CyberTAN Technology WM140 2.4GHz Draft 802.11n 1*1 miniCard Module User Manual WU260 AM PS 20090805
CyberTAN Technology Inc. 2.4GHz Draft 802.11n 1*1 miniCard Module WU260 AM PS 20090805
Manual
CyberTAN
Product Specification
WM140
2.4GHz Draft 802.11n 1*1 miniCard Module
1. Specification
Specifications
Product Name 802.11 b/g/n Wireless LAN Module
Network Standards Draft IEEE802.11n and 11 b/g -compliant
Data Rate
802.11b: 11 / 5.5 / 2 / 1Mbps
802.11g: 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6Mbps
Draft 802.11n (20MHz, 800ns GI): 65, 58.5, 52, 39, 26, 19.5, 13, and 6.5Mbps
Draft 802.11n (40MHz, 400ns GI): 135, 121.5, 108, 81, 54, 40.5, 27, and
13.5Mbps
Modulation 802.11g/n---- OFDM
802.11b---- CCK (11Mbps, 5.5Mbps), QPSK (2Mbps), BPSK (1Mbps)
Technique Direct Sequence Spread Spectrum(802.11b)
Network Architecture Infrastructure and ad hoc
Operating Frequency 2.4G 11b/g/n:
2.412
~
2.462
GHz:
North
America
Operating Channels
11b:
1~11
for
America
2.4GHz
11g/n:
1~11
for
America
RF Output Power
16dBm +/- 1.5dBm
(2.4GHz,
11Mbps,
CCK)
13.5Bm +/- 1.5dBm
(2.4GHz,
54Mbps,
OFDM)
13.5dBm +/- 1.5dBm
(2.4GHz,
11n)
Antenna Dipole antenna*1
LED Indicators N/A
Coverage Area
Indoor:
20M@54Mbps,
35M@24Mbps,
60M@6Mbps,
100M@11Mbps
Receive Sensitivity
-84
dBm
@
11M
(CCK,
10%
PER)
-70
dBm
@
54M
(2RX
11g
OFDM,
10%
PER)
-70
dBm
@
54M
(2RX
11a
OFDM,
10%
PER)
-6 4
dBm
@
130Mbps
(2.4GHz,
2RX
11n
OFDM
with
20MHz
BW,
10%
PER)
-62
dBm
@
270Mbps (2.4GHz,
2RX
11n
OFDM
with
40MHz
BW,
10%
PER)
Power Consumption TX Power consumption: < 700 mA
RX Power consumption: < 460 mA
Operating Temperature 0 to 60 ℃
Humidity 20% to 95% Non-condensing
Voltage 3.3V
2. Drivers Release Plan
Driver Release time Utility Tools Release time
Windows 2000
Windows XP
Linux
VxWorks
3. Compliant Approvals
3.1 Compliant Approvals
FCC Part 15 Class B, C,RSS-210
3.2 Compliant PTT approvals
Supported by customer request: USA & Canada
4. W arranty
One year limited warranty.
4.1 Warning statement
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable pro tection against harmful inte rference in a
residential inst allation. T his equ ipment ge nerates, uses and can radiate ra dio fre quency energy an d, if not
installed and used in a ccordance with the instructions, may cau se ha rmful inte rference to r adio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to rad io or t elevision reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the F CC Rules. Operation is sub ject to the following two conditions: (1) This
device ma y n ot cau se h armful in terference, an d ( 2) this de vice must ac cept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in US, OEM has to limit the operation channels in CH1 to CH11 for 2.4G band by
supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory
Domain change.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is
still responsible for testing their end-product for any additional compliance requirements required with this module
installed (for example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or
co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can
not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating
the end product (including the transmitter) and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm
may be maintained between the antenna and users. The final end product must be labeled in a visible area with the
following: “Contains FCC ID: N89-WM140”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Industry Canada Statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may cause undesired operation of the
device
This device has been designed to operate with an antenna having a maximum gain of 1.8dBi.
Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna
impedance is 50 ohms.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
EIRP is not more than required for successful communication.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
This device is intended only for OEM integrators
under the following conditions:
The transmitter module may not be co-located with any other transmitter or antenna.
As long as conduction above is met, further transmitter test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module
installed (for example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or
co-location with another transmitter), then the IC authorization is no longer considered valid and the IC ID can not
be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the
end product (including the transmitter) and obtaining a separate IC authorization.
End Product Labeling
The final end product must be labeled in a visible area with the following: “Contains TX IC : 5005A-WM140”.
Manual Information That Must be Included
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove.
This RF module in the user’s manual of the end product which integrates this module.
The user’s manual for OEM Integrators must include the following information in a prominent location
“IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements. The antenna must not be
co-located or operating in conjunction with any other antenna or transmitter”.
