DENSO Korea FD00430 IBU FOB User Manual ORIGINAL
DENSO KOREA ELECTRONICS CORPORATION IBU FOB ORIGINAL
User manual
3. Outline of Smart Key FOB
Smart Key FOB is mainly used for locking or unlocking the doors of the vehicles.
Smart Key FOB detects signals when it reaches the vicinity of vehicle, and sends
signals using radio frequency.
Also, Smart Key FOB sends a radio wave signal while a button is pushed. When the
button is released, the radio wave signal is automatically off within 0.392 seconds.
When the button is depressed continuously, Smart Key FOB sends a signal for a
predetermined constant time.
This product sends a signal when the following buttons are pushed.
Transmitter IC
Actuator
Receiver
Subject for application
Installation in vehicle
Micom
Smart Key FOB
Control IC
LF Transmitter
433.92 MHz
134.2 kHz
Smart Key ECU
Trunk button
for opening the trunk
or back door.
Lock button
for locking the doors
Unlock button
for unlocking the doors.
Panic button
for Panic Alarm
FCC Warning Statement
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) to this device that are not expressly approved by the manufacturer may void the user’s authority to
operate the equipment.
Industry Canada Statement:
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, mêmesi le brouillage est
susceptible d'en compromettre le fonctionnement.
