Cockpit EQUIPMENT Crouzet Aerospace Catalog

2016-06-16

: Crouzet Crouzet-Aerospace Catalog Cockpit Crouzet-Aerospace_Catalog_Cockpit library crouzet-aerospace

Open the PDF directly: View PDF PDF.
Page Count: 18

WWW.CROUZET-AEROSPACE.COM
COCKPIT EQUIPMENT
› Pushbuttons
› Grips
› Control Wheels
THE DETAIL
THAT MAKES THE DIFFERENCE
|WWW.CROUZET-AEROSPACE.COM | 2 |COCKPIT EQUIPMENT
InnoVista Sensors™: your trusted
partner of choice to face industrial
challenges of today and tomorrow.
InnoVista Sensors™ is a worldwide
industrial specialist of sensors,
controllers and actuators for automated
systems.
Through its brands, Crouzet Aerospace,
Crouzet Automation, Crouzet Control,
Crouzet Motors, Crouzet Switches and
Systron Donner Inertial,
InnoVista Sensors™ offers a wide range
of reliable, efcient and customizable
components dedicated to the Aerospace
& Defence, Transportation and Industrial
market and segments.
Thanks to the recognized expertise of
its teams and a strong innovation policy,
InnoVista Sensors™ brings performance
enhancing solutions to its customers
worldwide.
www.innovistasensors.com
For
Aerospace
& Defense
Transportation Industry
With commercial brands
Designs & Manufactures
ABOUT
CROUZET AEROSPACE
Crouzet Aerospace has been producing High
Performance Aerospace components for over
fty years and has secured a leading role in three
Product lines dedicated to aerospace applications:
›› Detection and Sensing: Limit switches, Proximity
switches and sensors
›› Electrical Protection and Distribution: Circuit
Breakers & Circuit Breaker Panels, Solid State
Power Controllers
›› Cockpit Equipment: Control Wheels, Helicopter
Grips, Pushbuttons.
Today Crouzet Aerospace’s components can be
found on most major xed wing programs around the
world.To ensure the necessary quality, all Crouzet
Aerospace High Performance components are
manufactured in Valence, France, and Casablanca,
Morocco and are fully certied to EN 9100,
ISO 9001, ISO 14001, EASA part 21/G and part 145.
With more than 50 years of
presence in the aerospace market,
Crouzet Aerospace is a specialist
providing customized solutions for
electromechanical switches, inductive
sensors, electrical protection and
cockpit equipment backed up by a
loyal and experienced team of experts
available worldwide.
Crouzet Aerospace is a brand of
InnoVista Sensors™.
|WWW.CROUZET-AEROSPACE.COM | 3 |COCKPIT EQUIPMENT
PROGRAMS
› We have the internal expertise to ensure
manufacturing engineering goes smoothly
› We use up-to-date logistic tools such as IDE to
provide quality service
› Our quality is of the highest level: ISO 9001,
ISO 14001, OHSAS 18001, AS/JIS Q/ EN 9100,
NADCAP Welding, FAA approved
(FAR 21 & FAR 145)
› Our production organisation is EASA
part 21 approved
› Our after-market services, EASA part 145
approved, include a specic customer support
department, distributors all around the world,
and an AOG service
› NATO code: FA0X2
QUALITY OF SERVICE THROUGHOUT THE LIFE OF THE PROGRAM
AIRBUS, BOEING, AGUSTA-WESTLAND, ANTONOV, BELL, BOMBARDIER, DASSAULT,
EMBRAER, AIRBUS HELICOPTERS, GULFSTREAM, HAL, IAI, MIL HELICOPTER, NH
INDUSTRIE, PILATUS, SOCATA, SUKHOI, MESSIER BUGATTI DOWTY, UTAS, AIRCELLE,
LIEBHERR, WOODWARD, NORDAM...
OUR REPUTATIONIS RECOGNIZED GLOBALLY BYTHE MAJOR PLAYERSIN THE
AEROSPACE MARKET.A NON-EXHAUSTIVE LIST OF CUSTOMERS INCLUDES:
|WWW.CROUZET-AEROSPACE.COM | 4 |COCKPIT EQUIPMENT
1. INNOVATION
Based on their experience in a wide range of sectors,
Crouzet Aerospace's design ofces share common objectives:
› Taking an innovative approach to market standards and the
best technologies
› Combining a number of technologies to create innovative
concepts.
2. PROJECT START-UP
After rst contact, Crouzet Aerospace business engineers will
work with you to identify your goals and constraints in order
to draw up a product performance specication and to take in
account the key factors of success for your projects.
SOLUTIONS FOR DESIGN,
INNOVATION AND
INDUSTRIALISATION
PROJECT TEAM
Crouzet Aerospace puts in place a project team
that provides you with a partnership of experts
throughout all your program phases: drawing up the
specication, feasibility, development, performance
testing, control of pre-production, optimisation of
logistical parameters, long-term support for the
design and product tracking.
Crouzet Aerospace’s factories in Valence, France
|WWW.CROUZET-AEROSPACE.COM | 5 |COCKPIT EQUIPMENT
3. DESIGN OFFICE
With more than 50 years of experience, Crouzet Aerospace has mastered
the necessary technologies for developing and industrialising complete
sensor offer as well as to customise products:
›Mechanical (CAD-3D)
›Magnetic
›Electromechanical
›Electronic (EMC, EMI)
5. PRODUCTION
Aerospace products require highly-tailored solutions for
demanding applications. Crouzet Aerospace state-of-the-art
production facilities are certied to the highest quality standards
to ensure that Crouzet Aerospace products meet the level of
performance that is needed for critical environments.
6. LOGISTICS
In order to meet the demands of the aerospace industry, Crouzet Aerospace
logistics are based on industry approved practices:
›Just-in-time processes
›Partnerships with our suppliers
›Capacity to deliver within 24 hours
The Crouzet Aerospace delivery platform also optimizes logistics
through
output and guarantees your lead times.
4. TEST LABORATORY
Crouzet Aerospace laboratories are equipped with facilities
for testing all our products from design to production. Either
with simulation or real-life tests (electrical, mechanical life
and environmental withstand), Crouzet Aerospace products
are validated, tested and tracked throughout the project
development process.
|WWW.CROUZET-AEROSPACE.COM | 6 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 7 |COCKPIT EQUIPMENT
For over 50 years, Crouzet Aerospace
has been providing technically-advanced
custom grips for major programs
worldwide with best in class quality and
logistical excellence.
The performance speaks for itself and
has resulted in both a solid commercial
relationship and a mutual understanding
with our global customer base.
Our man machine interfaces for both
Commercial and Military aerospace markets
have been designed, manufactured & delivered
for more than four decades. Crouzet Aerospace
wide range of grip designs enables us to provide
quick and accurate responses to any customer’s
needs or requirements.
2
1
3
1- HAL collective
2- Leonardo Helicopters
3- HAL cyclic
4- Airbus Helicopters
4
GRIPS
WORLD LEADER
STRENGTHS
› Crouzet Aerospace dened the modular
concept for helicopter grips. This heritage
enables Crouzet Aerospace to meet 100%
of a customer’s needs relative to ergonomy.
Modications to pushbutton congurations
can be performed quickly thanks to our
exclusively-incorporated removable front face,
with optional backlighting.
› This unique design approach not only gives
Crouzet Aerospace customers increased
exibility, but it greatly reduces the
customisation lead-time. Production can
continue and minor changes are easily
accomidated at nal assembly.
› Customisation
Front face by day Front face by night
Example: illuminated front panel
|WWW.CROUZET-AEROSPACE.COM | 9 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 8 |COCKPIT EQUIPMENT
CONTROL WHEELS
WORLD EXPERT
For over 50 years, Crouzet Aerospace has been providing technically-advanced
custom yokes for major programs worldwide with best in class quality and logistical
excellence.
The performance speaks for itself and has resulted in both a solid commercial
relationship and a mutual understanding of critical customer needs.
1
2
3
4
STRENGTHS
› Crouzet Aerospace's signicant experience
has been developed over many decades. We
pride ourselves in being able to assist Aircraft
manufacturer in specication nalization, thus
avoiding costly mistakes.
› Crouzet Aerospace world class, highly
experienced Management, Engineering
and Quality teams stand ready to offer their
competence and are available to support your
program needs immediately.
› The success of your program can be
accomplished with Crouzet Aerospace fully
integrated test facilities.
› Crouzet Aerospace's design approach is
fully tested and certied: both the wheels
and components are already ying in aircraft
worldwide.
› Yokes and components are low cost leaders
in terms of maintenance and operational
expenses.
› Crouzet Aerospace has a worldwide spare part
distribution network capable of supporting the
Aircraft manufacturer and their customers.
1- Socata
2- Antonov
3- Embraer
4- Gulfstream
5- Bombardier
5
BECAUSE THE FIRST FEELING
OF THE COCKPIT IS THE
CONTROL WHEEL
The quality of the man machine interface
in an Aircraft cockpit is a major concern
to the Aircraft designer and the operator
alike. The comfort and aesthetics of
Crouzet Aerospace handwheels are
of great importance to Crouzet Aerospace.
|WWW.CROUZET-AEROSPACE.COM | 10 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 11 |COCKPIT EQUIPMENT
www.crouzet.com
PUSHBUTTONS & ACCESSORIES
MORE THAN 200 ELECTRICAL
COMBINATIONS
By manufacturing its own switches, Crouzet Aerospace offers its customers all the
benets of vertical integration: cost control, short lead times, and proven dependable
quality.
The available range of pushbuttons and accessories makes it possible to provide
solutions for all necessary requirements.
Extensive research at Crouzet Aerospace has
resulted in industrialized and manufactured
control grips, pushbuttons (one pole, two
pole, 2, 3, 4 and 5 ways trim, trigger, joysticks,
transducer) and many other accessories.
Additionally, Crouzet Aerospace is able to design
dedicated functions for any customer application.
1 2
3
QuickFix®
Innovative
pushbutton
fastening solution
CUSTOMIZED DESIGN
› Choose from over 200
references, or let us help you
design your custom component.
STRENGTHS
›Tactile effect
›Simple integration
› Calculator designed
› Variety of shapes
› Wide range of colours
›Customized design
|WWW.CROUZET-AEROSPACE.COM | 12 |COCKPIT EQUIPMENT
PUSHBUTTONS 1 pole 2 pole 3 pole 4 pole
Ø12 Ø14 Ø14
Waterproof
front face
Y/N Y/N N N
Function
NO, NC or NO/NC
2 x NO/NC 3 x NO/NC 4 x NO/NC
Button Ø4, Ø5, Ø7, Ø9.4
short or round or
rectangular
Ø5, Ø9.4 or
rectangular
Ø9 Ø8
Color Black/Red/Grey/
White/Blue
Black/Red/Grey/
White/Blue
Black Red
Terminal Silver or Gold Silver or Gold Gold Gold
Accessories Monostable ap
Bistable ap
Bistable ap with
auxiliary contact
Electroluminescent
ring
Monostable ap
Bistable ap
Bistable ap with
auxiliary contact
Electroluminescent
ring
Monostable ap
Bistable ap
Bistable ap
with auxiliary
contact
Monostable ap
Bistable ap
Bistable ap
with auxiliary
contact
MULTIWAY
2-way 2-way +
validation
4-way 4-way
double pole
4-way +
validation
Ø16 Ø18 Ø24 Ø16 Ø24 Ø24
Waterproof front face Y/N N YY/N Y Y
Function NO NO NO NO NO NO, NO/NC
Button Rectangular,
Concave, Convex
Convex Cone, Concave,
Convex, Castle
Concave, Cone,
Convex, Long bat,
Medium bat, short
bat
Cone Cone, Concave,
Chinese, Castle
Color Black Black Black Black Black/Grey Black
Terminal Silver or Gold Silver or Gold Silver or Gold
Silver, Gold or Tined
Silver Silver or Gold
TRIGGER 1 position 2 positions
Waterproof front face Y/N Y/N
Function NO, NC or NO/NC 2 x NO/NC or 4 x NO/NC
Color Red/Black/Grey Red/Black/Grey
Terminal Silver or Gold Silver or Gold
THUMBSTICK
Analogic
Analogic +
validation
Ø14 Ø24
Waterproof
front face
Y Y
Function 0 15 V 0 15 V
Button Convex Convex
Color Black Black
Terminal Solder Solder
PANORAMIC RANGE
|WWW.CROUZET-AEROSPACE.COM | 13 |COCKPIT EQUIPMENT
www.crouzet.com
BUTTON PROTECTION
Circular Metallic ap guard Plastic ap guard Plastic ap guard
with auxiliary contacts
TRIM SWITCH 2-way 2-way + validation 4-way + validation
Ø24 Customized Ø24 Ø24
Waterproof front face N N N
Function 2 x NO/NC + 2 x NO/NC 2 x NO + NO 4 x NO + NO
Button Chinese Pyramidal Round Round
Color Black Black Black
Terminal Gold Silver Silver
ROCKER 3 positions 3 positions 5 positions
Waterproof front face NNN
Function 1x NO/NC + 1x NO/NC 2x NO/NC + 2x NO/NC 1x NO/NC + 1x NO/NC
+ 1x NO/NC + 1x NO/NC
Button Rectangular Gendarme Rectangular
Color Black Black Black
Terminal Silver Silver Silver
TOGGLE (CONSULT US) 2 positions 3 positions
Ø6 Ø12 Ø6 Ø12
Waterproof front face NNNN
Function 1x NO + 1x NC 2 x NO + 2 x NC 2 x NO + 2 x NC 2 x NO + 2 x NC
Color Black/Chrome Black/Chrome Chrome Black/Chrome
Terminal Silver Gold Silver Silver or Gold
Accessories Grey cap
|WWW.CROUZET-AEROSPACE.COM | 14 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 15 |COCKPIT EQUIPMENT
QuickFix®
◆
◆
◆
◆
◆
83450301
◆
◆
◆
Ø 7 + bayonet
83450738
◆
◆
◆
◆
◆
◆
◆
◆
Ø 7 + bezel
83450712
83450717
83450718
83450720
83450728
◆
83450719
83450711
83450723
83450722
83450721
◆
Ø 7
83450701
83450702
83450704
83450703
83450713
83450716
83450715
83450732
83450708
83450707
83450729
Ø 4
◆
83450714
◆
◆
◆
83450724
◆
◆
◆
Electrical
conguration
NO
NO/NC
NO
NO/NC
NO
NO/NC
NO/NC
NO/NC
NO/NC
Color
black
red
grey
black
red
grey
blue
No seal
Front face seal
1 pole
Double-throw
Ø 12
1 pole
No seal Front face seal
Mechanical characteristics
Operating force 8 N 16 N max 8 N 16 N max
Release force 3 N min 3 N min
Permissible force at end of travel 100 N 100 N
Overtravel 0.4 mm min 0.4 mm min
Total travel 2 mm ± 0.4 2 mm ± 0.4
Return overtravel 0.4 min 0.4 min
Mechanical life 300 000 cycles 100 000 cycles
Electrical characteristics
Voltage 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz
Current (resistive load) 0.1 mA to 7.5 A 0.1 mA to 7.5 A
Current (inductive load) 2 A 2 A
Contact resistance 25 mOhm 25 mOhm
Electrical life 100 000 cycles 100 000 cycles
Dielectric strength 1 200 V 1 200 V
General characteristics
Case polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass
Button acetate resin acetate resin
Terminal Soldering lugs W2 silver or gold plated Soldering lugs W2 silver or gold plated
Waterproof front face - MIL STD 810 D-506.2 methode 2
Operating temperature -55°C +85°C -55°C +85°C
Storage temperature -55°C +85°C -55°C +85°C
Weight
3.6g ±5% < M < 7.6g ±5% 3.6g ±5% < M < 7.6g ±5%
QuickFix®
83450401
83450402
83450403
83450404
◆
◆
◆
◆
◆
◆
concave
83450506
◆
◆
◆
83450513
◆
◆
◆
Ø 9.4 long
travel
83451001
◆
◆
◆
83451003
83451004
◆
◆
◆
Ø 9.4 1/4
turn xation
(or bayonet)
83450019
83450026
83450030
83450035
83450032
83450029
◆
◆
◆
◆
◆
◆
Ø 9.4
round
83450025
◆
◆
◆
83450013
◆
◆
◆
Ø 9.4
short hat
+ guard
83450014
◆
◆
◆
◆
◆
83450009
83450018
◆
Ø 9.4
short hat
◆
83450008
83450017
◆
83450012
83450011
83450010
83450036
Ø 9.4
83450001
83450002
◆
◆
83450006
83450028
83450007
83450005
83450015
83450016
Ø 5 +
guard
◆
83450511
◆
◆
◆
◆
◆
◆
Ø 5
83450501
83450502
◆
◆
83450512
83450510
83450509
83450514
Electrical
conguration
NO/NC
NO/NC
NO/NC
NO/NC
NO/NC
NO/NC
NO/NC
NO/NC
Color
black
red
grey
white
black
red
grey
blue
No
seal
Front
face
seal
1 pole
Double-
throw
Ø 14
Low level - Gold plated
Low level - Gold plated
Ø12
NO
18
16
14
0.25
16.5 0
-0.05
Ø14 Ø14 QuickFix®
1
3
2
4
NO/NC
Electrical diagram
Dimensions
◆ CONTACT US FOR ANY MISSING REFERENCE ◆ CONTACT US FOR ANY MISSING REFERENCE
PUSHBUTTONS
1 POLE
|WWW.CROUZET-AEROSPACE.COM | 16 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 17 |COCKPIT EQUIPMENT
2 pole 3 pole 4 pole
No seal Front face seal No seal No seal
Mechanical characteristics
Operating force 8 N 16 N max 8 N 16 N max 6.7 N max 1 N max
Release force 3 N min 3 N min 3 N min 1.1 N min
Permissible force at end of travel 100 N 100 N 100 N 100 N
Overtravel 0.4 mm min 0.4 mm min - -
Total travel 2 mm ± 0.4 2 mm ± 0.4 - -
Return overtravel 0.4 mm min 0.4 mm min - -
Mechanical life 300 000 cycles 100 000 cycles 600 000 cycles 100 000 cycles
Electrical characteristics
Voltage 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz 14 VDC to 28 VDC 14 VDC to 28 VDC
Current (resistive load) 0.1 mA to 7.5 A 0.1 mA to 7.5 A 3 mA to 5 A 1 mA to 1 A
Current (inductive load) 2 A 2 A 3 A 2 A
Contact resistance 25 mOhm 25 mOhm 25 mOhm 25 mOhm
Electrical life 100 000 cycles 100 000 cycles 50 000 cycles 100 000 cycles
Dielectric strength 1 200 V 1 200 V 1 200 V 1 200 V
General characteristics
Case
polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass
diallyl diallyl
Button acetate resin acetate resin acetate resin acetate resin
Terminal Soldering lugs W2 silver or gold plated Soldering lugs W2 silver or gold plated Soldering terminal brass, gold plated Soldering terminal brass, gold plated
Waterproof front face - MIL STD 810 D-506.2 methode 2 - -
Operating temperature -55°C +85°C -55°C +85°C -40°C +70°C -40°C +70°C
Storage temperature -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C
Weight
3.6g ±5% < M < 7.7g ±5% 3.6g ±5% < M < 7.7g ±5%
20g 20g
QuickFix®
◆
◆
◆
◆
◆
83453311
83453310
◆
◆
◆
rectangular
high
strength
83453506
◆
◆
◆
◆
◆
◆
◆
rectangular
◆
◆
◆
◆
83453514
◆
◆
◆
◆
◆
Ø 12
concave
◆
◆
◆
◆
83453014
◆
◆
◆
Ø 9.4 long
travel
83453026
◆
◆
◆
◆
◆
◆
◆
Ø 9.4 1/4
turn xation
(or bayonet)
◆
◆
◆
◆
◆
83453035
◆
83453030
◆
83460117
Ø 9.4 +wires
◆
83453019
◆
◆
◆
◆
◆
◆
◆
◆
Ø 9.4 screw
xation
◆
83453040
◆
◆
◆
◆
◆
◆
Ø 9.4
luminescent
ring
◆
◆
◆
◆
◆
83453027
◆
◆
◆
◆
Ø 9.4 round
◆
◆
◆
◆
83453031
83453034
83453021
◆
◆
◆
◆
Ø 9.4 short
hat+guard
+ higher
strength
◆
◆
◆
◆
83453029
83453023
◆
◆
Ø 9.4 short
hat+guard
83453006
◆
◆
◆
83453017
83453045
83453011
83453009
◆
Ø 9.4 short
hat+ higher
strength
◆
◆
◆
◆
◆
83453024
◆
◆
Ø 9.4
short hat
83453005
83453015
83453025
◆
83453013
83453032
83453033
◆
◆
◆
◆
Ø 9.4
higher
strength
◆
◆
◆
◆
83453039
83453022
◆
◆
Ø 9.4
83453001
83453002
83453028
◆
83453018
83453012
83453020
83453010
83453036
83453008
◆
83460115
◆
Ø 8
◆
◆
◆
◆
◆
◆
◆
◆
◆
◆
Ø 5 high
strength
◆
◆
◆
◆
83453510
◆
◆
◆
Ø 5 +guard
◆
◆
◆
◆
◆
83453509
83453518
83453512
◆
◆
Ø 5
83453501
83453502
83453516
◆
83453511
83453517
83453508
83453507
◆
Electrical
Conguration
2 x NO/NC
2 x NO/NC
2 x NO/NC
2 x NO/NC
2 x NO/NC
2 x NO/NC
2 x NO/NC
2 x NO/NC
3 x NO/NC
4 x NO/NC
Color
black
red
white
grey
black
red
grey
blue
black
red
No
seal
Front
face
seal
No
seal
2 pole
Double-
throw
3 pole
4 pole
Ø 14
3 pole 4 pole
1
3
5
7
2
4
6
8
NO/NC 2 pole
Switch 1
Switch 1
Switch 2
Switch 3
Switch 2
Switch 3
Switch 4
1
2
P0
P1
4
3
1
2
4
3
1
2
4
3
NO/NC 3 pole
1
2
P0
P1
4
3
1
2
4
3
1
2
4
3
1
2
4
3
NO/NC 4 pole
Dimensions
Electrical diagram
2 pole Ø14
◆ CONTACT US FOR ANY MISSING REFERENCE
PUSHBUTTONS
2, 3 & 4 POLE
18
16
14
0.25
16.5 0
-0.05
Ø14 QuickFix®
Low level - Gold plated
|WWW.CROUZET-AEROSPACE.COM | 18 |COCKPIT EQUIPMENT |WWW.CROUZET-AEROSPACE.COM | 19 |COCKPIT EQUIPMENT
2D 3D 4D 4D 5D
1 pole Ø 16 1 pole Ø 24 1 pole Ø 16 2 pole Ø 24 1 pole Ø 24
non waterproof
waterproof front face
waterproof front face non waterproof waterproof front face waterproof front face waterproof front face
Mechanical characteristics
Operating force 3.5 N 3 N 3.5 N 6 N 3 N
Release force 0.6 N 0.6 N 0.6 N 1 N 0.6 N
Permissible force at end of travel 70 N max 70 N max 70 N max 70 N max 70 N max
Button strengthness pulling action 25 N max 25 N max 25 N max 80 N max 25 N max
Button strengthness pushing action 100 N max 100 N max 100 N max 100 N max 100 N max
Angle measured from axis to full travel
12° 12° 12° 12° 12°
Mechanical life
100 000 up to 500 000 cycles 100 000 cycles 100 000 up to 500 000 cycles 100 000 cycles 100 000 cycles
Electrical characteristics
Output common Separate or common Separate Separate or common Separate Separate
Voltage 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz 5 VCC to 115 VAC 400 Hz
Current (resistive load) 0.5 mA to 2 A 0.5 mA to 2 A 0.5 mA to 2 A 0.5 mA to 2 A 0.5 mA to 2 A
Current (Inductive load) 1 A 1 A 1 A 1 A 1 A
Contact resistance 25 mOhm 25 mOhm 25 mOhm 25 mOhm 25 mOhm
Contact silver or gold plated silver or gold plated silver or gold plated silver or gold plated silver or gold plated
Electrical life 100 000 cycles 100 000 cycles 100 000 cycles 100 000 cycles 100 000 cycles
Dielectric strength 1 200 V 1 200 V 1 200 V 1 200 V 1 200 V
General characteristics
Case polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass polyamid 6.6 reinforced with 30% berglass
Button acetate resin acetate resin acetate resin acetate resin acetate resin
Terminal Solder lugs W2 silver Solder lugs W2 silver Solder lugs W2 silver Solder lugs W2 silver Solder lugs W2 silver
Waterproof front face MIL STD 810 D-506.2 methode 2 MIL STD 810 D-506.2 methode 2 MIL STD 810 D-506.2 methode 2 MIL STD 810 D-506.2 methode 2 MIL STD 810 D-506.2 methode 2
Fixation screw, glue screw, glue screw, glue screw, glue screw, glue
Operating temperature -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C
Storage temperature -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C
Weight 7.3g ±5% < M <15.7g ±5% 16g 7.3g ±5% < M <15.7g ±5% 13g 16g
Color
Electrical
Conguration
Chinese Chinese small Chinese large Rocker Convex streak Convex cross Concave Castle Bat Square Convex + insert QuickFix®
2D 1 pole Ø 16
non
waterproof black NO ◆◆◆83452504 83452515 ◆ ◆◆◆◆83452531 ◆
waterproof
front face
black NO ◆◆◆83452518 83452519 ◆ ◆◆◆◆◆◆
grey NO 83452510 ◆
3D 1 pole Ø 24 waterproof
front face black NO 83452709 ◆◆◆83452721
83452722 ◆83452718 ◆◆◆◆◆
4D 1 pole Ø 16
non
waterproof black NO
83452501
83452502
83452506
83452533
◆◆◆◆83452538 83452505
83452514 ◆ ◆ 83452520 ◆ ◆
waterproof
front face
black NO
83452516
83452521
83452524
83452525
83452529
83452534
83452572
83452570 83452576 ◆◆◆
83452523
83452526
83452530
83452543
83452575
◆
83452535
83452540
83452578
83452527
83452539 ◆83452301
blue NO ◆◆◆◆◆◆83452542 ◆◆◆◆◆
grey NO ◆◆◆◆◆◆83452511 ◆◆◆◆◆
4D 2 pole Ø 24 waterproof
front face
black NO 83452513 ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ 83452528 ◆ ◆
grey NO 83452509 ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
5D 1 pole Ø 24 waterproof
front face black
NO 83452701
83452706 ◆◆◆◆◆83452711
83452719
83452708
◆◆ ◆ ◆ ◆
NO/NC
83452702
83452707
83452717
◆◆◆◆◆83452712 83452720 ◆ ◆ ◆ ◆
Low level - Gold plated
Dimensions
Ø 24 2 pole
Electrical diagram
4D 2 pole 5D 1 pole
3D 1 pole2D 1 pole
4D 1 pole
separate common
4D 1 pole
with common
Ø 16 1 pole Ø 16 QuikFix®
◆ CONTACT US FOR ANY MISSING REFERENCE
MULTIWAY
Ø16+ 0.1
- 0.2
Ø18.5
Ø20
0
- 0.05
Ø18.5 0
- 0.05
Ø 24 5D
*
*
**
*
**
*
|WWW.CROUZET-AEROSPACE.COM | 20 |COCKPIT EQUIPMENT
Mechanical characteristics
Operating force per direction 9 N max 4 N max 10 N max 2.5 N 17 N 25 N
Release force 1.2 N min 0.6 N min 2 N min 2 N min 2 N min
Permissible force at end of travel
50 N 40 N 80 N 80 N 80 N
Mechanical life 100 000 cycles 400 000 cycles 100 000 cycles 50 000 cycles 100 000 cycles
Electrical characteristics
Voltage 5 VDC to 28 VDC 5 VDC to 28 VDC 5 VDC to 28 VDC 5 VDC to 28 VDC 5 VDC to 32 VDC
Current (resistor) 1 mA to 5 A 1 mA to 5 A 1 mA to 5 A 1 mA to 5 A 1 mA to 5 A
Current max @ 30VCC (self) 2 A 2 A 3.5 A 4 A 2 A
Current max @ 115VAC 400Hz (self)
2 A 2 A 2.5 A 1 A 2 A
Contact resistance 25 mOhm 25 mOhm 25 mOhm 25 mOhm 25 mOhm
Electrical life per direction 100 000 cycles 200 000 cycles 100 000 cycles 50 000 cycles 50 000 cycles
General characteristics
Case black polyamid 6.6 black polyamid 6.6 black polyamid 6.6 alumium alloy black polyamid 6.6
Actuator black polyamid 6.6 black polyamid 6.6 resin acetate alumium alloy resin acetate
Terminal solder lugs, silver plated solder lugs, silver plated solder lugs, silver plated solder lugs, silver plated solder lugs, silver plated
Contact silver silver silver silver silver
Operating temperature -55°C +85°C -55°C +85°C -55°C +85°C -40°C +70°C -15°C +60°C
Storage temperature -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C
Weight 35g 35g 18g 12g 29g
Dimensions
Electrical conguration
3 positions 3 positions
+ validation
5 positions
2 x NO/NC + 2 x NO/NC 2 x NO/NC + 2 x NO/NC 1 x NO/NC + 1 x NO/NC 1 x NO/NC + 1 x NO/NC 1 x NO/NC + 1 x NO/NC
Flat 83450706 ◆83450503 83454201 83450505
Gendarme ◆83450709 ◆◆◆
Electrical diagram
ROCKER SWITCH
|WWW.CROUZET-AEROSPACE.COM | 21 |COCKPIT EQUIPMENT
Mechanical characteristics
Operating force rst position 12 N 30 N 12 N 16 N 20 N 16 N 12 N 12 N 12 N 12 N 20 N 20 N 20 N
Release force rst position 2 N 2 N 2 N 4 N 4 N 4 N 2 N 2 N 2 N 2 N 4 N 4 N 4 N
Operating force second position
------40 N 40 N 30 N 30 N 33 N 33 N 33 N
Total travel rst position 14° 11° 14° 9° 14° 12° 12° 12° 12° 12° 12° 12° 12°
Total travel second position ------22° 22° 22° 22° 22° 22° 22°
Mechanical life 100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
100 000
cycles
Electrical characteristics
Voltage 14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
5 VDC to
32 VDC
14 VDC
to 30 VDC
14 VDC
to 30 VDC
Current (resistor) 6 A 6 A 6 A 6 A 6 A 6 A 6 A 6 A 2 A 6 A 20 mA 6 A 6 A
Current max @ 30VCC (self) 3 A 3 A 3 A 3 A 3 A 3 A 3 A 3 A -3 A -3 A 3 A
Electrical endurance 50 000
cycles
100 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
100 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
50 000
cycles
General characteristics
Case
black
polyamid
6.6
black
polyamid
6.6
black
polyamid
6.6
Thermoplastic
inox
Thermoplastic
inox
Thermoplastic
inox
black
polyamid
6.6
black
polyamid
6.6
black
polyamid
6.6
black
polyamid
6.6
Thermoplastic
inox
Thermoplastic
inox
Thermoplastic
inox
Button Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Acetate
resin
Terminal
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder pin
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
solder lugs,
cupper
nickel
Contact silver silver silver silver silver silver silver silver silver silver silver silver
Operating temperature -55°C
+85°C
-15°C
+60°C
-55°C
+85°C
-35°C
+75°C
-35°C
+75°C
-35°C
+75°C
-55°C
+85°C
-55°C
+85°C
-15°C
+60°C
-55°C
+85°C
-35°C
+75°C
-35°C
+75°C
-35°C
+75°C
Storage temperature -55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
-55°C
+85°C
Weight 40g 22g 22g 25g 27g 25g 22g 22g 38g 22g 25g 27g 25g
1 position 2 positions
non waterproof waterproof non waterproof waterproof
Color black red grey black red grey black red grey black red grey
Electrical conguration 2 x
NO/NC
2 x
NO/NC
2 x
NO/NC
1 x
NO/NC
2 x
NO/NC
2 x
NO/NC
2 x
NO/NC
2 x
NO/NC
4x
NO/NC
2 x
NO/NC
2 x
NO/NC
2 x
NO/NC
2 x
NO/NC
MOM
83574008 83574004 83574009 83574507 83574504 83574502 83574007 83574001 ◆83574010 83574514 83574555
83574505 83574501
MOM + FLAP
GUARD
◆83574006 ◆ ◆ 83574503 ◆83574011 83574013 83574512 ◆ ◆
83574509
83574511
83574559
◆
MOM + LOCKING
HOLE
◆◆◆◆◆◆83574012 ◆◆◆◆◆◆
MOM + FLAP+
LOCKING HOLE
◆◆◆◆◆◆◆83574014 ◆◆◆◆◆
Electrical diagram 1 x NO/NC
Dimensions MOM MOM + FLAP GUARD MOM + LOCKING HOLE
MOM + FLAP+ LOCKING HOLE
2 x NO/NC 4 x NO/NC
TRIGGER
Low level - Gold plated
|WWW.CROUZET-AEROSPACE.COM | 22 |COCKPIT EQUIPMENT
Mechanical characteristics
Operating force 13.5 N 13.5 N 7 N
Maximum torque on knob 0.3 mN 0.3 mN 0.3 mN
Permissible force at end of travel 20 N max 20 N max 13.5 N
Validation travel - - 3 mm max
Half force MTBF 10 000 000 cycles 10 000 000 cycles 1 000 000 cycles
Mechanical life 300 000 cycles 300 000 cycles 50 000 cycles
Electrical characteristics
Nominal voltage 0 15 VDC 0 15 VDC 0 15 VDC
Normal sensitivity 0.1 V/N 0.1 V/N 0.1 V/N
Hysteresis ± 0.035 V ± 0.035 V ± 0.1 V
Sensibility temperature coefcient ± 0.2% /SN/°C ± 0.2% /SN/°C ± 0.2% /SN/°C
Linearity error ± 0.07 VDC ± 0.07 VDC ± 0.07 VDC
General characteristics
Case inox inox inox
Actuator
Terminal solder terminal solder terminal solder terminal
Front face humidity resistance MIL STD 810D /506-2/proced 2 DO 160 E/ED 14E/section 6 cat B MIL STD 810D /506-2/proced 2
Dielectric strength 50 V 50 V 50 V
Insulation resistance > 10 MΩ@50V > 10 MΩ@50V > 10 MΩ@50V
Contact silver silver silver
Operating temperature -55°C +85°C -55°C +85°C -55°C +85°C
Storage temperature -55°C +85°C -55°C +85°C -55°C +85°C
Weight 24g 24g 100g
Electrical conguration Analogic
Standard Waterproof Validation
Concave 83459004 83459010 83459008
ANALOG TRANSDUCER
Dimensions
Electrical diagram
|WWW.CROUZET-AEROSPACE.COM | 23 |COCKPIT EQUIPMENT
2 directions
+ validation 2 directions 4 directions
+ validation
Color black black black black black
Electrical conguration 2 x NO + NO 2 x NO/NC
+ 2 x NO/NC
1 x NO/NC
+ 1 x NO/NC
2 x NO/NC
+ 2 x NO/NC 4 x NO + NO 2 x NO + 2 x NC
+ NO
Chinese 83460208
Pyramidal 83460109 79255317
Round 83452564
83452541
83452544
83452561
◆
Round
bayonet ◆ ◆ 83452580
Mechanical characteristics
Operating force per direction 6.5 N max 6.3 N max ◆ ◆ 6.5 N max 6.5 N max
Release force 3 N min 1.1 N min ◆ ◆ 3 N min 3 N min
Permissible force at end of travel
70 N 100 N ◆ ◆ 70 N 70 N
Validation operating force 6 N ◆◆ ◆ 6 N 6 N
Validation release force 2 N ◆◆◆2 N 2 N
Validation pushing action maximum
100 N ◆◆◆100 N 100 N
Total travel 12° 15° 13° 13° 12° 12°
Mechanical life 300 000 cycles 150 000 cycles 100 000 cycles 100 000 cycles 300 000 500 000 cycles 300 000 cycles
Electrical characteristics
Voltage 5 VDC to 28 VDC 14 VDC to 28 VDC 14 VDC to 28 VDC 14 VDC to 28 VDC 5 VDC to 28 VDC 5 VDC to 28 VDC
Current (resistor) 0.5 mA to 10 A 1 mA to 1 A 0.1 A 0.16 A 0.5 mA to 10 A 0.5 mA to 10 A
Current max @ 30VCC (self) 10 A 2 A 4 A 4 A 10 A 10 A
Current max @ 30VCC (self) 10 A ---10 A 10 A
Current max @ 120VAC 400Hz (self)
1 A ---1 A 1 A
Contact resistance 25 mOhm 25 mOhm 10 mOhm 10 mOhm 25 mOhm 25 mOhm
Electrical endurance 100 000 cycles 150 000 cycles 100 000 cycles 100 000 cycles 100 000 cycles 100 000 cycles
Dielectric strength 600 V @1mA 1 200 V 600 V @1mA 600 V @1mA
General characteristics
Case
polyamid 6.6 reinforced
with 40% berglass
AU4G black Diallyl phthalate Diallyl phthalate polyamid 6.6 reinforced polyamid 6.6 reinforced
Button black polyamid 6.6 AU4G black black polyamid 6.6 black polyamid 6.6 black polyamid 6.6 black polyamid 6.6
Terminal solder lugs,
silver plated solder lugs,
silver plated solder lugs,
silver plated solder lugs,
silver plated solder lugs,
silver plated solder lugs,
silver plated
Contact silver silver gold plated gold plated silver silver
Operating temperature -55°C +85°C -40°C +70°C -40°C +70°C -40°C +70°C -55°C +85°C -55°C +85°C
Storage temperature -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C -55°C +85°C
Weight 40g 35g 30g 40g 40g 40g
Electrical diagram
Dimensions Chinese PyramidalRound
TRIM SWITCH
Warning:
The product information contained in this catalogue is given purely as information and does not constitute a representation, warrantly or any form of contractual commitment.
Crouzet Automatismes SAS and its subsidiaries reserve the right to modify their products without notice. It is imperative that we should be consulted over any particular use or application
of our products and it is the responsability of the buyer to establish, particularly through all the appropriate tests, that the product is suitable for the use or application. Under no
circumstances will our warranty apply, nor shall we be held responsible for any application (such as any modication, addition, deletion, use in conjunction with other electrical or electronic
components, circuits or assemblies, or any other unsuitable material or substance) which has not been expressly agreed by us prior to the sale of our products.
FRANCE
InnoVista Sensors™
Tel.: +33 (0) 475 802 101
Fax: +33 (0) 475 828 900
relationclient@crouzet.com
GERMANY / AUSTRIA
InnoVista Sensors™
Tel.: +49 (0) 2103/980-0
Fax: +49 (0) 2103/980-222
kundenservice@crouzet.com
ITALY
InnoVista Sensors™
Tel.: +39 (02) 66 599 211
Fax: +39 (02) 66 599 218
assistenzaclienti@crouzet.com
USA
InnoVista Sensors™
Tel.: +1 (800) 677 5311
Fax: +1 (800) 677 3865
americas.custserv@crouzet.com
AMERICAS EUROPE
COUNTRIES NOT LISTED
InnoVista Sensors™
Tel.: +33 (0) 475 802 102
Fax: +33 (0) 475 828 900
relationclient@crouzet.com
OTHER COUNTRIES
WWW.CROUZET-AEROSPACE.COM WWW.INNOVISTASENSORS.COM
2016_NEW-MASTER_AERO.indd 1 13/06/2016 10:58:11
Ref. : 6736201B EN | 05/2016 - Photos: Ginko, Daniel Lattard, Airbus, Bombardier, Embraer, Eurocopter, Antonov, Gulfstream, © Eric Raz / Eurocopter

Navigation menu
