
开机配对模式：红蓝灯交替闪烁
来电接听电话：单击多功能键
来电拒接电话：长按多功能键2秒
挂电话：单击多功能键
音量加：单击V+
音量减：单击V-
下一首：长按V+键
上一首：长按V-键
按键定义
1.按配对步骤，配对第一部手机后，将手机蓝牙功能关
闭，再配对第二部蓝牙手机。
2.打开第一部手机的蓝牙功能，手动连接第一部手机。
双手机连接
Shutdown state, the magnetic pull,accompanied by a
"Power on" prompt.
Magnetic touch,red light for 1 second,accompanied by a
"Power off" prompt.
(Remarks: After power on, the device is not connected
until 5 minutes and it'll power off automatically.)
Power On/Off
Normal pairing steps as following:
1.Shutdown state, the magnetic pull, until the red and
blue LED light alternately flashing with the prompt
tone and then product will enter into matching state.
2. Open Bluetooth function on the phone
3. Search Bluetooth Devices
4. Choose “AWEI AK-MUSIC” (If require password,
please input “0000”)
5.Blue LED light will flash slowly with prompt tone , if
product is paired successfully.
6.In the connected state, it is disconnceted automaticly
while join the earbuds, it is re-connected automationly
while separate the earbuds.
Pairing
1.According to the pairing steps to connect the first
mobile phone and turn off the Bluetooth function on the
phone to pair the second mobile phone.
2.Open Bluetooth function on first mobile phone,then
manually connect to the first mobile phone.
Pairing two mobile phones
Answer / end a call: short press the MFB to connect or
hang up the current phone.
Reject a call:Long press the MFB for 2 seconds.
Redial a call: Double click the MFB .
Switching a Call: Short press the MFB to hang up the
current phone and answer the waited call when you are
calling. Double click on the MFB to answer second call, and
switch between two calls. Short press the MFB, you can
end the phone one by one.
Call
In the state of pairing mode( When red and blue lights
alternately flashing), double click the "V+" button, then you
could swtich the voice language between English Chinese
and korea.
Voice prompt switch
Power off: Magnetic touch
Power on: Magnetic pull
Pairing Mode: Red and blue LED light alternately flashing
Answer incoming call: click the MFB
Reject incoming call: Long press the MFB for 2 seconds
Hang up the phone: Click the MFB
Volume up: Click V+
Volume down: Click V-
Next track: long press V+ button
Previous track: long press V- button
Button Definition
• Waterproof IPX4
• Sweat and Splash Proof
• CVC Intelligent Noise Reduction
• Music Play time about 10h
• Call time about 12h
• Mobile Phone Battery Display
• Support Multi-Point Connection
Product Features
蓝牙耳机支持的协议与描述
支持协议
HSP（耳机）
HFP（免提）
A2DP（高级音频分发）
AVRCP（音/视频远程控制）
相关描述
耳机模式
用于单声道语音通话
电话通话管理
与拔打/接听电话相关的操作
支持立体声音乐播放
远程音乐控制（远程暂停/播放、
上一首/下一首、音量加/减）
音量+/下一首
多功能按键
USB充电接口音量-/上一首
Bluetooth earphone protocol and description
Protocol
HSP (Earphone)
HFP (Hands-free)
A2DP
(Senior frequency dispense)
AVRCP
(Audio/Video long-distance control)
Description
Earphone mode
for mono voice call
Phone call related controls
Support stereo music playing
Control music by long-distance
A
B
A
B
EN
CN
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
