INSTRUCTION MANUAL
DV-700S
DVD PLAYER
1
TABLE OF CONTENTS
IMPORTANT SAFETY PRECAUTIONS .... 2
FEATURES ............................................. 5
ABOUT DISC ......................................... 6
BEFORE OPERATION............................. 8
PREPARATIONS BEFORE OPERATION. 10
Front Panel..................................................... 10
Rear Panel...................................................... 11
VFD................................................................. 12
Names and Layout of Remote Controls ......... 13
CONNECTIONS ................................... 14
BASIC OPERATIONS............................ 15
Play Discs ....................................................... 15
System Setting................................................16
V-Mode .......................................................... 16
Display............................................................ 16
Fast Play......................................................... 17
Slow Play........................................................ 17
Pause/ Step..................................................... 17
Select Audio Language................................... 18
Select Channels.............................................. 18
Selecting 3D Audio......................................... 18
MICROPHONE CONTROL.................... 19
Microphone Setup.......................................... 19
Tone Control................................................... 20
PLAYING A DESIRED SCENE............... 21
To skip scenes in a disc................................... 21
Directly moving to a desired title (DVD) ......... 21
Playing a disc containing MP3 files................ 22
Repeat Play .................................................... 22
Repeating a defined period from A to B (DVD)
.. 23
Select a Subtitle Language............................. 23
Searching.........................................................24
PLAY DISCS IN VARIOUS WAYS.......... 26
Select Angle.................................................... 26
Zoom Play....................................................... 26
Mark............................................................... 26
Program Play (CD, MP3 only)......................... 27
Digest Play (CD only)...................................... 28
Playing DivX disc on CD-R(W) .........................28
Play MP3 or JPEG........................................... 29
FUNCTION SETTING ........................... 30
Menu Setting.................................................. 30
General Setup................................................. 32
Audio Setup.................................................... 33
Preference Setup ............................................ 34
OTHERS............................................... 36
Troubleshooting ............................................. 36
Technical Specifications.................................. 37
2
IMPORTANT SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and servicing
instructions in the literature accompanying the
appliance.
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
IMPORTANT FOR LASER PRODUCTS
• LASER This Digital Video Disc Player employs a Laser System. To ensure proper use of this product please
read this owner’s manual carefully and retain for future reference. Should the unit require
maintenance, contact an authorized service location - see service procedure.
Use of control adjustments or the performance of procedures other than those specified may result
in hazardous radiation exposure.
To prevent direct exposure to the laser beam, do not try to open the enclosure. Visible laser
radiation when open and interlocks defeated.
DO NOT STARE INTO THE BEAM.
• DANGER Visible laser radiation when open and interlock failed or defeated.
Avoid direct exposure to beam.
• CAUTION Do not open the top cover. There are no user serviceable parts inside
the Unit; leave all servicing to qualified service personnel.
CLASS 1
LASER PRODUCT
CAUTION: Any changes or modification in construction of this device which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
MACROVISION
This product incorporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN SAVE MODE. WHEN
THE SCREEN SAVE MODE IS KEPT MORE THAN AN HOUR, THE SET ENTERS STAND-BY MODE.
IMPORTANT SAFETY PRECAUTIONS
3
This set has been designed and manufactured to assure
personal safety. Improper use can result in electric shock or
fire hazard. The safeguards incorporated in this unit will
protect you if you observe the following procedures for
installation, use and servicing. This unit is fully transistorized
and does not contain any parts that can be repaired by the
user.
1 READ INSTRUCTIONS
All the safety and operating instructions should be read
before the unit is operated.
2 RETAIN INSTRUCTIONS
The safety and operating instructions should be retained
for future reference.
3 HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
4 FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5 CLEANING
Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
6 ATTACHMENTS
Do not use attachments unless recommended by the
unit’s manufacturer as they may cause hazards.
7 WATER AND MOISTURE
Do not use this unit near water- for example, near a
bath tub, wash bowl, kitchen sink or laundry tub, in a
wet basement, or near a swimming pool.
8 ACCESSORIES
Do not place this unit on an unstable cart, stand,
tripod, bracket, or table. The unit may fall, causing
serious injury to a
child or adult as well
as serious damage to
the unit. Use this unit
only with a cart, stand ,
tripod, bracket, or
table recommended by
the manufacturer.
8A A unit and cart combination should be moved with
care. Quick stops, excessive force, and uneven surfaces
may cause the video product and cart combination to
overturn.
9 VENTILATION
Slots and openings in the case are provided for
ventilation to ensure reliable operation of the unit and
to protect it from overheating. These openings must not
be blocked or covered. These openings must not be
blocked by placing the unit on a bed, sofa, rug, or other
similar surface. This unit should never be placed near or
over a radiator or heat radiator. This unit should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.
10 POWER SOURCES
This unit should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult
your video dealer or local power company. For units
intended to operate from battery power, or other
sources, refer to the operating instructions.
11 GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating -
current line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way.
This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug still fails to fit, contact your electrician to replace
your obsolete outlet.To prevent electric shock, do not
use this polarized plug with an extension cord,
receptacle, or other outlet unless the blades can be fully
inserted without blade exposure. If you need an
extension cord, use a polarized cord.
12 POWER-CORD PROTECTION
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs and the point where they exit from the
unit.
13 LIGHTNING
For added protection for this unit during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system.
PORTABLE CART WARNING
(symbol provided by RETAC)
IMPORTANT SAFETY PRECAUTIONS
4
This will prevent damage to the unit due to lightning
and power line surges.
14 DISC TRAY
Keep your fingers well clear of the disc as it is closing. It
may cause serious personal injury.
15 OVERLOADING
Do not overload wall outlets or extension cords as this
can result in a risk of fire or electric shock.
16 OBJECT AND LIQUID ENTRY
Never press objects of any kind into this unit through
openings as they may touch dangerous voltage points
or “short-out” parts that could result in a fire or electric
shock. Never spill liquid of any kind on the unit.
17 BURDEN
Do not place a heavy object on or step on the product.
The object may fall, causing serious personal injury and
serious damage to the product.
18 DISC
Do not use a cracked, deformed or repaired disc. These
discs are easily broken and may cause serious personal
injury and product malfunction.
19 SERVICING
Do not attempt to service this unit yourself as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
20 DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions.
A. When the power-supply cord or plug is damaged.
B. If liquid has been spilled, or objects have fallen into
the unit.
C. If the unit has been exposed to rain or water.
D. If the unit does not operate normally by following the
operating instructions. Adjust only those controls
that are covered by the operating instructions.
Improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the unit to its normal
operation.
E. If the product has been dropped or the cabinet has
been damaged.
F. When the unit exhibits a distinct change in
performance-this indicates a need for service.
21 REPLACEMENT PARTS
When replacement parts are required, have the service
technician verify that the replacements he uses have the
same safety characteristics as the original parts. Use of
replacements specified by the unit manufacturer can
prevent fire, electric shock, or other hazards.
22 SAFETY CHECK
Upon completion of any service or repairs to this unit,
ask the service technician to perform safety checks
recommended by the manufacturer to determine that
the unit is in safe operating condition.
23 WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only
as recommended by the manufacturer.
24 HEAT
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
FEATURES
5
OUTSTANDING SOUND QUALITY
Dolby Digital system developed by Dolby Laboratories and DTS
developed by DTS Inc., features high quality surround sound which can be played
in DVD or CD disc at home, to reproduce high quality sound effects.
HIGH DEFINITION
The unit adopts MPEG2 coding format and brings the high horizontal resolution.
UNIQUE FUNCTIONS
Multi-angle and multi-language bring unique trick functions.
Parent lock makes it easy to control the content of discs.
SCREEN
Ordinary screen and wide screen (16:9) are available.
COMPATIBILITY
The unit can play DVD-video discs, and is compatible with CD, CD-G, CD-R, CD-RW,
PIC-CD, MP3 discs also can do DVD-R, DVD+R, DVD-RW, DVD+RW of video format.
ZOOM
It can enlarge pictures.
MULTI-FUNCTIONS
Fast forward, fast reverse, forward and reverse slow, frame play, repeat play and
program play.
TIME SEARCH
It can search a specific part on a disc, especially good for watching fiction movies.
RESUME PLAY
It can memorize the position where the disc is stopped and resume playback.
VIDEO OUTPUT
Standard video, S-video, RGB signal output mode.
AUDIO OUTPUT
Analog audio output, coaxial and optical digital audio output, can be connected
with the appropriate amplifier to enjoy high-quality sound effects.
KARAOKE
Microphone input, KARAOKE channel selection.
ABOUT DISC
6
PRINCIPLES FOR WRITING
PLAYABLE DISCS / NONE PLAYABLE DISCS
This manual mainly introduces how to use buttons on the remote control.
You may operate the unit if the buttons on the unit have the same or similar names
as or to those on the remote control.
TITLE
The images or music of a DVD are divided into some units, among which title is the
biggest one.
When playing a DVD, the movie is the title.
When playing a CD, the combined tracks make up the title.
CHAPTER
It is smaller than title among the units of a DVD. A title is made up of several
chapters , and each chapter has a number for search. But some discs may not
have numbered chapters.
STRUCTURE OF DVD STRUCTURE OF CD
DISC
TITLE
CHAPTER
DISC
TRACK
Disc type Playable Restriction
DVD-video Possible Region number 2 or Region number All
CD-G Possible Playback audio/graphic file
CD-R/ CD-RW Possible * Not support discs
CD-ROM/ DVD-ROM Impossible 1. PC application files on CD-R or CD-RW
MP3 Possible 2. CD-ROM / DVD-ROM for PC application only
DVD-R/ DVD-RW Possible 3. CD-MP3 files under windows format
DVD+R/ DVD+RW Possible DVD video
DVD+RW Possible DVD video
JPEG Possible Total disc capacity: over 4M, Each file : under 1M
DVD-RAM Impossible
ABOUT DISC
7
TRACK
In a CD, each track has a number to enable search functions.
REGION MANAGEMENT INFORMATION
This unit is designed and manufactured to respond to the Region Management
information that is recorded on a DVD disc. The region number of this player is
“2”. If the region number described on the DVD discs does not correspond to the
Region number of this player, the player will not play this disc. This player will
play DVD discs made for “ALL” regions. Therefore, this player will play DVD discs
marked with labels containing the region number “2” or “ALL”.
(Region 2) (Region ALL)
2
SCENE
The menu pictures, motion and motionless pictures of a CD can be divided into some
parts, these parts are scenes. Each scene has a number for search.
BEFORE OPERATION
8
SECURITY
• Before operation, check if the voltage of the unit is in line with the local voltage.
• Hold the plug to disconnect it from the mains outlet. Do not pull the power cord.
• When the plug of the unit is connected to the mains outlet , the unit will be still
connected to AC even if the power is turned off.
• Disconnect the plug as soon as liquid or objects enter the unit. The unit can not be
used until being checked by experts.
• Do not open the cabinet as laser rays employed by the unit may damage eyes. Any
servicing should be done by qualified service personnel.
PLACEMENT
• Put the unit where ventilation is good enough to prevent overheating.
• Never put the unit in direct sunlight or near heat sources.
• Put the unit horizontally, never put any heavy object on the unit.
• To protect the pickup, do not put the unit where there is dust. If there is dust on
the pickup, use a cleaning disc to clean it. Paying particular attention to the
operating instructions of the cleaning disc.
CONDENSATION
Moisture will appear on the pickup lens in the following cases:
• The unit is suddenly moved from a cold place to a warm place.
• The unit is put in a room with a heater, or in cold air from an air-conditioner.
• Using the unit in a humid place. In these cases, the unit can not work. Unload the
disc and leave the unit on for about one hour to evaporate the moisture.
CLEANING
• Use a soft cloth with a little neutral detergent to wipe the cabinet, panel and
controls.
Never use abrasive paper, polishing powder, solvent like alcohol or gasoline.
HANDLING DISC
CLEANING DISC
•To keep the disc clean, do not touch the playsides of the disc.
•Do not attach paper or tape to the disc.
•Keep the disc away from direct sunlight or heat sources.
•Store the disc in a disc case after playback.
•Before playback, wipe the disc outward from the centre with clean cloth.
•Do not use any type of solvent such as thinner, benzine, commercially available
cleaners or antistatic spray.
BEFORE OPERATION
9
CHECK ACCESSORIES
USE REMOTE CONTROL
Check if you have all the accessories after the carton is opened.
1 Open the battery compartment.
2 Insert two AAA batteries, make sure to match "+" and "-" of the batteries to
the marks in the battery compartment.
3 Close the battery compartment.
4 Point the remote control at the remote sensor.
1. Batteries can last for about 6 months generally. Change the batteries of that does not
work.
2. If the remote control is not used for a long time, remove the batteries to prevent battery
leakage.
- UM-4 +
N
Note:
Remote control AAA batteries Video/Audio cord Instruction manual
PREPARATIONS BEFORE OPERATION
10
FRONT PANEL
!STANDBY/ON button
To switch the unit On or Off when connected to AC power outlet
@OPEN/CLOSE button
To open or close the disc tray.
#PLAY button
To play the loaded disc. Press this button to go to the preferred item when the menu is
displayed on the TV screen.
$PAUSE button
Used to view one frame at a time during play. Press PLAY button for normal play.
%STOP
^PREV button
To skip back from the current chapter (for DVD) or track (for CD).
&NEXT button
To skip forward to the next chapter (for DVD) or track (for CD).
*REMOTE SENSOR
Receives a light signal from the remote control.
(DISPLAY
Displays operation status
)Microphone Jack
1Microphone Level adjustment knob
!*1) ( @ # $ % ^ &
DV-700S-GB 2006.3.7 2:57 PM ˘`10
PREPARATIONS BEFORE OPERATION
11
REAR PANEL
!AUDIO OUT (L/R TRACK)
Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier.
@VIDEO OUT
Connects composite video signal to input AV or PHONO sockets of TV or monitor to achieve
high fidelity colour reproduction.
#EURO AV JACK
If VIDEO OUT phono is not utilized, the SCART socket can be used to connect to a TV set,
monitor or VCR.
$POWER SUPPLY SOCKET WIRE
Creates POWER between wall outlet and the unit.
%DIGITAL AUDIO OPTICAL OUT
Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.
^S-VIDEO OUTPUT
Connects to TV or monitor equipped with S-VIDEO input. In order to achieve a sharper and
cleaner picture than when connected via VIDEO OUT (composite video).
&DIGITAL AUDIO COAXIAL OUT
Connects digital audio under play mode into an AV amplifier or a receiver equipped with
digital audio decoder for you to enjoy the theatre-quality sound in your home.
! ^
$
&%
#@
DV-700S-GB 2006.3.7 2:57 PM ˘`11
PREPARATIONS BEFORE OPERATION
12
VFD
D
!Recognized DISC TYPE indicator
: DVD
@Recognized DISC TYPE indicator
: HDCD
#PBC indicator
This indicator is lit up in selecting PBC
ON while this indicator disappears in
selecting PBC OFF.
$DVD/CD indicator
Indicates the chapter or track number.
%DVD/CD indicator
Indicates the hour.
^DVD/CD indicator
Indicates the minutes.
&DVD/CD indicator
Indicates the seconds.
*Recognized DISC TYPE indicator
: MP3
(Recognized DISC TYPE indicator
: CD.
)DISC LOAD/PLAY indicator
This indicator is lit up after
recognizing the disc.
1PLAY/ PAUSE indicator
2REPEAT MODE indicator
: In case you want to repeat and
play a chapter or track.
ALL : In case you want to repeat
and play a title or disc.
3MP3 indicator
Indicates the track number when MP3
disc is played
4NUMBER/ CHARACTER indicator
Chapter, track number, and time are
displayed in loading DVD/CD disc,
while track number and time are
displayed in loading MP3.
: Tray is opened
: Tray is closed
: Disc is loaded
: There is no disc in tray
: Disc has some error
5DVD AUDIO STREAM indicator
Indicates the audio type of the
disc under play is DOLBY DIGITAL.
6DVD AUDIO STREAM indicator
:dts
* ) 32 45( 61
! @ # $ % ^ &
DV-700S-GB 2006.3.7 2:57 PM ˘`12
PREPARATIONS BEFORE OPERATION
13
NAMES AND LAYOUT OF REMOTE CONTROLS
POWER BUTTON
DISPLAY BUTTON
ANGLE
BUTTON
SETUP
BUTTON
TITLE/PBC BUTTON
UP/DOWN/LEFT/
RIGHT DIRECTION
BUTTON
SEARCH BUTTON
MARK BUTTON
PAUSE BUTTON
STEP BUTTON
AUDIO BUTTON
REPEAT BUTTON
LOWER TONE
VOLUME “+/-” BUTTON
ONE CHAPTER/TRACK
BACKWARD BUTTON
FAST BACKWARD
SEARCH BUTTON
SUBTITLE BUTTON
A-B REPEAT BUTTON
ATONIC TONE
OPEN/CLOSE BUTTON
NUMBER BUTTON
MENU BUTTON
RETURN BUTTON
V-MODE BUTTON
STOP BUTTON
RAISE TONE
SYSTEM BUTTON
INTRO BUTTON
ZOOM BUTTON
PROGRAM BUTTON
ONE CHAPTER/TRACK
FORWARD BUTTON
PLAY/ENTER BUTTON
MUTE BUTTON
3D SURROUND BUTTON
FAST FORWARD
SEARCH BUTTON
SLOW BUTTON
CHANNEL BUTTON
* After setting the mode by using SETUP menu (for example, PAL select in NTSC/PAL/AUTO
setup), the setting is kept though you switch the unit off and turn it on.
DV-700S-GB 2006.3.7 2:57 PM ˘`13
CONNECTIONS
14
CONNECTED TO A TV AND AN ORDINARY AMPLIFIER
Turn off all equipment before operation.
The unit has many kinds of output modes like A/V output, S-VIDEO output and digital
signal output (COAXIAL, OPTICAL). You may select as you need.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-
D symbol are trademarks of Dolby Laboratories. Confidential Unpublished
works.
©1992-1997 Dolby Laboratories, Inc. All rights reserved.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
@#!
CB
A
Connects either
!
,
@
+A,
#
+A,
@
+B,
#
+B,
@
+C,
#
+C,
@
+D
or
#
+D.
2 SPEAKERS
D
DV-700S-GB 2006.3.7 2:57 PM ˘`14
BASIC OPERATIONS
15
PLAY DISCS
Press "POWER" button on the TV and audio
system, Press "TV/VIDEO" button on the TV, select
VIDEO mode (TV).
Select S-Video mode if using an S-VIDEO
connection.
1
Select the correct audio input on the amplifier.
• Each amplifier is different from another, please
refer to the manual for the amplifier. (e.g.,
connect the audio output of the DVD player to
the DVD audio input of an amplifier.)
2
Press "STAND BY/ON" button on the front panel or " " button on the
remote control to turn the unit on.
3
Press "OPEN/CLOSE " button to open the disc tray and insert the disc
with its label upward. Press "OPEN/CLOSE " button again to close
the disc tray. The unit begins to read the disc. The TV screen shows the
DVD menu and title menu.
• When playing a DVD, DVD menus and titles are displayed on TV
screen.
• In the case of CD, the disc plays in order of its track number.
4
Stop playback.
Press .
5
Press to remove the disc.
6
TV/VIDEO
DVD/LD
The Step2 can be
cancelled if you
do not
connect it to the
amplifier.
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`15
BASIC OPERATIONS
16
SYSTEM SETTING
V-MODE (When selecting RGB or Composite)
According to the system of the TV to be connected, set the system of the unit to
make it match the TV.
Press SYSTEM button on the remote control, then choose TV TYPE.
SYSTEM
V-MODE
• Press the V-MODE on the remote control to select RGB or
Composite Video.
When you connect the Composite, picture is not
displayed, press the V-MODE on the remote control
to select Composite.
DISPLAY
Each time you press the “DISPLAY” button when playing a disc, the TV screen shows
the information as :
TITLE ELAPSED ➝TITLE REMAIN ➝CHAPTER ELAPSED ➝
CHAPTER REMAIN ➝DISPLAY OFF
DISPLAY
SINGLE ELAPSED ➝SINGLE REMAIN ➝TOTAL ELAPSED ➝TOTAL REMAIN
➝DISPLAY OFF
CHAPTER ELAPSED ➝CHAPTER REMAIN ➝DISPLAY OFF
DVD
CD
MP3
PAL
AUTO NTSC
• Each time the user presses the [SYSTEM] button, the video
output system changes as belows.
• When you press the [SYSTEM] button, the TV screen shows
the information as : “If you want to change, press
[SYSTEM] again.” Press the [SYSTEM] button again, the
video out system changes as follows.
DV-700S-GB 2006.3.7 2:57 PM ˘`16
BASIC OPERATIONS
17
FAST PLAY
When playing disc, you may play it forward fast or reverse it fast to find what you need.
Press √√ to play forward fast. Each time you
press the button, the speed of picture
changes like those shown on the right.
1
Press œœ to reverse the disc fast. Each time
you press the button, the speed of picture
changes like those shown on the right.
2
Press PLAY to
play normally .
Press PLAY to
play normally .
SLOW PLAY
PAUSE/ STEP
Enjoy slow motions by the following steps.
Press "SLOW" button to play slowly.
SLOW
• DVD
FF X2
FF X4
FF X8
FF X16
PLAY
1
2
3
4
5
FR X2
FR X4
FR X8
FR X16
PLAY
1
2
3
4
5
SF X 1/2
SF X 1/4
SF X 1/8
SR X 1/2
SR X 1/4
SR X 1/8
PLAY
1
2
3
4
5
6
7
Press PAUSE on the remote control to make the playback pause.
Pressing STEP again moves the picture forward frame by frame.
Press PLAY to
play normally
when playing fast.
The marked FAST
PLAY speed on
owner’s manual
and real fast play
speed can be
different
depending on
which disc you
play.
N
Note:
N
Note:
N
Note:
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`17
BASIC OPERATIONS
18
SELECT AUDIO LANGUAGE
You can choose the language according to your choice when playing a multi-
language DVD.
Press “AUDIO” button, select different languages.
SELECT CHANNELS (CD, MP3)
You may select the right channel or left channel or stereo from a multi-channel.
Press the "CHANNEL" button, the screen shows alternately the choices below and
select the desired audio channel:
1. Different discs have different languages
2. You can press the "AUDIO" button to choose the
language you want when you play multi-language DVD
discs.
CHANNEL
AUDIO
LEFT
MONO
RIGHT
MONO
STEREO
MIXED
MONO
SELECTING 3D AUDIO
This function outputs 3D effects on the stereo audio analog output where 3D effects
are broken down into 7 surround modes.
Press the [3D] button.
Every time the user presses the [3D] button,
STANDARD, CLASSIC, JAZZ, ROCK, POPS,
BALLAD and DANCE appear one by one.
1
Select the desired 3D sound mode.
2
3D
You can use the channel function when you play the disc, you can choose mono
audio output ( left or right channel ), stereo or mix-mono.
*Attention:
Please select the AUDIO language in SETUP menu to keep the setting!!!
N
Note:
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`18
MICROPHONE CONTROL
19
Microphone Set up
Turn on Microphone Switch.
1
1
Connect the Microphone to the input socket on the front panel.
2
2
Insert the Karaoke disc (label side uppermost) and select track to
play.
3
3
Adjust the microphone level on the front panel of DVD.
4
4
Select either the Left, Right, Mixed or Stereo mode, using channel
button on the remote control.
5
5
Adjust to a comfortable volume using the volume (+/-) button on
the remote control of the DVD player and the volume on the
Monitor/TV.
6
6
(not supplied)
DV-700S-GB 2006.3.7 2:57 PM ˘`19
MICROPHONE CONTROL
20
TONE CONTROL
You may change the pitch to adapt to your voice
• Press to raise the pitch.
Each time you press the button, the pitch is raised by one step. It can be raised by 7
steps at the most.
• Press to lower the pitch.
Each time you press the button, the pitch is lowered by one step. It can be lowered
by 7 steps at the most.
• Retune to the preliminary atonic-tone.
#
b
DV-700S-GB 2006.3.7 2:57 PM ˘`20
PLAYING A DESIRED SCENE
21
TO SKIP SCENES IN A DISC
Press √√
■
to move to the next chapter (or track).
The current chapter (or track) moves to the next chapter (or track).
1
Press
■
œœ to move to previous chapter (or track).
The current chapter (or track) moves to the previous chapter (or track) or
first scene of current chapter (or track).
2
DIRECTLY MOVING TO A DESIRED TITLE (DVD)
Press the [TITLE/PBC] or [MENU]
button.
A list of the titles on the disc is
displayed.
If using some disc, the menu screen
will appear only when the disc has PBC
function and PBC ON is activated.
1
Press the [PLAY] button after pressing the [œ √…†] or number
button to select the desired title.
The selected title now starts playing.
2
Some movie discs may contain multiple titles. If the disc has a movie title menu
recorded on it, the [TITLE/PBC] button can be used to select the movie title. Details of
operation may differ depending on the disc used.
PLAY MOVIE
PLAY MOVIE
SETUP
SCENE SELECTION
SPECIAL FEATURES
You can select
the desired title
directly by using
number button.
* In the case of PBC play, press RETURN to return to the sub-menu, press
it again to return to the home menu.
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`21
PLAYING A DESIRED SCENE
22
PLAYING A DISC CONTAINING MP3 FILES
When a MP3 disc is loaded, the MP3 menu screen is displayed
automatically depending on MP3 disc’s folder structure.
1
Use the direction button to select the folder you want to play and press the
[PLAY] button. This button allows you to see the file lists under the folder.
2
Use the direction button to select a MP3 file. Press the PLAY button then
play will start automatically. When you know the file number, enter the
MP3 file number using the numeric buttons on the remote control and
then press the [PLAY] button.
3
Press √√
■
( √) on the remote control to choose next PAGE (Folder, Files)
in stop mode . Press
■
œœ (œ ) for previous PAGE (Folder, Files) in stop
mode.
When pressing √√ or œœ during play back mode, the next or previous file
is played back.
When you know the file number, enter MP3 file number using the numeric
buttons on the remote control and then press the [PLAY] button.
4
Press REPEAT to
cancel the repeat
function.
REPEAT PLAY
When playing a disc, this function can be used to repeatedly play a title, chapter,
track or disc.
Press the "REPEAT" button, the screen shows orderly.
CHAPTER REPEAT ON
TITLE REPEAT ON
• CD
• DVD
REP-ONE REP-ALL
REPEAT OFF
REPEAT OFF
REPEAT
• MP3 (This function should be operated in stop mode.)
REPEAT ONE REPEAT FOLDER REPEAT DISC REPEAT OFF
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`22
PLAYING A DESIRED SCENE
23
You may press the A-B to enjoy some parts repeatedly when playing a disc.
1. Press “A-B” to set a starting point A.
2. Press “A-B” twice for an end point B.
Afterwards, the unit plays from A to B.
3. Press “A-B” three times to remove A-B repeat.
A-B
REPEATING A DEFINED PERIOD FROM A TO B (DVD)
A TO B : SET A A TO B : SET B REPEAT OFF
SELECT A SUBTITLE LANGUAGE
When you play a multi-subtitle DVD, you may select one subtitle to show it on the
screen.
Keep pressing the [SUBTITLE] button till
the user’s preferred language appears.
If a DVD disc includes subtitle information,
every time the user presses the [SUBTITLE]
button, ENGLISH, FRENCH, SPANISH and
others appear one by one.
1
Remove the subtitle.
Press SUBTITLE until the screen shows "SUBTITLE OFF".
2
SUBTITLE 01/03:ENGLISH
SUBTITLE
1. For some discs,
subtitles
cannot be
removed.
2. Subtitle
function is only
available for
some discs
with subtitle
recorders.
A MP3 disc may
not be repeated
from A to B.
N
Note:
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`23
PLAYING A DESIRED SCENE
24
■You may directly enter a title or chapter number to search fast on a disc. The unit
plays from the point.
SEARCHING
SEARCHING DVD WITH A TITLE or CHAPTER NUMBER
SEARCHING DVD WITH A TITLE or CHAPTER NUMBER
Search a title or a chapter.
Example: Search chapter 4 in title 2.
• Press SEARCH, the screen shows:
• Press the left direction button to move
the cursor on title number.
• Press button 2 to select title 2, the screen
shows:
• Press the right direction button and
button 4 to select chapter 4.
Press PLAY button, then the playback
mode starts at chapter 4 of title 2.
1
TITLE 03/03 CHAPTER 01 /04
Time Search
• Press SEARCH twice, the screen shows:
• Press number buttons to enter hour,
minute and second.
Press PLAY button, then playback mode
starts at your enter time.
2
TITLE 02/03 TIME
_ _
:
_ _
:
_ _
TITLE 03/03 CHAPTER 01/04
TITLE 02/03 CHAPTER 01/04
TITLE 02/03 CHAPTER 04 /04
DV-700S-GB 2006.3.7 2:57 PM ˘`24
PLAYING A DESIRED SCENE
25
■You may directly enter a disc or track time to search fast on a disc. The unit plays
from the point.
SEARCHING CD OR CD-R WITH A DICS OR TRACK TIME
SEARCHING CD OR CD-R WITH A DICS OR TRACK TIME
TRACK SEARCH
Press button 6 to select track 6.
The screen shows ;
“SELECT:06” and play track 6.
1
TIME SEARCH
Example)
to search time 1minute 38 seconds
Press SEARCH, the screen shows ;
“GO TO : _ _ : _ _ :_ _“.
Press button 0, 0, 0, 1, 3, 8 to enter the
time, the screen shows ;
“GO TO : 00:01:38” and play at the time.
2
SELECT : 06
GO TO
_ _
:
_ _ : _ _
GO TO 00 :01 :38
DV-700S-GB 2006.3.7 2:57 PM ˘`25
PLAY DISCS IN VARIOUS WAYS
26
SELECT ANGLE
Some discs have images with different screen angles, you may select among them.
For example, when you watch a running train, you may select to watch it from the
front, the left window or the right window without stopping it.
Keep pressing the [ANGLE] button till the
preferred angle appears. 1/4
ANGLE
2/4 (select ANGLE2)
3/4 (select ANGLE3)
4/4 (select ANGLE4)
Multi Angle
function is limited
to a DVD disc
supporting multi
angle
information.
If you erase a
book mark
function, press
“MARK” button.
ZOOM PLAY
This function can be used to enjoy a motion or motionless picture.
Once memorising a scene, the user may watch it anytime.
MARK
To memorise a scene,
- press [MARK] button while DVD playing.
The screen shows ; STORE MARK1.
- Press direction button […/†] to select the
saving number, up to 3 scenes can be
memorized.
- Press PLAY button to memorize the scene.
Press the "ZOOM" button when playing,
the screen changes as shown on the right:
1
Press UP/DOWN/LEFT/RIGHT [œ √…† ]
button to move the enlarged picture.
2
ZOOM X1.5
ZOOM X2
ZOOM X3
ZOOM OFF
1
2
3
4
ZOOM
1
To play a memorised scene, press [MARK] button twice.
Press […/†] button to get the desired scene and press PLAY(ENTER)
button. Playback will start from the memorised position.
2
N
Note:
N
Note:
GO TO MARK 1
DV-700S-GB 2006.3.7 2:57 PM ˘`26
PLAY DISCS IN VARIOUS WAYS
27
PROGRAM PLAY (CD, MP3 only)
■You may program the tracks on a disc and play them in the programmed order.
This function should be operated in stop mode.
After the unit stops, press PROGRAM to
select.
1
Press number buttons in order, according to the track to be programmed.
2
Press PLAY to start playing.
3
Press PROGRAM at stop mode to remove program play.
4
PROGRAM PROGRAM P00:00
PROGRAM P01:08
PROGRAM P04:02
.
.
..
.
.
8
2
N
Note:
track number
program order
P* * * *
:
Example: Press 8, play, 3, play, 5, play, 2, play
DV-700S-GB 2006.3.7 2:57 PM ˘`27
PLAY DISCS IN VARIOUS WAYS
28
DIGEST PLAY (CD only)
This function should be operated in stop mode.
After the unit stops, press INTRO.
The screen shows:
1
Press number buttons to select a digest
mode.
Press button 1 for intro mode.
The unit plays each scene for about 10~20
seconds.
2
1. INTRO
2.
_ _ _ _ _
3.
_ _ _ _ _
4. EXIT
1
INTRO
PLAYING DivX DISC ON CD-R(W)
When a DivX disc is loaded, the DivX menu screen is displayed
automatically depending on DivX disc’s folder structure.
1
Move the cursor to the subtitle file you want using the direction button
and press the [SUBTITLE] button. A message shows on TV: " DIVX
SUBTITLE SELECTED"
2
Move the cursor to the DivX file you want using the direction button and
press the [PLAY] button. Then play will start automatically.
Press the [SUBTITLE] button again to exit the display of [SUBTITLE].
3
YOUR DVD PLAYER CAN PLAY;
- Picture DivX version: DivX 3.11, 4.x, 5.x, XviD, ISO-MPEG4,
DivX PRO( Excluding QPEL and GMC)
- Subtitle file extension : It can support Smi, Srt, Sub.
- Subtitle Support language: It can display ENGLISH and some languages.
DV-700S-GB 2006.3.7 2:57 PM ˘`28
PLAY DISCS IN VARIOUS WAYS
29
PLAY MP3 OR JPEG
■
SELECT TRACKS
SELECT TRACKS
1. The screen will display after the disc is loaded.
2. You can select the file you want using the direction buttons.
3. Press the PLAY button after selecting the file you want.
The file will be played back.
Note: You can also select the desired track using number buttons.
■
SELECT REPEAT PLAYBACK MODE
SELECT REPEAT PLAYBACK MODE
After the unit stops, press the REPEAT button to select "REPEAT ONE", "REPEAT
FOLDER" , “REPEAT DISC” and "REPEAT OFF".
• REPEAT DISC mode: repeat the disc
• REPEAT ONE mode: repeat the current item
• REPEAT FOLDER mode: repeat the items in the current directory
■
PLAY JPEG BY ZOOM OR ROTATING OPERATING
PLAY JPEG BY ZOOM OR ROTATING OPERATING
The screen will show "ZOOM ON" when you press the ZOOM button under
playing status, the current picture can be zoomed by pressing √√ or œœ
button, and the screen will also show the zoom ratio of the picture ( ZOOM 025
PCT, ZOOM 050 PCT, ZOOM 100 PCT, ZOOM 150 PCT, ZOOM 200 PCT ). The
picture will restore to the normal status if you press the PLAY button under the
ZOOM status.
If you go to
Menu screen or
File list during
Playback mode,
press STOP
button.
N
Note:
DV-700S-GB 2006.3.7 2:57 PM ˘`29
FUNCTION SETTING
30
MENU SETTING
According to the recorded information and external equipment, set the following
functions for DVD to obtain the best playing status. Press "SETUP" button to set the
main menu.
S
E
T
U
P
M
E
N
U
-
M
A
I
N
P
A
G
E
GENERAL SETUP
DOLBY DIGITAL
SETUP
EXIT SETUP
OFF
BITSTREAM
LPCM
STEREO
L-MONO
R-MONO
MIX-MONO
ON
OFF
ENGLISH
SPANISH
DUTCH
FRENCH
GERMAN
PORTUGUESE
ITALIAN
FULL
(SELECTED DATA)
6/8
4/8
2/8
OFF
ON
OFF
ON
OFF
ANGLE MARK
OSD LANG
CAPTIONS
SCREEN SAVER
MAIN PAGE
DIGITAL OUTPUT
DUAL MONO
DYNAMIC
MAIN PAGE
DV-700S-GB 2006.3.7 2:57 PM ˘`30
FUNCTION SETTING
31
BASIC NAVIGATION
Navigate through the setting on the screen, use the direction buttons to scroll
through the list of settings and use the “PLAY” button to select the high lighted
function.
SETUP MENU
Press the SETUP button to enter the On Screen Display and to exit at any time. In
each of the menus, selecting MAIN PAGE (SETUP menu) will immediately return
you to the initial screen.
NORMAL/PS
NORMAL/LB
WIDE
TV DISPLAY
PREFERENCES
PAL
AUTO
NTSC
ENGLISH
SPANISH
DUTCH
FRENCH
GERMAN
PORTUGUESE
ITALIAN
JAPANESE
RUSSIAN
KOREAN
CHINESE
1 KID SAFETY
2 G
3 PG
4 PG-13
5 PG R
6 R
7 NC-17
8 ADULT
NO PARENTAL
CHANGE
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
RESET
DEFAULTS
MAIN PAGE
DV-700S-GB 2006.3.7 2:57 PM ˘`31
FUNCTION SETTING
32
GENERAL SETUP
■
ANGLE MARK
ANGLE MARK
This only works when there is an angle mark on the disc.
• Select "ON", the screen shows the mark when playing a DVD.
• Select "OFF", the mark is not shown.
■
OSD LANGUAGE
OSD LANGUAGE
When you select a language, the screen shows this language.
For example, if you select ENGLISH, the OSD is in English.
“OSD” means
“On Screen
Display”.
N
Note:
■
CAPTIONS
CAPTIONS
The hidden subtitle is shown or turned off.
■
SCREEN SAVER
SCREEN SAVER
Start the screen saver, the screen saver image appears when the unit stops or the
image is motionless for a few minutes. This saver can keep the screen from being
damaged.
DV-700S-GB 2006.3.7 2:57 PM ˘`32
FUNCTION SETTING
33
DOLBY DIGITAL SETUP
■
DUAL MONO
DUAL MONO
This is the output mode of the L and R signals of the set audio output. If it is set to
"MIX– MONO", the function only works when the DVD being played is 2.0-channel.
•STEREO
Choose this option, the audio output should be a dummy stereo signal.
•L–MONO
• R–MONO
•MIX–MONO
■
DYNAMIC
DYNAMIC
Set "OFF" to view a program in the dynamic range as recorded in the
disc. If you hear loud sounds softer and soft sounds louder, set "FULL".
– – FULL
––
– – 3/4
––
– – 1/2
––
– – 1/4
––
– – OFF
■
DIGITAL OUTPUT
DIGITAL OUTPUT
• OFF
No signal is output from the coaxial, optical port.
• BITSTREAM
Select this when the DVD player is connected with a power amplifier through
optical or coaxial port. Please refer to the page 14. when a Dolby Digital DVD, DTS
DVD or MPEG DVD is played, select this, the coaxial or optical port will output in
the corresponding digital format (source code). The power amplifier to be
connected must have the function that can play the Dolby Digital, DTS and MPEG
DVD.
• LPCM
Select this when the DVD player is connected with a TV or a power amplifier
through an audio cord.
DV-700S-GB 2006.3.7 2:57 PM ˘`33
FUNCTION SETTING
34
PREFERENCE SETUP
■
AUDIO
AUDIO
Selecting an audio language.
Set it as the preferred audio language. Where the audio language is set and
recorded in the DISC, it is automatically played in the set language on every playing.
For example, If English is set and recorded as the audio language in the DISC, it is
played in English.
■
SUBTITLE
SUBTITLE
Selecting Subtitle language.
Please set it as the preferred language. Where the subtitle language is set and
recorded in the DISC, it is automatically played in the set language on every playing.
For example, If English is set and recorded as the subtitle language in the DISC, it is
played in English.
■
TV TYPE
TV TYPE
You may select according to the colour system of the TV to be connected.
• Select "PAL" for a PAL TV.
• Select "AUTO" for a multi-system TV.
• Select "NTSC" for a NTSC TV.
■
TV DISPLAY
TV DISPLAY
NORMAL/PS
This is selected when the unit is connected
with a normal TV.
Wide-screen images are shown on the
screen, but with some parts cut
automatically.
1
1
NORMAL/LB
This is selected when the unit is connected
with a normal TV.
Wide-screen images are shown on screen,
with black belts on the top and bottom.
2
2
WIDE
This is selected when the unit is connected
with a 16: 9 wide-screen TV.
3
3
DV-700S-GB 2006.3.7 2:57 PM ˘`34
FUNCTION SETTING
35
■
DISC MENU
DISC MENU
Selecting Disc Menu language.
Please set it as the preferred DISC MENU language. Where the DISC MENU
language is set and recorded in the DISC, it is automatically played in the set
language on every playing. For example, English is set and recorded as the DISC
MENU language in the DISC, it is played in English.
■
PARENTAL
PARENTAL
The content of a disc with lock function is evaluated by grades. You can select an
age grade as your need.
Example: Select “1 KID SAFETY”, the scenes of violence inadvisable to children are
not played.
For adults, the screen suggests you enter the code after pressing the “PLAY”
button , you can watch if the code is right.
■
PASSWORD
PASSWORD
Select a "PASSWORD" in the PREFERENCE SETUP
menu to setup password, input a password.
Enter a password according to the screen.
The password is
set by yourself.
The password is
3308 when the
unit is turned on
initially or you
forget the
password.
■
DEFAULTS >> RESET
DEFAULTS >> RESET
Each function setting returns to the factory initial status if you select this.
N
Note:
N
Note:
OLD PASSWORD
NEW PASSWORD
CONFIRM PASSWORD
CHANGE PASSWORD
PLEASE ENTER OLD PASSWORD
DV-700S-GB 2006.3.7 2:57 PM ˘`35
TROUBLESHOOTING
If you experience the following problems while using the unit, this troubleshooting guide
can help you.
•NO SOUND
- Check if the unit is connected securely.
- Make sure you operate the TV or amplifier correctly.
•NO IMAGE , IMAGE ROLLS AND NO COLOUR
- Check if the unit is connected securely.
- Make sure you operate the TV correctly.
- Make sure you set the colour system correctly.
•BAD SOUND QUALITY
- Make sure the audio output mode is set correctly.
- Make sure the audio connection between the unit and amplifier is right.
•DISC CAN NOT BE PLAYED
- There is no disc in the unit.
- Insert the disc on the disc tray properly with the label side up.
- Clean the disc.
- Moisture has condensed in the unit.
Remove the disc and leave the unit on for about one hour.
•NO MICRO PHONE SOUND
- Switch on the microphone.
- Turn the MIC LEVEL knob clockwise.
•SCREAMING
- Keep the phone far away from the speaker
- Turn down the volume
- Turn down the volume of micro-phone.
•REMOTE CONTROL DOES NOT WORK
- Remove barriers between the remote control and the unit.
- Replace the batteries with new ones.
- Point the remote control at the remote control sensor of the unit.
•ATTENTION: KEEPING THE STATUS OF STOP MORE THAN 5 MINUTES ENTERS SCREEN
SAVE MODE. WHEN THE SCREEN SAVE MODE IS KEPT MORE THAN AN
HOUR, THE SET ENTERS STAND-BY MODE.
OTHERS
36
DV-700S-GB 2006.3.7 2:57 PM ˘`36
OTHERS
37
wavelength 650nm
PAL/AUTO/NTSC
20Hz ~ 20KHz (±1dB)
≥90dB
≥85dB ( 1KHz)
≥80dB ( 1KHz)
100-240V~, 50/60Hz
<12W
430 x38 x260 mm
About 3.5Kgs/ 2.6Kgs
Laser
Video
Frequency response
Signal/noise ratio
Channel separation
Dynamic range
Power supply
Power consumption
Dimensions (W x H x D)
Weight (Gross/ Net)
output level : 2.0 + 0/-0.2Vrms
(Load impedance : 1,0KΩ)
output level : 0.5 ± 0.1Vp-p
(Load impedance : 75Ω)
output level : 1.0 ± 0.1Vp-p
(Load impedance : 75Ω, imbalance, negative polarity)
output level : brightness (Luma) 1.0 ± 0.1Vp-p
chromaticity (Colour) 0.286 ± 20% (Load impedance : 75Ω)
0.5 Vp-p 75% white
Output
Audio
Output
Video
Analog
Digital
Composite
S-video
RGB
Notes : Design and specifications in this Instruction manual are subjected to change without
prior notice to improve quality and function.
TECHNICAL SPECIFICATIONS
DV-700S-GB 2006.3.7 2:57 PM ˘`37

Navigation menu
