Model name
Model No
Car Audio
FT0057A
Index
1-Rating
2-Button function spec
Page
2P
3～4P
(1/4)
1-Rating
RATED VOLTAGE
LOAD IMPEDANCE
BACK UP CURRENT
RATED CURRENT
AM TUNING RANGE
CD TYPE
13.2V(10.5～16.0V)-GROUND
4Ω
1.0mA OR LESS
3A OR LESS (VCC=14.4V 0.5W OUTPUT)
531～1629kHz
87.5～108.0MHz
12cm IN DASH ONE DISC (8cm ADAPTER USE)
FM TUNING RANGE
(2/4)
Button function spec
(3/4)
Switch the Setup menu
MENU④
Switch to USB/iPod mode/AUXUSB⑤
CD/USB/iPod/BT Audio TEXT Display
TEXT⑥
Dial Menu Operation
Receiving a Call Disconnecting a Call
PHONE⑦
Switching over to AM/FM
FM/AM
②
PWR Switch
PWR･VOL①Volume Control
Switch to Disc/BT audio modeDISC③
(Other) Fast UP
(Radio) SEEK UP
(Other) Track UP
SEEK TRACK UP
(∧)⑨
(CD,USB) Fast DOWN
(Radio) SEEK DOWN
(CD,USB) Track DOWN
SEEK TRACK
DOWN
(∨)
⑧
FunctionButton NameButton No.
(4/4)
ENTER
TUNE･
CONTROL
ENTER LIST
⑩(Radio) TUNE
(Other) Track change
(Audio control, BROWSE) Scroll
(Radio) Call Preset CH
(Radio) Insert Preset CH
Preset 1～6⑪～⑯
Disc eject⑰
SCAN⑱TRACK SCAN
FunctionButton NameButton No.
・FCC ID: BABFT0057A
・CAUTION: Radio Frequency Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for
uncontrolled equipment and meets the FCC radio frequency (RF)
Exposure Guidelines in Supplement C to OET65.
This equipment has very low levels of RF energy that it deemed to comply
without maximum permissive exposure evaluation (MPE).
But it is desirable that it should be installed and operated with at least 20cm
and more between the radiator and person's body
(excluding extremities: hands, wrists, feet and ankles).
・Co-location: This transmitter must not be co-located or operated in conjunction
with any other antenna or transmitter.
・This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
・FCC WARNING
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
