Single Slot Dock Charge Only
Quick Start Guide
822002530 (Rev. A) November 2017
Out of the Box
The Joya Touch Single Slot Dock Charge Only package contains:
• 1 Joya Touch Single Slot Dock Charge Only
• 1 Power Supply
•1 Quick Start Guide
• 1 Safety & Regulatory Addendum
General View
Front View
Bottom View
NOTE
Read this manual carefully before using the Joya Touch Single
Slot Dock Charge Only. The user is responsible for any damages
caused by incorrect use of the equipment or by inobservance of
the indication supplied in this manual.
CAUTION
Keep the original packaging for use when sending products to
the technical assistance center. Damage caused by improper
packaging is not covered under the warranty.
Notification LED
Power Jack
Insert the Joya Touch into the Single
Slot Dock Charge Only
Insert the device into the dock with the screen facing front and the head
facing down:
To confirm the correct insertion, the notification LED starts blinking.
NOTE
The Joya Touch gets warm during charging. This is normal and
does not mean a malfunction.
CAUTION
Do not put any foreign object such as, but not limited to, coins,
paper clips, stickers inside the slot of the dock (see the picture
below).
Handheld Models
Pistol Grip Models
See the Regulatory Addendum
included with your product for
additional regulatory, safety and
legal information.
©2017 Datalogic S.r.l. • All rights reserved.
Datalogic and the Datalogic logo are
registered trademarks of Datalogic S.p.A. in
many countries, including the U.S.A. and the
E.U.
www.datalogic.com
Powering the Dock
To prevent the risk of short-circuiting, first plug the power supply into the power jack on the back of
the dock, then plug the power supply into a power outlet.
LED Indicators
CAUTION
Use only the Datalogic power supply included in the box to power the Joya Touch Single Slot
Dock Charge Only.
Operation Status LED States Module Behavior
Power standby Blue on On-continuous
Power transfer Blue blink On-off-on = 1Hz
Over current protection Blue off -
Foreign object detected Blue off -
11
2
Technical Specifications
Electrical Features
Consumption 5V ± 5% 2A
Indicators Notification LED (blue)
Environmental Features
Operating
Temperature*
*The Joya Touch should be charged at an ambient temperature between 0 and 35º C to achieve the maximum
charging rate. Never charge the main device in a closed space where excessive heat can build up. Close to the
limits of the working temperature, some display and/or battery performance degradation may occur.
-5° to 50ºC
Storage
Temperature -25° to 60°C
Humidity**
** Multiple rapid humidity and/or temperature variations may cause condensing.
10-90% non condensing
Mechanical Features
Dimensions
(L x W x H)
Dock: 101.6 x 116.4 x 87.7 mm / 4 x 4.6 x 3.5 in
Dock with rubber feet: 101.6 x116.4 x 91.3 mm / 4 x 4.6 x 3.6 in
Dock with Joya Touch Handheld (with rubber feet):
101.6 x 116.4 x 163.6 mm / 4 x 4.6 x 6.4 in
Dock with Joya Touch Pistol Grip (with rubber feet):
101.6 x 154.9 x 163.6 mm / 4 x 6.1 x 6.4 in
Weight 314 g / 11.08 oz
