WELCOME
Thank you for buying the Doorbell module. This module allows you to set and control up to two doorbells using Zigbee and Z-Wave signals to
communicate with your home automation system. Please follow these instructions to connect your new Doorbell.
PACKAGE CONTENTS:
Doorbell Module Fastener (Hook and Loop)
with Adhesive (Qty. 2)
Quick Start Guide
5
Pull off the cover from your doorbell.
Follow the on-screen instructions on your home
automation system to complete setup.
Pull the plastic tab from the battery contacts.
USING YOUR DOORBELL
SETUP AND INSTALLATION
4
2Connect the three terminals from the Doorbell, using
the key on it’s cover.
1
3
If you need to secure the Doorbell module within
the doorbell case, use the provided velco strips with
adhesive backing.
GREEN - FRONT
YELLOW - REAR
WHITE - TRANS
DOORBELL
QUICK START GUIDE
