The Cyclades-TS100 v2 is a powerful,

yet highly compact single-port device

server used to connect serial devices

to a TCP/IP network. Typical

applications include industrial and

retail automation, console port

management and IP-enabling legacy

serial devices.

The TS100 v2 uses its PowerPC dual

CPU to transfer data from its

10/100BT Ethernet interface to its RS-

232/RS-485 (software selectable)

serial interface and vice-versa,

enabling communication between the

serial device and the network. The

Cyclades-TS100 v2 supports SSH v2

(Secure Shell) for a high degree of

security in data connections.

Unlike other device server equipment

designed with proprietary software

technologies, the Cyclades-TS100 v2

leverages Embedded Linux and other

Open Source software. Users have the

flexibility and power to customize its

operation, modifying or adding

features as needed.

Although it’s the same size of a deck

of playing cards, the Cyclades-TS100

v2 has all the power and functionality

necessary to take network

connectivity to the next level.

Applications:

•Server and Network Management

•Industrial/Commercial Automation

•Console Port Management

•IP enabling of Legacy Serial Devices

Benefits:

•Secure Network Management

•Easy Integration with the Network

and Serial Devices

•Easy Customization

•Rock-solid stability (Linux Inside)

Cyclades-TS100 v2

Secure Device Server

Application Example

Hardware

CPU: MPC855T (PowerPC dual-CPU)

Memory: 32MB SDRAM / 16MB Flash

Features: LED indications for Ethernet and serial port

Interfaces: 1 Ethernet 10/100BT on RJ-45

1 RS-232 DTE on DB-9 or

RS-485 DTE on DB-9 or

terminal block (software selectable,

230Kbps maximum)

Power: External Universal AC, 100-240VAC,

50/60 Hz, 5VDC, 5W max

Dimensions 2.8 x, 3.4 x 1.2 in.

(WxDxH): 7.0 x 8.5 x 3.0 cm

(standard 35mm DIN-rail based,

4-module width)

Operating

Temperature: 50°F to 122°F (10° to 50°C)

Storage

Temperature: -40°F to 185°F (-40°C to 85°C)

Humidity: 5% to 90% non-condensating

Certification: FCC Part 15, A

EN55022, A

Enclosure: Noryl VO1550 base, aluminum cover

Part Number Model Description

TES1661 Cyclades-TS100 v2 Secure Device Server

Features

Operating System

•Linux®

Security

•SSH v1 and v2

•Local, RADIUS and TACACS+ and LDAP Authentication

•Token-based strong authentication (SecurID)

•Local backup user authentication support

•IP Packet and Security Filtering

•User Access Lists

•System Event Syslog

Console Management

•Break Over SSH support

•Off-line data buffering - Local or Remote (NFS/Syslog)

•Timestamp for data buffering

•Simultaneous access on the same port (port sniffing)

•Event notification (email, pager, SNMP trap)

Port Access

•Directly by TCP port, IP address or server name

•Telnet/SSH with menu

•Raw TCP socket access

•HTTP/HTTPS

System Management

•Configuration wizard for first time users

•Command Line Interface (Linux Shell)

•Web Management Interface (HTTP/HTTPS)

•SNMP

Upgrades

•Upgrades available on FTP site, no charge

•Flash upgradable

•TFTP support for network boot

Customization

•Cyclades Development Kit (CDK) available

for custom applications, no charge

Additional Protocols Supported

•Modbus/RTU support for industrial automation applications

•DHCP for dynamic IP address assignment

•NTP for time server synchronization

•RFC2217 support for remote serial port access

Cyclades-TS100 v2 Specifications

3541 Gateway Boulevard, Fremont, CA 94538 T: 510.771.6100 F: 510.771.6200 www.cyclades.com sales@cyclades.com

© 2006 Cyclades Corporation, all rights reserved.
