Cover
17” WIDE TFT LCD TV
Before using this product, please read the security instructions first and bear them
in mind when using the product.
Security Instructions
To prevent damage, which may result in fire or electric shock hazard, do not expose this
appliance to rain or moisture.
This product has been designed and manufactured for home and office use.
Any problems with the TV will not be valid for the service agreement when the product
has been used for purposes other than home or office use, even if the warranty period has
not expired.
This product is manufactured and sold for domestic use only.
The company shall not be held liable for any malfunction of the TV, if it is used anywhere
else except the domestic market.
Additionally, TV support can only be provided for the domestic market.
1P
Safety Instructions
Warning! Important
Safety Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol indicates high voltage is present inside. It is
dangerous to make any kind of contact with any inside part of
this product.
This symbol alerts you that important literature concerning
operation and maintenance has been included with this product.
Note to CATV system installer: This reminder is provided to call CATV system
installer’s attention to Article 820-40 of the National Electrical Code (Section 54 of
Canadian Electrical Code, Part I), that provides guidelines for proper grounding
and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building as close to the point of cable entry as practical.
Caution: FCC/CSA regulations state that any unauthorized changes or modifications
to this equipment may void the user’s authority to operate it.
Caution: To prevent electric shock, match the wide blade of plug to the wide slot,
and fully insert the plug.
Attention: pour eviter les chocs electriques, introduire la lame le plus large de la
fiche dans la borne correspondante de la prise et pousser jusqu’au fond.
Important: One Federal Court has held that unauthorized recording of
copyrighted TV programs is an infringement of U.S. copyright laws.
Certain Canadian programs may also be copyrighted and any unauthorized
recording in whole or in part may be in violation of these rights.
To prevent damage which may result in fire or electric shock
hazard, do not expose this appliance to rain or moisture.
Important Safety Information
Always be careful when using your TV receiver. To reduce the risk of fire, electrical shock,
and other injuries, keep these safety precautions in mind when installing, using, and
maintaining your machine.
• Read all safety and operating instructions before operating your TV.
• Keep the safety and operating instructions for future reference.
• Heed all warnings on the TV receiver and in the operating instructions.
• Follow all operating and use instructions.
• Unplug the TV receiver from the wall outlet before cleaning. Use a damp cloth; do not use liquid or
aerosol cleaners.
• Never add any attachments and/or equipment without approval of the manufacturer. Such additions
can increase the risk of fire, electric shock, or other personal injury.
• Do not use the TV receiver where contact with or immersion in water is a possibility, such as near bath
tubs, sinks, washing machines, swimming pools, etc.
• Do not place the TV on an unstable cart, stand, tripod, bracket, or table
where it can fall. A falling TV can cause serious injury to a child or adult,
and serious damage to the appliance. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer or sold with the TV.
Follow the manufacturer’s instructions when mounting the unit, and use a
mounting accessory recommended by the manufacturer. Move the TV and
cart with care. Quick stops, excessive force, and uneven surfaces can
make the unit and cart unsteady and likely to overturn.
• Provide ventilation for the TV receiver. The unit is designed with slots in
the cabinet for ventilation to protect it from overheating. Do not block these openings with any object,
and do not place the TV receiver on a bed, sofa, rug, or other similar surface. Do not place it near a
radiator or heat register. If you place the TV receiver on a rack or bookcase, ensure that there is adequate
ventilation and that you’ve followed the manufacturer’s instructions for mounting.
• Operate your TV receiver only from the type of power source indicated on the marking label. If you are
not sure of the type of power supplied to your home, consult your appliance dealer or local power
company.
• Use only a grounded or polarized outlet. For your safety, this TV is equipped with a polarized alternating
current line plug having one blade wider than the other. This plug will fit into the power outlet
only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug
still does not fit, contact your electrician to replace your outlet.
• Protect the power cord. Power supply cords should be routed so that they won’t be walked on or
pinched by objects placed on or against them. Pay particular attention to cords at plugs, convenience
receptacles, and the point where they exit from the unit.
• Unplug the TV from the wall outlet and disconnect the antenna or cable system during a lightning
storm or when left unattended and unused for long periods of time. This will prevent damage to the
unit due to lightning and power-line surges.
• Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead
power lines or other electric light or power circuits or where it can fall into such power lines or
circuits. When installing an outside antenna system, be extremely careful to keep from touching the
power lines or circuits. Contact with such lines can be fatal.
• Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock.
• Do not insert anything through the openings in the unit, where they can touch dangerous voltage
points or damage parts. Never spill liquid of any kind on the TV.
• Ground outdoor antennas. If an outside antenna or cable
system is connected to the TV, be sure the antenna or cable
system is grounded so as to provide some protection against
voltage surges and built-up static charges. Section 810 of
the National Electrical Code, ANSI/NFPA No.70-1984, provides
information about proper grounding of the mast and
supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location
of antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
• Do not attempt to service the TV yourself. Refer all servicing to qualified service personnel. Unplug the
unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:
- when the power-supply cord or plug is damaged
- if liquid has been spilled on the unit or if objects have fallen into the unit
- if the TV has been exposed to rain or water
- if the TV does not operate normally by following the operating instructions
- if the TV has been dropped or the cabinet has been damaged
- when the TV exhibits a distinct change in performance
• If you make adjustments yourself, adjust only those controls that are covered by the operating instructions.
Adjusting other controls may result in damage and will often require extensive work by a qualified
technician to restore the TV to normal.
• When replacement parts are required, be sure the service technician uses replacement parts specified
by the manufacturer or those that have the same characteristics as the original part. Unauthorized substitutions
may result in additional damage to the unit.
• Upon completion of any service or repairs to this TV, ask the service technician to
perform safety checks to determine that the TV is in a safe operating condition.
• Keep all power adaptors apart.
Possible fire hazard.
• Keep the power adaptor away from any other heater.
Possible fire hazard.
• Remove and discard the plastic cover from the power adaptor before use.
Possible fire hazard.
• Always keep the power adaptor in a well-ventilated area.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference that may cause undesired operation.
This television receiver provides display of television closed captioning in accordance with
§15.119 of the FCC rules.
4P
FCC Information
User Instructions
The Federal Communications Commission Radio
Frequency Interference Statement includes the following
warning:
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation .
If this equipment does cause harmful interference to
radio or television receptions, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
User Information
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
If necessary, consult your dealer or an experienced
radio/television technician for additional suggestions.
You may find the booklet called How to Identify and
Resolve Radio/TV Interference Problems helpful. This
booklet was prepared by the Federal Communications
Commission. It is available from the U.S. Government
Printing Office, Washington, DC 20402,
Stock Number 004-000-00345-4 .
Warning
User must use shielded signal interface cables to
maintain FCC compliance for the product.
Provided with this monitor is a detachable power
supply cord with IEC320 style terminations.
It may be suitable for connection to any UL Listed
personal computer with similar configuration. Before
making the connection, make sure the voltage rating
of the computer convenience outlet is the same as the
monitor and that the ampere rating of the computer
convenience outlet is equal to or exceeds the monitor
voltage rating.
For 120 Volt applications, use only UL Listed detachable
power cord with NEMA configuration 5-15P
type (parallel blades) plug cap. For 240 Volt applications
use only UL Listed Detachable power supply
cord with NEMA configuration 6015P type (tandem
blades) plug cap.
IC Compliance Notice
This Class B digital apparatus meets all requirements
of the Canadian Interference-Causing Equipment
Regulations of ICES-003.
Cet appareil Numérique de classe B respecte toutes
les exigences du Règlemont NMB-03 sur les
équipements produisant des interférences au Canada.
Notice de Conformité IC
Cet appareil numérique de classe B respecte toutes les
exigences du Règlement ICES-003 sur les
équipements produisant des interférences au Canada.
VCCI
This is a Class B product based on the standard of the
Voluntary Control Council for Interference by Information
Technology Equipment (VCCI). If this is used
near a radio or television receiver in a domestic environment,
it may cause radio interference. Install and
use the equipment according to the instruction manual.
5P
Contents
6P
Using the Display Ergonomically
? Using the Computer Display
- Adjust the LCD panel so that it faces slightly downward from your eyes, and keep a
distance of at least 40 centimeters from your eyes to the panel.
- Adjust the illumination as well as the brightness and contrast of the LCD screen panel so
that the reflection of the light is minimized.
(300~1000 lux illumination is be comfortable for your eyes)
- Recommended computer use time is 6 hours a day or less. Additionally, taking a break of
10~15 minutes per hour is recommended.
- Keep a consistent distance from your eyes to the target, such as the screen, a document,
or the keyboard.
7P
Using ARM on the Outer Wall
You can use any wall mount arms manufactured by an office furniture manufacturer, You
should take into account the following conditions.
- They have to comply with VESA Mount Interface 100mm standard.
- They have to able to sustain the weight of the LCD TV.
- They have to be fixed to a position adjustable by hand.
- They have to be adjustable.
- The distance between the screw holes for fixing the arms has to be 100mm.
Additionally, refer to the installation manual supplied with the arms for installation.
Arm installation procedures
Install the arms following the procedures given below.
1. Remove all cables connected to the TV.
2. Lay the LCD TV face down on a flat surface with a cushion or some type of soft
material to protect the screen.
3. Using a screwdriver, remove the screws fixing the stand.
4. Install the steel frame of the arms, insert the attached screws into the screw holes
of the LCD TV, and then fasten the screws using a screwdriver.
? Attach the arm to the fixed board first.
? Do not use the handle screws for fixing the stand and the handle screws to fix the arms.
Use only the screws attached for the arms (M4 x 10 screws with a diameter of 4 mm,
and a length of 10 mm). If you use the stand screws to fix the arms, the TV may be fall
and get damaged, because the arms are not fixed completely.
To reattach the removed stand, use the stand screws.
? Attach the arms completely.
If the TV becomes detached from the arms, it may cause injury or damage the product.
If the TV is somehow detached accidentally, unplug the power cable from the wall outlet,
and contact your service center.
Damage may cause fire or electric shock.
8P
Using Securely
?Maintenance of the Exterior Cabinet
? Do not clean the surface of the cabinet with benzene or paint thinner, and do not spray
volatile matter such as insecticides on the surface. This may harm the coating on the
surface.
? When you clean the cabinet with a chemically treated cloth, please follow the
instructions carefully for that product.
? Clean the stains on the cabinet and the operation panel using a soft cloth.
For severe stains, clean the stains with a cloth damped with diluted mild detergent, and
then finish by cleaning the cabinet with a dry cloth.
? Do not use the following detergents to avoid harming the coating of the surface.
Alkaline detergent, alcohol-detergent, liquid compound, powdered compound, car wax, etc.
?Maintenance of the LCD Panel
?
To clean the dust on the LCD panel, lightly clean the surface of the panel with a soft dry
cloth.
If the stain on the surface of the LCD panel does not come off easily, spray an LCD panel
cleansing solution on the surface, and clean the surface with a soft cloth again. While
doing his, take care not to spill the solution so as to prevent the solution from entering the
inside of the panel.
? Best Posture to Watch TV
Keep a distance of 5~7 times the screen height from your eyes to the TV screen for
optimal viewing and to avoid eye strain.
?Checking and Replacing the Antenna
Since the antenna is exposed to wind and rain, a regular check and possible replacement
of the antenna is recommended.
Since the antenna is more easily affected when the antenna is exposed to exhaust gas or
sea air, if the video quality decreases, ask your product provider.
For optimal use
? Since the surface of the screen is fragile, do not scratch or knock it with hard objects
such as any objects harder than an HB pencil.
? Do not clean the surface with water.
9P
Before Using the TV
Overview
Front View
1. MENU: Brings up an on-screen menu.
2. VOLUME: Increases or decreases the volume. This is also used to select the
“Return/Menu” item on the on-screen menu.
3. LED Lights
4. Remote Control Sensor
5. CHANNEL: Changes channels or “Moves” to items on the on-screen menu.
6. TV/VIDEO: Selects an external device connected to the TV.
7. POWER: Turn the switch downward to turn on the TV.
List of Parts
Please make sure the following parts are included with your LCD TV.
Remote Control & Battery (1.5V AAA)
AC adapter
RF Connection Cables
Power Cord
Owner’s Instructions
Video/Voice Connection Cables
10P
Before Using the TV
Rear Panel Jacks
1. POWER INPUT CONNECTOR: Only connect with the AC adapter DC 12V/5A supplied
with this product.
2. PC INPUT JACK: Used to connect to a PC.
3. PC AUDIO INPUT JACK: Used to connect to a PC.
4. COMPONENT VIDEO INPUT JACK: Used to connect to a DVD player or a DTV receiver.
5. COMPONENT AUDIO INPUT JACK: Used to connect to a DVD player or a DTV receiver.
6. HEADPHONE JACK: Used for headphones that can be purchased additionally.
(When you are listening with headphones, the sound from the speakers is muted.)
7. SUPER VIDEO INPUT JACK: Used to connect to a DVD player, etc. that has an S-VIDEO
jack so that you can watch video in better quality.
8. VIDEO/AUDIO INPUT JACK: Used to connect a VCR, a DVD player or a camcorder.
9. TV ANTENNA INPUT JACK: Used to connect the antenna cable.
#The CONPONENT INPUT JACK complies with D1 video signal (525i signal), D2 video
signal (525p signal), D3 video signal (1125i signal) and D4 video signal (750p) from a DVD
player or a digital TV receiver.
11P
Before Using the TV
Remote Control
1. POWER: Turns the TV on and off.
2. MUTE: Temporarily cuts off the sound.
3. TV/VIDEO: Displays all available video sources.
4. PC: Switches to PC mode.
5. COMPONENT: Switches to the DVD player or the DTV transferred button
6. NUMBER BUTTONS: Selects channels directly on the TV.
7. 100: Selects channels over 100. For example, to select channel
121, press “+100,” then press “2” and “1.”
8. PRE: Moves to the previous channel.
9. MENU: Displays the OSD menu.
10. PICTURE: Configures various video modes.
11. SOUND: Configures various sound modes.
12. VOLUME (-/+): Increases or decreases the volume.
13. CHANNEL (?/?): Changes channels.
14. ASPEC: Changes the screen size.
15. EXIT: Cancels the current configuration.
16. STILL: Freezes a moving picture on the screen.
17. SOURCE: Selects the signal source for the PIP window.
18. SOUND: Exchanges the audio signal source of the main screen and the PIP window.
19. SWAP: Exchanges the video signal source of the main screen and the PIP window.
20. ROTATION: Selects the location of the PIP window.
21. CHANNEL (?/?): Selects the channel of the PIP window.
22. PIP: Switches PIP windows.
23. SCAN: Scans all channels automatically.
24. ADD: Adds a channel.
25. ERASE: Erases a channel.
26. CAPTION: Turns captions on or off (Caption boroadcast).
27. MTS: Selects stereo, mono or Separate Audio Program (SAP broadcast).
28. SLEEP: Selects a preset time interval for automatic shutoff.
29. DISPLAY: Displays the current channel and the audio-video settings.
.
12P
Before Using the TV
Installing Batteries in the Remote Control
1. Slide the cover out by pressing the ? part of the cover.
2. Install two AAA size batteries according to the correct polarity.
3. Close the cover in the arrow direction.
Using the Remote Control
The remote control works properly for the following operational range.
The remote control works up to about 7~10m from the TV, 3m to the left or right of the
TV, and to within 30 degrees from the remote control sensor of the TV.
The remote control does not work properly!
Check!
1. Are the polarities of the installed batteries correct?
2. Has the battery discharged completely?
3. Is the power cord plugged in properly or is there a power failure?
4. Is fluorescent lighting or a neon sign near the unit?
13P
Before Using the TV
Connecting VHF and UHF Antennas
TESCO 에서 준비
14P
Connections
Connecting a VCR/DVD Player
Connecting the Video or S-VHS/Audio Jack
Do not connect the video cable and the S-VIDEO cable at the same time.
You should connect only one cable at a time.
Connection Procedures
1. Connect the antenna cable to the ANTENNA IN terminal on the back of your VCR.
2. Connect the VIDEO/AUDIO INPUT jack of the TV and the video/audio output jack of
your VCR with the video/audio cables.
(Connect the cable to the terminal of the same color)
? You can use the S-VIDEO cable to connect a VCR or a DVD player for better video
quliaty.
? If your VCR does not support stereo sound, connect the mono audio out jack to the
AUDIO INPUT (left) jack.
Procedures for watching a video over a VCR
1. Turn the TV on, and select 'VIDEO' using the TV/VIDEO button on the remote control.
? If you have connected a S-VIDEO cable, select 'SVHS'.
2. Turn the VCR on, insert the tape, and press the Play button.
15P
Connections
Connecting the Antenna Input Jack
Connection Procedures
1. Connect the antenna cable to the ANTENNA IN terminal on the back of the VCR.
2. Connect a coaxial cable between the ANTENNA OUT terminal on the VCR and the
antenna terminal on the TV.
Procedures for watching a Video over a VCR
1. Set the channel select switch on the back of the video to 3 or 4.
2. Change the TV channel to 3 or 4 according to your selection of the channel select
switch.
3. Turn the VCR on, insert the tape and press the Play button.
16P
Connections
Connecting a DTV
Connection Procedures
1. Connect the COMPONENT VIDEO INPUT jack on the TV and the component video
output jack of your DTV receiver with the component video connectors (Y.Pb, and Pr).
2. Connect the left and right COMPONENT AUDIO INPUT jacks of the TV to the component
audio output jack of the DTV receiver using the audio cables.
Procedures to Watch DTV
1. Turn the TV on and select 'DTV' using the TV/VIDEO button on the remote control.
2. Turn the DTV receiver on and select the desired channel.
17P
Connections
Connecting an STB Receiver
Connection Procedures
1. Connect your STB receiver antenna cable to the antenna signal input jack on the STB
receiver tuner.
2. Connect the VIDEO/AUDIO INPUT jack of the TV and the video/audio output jack of the
STB receiver with the video/audio cables.
Procedures to Watch
1. Turn the TV on and select 'VIDEO' using the TV/VIDEO button on the remote control.
2. Turn the STB receiver on and select the desired channel using the remote control of the
STB receiver.
18P
Connections
Connecting a CATV Receiver
Connection Procedures
1. Connect the cable TV antenna cable to the antenna signal input jack of the cable TV
receiver.
2. Connect the VIDEO/AUDIO INPUT jack of the TV and the video/audio output jack of the
cableTV receiver using the video/audio cables. (Connect the cable to the terminal of the
same color).
Procedures to Watch Cable TV
1. Turn the TV on, and select 'VIDEO' using the TV/VIDEO button on the remote control.
2. Turn the cable TV receiver on and select the desired channel using the remote control
of the receiver.
19P
Connections
Connecting the Antenna Input Jack
Connection Procedures
1. Connect the cableTV antenna cable to the ANTENNA IN jack on the back of the cable
TV receiver.
2. Connect a coaxial cable between the ANTENNA INPUT jack of the TV and the antenna
output jack of the cable TV receiver.
Procedures for watching Cable TV
1. Set the channel select switch on the back of the cable TV receiver to 3 or 4.
2. Turn the TV on and change the TV channel to 3 or 4 according to the selection of the
channel select switch.
3. Turn the cable TV receiver on and select the desired channel using the remote control
of the cable TV receiver.
20P
Procedures for Using the TV
Check Before Using
Please check the following check list before using the TV.
1. Is the antenna cable connected properly?
2. Is the AC adapter connected properly?
When you connect the adapter to the unit, turn the power switch on the front panel
to “off”, and then connect the adapter cable.
When not using the adapter for a long time period, separate the AC adapter from
both the main body and the power outlet on the wall.
3. Are the remote control batteries installed properly?
4. Have the receive channels been configured?
5. Are the cables connected to any external devices connected properly?
21P
Procedures for Using the TV
Watching TV
Turning the TV On and OFF
Turn the power switch on the front panel of the unit downward to turn on the
unit.
?
When you turn the power「ON」, the screen appears and the POWER/STANDBY light
is turned off.
? ? When you turn the power 「OFF」, the screen goes blank, and the
POWER/STANDBY light turns red.
Selecting the Menu Language
1. Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select LANGUAGE using the「CHANNEL?/?」button and then press the
「VOL+」button.
4. Select the desired menu language using the 「CHANNEL?/?」button.
Press the 「EXIT」button to exit the menu.
22P
Procedures for Using the TV
Viewing the Status Information
Press the DISPLAY button on the remote control. The TV will display the input source, the
picture mode, the sound mode, the mts mode, the current time, the v-chip and the audio
signal you are listening to.
Adjusting the Volume
? Adjust the volume using the 「-VOL/VOL+」button.
Muting the Sound
? Press the「MUTE」button.
You can conveniently use the MUTE button when a telephone or a door bell rings.
To cancel, press the MUTE button again.
Viewing a Video or DVD
? Press the「TV/VIDEO」button.
For connection and setup procedures, refer to page 14~15.
23P
Procedures for Using the TV
Memorizing the Channels
Your TV can memorize and store all of the available channels for both “off-air” (antenna)
and cable channels. After the available channels are memorized, use the CHANNEL? and
CHANNEL? buttons to scan through the channels. This eliminates the need to change
channels by entering the channel digits. There are three steps for memorizing channels:
selecting a broadcast source, memorizing the channels (automatic) and adding and deleting
channels (manual).
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the
type of signal source that is connected to the TV (i.e., an antenna or a cable system).
1. Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select CHANNEL SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select ANTENNA using the「CHANNEL?/?」button and then press the
「VOL+」button.
4. Select AIR, STD, HRC, or IRC using the 「CHANNEL?/?」button.
If you are not sure which type of cable system you have, contact your cable company.
Note: STD, HRC and IRC represent various types of cable TV systems.
24P
Procedures for Using the TV
Storing Channels in Memory (Automatic Method)
The TV automatically runs through all available channels and stores them to memory. This
takes approximately one or two minutes.
1. First, select the correct signal source (AIR, STD, HRC, IRC). See steps 1~4 on the
previous page.
Note: The auto channel program does not function when the V-chip is active.
2. Select AUTOSEARCH using the「CHANNEL?/?」button and then press the
「VOL+」button.
The TV will begin storing all available channels.
After all available channels have been stored, the AUTOSEARCH menu reappears.
3. Press the 「EXIT」button to exit the menu.
Viewing Saved Channels
Press the 「CHANNEL?/?」button.
? Only saved channels are selected.
? The AUTO MEMORY function can select channels using the 「CHANNEL
?/?」button only when more than 3 channels have been saved.
25P
Procedures for Using the TV
Adding and Erasing Channels (Manual Method)
You can use this function to add channels and to delete unwanted channels after the auto
channel configuration.
1.Press the 「MENU」button.
The MENU will be displayed.
2. Select CHANNEL SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select ADD/ERASE using the「CHANNEL?/?」button and then press the
「VOL+」button.
Adding a channel
4. Select a channel to add using the「CHANNEL?/?」button and then press
the 「VOL+」button.
The OSD changes from ADD to – -- .
Deleting a channel
5. Select a channel to delete using the「CHANNEL?/?」button and then press
the 「VOL+」button.
The OSD changes from – to ADD.
Complete steps 4~5.
26P
Procedures for Using the TV
Changing Channel
You can change channels on your LCD TV by using the CHANNEL ?/? buttons, or
by direct selection using number buttons. You can use the number buttons to tune to
any channel (even one that has been erased or has not been memorized).
Using the CHANNEL buttons
Press the CHANNEL ?/? buttons to change channels.
The TV changes each channel in order, up or down, depending on which button you
press. You will see all the channels that the TV has memorized.(The TV must have
memorized at least three channels.) You will not see channels that were not
memorized or have been erased.
Using the NUMBER buttons
To change to single-digit channels(0~9) faster, press “0” before the single digit.
Example : For channel 4, press “0”,then “4”.
To select a channel over 100, press the 100, press the 100 button first.
Example : For channel 122, press ”100”,then ”2”,then ”2”.
Using the Previous Channel
Press the 「PRE」button on the remote control. The TV vhanged to the last channels
to the last channel you were watching..
27P
Operation
When the Picture Quality is poor or Unstable
Use fine tuning to adjust a particular channel for better picture quality when noise
interferes, color quality is poor, or the screen is unstable.
1. Select the channel to tune using the numeric or channel buttons.
2.Press the 「MENU」button.
The MENU will be displayed.
3. Select CHANNEL SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
4. Select FINE TUNE using the「CHANNEL?/?」button and then press the
「VOL+」button.
5. Adjust the screen until a clear screen appears using the
「CHANNEL?/?」button.
6. Press the 「EXIT」button to exit the menu.
28P
Operation
LNA (Low Noise Amplifier)
If the TV is operating in a weak signal area, sometimes the LNA function
can improve the reception (a low noise pre-amplifier boosts the incoming
signal)
1.Press the 「MENU」button.
The MENU will be displayed.
2. Select CHANNEL SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select LNA using the「CHANNEL?/?」button and then press the
「VOL+」button.
4. Select ON using the「CHANNEL?/?」button.
5. Press the 「EXIT」button to exit the menu.
29P
Operation
Selecting the Video Mode
You can select a video mode from among USER, STANDARD, DYNAMIC, or MILD mode
according to your personal preference.
Press the PICTURE button.
Whenever you press this button the video menu changes to USER ? STANDARD
?DYNAMIC?MILD mode, in this order.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PICTURE SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button twice.
3. Select the desired PICTURE MODE using the「CHANNEL?/?」button.
Whenever you press this button, PICTURE MODE is changed to USER ? STANDARD
?DYNAMIC?MILD mode, in this order.
4. Press the 「EXIT」button to exit the menu.
? PICTURE MODE
STANDARD : Select this mode when the surrounding illumination is bright.
DYNAMIC : Select this mode to increase picture clarity and sharpness.
MILD : Select this mode when viewing the TV when the light is low.
This mode lessens eye strain.
USER : Select this mode if you want to adjust the settings according to your
personal preferences.
(For procedures to customize the picture, refer to page 27.)
30P
Operation
Adjusting Manually
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PICTURE SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
3. Select the desired item to adjust using the「CHANNEL?/?」button and then
press the 「VOL+」button.
4. Select the desired status using the 「-VOL」and 「VOL+」button.
During the adjustment, an additional adjustment window will be displayed. The
adjustment window disappears and changes are applied when 3 seconds have elapsed
after the last input. In addition, PICTURE MODE is automatically changed to USER mode.
5. Press the「EXIT」button to exit the menu.
? PICTURE
CONTRAST: Determines the difference in brightness between an object and the
background.
BRIGHTNESS : Determines the brightness of the screen.
SHARPNESS : Determines the sharpness of an object image.
COLOR : Determines the color density.++
TINT : Determines the color of an object.
31P
Operation
Selecting the Sound Mode
You can select the sound mode from among USER, STANDARD, MUSIC, or SPEECH mode
according to your personal preference.
Pressing the SOUND button.
Whenever you press this button, the video menu changes to USER ? STANDARD
?MUSIC?SPEECH mode, in this order.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select SOUND SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
3. Select the desired SOUND MODE using the「CHANNEL?/?」button.
Whenever you press this button, the SOUND MODE is changed to USER ? STANDARD
?MUSIC?SPEECH mode, in this order.
4. Press the 「EXIT」button to exit the menu.
? SOUND MODE
STANDARD : Select this to listen to sound normally.
MUSIC : Select this to listen to the original sound.
SPEECH : Select this to listen to clear voice sound.
USER : Select this if you want to adjust the settings according to your personal
preferences.
(For sound adjustment procedures, refer to page 29.)
32P
Operation
Users can adjust the BALANCE, and EQUALIZER directly.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select SOUND SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
3. Select BALANCE using the「CHANNEL?/?」button and then press the
「VOL+」button.
4. Select the desired status using the 「-VOL」and 「VOL+」button.
During the adjustment, an additional adjustment window will be displayed. The
adjustment window disappears and changes are applied when 3 seconds have elapsed
after the last input. Also, the SOUND MODE is automatically changed to USER mode.
? BALANCE: Determines the volume ratio between the left and right speakers.
5. Press the「EXIT」button to exit the menu.
? Adjusting the EQUALIZER
EQUALIZE: Determines the volume of the frequency range (low to high tones).
1. Move to the EQUALIZER item using the 「CHANNEL?/?」button.
2. Move to the desired frequency using the 「VOL+」button.
120?(Low Tone)… 1K(Mid Tone)… (High Tone)10K
3. Select the desired status using the 「CHANNEL?/?」button.
? When you have adjusted the EQUALIZER, the SOUND MODE is automatically changed to
USER MODE.
33P
Choosing a Multi-Channel Sound (MTS)
Soundtrack
Depending on the particular program being broadcast, you can listen to
Stereo, Mono, or a Separate Audio Program. (SAP audio is usually a foreign-
language translation. Sometimes SAP has unrelated information like news or
weather.)
? Pressing the 「MTS」button.
Whenever you press this button, the mode changes to STEREO? MONO? SAP mode, in
this order.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select SOUND SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
3. Select MTS using the「CHANNEL?/?」button and then press the
「VOL+」button.
4. Press the 「CHANNEL?/?」button.
Whenever you press this button, the mode is changed to STEREO? MONO? SAP mode,
in ths order.
5.Press the「EXIT」button to exit the menu.
? MTS Settings
• Choose STEREOfor channels that are broadcasting in stereo.
• Choose MONO for channels that are broadcasting in mono, or if you are
having difficulty receiving a stereo signal.
• Choose SAP to listen to the Separate Audio Program, which is usually a
foreign-language translation.
34P
Operation
Changing the Screen Size
You can select a desired screen size for each video.
Press the 「SCREEN」button.
Whenever you press the SCREEN button, the screen size changes to WIDE →
NORMAL →ZOOM PANORAMA, in this order. →
(Note that you can select either WIDE or NORMAL mode in PC input mode.)
Screen Size Menu
? WIDE mode
Set the picture to 16:9 wide mode.
? NORMAL mode
Sets the picture to 4:3 normal mode.
This is a standard TV screen size.
?
ZOOM Mode
Magnifies the size of the picture on the screen.
? PANORAMA mode
Use this mode for the wide aspect ratio of a panoramic picture.
? Note
You can select only WIDE, NORMAL(4:3) screen size in the Component and
PC Mode.
35P
Operation
Viewing Picture-in-Picture
You can watch two videos on the screen simultaneously.
Pressing the 「PIP」button.
Pressing the button turns the PIP screen on or off.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select PIP SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The PIP SETUP menu will be displayed.
4. Select PIP ON/OFF using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select ON using the「CHANNEL?/?」button.
Whenever you press this button, PIP mode is turned either on or off.
Selecting OFF turns off PIP mode.
5. Press the「EXIT」button to exit the menu.
Note
? Since this product has a single tuner, you cannot watch two TV channels simultaneusly
in PIP mode.
? You can only listen to one sound output from either the main screen or the PIP window.
? Refer to the PIP configuration table (Page 65).
36P
Operation
Changing the Source of the PIP Window
You can change the video souce of the PIP window from any externally connected devices.
? Pressing the SOURCE button.
Whenever you press this button, the source of the PIP window is changed to the next
video signal of an externally connected device, in that order.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select PIP SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The PIP SETUP menu will be displayed.
4. Select PIP SOURCE using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select the desired external input signal.
Whenever you press this button, the video source is changed in the following order.
(TV->VIDEO->SVHS->DTV)
5. Press the「EXIT」button to exit the menu.
? Since this product has a single tuner, you cannot watch two TV channels simultaneusly
in PIP mode.
37P
Operation
Changing the PIP Window Channel
When the PIP window shows normal broadcasting (TV and CATV) channels, you can
change the PIP window channel.
? Press the 「CHANNEL?/?」button in the PIP function.
Whenever you press this button, the channel is changed.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select PIP SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The PIP SETUP menu will be displayed.
4. Select PIP SOURCE using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select the desired external input signal using the「CHANNEL?/?」button.
Whenever you press this button, the channel changes.
5. Press the「EXIT」button to exit the menu.
? Since this product has a single tuner, you cannot watch two TV channels simultaneusly
when in PIP mode.
38P
Operation
Selecting Audio in the PIP Screen Mode
You can select the desired audio source from either the main screen, or the PIP window.
? Pressing the 「SOUND」button.
Whenever you press this button, the mode is changed to MAIN ? SUB.
When MAIN is selected: Audio of the main screen is heard.
When SUB is selected: Audio of the PIP screen is heard.
Swapping the Main and the PIP Window
You can swap the video source of the main screen and the PIP window.
? Pressing the SWAP button.
Whenever you press this button, the video source of the main screen and PIP window
are swapped.
Changing the Location of the PIP Window
You can select the location of the PIP window from among the corners of the TV screen.
? Pressing the 「ROTATE」button.
Whenever you press this button, the PIP window moves from one corner to the next of
the TV screen.
39P
Operation
Changing the Border Color of the PIP Window
You can change the border color of the PIP window.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select PIP SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The PIP SETUP menu will be displayed.
4. Select PIP BORDER using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
Select the BORDER color using the「CHANNEL?/?」button.
Whenever you press this button, the PIP window border color is changed to
GRAY?BLACK?MAGENTA?CYAN?OFF, in this order.
5. Press the「EXIT」button to exit the menu.
40P
Freezing the Picture
You can freeze a moving picture on the screen.
Press the 「STILL」button.
Whenever you press this button, the freezing function is turned on or off.
?
Even if the picture has been freezed, the audio sound continues normally.
? The freezing function will not work for the PIP window in PIP mode.
41P
Operation
Setting the Clock
Setting the clock is neccessary for using the various timer features of the TV.
1. Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select TIME SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The TIME SETUP OSD will be displayed.
4. Move to the Hour using the「VOL+」button and then set the Hour to the
correct time using the 「CHANNEL?/?」button.
5. Move to the Minute using the 「VOL+」button and then set the Minutes to
the correct time using the 「CHANNEL?/?」button.
6. Press the「EXIT」button to exit the menu.
42P
Operation
Setting the On/Off Timer
You can set the On/Off Timer to automatically turn the TV on and off at a desired time.
The current time has to be configured first to set the On/Off Timer.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Move to TIME SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The TIME SETUP OSD will be displayed.
4. Move to TIMER using the 「CHANNEL?/?」button and then press the
「VOL+」button.
Select ON using the「CHANNEL?/?」button.
The ON/OFF TIMER works only when the timer is configured to ON.
5. Press the 「VOL+」button.
Move to ON TIME/ OFF TIME using the 「CHANNEL?/?」button.
43P
Operation
?
Turning On At 6:10 AM
1. Move to the Hours using the 「VOL+」button and then set the Hour to 6 AM
using the「CHANNEL?/?」button.
2. Move to the Minute using the 「VOL+」button and then set the Minutes to
10 using the 「CHANNEL?/?」button.
3. Press the「VOL+」button to finish the ON timer configuration.
4. Press the「EXIT」button to exit the menu.
?
Turning Off At 11:55 PM
1. Move to the Hour using the 「VOL+」button and then set the Hour to 11 PM
using the「CHANNEL?/?」button.
2. Move to the Minute using the 「VOL+」button and then set the Minutes to
55 using the 「CHANNEL?/?」button.
3. Press the 「VOL+」button to complete the OFF timer configuration.
4. Press the「EXIT」button to exit the menu.
44P
Operation
Selecting the ON Timer Channel / Adjusting the ON Timer
Volume
You can configure the channel and volume to play when the TV is turned on by the
Timer.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2.Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select TIME SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The TIME SETUP OSD will be displayed.
4. Select CHANNEL using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select the desired channel to watch when the TV is turned on using the
「CHANNEL?/?」button.
5. Press the「VOL+」button to finish the configuration.
6. Select VOLUME using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select the volume level for when the TV turns on using the
「CHANNEL?/?」button.
7. Press the「EXIT」button to exit the menu.
45P
Operation
Setting the Sleep Timer
You can shut off the TV after a desired period of time.
?
Press the 「SLEEP」button.
Whenever you press this button, the mode is changed to SLEEP OFF SLEEP 10 SLEEP → →
20 SLEEP 30 SLEEP 60,…SLEEP 120 → → → → SLEEP OFF, in this order.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select TIME SETUP using the「CHANNEL?/?」button and then press the
「VOL+」button.
The TIME SETUP OSD will be displayed.
4. Select SLEEP using the「CHANNEL?/?」button and then press the
「VOL+」button.
Configure the SLEEP time using the 「CHANNEL?/?」button.
Whenever you press the button, the SLEEP time is changed to SLEEP OFF SLEEP →
10 SL→EEP 20 SLEEP 30 SLEEP 60,…SLEEP 120 SLEEP OFF, in this order.→ → → →
5. Press the「EXIT」button to exit the menu.
46P
Operation
BLUE SCREEN Function
You can configure a blue screen to appear instead of noise when no video signal is being
received.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select BLUE SCREEN using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select ON using the 「CHANNEL?/?」button.
Whenever you press this button, the Blue Screen function is either activated or
deactivated.
4. Press the「EXIT」button to exit the menu.
47P
Operation
MELODY Function
If the MELODY function is turned on, a melody plays whenever the TV is turned on or off.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the 「VOL+」button.
3. Select MELODY using the「CHANNEL?/?」button and then press the
「VOL+」button.
Select ON using the 「CHANNEL?/?」button.
Whenever you press this button, the Melody function is turned either on or off.
4. Press the「EXIT」button to exit the menu.
48P
Operation
RESET Function
You can initialize the TV settings to the factory defaults.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select FUNCTION SETUP using the「CHANNEL?/?」button and then press
the「VOL+」button.
3. Select RESET using the 「CHANNEL?/?」button and then press the
「VOL+」button.
When you press this button, all settings are initialized with the factory defaults.
Note
After resetting, the screen goes blank and then displays a picture.
49P
Operation
Connecting to a PC
Connection Procedures
1. Connect the PC D-SUB INPUT jack of the TV and the monitor output jack of
the PC using the D-Sub cable.
2. Connect the PC AUDIO jack of the TV and the audio output jack of the PC
with the audio cable.
(This can only be applied when the PC actually has an audio output jack.)
Procedures for viewing the PC screen through the TV
1. Turn the PC on and check that the PC settings are correct.
? If the PC settings are incorrect, the screen may display a duplicated or distorted picture.
? For PC configuration procedures, refer to page 54.
2. Press the TV/SOURCE button and select PC IN PUT mode.
Else you can press the PC button on the remote control instead.
3. Adjust the PC screen.
(For adjustment procedures, refer to page 55~59.)
50P
Operation
Configuring a PC
The following PC screen configuration procedures may differ depending on the model of
your PC. This product supports DDC (Display Data Channel) to enable the automatic
configuration of the screen.
PC Configuration Procedures
1.
1. In WINDOW98/ ME/ 2000/XP, select Start-> Control Panel
2. Click the mouse ->Select Display Properties.
2 Select Display in Step 1.
3
The Display Properties window will be displayed.
1. Set the Screen resolution to 1280 by 768 pixels.
2. Set the Color quality to one of 16 bit, 24 bit, or 32 bit.
Note
. A screen resolution of WXGA(1280 X 768) provides the best screen quality.
. Configure the screen color to 16-bit, or 24-bit.
. The vertical frequency for a TFT LCD TV with a screen resolution of 1280 x 768 is 60Hz.
VESA Standard Mode
Resolution
Vertical Frequency
51P
Operation
Adjusting the PC Picture Quality
?
Adjusting the Frequency
If vertical lines appear on the PC screen, adjust the frequency.
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select FREQUENCY using the 「CHANNEL?/?」button and then adjust the
frequency using the 「VOL+」button.
During the adjustment, an additional adjustment window will be displayed.
4. Press the「EXIT」button to exit the menu.
52P
Operation
?
Adjusting the Phase
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select PHASE using the 「CHANNEL?/?」button and then adjust the phase
using the 「VOL+」button.
During the adjustment, an additional adjustment window will be displayed.
4. Press the「EXIT」button to exit the menu.
53P
Operation
Adjusting the Picture Position
If the picture is not centered in the screen, adjust the picture position by
completing the following procedures.
?
Adjusting the Horizontal Position
1. Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select H_POSITION using the 「CHANNEL?/?」buttons and adjust the
horizontal position using the「VOL+」button.
During the adjustment, an additional adjustment window will be displayed.
4. Press the「EXIT」button to exit the menu.
54P
Operation
?
Adjusting the Vertical Position
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select V_POSITION using the 「CHANNEL?/?」buttons and adjust the
vertical position using the 「VOL+」button.
During the adjustment, an additional adjustment window will be displayed.
4. Press the「EXIT」button to exit the menu.
55P
Operation
Initializing Settings (RESET)
1.Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select RESET using the 「CHANNEL?/?」buttons and then select using
the 「VOL+」button.
This returns you to the factory default screen.
4. Press the「EXIT」button to exit the menu.
56P
Operation
Auto Set
You can adjust the frequency and the phase of the PC screen automatically.
1. Press the 「MENU」button.
The OSD MENU will be displayed.
2. Select PC SETUP using the 「CHANNEL?/?」buttons and then press
the「VOL+」button.
3. Select AUTOSET using the 「CHANNEL?/?」button and then select using
the 「VOL+」button.
The PC screen is adjusted automatically.
4. Press the「EXIT」button to exit the menu.
57P
Trobleshooting
If the TV seems to have a problem, first try the following list of possible problems and
solutions before contacting a service center.
If none of these troubleshooting tips apply, do not attempt to repair the product yourself.
Call your nearest service center.
Symptoms that may appear to be a problem
The following symptoms may happen even if the TV has no problem. First try the
following list of possible problems and solutions before contacting a service center.
Symptom Possible Problem Possible Solution
No picture on the
screen, and the power
LED does not turn on.
Power connection
problem. Check the power cable
connectivity to the power
connector. Press the power switch
again.
The TV is turned on,
but there is no picture
on the screen.
The brightness is
adjusted too low.
The fluorescent
tube is out of
order.
Adjust the brightness and the
contrast so that a picture is
displayed brightly.
The fluorescent tube of a LCD TV
has a lifetime of about 50,000
hours. To replace the fluorescent
tube, contact a service center.
An afterimage is
generated when
continuously watching
a still image.
This is caused by an inherent property of LCD panels.
Depending on the number of valid pixels, there may be
black or bright pixels. These will be less than 0.005% of
the sum of all pixels. This is not a problem.
No picture on the
screen.
No audio.
Discordance
between the
external device jack
and the input
switch button
location
Adjust the input switch location.
A picture is displayed
on the screen, but
there is no audio.
The volume is
adjusted to 0.
Mute is active.
The audio cable is
disconnected.
Turn up the Volume button.
Press the Mute button again.
Check the audio cable
connectivity.
Remote control
malfunctions.
The polarity of the
batteries installed
in the remote
control is wrong.
The batteries
installed in the
remote control
have not been
discharged
completely.
Reinstall the batteries properly.
Replace the batteries with new
ones.
Noise is heard on the
radio. This may happen
when you use a
radio near the TV.
Noise may occur when you use a
radio near the TV. Keep some
distance between any radios and
the LCD TV.
No color in a color
picture. The Color density is
adjusted to 0 or
almost 0.
Adjust the Color density to 100 or
less.
Duplicated pictures on
the screen.
This
may
be
caused
by reflected
broadcasting
signals when there
is are mountains,
buildings, or
trees
Check if there are any tall objects
such as skyscrapers near your
house.
Check that the direction of the
antenna is adjusted correctly.
buildings, or trees
near your house.
Blurred or snowy
picture.
The direction of the
antenna is not
optimal.
The antenna cable
is disconnected.
Check that the direction of the
antenna is correct.
Check that the antenna cable is
connected to the ANTENNA jack
on the back of the LCD TV.
58P
First try the following list of possible problems and solutions.
If the symptom continues, turn the TV off, and call your nearest service center.
Symptom Possible Problem Possible Solution
The Signal
connection is
incorrect.
Check that the computer is turned
on.
Check the display cable
connectivity.
Check the supported input signal
specifications.
A “No input signal”
message appears
The input signal is
not supported by
the LCD TV.
Check the supported input signal
specifications.
Check the display cable
specifications.
Vertical bars appear Inappropriate clock
Perform an automatic adjustment
or adjust the clock manually.
Vertical lines and
letters are blurred. Inappropriate
phase. Perform an automatic adjustment
or adjust the phase manually.
The entire screen
flickers. This product has been optimally
set to watch TV channels in the
factory. There may be flickering
when you watch still images from
a PC. This is not a problem of the
product.
Warning
If a problem has been detected, unplug the power cable from the wall outlet first.
Using the product when it has a fault may cause electric shocks or fire. Do not place
objects near the wall outlet so that you can unplug the power cable if necessary.
59P
Specifications
The exterior design and the product specifications are subject to be changed
without prior notice due to improvements in performance.
This product is manufactured for domestic use. This product may not be used in
countries whose television system type or power voltage is different.
Model
Screen Size
17”WIDE
Viewable Screen
Size
Pixel Area
Type
LCD Pannel
Viewing Angle
Up/Down: 120 degrees
Left/Right: 150 degrees
VHF: Channel? ~ Channel ??
UHF: Channel ?? ~ Channel ??
CATV:??~??
Receiver / Channels
Television Broadcasting System: NTSC
Antenna Interface
VHF, UHF : 75?
Video Signal
NTSC-M TV/VIDEO
Video Type
CVBS, S-VHS
COMPONENT 720p, 480p, 1080i
Horizontal
Frequency 30~60 KHz PC Synchroni
zation
Vertical
Frequency 56~75 Hz
Color Quality
16,772,216 color
Maximum Resolution
1280 X 768
Separation Signal
TTL, Anode or Cathode
Audio Out 5W x 2 / 5W x 2 (2 Way)
Power Supply AC 120V,50/60Hz, DC12V/5A
Power Consumption Maximum 160W
Power Consumption When Power Saving
Mode Less than 3W
Dimension with Speaker/Monitor
Weight 7.9 Kg
Remote control,
Battery (AAA), Owner’s Instructions,
Power Cord, AC adapter, RF-
Cables,
Video/Voice Connectors.
Accessories
This device has been registered in regards to EMI for residential use. It may be
used in all areas.
60P
Apendix
Standard Signal Mode Table
A TFT LCD TV is configured to support the following 10 signal modes.
A user can register up to 10 modes.
Configure the PC display mode referring to the following table.
For configuration procedures, refer to the Appendix of the PC manual.
Resolution
Horizontal
Frequency
(Khz)
Vertical
Frequency
(Hz)
Clock Frequency
(Mhz) Polarity(H/V)
PIP Screen Configuration Table
61P
Warranty
Back Cover
DMTECH Translation Request
