D Link WA140B1 Wireless USB Adapter User Manual

D Link Corporation Wireless USB Adapter

User Manual

1
RANGEBOOSTER NT M
USB ADAPTER
DWA-140
Quick Install Guide+
Installations-Anleitung+
Guide d’installation+
Guía de instalacn+
Guida di Installazione+
Installatiehandleiding+
Instrukcja instalacji+
Instalíručka+
Telepítési Segédlet+
Installasjonsveiledning+
Installationsvejledning+
Asennusopas+
Installationsguide+
Guia de Instalação+
Οδηγός Γρήγορης Εγκατάστασης το+
2
Quick Installation Guide
DWA-140
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Installation CD, Manual
and Warranty)
If any of the items are missing, please contact your reseller.
1Remove the D-Link CD-ROM. 2B. Click “ Install Driver”
Quick Installation
Package Contents
RANGEBOOSTER NTM USB ADAPTER
Warning: Do NOT install the Adapter into your computer before installing the driver
software from the D-Link CD.
A. Insert D-Link CD-ROM into
your computer.
2 3
Quick Install Guide Troubleshooting
1. If I’ve lost my CD what can I do?
The CD contains software drivers and manual which can be obtained from D-Link
(see Technical Support below). Windows 2000, XP, Vista in most cases will
automatically install the correct drivers.
2. If I’ve forgotten my wireless encryption key?
The wireless encryption key is configured at the Wireless Access Point, Router or
DSL Modem Router. If you are unable to obtain your encryption key, the only solution
would be to re-configure your Access Point/Router to use a new encryption key. Please
contact your Wireless Access Point/Router/DSL Modem Router manufacturer.
3. Why can’t I get a wireless connection?
Check that your DWA-140 is plugged in properly to the USB port or try to plug the
DWA-140 into another USB port if available.
Check that the LED has come on. If no the driver or the USB port need to be look
at.
Ensure that the wireless settings on the DWA-140 match the settings on your Access
Point/Router. Please check and confirm your settings for.
Wireless Network Name (SSID)
Wireless Encryption Key
Wireless Security Method (E.g. WEP, WPA2)
To check whether a Wireless connection has been made, in the Windows System
Tray (bottom right). Red means no valid connections have been made.
Check that your Internet is working fine on existing computers.
Ensure that you have followed and completed the software installation process,
otherwise, please re-install the software. The LED on the DWA-140 should come on
after software installation.
4. Which Operating Systems does the DWA-140 support?
The DWA-140 support all popular Operating Systems including Microsoft Windows
XP(64/32 bit)/2000.
Note: If you are unable to connect, see the Troubleshooting chapter of the product
manual in the D-Link DWA-140 RangeBooster N Adapter CD
Technical Support
Thank you for choosing D-Link products. For further information, support, product drivers
and manuals please visit the D-Link website at www.dlink.eu
http://www.dlink.co.uk
4
Kurzanleitung für die Fehlerbehebung
1. Was kann ich tun, wenn ich meine CD verloren habe?
Auf der CD sind die Software-Treiber und das Handbuch gespeichert. Diese
sind jedoch auch direkt bei D-Link erhältlich (siehe „Technischer Kundendienst“).
Unter Windows 2000, XP, Vista werden die entsprechenden Treiber in der Regel
automatisch installiert.
Installationsanleitung
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Sollte eines dieser Teile fehlen, wenden Sie sich bitte an Ihren Fachhändler.
Lieferumfang
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Handbuch, Software
und Garantie auf der
CD-ROM)
1D-Link CD herausnehmen. 2B. Klicken Sie auf die
Schaltäche “ Install Driver”
Warnung! Installieren Sie auf keinen Fall den Adapter, bevor Sie nicht die Software von
der D-Link-CD-ROM installiert haben.
A. Legen Sie die D-Link CD ins
Laufwerk ein.
Installationsanleitung
4 5
2. Was kann ich tun, wenn ich meinen Verschlüsselungsschlüssel für die drahtlose
Verbindung vergessen habe?
Der Verschlüsselungsschlüssel wird im drahtlosen Access Point, Router oder DSL-
Modem-Router eingestellt. Wenn Sie Ihren Verschlüsselungsschlüssel verloren haben,
müssen Sie den Access Point bzw. den Router neu konfigurieren und einen neuen
Schlüssel einstellen. Bitte wenden Sie sich dazu an den Hersteller Ihres drahtlosen
Access Point, Routers oder DSL-Modem-Routers.
3. Warum kann ich keine drahtlose Verbindung aufbauen?
Überprüfen Sie, ob der DWA-140 ordnungsgemäß mit dem USB-Anschluss verbunden
ist, oder versuchen Sie, wenn möglich, den DWA-140 an einen anderen USB-
Anschluss anzuschließen.
Vergewissern Sie sich, dass die grüne Verbindungsanzeige leuchtet. Falls nicht,
müssen der Treiber oder der USB-Anschluss überprüft werden.
Überprüfen Sie, ob die Einstellungen für die drahtlose Verbindung am DWA-140 mit
den Einstellungen des Access Point bzw. Routers übereinstimmen. Überprüfen Sie
folgende Einstellungen:
Netzwerkname (SSID)
Verschlüsselungsschlüssel für die drahtlose Verbindung
Sicherheitsstandard für drahtlose Verbindungen (z. B. WEP, WPA2)
Überprüfen Sie in der Windows-Taskleiste (rechts unten), ob eine drahtlose Verbindung
aufgebaut wurde. Wenn das Symbol rot angezeigt wird, wurde keine Verbindung
aufgebaut.
Überprüfen Sie, ob das Internet auf anderen Computern funktioniert.
Vergewissern Sie sich, dass die Software korrekt und vollständig installiert ist.
Installieren Sie die Software bei Bedarf neu. Die Anzeige am DWA-140 beginnt zu
leuchten, sobald die Software korrekt installiert ist.
4. Welche Betriebssysteme werden vom DWA-140 unterstützt?
Der DWA-140 unterstützt alle gängigen Betriebssysteme, z. B. Microsoft Windows
XP(64/32 bit)/2000.
Hinweis: Wenn keine Verbindung aufgebaut werden kann, sehen Sie auf der CD für
den D-Link DWA-140 RangeBooster N Adapter im Produkthandbuch im Kapitel
Fehlerbehebung“ nach.
Technischer Kundendienst
Vielen Dank, dass Sie sich für ein Produkt von D-Link entschieden haben. Weitere
Informationen sowie technische Hilfe, Treiber und Handbücher finden Sie auf unserer
Website unter www.dlink.eu.
http://www.dlink.de
6
Guide d’installation rapide
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Si l’un des éléments ci-dessous est manquant, veuillez contacter votre revendeur.
Que contient la boîte ?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Manuel, logiciel, et
garantie sur CD)
1Retirez le CD D-Link. 2B. cliquez sur “ Install Driver”
Avertissement: Ne PAS installer la carte dans votre ordinateur avant d’avoir installé le
logiciel des pilotes à partir du CD D-Link.
A. Insérez le CD D-Link dans
votre ordinateur.
Installation rapide
6 7
Dépannage Guide d’installation rapide
1. J’ai perdu mon CD, que puis-je faire ?
Le CD contient les pilotes de la carte et son manuel. Vous pouvez les télécharger
sur le site D-Link (Voir Support Technique ci-dessous). Windows 2000, XP, Vista
installent généralemant de façon automatique les bons drivers.
2. J’ai perdu ma clé d’encryption sans fil
La clé d’encryption sans fil est configurée sur le point d’accès, le routeur ou le
modem routeur DSL sans fil. Si vous ne retrouvez pas cette clé d’encryption, l’unique
solution est de reconfigurer votre point d’accès ou routeur afin d’en utiliser une
nouvelle. Merci de contacter le constructeur de votre point d’accès/routeur/modem
routeur DSL.
3. Je n’arrive pas à me connecter en sans fil
Vérifiez que votre DWA-140 est correctement connecté sur le port USB ou essayez
de la connecter sur un autre port USB.
Vérifiez que la diode verte est bien allumée. Si ce n’est pas le cas vérifiez le port
USB ou son pilote.
Vérifiez que les paramètres sans fil de votre DWA-140 correspondent à ceux de
votre point d’accès/routeur. Voici les points à vérifier :
Nom du réseau sans fil (SSID)
Clé d’encryption sans fil
Méthode de sécurité sans fil (E.g. WEP, WPA2)
Vérifier qu’une connexion sans fil a été établie, dans la barre de tache de Windows (en
bas à droite). Le rouge indique que la connexion sans fil n’a pas été établie.
Vérifiez que la connexion Internet fonctionne sur les autres ordinateurs.
Assurez vous d’avoir suivi et fini la procédure d’installation logicielle, sinon merci de
la relancer. La diode de la DWA-645 ne doit s’allumer qu’après cette opération.
4. Quels sont les systèmes d’exploitation supportés par la DWA-140 ?
La DWA-140 supporte les principaux systèmes d’exploitation dont Microsoft Windows
XP(64/32 bit)/2000.
Note: Si la connexion ne s’établie pas, merci de consulter le chapitre Dépannage du
manuel présent sur le CD de la carte RangeBooster N 650 D-Link DWA-140
Support Technique
Merci d’avoir choisi les produits D-Link. Pour plus d’information, un support, télécharger
des pilotes ou manuels merci de visiter le site web de D-Link www.dlink.eu
http://www.dlink.fr
8
Solución de problemas de la Guía de instalación rápida
1. He perdido el CD
El CD contiene controladores y el manual, que pueden obtenerse de D-Link (vea más
adelante «Asistencia técnica»). Windows 2000, XP, Vista instalarán automáticamente
los controladores correctos en la mayoría de casos.
Guía de instalación rápida
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Si falta alguno de estos componentes, contacte con el proveedor.
¿Qué contiene la caja?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Manual, software y
garantía en el CD-ROM)
1Saque el CD D-Link. 2B. Haga clic en “ Install Driver”
Atención: NO instale el adaptador en su ordenador sin antes haber instalado el
software con el controlador que se encuentra en el CD-ROM de D-Link.
A. Introduzca el CD D-Link en el
ordenador.
Guía de instalación rápida
8 9
2. He olvidado mi clave de encriptación inalámbrica
La clave de encriptación inalámbrica está configurada en el punto de acceso, router o
módem router DSL inalámbricos. Si no puede obtener su clave de encriptación, la única
solución es volver a configurar su punto de acceso o router y, de este modo, usar una
nueva clave de encriptación. Póngase en contacto con el fabricante de su punto de
acceso, router o módem router DSL inalámbricos.
3. No consigo una conexión inalámbrica
Compruebe que el DWA-140 está conectado correctamente en el puerto USB o pruebe a
conectar el DWA-140 en otro puerto USB que esté libre.
Compruebe que el LED de enlace se ha iluminado en verde. Si no es así, debe examinar
el controlador o el puerto USB.
Asegúrese de que los parámetros inalámbricos del DWA-140 coinciden con los
parámetros de su punto de acceso o router. Compruebe y confirme los parámetros
siguientes:
Nombre de red inalámbrica (SSID)
Clave de encriptación inalámbrica
Método de seguridad inalámbrica (p. ej.: WEP, WPA2)
Para comprobar si es ha establecido una conexión inalámbrica, haga clic con el botón de
la derecha en la bandeja del sistema de Windows. Si aparece en rojo, es que no se ha
establecido ninguna conexión válida.
Compruebe que en los otros navegadores no hay ningún problema con la conexión a
internet.
Asegúrese de que ha seguido y completado todo el proceso de instalación del software.
El LED del DWA-645 debe encenderse tras la instalación del software.
4. ¿Qué sistemas operativos admite el DWA-140?
El DWA-140 admite todos los sistemas operativos más habituales, incluidos Microsoft
Windows XP(64/32 bit)/2000.
Nota: Si no puede conectarse, consulte el capítulo «Solución de problemas» del manual
del producto en el CD del adaptador RangeBooster N DWA-140 de D-Link.
Asistencia técnica
Gracias por elegir los productos de D-Link. Si desea más información, asistencia,
controladores y manuales del producto, visite el sitio web de D-Link, en www.dlink.eu.
http://www.dlink.es
10
Manuale rapido d’installazione risoluzione degli errori
1. Ho perso il CD. Come devo comportarmi?
Il CD contiene i driver software e il manuale che possono essere richiesti a D-Link
(vedi il paragrafo Supporto tecnico). In molti casi, Windows 2000, XP, Vista installano
automaticamente il driver corretto.
Guida di Installazione Rapida
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Se uno dei componenti dovesse risultare mancante, contattare il rivenditore.
Cosa contiene la confezione?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(CD con manuale,
software e garanzia)
1Rimuovere il CD D-Link. 2B. Cliccare su “ Install Driver”
Attenzione: NON installare l’adattatore nel computer prima di avere installato i driver
contenuti nel CD D-Link.
A. Inserire il CD D-Link nel
vostro computer.
Guida di Installazione Rapida
10 11
2. Ho dimenticato la chiave di cifratura wireless. Come devo comportarmi?
La chiave di cifratura wireless è configurate sul router, sul modem router DSL o sull’
accesso point wireless. Se non si riesce a recuperare la chiave di cifratura wireless è
necessario riconfigurare l’access point/router per utilizzare una nuova chiave di cifratura.
Contattare il produttore dell’access point wireless/router/modem DSL.
3. Non riesco a instaurare una connessione wireless.
Verificare che il dispositivo DWA-140 sia correttamente connesso alla porta USB. Se
possibile, provare a collegare il dispositivo DWA-140 a un’altra porta USB disponibile.
Verificare che il LED Link emetta una luce verde. In caso contrario è necessario
controllare il driver o la porta USB.
Verificare che le impostazioni wireless del dispositivo DWA-140 corrispondano alle
impostazioni dell’access point/router. Controllare e confermare le impostazioni relative a:
Nome della rete wireless (SSID)
Chiave di cifratura wireless
Metodo di sicurezza wireless (per esempio, WEP, WPA2)
Per verificare la connessione wireless, utilizzare la barra delle applicazioni di Windows (in
basso a destra). In assenza di una connessione valida è rossa.
Verificare che internet funzioni correttamente sui computer disponibili.
Verificare di avere eseguito e completato la procedura d’installazione del software.
In caso contrario installare nuovamente il software. Il LED del dispositivo DWA-645
dovrebbe accendersi dopo l’installazione del software.
4. Quali sistemi operativi sono supportati dal dispositivo DWA-140?
Il dispositivo DWA-140 supporta tutti i più diffusi sistemi operativi, inclusi Microsoft
Windows XP(64/32 bit)/2000.
Nota: Se non si riesce a instaurare una connessione, consultare il capitolo Risoluzione
degli errori del manuale utente contenuto nel CD delladattatore RangeBooster N
D-Link DWA-140
Supporto tecnico
Grazie per avere scelto i prodotti D-Link. Per maggiori informazioni o per ricevere supporto
tecnico, driver e manuali, visitare il sito D-Link all’indirizzo www.dlink.eu
http://www.dlink.it
12
Beknopte installatiehandleiding - Problemen oplossen
1. Wat moet ik doen als ik mijn cd kwijt ben?
De cd bevat stuurprogramma's en een handleiding. Deze materialen kunt u ook
downloaden van de site van D-Link (zie Technische ondersteuning hieronder). In
Windows 2000, XP, Vista worden in de meeste gevallen automatisch de juiste
stuurprogramma's geïnstalleerd.
Beknopte installatiehandleiding
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Als een van deze items ontbreekt, neemt u contact op met de leverancier.
Inhoud van de verpakking
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Handleiding, software
en garantieformulier
op cd)
1Verwijder de cd D-Link. 2B. Klik op “ Install Driver”
Waarschuwing: De draadloze adapter mag nog NIET op de computer zijn aangesloten
wanneer u de stuurprogramma's gaat installeren vanaf de cd!
A. Plaats de cd D-Link in de
computer.
Beknopte installatiehandleiding
12 13
2. Ik ben de encryptiesleutel voor mijn draadloze netwerk vergeten.
De encryptiesleutel voor het draadloze netwerk is opgeslagen op het draadloze Access
Point, de router of de ADSL-router met modem. Als u niet kunt achterhalen wat de
encryptiesleutel is, kunt u het probleem alleen verhelpen door het Access Point of de
router te configureren met een nieuwe encryptiesleutel. Neem voor meer informatie
contact op met de fabrikant van het draadloze Access Point, de router of de ADSL-
router met modem.
3. Waarom kan ik geen draadloze verbinding tot stand brengen?
Controleer of de DWA-140 goed is aangesloten op de USB-poort of sluit de DWA-140
aan op een andere USB-poort (indien beschikbaar).
Controleer of het groene lampje brandt. Als dat niet het geval is, controleert u de
werking van het stuurprogramma of de USB-poort.
Zorg ervoor dat de draadloze instellingen op de DWA-140 overeenkomen met de
instellingen op het Access Point of de router. Controleer de volgende instellingen en
pas deze zo nodig aan.
Naam draadloos netwerk (SSID)
Encryptiesleutel voor het draadloze netwerk
Beveiligingsmethode voor het draadloze netwerk (bijvoorbeeld WEP of WPA2)
U kunt op de taakbalk van Windows (helemaal rechts) zien of er een draadloze
verbinding tot stand is gebracht. Rood betekent dat er geen draadloze verbinding tot
stand is gebracht.
Controleer of internet wel goed werkt op andere computers.
Controleer of u de installatie van de software op de juiste manier en volledig hebt
uitgevoerd. Installeer de software anders opnieuw. Het lampje van de DWA-140 moet
gaan branden na de software-installatie.
4. Met welke besturingssystemen kan ik de DWA-140 gebruiken?
De DWA-140 ondersteunt alle populaire besturingssystemen, zoals Microsoft Windows
XP(64/32 bit)/2000.
Opmerking Als u nog steeds geen verbinding kunt maken, lees dan het hoofdstuk
Troubleshooting in de producthandleiding op de cd van de D-Link DWA-140
RangeBooster N adapter.
Technische ondersteuning
D-Link stelt het zeer op prijs dat u hebt gekozen voor een van onze producten. Ga voor
meer informatie, ondersteuning, stuurprogramma's en handleidingen naar de website van
D-Link op het adres www.dlink.eu.
http://www.dlink.nl
14
Ostrzeżenie: nie instaluj karty bezprzewodowej w komputerze przez zainstalowaniem
sterowników z płyty CD.
Rozwiązywanie problemów
1. Co zrobić, jeśli zagubieniu uległa płyta CD?
Płyta CD zawiera sterowniki oraz podręcznik użytkownika które mogą być również
pobrane z witryny internetowej firmy D-Link. Systemy operacyjne Windows 2000, XP,
Vista w większości przypadków zainstalują automatycznie prawidłowe sterowniki.
Skrócona instrukcja obsługi
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Sprawdź czy wszystkie elementy znajdują się w opakowaniu
Zawartość opakowania
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Instrukcja oraz
oprogramowanie na
płycie CD)
1Wyjmij płytę D-Link CD-ROM. 2B. Kliknij “ Install Driver”
A. Włóż płytę D-Link do napędu
CD.
Skrócona instrukcja obsługi
14 15
2. Co zrobić, jeśli zapomniałem sieciowy klucz szyfrowania?
Sieciowy klucz szyfrowania jest konfigurowany w bezprzewodowym punkcie
dostępowym lub routerze bezprzewodowym. Jeśli nie ma możliwości przypomnienia
sobie klucza, jedynym rozwiązaniem jest jego zmiana w powyższym urządzeniach.
Zajrzyj do podręcznika użytkownika aby dowiedzieć się, w jaki sposób skonfigurować
klucz szyfrowania sieci bezprzewodowej.
3. Dlaczego nie mogę uzyskać połączenia bezprzewodowego?
Sprawdź, czy adapter DWA-140 jest poprawnie przyłączony do portu USB lub spróbuj
przyłączyć go do innego wolnego portu.
Upewnij się, że zaświeciła się zielona dioda LED. Jeśli nie, sprawdź połączenie z
portem USB oraz czy jest zainstalowany odpowiedni sterownik.
Upewnij się, że ustawienia sieci bezprzewodowej adaptera DWA-140 odpowiadają
ustawieniom sieci bezprzewodowej punktu dostępowego lub routera bezprzewodowego.
Sprawdź następujące ustawienia:
Nazwa sieci bezprzewodowej (SSID)
Klucz szyfrowania sieci bezprzewodowej
Rodzaj szyfrowania (np. WEP, WPA2)
Aby sprawdz, czy nawiązane zostało połączenie bezprzewodowe, w zasobniku
systemowym Windows (po prawej na dole ekranu). Kolor czerwony oznacza brak
połączenia.
Upewnij się, że na przyłączonych komputerach masz dostęp do Internetu.
Upewnij się, że ukończyłeś instalację oprogramowania i sterowników do urządzenia.
Jeśli nie, zainstaluj oprogramowanie ponownie. Dioda na adapterze DWA-140 powinna
zaświecić się po instalacji oprogramowania.
4. Z jakimi systemami operacyjnymi działa adapter DWA-140?
Adapter DWA-140 działa z następującymi systemami operacyjnymi: Microsoft Windows
XP(64/32 bit)/2000.
Notatka: Jeśli nie możesz się połączyć, zajrzyj do rozdziału rozwiązywania problemów
w podręczniku ytkownika adaptera DWA-140 znajdującego się na płycie CD
dołączonej do tego produktu.
Wsparcie techniczne
Dziękujemy za wybranie produktów D-Link. Aby uzyskać dodatkowe informacje, wsparcie
techniczne oraz sterowniki i podręczniki użytkownika, odwiedź witrynę internetową firmy
D-Link pod adresem http://www.dlink.eu
http://www.dlink.pl
16
Návod na rychlou instalaci – Řešení problémů
1. Co mám dělat, když jsem ztratil dodávané CD?
CD obsahuje ovladače a návod, které lze získat od D-Link (viz „Technická podpora
níže). Systémy Windows 2000, XP, Vista nainstalují ve většině případů automaticky
správné ovladače.
Návod na rychlou instalaci
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Pokud některá z položek chybí, kontaktujte prodejce.
Balení obsahuje
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Návod, software a
záruční podmínky na CD)
1vyjměte CD D-Link. 2B. Klikněte na “ Install Driver”
Varování: NEINSTALUJTE adaptér do počítače dříve, než nainstalujete ovladač z CD
D-Link.
A. vložte do počítače CD D-Link .
Návod na rychlou instalaci
16 17
2. Co když jsem zapomněl šifrovací klíč pro svoji bezdrátovou síť?
Šifrovací klíč pro bezdrátovou síť je nakonfigurován v bezdrátovém přístupovém bodu,
směrovači nebo směrovači s DSL modemem. Pokud nemůžete zjistit svůj šifrovací
klíč, jediným řešením bude nakonfigurovat váš bezdrátový přístupový bod/směrovač
na nový šifrovací klíč. Pokud nevíte jak, kontaktujte výrobce vašeho bezdrátového
přístupového bodu, směrovače nebo směrovače s DSL modemem.
3. Proč se nemohu bezdrátově připojit?
Zkontrolujte, zda je DWA-140 připojen správně do USB portu nebo zkuste připojit
DWA-140 do jiného volného USB portu.
Zkontrolujte, zda svítí zelený indikátor Link. Pokud ne, je třeba zkontrolovat USB port
nebo instalaci ovladače.
Ujistěte se, že nastavení bezdrátové sítě na DWA-140 odpovídá nastavení na vašem
přístupovém bodu/směrovači. Zkontrolujte shodu těchto nastavení.
Název bezdrátové sítě (SSID)
Šifrovací klíč (Encryption Key)
Typ šifrování (např. WEP, WPA2)
Podívejte se na hlavní panel Windows (oznamovací oblast vpravo dole). Červená
znamená, že se nepodařilo navázat spojení.
Zjistěte, zda na ostatních počítačích funguje připojení k Internetu.
Ujistěte se, že jste dokončili proces instalace a postupovali přitom podle pokynů. V
opačném případě reinstalujte software. Indikátor na DWA-140 by se měl po instalaci
softwaru rozsvítit.
4. Jaké operační systémy podporuje DWA-140?
DWA-140 podporuje všechny nejznámější operační systémy včetně Microsoft Windows
XP(64/32 bit)/2000.
Poznámka: Pokud se nemůžete připojit, podívejte se do kapitoly „Řešení problémů“ v
návodu na CD pro RangeBooster N adaptér D-Link DWA-140
Technická podpora
Děkujeme, že jste si vybrali produkty D-Link. Další informace, podporu, ovladače a návody
najdete na webových stránkách D-Link na www.dlink.eu
http://www.dlink.cz
18
Hibaelhárítás
1. Mit tegyek, ha elvesztettem a CD-t?
A CD-n található szoftvereket és használati útmutatót letöltheti a D-Link weboldalán
található Technikai támogatás menüre kattintva. A Windows 2000, XP, Vista operációs
rendszerek rendszerint automatikusan telepítik a megfelelő meghajtókat.
Gyors telepítési útmutató
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Mit tartalmaz a csomag?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Használati útmutató,
szoftver és garancia CD
lemezen)
2
Amennyiben az alábbi elemek bármelyike hiányzik, kérjük, keresse fel értékesítőjét.
Vegye ki a D-Link CD lemezt B. Kattintson az “ Install Driver”
gombra.
Figyelmeztetés: NE csatlakoztassa az adaptert számítógépéhez, mielőtt a D-Link CD-n
található driver szoftvert nem telepítette!
A. Helyezze be a D-Link CD-t a
számítógépbe.
Gyors Telepítési Útmutató
1
18 19
2. Mit tegyek, ha elfelejtettem a vezeték nélküli titkosítási kulcsomat?
A vezeték nélküli titkosítási jelszó a vezeték nélküli hozzáférési ponton, roteren vagy
DSL modem routeren került beállításra. Ha nem tudja megszerezni a titkosítási kulcsot,
újat kell beállítania a hozzáférési ponton / routeren. Ehhez olvassa el a vezeték nélküli
hozzáférési pont/router/DSL modem router gyártójának utasításait.
3. Miért nem működik a vezeték nélküli kapcsolatom?
Ellenőrizze, hogy a DWA-140 megfelelően csatlakozik-e az USB portra, illetve ha van
rendelkezésre álló másik USB port, helyezze át abba az adaptert.
Ellenőizze, higy a zöld Link LED világít-e. Ha nem, ellenőrizze a drivert vagy az USB
portot.
Ellenőrizze, hogy a DWA-140 vezeték nélküli beállításai megegyeznek-e a hozzáférési
pont/router megfelelő beállításaival különös tekintettel az alábbiakra:
Vezeték nélküli hálózat neve (SSID)
Vezeték nélküli titkosítási kulcs
Vezeték nélküli biztonsági mód (pl. WEP, WPA2)
A Windows rendszertálcáján (jobb alul) ellenőrizheti a vezeték nélküli kapcsolat
létrejöttét. A piros szín azt jelzi, hogy nem jött létre a kapcsolat.
Ellenőrizze, hogy az Internet megfelelően működik-e a már hálózatba kapcsolt
számítógépeken.
Ellenőrizze, hogy megfelelően követte-e a szoftver telepítési eljárását. Ha nem,
telepítse újra a szoftvert. A DWL-140 LED kijelzőjének ki kell gyulladnia a szoftver
telepítését követően.
4. Milyen operációs rendszerek használatát támogatja a DWA-140?
A DWA-140 minden elterjedt operációs rendszer (Microsoft Windows XP(64/32
bit)/2000 ) használatát támogatja.
Figyelem: Ha nem tud csatlakozni, olvassa el a D-Link DWA-140 RangeBooster N
adapter CD-jén található Használati útmutató Troubleshooting (Hibaelhárítás) című
fejezetét.
Technikai támogatás
Köszönjük, hogy a D-Link termékét választotta. További információkat, támogatást, termék
drivereket és használati útmutatókat talál weboldalunkon: www.dlink.eu.
http://www.dlink.hu
20
Hurtiginstallasjonsveiledning
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Vennligst kontakt forhandleren hvis noen av disse delene mangler.
Hva inneholder esken?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Håndbok, programvare
og garanti på CD)
1Ta ut CD-en D-Link. 2B. Klikk på “ Install Driver”
Advarsel: IKKE installer kortbusskort i datamaskinen før du har installert driverprogram-
varen på CD-en fra D-Link.
A. Sett CD-en D-Link i
datamaskinen.
Hurtiginstallasjonsveiledning
20 21
Problemløsing ved installering
1. Jeg har mistet CD-en min. Hva kan jeg gjøre?
CD-en inneholder drivere og håndbøker som kan fås fra D-Link (se Teknisk støtte
nedenfor). Windows 2000, XP, Vista vil i de fleste tilfeller installere riktige drivere
automatisk.
2. Jeg har glemt min trådløse krypteringsnøkkel
Den trådløse krypteringsnøkkelen er konfigurert på det trådløse aksesspunktet, ruteren
eller ADSL-modemruteren. Hvis du ikke finner frem til krypteringsnøkkelen, er eneste
løsning å omkonfigurere aksesspunktet/ruteren med en ny krypteringsnøkkel. Kontakt
produsenten av det trådløse aksesspunktet/ruteren/DSL-modemruteren.
3. Hvorfor oppnår jeg ikke trådløs forbindelse?
Kontroller at DWA-140 er koblet riktig til USB-porten, eller prøv å koble DWA-140 i en
annen, tilgjengelig USB-port.
Sjekk at den grønne forbindelseslampen lyser. Hvis ikke, du konsentrere deg om
driveren eller USB-porten.
Pass at de trådløse innstillingene DWA-140 samsvarer med innstillingene
aksesspunktet/ruteren. Kontroller og bekreft innstillingene for:
Navn på trådløst nettverk (SSID)
Trådløs krypteringsnøkkel
Trådløs sikkerhetsmetode (f.eks. WEP, WPA2)
Sjekk om det er opprettet en trådløs forbindelse i systemstatusfeltet til Windows
(nederst til høyre). Rød vil si at det ikke er opprettet gyldige forbindelser.
Kontroller at internett fungerer på eksisterende datamaskiner.
Pass at du har fulgt og fullført programvareinstallasjonen. Hvis ikke, installerer du
programvaren på nytt. Lampen på DWA-140 skal lyse etter programvareinstallasjon.
4. Hvilke operativsystemer støtter DWA-140?
DWA-140 støtter alle populære operativsystemer, inkludert Microsoft Windows
XP(64/32 bit)/2000.
Merk: Hvis du ikke klarer å koble til, slår du opp kapittelet om problemløsing i
produkthåndboken på CD-en til D-Link DWA-140 RangeBooster N adapter.
Teknisk støtte
Takk for at du valgte produkter fra D-Link. Hvis du trenger mer informasjon, støtte, drivere
og håndbøker, kan du gå inn på D-Links nettsted på www.dlink.eu.
http://www.dlink.no
22
Kort installationsvejledning
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Hvis noget af ovennævnte indhold mangler, skal du kontakte forhandleren.
Hvad er der i boksen?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Manual, software og
garanti på cd)
Tag cd’en med D-Link CD. 2B. Klik på “ Install Driver”
Advarsel! Installer IKKE netværkskortet i computeren, før du installerer driverprogram-
met på cd'en fra D-Link.
A. Sæt cd’en med D-Link CD
i computeren.
Kort installationsvejledning
22 23
Kort installationsvejledning – fejlnding
1. Hvad kan jeg gøre, hvis jeg har mistet min cd?
Cd'en indeholder softwaredrivere og håndbog, og disse kan fås fra D-Link (se
Teknisk support nedenfor). Windows 2000, XP, Vista vil i de fleste tilfælde automatisk
installere de rigtige drivere.
2. Hvis jeg har glemt nøglen til trådløs kryptering?
Nøglen til trådløs kryptering konfigureres ved det trådløse access point, routeren eller
DSL-modemrouteren. Hvis du ikke kan få fat i krypteringsnøglen, er den eneste løsning
at konfigurere dit access point/router igen, du kan bruge en ny krypteringsnøgle.
Kontakt producenten af dit trådløse access point/router/DSL-modemrouter.
3. Hvorfor kan jeg ikke få oprettet trådløs forbindelse?
Kontroller, at DWA-140 er sat korrekt i USB-porten, eller prøv at sætte DWA-140 i en
anden USB-port, hvis der er en ledig.
Kontroller, at den grønne Link-lysdiode tændes. Gør den ikke det, skal du kontrollere
driveren eller USB-porten.
Sørg for, at de trådløse indstillinger i DWA-140 svarer til indstillingerne for dit access
point/router. Kontroller og bekræft indstillingerne for:
Navnet på det trådløse netværk (SSID)
Nøglen til trådløs kryptering
Metoden til trådløs sikkerhed (f.eks. WEP, WPA2)
Kontroller proceslinjen i Windows (nederst til højre), om der er oprettet trådløs
forbindelse. Rød betyder, at der ikke er oprettet brugbar forbindelse.
Kontroller, at internettet fungerer korrekt på de computere, du allerede har.
Kontroller, at du har fulgt instruktionerne ved installationen af softwaren og fuldført
processen. Hvis ikke, skal du installere softwaren igen. Lysdioden DWA-140 bør
blive tændt efter installation af softwaren.
4. Hvilke operativsystemer understøtter DWA-140?
DWA-140 understøtter alle almindelige operativsystemer, inklusive Microsoft Windows
XP(64/32 bit)/2000.
Bemærk! Hvis du ikke kan oprette forbindelse, skal du læse fejlfindingskapitlet i
produkthåndbogen på cd'en med det trådløse D-Link DWA-140 RangeBooster N.
Teknisk support
Tak, fordi du har valgt D-Link-produkter. Du kan finde flere oplysninger, support,
produktdrivere og håndbøger på D-Links websted på adressen www.dlink.eu
http://www.dlink.dk
24
Pika-asennusopas
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Jos pakkauksesta puuttuu jokin yllämainituista, ota yhteys jälleenmyyjääsi.
Mitä laatikossa on?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Käyttöopas, ohjelmisto
ja takuutodistus CD-
levyllä)
1Poista D-Link CD-levy. 2B. Klikkaa “ Install Driver”
Varoitus: ÄLÄ ASETA DWA-140-sovitinta tietokoneeseesi ennen kuin olet suorittanut
loppuun ohjainten asennuksen CD:ltä.
A. Aseta D-Link CD-levy
tietokoneeseesi.
Pika-asennusopas
24 25
Pika-asennusopas / ongelmanratkaisu
1. Mitä teen, jos CD-levy katoaa?
CD-levy sisältää ohjaintiedostoja ja käyttöoppaan. Ne ovat saatavissa D-Linkiltä (ks.
kohta Tekninen tuki alla). Windows 2000-, XP-, Vista käyttöjärjestelmät asentavat
useimmiten oikeat ohjaimet automaattisesti.
2. Mitä jos olen unohtanut langattoman salausavaimeni?
Langaton salausavain kuuluu langattoman tukiaseman, reitittimen tai DSL-modeemin
asetuksiin. Jos olet unohtanut tai kadottanut salausavaimesi, on ainoa vaihtoehto
tehdä tukiaseman/reitittimen asetukset uudelleen käyttäen uutta salausavainta. Ota
yhteyttä langattoman tukiaseman/reitittimen/DSL-modeemireitittimen valmistajaan tai
maahantuojaan.
3. Langaton yhteys ei toimi – miksi?
Tarkista, että DWA-140:n liitäntä USB-porttiin on kunnossa. Koeta kytkeä DWA-140
toiseen USB-porttiin, jos sellainen on vapaana.
Tarkista, että vihreä Link-merkkivalo on syttynyt. Jos se ei ole syttynyt, on tarkistettava
ohjain tai USB-yhteys.
Varmista, että DWA-140:n langattomat asetukset vastaavat tukiaseman/reitittimen
asetuksia. Tarkista seuraavat asetukset.
Langattoman verkon nimi (SSID)
Langaton salausavain
Langattoman tietoturvan tyyppi (esim. WEP, WPA2)
Tarkista Windowsin tehtäväpalkista (alhaalla oikealla). Punainen väri merkitsee, ettei
toimivaa yhteyttä ole syntynyt.
Varmista muiden tietokoneiden avulla, että yhteys Internetiin toimii asianmukaisesti.
Varmista, että olet tehnyt ohjelmistoasennuksen asianmukaisesti. Muussa
tapauksessa asenna ohjelmisto uudelleen. DWA-140:n merkkivalon pitäisi syttyä
ohjelmistoasennuksen jälkeen.
4. Mitä käyttöjärjestelmiä DWA-140 tukee?
DWA-140 tukee kaikkia suosittuja käyttöjärjestelmiä, mm. Microsoft Windows XP(64/32
bit)/2000.
Huom! Jos yhteyttä ei edelleenkään synny, tutustu D-Linkin langattoman DWA-140-
sovittimen CD-levyllä sijaitsevan käyttöoppaan kappaleeseen Vianetsintä.
Tekninen tuki
Kiitos, että valitsit D-Linkin tuotteen. Lisätietoja, tuotetukea, laiteohjaimia ja käyttöoppaita
löydät D-Linkin www-sivuilta osoitteessa www.dlink.eu.
http://www.dlink.
26
Snabbinstallationsguide – felsökning
1. Vad kan jag göra om jag har förlorat CD:n?
CD:n innehåller drivrutiner och en manual, vilka kan fås från D-Link (se Teknisk
support nedan). Windows 2000, XP, Vista installerar i de flesta fall automatiskt rätt
drivrutiner.
Snabbinstallationsguide
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Vänligen kontakta din återförsäljare om någon av ovanstående komponenter saknas.
Vad nns i lådan?
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Manual, programvara
och garanti på cd)
Ta ut cd:n D-Link CD. 2B. Klicka på “ Install Driver”
Varning! Installera INTE adaptern i din dator innan du installerat drivrutinerna från
D-Links cd-skiva.
A. Stoppa in cd:n D-Link CD
i datorn.
Snabbinstallations
26 27
2. Om jag har glömt min trådlösa krypteringsnyckel?
Den trådlösa krypteringsnyckeln är konfigurerad den trådlösa accesspunkten,
routern eller DSL-modemroutern. Om du inte kan ta reda din krypteringsnyckel,
återstår bara att omkonfigurera accesspunkten/routern, så att du kan använda en ny
krypteringsnyckel. Kontakta tillverkaren av den trådlösa accesspunkten/routern/DSL-
modemroutern.
3. Varför går det inte att skapa någon trådlös anslutning?
Kontrollera att DWA-140 är ordentligt ansluten till USB-porten, eller prova att ansluta
DWA-140 till en annan USB-port om det finns någon.
Kontrollera att den gröna lysdioden för förbindelse lyser. Om den inte lyser måste
drivrutinerna eller USB-porten kontrolleras.
Kontrollera att de trådlösa inställningarna för DWA-140 stämmer överens med
inställningarna för accesspunkten/routern. Kontrollera och bekräfta inställningarna
för:
Namn på trådlöst nätverk (SSID)
Trådlös krypteringsnyckel
Typ av trådlös kryptering (t.ex. WEP, WPA2)
Kontrollera i aktivitetsfältet i Windows (nere till höger) att det finns en trådlös
anslutning. Rött innebär att det inte finns någon fungerande anslutning.
Kontrollera att Internet fungerar ordentligt på de befintliga datorerna.
Kontrollera att du har installerat programvaran rätt sätt. Om inte, måste du
ominstallera programvaran. Lysdioden DWA-140 bör tändas efter det att
programvaran installerats.
4. Vilka operativsystem stödjer DWA-140?
DWA-140 stödjer alla vanliga operativsystem såsom Microsoft Windows XP(64/32
bit)/2000.
Obs! Om du inte kan upprätta gon anslutning kan du läsa i produktmanualens
kapitel om felsökning på CD-skivan D-Link DWA-140 RangeBooster N adapter
Teknisk support
Tack för att du har valt D-Links produkter. För ytterligare information, support, drivrutiner
till produkterna samt manualer ber vi dig att besöka D-Links webbplats www.dlink.eu
och därifrån välja land samt support.
http://www.dlink.se
28
Guia de instalação rápida – Resolução de Problemas
1. Perdi o meu CD, o que posso fazer?
O CD contém os drivers do software e o manual que podem ser obtidos na D-Link
(consulte a Assistência Técnica abaixo). O Windows 2000, XP, Vista na maior parte
dos casos, vão instalar automaticamente os drivers correctos.
Guia de instalação rápida
DWA-140
RANGEBOOSTER NTM USB ADAPTER
Se algum destes itens não estiver na embalagem entre em contacto com o seu revendedor.
Conteúdo da embalagem
12B. Clique em “ Install Driver”
Aviso: NÃO instale o adaptador no seu computador antes de instalar o software do
controlador que está no CD da D-Link.
Instalação rápida
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(Manual, software e
garantia no CD)
Retire o CD D-Link. A. Coloque o CD D-Link no
seu PC.
28 29
2. Esqueci-me do meu código de encriptação sem fios?
O código de encriptação sem fios é configurado no Ponto de Acesso Sem Fios,
Router ou Router do Modem DSL. Se não conseguir obter o seu código de
encriptação, a única solução será reconfigurar o seu Ponto de Acesso/Router para
utilizar um novo código de encriptação. Contacte o fabricante do seu Ponto de
Acesso Sem Fios/Router/Router Modem DSL.
3. Porque não consigo obter uma ligação sem fios?
Verifique se o seu DWA-140 está ligado correctamente à sua porta USB ou tente
ligar o DWA-140 a outra porta USB se possível.
Verifique se o LED de Ligação verde está aceso. Caso contrário, tem de verificar o
driver ou a porta USB.
Certifique-se de que as definições sem fios do DWA-140 correspondem às
definições do seu Ponto de Acesso/Router. Verifique e confirme as suas definições.
Nome de Rede Sem Fios (SSID)
Código de Encriptação Sem Fios
Método de Segurança Sem Fios (P. ex. WEP, WPA2)
Para confirmar se foi realizada uma ligação sem fios, vá ao ícone do Windows (canto
inferior direito). Vermelho significa que não foram feitas ligações válidas.
Verifique se a Internet está a trabalhar correctamente nos computadores existentes.
Certifique-se de que seguiu e concluiu o processo de instalação do software, caso
contrário, volte a instalar o software. O LED do DWA-140 deve acender-se depois da
instalação do software.
4. Qual é o Sistema Operativo suportado pelo DWA-140?
O DWA-140 suporta todos os Sistemas Operativos usuais incluindo o Microsoft
Windows XP(64/32 bit)/2000.
Nota: Se não consegue estabelecer uma ligação, consulte o capítulo Resolução de
Problemas do manual do produto no CD do Adaptador RangeBooster N DWA-140
da D-Link
Assistência Técnica
Obrigado por ter escolhido produtos da D-Link. Para mais informações, suporte, drivers
de produtos e manuais visite o website da D-Link em www.dlink.eu
http://www.dlink.pt.
30
Εγχειρίδιο σύντομης εγκατάστασης – διόρθωση λαθών
1. Έχασα το CD. Τι πρέπει να κάνω;
Το CD περιέχει τα driver software και το εγχειρίδιο που μπορούν να ζητηθούν από
την D-Link (βλέπε την παράγραφο Τεχνική υποστήριξη). Σε πολλές περιπτώσεις, τα
Windows 2000, XP, Vista εγκαθιστούν αυτόματα το σωστό driver.
Οδηγός Γρήγορης Εγκατάστασης του
DWA-140
Aν κάποιο από τα παρακάτω τεμάχια λείπει, παρακαλώ επικοινωνήστε με τον μεταπωλητή σας.
Περιεχόμενα Πακέτου
RANGEBOOSTER NTM USB ADAPTER
DWA-140
RANGEBOOSTER N
Wireless USB Adapter
CD-ROM
(CD με εγχειρίδιο,
software και εγγύηση)
Αφαιρέστε το D-Link CD. 2B. Κάντε κλικ“ Install Driver”
Προσοχή: ΜΗΝ εγκαθιστάτε τον προσαρμογέα στο computer αν πριν δεν έχετε
εγκαταστήσει τα driver που περιέχει το CD D-Link.
A. Εισάγετε το D-Link CD στον
υπολογιστή σας.
Οδηγός Γρήγορης Εγκατάστασης
30 31
2. Ξέχασα το κλειδί κρυπτογράφησης wireless. Τι πρέπει να κάνω;
Το κλειδί κρυπτογράφησης wireless είναι διαμορφωμένο στο router, στο modem
router DSL ή στην πρόσβαση point wireless. Αν δεν καταφέρετε να επανακτήσετε
το κλειδί κρυπτογράφησης wireless, είναι απαραίτητο να αναδιαμορφώσετε το
access point/router για να χρησιμοποιήσετε ένα νέο κλειδί κρυπτογράφησης.
Επικοινωνήστε με τον παραγωγό του access point wireless/router/modem DSL.
3. Δεν καταφέρνω να εγκαθιδρύσω μια σύνδεση wireless.
Ελέγξτε αν η συσκευή DWA-140, είναι σωστά συνδεδεμένη με την θύρα USB. Αν
σας είναι δυνατό, δοκιμάστε να συνδέσετε την συσκευή DWA-140 με μια άλλη
διαθέσιμη θύρα USB.
Ελέγξτε αν το LED Link εκπέμπει ένα πράσινο φως. Στην αντίθετη περίπτωση είναι
απαραίτητο να ελέγξετε το driver ή την θύρα USB.
Ελέγξτε αν οι ρυθμίσεις wireless της συσκευής DWA-140 αντιστοιχούν στις
ρυθμίσεις του access point/router. Ελέγξτε και επιβεβαιώστε τις ρυθμίσεις που είναι
σχετικές με:
Όνομα του δικτύου wireless (SSID)
Κλειδί κρυπτογράφησης wireless
Μέθοδος ασφάλειας wireless (για παράδειγμα, WEP, WPA2)
Για να ελέγξετε την σύνδεση wireless, χρησιμοποιήστε την γραμμή των εφαρμογών
του Windows (κάτω δεξιά). Όταν δεν υπάρχει μια ισχύουσα σύνδεση είναι κόκκινο.
Ελέγξτε αν το Ιnternet λειτουργεί σωστά στα διαθέσιμα κομπιούτερ.
Ελέγξτε αν έχετε εκτελέσει και ολοκληρώσει την διαδικασία εγκατάστασης του
software. Στην αντίθετη περίπτωση εγκαταστήστε και πάλι το software. Το LED της
συσκευής DWA-140 θα πρέπει να ανάψει μετά την εγκατάσταση του software.
4. Ποια λειτουργικά συστήματα υποστηρίζει η συσκευή DWA-140;
Η συσκευή DWA-645 υποστηρίζει όλα τα πιο γνωστά λειτουργικά συστήματα,
συμπεριλαμβανόμενα Microsoft Windows XP(64/32 bit)/2000.
Σημείωση: αν δεν καταφέρνετε να εγκαθιδρύσετε μια σύνδεση, συμβουλευτείτε
το κεφάλαιο Διόρθωση λαθών του εγχειριδίου χρήστη που περιέχει το CD του
αντάπτορα RangeBooster N D-Link DWA-140
Τεχνική υποστήριξη
Ευχαριστούμε που διαλέξατε τα προϊόντα της D-Link. Για περισσότερες πληροφορίες ή
για να έχετε τεχνική υποστήριξη, driver και εγχειρίδια, επισκεφτείτε το site D-Link στην
διεύθυνση www.dlink.eu.
http://www.dlink.gr
Warranty
Subject to the terms and conditions set forth herein, D-Link
Systems, Inc. (“D-Link”) provides this Limited Warranty:
• Only to the person or entity that originally purchased the
product from D-Link or its authorized reseller or distributor, and
• Only for products purchased and delivered within the fifty
states of the United States, the District of Columbia, U.S.
Possessions or Protectorates, U.S. Military Installations, or
addresses with an APO or FPO.
Limited Warranty:
D-Link warrants that the hardware portion of the D-Link product
described below (“Hardware”) will be free from material defects in
workmanship and materials under normal use from the date of
original retail purchase of the product, for the period set forth below
(“Warranty Period”), except as otherwise stated herein.
• Hardware (excluding power supplies and fans): One (1) year
• Power supplies and fans: One (1) year
• Spare parts and spare kits: Ninety (90) days
The customer’s sole and exclusive remedy and the entire liability of
D-Link and its suppliers under this Limited Warranty will be, at
D-Link’s option, to repair or replace the defective Hardware during
the Warranty Period at no charge to the original owner or to refund
the actual purchase price paid. Any repair or replacement will be
rendered by D-Link at an Authorized D-Link Service Office. The
replacement hardware need not be new or have an identical make,
model or part. D-Link may, at its option, replace the defective
Hardware or any part thereof with any reconditioned product that
D-Link reasonably determines is substantially equivalent (or
superior) in all material respects to the defective Hardware.
Repaired or replacement hardware will be warranted for the
remainder of the original Warranty Period or ninety (90) days,
whichever is longer, and is subject to the same limitations and
exclusions. If a material defect is incapable of correction, or if
D-Link determines that it is not practical to repair or replace the
defective Hardware, the actual price paid by the original purchaser
for the defective Hardware will be refunded by D-Link upon return to
D-Link of the defective Hardware. All Hardware or part thereof that
is replaced by D-Link, or for which the purchase price is refunded,
shall become the property of D-Link upon replacement or refund.
Limited Software Warranty:
D-Link warrants that the software portion of the product (“Software”)
will substantially conform to D-Link’s then current functional
specifications for the Software, as set forth in the applicable
documentation, from the date of original retail purchase of the
Software for a period of ninety (90) days (“Software Warranty
Period”), provided that the Software is properly installed on
approved hardware and operated as contemplated in its
documentation. D-Link further warrants that, during the Software
Warranty Period, the magnetic media on which D-Link delivers the
Software will be free of physical defects. The customer’s sole and
exclusive remedy and the entire liability of D-Link and its suppliers
under this Limited Warranty will be, at D-Link’s option, to replace
the non-conforming Software (or defective media) with software
that substantially conforms to D-Link’s functional specifications for
the Software or to refund the portion of the actual purchase price
paid that is attributable to the Software. Except as otherwise agreed
by DLink in writing, the replacement Software is provided only to the
original licensee, and is subject to the terms and conditions of the
license granted by D-Link for the Software. Replacement Software
will be warranted for the remainder of the original Warranty Period
and is subject to the same limitations and exclusions. If a material
non-conformance is incapable of correction, or if D-Link determines
in its sole discretion that it is not practical to replace the
nonconforming Software, the price paid by the original licensee for
the non-conforming Software will be refunded by D-Link; provided
that the non-conforming Software (and all copies thereof) is first
returned to D-Link. The license granted respecting any Software for
which a refund is given automatically terminates.
Non-Applicability of Warranty:
The Limited Warranty provided hereunder for Hardware and
Software portions of D-Link’s products will not be applied to and
does not cover any refurbished product and any product purchased
through the inventory clearance or liquidation sale or other sales in
which D-Link, the sellers, or the liquidators expressly disclaim their
warranty obligation pertaining to the product and in that case, the
product is being sold “As-Is” without any warranty whatsoever
including, without limitation, the Limited Warranty as described
herein, notwithstanding anything stated herein to the contrary.
Submitting A Claim:
The customer shall return the product to the original purchase point
based on its return policy. In case the return policy period has
expired and the product is within warranty, the customer shall
submit a claim to D-Link as outlined below:
• The customer must submit with the product as part of the
claim a written description of the Hardware defect or Software
nonconformance in sufficient detail to allow DLink to confirm
the same, along with proof of purchase of the product (such as
a copy of the dated purchase invoice for the product) if the
product is not registered.
• The customer must obtain a Case ID Number from D-Link
Technical Support at 1-877-453-5465, who will attempt to
assist the customer in resolving any suspected defects with
the product. If the product is considered defective, the
customer must obtain a Return Material Authorization (“RMA”)
number by completing the RMA form and entering the
assigned Case ID
• After an RMA number is issued, the defective product must be
packaged securely in the original or other suitable shipping
package to ensure that it will not be damaged in transit, and
the RMA number must be prominently marked on the outside
of the package. Do not include any manuals or accessories in
the shipping package. DLink will only replace the defective
portion of the product and will not ship back any accessories.
• The customer is responsible for all in-bound shipping charges
to D-Link. No Cash on Delivery (“COD”) is allowed. Products
sent COD will either be rejected by D-Link or become the
property of D-Link. Products shall be fully insured by the
customer and shipped to D-Link Systems, Inc., 17595 Mt.
Herrmann, Fountain Valley, CA 92708. D-Link will not be held
responsible for any packages that are lost in transit to D-Link.
The repaired or replaced packages will be shipped to the
customer via UPS Ground or any common carrier selected by
D-Link. Return shipping charges shall be prepaid by D-Link if
you use an address in the United States, otherwise we will
ship the product to you freight collect. Expedited shipping is
available upon request and provided shipping charges are
prepaid by the customer. D-Link may reject or return any
product that is not packaged and shipped in strict compliance
with the foregoing requirements, or for which an RMA number
is not visible from the outside of the package. The product
owner agrees to pay D-Link’s reasonable handling and return
shipping charges for any product that is not packaged and
shipped in accordance with the foregoing requirements, or
that is determined by D-Link not to be defective or
non-conforming.
What Is Not Covered:
The Limited Warranty provided herein by D-Link does not cover:
Products that, in D-Link’s judgment, have been subjected to abuse,
accident, alteration, modification, tampering, negligence, misuse,
faulty installation, lack of reasonable care, repair or service in any
way that is not contemplated in the documentation for the product,
or if the model or serial number has been altered, tampered with,
defaced or removed; Initial installation, installation and removal of
the product for repair, and shipping costs; Operational adjustments
covered in the operating manual for the product, and normal
maintenance; Damage that occurs in shipment, due to act of God,
failures due to power surge, and cosmetic damage; Any hardware,
software, firmware or other products or services provided by
anyone other than D-Link; and Products that have been purchased
from inventory clearance or liquidation sales or other sales in which
D-Link, the sellers, or the liquidators expressly disclaim their
warranty obligation pertaining to the product.
While necessary maintenance or repairs on your Product can be
performed by any company, we recommend that you use only an
Authorized D-Link Service Office. Improper or incorrectly performed
maintenance or repair voids this Limited Warranty.
Disclaimer of Other Warranties:
EXCEPT FOR THE LIMITED WARRANTY SPECIFIED HEREIN,
THE PRODUCT IS PROVIDED “AS-IS” WITHOUT ANY
WARRANTY OF ANY KIND WHATSOEVER INCLUDING,
WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE
AND NONINFRINGEMENT.
IF ANY IMPLIED WARRANTY CANNOT BE DISCLAIMED IN ANY
TERRITORY WHERE A PRODUCT IS SOLD, THE DURATION OF
SUCH IMPLIED WARRANTY SHALL BE LIMITED TO THE
DURATION OF THE APPLICABLE WARRANTY PERIOD SET
FORTH ABOVE. EXCEPT AS EXPRESSLY COVERED UNDER
THE LIMITED WARRANTY PROVIDED HEREIN, THE ENTIRE
RISK AS TO THE QUALITY, SELECTION AND PERFORMANCE
OF THE PRODUCT IS WITH THE PURCHASER OF THE
PRODUCT.
Limitation of Liability:
TO THE MAXIMUM EXTENT PERMITTED BY LAW, D-LINK IS
NOT LIABLE UNDER ANY CONTRACT, NEGLIGENCE, STRICT
LIABILITY OR OTHER LEGAL OR EQUITABLE THEORY FOR
ANY LOSS OF USE OF THE PRODUCT, INCONVENIENCE OR
DAMAGES OF ANY CHARACTER, WHETHER DIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT NOT
LIMITED TO, DAMAGES FOR LOSS OF GOODWILL, LOSS OF
REVENUE OR PROFIT, WORK STOPPAGE, COMPUTER
FAILURE OR MALFUNCTION, FAILURE OF OTHER
EQUIPMENT OR COMPUTER PROGRAMS TO WHICH D-LINK’S
PRODUCT IS CONNECTED WITH, LOSS OF INFORMATION OR
DATA CONTAINED IN, STORED ON, OR INTEGRATED WITH
ANY PRODUCT RETURNED TO D-LINK FOR WARRANTY
SERVICE) RESULTING FROM THE USE OF THE PRODUCT,
RELATING TO WARRANTY SERVICE, OR ARISING OUT OF
ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK
HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE
FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT
OR REFUND OF THE DEFECTIVE OR NONCONFORMING
PRODUCT. THE MAXIMUM LIABILITY OF D-LINK UNDER THIS
WARRANTY IS LIMITED TO THE PURCHASE PRICE OF THE
PRODUCT COVERED BY THE WARRANTY. THE FOREGOING
EXPRESS WRITTEN WARRANTIES AND REMEDIES ARE
EXCLUSIVE AND ARE IN LIEU OF ANY OTHER WARRANTIES
OR REMEDIES, EXPRESS, IMPLIED OR STATUTORY.
Governing Law:
This Limited Warranty shall be governed by the laws of the State of
California. Some states do not allow exclusion or limitation of
incidental or consequential damages, or limitations on how long an
implied warranty lasts, so the foregoing limitations and exclusions
may not apply. This Limited Warranty provides specific legal rights
and you may also have other rights which vary from state to state.
Trademarks:
D-Link is a registered trademark of D-Link Corporation/D-Link
Systems, Inc. Other trademarks or registered trademarks are the
property of their respective owners.
Copyright Statement:
No part of this publication or documentation accompanying this
product may be reproduced in any form or by any means or used to
make any derivative such as translation, transformation, or
adaptation without permission from D-Link Corporation/D-Link
Systems, Inc., as stipulated by the United States Copyright Act of
1976 and any amendments thereto. Contents are subject to change
without prior notice.
Copyright 2007 by D-Link Corporation/D-Link Systems, Inc. All
rights reserved.
CE Mark Warning:
This is a Class B product. In a domestic environment, this product
may cause radio interference, in which case the user may be
required to take adequate measures.
FCC Statement:
This device has been tested for compliance with FCC RF
Exposure (SAR) limits in the typical laptop computer
configuration and this device can be used in desktop or laptop
computers with side mounted USB ports which can provide 2
cm separation distance from the antenna to the body of the user
or a nearby person. This device cannot be used with handheld
PDAs (personal digital assistants). This device and its antenna
must not be co-located or operated in conjunction with any other
antenna or transmitter.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution:
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this equipment.
Industry Canada Notice:
This device complies with Canadian RSS-210
“This Class B digital apparatus complies with Candadian ICES-003”
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
IC statement
Operation is subject to the following two conditions:
(1)This device may not cause interference and
(2)This device must accept any interference, including interference
that may cause undesired operation of the device.
This device has been designed to operate with an antenna having a
maximum gain of 2.12 dBi. Antenna having a higher gain is strictly
prohibited per regulations of Industry Canada. The required
antenna impedance is 50 ohms.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth
for an uncontrolled environment. End users must follow the specific
operating instructions for satisfying RF exposure compliance.
This EUT is compliance with SAR for general
population/uncontrolled exposure limits in IC RSS-102 and had
been tested in accordance with the measurement methods and
procedures specified in IEEE 1528. This equipment should be
installed and operated with minimum distance 1.5cm between the
radiator & your body.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
For products available in the USA/Canada market, only channel
1~11 can be operated. Selection of other channels is not possible.
Règlement dIndustry Canada
Les conditions de fonctionnement sont sujettes à deux conditions:
(1)Ce périphérique ne doit pas causer d’interférence et.
(2)Ce périphérique doit accepter toute interférence, y compris les
interférences pouvant perturber le bon fonctionnement de ce
périphérique.
32
Ver. 1.10 (E)
2007/03/02

Navigation menu
