Dayton Audio Division of Parts Express DSP408 Digital Processing Unit User Manual
Dayton Audio Division of Parts Express Digital Processing Unit Users Manual
Users Manual
RegulatoryInformation
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Note: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. such modifications could void the user’s
authority to operate this equipment
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
DSA‐408 Brief Introduction：
Section One：General Introduction
Section Two：DSP Connectors and control units
Section Three：Technical Data
Section Four：Graphical User Interface
Section Five：Mobile APP
Section Six：Wiring Diagram
1、General Introduction：
→ 24bit/48Khz sampling frequency，56bit DSP Resolution
→ 4CH RCA Stereo inputs, 4CH Stereo High Level Inputs , 8CH RCA Low
Level Outputs
→ Remote controller with LED-Display for Master Volume and storage data
→ Subwoofer Volume
→ 6 storage modes
→ simple system with high stability
12 3
4
4
5
6
8
2. Connectors and control units
1. Power/Speaker Connector: REM /IN REM/OUT /SPK LEVEL IN
2. Turn on selection: REM ，SPK DC turn on，RCA signal auto turn on
3. Power LED（Green）
4. RCA signal input (Line input):RCA inputs for connecting head unit signals
5. External Remote for the volume and mode switch
7
6. PC control: connect the DSP to your PC.
7. 8CH low level output (Line output):Line outputs for connecting amplifiers.
8. External Bluetooth: connect the mobile for APP adjustment and play music. (Bluetooth 4.0 dual-mode)
3. Technical Data：
1. Over/under voltage protection，DSP will go into protection automatically when the voltage is over 17.5V or lower 7.5V.
The DSP will resume normal work when the voltage returns to normal.
2. Reverse voltage protection
3. Mute circult and delay.
4. High level input impedance: 180R
5. RCA input impedance: ≥20K
6. Frequency response:20HZ-20KHZ
7. Output impedance: <50R
8. Maximun input level ≥3.2V 1% THD
9. S/N≥115DB.
10. REM OUT current >500MA
11.Operating voltage : 9-17V
4. Graphical User Interface
（1）Main menu (see above)
A、load：connect with the DSP and on-line operation
1
4
3
2
5
B、Menu：Save modes, encryption and change language.
（2）Channel configuration
（3）Equalizer
（4）Highpass filter and Lowpass filter
（5）Volume Control
1. Main Menu，volume control and six storage modes
2. Equalizer adjustment
3. Volume control, mute, phase and HP/LP
4. Set Delay
5. Mixer (summing)
1
4
3
25
¿
8.8.
VOL MO DE
DSP LAT
+ - SPK
DSP-408 Wiring diagram
RCA signal power on
Hi-input DC power on
REM power on
3 ways for adjustment:
1. GUI
2. Connect to Mobile phone via Bluetooth and control by App
3. Remote control
PC will be priority, when 3 ways are all be connected,
