User Manual
BLUE HR
Contact Wahoo Fitness
Please feel free to contact
Wahoo Fitness for any
questions you have
regarding your product.
Wahoo Fitness L.L.C.
141 W. Wieuca B104
Atlanta, Georgia, USA 30342
www.wahoofitness.com
support@wahoofitness.com
Warnings
Before beginning or modifying any exercise program, please consult your physician.
If you have a pacemaker or other implanted electronic device, consult your
physician before using a heart rate sensor. This product is intended for recreational
use only and is not intended for medical purposes. Heart rate and other readings
could be influenced by interference from external sources.
If you use this product with navigation software, always be aware of your surround-
ings and do not fixate on the screen. Moreover, set destinations and other user
inputs prior to your departure to ensure your attention stays on task and your
facilities are directed to your activity and not the device.
This device contains no user user-serviceable parts and repairs/modifications should
only be made by a technician authorized by Wahoo Fitness. Any unauthorized
modifications or repairs will void your warranty. Do not leave device exposed to
excessive heat or cold.
California Proposition 65
The enclosed hardware and its packaging contain chemicals the State of California
has found to cause cancer, birth defects or reproductive harm.
FCC Rules Part 15
The enclosed hardware device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference and (2) it must accept any interference received, including interfer-
ence that may cause undesired operation.
Limited Warranty
Wahoo Fitness warrants this product to be free from defects in material and
workmanship, under normal use, for one year from the date of original purchase.
Defects that have resulted from improper or unreasonable use or maintenance,
accident, excess moisture, insects, improper packing, lightning, power surges, or
unauthorized tampering, alteration or modification are not covered. Wahoo Fitness
will, at its discretion, repair or replace with a comparable product, at no charge to
the customer for parts or labor, so long as customer is responsible for shipping costs.
Products may be new, refurbished or reconditioned and are warranted for the
unexpired period of the original purchase, or 60 days from return, whichever is
greater. Any products replaced become the property of Wahoo Fitness.
WHERE PERMITTED, THE PROVISIONS OF THIS LIMITED WARRANTY ARE IN LIEU OF ANY
OTHER WRITTEN WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
IN NO EVENT SHALL WAHOO FITNESS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSE-
QUENTIAL OR INDIRECT DAMAGES. SOME PLACES DO NOT ALLOW LIMITATIONS ON
THE EXCLUSION OR LIMITATION OF LIABILITY TO SPECIFIED AMOUNTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
To obtain warranty service, contact Wahoo Fitness for shipping instructions and an
RMA tracking number. Return your device, freight prepaid, along with the original
sales receipt which is a required proof of purchase for warranty repairs, with the
RMA tracking number written on the outside of the package, and mail to Wahoo
Fitness.
Legal
BLUE HR
Heart Rate Sensor Pod (Front) Heart Rate Sensor Pod (Back)
Heart Rate Strap
Overview
Your Wahoo Fitness Heart Rate Strap is a device worn in proximity to the heart that
captures electrical activity data to derive your pulse.
How to Use
zThoroughly wet both of the plastic Conductive Pads on the Strap with water or
electrode gel. It is important that the Conductive Pads are sufficiently moist so
that a good skin-to-Conductive Pad connection is made.
zSnap one end of the Strap to one side of the Pod. Either end of the Strap can
connect to either end of the Pod, but the Pod should have the Wahoo Fitness
logo facing up when in use.
zWrap the Strap around your back and snap the free end to the free side of
the Pod so that the Pod is located on your breastplate, just below your
breasts. Adjust the Strap to create a snug, yet comfortable fit.
zOnce in place, move within 5’ - 10’ of any device that is compatible with
Bluetooth Smart wireless sensors.
Troubleshooting
If you do not get a reading, or the readings are erroneous, ensure that the
Conductive Pads are wet, have good contact with your skin and the that your
Strap is sufficiently snug. Your Heart Rate Sensor ‘sleeps’ with inactivity and
‘awakens’ with good electrical contact. To test your Sensor, the following
procedure is helpful: 1/start your reader so that it is looking for a heart rate sensor,
2/in your hands, connect the Strap to the Sensor Pod as you would if wearing it (ie.
connect both snaps), 3/rub your two thumbs on the two conductive pads on either
side of the Sensor Pod for 5-10 seconds. This should ‘awaken’ your sensor so that it is
broadcasting and the results should be displayed on your reader.
Pairing
Each Wahoo Fitness Sensor has a unique identification code and can be uniquely
paired with a reader so that if you start your activity in proximity to other sensors,
such as the start of a race, your program doesn‘t pick up someone else’s sensor.
Since each reader is unique, you should reference the instructions of your reader for
pairing techniques.
Battery
The battery in your Wahoo Fitness Heart Rate Sensor is located behind a cover on
the back of your Heart Rate Sensor Pod and can be replaced by placing a coin in
the slot and turning the cover 1/4 turn counterclockwise. Replace with a 3 volt
CR2032 battery (contact a local waste handling group for proper disposal of old
battery). After removing the old battery, wait 45 seconds before installing the new
battery to ensure the electronics fully reset.
Instructions
WFBTHR01
Snaps
Battery Cover
For more information on the
Wahoo Fitness Heart Rate Sensor,
visit
www.wahoofitness.com/manuals
a
ps
Snaps
Conductive
Pads
Limited Warranty
Wahoo Fitness warrants this product to be free from
defects in material and workmanship, under normal
use, for one year from the date of original purchase.
Defects that have resulted from improper or
unreasonable use or maintenance, accident, excess
moisture, insects, improper packing, lightning, power
surges, or unauthorized tampering, alteration or
its discretion, repair or replace with a comparable
product, at no charge to the customer for parts or
labor, so long as customer is responsible for shipping
costs. Products may be new, refurbished or
reconditioned and are warranted for the unexpired
period of the original purchase, or 60 days from
return, whichever is greater. Any products replaced
become the property of Wahoo Fitness.
WHERE PERMITTED, THE PROVISIONS OF THIS
LIMITED WARRANTY ARE IN LIEU OF ANY OTHER
WRITTEN WARRANTY, WHETHER EXPRESS OR
IMPLIED, WRITTEN OR ORAL, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL WAHOO FITNESS BE LIABLE
FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES. SOME PLACES DO NOT
ALLOW LIMITATIONS ON THE EXCLUSION OR
LIMITATION OF LIABILITY TO SPECIFIED
AMOUNTS, SO THE ABOVE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU.
To obtain warranty service, contact Wahoo Fitness for
shipping instructions and an RMA tracking number.
Return your device, freight prepaid, along with the
original sales receipt which is a required proof of
purchase for warranty repairs, with the RMA tracking
number written on the outside of the package, and
mail to Wahoo Fitness.
Contact Wahoo Fitness
Please feel free to contact Wahoo Fitness for any
questions you have regarding your product.
Wahoo Fitness L.L.C.
141 W. Wieuca Road B104
Atlanta, Georgia, USA 30342
If this equipment does cause interference to radio or
television equipment reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and
receiver
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV
technician for help
To assure continued compliance, any changes or
responsible for compliance could void the users
authority to operate this equipment. (Example- use
only shielded interface cables when connecting to a
computer or peripheral devices).
Radiation Exposure Statement
This device complies with Part 15 of the FCC Rules.
Operation is subjected to the following two
conditions 1) this device may not cause harmful
interference and 2) this device must accept any
interference received, including interference that
may cause undesired operation.
Caution! The manufacturer is not responsible for any
radio or TV interference caused by unauthorized
could void the users authority to operate the
equipment.
IC Statement
This device complies with Industry Canada
license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may
not cause interference, and (2) this device must
accept any interference, including interference that
may cause undesired operation of the device. The
device meets the exemption from the routine
evaluation limits in section 2.5 of RSS 103 and
users can obtain Canadian information on RF
exposure and compliance.
d'Industrie Canada applicables aux appareils radio
radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement. Le
Canadian Representative as seen below:
Name: Iona Enterprises Ltd
Address: 203-1975 Pine Street Vancouver, BC V6J
3E1
Tel: 604-992-0612
This Important Product Information Guide contains
safety and handling, regulatory, and warranty
information for the Wahoo Blue HR
Important Safety and Handling Information
CAUTION: RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE.
CAUTION: DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.
Before beginning or modifying any exercise program,
please consult your physician. If you have a
pacemaker or other implanted electronic device,
consult your physician before using a heart rate
sensor. This product is intended for recreational use
only and is not intended for medical purposes. Heart
interference from external sources. If you use this
product with navigation software, always be aware of
Moreover, set destinations and other user inputs prior
to your departure to ensure your attention stays on
task and your facilities are directed to your activity
and not the device. This device contains no user user
only be made by a technician authorized by Wahoo
will void your warranty. Do not leave device exposed
to excessive heat or cold.
California Proposition 65
The enclosed hardware and its packaging contain
chemicals the State of California has found to cause
cancer, birth defects or reproductive harm.
FCC Rules Part 15
The enclosed hardware device complies with part 15
of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not
cause harmful interference and (2) it must accept
any interference received, including interference that
may cause undesired operation.
FCC ID : O4GHRMBLE
IC: 7666A-HRMBLE
FCC Compliance Statement:
This equipment has been tested and found to comply
with limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful
interference in residential installations. This
equipment generates, uses, and can radiate radio
frequency energy, and if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
Important Product
Information
