DENSO TEN FT0102A Car Navigation User Manual Users manual
Fujitsu Ten Limited Car Navigation Users manual
Users manual
（1/8）
FUJITSU TEN CONFIDENTIAL
User manual
Index
1－Function list
2－Button function
Page
3P－5P
6P－7P
Model name Car Audio
Model No. FT0102A
（2/8）
FUJITSU TEN CONFIDENTIAL
Revision history
Revision
number Date Author Content of change
01 2015/12/11 Terajima New
（3/8）
FUJITSU TEN CONFIDENTIAL
1－Function list
－：Not supported
Function North
America Canada
ハンドル STEERING WHEEL LHD ←
NAVI NAVIGATION SD ←
RADIO ← AM/FM/X
M←
フェースダイバー PHASE DIVER ○ ←
SWダイバー SWITCHING DIVER － ←
DTV DIGITAL TV － ←
デッキ DECK DVD-
PLAYER ←
CDリッピング CD RIPPING － ←
USBオーディオ USB AUDIO ○ ←
BTオーディオ BLUETOOTH AUDIO ○ ←
AUX ← ○ ←
VTR ← ○ ←
ハンズフリー HANDSFREE ○ ←
後席映像出力
(DVD/VTR)
REAR SEAT VIDEO
OUTPUT（DVD/VTR） －←
A/C操作 A/C OPERATION
SCREEN ○←
言語切替 SET LANGUAGE ○ ←
音声認識 SPEECH
RECOGNITION ○←
（4/8）
FUJITSU TEN CONFIDENTIAL
Function North
America Canada
周辺監視 SURROUND
MONITORING -←
クリソナ CLEARANCE SONAR ○ ←
e-NAVI e-NAVI ○ ―
リモートサー
ビス REMOTE SERVICE ○ －
ハザードＳＷ HAZARD SWITCH ○ ←
P席 A/Bｲﾝ
ｼﾞｹｰﾀ
PASSENGER
INDICATOR －←
ｾｷｭﾘﾃｨｲﾝｼﾞ
ｹｰﾀ
SECURITY
INDICATOR ○←
－：Not supported
（5/8）
FUJITSU TEN CONFIDENTIAL
－：Not supported
Function North
America Canada
DVD 部 DVD PLAYER 12cm 1枚
12cm 1 DISC ←
SD 容量
（MAP)
SD CAPACITY
（MAP) 16G ←
性能保証温
度範囲
PERFORMANCE
GUARANTEED
TEMPERATURE
RANGE
-20～65℃ ←
通信機能 COMMUNICATION
FUNCTION -30～65℃ ←
メカ可動部 MOVABLE PART -20～65℃ ←
保存温度範
囲
PRESERVATION
TEMPERATURE
RANGE
-40～85℃ ←
（6/8）
FUJITSU TEN CONFIDENTIAL
No. Button Caption Function
①TUNE・SCROOL The radio tuning /
Scroll control
②Play / Pause
③Disc eject
④PWR・VOL Power supply switch /
Volume control
⑤CH-TRACK Preset channel up key /
Track up key
⑥CH-TRACK Preset channel down key /
Track down key
⑦MEDIA Change of the media sources
⑧RADIO Change of the radio sources
2－Button function
⑧
③
⑥
②①
⑤
④
⑦
（7/8）
FUJITSU TEN CONFIDENTIAL
No. Button Caption Function
⑨Hazard Indicator ON/OFF
⑩⑫ Temperature adjustment UP
(driver's seat and passenger's seat)
⑪⑬ Temperature adjustment DOWN
(driver's seat and passenger's seat)
⑭Automatic control of air conditioner
⑮Air conditioner OFF
⑯Air conditioner Adjustment DOWN
⑰Air conditioner Adjustment UP
⑱Pollen removal ON/OFF
⑲Air recirculation/AUTO/Fresh air switch
⑳Front Defogger ON/OFF
21 Rear Defogger and Mirror heater ON/OFF
22 Air conditioner DUAL mode ON/OFF
23 Security indicator ON/OFF
⑨
⑪
⑲
⑭⑮⑯⑰
⑫
⑬
⑩
⑳21
⑱22
23
（8/8）
FUJITSU TEN CONFIDENTIAL
FCC ID: BABFT0102A
CAUTION: Radio Frequency Radiation Exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines. This
equipment should be installed and operated keeping the radiator at least 20cm or more
away from person’s body in normal use position.
Co-location: This transmitter must not be co-located or operated in conjunction with any
other antenna or transmitter.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
IC: 2024B-FT0102A
This device complies with Industry Canada's licence-exempt RSSs. Operation is subject
to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
CAUTION: Radio Frequency Radiation Exposure
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment should be installed and operated keeping the radiator at least 20cm or more
away from person's body.
