CyberData Corporation - 2555 Garden Road - Monterey, California 93940
(831) 373-2601 - (831) 373-4193 - www.cyberdata.net
CyberData Corporation
VoIP Multicast Microphone
Typical Installation
VoIP Loudspeaker Amplifiers VoIP Paging Amplifier*
Generic PoE Hub
1 2 3 4 5 6
VoIP Ceiling Speakers* VoIP Intercom*
Multicast Microphone
*
* Configured for multicast mode
VoIP Multicast Microphone
Features
- Multicast and Unicast support
- Dual-Speed 10/100 Mbps
- Web based configuration
- Web based firmware upgradeable
- PoE 802.3af Enabled (Powered-over-Ethernet)
- Electred condenser microphone
- Single button push-to-talk function
- RoHS compliant
- IGMP 2
The CyberData Multicast Microphone is a
Power-over-Ethernet (PoE) and Voice-over-IP
(VoIP) microphone. The Multicast Microphone is
one of the central components of a paging alert
notification system. No IP PBX is required.
The microphone is compatible with CyberData’s
IP speakers and other endpoints that can
receive multicast audio. The microphone is
powered via a standard PoE-compliant Ethernet
cable - no external power supply is needed.
Dimensions 1.9” x 4.25” x 5.33” (H x W x D)
2 years limitedWarranty
011007Part Number
VoIP Multicast Microphone Specifications
Power Requirement PoE 802.3af
Sensitiviy -74dB
Frequency Response 100 - 1000 Hz
RTPData type
30 ms packet time
G711 A-law and µ-law
Payload type
CyberData Corporation Innovative Concepts in Peripheral Connectivity.
CyberData Corporation
930228A/080813
CyberData Corporation - 2555 Garden Road - Monterey, California 93940
(831) 373-2601 - (831) 373-4193 - www.cyberdata.net
CyberData Corporation
VoIP Multicast Microphone
Typical Installation
VoIP Loudspeaker Amplifiers VoIP Paging Amplifier*
Generic PoE Hub
1 2 3 4 5 6
VoIP Ceiling Speakers* VoIP Intercom*
Multicast Microphone
*
* Configured for multicast mode
CyberData Corporation Innovative Concepts in Peripheral Connectivity.
