DAZA Electronics SP-25BT Bluetooth Speaker User Manual SP 25BT
DAZA Electronics Company Bluetooth Speaker SP 25BT
Users Manual
SP-25BT stereo Mini-Speaker User Manual
Thank you for using our BT speaker! This unit provides rich quality sound in
order to provide you with a good experience. Please read this User Manual
before using this product. Thank you so much for attention.
Features:
1. Bluetooth communication and Bluetooh music.
2. AUX in function.
3. Charging fuction
Operation:
1. Bluetooth Pairing
This device is built-in battery. Press and hold on button for 4-5 seconds
to start the device.
The BLUE light will into quick flash, then it will default into the same
connection with last time. If the reconnection is failed, it will enter into New
pairing model with the blue and green light flash in turn.
Use your mobile phone to search the device”…..”. If a password is needed,
pls input”0000”. Wait for 3-5 seconds, the pairing is successful with the BLUE
light keeps bright, while the GREEN light turns out.
Then you can press and hold on button for 3-4 seconds to turn off the
device,
2. Bluetooth Music
Start your mobile phone’s media player and choose your favorite song,
then you will hear the nice music from the Mini-Speake with the BLUE light in
slow flash.
When you want to change the song, pressing “ ” button to pick the next
song, and pressing “ ” button to pick the previous song.
When you want to adjust volume, press and hold the “ ” button to
increase the volume, press and hold the “ ” button to reduce the volume.
Press button to pause or play the music.
3. AUX in function:
Connect the device’s audio cable with computer’s (or other audio devices )
output interface“ ”, while keep the other end into the AUX in port. This
device will enter into Line in model automatically with the BLUE light on.
4. Charging function:
when the machine is out of power with the GREEN light in quick flash,
please insert the charging cable into the “DC-5V IN” interface, Connect the
other USB end with the computer (or charger).
When charging, the RED light keeps bright. When it is full, it will turn off
automatically.
Notes:
1. When the GREEN light is in quick flash, please charge for the device in
time, or it will turn off automatically,
2. When this device has connected with the your mobile phone or in Bluetooth
Music model, you can charging for it with charging cable. But if you pull the
charging cable out, the device will turn off automatically.
Product parameters:
Charging voltage: DC-5V
Charging current: 1-2A(Max)
Working voltage: 3.7-4.2V
Product Power: 200MA
Battery capacity: 500MAH
Working hours: 3H(based on 80% Volume)
Speaker impedance: 4Ω 3W *2
Speaker distortion: ±5%MAX
Frequency distortion: <1%
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure requirement. The device can
be used in portable exposure condition without RF striction
