DNS BT11 Wireless Speaker User Manual mini speaker manual 8 5x11in v2
SHENZHEN DNS INDUSTRIES CO., LTD. Wireless Speaker mini speaker manual 8 5x11in v2
DNS >
User Manual
Bluetooth: 2.1
Working Distance: about 10 Meters
SNR: >=80DB
Battery: 180mah 3.7V
Speaker unit: Dia 23mm
Power: 4Ohm 3W
Frequency response: 180Hz-20Khz
Charging: 5V/1A
USER MANUAL
Product Specification
□
□
□
□
□
□
□
□
Product Feature
A Smallest size of bluetooth speaker
B Bluetooth distance is 10 Meters
C Built-in Mic with hands free functionality
Operation
Bluetooth Connection
Turn the speaker on by pressing the power button for several seconds. The blue LED flashes quickly and makes a sound indicating that
the speaker is now in Bluetooth pairing mode.
SKU: XXX XXX XXXX
Model # BT11
□
□
□
□
□
Operation
Connecting to Mobile Phones/Tablets/Computers
Activate your phone's Bluetooth.
Go to your phone's Bluetooth settings and scan for new Bluetooth devices.
When your device locates BT11, click the device name and pair with it.
If you are prompted for a pairing code, enter "0000".
After successful pairing, your speaker makes a sound and the LED illuminates blue.
NOTE: Pairing time is varied with different mobile phones. You only need to pair each device once. The speaker can remember up to
the last 8 devices paired with it.
Troubleshooting
1My mobile phone can't find any
new Bluetooth devices
2Bluetooth devices can't pair up
Make sure your mobile phone allows new connections
and did not reach the maximum allowed connections.
Refer to your phone's user manual for more information.
□
□
□
Make sure the Bluetooth speaker has entered pairing
mode.
Ensure the speaker is within the effective working
range. 3My mini speaker does not play music
/ answer call when connected to a
Bluetooth mobile phone
□
□
Make sure your Bluetooth mobile phone supports A2DP
and HSF (hands-free) profile.
Ensure your Bluetooth cell phone is within effective
working range.
□Make sure the pairing password entered is “0000’.
If your are using a Bluetooth transmitter device,
please ensure the responding password of your
Bluetooth transmitter supports “0000” code.
□
Operation
Bluetooth Connection
When receiving incoming calls, the speaker provides instruction for receiving the call. Speak directly into the speaker during the
phone call.
□
Operation
Charging
Connect the micro USB charging cable to a computer or USB charger. The red LED indicates that the speaker is charging. The red
LED turns off when fully charged.
Read the following safety information before using the Bluetooth speaker.
Safety Notices
WARNING: Keep the speaker dry and do not take it to damp
places to avoid the product’s internal circuit being affected.
WARNING: Keep the product away from direct sunlight or hot places. High temperatures will shorten the life of electronic devices,
destroy the battery or distort certain plastic parts.
CAUTION: Do not attempt to disassemble this product.
CAUTION: Do not drop the speaker on the floor or other
hard surfaces. The internal circuit might get damaged.
CAUTION: Do not use harsh chemical products or
detergent to clean the product.
CAUTION: Do not expose the product to extremely cold
temperatures. It may damage the internal circuit board.
CAUTION: Do not scratch the surface with sharp tips.
Made in china
60.00mm
85.00mm
