Polk Audio Bluetooth Speaker
User Manual
Polk
Camden Square
Quick Start Guide
April 15th, 2013
What’s in the box
Camden Square wireless speaker
Power adapter and cord
Quick start guide
Controls
Power – Turns speaker on/off > press and hold for 2-3 seconds
After a period of inactivity, the Camden Square will go into
Low-power mode. To wake up the speaker, press power.
-/+ -- Adjusts volume up and down
>II Play/Pause current song (Bluetooth only)
>>/<< Next/Previous track (Bluetooth only) press and release
Fast forward/Rewind current track (Bluetooth only) press and hold
LED Colors
Blue (solid) Speaker is ON and in normal operating mode.
Blue (slowly blinking) Volume is muted
Blue (Quickly blinking) Volume at its maximum or minimum
Red (solid) Standby mode
Blue/Red (alternating) Battery at critical low level
Pairing and Connecting
1. Turn power on.
2. Enable Bluetooth on your device
3. In device settings menu, select “polk
camdensquare”
4. Audio tone sounds when device is paired and
connected
Source Select
The Camden Square is always in Bluetooth source mode, unless a cable is plugged
into the AUX input.
Battery
The battery in your Camden Square comes partially charged from the factory. The
charge is enough so that you can enjoy playing music right out of the box.
Charging Battery
Plug one end of the included power adapter into an AC wall outlet and the other end
into the Camden Square. You will hear an audio tone, indicating the battery is
charging.
Battery Charge Indicator
LED blinks Indicates
Red 4 X Full charge
Red 3 X Normal battery
Red 2 X low charge
Red 1 X Critical battery
With less than 30 minutes of charge remaining in the battery, an audio tone will
Indicate recharging is needed. The LED will fade from RED to BLUE constantly, until
The battery can no longer play music.
important safety instructions
This product was designed and manufactured to meet strict quality and safety
standards.
There are, however, some installation and operation precautions which you should be
particularly aware of.
1. Read Instructions. All the safety and operating instructions should be read before
the system is operated.
2. Retain Instructions. The safety and operating instructions should be retained for
future reference.
3. Heed Warnings. All warnings on the appliances and in the operating instructions
should be adhered to.
4. Follow Instructions. All operating and use instructions should be followed.
5. Cleaning. Unplug the appliance from wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments. Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture. Do not use these appliances near water for example, near a
bath tub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool, and the like.
8. Accessories. Do not place these appliances on an unstable cart, stand, tripod,
bracket, or table. The audio/video products may fall, causing serious injury to a child
or adult, and serious damage to the products. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the appliances. Any
mounting of the appliances should follow the manufacturer’s instructions, and
should use mounting accessories recommended by the manufacturer.
9. Ventilation. Slots and openings in the cabinet are provided for ventilation and to
ensure reliable operation of the appliances and to protect them from overheating,
and these openings must not be blocked or covered. The openings should never be
blocked by placing the products on a bed, sofa, rug, or other similar surface. This
product should never be placed near or over a radiator or heat register. This product
should not be placed in a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have been adhered
to.
10. Power Sources. This product should be operated only from the type of power
source indicated on the marking labels. If you are not sure of the type of power
supply to your home, consult your appliance dealer or local power company.
11. Grounding or Polarization. This product is equipped with polarized alternating-
current line plugs (plugs having one blade wider than the other). This plug will fit into
the power outlet only one way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.
12. Power Cord Protection. Power-supply cord should be routed so that it is not likely
to be walked on or pinched by items placed upon or against it, paying particular
attention to cords at plugs, convenience receptacles, and the point where they exit
from the appliances.
13. Lightning. For added protection for this audio/video product during a lightning
storm, or when it is left un-attended and unused for long periods of time, unplug it
from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
14. Power Lines. An outside antenna system should not be located in the vicinity of
overhead power lines or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as contact
with them might be fatal.
15. Overloading. Do not overload wall outlets and extension cords as this can result
in a risk of fire or electric shock.
16. Object and Liquid Entry. Never push objects of any kind into this product through
openings, as they may touch dangerous voltage points or short out parts that could
result in a fire or electric shock. Never spill liquid of any kind on this audio/video
product.
17. Servicing. Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
18. Damage Requiring Service. Unplug this product from wall outlets and refer
servicing to qualified service personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as an
improper adjustment of other controls may result in damage and will often require
extensive work by a qualified technician to restore the product to its normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. When the product exhibits a distinct change in performance this indicates a
need for service.
19. Replacement Parts. When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or that the
parts have the same characteristics as the original part. Unauthorized substitutions
may result in fire, electric shock or other hazards.
CAUTION: Danger of EXPLOSION if battery is incorrectly replaced. Replace only with
the same or equivalent type. (CR2025)
WARNING: Do not expose batteries or battery pack to excessive heat such as
sunshine, fire or the like.
20. Safety Check. Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the products are in
proper operating condition.
21. Carts and Stands. The appliances should be used only with a cart or stand that
is recommended by the manufacturer. An appliance and cart combination should be
moved with care. Quick stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn. Use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
22. This product is not intended for use outdoors.
The CAUTION marks shown here are located on the back of your Camden Square™
wireless speaker system
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, insert fully.
CAUTION: No naked flame sources, such
as candles, should be placed on the apparatus.
class b emissions limits
This Class B digital apparatus meets all requirements of the Canadian Interference—
Causing Equipment Regulations.
operation
Operation is subject to the following two conditions:
1) This device may not cause interference, and
2) This device must accept any interference, including interference that may cause
undesired operation of
the device.
product disposal
Certain international, national and/or local laws and/or regulations may apply
regarding the disposal of this product. For further detailed information, please
contact the retailer where you purchased this product or the Polk Audio
Importer/Distributor in your country. A listing of Polk Audio Importer/Distributors
can be found on the Polk website www.polkaudio.com or by contacting Polk Audio at:
5601 Metro Drive, Baltimore, Maryland 21215, USA. Phone: +1-410-358-3600; in
California: 1-800-377-7655.
note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy,
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the separation
between the equipment and receiver. Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected. Consult the dealer or an
experienced radio/TV technician for help.
• The antenna(s) used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be
co-located or operating in conjunction with any other antenna or transmitter.
• Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
limited five year warranty
Polk Audio, warrants to the original retail purchaser only. This warranty will terminate
automatically prior to its stated expiration if the original retail purchaser sells or
transfers the product to any other party.
Polk Audio, warrants, to the original retail purchaser only, that the LOUDSPEAKER(S),
PASSIVE CROSSOVER COMPONENT(S) and ENCLOSURE on this Polk Audio
Loudspeaker Product will be free from defects in material and
workmanship for a period of five (5) years from the date of original retail purchase
from a Polk Audio Authorized Dealer.
Furthermore, Polk Audio, Inc., warrants, to the original retail purchaser only, that any
AMPLIFIER OR OTHER ELECTRONIC COMPONENT that may be included in this Polk
Audio Loudspeaker Product will be free from defects in material and
workmanship for a period of one (1) years from the date of original retail purchase
from a Polk Audio Authorized Dealer.
To allow Polk Audio to offer the best possible warranty service, please register your
new product online at: www.polkaudio.com/registration or call Polk customer service
800-377-7655 in the USA and Canada (outside the USA: 410-358-3600)
within ten (10) days of the date of original purchase. Be sure to keep your original
purchase receipt.
Defective Products must be shipped, together with proof of purchase, prepaid
insured to the Polk Audio Authorized Dealer from whom you purchased the Product,
or to the Factory at 1 Viper Way, Vista, California 92081. Products must be shipped
in the original shipping container or its equivalent; in any case the risk of loss or
damage in transit is to be borne by you. If upon examination at the Factory or Polk
Audio Authorized Dealer it is determined that the unit was defective in materials
or workmanship at any time during this Warranty period, Polk Audio or the Polk Audio
Authorized Dealer will, at its option, repair or replace this Product at no additional
charge, except as set forth below. All replaced parts and Products become
the property of Polk Audio. Products replaced or repaired under this warranty will be
returned to you, within a reasonable
time, freight prepaid.
This warranty does not include service or parts to repair damage caused by accident,
disaster, misuse, abuse, negligence, inadequate packing or shipping procedures,
commercial use, voltage inputs in excess of the rated maximum of the unit,
cosmetic appearance of cabinetry not directly attributable to defect in materials or
workmanship, or service, repair, or
modification of the Product which has not been authorized or approved by Polk Audio.
This warranty shall terminate if the
Serial number on the Product has been removed, tampered with or defaced.
This warranty is in lieu of all other expressed Warranties. If this Product is defective in
materials or workmanship as warranted above, your sole remedy shall be repair or
replacement as provided above. In no event will Polk Audio, Inc. be liable to you for
any incidental or consequential damages arising out of the use or inability to use the
Product, even if Polk Audio, Inc. or a Polk Audio Authorized Dealer has been advised
of the possibility of such damages, or for any claim by any other party. Some states
do not allow the exclusion or limitation of consequential damages, so the above
limitation and exclusion may not apply to you. All implied warranties on this Product
are limited to the duration of this expressed Warranty. Some states do not allow
limitation on how long an implied Warranty lasts, so the above limitations may not
apply to you. This Warranty gives you specific legal rights, and you also may have
other rights which vary from state to state.
This Warranty applies only to Products purchased in Canada, the United States of
America, its possessions, and U.S.
and NATO armed forces exchanges and audio clubs.
The Warranty terms and conditions applicable to Products purchased in other
countries are available from the Polk Audio Authorized Distributors in such countries.
FCC Radiation Exposure Statement
1)This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. This equipment should be installed and operated with a minimum distance
of 20 centimeters between the radiator and your body.
Caution!
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Industry Canada RSS-210. Operation is subject to the following two
conditions: (1) this device may not cause interference, and(2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
RSS-210. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure
and compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS
102 et la conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information
canadienne sur l'exposition et la conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre
antenne ou émetteur. Cet équipement devrait être installé et actionné avec une distance
minimum de 20 centimètres entre le radiateur et votre corps.
