DIMTON BSH-02 BLUETOOTH STEREO HEADSET User Manual
DIMTON CO., LTD. BLUETOOTH STEREO HEADSET
DIMTON >
user manual
BlueRider DT-BSH-02 BLUETOOTH STEREO HEADSET manual
Front view:
(A) Lights and sound audio interest list
Mode Button
Push
button
period
Sound
operated:
Light
operated : Action :
A 5
second
Beep~Bo
A slow
flashing
green
Power on
A 5
second Beep~Bo
The green
light on the
quick Flash 3
times
Power off
A 8
second
Continuous
sound
playing↘
Red, green
twinkle slow
playing
exchanged
Normal pairing mode
Basic quick
operation :
A 10
second
Continuous
sound
playing↗
Red, green
twinkle
quickly
playing
exchanged
Front and rear speaker
dedicated pairing
mode
A 1 time Beep - Increasing volume Under Mobile
Cell phone
connection
tt
B 1time Beep - Decreasing volume
1 Push button B, increase the
volume, switch to a mobile
phone (default)
2 Push button “A”, Switch on/off,
pairing
3 Push button c, answer, end, lights
4 Battery placement in the
Department
5 Battery cover
status :
B 3
second Beep Beep Green light
flash quickly
In connection status
( some of mobile
supporting )
(Sound/ Voice
control)
A 1 time Beep - Increasing Volume
B 1 time Beep - Decreasing Volume
C 3
second
Beep Beep
Beep - Connect to
inter-communication
Front and rear
speaker inter
-communication
C 3
second
Beep Beep
Beep - Disconnect to
inter-communication
Opening
address
received signals
C 1 time Beep Green light
flash quickly
Calls, response, end the
call
(B) Basic operation
1. Power on ：
Put the battery into the machine. The battery outwards shown as in the 1st
page photo. To match the battery cover signs ” ▲ “ of the alignment machine ” ▼
“, and to turn off the battery cover by rotating 45 degrees . (about 12 o'clock,
direction)
Holding a no-drop of about 5 seconds, at this point will see Green Flash or
hear the power on sound ”Beep-Bo “, shall be power-on completion.
2. Power off ：
When you use completion, holding a no-drop of about 5 seconds, will see the
lights blinking three times at this point or hear shutdown sound ” “ beep ~ , means
the shutdown completed.
3. Normal Pairing：
General pairing: pairing with the Bluetooth device, such as have Bluetooth
functionality for mobile phones, computers, and music player. To the machine is
not powered on State, holding the Key “A” no-drop of about 8 seconds, at this
point lights will first represents the red light and power to enter the green light,
Twinkle, Twinkle State (intersection interval time longer), i.e. into general pairing
mode
4. Exceptional pairing：
Exceptional pairing： Pairing to another device of BSH-02 product, it is to
available to become a speaker unit after connection completed. If the machine is
under NOT powered on State, please holding key “A” no-drop about 10 seconds,
at this point to the parade will first represents the reboot, enter general pairing
mode, still do not let go, when the lights indicated that the red light and green light,
Twinkle, Twinkle State (intersection interval time shorter), means to enter
exceptional pairing mode
(C) Pairing Bluetooth products：
1. Please be paired Bluetooth devices are placed at and away next to the device
which was with blue tooth function on (some brands of mobile phones will search
all open Bluetooth devices, after the completion of all search, to complete a
pairing, time will be better than long, please wait and be patience )
2. Will this product is holding with key “A” no-drop, until the product after entering
general pairing mode, at this point lights should be green, red light flashing (slow
flashing)
3. Begin to search for Bluetooth products, and it will be found (DT-BSH-02) product, to
encounter when you need to be paired codes, please enter numbers ” 0000 “
4. When products lights by a two-color back to green lights, means the pairing is
complete, you can make use of this product online
5. After pairing is completed, press key “C “can be connected or disconnected for
communication, Key “A” , and Key “B” are be as increase and decreased the
volume function
6. Wake-up function：
When you are finished pairing process, two pairing Bluetooth devices in the
distance of more than 10 meters coverage will be automatically disconnected.
When you want to connect to Bluetooth function again, please long press key “B”,
you will hear the sound of “ beeping ” , and the point lights to be green lights flash,
means the function be wake up, and mobile phones and Bluetooth will be begin to
connect again.(some brands phone may not support wake-up features, please
refer to the mobile phone specification to confirm that supported Bluetooth
wake-up function).
(D) To pairing with another product of DT-BSH-02 / Exceptional pairing
( inter-communication function)
1. Internal speaker function is created by our company DIMTON technology, like small
intercom, facilitate dialogue. It will not be need to through another Bluetooth
receive or launching device, you only need two Bluetooth headset, and fully
compatible to BSH-01.
2. Take 2-supported Bluetooth headset placed within 1-meter, and identify 2 sticks
Bluetooth headphones all during the shutdown state
3. Select one headset holding key “ A “ about 10 seconds, will first powered on, enter
general pairing mode, and then enter the special pairing mode (internal intercom
pairing), at this point lights will first powered on green lights are turned into the dual
solar panels in the number of the slow blink, finally entering double No. blinking
lights
4. Another headphones, please holding key “A “ about 8 seconds, will first powered
on, and then enter the General pairing mode, at this point you will see a slow blink
double solar panels in the number
5. When 2 DT-BSH-02 pairing is complete, will only flashes green lights, at this point is
paired to complete.
6. To begin to speak, holding key ” C” about three seconds, at this point will hear
sounds 3 times” beeping ” then, to could let go, at this point the other supported
Bluetooth headset will hear a beep, namely switch on the intercom function, any 1
supported Bluetooth headset and then press the next key “ C “to switch off BSH-02
intercom.。
(E) SPEC
Item Description
Bluetooth
chip version
Bluetooth V2.1 + EDR
frequency 2.4GHz
Antenna 0.000045W~0.0002W
Profile HSP, HFP, A2DP, AVRCP
valid 10 m (open space)
Battery time 8hus
Standby time 150hrs
Battery AAA Battery*1
Dimension 60 x 35 x 15 mm
Weight 18g (NOT including battery)SS
(F) Remark ( Warning )：
1. Long term does not use this product, please insert the batteries out, to avoid
causing the battery because excessive discharge phenomena, leakage will not be
in warranty.
2. Please do not dismantle, adapted, as a result of disassembles refit, cause
unforeseen damage, will not be in warranty and indemnity
3. Specifications listed on the table for the use of time before and after the speaker of
the data will still be data, but, the volume and types of batteries.
Regulations
You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference and (2) this device must accept any interference received, including interference that may cause
undesired operation
