CyberTAN Technology DTA171HD Digital Transport Adapter User Manual Cisco HD Digital Transport Adapter DTA

CyberTAN Technology Inc. Digital Transport Adapter Cisco HD Digital Transport Adapter DTA

User Manual

Cisco HD Digital Transport Adapter (DTA)
Quick Reference Guide
IMPORTANT SAFETY INSTRUCTIONS
Notice to Installers
The servicing instructions in this notice are for use by quali ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions, unless you are quali ed to do so.
20080814_Installer820
Note to System Installer
CAUTION: To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable parts
inside. Refer servicing to qualified service personnel.
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
For this apparatus, the coaxial cable shield/screen shall be
grounded as close as practical to the point of entry of the
cable into the building. For products sold in the US and
Canada, this reminder is provided to call the system
installer's attention to Article 820-93 and Article 820-100 of
the NEC (or Canadian Electrical Code Part 1), which provides
guidelines for proper grounding of the coaxial cable shield.
This symbol is intended to alert you that uninsulated voltage
within this product may have sufficient magnitude to cause
electric shock.Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne qu’un contact
avec une pièce interne de ce produit, sous tension et non
isolée, pourrait être suffisant pour provoquer un choc
électrique. Il est donc dangereux d’être en contact avec toute
pièce interne de ce produit.
This symbol is intended to alert you of the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying this product.
Ce symbole a pour but de vous avertir qu’une
documentation importante sur le fonctionnement et
l’entretien accompagne ce produit.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid
injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as a power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Power Source Warning
A label on this product indicates the correct power source for this product.
Operate this product only from an electrical outlet with the voltage and
frequency indicated on the product label. If you are uncertain of the type
of power supply to your home or business, consult your service provider
or your local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
WARNING: Avoid electric shock and  re hazard! If this
product connects to coaxial cable wiring, be sure the cable system
is grounded (earthed). Grounding provides some protection against
voltage surges and built-up static charges.
WARNING: Avoid electric shock and  re hazard! Do
not locate an outside antenna system in the vicinity of overhead
power lines or power circuits. Touching power lines or circuits
might be fatal.
This product may contain a tuner capable of receiving off-the-air
broadcasts.
Operating Environment
This product is designed for operation indoors with a temperature range
from 32° to 104° F (0° to 40°C). Each product should have adequate
spacing on all sides so that the cooling air vents on the chassis are not
blocked.(Protect from Exposure to Moisture and Foreign Objects)
Protect from Exposure to Moisture and Foreign
Objects
WARNING: Avoid electric shock and  re hazard! Do not
expose this product to dripping or splashing liquids, rain, or moisture.
Objects  lled with liquids, such as vases, should not be placed on
this apparatus.
WARNING: Avoid electric shock and  re hazard! Unplug
this product before cleaning. Do not use a liquid cleaner or an
aerosol cleaner. Do not use a magnetic/static cleaning device (dust
remover) to clean this product.
WARNING: Avoid electric shock and  re hazard! Never
push objects through the openings in this product. Foreign objects
can cause electrical shorts that can result in electric shock or  re.
Service Warnings
WARNING: Avoid electric shock! Do not open the cover
of this product. Opening or removing the cover may expose you
to dangerous voltages. If you open the cover, your warranty will be
void. This product contains no user-serviceable parts.
Check Product Safety
Upon completion of any service or repairs to this product, the service
technician must perform safety checks to determine that this product is in
proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or
connecting or disconnecting cables.
20110316_Cable_Safety
Cisco HD Digital Transport Adapter (DTA)
Models: 170HD and 171HD
Manufactured by:
Cisco Systems, Inc.
5030 Sugarloaf Parkway
Lawrenceville, Georgia 30044 USA
Telephone: 770 236-1077
Open Source GNU GPL Statement
Cisco HD Digital Transport Adapter (DTA) contain(s), in part, certain
free/open source software (“Free Software”) under licenses which
generally make the source code available for free copy, modi cation, and
redistribution. Examples of such licenses include all the licenses sponsored
by the Free Software Foundation (e.g. GNU General Public License (GPL),
GNU Lesser General Public License (LGPL), Berkeley Software Distribution
(BSD), the MIT licenses and di erent versions of the Mozilla and Apache
licenses). To  nd additional information regarding the Free Software,
including a copy of the applicable license and related information, please
go to: (i) for North America http://www.cisco.com/web/consumer/support/
open_source.html, or (ii) for outside North America http://www.cisco.com/
web/consumer/support/open_source.html#~international. Once at the site,
search for the product listing and click on the related items identi ed. If you
have any questions or problems accessing any of the links, please contact:
spvtg-external-opensource-requests@cisco.com.
United States FCC Compliance
This device has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against such interference in a
residential installation. This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance with the
instructions, it may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment
OFF and ON, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit di erent from that to
which the receiver is connected.
Consult the service provider or an experienced radio/television technician
for help.
Any changes or modi cations not expressly approved by Cisco Systems,
Inc., could void the user’s authority to operate the equipment.
The information shown in the FCC Declaration of Conformity paragraph
below is a requirement of the FCC and is intended to supply you with
information regarding the FCC approval of this device. The phone numbers
listed are for FCC-related questions only and not intended for questions
regarding the connection or operation for this device. Please contact your
service provider for any questions you may have regarding the operation or
installation of this device.
Declaration of Conformity
This device complies with Part 15 of FCC Rules. Operation is subject
to the following two conditions: 1) the device may not cause harmful
interference, and 2) the device must accept any interference received,
including interference that may cause undesired operation.
AVC VIDEO LICENSE
With respect to each AVC/H.264 product, we are obligated to provide
the following notice:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE
FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT
DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE
WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM.
Accordingly, please be advised that service providers, content providers,
and broadcasters may be required to obtain a separate use license from
MPEG LA prior to any use of AVC/H.264 encoders and/or decoders.
ROVI CORPORATION COPYRIGHT
NOTICE
This product incorporates copyright protection technology that is protected
by U.S. patents and other intellectual property rights of Rovi Corporation.
Use of this copyright protection technology must be authorized by Rovi
Corporation, and is intended for home and other limited viewing uses only
unless otherwise authorized by Rovi Corporation. Reverse engineering and
disassembly are prohibited.
Disclaimer
Cisco Systems, Inc. assumes no responsibility for errors or omissions that
may appear in this guide. We reserve the right to change this guide at any
time without notice.
Protect the Product from Lightning
In addition to disconnecting the AC power from the wall outlet, disconnect
the signal inputs.
Verify the Power Source from the On/Off
Power Light
When the on/o power light is not illuminated, the apparatus may still
be connected to the power source. The light may go out when the
apparatus is turned o , regardless of whether it is still plugged into an
AC power source.
Eliminate AC Power/Mains Overloads
WARNING: Avoid electric shock and  re hazard! Do not
overload AC power/mains, outlets, extension cords, or integral
convenience receptacles. For products that require battery
power or other power sources to operate them, refer to the
operating instructions for those products.
Handling Disposable Batteries
This product may contain disposable batteries. Heed the following warning
and follow the Battery Safety and Battery Disposal instructions below.
WARNING: There is danger of explosion if the battery is
mishandled or incorrectly replaced. Replace only with the same
type of battery. Do not disassemble it or attempt to recharge it
outside the system. Do not crush, puncture, dispose of in  re,
short the external contacts, or expose to water or other liquids.
Dispose of the battery in accordance with local regulations and
instructions from your service provider.
Battery Safety
• Insert batteries correctly. There may be a risk of explosion if the
batteries are incorrectly inserted.
Do not attempt to recharge ‘disposable’ or ‘non-reusable’ batteries.
Please follow instructions provided for charging ‘rechargeable’
batteries.
Replace batteries with the same or equivalent type that we recommend.
Do not expose batteries to excessive heat (such as sunlight or  re).
Do not expose batteries to temperatures above 100°C (212°F).
Battery Disposal
The batteries may contain substances that could be harmful to the
environment.
• Recycle or dispose of batteries in accordance with the battery
manufacturer’s instructions and local/national disposal and recycling
regulations.
The batteries may contain perchlorate, a known hazardous substance,
so special handling and disposal of this product might be necessary.
For more information about perchlorate and best management
practices for perchlorate-containing substance, see www.dtsc.
ca.gov/hazardouswaste/perchlorate
Provide Ventilation and Select a Location
Remove all packaging material before applying power to the product.
Do not place this apparatus on a bed, sofa, rug, or similar surface.
Do not place this apparatus on an unstable surface.
Do not install this apparatus in an enclosure, such as a bookcase or rack,
unless the installation provides proper ventilation.
Do not place entertainment devices (such as VCRs or DVDs), lamps,
books, vases with liquids, or other objects on top of this product.
Do not block ventilation openings.
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme
NMB-003 du Canada.
20081121 FCC Standard
ENERGY STAR® Notice
This Cisco product has earned the ENERGY STAR.
Products that earn the ENERGY STAR reduce greenhouse
gas emissions by meeting strict energy e ciency guidelines
set by the U.S. Environmental Protection Agency and the
U.S. Department of Energy. ENERGY STAR is a registered
mark owned by the U.S. government.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other countries. A listing of Cisco’s trademarks can be
found at www.cisco.com/go/trademarks
ENERGY STAR and the ENERGY STAR mark are registered trademarks of the U.S. government.
HDMI, the HDMI logo, and High-De nition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
Rovi is a trademark of Rovi Corporation.
Other third party trademarks mentioned are the property of their respective owners.The use of the word partner does not imply a partnership relationship between Cisco
and any other company. (1009R)
Product and service availability are subject to change without notice.
© 2011-2012 Cisco and/or its a liates. All rights reserved.
February 2012 Printed in United States of America Part Number 4040685 Rev C
POWER
DTA 170HD
Cisco Systems, Inc. 678 277-1120
5030 Sugarloaf Parkway, Box 465447 800 722-2009
Lawrenceville, GA 30042 www.cisco.com
Note: This illustration may vary from the actual product.
7
POWER
DTA 170HD
Welcome
The Cisco® HD Digital Transport Adapter (DTA) works with traditional analog TVs and
digital High De nition TVs. Decryption technology on the DTA lets both analog and digital
TV owners view a variety of standard and high de nition channels, including subscribed
premium channels where o ered. See your service provider for details. Use the instructions
in this guide to install the DTA.
The consumer support website provides news and information about this product. For more
information, please refer to: http://www.cisco.com/web/consumer/support/index.html
1 Power LED Illuminates green when the DTA is powered up.
Illuminates red when the DTA is in standby mode.
Note: This illustration may vary from the actual product.
Front Panel
Safety and Performance Tip
Keep the top of the DTA free of all objects and electronic devices, including your
TV.
Mounting the DTA to a TV with Optional Hook-and-Loop
Squares
1. Remove one of the two optional hook-and-loop mounting squares from the carton
in which your DTA unit was shipped.
Note: Mounting the DTA to your television may be easier if the loop tape remains
attached to the hook fastener.
Connecting an Optional IR Extender
The IR Extender, if packaged with your DTA, allows you to install your DTA in an
unobtrusive location, such as a cabinet, and control your DTA with a remote control.
Back Panel
1 Cable In Connects to a coaxial cable that delivers the signal from
your service provider
2 TV Out Connects to a coaxial cable that sends signals to your TV
3 IR In Connects to an optional IR Extender if provided with the DTA
by your service provider
4 Slide Switch Can be set to either channel 3 or channel 4
5 HDMI Connect an HDTV HDMI™ (High-De nition Multimedia
Interface) cable from the HDTV to the HDMI port. HDMI
supports both digital audio and video
6 DC Power Input Connects to the external power supply for the DTA
Note: This illustration may vary from the actual product.
POWER SUPPLY WARNING: Only the supply that came with
your system may be safely used to power the DTA.
Safety First
Before using this DTA, read the IMPORTANT SAFETY INSTRUCTIONS section of
this guide.
Avoid Screen Burn-In
Images such as letterbox bars or side bars, bright closed-captioning backgrounds, station
logos, or any other stationary images may cause the TV screen to age unevenly and cause
damage to your TV. Refer to the user guide that came with your TV for more information
about screen burn-in.
Performance Tips
If the DTA does not perform as expected, the following tips may help.
No picture
Verify that the power to your TV is turned on.
If the DTA is plugged into a wall switch, verify the switch is in the ON position.
(Avoid plugging into an outlet that is controlled by a wall switch.)
Verify that all cables are properly connected.
The current channel may not be available in your service package. Try selecting
another channel to see if a picture appears.
No color
Verify the current TV program is broadcast in color.
Adjust the TV color controls.
No sound
Verify the volume is turned up.
Verify the mute function is not on.
2. Peel the paper backing from the loop tape on the mounting square you selected.
3. Press and hold the mounting square against the bottom of the DTA until the square
forms a secure bond.
4. Repeat steps 2 – 3 for the other mounting square.
5. Peel the paper backing from the hook fastener on each of the mounting squares.
6. Press and hold the mounting squares to the top or back of your television until the
squares form a secure bond.
1. Plug the connector into the IR port on the back of the DTA.
2. Peel the paper backing from the adhesive pad on the bottom of the receiver.
Then, mount the IR Extender receiver in an inconspicuous place, but make
certain that nothing blocks the sensor on the front of the receiver. You must
be able to point the remote control at this sensor.
To control the DTA, press the keys on the remote control while aiming the
remote control at the sensor on the receiver.
Note: If you encounter problems, make sure that all connections are secure and
that nothing blocks the path between the receiver and your remote control.
For further assistance, contact your service provider.
Important: Do not block
the sensor on the front
of the receiver, or you
cannot control the DTA
with your remote control.
Place the sensor away
from compact  uorescent
light, plasma TV displays,
or LCD HDTVs. The
sensor signal may be
blocked when placed too
close to these types
of devices, and the
remote control will no
longer function properly.
Installing the DTA
WARNING: Electric shock hazard! Unplug all electronic devices
before connecting or disconnecting any device cables to the DTA.
TVs with an HDMI Connector
1. Connect the DTA to the coaxial cable coming from the wall.
2. Connect an HDMI cable from the DTA to your TV.
Note: This illustration may vary from the actual product.
Other TVs
1. Connect the DTA to the coaxial cable coming from the wall.
2. Connect a coaxial cable from the DTA to your TV.
3. Slide the switch to channel 3 or channel 4 based on the channel your service
provider uses.
All TVs
After connecting your TV to the DTA:
1. Plug the power cord from the external power supply into the DTA.
2. If you received an IR Extender from your service provider, read and follow the
installation instructions in Connecting an Optional IR Extender.
3. Plug the DTA’s external power supply and the TV into an AC power source.
4. The DTA will power on once plugged in (indicated by a green light on its front panel).
Follow the on-screen steps or instructions provided by your Service Provider for
initial activation.
POWER
DTA 170HD
7
S/N:10112400012
CABLE IN TV OUT IR IN CH 3/4 +5V DC IN
7
 
79
S/N:10112400012
CABLE IN TV OUT IR IN CH 3/4 +5V DC IN
&DEOH
,QSXW
7
S/N:10112400012
CABLE IN TV OUT IR IN +5V DC IN
CH 3/4
CABLE IN
79
7
%RWWRP
RI'7$
+RRN)DVWHQHU
/RRS7DSH
5HPRYH$GKHVLYH
6WULS&RYHULQJ
$WWDFK0RXQWLQJ6TXDUHV+HUH
7
%RWWRP
RI'7$
%DFN
RI79
7
S/N:10112400012
TV OUT CH 3/4 +5V DC IN
IR INCABLE IN
,53RUWIRU,5([WHQGHU
7
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
This transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.

Navigation menu
