DT301A

BASICOPERATIONGUIDE



ENGLISH



INTRODUCTION

ThankyouforacquiringthelatestadditiontoDTResearch’slineoftablets—theDT301A.

Featuringaslimyetrobustenclosure,theDT301Awith10.1”capacitivetouchdisplayispowered

bytheIntel®processor,offeringoptimalcombinationsofperformanceandpowersavings.The

DT301AisavailablewithMicrosoftoperatingsystem.Theoperatingsystemfeaturesweb

browser,client/servercomputingsoftware,mediaplayer,accessories,andapplicationssupport.



PACKAGECONTENTS

•OneDT301AwithBatteryPackandHandstrap

•CapacitiveTouchStylusandLanyard

•AC‐DCPowerAdapterwithPowerCord

•BasicOperationGuide



DT301A

DT301A:



Input/OutputPortsButtonFunctions



AHeadphoneJackBUTTON ACTION

BUSB3.0Port1powerbutton

CDCPowerInput2programmablebutton

DGNSSmodule3BatteryLatch

•Pushtheswitchtounlockthelatch,thanslidethe

latchtolefttoremovethebattery.

EBackCamera(optional)

FLongRangeTansmittermodule



ENGLISH2



Precautions

• AlwaysexercisecarewhenoperatingandhandlingtheDT301A.

• DoNOTapplyexcessivepressuretothedisplayscreen.

• Avoidprolongedexposureofthedisplaypaneltoanystrongheatsource.Whereverpossible,theDT301A

shouldfaceawayfromdirectlighttoreduceglare.

• IftheAC‐DCpoweradapterisusedtorechargeorpowerthetablet,doNOTuseanyAC‐DCadapterother

thantheoneprovidedoracquiredfromthemanufactureroritspartners.

• Intheunlikelyeventthatsmoke,abnormalnoise,orstrangeodorispresent,immediatelypoweroffthe

DT301Aanddisconnectallpowersources.Reporttheproblemtoyourdeviceproviderimmediately.

• NeverattempttodisassembletheDT301A,asthiswillvoidthewarranty.



BasicFeatures



TheDT301Awirelesstabletintegratesabrightdisplay,oneUSBport,andembeddednetworkingelements

suchaswirelessLANandBluetooth,4GLTEandLongRangeTansmittermodule.TheDT301Ais

complementedbyasuiteofaccessories,includingbatteryexpansion,chargingcradles,andbatterycharger

kit,foracomprehensiveuserexperience.

ADT301Atypicallyintegratesan802.11acwirelessLAN(WLAN)adapterthatmayconnecttootherwireless

devicesoraccesspoints.IfyourDT301Adoesnotcomewithsuchanetworkadapter,pleaseconsultyour

deviceprovidertoestablishthedesirednetworkconnectivity.



ENGLISH3



DT301A



OPERATION



Internal Battery

Warning !

TheInternalbatterypackshouldonlybereplacedbyanauthorizedDTResearchservicerepresentative.

Pleasecontactyourproductand/orserviceproviderforinternalbatteryreplacementservice.

Powering ON and OFF

ToactivatetheDT301A,pushandquicklyreleasethePowerButton.Thedisplaywillcomeoninafew

seconds.ToputtheDT301AinStandbymode,pushandquicklyreleasethePowerButton.Toturnthe

DT301Aoffforextendedstorage,poweroffsafelyusinganysoftwarefunctionthat“shutsdowncomputer”

providedinthesoftwareoperatingsystem.



NOTE:

Thebatterypacksshippedwithyourtabletmaybelowinpower—pleaseusetheAC‐DC

adapterwiththeDT301Awhensettingupforthefirsttimetofullychargetheinternalbattery

pack.YoumaychargetheexternalbatterypackwithitattachedtotheDT301A,orwiththe

optionalexternalbatterychargerkit.



NOTE:

Whenthebatterypack(s)is(are)charging,theblue‐coloredBatteryLEDshouldblinkslowly.If

pluggingintheAC‐DCadapterdoesnottriggerthisblinkingactivityandtheLEDstaysdark,

thebatterypack(s)mayhavebeendrainedsubstantially.Tryunplugging/repluggingthe

AC‐DCadaptertotheDT301Aafewtimestoactivatethechargingprocess.



NOTE:

Toconservepower,use(pushandquickrelease)thePowerButtontoputin“Standby”mode

whilenotinuse.Pushingbrieflyonthesamebuttonwillwakeupthesystemwithinseconds.



NOTE:

AvoidusingthePowerButton(“hold4+seconds”feature)toturnoffthetablet—thisformof

hardwareshutdownisintendedtobeameansofrecoveryfromlockups,andnotasnormal

operation.



ENGLISH4



DT301A



StartUp

Ifthepowerup(fromStandbyorotherwise)issuccessful,theappropriateinterfacewillbedisplayedaftera

launchsequenceofseveralseconds.ThewirelessLANconnectionmaytake10‐15secondstobeestablished.



ConfiguringtheMobileTablet

TheDT301Amaybeconfiguredusingtheutilitiesandmethodsdictatedbythesoftwareoperatingsystem.The

DT301Ashouldbeconfigurableforvariouspropertiessuchasuserprofiles,networkfeatures,andseveral

systemelements.



WirelessNetworking

WirelessLAN

TheDT301Aisoftendeliveredwithanembedded(user‐inaccessible)802.11acWLANadapterequippedwitha

hiddencustomantenna.

•ThroughthesupportoftypicalWLANadapters,theDT301Ashouldbeabletodetectall802.11accesspoints

inthevicinityforyoutoselecttheaccesspointofyourchoiceforconnection.

•TheSSIDandWEP/WPA/WPA2(ifenabled)parametersontheDT301Aandtheaccesspointshavetomatch.

TheSSIDiscase‐sensitiveanditisrecommendedthatyouenableWEP/WPA/WPA2encryption(or

advancedalternatives)forsecureaccess.

•WhenWEP/WPA/WPA2isenabled,youmayneedtoconsultyournetworkadministratororyournetworking

equipmentliteraturetoproperlyconfigureassociatedsettingssuchasAuthenticationmode,etc.

•Refertotheaccesspointoperatingmanualsforsettingupthe802.11accesspoints.



ENGLISH5

DT301A



Bluetooth

TheBluetoothconfigurationapplicationisenabledfromtheSystemTrayorfromtheWindowsMobility

Center.Followtheinstructionsandoptionsprovidedwithintheapplicationtoconfigureandinvoke

Bluetoothconnectivitywiththecorrespondingperipherals.



LongRangeTansmitter

LongRangeTansmitter,theCIRRONETWIT2410,providesatransmissionrangeofapproximatelyto100

meters,supportingpoint‐to‐pointormultipointapplications.Itensuresmaximumresistancetonoiseand

multipathfadingandrobustnessinthepresenceofinterferingsignals,whileoperationinthe2.4GHzISM

bandallowslicense‐freeuseandworldwidecompliance.Asimpleserialinterfacesupportsasynchronousdata

upto230400bps.Anon‐board3KBbufferandanerror‐correctingover‐the‐airprotocolprovidesmoothdata

flowandsimplifythetaskofintegrationwithexistingapplications.



USINGTHEMOBILETABLET

PeripheralsSupport

ThroughitsUSBport,theDT301AsupportsawiderangeofUSB‐basedperipherals.Theseperipheralsare

applicableforsoftwareinstallation,applicationsstorage,datastorage,andsystemsoftwarerecoveryand

updates.



RemoteManagement

Dependingonsoftwareconfiguration,theDT301Acanbecentrallymanagedforassetmonitoringandfor

softwarecontrol.Pleaseconsultyourdeviceprovider.



ForMoreSupport

UserscandownloadtheTabletModulesBasicOperationGuidesfromtheDTResearchwebsite.



ENGLISH6



DT301A



DT301Ainstallation

ThemajorapplicationofDT301AisforArchitecturemeasurementthatisutilizedtheLongRangeTansmitter.

TheDT301Ainstallationandoperation,pleaseseethebelowphotos,iserectedonthetripod.



Thedistanceisexceed20cmbetweenDT301Amobiletabletandthebodyofoperatorthatensurethe

precisionandaccuracyofmeasurement.



ENGLISH7



DT301A



Specifications:

ItemDT301A

System

CPUIntel®6thGenerationCore™i7,2.6GHz

RAM8GB

Storage128GBflash

OperatingSystemMicrosoft®Windows®7ProfessionalorWindows®10IoTEnterprise

Display10.1”LED‐backlightscreenwithmultitouchcapacitivetouch

DisplayResolution1920x1200

NetworkInterfaceWi‐Fi802.11ac,2.4GHz/5GHzdualband;Bluetooth4.1LE

MobileBroadbandprovidesLTE,WCDMA,CDMA

GNSSModuleU‐bloxM8GNSSmodulewithconcurrentreceptionofGPSandGLONASS.

LongRangeTansmitter2.4GHzto2.483GHz,FCC Part 15.247 and ETSI 300328 rules, license free

ControlSwitchand

Buttons1powerbutton,1Wifiswitchand3programmablebuttons

Indicator1power/batterystatusLED

MicrophoneBuilt‐inmicrophonewithDSPforvideoconferencecall

SpeakerBuilt‐inspeaker

Camera(optional)5megapixelbackcamerawithLEDflash,autofocus,whitebalance,gaincontrolandexposurecontrol

I/OPorts

USBport1USB3.0port

AudioJack1(3.5mm)

DC‐in1

MechanicalandEnvironmental

AC/DCAdapterInput:100–240VAC;Output:19VDC,3.42A

BatteryPackHotSwappablebattery,11.4Vdc,5400mAh,61.56Wh

BackupBattery3.7Vdc,240mAh

EnclosureABS+PCplasticsandmagnesium‐aluminumalloy

StylusCapacitivetouchstylusordigitizerdigitalpen

ProtectiveGripsRubberbumpersoneachcornerforhandlingprotection

Dimensions(HxWxD)7.5x10.98x0.86in/190x279x21.9mm

Weight2.86lbs/1.3kg

RegulatoryFCCClassB,CE,RoHScompliant

OperatingTemperatureOperation:0°C~45°C;Storage:‐20°C~60°C

Humidity0%–90%non‐condensing



DTResearch,Inc.

2000ConcourseDrive,SanJose,CA95131http://www.dtresearch.com



ENGLISH8



FCC Warning:

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.



This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in

a residential installation. This equipment generates, uses and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one or more of the following measures:



‐Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s

authority to operate the equipment.



RF Exposure Information (SAR) 

This device meets the government’s requirements for exposure to radio waves.

This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission of the U.S. Government.

The exposure standard for wireless devices employs a unit of measurement known as the Specific Absorption

Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. *Tests for SAR are conducted using standard

operating positions accepted by the FCC with the device transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR

level of the device while operating can be well below the maximum value. This is because the device is

designed to operate at multiple power levels so as to use only the poser required to reach the network. In

general, the closer you are to a wireless base station antenna, the lower the power output.

This device was tested according to FCC SAR procedure, and was tested directly contacted with the Body.

While there may be differences between the SAR levels of various devices and at various positions, they all

meet the government requirement.

The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in

compliance with the FCC RF exposure guidelines.

When the device installed for distance measurement, please make sure the device be installed and operated with

minimum distance 20cm between the radiator &you body.

SARinformationonthisdeviceisonfilewiththeFCCandcanbefoundundertheDisplayGrantsectionof

www.fcc.gov/eot/ea/fccidaftersearchingonFCCID:YE3801I.



Canada,ISEDCNotices

ThisdevicecomplieswithISEDC’slicence‐exemptRSSs.Operationissubjecttothefollowingtwo

conditions:

(1) Thisdevicemaynotcauseinterference;and

(2) Thisdevicemustacceptanyinterference,includinginterferencethatmaycauseundesired

operationofthedevice.



Canada,avisd'ISEDC

LeprésentappareilestconformeauxCNRd'ISEDCapplicablesauxappareilsradioexemptsde

licence.L'exploitationestautoriséeauxdeuxconditionssuivantes:

(1)l'appareilnedoitpasproduiredebrouillage,et

(2)l'utilisateurdel'appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesile

brouillageestsusceptibled'encompromettrelefonctionnement.



Usersshouldalsobeadvisedthathigh‐powerradarsareallocatedasprimaryusers(i.e.priorityusers)

ofthebands5250‐5350MHzand5470‐5725MHzandthattheseradarscouldcauseinterference

and/ordamagetoLE‐LANdevices.5GHzWifiBand1shouldindooruseonly.



Devraientégalementêtreinforméslesutilisateursquelesradarsàhautepuissance

sontdésignéscommeutilisateursprincipaux(c.‐à‐utilisateursprioritaires)desbandes5250‐5350MHzet

5470‐5725MHzetquecesradarspourraientprovoquerdesinterférenceset/ouendommagerles

appareilsLE‐LAN.LeWifi5GHznedoitêtreutiliséqu'àl'intérieur.



RadioFrequency(RF)ExposureInformation

TheradiatedoutputpoweroftheWirelessDeviceisbelowtheISEDCradiofrequencyexposure

limits.TheWirelessDeviceshouldbeusedinsuchamannersuchthatthepotentialforhuman

contactduringnormaloperationisminimized.

ThisdevicehasbeenevaluatedforandshowncompliantwiththeISEDCSpecificAbsorptionRate

(“SAR”)limitswhenoperatedinportableexposureconditions.



Whenthedeviceinstalledfordistancemeasurement,pleasemakesurethedevicebeinstalledand

operatedwithminimumdistance20cmbetweentheradiator&youbody.



Informationsconcernantl'expositionauxfréquencesradio(RF)

Lapuissancedesortieémiseparl’appareildesansfilestinférieureàlalimited'expositionaux

fréquencesradiod'ISEDC.Utilisezl’appareildesansfildefaçonàminimiserlescontactshumainslors

dufonctionnementnormal.



Ce dispositif a été évalué pour et démontré conforme à la Taux ISEDC d'absorption spécifique

("SAR") des limites lorsqu'il est utilisé dans des conditions d'exposition portatifs.

Lorsquel'appareilestinstallépourlamesurededistance,veuillezvousassurerquel'appareilest

installéetutiliséavecunedistanceminimalede20cmentreleradiateuretvotrecorps.



DT Research 801I Mobile Tablet User Manual

DT Research, Inc. Mobile Tablet

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
