CyberData Corporation CyberData Corporation - 2555 Garden Road - Monterey, California 93940
(831) 373-2601 - (831) 373-4193 - www.cyberdata.net
VoIP Zone Controller
4-Port Audio Out
Analog Amplifiers Paging Speakers
VoIP Zone Controller 4-Port Audio Out
Server
IP Phone
Typical Installation
VoIP Zone Controller
4-Port Audio-Out
Features
- SIP RFC 3261 compatible
- PoE 802.3af enabled
(Power-over-Ethernet)
- Dual-Speed Ethernet 10/100 Mbps
- Page up to 16 zones
- Web-based configuration
- Web-based firmware upgradeable
- Connector for external power supply
- Small footprint
The CyberData VoIP Zone Controller
with Audio-Out enables access to
existing paging speakers through a
VoIP phone system. The interface is
designed to use a standard paging
amplifier with audio inputs and
supports paging up to 16 zones from a
VoIP phone.
Dimensions 6.11”L x 4.05”W x 1.15”H
Regulatory Compliance FCC Class B, UL 60950, CE
Protocol SIP RFC 3261 Compatible
Ethernet I/F 10/100 Mbps
Power Input PoE 802.3af or 48VDC
2 years limitedWarranty
010xxxPart Number
VoIP Zone Controller 4-Port Audio-Out Specifications
G711Payload Types
CyberData Corporation CyberData Corporation - 2555 Garden Road - Monterey, California 93940
(831) 373-2601 - (831) 373-4193 - www.cyberdata.net
061212
