CyberTAN Technology WU182 802.11 b/g/n USB Module User Manual CyberTAN
CyberTAN Technology Inc. 802.11 b/g/n USB Module CyberTAN
User Manual
![](/img.php?id=2489746&img=bg1.png)
i
CyberTAN
User Manual
WU182-LO
802.11 b/g/n USB Module
Release 0.1
Date:
December 23, 2014
Author:
Cindy Fan
![](/img.php?id=2489746&img=bg2.png)
ii
Table of Contents
1. REVISION HISTORY ......................................................................................................................... 1
2. RELATED DOCUMENTS .................................................................................................................. 1
3. INTRODUCTION ................................................................................................................................ 2
4. SPECIFICATION ................................................................................................................................. 3
5. REGULATORY INFORMATION ......................................................................................................... 4
5.1 FCC NOTICE (USA) ............................................................................................................................. 4
![](/img.php?id=2489746&img=bg3.png)
1
1. Revision History
Date
Release
Author
Description
December 23, 2014
0.1
Cindy Fan
First Release
2. Related Documents
Date
Author
Document
IEEE.org
IEEE 802.11 b/g/n specification
Datasheet for MediaTek MT7603U
![](/img.php?id=2489746&img=bg4.png)
2
3. Introduction
The WU182-LO is a module based on a highly integrated Wi-Fi single chip which supports 300 Mbps PHY rate. It
fully complies with IEEE 802.11n and IEEE 802.11 b/g standards, offering feature-rich wireless connectivity at high
standards, and delivering reliable, cost-effective throughput from an extended distance.
Optimized RF architecture and baseband algorithms provide superb performance and low power consumption.
Intelligent MAC design deploys a high efficient DMA engine and hardware data processing accelerators which
offloads the host processor.
The WU182-LO is designed to support standard based features in the areas of security, quality of service and
international regulations, giving end users the greatest performance any time and in any circumstance.
Features and Benefits
IEEE 802.11 b/g/n compliant
Embedded high-performance 32-bit RISC microprocessor
Highly integrated RF with 55nm CMOS technology
2T2R mode with support of 300Mbps PHY rate
Integrate high efficiency switching regulator
Best-in-class power consumption performance
6-pin header interface for USB signal and power
1/2/3/4-wire PTA Wi-Fi / Bluetooth coexistence support
802.11 d/h/k support
Security support for WFA WPA/WPA2 personal, WPS2.0, WAPI
Supports 802.11w protected managed frames
QoS support of WFA WMM, WMM PS
Supports Wi-Fi Direct
Fully compliance with USB v2.0 High-speed mode
Per packet transmit power control
Antenna Detection
![](/img.php?id=2489746&img=bg5.png)
3
4. Specification
Specifications
Product Name
IEEE802.11 b/g/n USB Module
Interface
USB2.0 in a ROHS 6P header
Network Standards
IEEE802.11n and 11b/g -compliant
Data Rate
11b/g:
54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2,1 Mbps
11n:
20MHz and 40 MHz BW: up to 150 Mbps
Modulation
802.11g/n---- OFDM (BPSK, QPSK, 16QAM, 64QAM)
802.11b---- CCK (11Mbps, 5.5Mbps), QPSK (2Mbps), BPSK (1Mbps)
Network Architecture
Infrastructure and ad hoc
Operating Frequency
2.4GHz 11b/g/n:
2.412
~
2.462
GHz:
North
America
Operating Channels
11b:
1~11
for
America
2.4GHz
11g/n:
1~11
for
America
Antenna
Two Metal Antennas on-board design
LED Indicators
N/A
Coverage Area
Indoor:
20M@54Mbps,
35M@24Mbps,
60M@6Mbps,
100M@11Mbps
Operating Temperature
0 to 55 ℃
Humidity
20% to 95% Non-condensing
Dimensions (mm)
40 x 46.45 x5.1 mm (typical)
(The height including WTB connector and antenna)
Weight (g)
7.3g
Voltage
3.3 V
![](/img.php?id=2489746&img=bg6.png)
4
5. Regulatory Information
5.1 FCC Notice (USA)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This device and its antenna(s) must not be co-located with any other transmitters except in accordance with FCC
multi-transmitter product procedures. Referring to the multi-transmitter policy, multiple-transmitter(s) and
module(s) can be operated simultaneously without C2PC.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels
is not possible.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
![](/img.php?id=2489746&img=bg7.png)
5
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed
IMPORTANT NOTE:
This module is intended for OEM integrator. The OEM integrator is responsible for the compliance to all the
rules that apply to the product into which this certified RF module is integrated.
Additional testing and certification may be necessary when multiple modules are used.
USERS MANUAL OF THE END PRODUCT:
In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with the
antenna while this end product is installed and operated. The end user has to be informed that the FCC
radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. The end user has to also
be informed that any changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate this equipment. If the size of the end product is smaller than 8x10cm, then additional FCC
part 15.19 statement is required to be available in the users manual: This device complies with Part 15 of FCC
rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference
and (2) this device must accept any interference received, including interference that may cause undesired
operation.
LABEL OF THE END PRODUCT:
The final end product must be labeled in a visible area with the following " Contains TX FCC ID: N89-WU182
". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be
available on the label: This device complies with Part 15 of FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm
may be maintained between the antenna and users. The final end product must be labeled in a visible area with
![](/img.php?id=2489746&img=bg8.png)
6
the following: “Contains FCC ID: N89-WU182”. The grantee's FCC ID can be used only when all FCC
compliance requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module. The end user
manual shall include all required regulatory information/warning as show in this manual.
