Users Manual
Dayton Audio Division of Parts Express
Wireless Speaker Kit with Subwoofer Output
(M/N)：XRA25
1. working voltage: DC 9V/0.2A.
2. modulation GFSK
3. 2.4GHz ISM Band
4. Low LBOM cost
5. Audio format 16bit , 48KHz sampling rate
6. Power ON/OFF pop noise reduction
7. Robust Packet error correction
8. Low power consumption
9. No RF induced audio noise
10. Ready to go reference system
11. S/N: -95dB
Main Function
DC9V
LINE IN
Speaker input RF pairing
Subwoofer in
Dayton Audio Division of Parts Express
The application diagram
DVD M
p
3
Wireless Speaker Kit with Subwoofer Output
wired
audio RF Receiver
Power button
FCC Certification Requirements
Caution: Any changes or modifications in construction of this device which are not
expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
