User Manual
General Specification
FS-SSTB
User Guide
TANDBERG
General Specification
INFORMATION TO USER :
General Specification
TABLE OF CONTENTS
1. Product Drawing------- ------------------------------------------------------------------------------1
2. Front Specification --------------------------------------------------------------------------------2
3. Connector Specification----------------------------------------2
4. Signal Connector Pin Assignments------------------------------------------------------------3
General Specification
1. Product Drawing
Unit : mm
1
General Specification
2. Front Specification
PC
2
PC
MENU
3. Connector Specification
Data
Port 1
Data
Port 2
Operating sequence
1. Make sure that SSTB is connected to console.
2. Supply DC power through FSP040-1ADF03A AC/DC adaptor.
3. Touch any button and you can see that LED is lighting.
General Specification
4. Signal Connector Pin Assignments
3
Ground5
4
3
2
1
Pin No.
DTRIN612V Power
RTSIN8RXD
No Connection9DSRIN
CTSIN7TXD
AssignmentPin No.Assignment
1. Data Port 1 (D-Sub 9Pin)
2. Data Port 2 (D-Sub 9Pin)
Ground5
4
3
2
1
Pin No.
DSR612V Power
CTS8LTXD
No Connection9DTR
RTS7LRXD
AssignmentPin No.Assignment
15
69
51
96
