User Manual
Instruction for usage of Bluetooth device
■What is like " Bluetooth device”?
By connecting Bluetooth portable Audio player (hereinafter
called portable device) or Hands-free phone* which
operation is confirmed, to the system, you will be able to use
portable device without operating a portable device.
* Including Audio player in a Hands-free phone. The
operation of an adaptor for Bluetooth audio is not confirmed.
You can check if the operation of your portable device is
confirmed at TOYOTA dealer or on the following website.
・The U.S. main･land : http://www.toyota.com
・Hawaii : http://www.toyotahawaii.com
・Canada: http://www.toyota.com
The portable device must be complied with the following
specification to connect this system.
Please understand that some functions in this system may be
limited by the model of portable device.
■Required Bluetooth Specification for cellular phone or
portable audio player
Ver.1.1 or above
■Required profiles for a cellular phone
・ HFP (Hands Free Profile)
Ver. 1.0
・ OPP (Object Push Profile)
Ver. 1.1
■Required profiles for a portable audio player
・ A2DP (Advanced Audio Distribution Profile)
Ver.1.0
・ AVRCP (Audio/Video Remote Control Profile)
Above Ver.1.0 (Above Ver.1.3 is recommended.)
Bluetooth is trademark owned by Bluetooth SIG. Inc
The frequency band is adopted for industrial, scientific,
medical and amateur radio service, besides this device.
(Hereinafter called other wireless stations for the above
services) Before using this system, ensure there is no
wireless station near this device, which is under operation.
If you would find this device would cause harmful
interference toward other wireless stations, move to another
location to prevent the interference.
■Certifications for this system
FCC ID: BABFT0001A
IC: 2024B-FT0001A
Note:
This device complies with Part15 of the FCC Rules and
RSS-Gen of the IC Rules. Operation is subject to the
following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any
inference received, including interference that may cause
undesired operation.
Change or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operative the equipment.
Don't operate portable device while driving.
• Don't leave portable device in the vehicle to prevent
damage. (Under the scorching sun, temperature in a
vehicle will be very high)
• Don't use portable device near the system. It may
cause the debased sound quality, or bad connection
status.
Note
• If you would use other wireless equipment near this system.
It may cause a bad effect on the connection of each device.
• By connecting Bluetooth, the battery of portable device will
run out faster.
When you use this system with a hands-free phone.
If you would use 2 portable devices such as Bluetooth
Audio and Hands-free phone, it may cause the
following situations.
・ The Bluetooth connection of portable device may be
disconnected.
・ The performance of the portable device may be slow.
The connection to portable device may be
disconnected when the phone book is transferring
from hands-free phone. In this case, the connection
may be re-connected after the completion of transfer
(Some models may not be re-connected.)
About Indications on display
■The connection of Bluetooth
The status of Bluetooth connection is displayed as below
display image.
This indication on display shows Bluetooth
connection is in good status.
Please use portable device or Hands-free phone
under this condition.
When there is no mark on the display, it shows
Bluetooth connection is not active. You cannot use
this system under this condition.
Please check the portable device or Hands-free
phone is selected correctly. If the portable device is
not registered in the system, please register the
portable device or Hands-free phone first before
using this system.
Note:
The antenna for Bluetooth connection on vehicle side is built
in a display. Under the following condition, Bluetooth
connection may not be in function.
• Portable device is lie on a position where encumber
wireless communication between portable device and the
system, or between Hands-free phone and the system,
such as on backside of seat, globe box, or in console box.
• Portable device is touched or covered by things in metal.
For good Bluetooth connection, place the portable
device so that mark will be shown on display
as the above.
! Warnin
g
! Caution
Bluetooth Audio
Bluetooth setting
■To register a portable device
To use Bluetooth audio, it is necessary to register a
portable device in the following steps.
・ Up to 2 portable devices can be register in the system.
・ As for the operation of a portable device, see the users'
manual that comes with it.
1. Press several times until "BT AUDIO" will appear.
Then press the button indicated 'SETUP' in the screen.
2. While turning TUNE-SCROLL knob, select "Pair Audio"
then "Record name.” After hearing blip, speak the
desired name of portable device.
3. The registration of portable device will be completed
after selecting "Confirm" then " Car M_Media" by
turning TUNE-SCROLL knob.
Note: You have to register passkey of portable device into the
system in advance.
4. If "Failed" is indicated, start over from the step 1.
■To connect a portable device
The portable device can be connected to a vehicle both
automatically and manually.
As for the operation of a portable device, see the users'
manual that comes with it.
■To connect automatically
The system will automatically establish Bluetooth
connection with a portable device, which is connected last
time, when ACC or IG mode is switched on.
■To check Bluetooth connection
When Bluetooth is connected in the stable condition,
ｗill appear on the display. Please check this indication
when using.
■When automatic connection is failed.
The automatic connection will be performed for certain
duration of time. When it doesn't succeed in connecting
during the time, try it manually.
■To connect manually
Connect Bluetooth manually when failing in automatic way,
or when automatic connection mode is off.
1. Press several times until "BT AUDIO" will
appear. Then press the button indicated
'SETUP' in the screen.
2. Select portable device to connect after selecting
"select Audio" by turning TUNE-SCROLL knob.
3. You can connect the portable device by selecting
"From Car"
4. If "Failed" is indicated, start over from the step 1.
■To reconnect Bluetooth
When Bluetooth connection is disconnected due to low radio
transmission circumstance, Bluetooth will perform an
automatic connection.
Note: The automatic connection will be performed only for
certain duration of time. If the connection wouldn’t be
established during the time, try it manually.
Note: Some portable devices model may not support
this function.
■When Bluetooth connection is disconnected on purpose
The automatic reconnection will not work when Bluetooth
has been disconnected on purpose, such as when
disconnected from the portable device side. In this case,
reconnect in either of the following ways.
・ Connect it manually
・ Reselect the portable device again.
■To change a name of a portable device
The name of portable device that appears on the display
can be changed as desired.
・ Even if the name of a portable device is changed at
the system, the registered name in portable device will
not be changed automatically.
1. Press several times until "BT AUDIO" will
appear. Then press the button under the indicated
“SETUP” on the display.
2. Select portable device to connect after selecting
"change Name" by turning TUNE-SCROLL knob.
3. Then select "NAME" and "RECORD NAME" on the
display after hearing blip read aloud a desired name
to be registered.
4. To complete the change, press “CONFIRM” on the
display.
■To change the Bluetooth setting of the system
・pass key
It is a password, which is used when you register a
portable device into the system. It can be changed to the
desired 4 to 8 digit numbers.
■To Initialize the Bluetooth setting
You can reset each setting you have made before.
1. Press a button under the indicated “SETUP” on the
display.
2. Find “System Setup” by turning TUNE-SCROLL knob
and press the knob to select.
3. Then find “Initialize” by turning TUNE-SCROLL knob,
and press the knob to select.
4. Then find “Confirm” by turning TUNE-SCROLL knob,
and press the knob to completion.
■To delete the registration of a portable device
1. Press a button under the indicated “SETUP” on the
display.
2. Then find “Delete Audio” by turning TUNE-SCROLL
knob, and press the knob to complete.
How to use Bluetooth Audio
You can play the connected portable device. To use Bluetooth audio, you have to register the portable device on the system.
About Indication on desplay
Depending on portable device models, artist names,
album name, or truck name may not be indicated on
the display.
To use Bluetooth Audio
Register a portable device to the the system (see
page 256)
Note:
Upon some portable device models, following
circumstance may be caused by connecting.
・ You cannot operate on the system side.
・ behavior or volume may be different.
・ The indications such as track or time information,
may be different between portable device and
the system side.
・ The connection may be disconnected when you
turn off the portable device. In this case, connect
manually.
When the connection between portable device and
the system is not stable, you may not operate the the
system. In this case, check if the connection status is
fine on the display, and retry the operation.
Tune scroll knob
Type Folder sw
Scan sw
Text s
w
Seek sw
To Pause
See the previous page for Bluetooth audio operation
image on the display.
・ Press button to pause.
・ And Press botton again to play trucks
To Select an album
Upon connecting to a portable device,
See the previous page for the display image for
Bluetooth audio operation.
・ To select previous album.
Press ∨side of the botton
・ To select following album
Press ∧side of the botton.
Note: Some portable devices may not support this
function.
To Select a track
Upon connecting to a portable device,
See the previous page for the display image for
Bluetooth audio operation.
You can select a track with botton.
・ Press ∨side to select previous
album.
・ Press ∧ side to select next
album.
Fast-Forward / Fast Rewind
Upon connecting to a portable device,
You can Fast-Forward or Fast-Rewind with
botton
・ To fast-forward
press and hold ∧side of the
botton
・ To fast-rewind
press and hold ∨side of the
botton
Track will be played again when you release the
botton
Note: Upon Some portable devices model, even
after releasing the button, fast-forwarding or
fast-rewinding may be continued.
In this case, Press again button to
play again a track.
Scanning introduction of a track
Upon connecting to a portable device,
・ To scan an introduction of tracks
Press button.
This function will be performed in a method of portable
device accordingly
Note: Some portable devices model do not support
this function.
Play tracks on repeat
Upon connecting to a portable device,
Indication for each setting will be as follow.
・ RTP (without underline): Play without repeat
・ RTP (with underline): Current track will be played on
repeat
■To change setting for repeat
By pressing a button, which is located under the indication
“RPT” or “RPT” on display,
the setting will be change from “RPT” to “RPT”,
or from “RPT” to “RPT”
Note: Some portable device models may not support
this function.
Play tracks at random
Upon connecting to a portable device,
Indication for each setting will be as follow.
・ RDM (without underline): Play in normal order.
・ RDM (with underline): The tracks in a album will be
played at random
■To change setting “play at random”
By pressing a button, which is located under the
indication “RDM” or “RDM” on display,
the setting will be changed from “RDM” to “RDM”,
or from “RDM” to “RDM”
Note: Some portable device models may not support this
function.
Displaying information of current track
Upon connecting to a portable device,
By pressing button while a track is playing, artist
name, album title and playing time will be sequentially
showed on display.
Note: Some portable devices models may not
support this function.
To chose a channel on a Radio
You can choose a channel (Frequency) of broadcasting
station.
To select from pre-set channels
Press button
・ To select higher channel
Press ∧side of the botton
・ To select lower channel
Press ∨side of the button
To seek a channel automatically
Press and hold SEEK-TRACK button until you hear
blip.
・ To seek higher channel
Press and hold ∧side of the botton
・ To seek lower channel
Press and hold ∨side of the button
Seeking a channel will stop at a channel with good
reception, which is closest to current channel.
To stop seeking channel, press SEEK-TRACK button
again.
To select a track on a music CD, MP3/WMA
Upon playing music, press button
・ To select the reverse track
Press ∧side of the botton
・ To select the forward track
Press ∨side of the button
To select a scene on DVD or MP3/WMA
The chapter or a track can be selected.
Upon playing DVD or MP3/WMA, press
button
・ To select the reverse chapter or track
Press ∧side of the botton
・ To select the forward chapter or track
Press ∨side of the button
Note: Some portable device models may not have this
function or may perform in a different behavior.
STEERING AUDIO SWITCH
Operation with a steering switch
■Steering audio switch
・Type A
・Type B
1. Volume up/down
2. ON-HOOK switch
3. OFF-HOOK switch
4. TALK switch
■Power on / off
・ To turn on power
Press MODE switch
・ To turn off power
Press and hold MODE switch until you hear blip.
■Volume adjustment
Press the volume adjustment switch
・ To turn up the volume
Press +
・ To turn down the volume
Press -
For your safety, adjust the volume properly.
■To change the MODE
Press MODE switch
The mode will be changed by pressing MODE switch every
times.
!Caution
1
2
3 4
1
2
3 4
Bluetooth Hands-free phone
Operating the system by using a voice command
By following voice guidance instructions output from the
speaker, voice commands can be given to allow for the
operation of the hands-free phone system without checking
the display or operating a button or a knob.
■Operation procedure when using a voice command
Press the talk switch on the steering and say the
command for a desired function.
■Auxiliary commands when using a voice command
The following auxiliary commands can be used when
operating the system using a voice command:
Cancel: Exits the hands-free phone system
Repeat: Repeats the previous voice guidance
instruction
Go back: Returns to the previous procedure
Help: Reads aloud the function summary if a help
comment is registered for the selected function.
Note: For the buttons on the steering, see STEERING
AUDIO SWITCH image on the previous page.
■Using the hands-free phone system for the first time
Before using the hands-free phone system, it is necessary
to register a Hands-free phone in the system. The phone
registration mode will be entered automatically when
starting the system with no Hands-free phone registered.
1. Press the OFF-HOOK or the TALK switches on the
steering. The introductory guidance and phone name
registration instructions are heard.
2. Register a phone name by either of the following
methods.
a. Select “Record Name” by using TUNE-SCROLL
knob.
b. Press the talk switch and say a name to be
registered.
A voice guidance instruction to confirm the input is heard.
3. Select “Confirm” by using a voice command or
TUNE-SCROLL knob.
A passkey is displayed and heard, and a voice guidance
instruction for inputting the passkey into the Hands-free
phone is heard.
4. Input the passkey into the Hands-free phone.
Refer to the manual that comes with the Hands-free
phone for the operation of the phone.
Guidance for registration completion is heard.
Normal operation
First menu Second
menu
Third
menu
Operation detail
Callback - - Dialing a number stored in the
incoming call history memory
Redial - - Dialing a number stored in the
outgoing call history memory
Dial
by number
- - Dialing by inputting a number
Dial
by name
- - Dialing by inputting a name
registered in the phone book
A
dd Entry -
A
dding a new numbe
r
Change
Name
- Changing a name in the phone
book
Delete
Entry
- Deleting the phone book data
Delete
Speed Dial
- Deleting a registered speed dial
List
Names
- Listing the phone book data
Phone
book
Set Speed
Dial
- Registering a speed dial
First
menu
Second
menu
Third
menu
Operation detail
Set PIN Setting a PIN code
Phonebook
Lock
Locking the phone book
Security
Phonebook
Unlock
Unlocking the phone book
Pair phone Registering the Hands-free phone
to be used
Change
Name
Changing a registered name of a
Hands-free phone
Delete Deleting a registered Hands-free
phone
List phones Listening the registered
Hands-free phones
Select
phone
Selecting a Hands-free phone to
be used
Phone
Setup
Set
Passkey
Changing the passkey
Guidance
Volume
Setting voice guidance volumeSystem
Setup
Initialize Initialization
Setup
Phone
Setup
Hands-Free
ON/OFF
Setting automatic connection of
Bluetooth links
Using a short cut key
First
menu
Second
menu
Operation detail
Dial
"XXX (name)"
- Dialing a number registered
in the phone book
Phonebook
add entry
- Adding a new number
Phonebook
change name
- Changing the name of a
phone number in the phonebook
Phonebook
delete entry
- Deleting phone book data
Phonebook
set speed dial
- Registering a speed dial
Phonebook
delete speed
dial
- Deleting a speed dial
Phonebook
Unlock
Unlocking the phone book Phonebook
Phonebook
Lock
Locking the phone book
■Automatic adjustment of volume
When vehicle is 50mph(80km/h) or more, the volume
automatically increases. The volume returns to the previous
volume setting when vehicle speed drops to 43 mph (70 km/h)
or less.
■When using a voice command
For numbers, say a combination of single digits from zero to
nine, #(pound), *(star), and +(plus).
Say a command correctly and clearly.
■The system may not recognize your voice in the following
situations:
・ When driving on a rough road
・ When driving at high speeds
・ When air is blowing out of the vents onto the microphone
・ When the air conditioning fan emits a loud noise
■The following cannot be performed while driving:
・ Operating the system with button or knob on display.
・ Registering a Hands-free phone to the system
■Changing the passkey
See the following page accordingly.
■Making a phone call
・ Dialing by inputting a number
”Dial by number”
・ Dialing by inputting a name
”Dial by name”
・ Speed dialing
・ Dialing a number stored in the outgoing history memory
”Redial”
・ Dialing a number stored in the incoming history memory
”Call back”
■Receiving a phone call
・ Answering the phone
・ Refusing the call
■Transferring a call
■Using the call history memory
・ Dialing
・ Storing data in the phone book
・ Deleting
■Dialing by inputting a number
1. Press the talk switch and say “Dial by number”
2. Press the talk switch and say the phone number.
3. Dial by one of the following methods:
a. Press the OFF-HOOK switch on the steering
b. Press the talk switch on the steering and say “Dial”
c. Select “Dial” by using TUNE-SCROLL knob
■Dialing by inputting a name
1. Press the TALK switch on the steering and say “Dial by
name”
2. Select a registered name to be input by either of the
following methods:
a. Press the TALK switch on the steering and say a
registered name.
b. Press the TALK switch on the steering and say,
“ List names”. Press the TALK switch on the
steering while the desired name is being read
aloud.
3. Dial by one of the following methods:
a. Press the OFF-HOOK switch on the steering
b. Press the TALK switch on the steering and say “Dial”
c. Select “Dial” by using TUNE-SCROLL knob
■Speed dialing
1. Press the OFF-HOOK switch on the steering on the
steering/
2. Press the preset button on the display in which the
desired number is registered
3. Press the OFF-HOOK switch on the steering.
■When receiving a phone call
■Answering the phone
Press the OFF-HOOK switch on the steering
■Refusing the call
Press the ON-HOOK switch on the steering.
■Transferring a call
A call can be transferred between the Hands-free phone
and system while dialing, receiving a call, or during a call.
Use one of the following methods:
a. Operate the Hands-free phone.
Refer to the manual that comes with the
Hands-free phone for the operation of the phone.
b. Press the OFF-HOOK switch on the steering *1
c. Press the TALK switch on the steering and say
“ Call Transfer”*2
*1 This operation can be performed only when
transferring a call from the Hands-free phone to the
system during a call.
*2 While the vehicle is in motion, a call cannot be
transferred from the system to the Hands-free phone.
■Using the call history memory
Follow the procedure below to use a number stored in
the call history memory:
1. Press the TALK switch on the steering and say
“Redial” (when using a number stored in the outgoing
call history memory) or “ Call back”(when using a
number stored in the incoming call history memory).
2. Select the number by either of the following methods:
a. Say “previous” or “Go back” until the desired
number is displayed.
b. Select the desired number by using
TUNE-SCROLL knob
The following operations can be performed:
Dialing: Press the OFF-HOOK switch on the steering
or select “Dial” by using a voice command or
TUNE-SCROLL knob.
Storing the number in the phone book: Select
“Store” by using a voice command or TUNE-SCROLL
knob.
Deleting: Select “Delete” by using a voice command
or TUNE-SCROLL knob.
■Call history
Up to 5 numbers can be stored in each of “out going” and
“incoming” call history memories.
■When talking on the phone
・ Do not talk simultaneously with the other party.
・ Keep the volume of the received voice down. Otherwise,
voice echo will increase.
Setting a Hands-free phone
Registering a Hands-free phone in the system allows the
system to function. The following functions can be used for
registered Hands-free phones:
■Functions and operation procedures
To enter the menu for each function, follow the steps
below by using a voice command or TUNE-SCROLL
knob
・ Registering a Hands-free phone
1. “Setup” -> 2. “Phone Setup” -> 3. “Pair Phone”
・ Selecting the Hands-free phone to be used
1. “Setup” -> 2. “Phone Setup” -> 3. “Select phone”
・ Changing a registered name.
1. “Setup” -> 2. “Phone Setup” -> 3. “Change Name”
・ Listening the registered Hands-free phones
1. “Setup” -> 2. “Phone Setup” -> 3. “List Phones”
・ Deleting a Hands-free phone
1. “Setup” -> 2. “Phone Setup” -> 3. “Delete”
・ Changing the passkey
1. “Setup” -> 2. “Phone Setup” -> 3. “Set Passkey”
Registering a Hands-free phone
Select “Pair Phone” by using a voice command or
TUNE-SCROLL knob, and do the procedure for
registering a Hands-free phone.
Selecting the Hands-free phone to be used.
1. Select “Select Phone” by using a voice command
or TUNE-SCROLL knob.
2. >Pattern A: Select the Hands-free phone to
be used by either of the following methods, and
select “ confirm” by using a voice command or
TUNE-SCROLL knob.
a. Press the TALK switch on the steering and
say the desired phone name.
b. Press the TALK switch on the steering and
say “List phones”. While the name of the
desired Hands-free phone is being read aloud,
press the TALK switch on the steering.
>Pattern B: Select the Hands-free phone to
be used by using TUNE-SCROLL knob.
Changing a registered name
1. Select “Change Name” by using a voice command
or TUNE-SCROLL knob.
2. Select the name of the Hands-free phone to be
changed from one of the following methods:
a. Press the TALK switch on the steering and
say the desired phone name, and select
“confirm” by using a voice command or
TUNE-SCROLL knob.
b. Press the TALK switch on the steering and
say “List phones”. While the desired phone
name is being read aloud, press the TALK
switch on the steering.
c. Select the desired phone name by using
TUNE-SCROLL knob.
3. Press the TALK switch on the steering or select
“ Record Name” by using Tune scroll knob and say
a new name.
4. Select “Confirm” by using a voice command or
TUNE-SCROLL knob.
Listing the registered Hands-free phones
Selecting “ List phones” by using a voice command or
TUNE-SCROLL knob causes the list of registered
Hands-free phones to b read a loud. When listing is
completed, the system returns to “Phone Setup”
Pressing the TALK switch on the steering while the name
of a Hands-free phone is being read selects the
Hands-free phone, and the following functions will be
available:
・ Selecting a Hands-free phone: “Select phone”
・ Changing a registered name: “Change Name”
・ Deleting a Hands-free phone: “Delete”
Deleting a Hands-free phone
1. Select “Delete” by using a voice command or
TUNE-SCROLL knob.
2. >Pattern A Select the Hands-free phone to
be deleted by either of the following methods and
select “Confirm” by using a voice command or
TUNE-SCROLL knob.
a. Press the TALK switch on the steering and
say the name of the desired Hands-free
phone.
b. Press the TALK switch on the steering and
say “ List phones”. While the name of the
desired Hands-free phone is being read aloud,
press the TALK switch on the steering.
>Pattern B Select the desired Hands-free
phone to be deleted by using Turn scroll knob.
Changing the passkey
1. Select “Set Passkey” by using a voice command or
TUNE-SCROLL knob.
2. >Pattern A Press the TALK switch on the
steering, say a 4 to 8 digit number, and select
“Confirm” by using a voice command or
TUNE-SCROLL knob.
>Pattern B Select a 4 to 8 digit number by
using TUNE-SCROLL knob. Then number should
be input 1 digit at a time.
3. >Pattern B When the entire number to be
registered as a passkey has been input, press
TUNE-SCROLL knob once again.
The numbers of Hands-free phones that can be
registered
Up to 6 Hands-free phones can be registered in the
system.
To enter the menu of each setting, follow the steps below:
Security setting items and operation procedure
・ Setting or changing the PIN (Personal
Identification Number)
1. “Setup” -> 2. “Security” -> 3. “Set PIN”
・ Locking the phone book
1. “Setup” -> 2. “Security” -> 3. “Phonebook Lock”
・ Unlocking the phone book
1. “Setup” -> 2. “Security” -> 3. “Phonebook
Unlock”
System setup items and operation procedure
・ Setting voice guidance volume
1. “Setup” -> 2. “System Setup” -> 3. “Guidance
Vol”
・ Initialization
1. “Setup” -> 2. “System Setup” -> 3. “Initialize”
TUNE-SCROLL knob can only be used for system setup
operation.
Setting or changing the PIN
■Setting a PIN
1. Select “Set PIN” by using a voice command or
TUNE-SCROLL knob.
2. Enter a PIN by using a voice command or
TUNE-SCROLL knob. When using TUNE-SCROLL
knob, input the code 1 digit at a time.
■Changing the PIN
1. Select “Set PIN” by using a voice command or
TUNE-SCROLL knob.
2. Enter the registered PIN by using a voice command
or TUNE-SCROLL knob.
3. Enter a new PIN by using a voice command or
TUNE-SCROLL knob.
Locking or unlocking the phone book
1. Select “Phone book Lock” or “Phonebook unlock” by
using a voice command or TUNE-SCROLL knob.
2. Input the PIN by either of the following methods and
select “Confirm” by using a voice command or
TUNE-SCROLL knob.
a. Press the TALK switch on the steering and
say the registered PIN
b. Input a new PIN by using TUNE-SCROLL
knob.
Setting voice guidance volume
1. Select “Guidance Vol “ by using TUNE-SCROLL knob.
2. Change the voice guidance volume.
・ To decrease the volume: Turn TUNE-SCROLL
knob counterclockwise.
・ To increase the volume: Turn TUNE-SCROLL
knob clockwise.
Initialization
1. Select “Initialize” and then “Confirm” by using
TUNE-SCROLL knob.
2. Select “Confirm” by using TUNE-SCROLL knob.
■Initialization
• The following data in the system can be initialized:
・ Phone book
・ Outgoing and incoming call history
・ Speed dials
・ Registered Hands-free phone data
・ Security code
• Once the initialization has been completed, the data
cannot be restored to its original state.
■When the phone book is locked
The following functions cannot be used:
・ Dialing by inputting a name
・ Using Speed dialing
・ Dialing a number stored in the call history memory
・ Using the phone book
To enter the menu of each setting, follow the steps below:
• Adding a new phone number
1.“Phonebook” -> 2.“Add Entry”
• Setting speed dial
1. “Phonebook” -> 2.“Set Speed Dial”
• Changing a registered name
1. “Phonebook” ->2.“Change Name”
• Deleting registered data
1. “Phonebook” ->2.“Delete Entry”
• Deleting speed dial
1. “Phonebook” ->2.“Delete Speed Dial”
• Listing the registered data
1. “Phonebook” ->2. “List Names”
Adding a new phone number
The following methods can be used to add a new phone
number:
• Inputting a phone number by using a voice
command
• Transferring data from a Hands-free phone
• Inputting a phone number by using TUNE-SCROLL
knob
• Selecting a phone number from outgoing or
incoming call history
■Adding procedure
1. Select “Add Entry” by using a voice command or
TUNE-SCROLL knob.
2. Use one of the following methods to input a telephone
number:
>Inputting a telephone number by using a voice command
2-1 Select “By Voice” by using a voice command or
TUNE-SCROLL knob.
2-2 Press the TALK switch, say the desired number,
and select “Confirm” by using a voice command.
>Transferring data from the Hands-free phone
2-1 Select “By Phone” and then “Confirm” by using a
voice command or TUNE-SCROLL knob.
2-2 Transfer the data from the Hands-free phone.
Refer to the manual that comes with the Hands-free
phone for the details of transferring data.
2-3 Select the data to be registered by either of the
following methods:
a. Say “Previous” or “Nest” until the desired data is
displayed, and select “Confirm” by using a voice
command.
b. Select the desired data by using TUNE-SCROLL
knob.
>Inputting a phone number by using TUNE-SCROLL knob.
2-1 Select “Manual Input” by using TUNE-SCROLL
knob.
2-2 Input a phone number by using TUNE-SCROLL
knob, and presses it again.
Input the phone number 1 digit at a time.
>Selecting a phone number from outgoing or incoming call history
2-1 Select “Call History” by using a voice command or
TUNE-SCROLL knob.
2-2 Select “Outgoing” or “Incoming” by using a voice
command or TUNE-SCROLL knob.
2-3 Select the data to be registered by either of the
following methods:
a. Say “Previous” or “Go back” until the desired data is
displayed, and select “Confirm” by using a voice
command.
b. Select the desired data by using TUNE-SCROLL
knob.
3. Select the name to be registered by either of the following
methods, and select “Confirm” by using a voice command
or TUNE-SCROLL knob.
a. Press the TALK switch on the steering and say the
desired name.
b. Select “Record Name” by using TUNE-SCROLL
knob, and say the desired name.
4. Select “Confirm” by using a voice command or
TUNE-SCROLL knob.
In 3., selecting “Set Speed Dial” instead of “Confirm”
registers the newly added phone number as a speed dial.
Setting speed dials
1. Select “Set Speed Dial” by using a voice command or
TUNE-SCROLL knob.
2. Select the data to be registered as a speed dial from
one of the following methods:
a. Press the TALK switch on the steering, say a
desired number, and select “Confirm” by using a
voice command or TUNE-SCROLL knob.
b. Press the TALK switch on the steering, and select
“Confirm” by using a voice command or
TUNE-SCROLL knob.
c. Select the desired data by using TUNE-SCROLL
knob.
3. Select the desired preset button, and register the data into
speed dial by either of the following methods:
a. Press the desired preset button, and select
“Confirm” by using a voice command or
TUNE-SCROLL knob.
b. Press and hold the desired preset button.
Changing a registered name
1. Select “Change Name” by using a voice command or
TUNE-SCROLL knob.
2. Select the name to be changed from one of the
following methods.
a. Press the TALK switch on the steering, say a
desired name, and select “Confirm” by using a
voice command or TUNE-SCROLL knob.
b. Press the TALK switch on the steering, and say
“List names.” While the desired name is being
read aloud, press the TALK switch on the steering,
and select “Confirm” by using a voice command
or TUNE-SCROLL knob.
c. Select the desired name with TUNE-SCROLL
knob or the TALK switch on the steering.
3. Select “Record Name” with TUNE-SCROLL knob or
the TALK switch on the steering.
4. Say a new name, and select “Confirm” by using a
voice command or TUNE-SCROLL knob.
Deleting registered data
1. Select “Delete Entry” by using a voice command or
TUNE-SCROLL knob.
2. >Pattern A Select the data to be deleted by
either of the following methods, and select “Confirm” by
using a voice command or TUNE-SCROLL knob.
a. Press the TALK switch on the steering, and say
the name of the desired phone number to be
deleted.
b. Press the TALK switch on the steering, and say
“List phones.” While the name of the desired
phone number is being read aloud, press the TALK
switch on the steering.
>Pattern B Select the data to be deleted by
using TUNE-SCROLL knob.
Deleting speed dials
1. Select “Delete Speed Dial” by using a voice command
or TUNE-SCROLL knob.
2. Press the preset button in which the desired speed dial
is registered, and select “Confirm” by using a voice
command or TUNE-SCROLL knob.
Listing the registered data
Selecting “List names” by using a voice command causes
a list of the registered data to be read aloud.
When listing is complete, the system will return to
“Phonebook.”
Pressing the TALK switch on the steering while the
desired data is being read aloud selects the data, and the
following function will be available.
• Dialing: “Dial”
• Changing a registered name: “Change Name”
• Deleting an entry: “Delete Entry”
• Setting a speed dial: “Set Speed Dial”
__________________________________________
■Limitation of the phone number digits
A phone number that exceeds 24 digits cannot be
registered.
