1. User Manual
2. Users Manual

User Manual





DT311

BASICOPERATIONGUIDE





ENGLISH

INTRODUCTION

ThankyouforacquiringthelatestadditiontoDTResearch’slineoftablets—theDT311.

Featuringaslimyetrobustenclosure,theDT311with11.6”TFTdisplayispoweredbytheIntel®

processor,offeringoptimalcombinationsofperformanceandpowersavings.

TheDT311isavailablewithMicrosoft®operatingsystems.Eachsoftwareoperatingsystem

featureswebbrowser,client/servercomputingsoftware,mediaplayer,accessories,and

applicationssupport.



PACKAGECONTENTS

•OneDT311withBatteryPackandHandstrap

•CapacitiveTouchStylusandLanyard

•AC‐DCPowerAdapterwithPowerCord

•BasicOperationGuide

*Theactualpackagecontentsmayvarydependingontheconfigurationacquired.



 

DT311



DT311:



Input/OutputPortsButtonFunctions



AUSB3.0portBUTTONACTION

BHeadphoneJack1programmablebutton

CDCPowerInput2powerbutton

DSmartCardReader3KeyboardWedge

EBackCamera 



ENGLISH 2



Power/BatteryLEDStatus:

•Blueindicatesthebatteryis25%to100%charged

•Blinkingblueindicatesthebatteryischarging

•Orangeindicatesthatthebatteryisbetween11%to25%

•BlinkingOrangeindicatesthatthebatteryisbelow10%



Precautions

•AlwaysexercisecarewhenoperatingandhandlingtheDT311.

•DoNOTapplyexcessivepressuretothedisplayscreen.

•Avoidprolongedexposureofthedisplaypaneltoanystrongheatsource.Whereverpossible,theDT311

shouldfaceawayfromdirectlighttoreduceglare.

•IftheAC‐DCpoweradapterisusedtorechargeorpowerthetablet,doNOTuseanyAC‐DCadapterother

thantheoneprovidedoracquiredfromthemanufactureroritspartners.

•Intheunlikelyeventthatsmoke,abnormalnoise,orstrangeodorispresent,immediatelypoweroffthe

DT313anddisconnectallpowersources.Reporttheproblemtoyourdeviceproviderimmediately.

•NeverattempttodisassembletheDT311,asthiswillvoidthewarranty.



THEDT311

BasicFeatures



TheDT311wirelesstabletintegratesabrightandmulti‐touchdisplay,oneUSBport,andembedded

networkingelementssuchaswirelessLANandBluetooth.TheDT311iscomplementedbyasuiteof

accessories,includingbatteryexpansion,chargingcradles,andbatterychargerkit,foracomprehensiveuser

experience.

ADT311typicallyintegratesan802.11acwirelessLAN(WLAN)adapterthatmayconnecttootherwireless

devicesoraccesspoints.IfyourDT311doesnotcomewithsuchanetworkadapter,pleaseconsultyour

deviceprovidertoestablishthedesirednetworkconnectivity



ENGLISH 3

DT311



OPERATION



Internal Battery

Warning! !

TheInternalbatterypackshouldonlybereplacedbyanauthorizedDTResearchservicerepresentative.

Pleasecontactyourproductand/orserviceproviderforinternalbatteryreplacementservice.

Powering ON and OFF

ToactivatetheDT311,pushandquicklyreleasethePowerButton.Thedisplaywillcomeoninafewseconds.

ToputtheDT311inStandbymode,pushandquicklyreleasethePowerButton.ToturntheDT311offfor

extendedstorage,poweroffsafelyusinganysoftwarefunctionthat"shutsdowncomputer"providedinthe

softwareoperatingsystem.



NOTE:

Thebatterypacksshippedwithyourtabletmaybelowinpower—pleaseusetheAC‐DC

adapterwiththeDT311whensettingupforthefirsttimetofullychargetheinternalbattery

pack.YoumaychargetheexternalbatterypackwithitattachedtotheDT311,orwiththe

optionalexternalbatterychargerkit.



NOTE:

Whenthebatterypack(s)is(are)charging,theblue‐coloredBatteryLEDshouldblinkslowly.If

pluggingintheAC‐DCadapterdoesnottriggerthisblinkingactivityandtheLEDstaysdark,

thebatterypack(s)mayhavebeendrainedsubstantially.Tryunplugging/repluggingthe

AC‐DCadaptertotheDT311afewtimestoactivatethechargingprocess.



NOTE:

Toconservepower,use(pushandquickrelease)thePowerButtontoputthetabletin

“Standby”modewhilenotinuse.Pushingbrieflyonthesamebuttonwillwakeupthesystem

withinseconds.



NOTE:

AvoidusingthePowerButton(“hold4+seconds”feature)toturnoffthetablet—thisformof

hardwareshutdownisintendedtobeameansofrecoveryfromlockups,andnotasnormal

operation.



ENGLISH 4



StartUp



Ifthepowerup(fromStandbyorotherwise)issuccessful,theappropriateinterfacewillbedisplayedaftera

launchsequenceofseveralseconds.ThewirelessLANconnectionmaytake10‐15secondstobeestablished.



ConfiguringtheMobileTablet

TheDT311maybeconfiguredusingtheutilitiesandmethodsdictatedbythesoftwareoperatingsystem.The

DT311shouldbeconfigurableforvariouspropertiessuchasuserprofiles,networkfeatures,andseveral

systemelements.



WirelessNetworking

WirelessLAN

TheDT311isoftendeliveredwithanembedded(user‐inaccessible)802.11acWLANadapterequippedwitha

hiddencustomantenna.

•ThroughthesupportoftypicalWLANadapters,theDT311shouldbeabletodetectall802.11access

pointsinthevicinityforyoutoselecttheaccesspointofyourchoiceforconnection.

•TheSSIDandWEP/WPA/WPA2(ifenabled)parametersontheDT311andtheaccesspointshaveto

match.TheSSIDiscase‐sensitiveanditisrecommendedthatyouenableWEP/WPA/WPA2encryption(or

advancedalternatives)forsecureaccess.

•WhenWEP/WPA/WPA2isenabled,youmayneedtoconsultyournetworkadministratororyour

networkingequipmentliteraturetoproperlyconfigureassociatedsettingssuchasAuthenticationmode,

etc.

•Refertotheaccesspointoperatingmanualsforsettingupthe802.11accesspoints.



ENGLISH 5



DT311



Bluetooth

TheBluetoothconfigurationapplicationisenabledfromtheSystemTrayorfromtheWindowsMobility

Center.Followtheinstructionsandoptionsprovidedwithintheapplicationtoconfigureandinvoke

Bluetoothconnectivitywiththecorrespondingperipherals.



USINGTHEMOBILETABLET

PeripheralsSupport

ThroughitsUSBport,theDT311supportsawiderangeofUSB‐basedperipherals.Theseperipheralsare

applicableforsoftwareinstallation,applicationsstorage,datastorage,andsystemsoftwarerecoveryand

updates.



RemoteManagement

Dependingonsoftwareconfiguration,theDT311canbecentrallymanagedforassetmonitoringandfor

softwarecontrol.Pleaseconsultyourdeviceprovider.



ForMoreSupport

UserscandownloadtheTabletModulesBasicOperationGuidesfromtheDTResearchwebsite.



To Hold the Tablet

Lefthand:griptheleftbacksideofthetabletwithyourlefthand

fourindexfingers,withthumbrestingonthetopofthebackside

ofthetabletandpalmsecurelyagainsttheback.

Righthand:griptherightbacksideofthetabletwithyourright

handfourindexfingers,withthumbrestingonthetopoftheback

sideofthetabletandpalmsecurelyagainsttheback.



ENGLISH 6







FederalCommunicationCommissionInterference

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,

pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection

againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan

radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,may

causeharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterference

willnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor

televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuseris

encouragedtotrytocorrecttheinterferencebyoneofthefollowingmeasures:



•Reorientorrelocatethereceivingantenna.

•Increasetheseparationbetweentheequipmentandreceiver.

•Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.

•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



FCCCaution:Anychangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor

compliancecouldvoidtheuser’sauthoritytooperatethisequipment.

ThisdevicecomplieswithPart15oftheFCCRules.

Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemaynotcauseharmful

interference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay

causeundesiredoperation.





Thisdeviceanditsantenna(s)mustnotbeco‐locatedoroperatinginconjunctionwithanyother

antennaortransmitter.

ThisClass[B]digitalapparatuscomplieswithCanadianICES‐003.

Cetappareilnumériquedelaclasse[B]estconformeàlanormeNMB‐003duCanada.



ENGLISH 7



DT311

Specifications:

ItemDT311

System

CPUIntel®Core™i7,2.4GHz(4MCache,upto3.0GHz)

RAM8GB

Storage64GBto512GBflash

OperatingSystemMicrosoft®Windows®EmbeddedStandard7,7Professional,Embedded8Standardor8.1ProIndustry

Display11.6”LED‐backlightscreenwithcapacitivetouch

DisplayResolution1920x1080(Full‐HD)

NetworkInterfaceWi‐Fi802.11ac,2.4GHz/5GHzdualband;Bluetooth4.0LE

ControlSwitchand

Buttons1powerbutton,1RFswitchand2programmablebuttons

Indicator1power/batterystatusLEDand1WLANactiveLED

MicrophoneBuilt‐inmicrophonewithDSPforvideoconferencecall

Speaker2Wbuilt‐inspeaker

Camera5megapixelbackcamerawithLEDflash,autofocus,whitebalance,gaincontrolandexposurecontrol

I/OPorts

USBport1USB3.0port

AudioJack1(3.5mm)

DC‐in1

SmartCardReaderFull‐slot,readsISO7816T=0,T=1;1.8/3/5Vsmartcard

Mechanical

AC/DCAdapterInput:100–240VAC;Output:19VDC,3.42A

BatteryPackHotSwappablebattery,7.2V,6150mAh

EnclosureABS+PCplasticsandmagnesium‐aluminumalloy

StylusYes,capacitivetouchstylus

ProtectiveGripsRubberbumpersoneachcornerwithhandstrapforhandlingprotection

Dimensions(HxWxD)8.2x12.3x0.86in/208.2x312.3x22mm

Weight2.76lbs/1.25kg

Environmental

WaterandDust

ResistanceIP65

Vibrationand

ShockResistanceMIL‐STD‐810G

RegulatoryFCCClassB,CE,RoHScompliant

OperatingTemperatureOperation:0°C~40°C(Upgradeoption:‐20°C~50°C);Storage:‐20°C~60°C

Humidity0%–90%non‐condensing



DTResearch,Inc.

2000ConcourseDrive,SanJose,CA95131http://www.dtresearch.com



ENGLISH 8

BOG060815DT311ENG

FCC Regulations:

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

This device has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiated radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation If this equipment does

cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance

could void the user‘s authority to operate the equipment.

RF Exposure Information (SAR)

This device meets the government’s requirements for exposure to radio waves.

This device is designed and manufactured not to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal Communications Commission of the U.S.

Government.

The exposure standard for wireless devices employs a unit of measurement known as the

Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for

SAR are conducted using standard operating positions accepted by the FCC with the device

transmitting at its highest certified power level in all tested frequency bands. Although the

SAR is determined at the highest certified power level, the actual SAR level of the device

while operating can be well below the maximum value. This is because the device is

designed to operate at multiple power levels so as to use only the poser required to reach the

network. In general, the closer you are to a wireless base station antenna, the lower the

power output.

This device was tested according to FCC SAR procedure, and was tested directly contacted

with the Body. While there may be differences between the SAR levels of various devices

and at various positions, they all meet the government requirement.

The FCC has granted an Equipment Authorization for this device with all reported SAR

levels evaluated as in compliance with the FCC RF exposure guidelines.

DT Research 800D Mobile Tablet User Manual DT311 for FCC

DT Research, Inc. Mobile Tablet DT311 for FCC

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
