User Manual
User Manual
-I-
Contents
1.Getting to know your phone..................... 1
1.1 Your Phone..........................................1
1.2 Status icons..........................................1
1.3 Installing SIM card and battery.............1
1.4 Installing Storage card..........................1
1.5 Battery charging...................................2
1.6 Power on/ off.......................................2
1.6.1 Power on .......................................2
1.6.2 Power off.......................................2
1.7 Using shortcut keys..............................2
2.Using Call Function .................................3
2.1 Making a call.......................................3
2.2 Answering or rejecting a call ................3
2.2.1 Answer a call .................................3
2.2.2 Reject a call...................................3
2.3 Adjusting call volume...........................3
2.4 Ending a call........................................3
3.Contacts ...................................................3
3.1 View a contact .....................................3
3.2 Adding a new contact...........................3
4.Call logs....................................................4
4.1 Dialed calls..........................................4
4.2 Received calls......................................4
4.3 Missed calls.........................................4
4.4 Rejected calls.......................................4
4.5 Delete all.............................................4
4.6 Call timers ...........................................4
4.7 Call cost ..............................................4
4.8 GPRS counter......................................4
5.Message....................................................4
5.1 Write message......................................4
5.1.1 New SMS......................................4
5.1.2 New MMS.....................................5
5.2 Inbox...................................................5
5.3 Outbox ................................................5
5.4 Drafts ..................................................5
5.5 Sentbox ...............................................5
5.6 Message setting....................................5
5.6.1 Templates ......................................5
5.6.2 Voice mail server............................5
5.6.3 Broadcast message.........................6
5.6.4 Settings..........................................6
5.6.5 Message capacity...........................6
6.Application...............................................7
6.1 MSN ...................................................7
6.2 Facebook.............................................7
6.3 Yahoo..................................................7
6.4 Twitter.................................................7
-II-
6.5 Sokoban.............................................. 7
7.Profiles..................................................... 7
7.1 Normal................................................ 7
7.2 Silent .................................................. 7
7.3 Meeting............................................... 7
7.4 Indoor ................................................. 7
7.5 Outdoor............................................... 7
8.Multimedia .............................................. 7
8.1 Camera ............................................... 7
8.2 Audio player........................................ 7
8.2.1 Background audio player ............... 8
8.3 Video player........................................ 8
8.4 Image browser..................................... 8
8.5 Recorder ............................................. 8
8.6 FM radio............................................. 8
9.Tools......................................................... 8
9.1 Alarm.................................................. 8
9.2 Bluetooth ............................................ 9
9.3 eBook ................................................. 9
9.4 Calendar ............................................. 9
9.5 Calculator ........................................... 9
9.6 World clock......................................... 9
10.File management ................................... 9
11.Settings..................................................10
11.1 Dual-SIM .........................................10
11.2 Call settings......................................10
11.2.1 Network selection.......................10
11.2.2 Call divert ..................................10
11.2.3 Call barred..................................10
11.2.4 Call waiting................................10
11.2.5 Hide ID ......................................11
11.2.6 Select line...................................11
11.2.7 Flight mode................................11
11.2.8 Others ........................................11
11.3 Phone settings...................................12
11.3.1 SOS number...............................12
11.3.2 Time & date................................12
11.3.3 Select language...........................12
11.3.4 Shortcut settings .........................12
11.3.5 Auto power on/off.......................12
11.3.6 Power management.....................12
11.3.7 Restore factory settings...............12
11.4 Display settings ................................12
11.4.1 Wallpaper settings.......................12
11.4.2 Contrast......................................12
11.4.3 Backlight....................................12
11.4.4 Keypad backlight time................12
11.4.5 Animation effect .........................12
11.5 Security settings ...............................13
11.5.1 PIN ............................................13
-III-
11.5.2 PIN2..........................................14
11.5.3 Privacy ......................................14
11.5.4 Auto keypad lock ....................... 14
11.5.5 Lock screen by end- key............. 15
11.5.6 Power-on password .................... 15
11.5.7 Guardlock.................................. 15
11.6 Connection management................... 17
11.6.1 Network account ........................ 17
12.Internet.................................................17
13.Safety Precaution ................................. 17
13.1 Usage environment ..........................17
13.2 Medical devices ............................... 18
13.2.1 Pacemaker .................................18
13.2.2 Hearing aids...............................19
13.2.3 Emergency calls.........................19
13.3 Password access...............................19
13.3.1 Phone password .........................19
13.3.2 PIN code....................................20
13.3.3 PIN2 code..................................20
13.3.4 PUK code ..................................20
13.3.5 PUK2 code ................................ 20
13.4 Cautions for battery charging............ 21
13.5 Cautions for battery usage ................ 21
13.6 Cautions for spare parts usage........... 23
13.7 Other safety information................... 23
-1-
1. Getting to know your phone
1.1 Your Phone
1.2 Status icons
Icon Function description
Represent current SIM1 and
SIM2 network signal. The more
bars, the stronger the signal
Flight mode
Battery status, more bars
indicate more battery capacity
left
Unread SMS
Clock has set
Bluetooth function is activated
Profile has set as Silent Mode
Profile has set as Meeting Mode
Profile has set as Indoor Mode
Profile has set as Outdoor Mode
1.3 Installing SIM card and battery
(1) Hold on 【End Key】 for about three
seconds to switch off the phone.
(2) Remove the battery cover.
(3) Remove the battery.
(4) Follow the sign for SIM1 and SIM2 on
the phone to install SIM1 and SIM2.
Please make sure that the golden contacts
of the card face into the phone and the
notched corner has the same direction
with the card slot, then push the other side
of the card gently until it fixes itself in the
card slot.
(5) Replace the battery with its golden
contact part facing the set phone battery
contact piece, and then replace the battery
cover.
1.4 Installing Storage card
(1) Hold on 【End Key】 for about three
seconds to switch off the phone.
-2-
(2) Remove the battery cover.
(3) Remove the battery.
(4) Follow the arrow direction of "OPEN" on
the T-Card slot cover, open card slot
cover, put the T-Card into the slot
vertically, make sure that the gold
contacts of the card face upwards, until
the card fixes itself in the card slot.
(5) Follow the arrow direction of "LOCK" on
the T-Card slot cover, pull card slot cover
to lock the card slot.
1.5 Battery charging
Charged by the travel charger
(1) Install the battery correctly into the
phone.
(2) Insert the lead of the travel charger to
connecting slot of the phone, and then
connect the charger to a standard power
socket.
When charging is complete, unplug the
charger from the standard power socket first,
and then disconnect the phone and charger.
1.6 Power on/ off
1.6.1 Power on
Hold on【End Key】for three seconds to
switch on the phone.
1.6.2 Power off
Hold on 【End Key】for three seconds to
switch off the phone.
Warning:
Don’t switch the phone on in areas where
wireless phone usage is prohibited or
where it may cause interference or danger,
and also make sure that you haven’t
activated the function “Auto power
on/off”.
1.7 Using shortcut keys
Pressing some keys directly from the Home
Screen provides direct access to common
-3-
phone functions.
Key Operation
Function
Call
key
press
briefly
Enter Call History
1 Key
hold on Enter voicemail
box for SIM1 or
SIM2
2. Using Call Function
2.1 Making a call
(1) On the Home Screen, input the area code
and phone number.
(2) Select <Options→Call→Voice
call→SIM1/SIM2 > to select SIM1 or
SIM2 to call.
2.2 Answering or rejecting a call
2.2.1 Answer a call
When there is an incoming call, you can press
【Call Key】to answer.
2.2.2 Reject a call
When there is an incoming call, you can press
【End Key】to reject it.
2.3 Adjusting call volume
During a call, you can press 【Navigation
Key】 to adjust the earphone volume.
2.4 Ending a call
Press 【End Key】 to end the call.
3. Contacts
3.1 View a contact
Enter the phonebook, the phone is defaulted
to show contact list with all entries. Press
【Left Key/Right Key】to switch between
different groups.
3.2 Adding a new contact
On the Contacts list,
select<Options→New>to create a new
contact.
Phone: You can input the contact name,
mobile phone, home phone, etc. You can
-4-
also set special image and ring for the
contact entry.
SIM1: The input record will be saved to
SIM1, with each name one phone number.
SIM2: The input record will be saved to
SIM2, with each name one phone number.
4. Call logs
Enter the main menu, and then select [Call
logs] to enter the call list.
4.1 Dialed calls
Display recent calls dialed.
4.2 Received calls
Display recent calls received.
4.3 Missed calls
Display recent calls unpicked up.
4.4 Rejected calls
Display recent calls rejected.
4.5 Delete all
Delete all the call entries.
4.6 Call timers
Select the desired SIM Card, and then you
can view all relevant information about the
SIM Card.
4.7 Call cost (need the network support)
Total cost: Record total call charges for
SIM1 and SIM2.
Max cost: You can set the desired upper
limit for call costs.
Price per unit: Record the cost rate for
SIM1 and SIM2.
Reset cost: Reset the total call charges as
zero.
4.8 GPRS counter
You can view the detail about GPRS flowrate.
5. Message
5.1 Write message
5.1.1 New SMS
On the Home Screen, press【Left Soft Key】
and select [Message→Write message→New
SMS] to edit a new SMS directly.
-5-
After writing an SMS, click <Send> to send
the message.
5.1.2 New MMS
On the Home Screen, press【Left Soft Key】
and select [Message→Write message→New
MMS] to create a new MMS.
5.2 Inbox
Store all received SMS and MMS.
5.3 Outbox
Store all SMS and MMS failed to be sent.
5.4 Drafts
Save edited SMS and MMS haven’t sent.
5.5 Sentbox
Store all the SMS and MMS successfully sent
out. If you want the sent messages be saved
automatically, please select
[Message→Options], then select
[Settings→SMS→Save sent
messages→Save].
5.6 Message setting
On the Home Screen, press【Left Soft Key】
to enter the main menu, then select
[Message→Options] to enter the message
setting menu.
5.6.1 Templates
While editing messages, you can directly cite
the preset common phrases. Select <Edit> to
set the common phrases by yourselves.
5.6.2 Voice mail server
This function works like an answering
machine, which can transfer a missed call to
your personal voice mail, allowing the caller
to leave a voice message and notify you by an
SMS. Voice Mail is a part of the bundled
software provided by network operator,
therefore, you need to register to active this
function, and manually set the phone. Please
contact with your network operator for more
details.
Caution：
It’s workable to transfer the voice call
into the voice mail (The number the call
will leave a message) by setting “Divert
calls”.
-6-
5.6.3 Broadcast message
You can receive broadcast text messages with
various contents via network service, such as
news, weather or traffic information. For
more details, please consult your network
operator.
5.6.4 Settings
SMS
SIM1 msg center: While sending
messages, you must set the service
center number provided by network
operator. Most SIM cards defaulted
contain the service center number. You
can also gain this number directly from
the network operator.
If you modify or delete the service center
number, an SMS might not be sent
successfully.
SIM2 msg center: Please refer to
[SIM1 msg center].
Message validity period: Allows you to
set the length of time during which your
SMS will be stored in the message
center. The validity period depends on
the network operator.
Status report: Select [On], then the text
message center will inform you when
you successfully sent a message.
Save sent messages: You can select
whether to save the sent message or not.
Preferred storage: You can select to
save the SMS to the SIM card or the
phone first.
MMS
Broadcast message
5.6.5 Message capacity
You can view memory capacity status for
SMS and MMS via this function.
-7-
6. Application
6.1 MSN
6.2 Facebook
6.3 Yahoo
6.4 Twitter
6.5 Sokoban
Push all the boxes to the destination ,
then you can go to the next game level, press
【Navigation Key】 to move the snail.
7. Profiles
7.1 Normal
Activate: Activate the chosen profile.
Customize: Set the options as required.
Rename: Modify the name of the selected
profile.
7.2 Silent
For the settings, please refer to”Normal”.
7.3 Meeting
For the settings, please refer to”Normal”.
7.4 Indoor
For the settings, please refer to”Normal”.
7.5 Outdoor
For the settings, please refer to”Normal”.
8. Multimedia
8.1 Camera
Enter the main menu, and select
[Multimedia→Camera] to enter the camera
preview screen, press 【OK Key】to take a
photo.
8.2 Audio player
On Home Screen, press 【Left Soft Key】 to
enter the main menu, and select
[Multimedia→Audio player] to enter the
Audio Player screen.
Press【OK Key】to play or pause
Press【Left/Right Key】to skip to last /next
one
Press 【Up/Down Key 】to adjust the
volume
-8-
8.2.1 Background audio player
While playing a song, press 【End Key】to
quit the Playing screen to enter the
background playing mode.
8.3 Video player
Enter the Main menu, and select
[Multimedia→Video player].
Press【OK Key】to play or pause
Press【Left/Right Key】to skip to last /next
one
Press 【Up/Down Key 】to adjust the
volume
8.4 Image browser
The function provides a prompt access to
view the photos and pictures.
8.5 Recorder
On Home Screen, press 【Left Soft Key】to
enter the main menu, select
[Multimedia→Recorder], and choose
<Options→Start recording > to start
recording. Select <Pause> to have the
recording pause for a while, select <Stop> to
cease recording. After ceasing the recording,
the recorded file will be automatically save in
the folder [Audio], select <Options→Record
file list> to check.
8.6 FM radio
On standby mode, enter the Main menu, then
select [[Multimedia→FM radio].
Press【Down Key】to activate or deactivate
the radio
Press 【Left/Right Key 】to adjust the
frequency
Press【*/# Key】to adjust the volume
9. Tools
9.1 Alarm
On the Home Screen, press【Left Soft Key】
to enter the main menu, and select
[Tools→Alarm], then you can set the alarm
name, time, ring and mode.
-9-
9.2 Bluetooth
Open/Close Bluetooth: This function
allows you to switch the Bluetooth on or
off.
Bluetooth visibility: Set to show or hide
the Bluetooth of your phone. If you select
to hide the phone, other devices cannot
detect the Bluetooth device of your phone,
even you activated your Bluetooth
function.
Paired device: You can search for the
nearby Bluetooth-enabled devices.
My bluetooth name: If Bluetooth
function activated, while other devices
search for Bluetooth signal, the
corresponding name represents your
phone.
Bluetooth file storage: Able to set the
storage location for files received via
Bluetooth.
9.3 eBook
You can view file in TXT format by Ebook
and copy the TXT file to the [Ebook] folder
in the memory card from your PC.
On the Home Screen, press【Left Soft Key】
to enter the main menu and select
[Tools→eBook] to enter the Ebook screen
you read last time. Select <Back> to enter the
Ebook list and reselect the desired file to
read.
9.4 Calendar
Enter the main menu, and select
[Tools→Calendar] to enter the Calendar
screen.
9.5 Calculator
Directly input numbers, press【Navigation
Key 】 to select your desired operation
symbols (+, -, /, X). Press 【OK Key】 to get
the answer.
9.6 World clock
This function allows you to check the
standard time in different areas of the world.
10. File management
This menu allows you to manage files stored
in the phone or storage card.
-10-
11. Settings
11.1 Dual-SIM
Standby mode: You can select the
standby mode for SIM card, either to have
one SIM card standby, or to have both
SIM cards standby simultaneously.
Reply by original SIM: You can activate
the function to reply from current SIM
card for call, SMS and MMS.
Set SIM name: You can name the Card as
you want.
11.2 Call settings
11.2.1 Network selection
Auto select: The phone can automatically
search and register available networks.
Manual select: Enable this function, the
phone will search for the network, and list
all searched networks, then you need to
choose the one needed to register.
11.2.2 Call divert
Based the set diverting conditions, incoming
calls will be forwarded into voice mail or
other numbers.
11.2.3 Call barred
This function helps you to restrict the
incoming and outgoing calls.
Select the desired call and press <OK>, then
you can select [Activated], [Off] or [Query
status]. Select [Activated], the phone will
need network support current setting.
Caution：
1． Some network operators forbid the
function. For more details, please contact
your network service provider.
2. The network operator will provide you
the initial network password while you
apply for this service.
11.2.4 Call waiting (Need network support)
Activated: If you set the function on, the
network will alert you that there is an
incoming call. You can keep current call
and answer another one.
-11-
Off: Cancel call waiting function, then the
new incoming calls won’t be answered
while you’re on the phone already.
Query status: Select it to view current
status of this function.
11.2.5 Hide ID (Need network support)
Hide ID: While calling, the recipient
won’t see your phone number.
Display own ID: While calling, your
phone number will be visible for the
recipient.
Display ID by network: While calling,
whether your phone number will be visible
or not for the receiver depends on the
network presetting.
11.2.6 Select line
You can choose Line 1 or Line 2 as you need.
11.2.7 Flight mode
Activate: Activate flight mode, then all
network service won’t be available.
Select when power on: You can select
whether to activate flight mode when
power on.
11.2.8 Others
IP shortcut key
After activating this function, selecting
<Options→Call→IP call>, then preset IP
number will be automatically added before
the number you want to dial and call via it.
50 secs warning
If you activate the function, an elapsed time
reminder will be heard at the 50th second of
every minute during your call, so that you
may end the call timely to save the phone
fare.
Vibration when connected
The phone will vibrate to prompt you when
the recipient answers your phone.
Answer/Reject mode
Reply SMS after reject: You can select
whether to reply an SMS after rejecting
a call.
-12-
Auto redial
If you set this function on, the phone will
redial the number after an unsuccessful call,
11.3 Phone settings
11.3.1 SOS number
You can set SOS number.
11.3.2 Time & date
Set time: Directly input the time or press
【Up /Down Key】to set it.
Set date: Directly input the date or press
【Up /Down Key】to set it.
11.3.3 Select language
You can select the language you want.
11.3.4 Shortcut settings
You can change the responsible shortcuts for
【Navigation Key】under standby mode.
11.3.5 Auto power on/off
You can set the phone to switch on/off at a
scheduled time.
11.3.6 Power management
Display the battery capacity.
11.3.7 Restore factory settings
Reset all parameter values into default status.
Please enter the privacy preserving password
(Initial password is 1234) to resume factory
setting.
11.4 Display settings
11.4.1 Wallpaper settings
Select the default or other pictures as the
wallpaper of the phone.
11.4.2 Contrast
Press 【Left /Right Key 】to adjust the
contrast.
11.4.3 Backlight
Select the desired backlight time.
11.4.4 Keypad backlight time
Select the desired keypad light time.
11.4.5 Animation effect
Power on display: You can select the
preset animation or others as the Power on
animation for your phone.
-13-
Power off display: You can select the
preset animation or others as the Power off
animation for your phone.
11.5 Security settings
In order to secure the information, you can set
PIN code, PIN2 code and power-on
password.
11.5.1 PIN
PIN code is the personal identification
number for SIM card. If never be modified,
the initial password set by network operator
should be 1234 or 0000. If activated the
power-on PIN code, then you have to input
the PIN password each time you switch the
phone on. You can modify the PIN code to
prevent your SIM card being used by others.
Caution：
If you input your PIN code incorrectly
three times in succession, the SIM card
will be locked automatically, and
prompting to enter PUK code to unlock it.
Therefore, please do remember the PIN
code, if you modify it.
PUK code (PUK1) is made up by 8 digits,
unmodifiable. When the phone is locked by
PIN code, please enter correct PUK code to
unlock the phone. If you incorrectly input the
PUK code ten times in succession, then the
SIM card cannot be used any more. Some
PUK codes are provided together with the
SIM card, some should be gained from the
network service provider. If you don’t know
the PUK code while your PIN code is locked,
please never input the code casually. In this
case, please call the hotline of the service
provider for your SIM card, after simply
checking about the user identity, you can gain
the PUK code for free to unlock your phone.
Caution：
Please be careful when use this function.
If you forget PUK code, please consult
your network operator. If you incorrectly
input the PUK code ten times in
succession, the SIM card will be scrap.
-14-
Select the desired SIM type and have the
following options:
Activated: You should input PIN code
each time switching the phone on.
Modify: You should activate PIN code
before modifying it.
Off: You should input the correct PIN
code before deactivating it.
11.5.2 PIN2
PIN2 code is the personal identification code
required for some certain functions (such as
set fixed number, set phone fare, etc).
PIN2 code is another password provided
together with SIM card by service provider. If
wrongly input it for three times in succession,
the phone will be locked until correct PUK2
code entered, for detailed operation, please
refer to PIN code and PUK code.
Caution：
If you incorrectly input the PUK2 code
ten times in succession, you will not be
able to use SIM card. Please be careful
when use this function.
11.5.3 Privacy
Secured by phone password, the phone will
be protected from other unauthorized users.
When password function has been activated
for call logs or message, you have to enter
correct password on corresponding main
menu or sub-menu. The defaulted password is
“1234”.
11.5.4 Auto keypad lock
After activating this function, the phone will
be locked automatically if the time you set is
arrived, so as to avoid error operations.
Manual lock keypad: On the Home
screen, press 【Left Soft Key】, then press
【* Key】 to lock the keypad manually.
Manual unlock keypad: On the Home
screen, press【Left Soft Key】, then press
【* Key】 to unlock the keypad manually.
-15-
11.5.5 Lock screen by end- key
Once activated this function, when the
backlight is on, press【End Key】to turn off the
backlight and auto lock the keypad.
11.5.6 Power-on password
You should set the power on password when
you use this function for the first time. After
activated this function, you should input
password each time you switch the phone on.
Caution:
Power-on password doesn’t have the
limitation for wrongly inputting. Please
remember carefully about the Power on
PWD, otherwise, the phone won’t be
switched on normally once password
forgotten.
11.5.7 Guardlock
Guardlock (MSD) is nicknamed as Mobile
Phone Dog. When others illegally use your
phone, information like CELLID of the phone
will be collected and sent to preset mobile
phone; moreover, the function will prevent
others to use the phone after certain times or
certain power-on times.
This function is defaulted to be off. To
activate it, please modify the password. Then
you need to enter the password if you want to
activate, deactivate, or modify the password
to process operation, and the password has 6
digits. To activate it, you have to enter a
preset mobile phone number (The mobile
phone number set to receive the message if
the phone is stolen) apart from the password.
After activated, the phone stores the IMSI
number for original SIM card, which is sole
and unique, if you insert another SIM card,
there will be a prompt, asking you to input
the guardlock password. If you wrongly enter
the password for three times in succession,
the phone will default it as illegal and display
a relevant prompt, then collect and send
information like CELLID, LAC, MCC, MNC,
MCN to preset mobile phone number. While
receiving this message, legal user can report it
to the police, who can inquire the illegal
-16-
usage situation (Including the used location,
call history, etc) from network operator via
the piece of information.
The message will be kept senting to the preset
mobile phone till it is successfully received.
If the stolen phone is on over 24 hours or
re-switch on, the phone will resend a message
to your preset phone number. When the
message has been successfully sent up to 15
times, any illegally used SIM card won’t
work in the stolen phone, which will
automatically switched off.
Caution:
Please report to the police timely if the
phone is stolen, but this doesn’t mean that
the lost phone will be definitely traced
back. Therefore, please take care of your
personal property.
If the phone defaults the SIM card inserted is
illegal, then guardlock function can not be
activated, and relevant setting can not work.
If another SIM card is inserted, enter correct
password, message count will be sent from
zero, meanwhile, there will be a prompt,
asking you whether to bind this SIM card.
Select binding, then the phone will renew the
IMSI number and default the SIM card as the
designated one.
Activated: Before activating this function,
please set the password first, if password
hasn’t been set, then please enter [Change
password] to finish the password setting
and back to activate this function. While
activating it, guardlock password and
notified mobile phone number (The
number to receive the information of the
SIM card illegally used in the stolen
phone) are required. After these,
guardlock function will work.
Off: To deactivate guardlock function, you
should input correct Guardlock password.
-17-
Change password: Modify guardlock
password.
Warning:
Please use this function carefully. The
phone won’t be used if password
forgotten.
11.6 Connection management
11.6.1 Network account
You can select the desired network account,
and add the desired account by yourself as
well.
12. Internet
On the Home screen, press【Left Soft Key】
and select [Internet].
SIM1: By selecting this option, your
mobile phone will directly visit the preset
or defaulted homepage.
SIM2: By selecting this option, your
mobile phone will directly visit the preset
or defaulted homepage.
Caution：
1．Your network service provider may not
support some functions. In order to
ensure the browser work normally, please
confirm first that your SIM card supports
and have the Internet function activated.
2. If you browse the web page, flowrate
fee will be charged.
13. Safety Precaution
13.1 Usage environment
Please remember to obey relevant rules and
regulations whenever use your phone. This
will prevent bad effect from you and the
environment.
Switch off your phone near explosive
places, such as gas station, bunkers,
-18-
chemical factories or blasting scene, and
adhere to any safety signs and instructions
there. Breaking any rules may cause
explosion or injury.
Phone using in plane will interfere with
the flight operation and bring dangers.
Therefore, please do switch off your
phone before boarding, and make sure it is
power off during the whole flight.
Please keep the phone in its special
bracket while you’re driving. Please don’t
put it on a seat or in places where it could
fall off when the car encounters collision
or break. In order to ensure safe driving
and avoid road accidents, please don’t use
the phone when driving. If you must use it,
please use the phone’s hands-free asset or
park at roadside before making or
answering a call.
Please put the phone away from the high
temperature environment, for explosion
might be caused when the battery is of
excess high temperature.
13.2 Medical devices
Please switch off your phone in areas near the
electronic medical equipments that obviously
requires switching the phone off (Such as
heart pacemakers, hearing aids, etc). Most
medical devices can shield the phone’s RF
signal, but some can’t. If you have any doubts
or need to find out more, please consult your
doctor or medical device manufacturer.
13.2.1 Pacemaker
Pacemaker manufacturers advise the distance
between your phone and heart pacemaker
should be 6 inches (15.3 cm) at least,
otherwise the phone could interfere with the
pacemaker.
The personnel who wears pacemaker
should do the followings:
Should always keep a distance (at lease 6
inches) between the phone and pacemaker,
when the phone is switched on.
Should not have the phone in a breast
pocket
-19-
Should listen to the phone closer to the ear
which is farther from the pacemaker.
Caution:
Please switch off your phone while you
feel there is interference, and consult the
doctor timely.
13.2.2 Hearing aids
Mobile phone might bring some interference
to some hearing aids. If so, please consult the
hearing aids manufacturer.
13.2.3 Emergency calls
As the phone uses a radio signal, wireless and
ground communication network and personal
settings functions like other phones, it is
impossible to ensure your phone can be
connected successfully in any situation, so
please don’t rely purely on your phone as the
only means of notification in cases of
emergency (such as medical first aid ).
Make an emergency call
If your phone is switched off, please turn on
your phone and check whether the network
signal is strong enough.
(1) Input the local first aid number correctly
(such as 120), different areas have
different first aid numbers.
(2) Please press the call key to call.
Caution:
While making an emergency call, you
should try best to provide all important
information precisely. At this time, the
phone may be the only communication
tool, so don’t end the call without
permission.
13.3 Password access
Your phone and SIM card can be protected by
a password to prevent others using them
illegally.
13.3.1 Phone password
This protects your phone from unauthorized
users. You can set the preset password when
-20-
you use it for the first time. After using it,
please modify your phone password as soon
as possible and keep it secret.
13.3.2 PIN code
This is personal identification code, which is
used to protect the SIM card from
unauthorized users. Generally, the PIN code
and SIM card will be provided together. After
activating the PIN code, you need to input
correct password each time you switch the
phone on to ensure normal usage.
Caution：
If you input your PIN code incorrectly for
three times in succession, the SIM card
will be locked. You need to enter the
PUK code to unlock it. (If you don’t have
a PUK code, please contact your network
operator or SIM card retailer for this
information. Please don’t input any
characters).
13.3.3 PIN2 code
This is the password for activating special
functions of the SIM card. You need to input
it while entering some functions (eg.Charge
Unit, Fixed Dialling etc). Usually, the PIN2
code and the SIM card will be provided
together. If you incorrectly input the PIN2
code for three times in succession, it will be
locked and you will need to input PUK2 to
unlock it.
13.3.4 PUK code
This is used to unlock the PIN code. Usually
the PUK code and SIM card are provided
together. If you don’t have it, please contact
with your network operator or SIM card
retailer. SIM Card won’t be used any more, if
you incorrectly input the PUK code ten times
in succession. In that case, please apply a new
SIM card from your network operator. PUK
code is unmodifiable.
13.3.5 PUK2 code
This is used to unlock the PIN2 code. Usually
the PUK2 code and the SIM card are
-21-
provided together. PUK2 can modify the
locked PIN2 code. If you incorrectly input the
PUK2 code for ten times in succession, you
will not be able to access some functions.
Please apply to your operator for a new card.
The PUK2 code is unmodifiable. If you lose
it, please contact your service provider.
13.4 Cautions for battery charging
The phone provides power by using a lithium
battery. The standby time and call time will
be influenced by the system’s environment
and phone settings.
Please use the approved battery and
charger designated for this product. The
company will take no responsibility for
damage caused by unauthorized battery or
charger.
The battery icon will start scrolling when
the phone is charged in power-on-state.
Caution:
1．If there is no battery left at all, then
the battery icon will appear after 2-3
minutes of charging. The battery
charging time depends on the status of
the phone (whether switched on, making
a call), usually, it will take about 2-5
hours.
2. To make the new battery achieve its
best capacity, please charge and
discharge the phone for twice or three
times. Please charge the new battery
over 10 hours for the first several times.
Don’t use wet hands to touch the battery
or charger while charging in order to avoid
danger.
Try not to use the phone while charging.
The battery icon stops scrolling while the
battery is full, and then you can disconnect
the phone from the charger adapter.
13.5 Cautions for battery usage
The battery usage depends on the network,
phone setting and usage situation.
Never use any damaged battery.
-22-
The phone will consume a little power if it
is near network station. Therefore, the call
and standby time depends greatly on the
signal strength of honeycomb network and
the parameters set by network operator.
The battery charging time lies on the
remnant power, and the type of the battery
and charger. When the operation time (talk
time and standby time) is noticeably
shorter than normal, it is time to replace
with a new battery.
Only use batteries and charges authorized
for this device, otherwise, explosion might
be caused. Please disconnect the charger
while unused. Do not leave the battery
connected to a charger over one week, for
overcharging may shorten the life length.
Do not connect the anode and cathode of a
battery inversely.
Do not leave the battery in places with
over-high or over-low temperature,
otherwise, the battery capacity will be
reduced and battery life will be shortened.
Always try to keep the battery in room
temperature.
Do not short-circuit the battery. This may
damage the electronic core or internal
protected circuit. If you keep the unused
battery in the pocket or bags, metal objects
(eg. coin, clip or pen, etc) inside might
have the anode directly contacted with the
cathode of the battery and caused
accidental short circuit. Therefore, please
carefully and separately store the battery.
Don’t burn your phone battery or treat it as
common rubbish. Please adhere to the
local environmental policy in order to
avoid endangering life and causing
environmental damage, and recycle your
batteries in time.
If your phone, battery or other charging
device is accidentally penetrated by water,
you must not put it inside any calefaction
equipment (such as drier, microwave oven
etc.) to dry it. The phone or other products
may go wrong, and may even cause the
-23-
phone, battery or other charging device to
burn, expand and explode.
Please deal with the discarded battery
according to the relative introduction.
The company will take no responsibility for
any direct or indirect damage caused by user
error.
13.6 Cautions for spare parts usage
Please put all spare parts (such as SIM card,
storage card, battery etc) out of reach of
children, in case danger occurs.
Please do switch off the phone and unplug
the phone and charger before you removing
the battery from the phone.
As the phone’s spare parts are not
waterproof, please keep all spare parts dry.
You should pull out the plug of any spare
part correctly when you switch off the
power, don’t drag the power line forcibly.
If the phone, battery, and charger don’t
operate normally, please contact closest
qualified maintenance centres timely.
13.7 Other safety information
If you don’t use your phone, it’s better to
switch it off and remove the battery so as
to save energy and avoid cellular
radiation.
Please don’t have the volume over loud
while using the phone, which might impair
your hearing.
The unprofessional shouldn’t disassemble
the terminal and battery of the phone.
It is recommended that you should try not
to use the holster with magnet button, for
the magnet may interfere with the phone
signal, and hard iron button may crush the
LCD screen. Plastic phone cover will lead
to poor volatilization of vapor and have
the internal components corrupted,
moreover, it can have the phone shell
oxidized and faded.
If you or your family has a medical record
of dizziness or epilepsy, please consult
with the doctor first, if you want to play
-24-
phone games or use the flashlight (the
flash doesn’t available in all phone
models).
Please don’t put the flashlight too close to
the eyes of human beings or animals, as
this could do harm to the eyes.
Should avoid the phone falling off from
high places.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may causeundesired
operation.
Any Changes or modifications not expressly
approved by the party responsible for
compliance could void the user's authority to
operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class
Bdigital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
-25-
-Consult the dealer or an experienced radio
technician for help.
Specific Absorption Rate (SAR)
information:
This wireless phone meets the government's
requirements for exposure to radio waves.
The guidelines are based on standards that
were developed by independent scientific
organizations through periodic and thorough
evaluation of scientific studies. The standards
include a substantial safety margin designed
to assure the safety of allpersons regardless of
age or health.FCC RF Exposure Information
and Statement The SAR limit of USA (FCC)
is 1.6W/kg averaged over one gram of tissue.
Device types: DOMO 2 (FCC ID:
) has also been tested
against this SAR limit. The highest SAR
value reported under this standard during
product certification for use at the ear is
0.831W/kg and when properly worn on the
body is 0.477W/kg. This device was tested
for typical body-worn operations with the
back of the handset kept 1.5cm from the body.
To maintain compliance with FCC RF
exposure requirements, use accessories that
maintain a 1.5cm separation distance between
the user's body and the back of the handset.
The use of belt clips, holsters and similar
accessories should not contain metallic
components in its assembly. The use of
accessories that do not satisfy these
requirements may not comply with FCC RF
exposure requirements, and should be
avoided.
Body-worn Operation
This device was tested for typical body-worn
operations. To comply with RF exposure
requirements, a minimum separation distance
of 1.5 cm must be maintained between the
user’s body and the handset, including the
antenna. Third-party belt-clips, holsters, and
similar accessories used by this device should
not contain any metallic components.
Body-worn accessories that do not meet these
requirements may not comply with RF
A4JDOMO2
-26-
exposure requirements and should be avoided.
Use only the supplied or an approved
antenna.
