VIDEO DISK RECORDER

VDR-3000

INSTRUCTION MANUAL

COMPATIBLE

http://www.datavideo-tek.com

2

CONTENTS

Introduction

Packing list --------------------------------------------------------------------------- 3

Front & Rear Panel ---------------------------------------------------------------- 4

Display Panel ----------------------------------------------------------------------- 7

Remote Control Handset -------------------------------------------------------- 8

Connections

Connection a TV/Monitor --------------------------------------------------------- 11

Connecting an analog video source ------------------------------------------- 12

Connecting a DV video source (DV Model only) --------------------------- 13

Connecting a digital still camera ----------------------------------------------- 14

Connecting to a Project TV /monitor with component video------------- 15

Connecting a digital audio CD player ----------------------------------------- 16

Operation

Switching on ------------------------------------------------------------------------ 17

Playing a disk ----------------------------------------------------------------------- 17

Recording a disk ------------------------------------------------------------------- 18

PC Playback

Playing CD’s in your PC --------------------------------------------------------- 20

Grabbing Frames from your CD to save or e-mail ------------------------ 22

Advanced Operation

Color correcting the video source before recording ---------------------- 23

Frequently Asked Questions ------------------------------------------------ 24

Specifications -------------------------------------------------------------------- 32

Contact Information ------------------------------------------------------------ 33

3

PACKING LIST

VDR-3000 is supplied with the following accessories:

Infrared Remote Control Handset

VDR-3000

PLAY LIST TI ME MODE DISPLAY COMP.

VIDEO BOOK MARK

CLE AR RECALL

TIME SET PAL/ NTSC LANG

AUDIO VIDEO

STEP PAUSE STOP

MUTEPOWER

1234

5678

90

+10 CE

REW P LAY F. F ERASE

STP REC

PL TM OSD O/ P

I/ P I/ P

BM

RCLA N GP/ NTSCL

RETURN

A/B

REPEAT

SLOW

REPEAT

PBC

ENT

2 x “AAA” Batteries for Handset

Main Power Cord

S-Video Cable

3 Phono (RCA) to 3 Phono (RCA) Audio/Video Cable

IEEE1394 “Firewire” Cable (DV Model only)

4

CD-RW Rewritable CD.

Rear Panel 1 3 4

AC IN PUT

INPUT

OUTPUT

RIGHT LEFT VIDEO S

V

IDEOAUDIO

INPUT

SOURCE

AC VOLTS

DIGITAL INPUT

COMP ONEN T VIDEO OUTP UT

Y/ G P / B P / R

BR

230VAC

2 7 6 5

1. Main Power Cord connecting socket

To connect to the main power supply

2. AC Main voltage selector

Sets the voltage input to 115 VAC or 230VAC. Note: This setting does not need to be

changed under normal conditions. Do not adjust this setting without consulting your

dealer or a qualified electrician.

3. Input Source Selector Switch (DV Model only)

To select DV or Analog Video Input

4. Audio and Video Inputs

To connect left and right audio and composite or S-Video signals from a

camcorder/VCR etc.

5. Component Video Output

Component Y.U.V. or R.G.B. video signal output for project or big screen TV/Monitor.

Note: The component video output cannot be used with the S(Y/C) output and the

composite output at the same time. Outputing to both outputs will lower the video

output level.

6. Audio and Video Outputs

To connect to a TV or Monitor

5

7. Digital Audio Input

To connect a audio digital signal from a CD player to duplicate an audio CD without

sound quality loss. Please note: The Audio Digital Duplicate is only available with Audio

CD-R due to copyright protection.

Front Panel

8 9 10 17 18 19 22 20 24 21

Vid eo Disk Record er /

CD

DVD S-VCD/ VCD/ CD

VDR-3000

POWER MENU

/

ENTER FINALI ZE

EJECT REC REW F.F.

VOL. A MI C.A VOL. B MIC.B

DV

PREVIOUS NEXT ERASE PBC

R

11 12 13 14 15 16 23 25 26 27 28

8. Power Button

To switch the unit from On to Standby mode or vice versa.

9. Menu/Enter Button

This button contents two functions: Menu and Enter

Menu: Press this key to open the Color Processor on screen menu for adjustment

Enter: To select a recording format CDDVD, DVD-PHOTO, S-VCD, HQ-VCD, VCD or

Audio CD after inserted the blank disc into CD tray

10. Finalize Button

To finalize the disc. Until a disc is finalized it can only be played back in the VDR 3000.

A finalized disc can be played back in other suitable devices such as Audio CD, VCD,

S-VCD, DVD player or CD-ROM in PC.

11. IEEE 1394 DV “iLink” Socket (DV Model only)

To input Digital Video/Audio from DV Camcorders etc.

12. Previous Button

To skip back to the previous track during playback or to navigate up the on screen

menu options

13. Next Button

To skip forward to the next track during playback or to navigate down the on screen

menu options

14. Erase Button

To erase the data on a CD-RW disc. Erasing takes a CD-RW disc takes around 2

minutes irrespective of how much data is on the disc. Note: The Erase feature does not

function with CD-R discs.

6

15. PBC Button

Playback control button for commercially produced VCD’s

16. CD Tray

To load discs into the unit

17. Display Panel (see separate illustration)

Shows current status of unit.

18. Eject Button

To Open the CD Tray for loading or removing CD

19. REC Button

To start recording

20. REW Button

To picture search backward through a track. Several speeds are available each press

of the button will increase the speed.

21. F.F. Button

To picture search forward through a track. Several speeds are available each press of

the button will increase the speed.

22. STOP Button

To stop the disk during playback or record

23. PAUSE Button

To pause the disk during playback

24. PLAY Button

To start the disk playing

25. Microphone Volume Control (Left/Mono)

To control the volume of the Left Channel Microphone. Also controls the volume of

mono microphone track.

26. Microphone Input Jack (Left/Mono)

Input Jack for Left Channel Microphone. Also for single mono microphone.

27. Microphone Volume Control (Right)

To control the volume of the Right Channel Microphone.

28. Microphone Input Jack (Right)

Input Jack for Right Channel Microphone.

7

Display Panel

1 2 3 6 7 8 9

REPEAT 1 TRK PBC

A-B

CD

Super VCD

4 5 10 11

1. Infrared receiver

Receives signals from the Infrared Remote Control Handset

2. DV on LED

Indicates the DV source is selected

3. CD/Super/VCD

Indicates the format of the loaded disk or the selected recording format

4. Play Indicator

Indicates that the disk is playing

5. Pause Indicator

Indicates that the disk is paused

6. Repeat

Indicates that Repeat function is activated

7. A-B Repeat

Indicates that A-B Repeat function is activated

8. Track Indicator

Indicates the total number of tracks on the disk when the disk is static or the

track number when the disk is playing

9. PBC

Indicates that Play Back Control function is activated

10. Initial Status Display

- - - - Indicates no disk

OPEN Indicates the CD Tray is open

LOAD Indicates the inserted disk is loading

11. Counter Display

Indicates in Hours: Minutes: Seconds the total duration of the disk when the disc

is static or the position within a track when the disk is playing.

8

Infrared Remote Control Handset

36

35

34

33

32

31

30

29

28

27

26

25

24

23

22

21

20

VDR-3000

PL

A

Y LIST TIME MODE DISPLAY VIDEO BOOK MARK

CLEAR RECALLTIME SET PAL/ NTSC LANG

AU DI O VI D EO

STEP PAUSE STOP

MUTE POWER

1234

5678

90

+10 CE

REW PLAY F.F ERASE

STP REC

PL TM OSD O/ P

I/ P I/ P

BM

RCLAN GP/ NTSCL

RETURN

A/B

REPEAT

SLOW

REPEAT

PBC

ENT

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

1. Power Button

To switch the unit from On to Standby mode or vice versa.

2. Numerical Keypad

To give direct access to tracks on a disk

3. RETURN Button

To return to the first track on a disk

4. ENT Button (ENTER)

This button contents two functions: Menu and Enter Menu: Press this key to

open the Color Processor on screen menu.

Enter: To select a recording format DVD-PHOTO, S-VCD, VCD or Audio CD after

inserted the blank disc into CD tray

5. Sound Output

To select the sound output mode: Left, Right or Stereo channel output

6. NEXT Button

To skip forward to the next track during playback or to navigate down the on

Screen

9

7. REPEAT Button

Offers repeat playback options. Press once to repeat a single track, twice to repeat

the entire disk or three times to turn repeat function off.

8. DOWN Arrow

Navigates down through on screen menu options. Also with on screen controls

reduces the setting

9. PBC Button (Playback Control)

Offers playback control options for commercially produced VCD’s

10. Video Output Button

To select video output format: Composite, S (Y/C), Y.U.V. or RGB video

11. BM Button (Book Mark)

To mark a reference point on a track for later recall

12. RC Button (Recall)

Goes to the book mark reference point

13. LANG Button

To set the on screen menu language English or Chinese

14. P/N Button (PAL/NTSC)

To select video input format PAL, NTSC or AUTO detect system

15. Video I/P Button (CV/S)

To select analog video input source. Select CV to input via Phono (RCA) or S to

input via the mini 4 Pin S-Video sockets.

16. Erase Button

To erase the data on a CD-RW. Erasing takes a CD-RW takes around 2 minutes in

respect of how much data is on the disk

Note: The Erase feature does not function with CD-R discs.

17. F.F. Button

To picture search forward through a track. Several speeds are available each press

of the button will increase the speed

18. REC Button

To start recording

19. STOP Button

To stop the disk during playback or record

20. PAUSE Button

To pause the disk during playback

21. STP Button (Step)

To step forward one frame at a time. (Single Frame Advance)

10

22. PLAY Button

To start the disk playing

23. REW Button

To picture search backwards through a track. Several speeds are available each

press of the button will increase the speed

24. Audio Input Button

To select the digital audio or analog audio input source

25. TS Button (Time Set)

To jump to any point on a disk enter the time in minutes and seconds

26. CL Button (Clear)

Clears entries from the user programmable Play List

27. PL Button (Play List)

Calls up a user programmable Play List of up to 12 tracks

28. TM Button (Time Mode)

To change the counter display from position in the track to time remaining

29. OSD Button

Turns on “On Screen Display”. During playback Track number, Counter, Disk format

and Audio format can be displayed on the screen

30. RESUME Button

Will resume playback from the same point in a track if playback has been stopped

31. SLOW Button

To select slow motion playback. Three speeds are available press once for ½

speed, twice for ¼ speed and three times for 1/8 speed

32. PREV Button (Previous)

To skip back to the previous track during playback or to navigate up the on screen

menu options

33. EJECT Button

To open and close the CD tray

34. UP Arrow

Navigates up through on screen menu options. Also with on screen controls

increases the setting

35. A/B Repeat Button

To mark start and stop points within a track for repeat play

36. Mute button

To mute the volume during playback

11

CONNECTIONS

Connecting to a TV Monitor

NOTE: While connecting please ensure that the VDR 3000 and all devices that you are

connecting to are switched off.

The VDR 3000 should be connected to the video and audio inputs of a TV Monitor. The TV

Monitor may have a SCART socket, PHONO (RCA) sockets or S-Video socket.

TV/ Monitor

RL S

Selects the AC input range 115VAC or 230VAC for VDR-3000

Selects the input source to Video

To connect to a SCART input a three phono (RCA) plug (Left and Right Audio plus

Composite Video) to SCART Plug cable will be required.

If the TV has an S-Video socket use an S-Video cable for connection as this will give the

best quality signal. No connection is required from the Video Out phono (RCA) if S-Video

is connected.

12

Connecting an analog video source

NOTE: While connecting please ensure that the VDR 3000 and all devices that you are

connecting to are switched off.

TV/ Monitor

RL S

Selects the AC input range 115VAC or 230VAC for VDR-3000

Selects the input source to Video

Source Audio/ Video

An analog video device can be connected via composite or S-Video if available. Connect

the left and right audio output from the device to the left and right audio input on the rear of

the VDR 3000. Connect either the composite video out (yellow phono (RCA)) or the S-

Video out (mini 4 pin) from the device to the video input on the rear of the VDR 3000. Only

connect composite or S-Video – do not connect both.

Set the Input Source Selector Switch to the V position.

13

Connecting a DV video source (DV Model only)

NOTE: During connection please ensure that the VDR 3000 and all devices that you are

connecting are switched off.

TV/ Monitor

RL S

Selects the AC input range 115VAC or 230VAC for VDR-3000

Selects the input source to DV

DV Out DV In

DV IN/OUT

Source Player

Connect the IEEE1394 “iLink” cable from your DV/mini DV device to the DV Input socket

on the front of the VDR 3000.

Set the Input Selector Switch on the rear of the VDR 3000 to the DV position

14

Connecting a Digital Still Camera

NOTE: While connecting please ensure that the VDR 3000 and all devices that you are

connecting to are switched off.

TV/ Monitor

RL S

Selects the AC input range 115VAC or 230VAC for VDR-3000

Selects the input source to Video

Video Out

Audio Out

Digital Photo Camera

Audio CD Player

Digital still cameras can be connected to the Video Input on the rear of the VDR 3000.

Connect the Video Out from the Digital Still Camera to the Video In Phono (RCA) socket

on the VDR 3000. Set the Input Source Selector Switch to the V position.

Note: 1. To achieve a high quality video photo CD, please select the “DVD-PHOTO” video

format after you have loaded a blank disc into the VDR 3000.

Do not record more than 98 tracks and 37 minutes on a disk in the

DVD-PHOTO format.

15

Connecting to a Projection TV / Monitor with Component Video

NOTE: While connecting please ensure that the VDR 3000 and all devices that you are

connecting to are switched off.

The VDR 3000 should be connected to the component R.G.B. or Y.U.V. video and audio

inputs of a Projection TV / Monitor.

R

P

R

P

B

Y

GB

Selects the AC input range 115VAC or 230VAC for VDR-3000

Project TV/ Monitor

To Hi-Fi System

To connect to a component input a three BNC plug (R.G.B. or Y.U.V. Video) to BNC Plug

cable will be required.

NOTE: The Composite and S (Y/C) video cables should be disconnected when hooking

up the Component video output to TV/Monitor to ensure the best component video

level.

16

Connecting a Digital Audio CD Player (Optional)

NOTE: During connection please ensure that the VDR 3000 and all devices that you are

connecting are switched off.

To Hi-Fi System or TV/ Monitor Audio Input Jack

Selects the AC input range 115VAC or 230VAC for VDR-3000

AUDI O CD

OPT.

Optical Cable

Digital Audio Player

To connect to a digital audio input either a optical fiber plug to a optical fiber plug cable or

phono (RCA) plug to phono (RCA) plug cable will be required.

To connect the audio output from VDR 3000 to audio input of either audio hi-fi system or

TV/Monitor.

Note: The VDR 3000 requires an Audio CD-R to duplicate Audio CDs because of

Copyright protection.

17

OPERATION

Switching on

Once all cables are in place it is ok to power on the VDR-3000.

Press the Power Button on the front of the VDR 3000 or on the remote control handset,

the display panel should light up and display ” - - - -“.

Power on the TV Monitor and select the correct A/V channel, the VDR 3000 start-up

screen will appear. The TV screen it will display ” Insert CD”.

1

Playing a disk

Press the Eject Button on the front of the VDR 3000 or on the remote control handset and

the CD tray will slide open.

The VDR 3000 will accept Audio CD, VCD, HQ-VCD, S-VCD, DVD-Photo or CDDVD disks.

Place the disk that you want to load onto the tray, printed side facing up.

Press the Eject Button and the CD tray will close and “LOAD” will appear on the display

panel.

After a few moments the display panel will indicate the format of the loaded disk

(CD/VCD/HQVCD/SVCD/DVD-PHOTO/ CDDVD). It will also show how many tracks the

loaded disk features and the total running time of the disc.

Note: The VDR-3000 cannot play DVD media.

To play the disc from the beginning, press the Play Button on the VDR 3000 or on the

remote control handset.

To play a specific track, select the track number from the numeric keypad on the remote

control handset.

To skip forward to the next track press the Next Button on the VDR 3000 or remote control

handset

1 Screen shots are simulated.

18

To return to the previous track press the Previous Button on the VDR 3000 or remote

control handset

If you wish to search through a track during playback you can press the F.F. Button. There

are several speeds available and pressing the F.F. Button will cycle through to a faster

fast forward speed.

To search back through a track, press the REW Button. There are several speeds

available and each press of the REW Button will cycle through to a faster rewind speed.

To pause a track during playback, press the Pause Button. This will stop the playback and

a still image of the frame will be held on the TV Monitor (video disk only). You can move

forward one frame at a time by pressing the STP (STEP) Button. To release the pause and

return to normal playback press the Play Button.

To stop playback press the Stop Button.

To silence the track during playback press the Mute Button. To cancel the mute function

press the Mute Button a second time.

To remove the disk press the Eject Button, the CD tray will slide open. Remove the disk

and press the Eject Button again to close the CD tray.

Recording a disk

The VDR 3000 can record onto CD-R and CD-RW disks. CD-R disks can only be recorded

once whereas CD-RW disks can be erased and re-recorded several times.

Press the Eject Button on the front of the VDR 3000 or on the remote control handset and

the CD tray will slide open.

Place the disk that you want to record on to in the tray, printed side facing up.

Press the Eject Button and the CD tray will close and “LOAD” will appear on the display

panel.

If the disk is blank after a few seconds’ six recording format options will appear on the TV

screen VCD/HQVCD/SVCD/DVD-PHOTO/ CDDVD and CD-DA. Highlight the format that

you want to record in by using the Up/Down Arrow Buttons and then press the Enter

Button. This can be achieved by using the front panel of the VDR 3000 or by using the

supplied remote control.

19

2

The VDR 3000 will take a few moments to prepare the disk for recording. If CDDVD, DVD-

PHOTO, HQ-VCD, VCD or SVCD has been selected then once prepared the VDR 3000

start up screen will disappear and the system will be ready to start recording. If CD-DA is

selected the VDR 3000 start up screen will remain on the TV.

Select the video input source:

DV Input (Option): To select a DV input source, set the slide switch on the rear panel to

DV position. Analog Input: To select the analog video input, set the slide switch on the

rear panel to VIDEO position. To select an analog video format by pressing the “VIDEO

INPUT” key on the remote controller. The “Video” will appear on the screen. Press the

“VIDEO INPUT” key again to cycle through Video and S-Video source and press the

“ENTER” key to select the desire video source.

Note: The default setting is composite video input mode.

Select the audio input source:

Press the “AUDIO INPUT” key on the remote controller to select the digital audio or analog

audio input source. Note: The default setting is set at analog audio input mode.

Select the video output format:

Press the “VIDEO OUTPUT” key, the video output format would be cycle shown on the top

of TV screen:

Video/S-Video

Sony Betacam

Mastushita M2

SMPTE

R.G.B.

The Sony Betacam, Mastushita M2 and SMPTE format are all output with component

Y.U.V. video format with slight different level. Press the “VIDO OUTPUT” key till find the

format you want. The default setting is set at Video/S-Video format. Note: Please don’t

hook up the video cables to Y.U.V./R.G.B. and Video/S-Video connectors at same time. It

will cause the incorrect (lower) video output level.

NOTE: The VDR-3000 will return to default settings when powered on.

2 Screen Shots are simulated.

20

After set up the audio/video input and output. Start the source machine playing, in the case

of a video source the picture will appear on the TV screen. Find the footage that you want

to record to the disc and press the Rec. Button.

On the TV screen “record” will appear in the corner of the screen and after a moment

“recording” will appear. The display panel will start counting up in minutes and seconds to

indicate the recording length. When you reach the end of the footage press the Stop

Button.

To start recording the next track press the Record Button again. The Record message will

again appear on the TV screen, a new track number will appear on the display panel and

the counter will start counting from zero to indicate the record duration of the new track.

When you reach the end of the footage press the Stop Button. The display panel will

indicate how many tracks have been recorded and the total record duration of all the

tracks on the disc.

The tracks that have been recorded can be played back in the VDR 3000 but until the disc

is finalized the disc will not playback in other devices. Once a disc has been finalized it

is not possible to add any further tracks.

To finalize the disk press the Finalize Button on the front of the VDR 3000.

Note: The disk will be finalized automatically if the whole disk has been filled with

audio/video.

Finalizing CD appears on the TV screen. Finalizing takes about two minutes and once

finished the message disappears. The finished disk will now playback in other compatible

devices.

To remove the disk press the Eject Button, the CD tray will slide open. Remove the disk

and press the Eject Button again to close the CD tray.

PC Playback

Datavideo has provided a player that will be recorded onto every CD that is created by the

VDR 3000. The player will auto-run in a Windows based Personal Computer.3





 !"#$""$$"""$%#&'($&'$

%$)$Windows® 95/98/NT/2000 with DirectShow® installed (for Windows® NT 4.0 and

Windows® 95 download DXMedia® Runtime here). 32 MB RAM, Any VGA card

21

4

Playing CD’s in your PC:

1. The PC auto player is a MPEG-2 decoder, which requires a large amount of PC

resources. It is recommended that you close all running applications before

inserting the autoplay disk.

2. Insert your disk into your CD-ROM drive.

3. It could take up to 30 seconds for the disk to auto-play. Your PC will start the player

if it does not. Double left click “my computer”. Double left click your CD-ROM drive

and then double left click “playwnd.exe” icon ( ).This should start the auto

player.

4. A large video window will appear and a smaller play control window will appear.

Shown below:

Video Window

5

4 Screen shots are simulated.

5 Screen shots are simulated.

22

Player Control

Grabbing Frames from your CD to save or e-mail

1. Make sure the auto player is running.

2. On the player control window there is a Frame Grab Icon (picture of a camera).

3. Once you have decided on a specific frame press the Frame Grab icon

immediately.

4. A Save As window will appear, prompting for a file name.

5. Type in your file name and click ok.

Shown Below:

23

ADVANCED OPERATION

Colour correcting the video source before recording

The VDR-3000 has a built in a Digital Colour Processor that is very useful for recording a

videodisc from a low quality video source such as old VHS and Video 8 tape.

To make a correction to the video source, select the video format for the disc and then

press the Enter key. The Colour Processor on screen menu will appear on the TV screen,

AGC ON

Brightness

Contrast

Sharpness Color/

Hue

move the cursor up and down by using the “Up” and “Down” keys to select an adjustment

item and then press the “Enter” key again. The high light bar will be shown on the top of

TV screen. Please press the “Previous”(-) and “Next”(+) keys to adjust the level of

Brightness, Contrast, Sharpness, Colour and Hue (Hue adjustment only available with

NTSC system) for the source video. Note: To ensure to record a active video onto VCD or

S-VCD with less blocking. Please adjust the sharpness to “Soft” (high light bar to the end

of left side) position.

Please keep AGC (Auto Gain Control) turned “ON” for recording to ensure that the correct

video level is recorded on disc. If the video signal is too bright (can’t see the grade level of

light gray color) and cannot be corrected by adjusting the Contrast and Brightness

controls. Please switch the AGC to “OFF” by pressing the “Enter” when the cursor is on

“AGC On” position. Press the “Enter” key again to switch AGC mode back to “ON” status.

24

FAQ for the Datavideo Recorders

Q1. Which CD-R and CD-R/W Disc are recommended for use with the VDR-3000?

CD-R Disc CD-R/W Disc

Brand Speed Brand Speed

CMC 1-12X Acer 1-4X

Datavideo 1-12X CMC 1-4X

FUJI 1-12X Datavideo 1-4X

LeadData 1-12X Megadata 1-4X

Mitsubishi 1-12X Mitsubishi 1-4X

Maxell 1-12X Princo 1-4X

Mitsui 1-12X Ritek 1-4X

Prodisc Silver 1-12X RICOH 1-4X

PIONEER 1-12X Seantram 1-4X

Ritek 1-12X

RICOH 1-12X

SONY 1-12X

TDK 1-12X

Taiyo Yuden 1-12X

1-12X

Note: These discs have been tested, there are many others that will work that have

not been tested.

Q 2. Why will a CD-R Disc written by the VDR-3000 not play back in some home VCD

or DVD Players?

Some VCD or DVD Players do not support CD-R disc playback, so it cannot

recognize the CD-R that’s written by the VDR-3000. See the attached VCD/DVD

player list for your reference.

Q3. What is the difference of VCD, HQ-VCD, S-VCD, DVD-Photo and CDDVD format ?

VCD: MPEG-1 is a compression format compatible with most of VCD and DVD

players. The VCD disc can be played back by most VCD players, DVD players

and Microsoft Media Player Software on a PC. Since the VCD has a low

resolution and low bit rate 1.15Mbps format that is a good application for long

recording times without degrading too much of the image quality. This is ideal

for seminars and conference audio/video recording. VCD can record 74

minutes audio/video program on a 650MB CD-R disc.

HQ-VCD: MPEG-1 compression format is compatible with most media players. The HQ-

VCD can be played back by most DVD or S-VCD players and Microsoft Media

Player software on a PC. HQ-VCD has a low resolution but high bit rate

4Mbps, which is good for recording the active video without blocking effect.

The HQ-VCD can record 37 minutes of audio/video on a 650MB CD-R.

S-VCD: MPEG-2 compression format. The S-VCD player or DVD player that supports

S-VCD format can playback the S-VCD disc. PC CD-ROM can also playback

the S-VCD with the Datavideo auto PC player. The S-VCD has double the

resolution compared with VCD and also has a higher bit rate 2.4Mbps. The S-

VCD can record 37 minutes of audio/video on a 650MB CD-R.

25

DVD-Photo: MPEG-2 video compression format. The DVD-Photo disk can be played back

on a DVD player which supports S-VCD format and can be played back by PC

CD-ROM with the Datavideo auto PC player. DVD-Photo is full D1 resolution

(same as DVD) but only available for still images or slow motion video sources

due to low data transfer rate of 2.4Mbps for a high video resolution. The DVD-

Photo mode is very useful for creating a video album with high quality images

on disk. The DVD-Photo can record upto 98 images on a CD-R disc with DVD

video image quality.

CDDVD: MPEG-2 compression format. The CDDVD disk can be played back by newer

version DVD players and by a PC’s CD-ROM drive with our auto player. The

CDDVD disk is full D1 resolution (same as DVD) with a very high data transfer

rate of 4.8Mbps. It provides high quality video images for presentations,

educational or personal video collections. The CDDVD disk can record 18

minutes audio/video program on a 650MB CD-R.

Q4. Why will home DVD Players not playback SVCD Discs.

1、SVCD is not a DVD standard format, so most DVD Players do not support

SVCD Disc playback.

2、Some VCD or DVD Players do not support CD-R disc playback, so it cannot

recognize the CD-R written by the VDR-3000. See the attached VCD/DVD player

list for your reference.

Q5. Why will the recorded video not synchronize with it’s audio on playing back?

We have evaluated similar conditions on playing back the disc with few Players,

but this problem won’t happen on playing back the disc by most famous brand of

VCD/DVD player, such as Pioneer, SAMPO, ACER… so it is a VCD/DVD player

related compatible problem.

Q6. Why does the VDR-3000 take a much longer time on reading some various

Brands of CD-R, CD-R/W discs?

Some CD-R, CD-R/W disc are not fully compatible with the VDR 3000 CD-R/W

drive, so it will take a longer time to recognize the new disc or sometimes it will

fail. We recommend using the Datavideo specific VDR-1000R CD-R or VDR-

1000R/W CD-R/W disc, which have been verified and approved good quality for

VDR-3000.

Q7. Why does the recorded video have some flicking or shifting phenomenon?

Most of the root cause is the original video source quality, problems due to too old

VHS tape or others. Datavideo manufactures a Time Base Corrector machine

TBC-1000 or TBC-3000, which you may use it to correct the unstable video

source and color processing (TBC-3000 only).

Q8. Why does recording fail on some discs.

If there are more than 10% recording fail situation, please contact Datavideo for

further support.

According to the quality level of CD-R disc manufacture:

The “A” grade disc field failure rate is about --- 2%

The “B” grade disc field failure rate is about --- 6%

The “C” grade disc field failure rate is about --- 10%

So there is the opportunity to have a failure recording due to bad disk.

26

Q9. Why do some recorded CD-R/W discs have mosaic video or overlay video

effect after a few erase and re-write cycles?

It’s because the erase operation was not completed; you may double erase the

disc in VDR-3000 to resolve the problem.

Q10. What is the right setting for Power MAC G4 or iMAC to output video to VDR-

1000/3000DV for producing Video CD disc?

a). Require MAC O.S. 9.0.4 and QuickTime V4.1.2 for Power MAC G4 or iMAC

b). Please use the Final Cut Pro or iMovie software utility in the G4 for video capture

b). To disable the "remote function" in the Apple fire wire device control and treat the

VDR-1000DV interface as a video capture card, which means you need to "click"

on capture video manually as soon as the video is showing on the screen.

c). Online Un-plug the VDR-1000/3000DV fire wire cable from the G4 and re-plug it

back again to initialize the cable link and the G4 will find the correct protocol to

work with VDR-1000/3000DV.

Q11. Why am I getting the error message "Vencmpeg did not start"?

The VDR-3000 needs to have a signal to synchronize to before it records.

This error message is usually given when a user enables recording on the

VDR-3000 before playing back source material. When recording from

DV(IEEE/1394) you must play your source before pressing record on the

VDR-3000. Running 10 seconds of black should allow for a smooth recording

entry.

Q12. Why isn't the DV input working?

When connecting to your unit make sure that you have switched the

selector switch in the back of the VDR-3000 to "DV". Once the DV

selector switch is changed to DV, a red led will appear on the front

panel of the VDR-3000. Play your source video and watch to see

that the video is appearing on your monitor.

Q13. Why doesn't the S-video input work?

If you want to record from an S-video input source the selector button

on the remote control must be pressed when the unit is powered up.

On the lower right corner of the remote control there is a button marked

"I/P" this is the button that must be pressed. The default input for video

is composite (RCA type connectors) if you don't change the input the

S-video input will roll and the video signal will not pass through.

Q14. Why doesn't the CD-R disc that was written by the VDR-3000

play back in my home DVD player?

Not all consumer dvd players are compatible with the VCD or SVCD

formats. Some consumer dvd players are unable to read CD-R and

CD-RW discs.

27

Q15. Is there a way to get Windows Media Player or any other

editing program to recognize the "avseq01.dat" file created

by the VDR-3000?

The file name and extension of the raw mpeg file can be renamed

to a "*.mpg" extension. Windows Media Player is able to recognize this format.

Note: This will only work with mpeg-1 formats (VCD and HQ-VCD Modes)

that are created on the VDR-3000.

To achieve this, follow the directions below:

Explore your VCD or HQ-VCD disk in Windows Explorer

Look for a folder called "MPEGAV" (this is where each track of *.dat files

are saved in) Copy the AVSEQ01.DAT file to C:\ or any directory on your

hard drive. Right click your "AVSEQ01.DAT" file and choose "Rename"

Rename the file (anyname).MPG

Then press - Enter

The file now appears as a Windows Media Player icon

with the name you gave it.

The file will now be recognized as such and will open in programs that

are compatible with Windows Media Player.

Q16. What do I do if my machine has a rolling picture and I am inputting

an NTSC signal?

The unit could be set to the wrong format such as PAL@25 frames/second.

To change the input selector back to NTSC mode, the remote control is

needed.

There is a button on the remote called "P/N" it stands for PAL/NTSC.

It sets the input format of the machine. To change it back to NTSC

please do the following:

1. Power the VDR on.

2. Insert a blank CD-R.

3. Select any recording format. (VCD, etc.)

4. Press the "P/N button on the remote controller.

5. Keep pressing it until it either says "Auto or NTSC".

(Either one of these modes should be fine.)

6. Once this is completed, eject the blank disk and discard it.

This should make the PAL menu display go away and put the

VDR 3000 into NTSC mode.

28

Q17. DVD Players that can play back CD-R, CD-RW Discs and CD-DVD SVCD HQ-

VCD and VCD format video (For reference only)

DVD Model Capable

of CD-R

Playback

Capable

of

CD-R/W

Playback

DVD players that can playback

CD-DVD, HQ-VCD,SVCD,VCD

Unless otherwise noted, VCD

playback only is assummed

Acer DVD-5150 Yes Yes CD-DVD, SVCD,HQ-VCD,VCD

Afreey LD-2060 Yes Yes SVCD,HQ-VCD,VCD MP3

Aiwa XD-DV500 Yes ？

？？

？

Apex AD-500

/600/660/700/703 Yes Yes

SVCD、HQ-VCD、VCD、MP3

Amoisonic DVR2000 Yes Yes SVCD、HQ-VCD、VCD、MP3

Amoisonic DVD8506 Yes Yes SVCD、VCD、MP3

Denon DVD1500 Yes ？

？？

？

Denon DV3000 No Yes

Denver JVD200 Yes Yes MP3

Digitron DVS360 Yes No SVCD、HQ-VCD、VCD、MP3

DMW360 Sanyo Yes Yes

Eclipse Yes Yes

SVCD、HQ-VCD、VCD、MP3

Formax AV-2188 Yes Yes CD-DVD, SVCD,HQ-VCD,VCD

GE Digital GE1105P Yes Yes

GPX DV2000 Yes Yes SVCD、HQ-VCD、VCD、MP3

Hitachi DV-K2 No No

Hitachi DV-P250/E/U Yes Yes

Hitachi DV-P300U Yes Yes SVCD、HQ-VCD、VCD、MP3

Hitachi DV-P505U Yes Yes SVCD、HQ-VCD、VCD、MP3

HTK DVD868T Yes Yes CD-DVD, SVCD,HQ-VCD,VCD

Hoyo 8200 Yes Yes

JVC XV-D501BK Yes Yes

JVC XV-D701 No Yes

JVC XV-511 Yes Yes

JVC XV-515GD Yes No

JVC XV-523GD Yes Yes

JVC XV-521/525BK Yes Yes

Kenwood

DVF 5010/7010 No Yes

Kiss 1302/1502 Yes Yes SVCD、HQ-VCD、VCD、MP3

Kones DVD-3000 No Yes MP3

Konka KD-1800U Yes Yes

Labway Xwave 900 Yes Yes SVCD、HQ-VCD、VCD

Lasonic 850/2000 Yes Yes SVCD、HQ-VCD、VCD、MP3

LB 900 Xwave Yes Yes SVCD、HQ-VCD、VCD、MP3

Lenoxx 725B Yes Yes SVCD、HQ-VCD、VCD

Loewe Xemix Yes Yes

Marantz DVD-890 Yes No

Marantz DVD-4000 Yes ？

？？

？

Memorex

MVD-2025/2026 Yes ？

？？

？

Metz DE81 Yes Yes

29

DVD Model Capable

of CD-R

Playback

Capable

of

CD-R/W

Playback

DVD players that can playback

CD-DVD, HQ-VCD,SVCD,VCD

Unless otherwise noted, VCD

playback only is assummed

MICO A980 Yes Yes SVCD、HQ-VCD、VCD、MP3

Microboss MP3 Rock Yes Yes

Micromega minium Yes Yes

Oritron DVD200 Yes Yes

Panasonic A100 No Yes

Panasonic A105 No Yes

Panasonic A110 No Yes SVCD,HQ-VCD,VCD

Panasonic A115 No Yes Drop frames

Panasonic A120 No Yes

Panasonic A160 No Yes

Panasonic A300/

310/320/350/360 No Yes

Panasonic L50 Yes Yes

Panasonic LV75 Yes No

Panasonic M360K Yes Yes CD-DVD, SVCD,HQ-VCD,VCD

Panasonic P10 Yes No

Panasonic RV20 Yes No

Panasonic RV30 Yes Yes

Panasonic SCHT80 No Yes

Panasonic T-2000 No Yes

Phoenix 203 Yes Yes

Philips DVD701 Yes Yes

Philips DVD701/710/

711/718/730/750/751/

825/865AT/

930/940/950/955

Yes Yes SVCD,HQ-VCD,VCD

Philips DVD315AT ？

？？

？ Yes

Phoenix 204 Yes ？

？？

？

Pioneer DV-333/414/

434/505/515/525(K)/5

35/606(D)/626(D)/717

/C302D/C530D/F727

Yes Yes

Pioneer DV-K101 No Yes

Pioneer DV-K102 Yes Yes

Pioneer DV-K505 Yes Yes

Pioneer DVL 909/91 Yes Yes

Pioneer PDV-LC10 Yes Yes

Pioneer NS-DV1 Yes Yes

Pioneer NS-DV55 Yes ？

？？

？

Pioneer NS-

VSX09TX Yes ？

？？

？

ProScan PS8682P No No

Raite AVPhile 713 /

715/722D/727D Yes Yes CD-DVD, SVCD,HQ-VCD,VCD

RCA 5210P Yes Yes

RCA 5215P/5220P/

5221P/5223P No Yes

30

DVD Model Capable

of CD-R

Playback

Capable

of

CD-R/W

Playback

DVD players that can playback

CD-DVD, HQ-VCD,SVCD,VCD

Unless otherwise noted, VCD

playback only is assummed

Sampo DVE 560+ Yes Yes CdDVD, HQ-VCD, SVCD, VCD

Sampo DVE-611 Yes Yes CdDVD, HQ-VCD, SVCD, VCD

Sampo DVE-660 Yes Yes CdDVD, HQ-VCD, SVCD, VCD

Samsung

DVD608/611/709/711

/811/812/909

Yes Yes

Samsung DVD 927 Yes No

Sanyo DVD 6070 Yes ？

？？

？

Sharp 600U No Yes

Shinco DVD 360 Yes No

Shinco DVD 8320 Yes Yes

Shinco DVD 868 Yes Yes

Skyworth Yes Yes

SVCD、HQ-VCD、VCD、MP3

Smart DVD 2000 Yes Yes

SMC 330S/530 Yes Yes SVCD、HQ-VCD、VCD、MP3

SM Supervision 2000 Yes ？

？？

？

Sony DAVS-300 Yes Yes

Sony DVP-C600D Yes No

Sony DVP-C650D No Yes

Sony DVP-CX850D No Yes

Sony DVP-FX1 Yes Yes

Sony DVP-K330 No Yes

Sony DVP-S300 Yes Yes Can not use the blue color CD-R

Sony DVP-S315 Yes No Can not use the blue color CD-R

Sony DVP-S325 Yes Yes

Sony DVP-S330 Yes Yes

Sony DVP-S335 Yes Yes

Sony DVP-S336 Yes Yes

Sony DVP-S360 Yes Yes

Sony DVP-S3000 Yes No

Sony DVP-S500D Yes Yes

Sony DVP-S501D Yes No

Sony DVP-S525D Yes Yes

Sony DVP-S530D No Yes

Sony DVP-S550D Yes Yes

Sony DVP-S560D No Yes

Sony DVP-S715 Yes Yes

Sony DVP-S725D Yes Yes

Sony DVP-S7700 Yes No

Thomson

DTH 2500 Yes No

Thomson

DTH 2600 No Yes

Tokal 715S Yes Yes SVCD、HQ-VCD、VCD、MP3

Toshiba SD1200 No Yes SVCD、HQ-VCD、VCD

Toshiba SD2107 No No

Toshiba SD2109 Yes Yes

31

DVD Model Capable

of CD-R

Playback

Capable

of

CD-R/W

Playback

DVD players that can playback

CD-DVD, HQ-VCD,SVCD,VCD

Unless otherwise noted, VCD

playback only is assummed

Toshiba SD2200 Yes Yes

Toshiba SD3107 Yes No

Toshiba SD3107e Yes ？

？？

？

Toshiba SD3109 No Yes Drops frames

Whanedale

DVD-750 Yes No

Yamaha DVDS 795 No ？

？？

？

Note:

YES: Only Means that it can read a particular media type.

NO: Only means that it cannot read a particular media type.

？

？？

？: Means it has not been tested.

It would be appreciated if you can add to the compatibility information of DVD

players, which we can share with other users. For new information on DVD players,

please mail to service@datavideo.com.tw

32

SPECIFICATIONS:

 Playback Disc Type CDDVD/DVD-Photo/SVCD/HQ-VCD/VCD/Audio CD

 Recorder Disc Type CD-R, CD-R/W 650MB

 Audio CD sampling rate 44.1KHz, 16bit CD quality

 Video format CCIR601 NTSC and PAL

 CDDVD NTSC 704x480 at 30fps

PAL 704x576 at 25fps

Bit rate at 4.8Mb/sec

 DVD-Photo NTSC 704x480 at 30fps

PAL 704x576 at 25fps

Bit rate at 2.4Mb/sec

 S-VCD video resolution NTSC 352x480 at 30fps

PAL 352x576 at 25fps

Bit rate at 2.4Mb/sec

 HQ-VCD video resolution NTSC 352x240 at 30fps

PAL 352 x288 at 25fps

Bit rate at 2.4Mb/sec

 VCD video resolution NTSC 352x240 at 30fps

PAL 352 x288 at 25fps

Bit rate at 1.15Mb/sec

 Video inputs: Y/C (S-Video) mini DIN

CVBS (Video) RCA

Optional DV (IEEE1394/i-Link) 4-pin connector

*. By DV25 YUV 4:1:1 NTSC or YUV 4:2:0 PAL at

25Mb/sec bit rate

 Video Outputs: Y/C (S-Video) mini DIN

CVBS (Video) RCA

Y.U.V. Sony Betacam BNC

Y.U.V. Mastushita M2 BNC

Y.U.V. SMPTE BNC

R.G.B. BNC

 Digital Audio Input S/PDIF 44.1KHz, 16bit CD quality

 Audio Inputs: Stereo RCA 20Hz – 20KHz

 Audio Outputs: Stereo RCA 20Hz – 20KHz

 Microphone input Two dynamic microphone inputs, 600 ohm

 Power supply 115 –230VAC, 50/60Hz selectable

 Dimension 16.1x11.8x3.6 inches (410x300x92mm)

 Weight 9.3lbs / 4.2kg

33

Personal Computer Playerback Minimum System Requirements:

MMX-enhanced CPU (Intel® Pentium MMX, Pentium II, Celeron, Pentium III, AMD® K6-2,

K6-3, Athlon, etc.),

Windows® 95/98/NT/2000 with DirectShow® installed (for Windows® NT 4.0 and

Windows® 95 download DXMedia® Runtime here).

32 MB RAM

VGA card

Datavideo does not guarantee compatibility with all PCs.

For further information or technical support, visit our website at: www.datavideo-tek.com.

If your question cannot be answered from the website, please contact one of our locations.

Datavideo Locations

Datavideo Corporation USA

12300-U East Washington Blvd.,

Whittier, CA 90606

Tel: (562) 696-2324

Email: info@datavideo-tek.com

Datavideo Technologies Europe

Bv

Californiedreef 26,

3565 BL Utrecht, The

Netherlands

Tel: +31 30 261 9656

Email: info@datavideo.nl

Datavideo Technologies Co., LTD.

7F. Number 352, secretary. 2, Chung

Shan Rd.

Chung Ho City, Taipei Hsien,

Taiwan R.O.C.

Tel: 886-2-2246-7979

Email: info@datavideo.com.tw

www.datavideo-tek.com

P/N: 0820603112E
