Datalogic S r l DLNFCR1 Personal Device Assistant User Manual 852000861

Datalogic ADC S.r.l. Personal Device Assistant 852000861

User manual

Datalogic ADC S.r.l.Via S. Vitalino, 1340012 Lippo di Calderara di RenoBologna - ItalyTelephone: (+39) 051-3147011 Fax: (+39) 051-3147205©2016 Datalogic ADC S.r.l.An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein may be reproduced or transmitted in any form or by any means without prior written permission of Datalogic ADC Inc. or its subsidiaries or affiliates ("Datalogic" or “Datalogic ADC”). Owners of Datalogic products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own internal business purposes. Purchaser shall not remove or alter any proprietary notices, including copyright notices, contained in this documentation and shall ensure that all notices appear on any reproductions of the documentation.Should future revisions of this manual be published, you can acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the Datalogic website (www.datalogic.com) or provided on appropriate media. If you visit our website and would like to make comments or suggestions about this or other Datalogic publications, please let us know via the "Contact Datalogic" page.DisclaimerDatalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic reserves the right to change any specification at any time without prior notice.Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. DL-Axist and the DL-Axist logo are trademarks of Datalogic ADC S.r.l. All other brand and product names may be trademarks of their respective owners.PatentsSee www.patents.datalogic.com for patent list.This product is covered by one or more of the following patents:Utility patents: EP0789315B1; EP0996284B1; EP0999514B1; EP1128315B1; EP1172756B1; EP1396811B1; EP1413971B1; EP1804089B1; EP1828957B1; EP2315156B1; JP4435343B2; JP5192390B2; US5992740; US6478224; US6512218; US6513714; US6517003; US6561427; US6808114; US6877664; US6997385; US7053954; US7234641; US7387246; US7721966; US8113430; US8561906; ZL200680050007.8Waste Electrical and Electronic Equipment (WEEE)Information for the UserAt the end of its useful life, the product marked with the crossed out wheeled wastebin mustbe disposed of separately from urban waste.For more detailed information about disposal, contact the supplier that provided you withthe product in question or consult the dedicated section at the website http://www.datalogic.com.Informazione per gli utentiL’apparecchiatura che riporta il simbolo del bidone barrato deve essere smaltita, alla finedella sua vita utile, separatamente dai rifiuti urbani.Per maggiori dettagli sulle modalità di smaltimento, contattare il Fornitore dal quale è stataacquistata l’apparecchiatura o consultare la sezione dedicata sul sito http://www.datalogic.com.Information aux utilisateursAu terme de sa vie utile, le produit qui porte le symbole d'un caisson à ordures barré ne doitpas être éliminé avec les déchets urbains.Pour obtenir des informations complémentaires concernant l'élimination, veuillez contacterle fournisseur auprès duquel vous avez acheté le produit ou consulter la section consacréeau site web http://www.datalogic.com.Benutzerinformation bezüglich Am Ende des Gerätelebenszyklus darf das Produkt nicht über den städtischen Hausmüllentsorgt werden. Eine entsprechende Mülltrennung ist erforderlich. Weitere Informationen zu dieser Richtlinie erhalten sie von ihrem Lieferanten über den siedas Produkt erworben haben, oder besuchen sie unsere Hompage unter http://www.datalogic.com.Información para el usuarioAl final de su vida útil, el producto marcado con un simbolo de contenedor de bassura móviltachado no debe eliminarse junto a los desechos urbanos.Para obtener una información más detallada sobre la eliminación, por favor, póngase en con-tacto con el proveedor donde lo compró o consultar la sección dedicada en el Web site http://www.datalogic.comEuropean Union Regulatory NoticeThis device bearing the CE marking is in compliance with the essential requirements andother relevant provisions of Directive 1999/5/EC. This device complies with the followingharmonized European standards.The following CE marking is valid for EU harmonized telecommunications products.Personal Digital Assistant (PDA)Safety & Regulatory Addendum 852000861 (Rev. A) Mar. 2016General Safety RulesPower SupplyThis device is intended to be connected to a UL Listed/CSA Certified computer which suppliespower directly to the DL-Axist or else be supplied by a UL Listed/CSA Certified Power Unitmarked “Class 2” or LPS power source rated 5 V, 2.0 A, which supplies power directly to theDL-Axist via the power connector of the cable.The adapter package includes three international plug adapters. The adapters must beplugged in the power supply before the power supply itself is plugged on the wall outlet.Battery InformationDL-Axist battery pack is not initially fully charged. After installing the battery, charge it withthe USB cable or with the single dock.Battery Safety GuidelinesNOTERead carefully the DL-Axist user manual (available at www.datalogic.com) beforeperforming any type of connection to the DL-Axist PDA.The user is responsible for any damage caused by incorrect use of the equipment or byinobservance of the indication supplied in the user manual.CAUTION• Before using the device and the battery packs, read this Addendum carefully.• Use only the components and accessories supplied by the manufacturer for the specific DL-Axist being used.• Do not attempt to disassemble the DL-Axist PDA, as it does not contain parts that can be repaired by the user. Any tampering will invalidate the warranty.• When replacing the battery pack or at the end of the operative life of the DL-Axist PDA, disposal must be performed in compliance with the laws in force in your jurisdiction. • Do not submerge the DL-Axist in liquid products.• For further information or support, refer to the Datalogic web site: www.data-logic.com. CAUTIONBy default, the battery pack is disconnected at the factory to avoid damage due to excessivedraining.Annual replacement of rechargeable battery pack avoids possible risks or abnormalitiesand ensures maximum performance.Avoid storing batteries for long periods in a state of full charge or very low charge.We recommend charging the battery pack every two to three months to keep its charge at amoderate level to maximize battery life.WARNINGRisk of explosion if battery is replaced by an incorrect type.Dispose of used batteries according to the instructions.Il y a risque d’explosion si la batterie est remplacée par une batterie de type incorrect.Mettre au rebut les batteris usagées confor mément aux instructions.NOTEEven if the storage temperature range is wider, in order to achieve the longest battery life,store the terminal and the spare batteries between 20 to 30°C (68 to 86°F).Charging is allowed in the battery temperature range from 0°C to 45°C.To maximize operating autonomy, the DL-Axist checks its battery level at all times. If thebattery is not sufficiently charged, the DL-Axist will not turn on when the ON/OFF Powerbutton is pressed.In this case, either substitute with a charged battery, insert the DL-Axist into a poweredcradle, or plug it into a wall charger.To maximize battery life, turn off radios when they are not needed.WARNINGInstalling, charging and/or any other action should be done by authorized personnel andfollowing this manual.The battery pack may get hot, explode, ignite, and/or cause serious injury if exposed toabusive conditions.If the battery pack is replaced with an improper type, there is risk of explosion and/or fire.Use the battery box to carry the battery pack, do not put the battery pack in your pocket.Do not place the battery pack in or near a fire or other heat source; do not place the batterypack in direct sunlight, or use or store the battery pack inside unventilated areas in hotweather; do not place the battery pack in microwave ovens, in clothes dryers, in highpressure containers, on induction cook surfaces or similar devices. Doing so may cause thebattery pack to generate heat, explode or ignite. Using the battery pack in this manner mayalso result in a loss of performance and a shortened life expectancy.Use only a Datalogic approved power supply. The use of an alternative power supply willvoid the product warranty, may cause product damage and may cause heat, an explosion, orfire.The area in which the units are charged should be clear of debris and combustible materialsor chemicals.Do not use the battery pack of this terminal to power devices other than this terminal.Immediately discontinue use of the battery pack if, while using, charging or storing thebattery pack, the battery pack emits an unusual smell, feels hot, changes color or shape, orappears abnormal in any other way.Do not short-circuit the battery pack contacts connecting the positive terminal and negativeterminal. This might happen, for example, when you carry a spare battery pack in yourpocket or purse; accidental short–circuiting can occur when a metallic object such as a coin,clip, or pen causes direct connection of the contacts of the battery pack (these look likemetal strips on the battery pack). Short–circuiting the terminals may damage the batterypack or the connecting object.Do not apply voltages to the battery pack contacts.Do not pierce the battery pack with nails, strike it with a hammer, step on it or otherwisesubject it to strong impacts, pressures, or shocks.Do not disassemble or modify (i.e. bend, crush or deform) the battery pack. The battery packcontains safety and protection devices, which, if damaged, may cause the battery pack togenerate heat, explode or ignite.In case of leakage of liquid from the battery, avoid contact with liquid the skin or eyes. If thecontact occurs, immediately wash the affected area with water and consult a doctor.Do not solder directly onto the battery pack.Do not expose the battery pack to liquids.Avoid any knocks or excessive vibrations. If the device or the battery is dropped, especiallyon a hard surface, you should take it to the nearest Authorised Repair Centre for inspectionbefore continuing to use it.Before replacing the battery pack, turn off the device or put it in swap battery mode (refer tothe DL-Axist User's Manual).Do not remove or damage the battery pack’s label.Do not use the battery pack if it is damaged in any part.Battery pack usage by children should be supervised.Collect and recycle waste batteries separately from the device in compliance with EuropeanDirective 2006/66/EC, 2011/65, 2002/96/EC and subsequent modifications, with US andChina regulatory laws and regulations about the environment.Wireless and Radio Frequencies WarningsLaser SafetyThe following information applies to both laser models and the DL-Axist Imager AimingSystem.The laser light is visible to the human eye and is emitted from the window indicated inthe figure below.LASER LIGHT - DO NOT STARE INTO BEAMCLASS 2 LASER PRODUCTMAX OUTPUT RADIATION 1 mWCOMPLIANT WITH EN 60825-1 (2007)1. For models with Type containing WI.2. For models with Type containing HL.3. The label artworks may be only a draft. Refer to the product labels for more precise information.NOTE: do not remove the labelsWARNINGMost modern electronic equipment is shielded from RF signals. However, certainelectronic equipment may not be shielded against the RF signals generated by theDL-Axist.Datalogic recommends persons with pacemakers or other medical devices to followthe same recommendations provided by Health Industry ManufacturersAssociations for mobile phones.Persons with pacemakers:• Should ALWAYS keep this device more than twenty five (25) cm from their pacemaker and/or any other medical device;• Should not carry this device in a breast pocket;• Should keep the device at the opposite side of the pacemaker and/or any other medical device;• Should turn this device OFF or move it immediately AWAY if there is any reason to suspect that interference is taking place.• Should ALWAYS read pacemaker or any other medical device guides or should consult the manufacturer of the medical device to determine if it is adequately shielded from external RF energy.In case of doubt concerning the use of wireless devices with an implanted medicaldevice, contact your doctor.Turn this device OFF in health care facilities when any regulations posted in theseareas instruct you to do so. Hospitals or health care facilities may use equipmentthat could be sensitive to external RF energy.RF signals may affect improperly installed or inadequately shielded electronicsystems in motor vehicles. Check with the manufacturer or its representativeregarding your vehicle. You should also consult the manufacturer of any equipmentthat has been added to your vehicle.An air bag inflates with great force. DO NOT place objects, including either installedor portable wireless equipment, in the area over the air bag or in the air bagdeployment area. If a vehicle’s wireless equipment is improperly installed and theair bag inflates, serious injury could result.Turn off the device when in any area with a potentially explosive atmosphere.Observe restrictions and follow closely any laws, regulations, warnings and bestpractices on the use of radio equipment near fuel storage areas or fuel distributionareas, chemical plants or where any operation involves use of explosive materials.Do not store or carry flammable liquids, explosive gases or materials with the deviceor its parts or accessories.Areas with a potentially explosive atmosphere are often, but not always, clearlymarked or shown.Sparks in such areas could cause an explosion or fire, resulting in injury or evendeath.ITALIANO DEUTSCH FRANÇAIS ESPAÑOLLA LUCE LASER È VISIBILE ALL'OCCHIO UMANO E VIENE EMESSA DALLA FINESTRA INDICATA NELLA FIGURA.DIE LASER-STRAHLUNG IST FÜR DAS MENSCHLICHE AUGE SICHTBAR UND WIRD AM STRAHLAUS TRITTSFENSTER AUSGESENDET (SIEHE BILD).LE RAYON LASER EST VISIBLE À L'OEIL NU ET IL EST ÉMIS PAR LA FENÊTRE DÉSIGNÉE SUR L'ILLUSTRATION DANS LA FIGURE.A LUZ LÁSER ES VISIBLE AL OJO HUMANO Y ES EMITIDA POR LA VENTANA INDICADA EN LA FIGURA.LUCE LASER NON FISSARE IL FASCIOAPPARECCHIO LASER DI CLASSE 2 MASSIMA POTENZA D'USCITA: 1 mWLUNGHEZZA D'ONDA EMESSA:CONFORME A EN 60825-1 (2007).LASERSTRAHLUNG NICHT IN DEN STRAHL BLICKEN PRODUKT DER LASERKLASSE 2 MAXIMALE AUSGANGSLEISTUNG: 1 mWWELLENLÄGE:ENTSPR. EN 60825-1 (2007).RAYON LASER EVITER DE REGARDER LE RAYON APPAREIL LASER DE CLASSE 2 PUISSANCE DE SORTIE: 1 mWLONGUEUR D'ONDE EMISE:CONFORME A EN 60825-1 (2007).RAYO LÁSER NO MIRAR FIJO EL RAYO APARATO LÁSER DE CLASE 2 MÁXIMA POTENCIA DE SALIDA: 1 mWLONGITUD DE ONDA EMITIDA:CONFORME A EN 60825-1 (2007).WI1Scan WindowHL2WI1HL2Additional Label3Product Label3This document is an addendum to the Quick Start Guide(QSG) for this product. See the QSG for additionalproduct information.©2016 Datalogic ADC S.r.l. • All rights reserved. Datalogic and the Datalogic logo are registered trademarks ofDatalogic S.p.A. in many countries, including the U.S.A. and the E.U.DL-Axist and the DL-Axist logo are trademarks of Datalogic ADC S.r.l.All other brand and product names may be trademarks of theirrespective owners. www.datalogic.com
">
