Users manual
fisica
Sensor Case
Warnings
Before beginning or modifying any exercise program, please consult your physician.
If you have a pacemaker or other implanted electronic device, consult your
physician before using a heart rate sensor. This product is intended for recreational
use only and is not intended for medical purposes. Heart rate and other readings
could be influenced by interference from external sources.
If you use this product with navigation software, always be aware of your surround-
ings and do not fixate on the screen. Moreover, set destinations and other user
inputs prior to your departure to ensure your attention stays on task and your
facilities are directed to your activity and not the device.
This device contains no user user-serviceable parts and repairs/modifications should
only be made by a technician authorized by Wahoo Fitness. Any unauthorized
modifications or repairs will void your warranty. Do not leave device exposed to
excessive heat or cold.
California Proposition 65
The enclosed hardware and its packaging contain chemicals the State of California
has found to cause cancer, birth defects or reproductive harm.
FCC Rules Part 15
The enclosed hardware device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference and (2) it must accept any interference received, including interfer-
ence that may cause undesired operation.
Limited Warranty
Wahoo Fitness warrants this product to be free from defects in material and
workmanship, under normal use, for one year from the date of original purchase.
Defects that have resulted from improper or unreasonable use or maintenance,
accident, excess moisture, insects, improper packing, lightning, power surges, or
unauthorized tampering, alteration or modification are not covered. Wahoo Fitness
will, at its discretion, repair or replace with a comparable product, at no charge to
the customer for parts or labor, so long as customer is responsible for shipping costs.
Products may be new, refurbished or reconditioned and are warranted for the
unexpired period of the original purchase, or 60 days from return, whichever is
greater. Any products replaced become the property of Wahoo Fitness.
WHERE PERMITTED, THE PROVISIONS OF THIS LIMITED WARRANTY ARE IN LIEU OF ANY
OTHER WRITTEN WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
IN NO EVENT SHALL WAHOO FITNESS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSE-
QUENTIAL OR INDIRECT DAMAGES. SOME PLACES DO NOT ALLOW LIMITATIONS ON
THE EXCLUSION OR LIMITATION OF LIABILITY TO SPECIFIED AMOUNTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
To obtain warranty service, contact Wahoo Fitness for shipping instructions and an
RMA tracking number. Return your device, freight prepaid, along with the original
sales receipt which is a required proof of purchase for warranty repairs, with the
RMA tracking number written on the outside of the package, and mail to Wahoo
Fitness.
Legal
Compatible With
“Made for iPhone” means that an
electronic accessory has been
designed to connect specifically to
iPhone and has been certified by
the developer to meet Apple
performance standards. Apple is
not responsible for the operation of
this device or its compliance with
safety and regulatory standards.
Please note that the use of this
accessory with iPhone may affect
wireless performance.
iPhone is a trademark of Apple Inc.,
registered in the U.S. and other
countries.
fisica
Download
Wahoo Fitness Utility App from iTunes.
Insert
fisica securely into 30-pin connector at bottem of iPhone, iPod touch or iPad.
Open
Wahoo Fitness Utility and select Sensor tab.
Select
sensor you would like to pair with iPhone, iPod touch or iPad. Ensure the sensor is
within 5’ of fisica.
Done!
Your sensor should show data from the sensor, the signal strength and the serial
number of your sensor. Since ANT+ sensors ‘sleep’ when not in use, you may have
to ‘awaken’ it - for example, a footpod can be activated by taking a few steps.
Other Apps
Each App has a unique way in which it works with sensors so there is no universal
method for using fisica with all Apps. One common feature is that each App can
be ‘paired’ with a particular sensor to avoid readings from other people’s sensors.
Check our website for the current list of Apps compatible with your fisica sensor key.
3rd Party Sensors
fisica will work with all wireless sensors that conform to the ANT+ standard.
However, third party sensors have not been tested or verified by Wahoo Fitness and
the accuracy of the data produced may not be as precise as those of Wahoo
Fitness sensors
Contact Wahoo Fitness
Please feel free to contact Wahoo Fitness for any questions you have regarding
your product.
Wahoo Fitness L.L.C.
1604 athens Hwy
Gainesville, Georgia, USA 30507
(404) 939-2447
www.wahoofi
AP201
tness.com
Instructions
fisica
Warnings
Before beginning or modifying any exercise program, please consult your physician.
If you have a pacemaker or other implanted electronic device, consult your
physician before using a heart rate monitor. This product is intended for
recreational use only and is not intended for medical purposes. Heart rate and
other readings could be influenced by interference from external sources.
If you use this product with navigation software, always be aware of your surround-
ings and do not fixate on the screen. Morover, set destinations and other user inputs
prior to your departure to ensure your attention and facilities are directed on your
activity and not the device.
This device contains no user user-serviceable parts and repairs/modifications should
only be made by a technician authorized by Wahoo Fitness. Any unauthorized
modifications or repairs will void your warranty. Do not leave device exposed to
excessive heat or cold.
California Proposition 65
The enclosed hardware and its packaging contain chemicals the State of California
has found to cause cancer, birth defects or reproductive harm.
FCC Rules Part 15
The enclosed hardware device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmul
interference and (2) it must accept any interference received, including interfer-
ence that may cause undersired operation.
Limited Warranty
Wahoo Fitness warrants this product to be free from defects in material and
workmanship, under normal use, for one year from the date of orignial purchase.
Defects that have resulted from improper or unreasonable use or maintenance,
accident, excess moisture, insects, improper packing, lightning, power surges, or
unauthorized tampering, alteration or modification are not covered. Wahoo Fitness
will, at its discretion, repair or replace with a comparable product, at no charge to
the customer for parts or labor, so long as customer is repsonsible for shipping costs.
Products may be new, refurbished or recondishioned and are warranted for the
unexpired period of the original purchase, or 60 days from shipment, whichever is
greater. Any products replaced become the property of Wahoo Fitness.
WHERE PERMITTED, THE PROVISIONS OF THIS LIMITED WARRANTY ARE IN LIEU OF ANY
OTHER WRITTEN WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
IN NO EVENT SHALL WAHOO FITNESS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSE-
QUENTIAL OR INDIRECT DAMAGES. SOME PLACES DO NOT ALLOW LIMITATIONS ON
THE EXCLUSION OR LIMITATION OF LIABILITY TO SPECIFIED AMOUNTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
To obtain warranty service, contact Wahoo Fitness for shipping instructions and an
RMA tracking number. Return your device, freight prepaid, along with the original
sales receipt which is a required prrof of purchase for warranty repairs, with the RMA
tracking number written on the outside of the package, and mail to Wahoo Fitness.
Legal
Compatible With
iPhone is a trademark of Apple,
Inc., registers in the U.S. and other
countries.
iPhone is a trademark of Apple,
Inc., registers in the U.S. and other
countries.
“Made for iPod,” and “Made for
iPhone” mean that an electronic
accessory has been designed to
connect specifically to iPod or
iPhone, respectively, and has been
certified by the developer to meet
Apple performance standards.
Apple is not responsible for the
operation of this device or its
compliance with safety and
regulatory standards.
iPhone and iPod touch are
trademarks of Apple Inc., registered
in the U.S. and other countries.
fisica
Sensor Case
Thank you for buying the Wahoo Fitness fisica Sensor Case! With fisica technology, a
world of sensor information is opened to your iPhone and scores of Apps are available to
access sensor information in countless ways. Provided here is a quick start guide to using
your fisica Sensor Case - for more information please see our website for more detailed
information and troubleshooting...
www.wahoofitness.com/fisicacaseinfo
Quick Start Guide
Open the fisica Case by unseating each of the six release tabs. Remove cover. Select
and install the approriate rubber cradle for your iPhone, either the iPhone 3G/3GS cradle
or the iPhone 4 cradle (the case comes with the iPhone 4 cradle already installed). Slide
your iPhone into the Case from the top so that the slot at the bottom of the iPhone slides
into the 30-pin connector located at the bottom of the Case. Replace cover and
secure by engaging all six release tabs.
Find Sensors
Each App that incorporates fisica technology uses a unique method to pair with sensors
and you should consult the instructions of the App you are using for the appropriate
pairing technique. If you are having a problem getting your sensor to pair with a
particular App, you can check if the case is working with a particular sensor by using the
fisica Sesnor Utility App. To do this, download the free fisica Sensor Utility App onto your
iPhone from iTunes. Open the App, go to the Sensors tab and select the appropriate
sensor you are trying to find - ensure the sensor is within 5’ of fisica. Your iPhone should
show data from the sensor, the signal strength and the serial number of your sensor.
Since most ANT+ sensors ‘sleep’ when not in use, you may have to ‘awaken’ it - for
example, a stride sensor can be activated by taking a few steps.
Bike Mount
The fisica Case comes with a semi-permanent Bike Mount. The Bike Mount is secured by
threading each of the two Cable Ties through the mounting eyes on the bike mount
(located under the body of the mount) and wrapping around either the handlebars or
the stem, depending on preference. Pull the Cable Ties through their self mating
receivers and pull tight (excess length can be trimmed with scissors). The Bike Mount
can rotate in 90 degree increments by loosening the set screw in the middle of the base,
turning as desired, and re-tightening the set screw.
Auxilliary Battery
Any iPhone compatible auxilliary battery that utilizes a microUSB connector can be used
by plugging the battery into the microUSB port located at the bottom of the Case.
Useability
The Case is designed to be weather and impact resistant. However, Wahoo Fitness does
not warrant against damage to the Case or your iPhone as a result of water, impact or
other factors. It is your responsibility to determine if the Case will provide adequate
protection given the conditions in which it is being used.
3rd Party Sensors
fisica will work with all wireless sensors that conform to the ANT+ standard. However, third
party sensors have not been tested or verified by Wahoo Fitness and the accuracy of
the data produced may not be as precise as those of Wahoo Fitness sensors.
Contact Wahoo Fitness
Feel free to contact Wahoo Fitness for any questions you have regarding your product.
Wahoo Fitness L.L.C.
1604 Athens Hwy
Gainesville, Georgia, USA 30507
AP202
Quick Start
Instructions
WFPeto01
fisica Case
Rear
fisica Case
Front
Back
Bike
Mount
Track
MicroUSB
Port
Headphone
Jack
Rubber Cradle
Bike Mount
Slide Lock
Set Screw
Mounting Eye
For a list of Apps compatible with
the fisica Case, please visit
wahoofitness.com/Apps/Apps.asp
www.wahoofitness.com
fisica
Sensor Case
Warnings
Before beginning or modifying any exercise program, please consult your physician.
If you have a pacemaker or other implanted electronic device, consult your
physician before using a heart rate sensor. This product is intended for recreational
use only and is not intended for medical purposes. Heart rate and other readings
could be influenced by interference from external sources.
If you use this product with navigation software, always be aware of your surround-
ings and do not fixate on the screen. Moreover, set destinations and other user
inputs prior to your departure to ensure your attention stays on task and your
facilities are directed to your activity and not the device.
This device contains no user user-serviceable parts and repairs/modifications should
only be made by a technician authorized by Wahoo Fitness. Any unauthorized
modifications or repairs will void your warranty. Do not leave device exposed to
excessive heat or cold.
California Proposition 65
The enclosed hardware and its packaging contain chemicals the State of California
has found to cause cancer, birth defects or reproductive harm.
FCC Rules Part 15
The enclosed hardware device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful
interference and (2) it must accept any interference received, including interfer-
ence that may cause undesired operation.
Limited Warranty
Wahoo Fitness warrants this product to be free from defects in material and
workmanship, under normal use, for one year from the date of original purchase.
Defects that have resulted from improper or unreasonable use or maintenance,
accident, excess moisture, insects, improper packing, lightning, power surges, or
unauthorized tampering, alteration or modification are not covered. Wahoo Fitness
will, at its discretion, repair or replace with a comparable product, at no charge to
the customer for parts or labor, so long as customer is responsible for shipping costs.
Products may be new, refurbished or reconditioned and are warranted for the
unexpired period of the original purchase, or 60 days from return, whichever is
greater. Any products replaced become the property of Wahoo Fitness.
WHERE PERMITTED, THE PROVISIONS OF THIS LIMITED WARRANTY ARE IN LIEU OF ANY
OTHER WRITTEN WARRANTY, WHETHER EXPRESS OR IMPLIED, WRITTEN OR ORAL,
INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
IN NO EVENT SHALL WAHOO FITNESS BE LIABLE FOR SPECIAL, INCIDENTAL, CONSE-
QUENTIAL OR INDIRECT DAMAGES. SOME PLACES DO NOT ALLOW LIMITATIONS ON
THE EXCLUSION OR LIMITATION OF LIABILITY TO SPECIFIED AMOUNTS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
To obtain warranty service, contact Wahoo Fitness for shipping instructions and an
RMA tracking number. Return your device, freight prepaid, along with the original
sales receipt which is a required proof of purchase for warranty repairs, with the
RMA tracking number written on the outside of the package, and mail to Wahoo
Fitness.
Legal
Compatible With
“Made for iPhone” means that an
electronic accessory has been
designed to connect specifically to
iPhone and has been certified by
the developer to meet Apple
performance standards. Apple is
not responsible for the operation of
this device or its compliance with
safety and regulatory standards.
Please note that the use of this
accessory with iPhone may affect
wireless performance.
iPhone is a trademark of Apple Inc.,
registered in the U.S. and other
countries.
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
To assure continued compliance, any changes or modifications
not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
(Example- use only shielded interface cables when connecting to
computer or peripheral devices).
Radiation Exposure Statement
This equipment complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this
equipment. Such modifications could void the user authority to
operate the equipment.
fisica
Download
Wahoo Fitness Utility App from iTunes.
Insert
fisica securely into 30-pin connector at bottem of iPhone, iPod touch or iPad.
Open
Wahoo Fitness Utility and select Sensor tab.
Select
sensor you would like to pair with iPhone, iPod touch or iPad. Ensure the sensor is
within 5’ of fisica.
Done!
Your sensor should show data from the sensor, the signal strength and the serial
number of your sensor. Since ANT+ sensors ‘sleep’ when not in use, you may have
to ‘awaken’ it - for example, a footpod can be activated by taking a few steps.
Other Apps
Each App has a unique way in which it works with sensors so there is no universal
method for using fisica with all Apps. One common feature is that each App can
be ‘paired’ with a particular sensor to avoid readings from other people’s sensors.
Check our website for the current list of Apps compatible with your fisica sensor key.
3rd Party Sensors
fisica will work with all wireless sensors that conform to the ANT+ standard.
However, third party sensors have not been tested or verified by Wahoo Fitness and
the accuracy of the data produced may not be as precise as those of Wahoo
Fitness sensors
Contact Wahoo Fitness
Please feel free to contact Wahoo Fitness for any questions you have regarding
your product.
Wahoo Fitness L.L.C.
1604 athens Hwy
Gainesville, Georgia, USA 30507
(404) 939-2447
www.wahoofi
AP201
tness.com
Instructions
IC Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may
cause undesired operation of the device.
The device meets the exemption from the routine evaluation limits in
section 2.5 of RSS 102 and users can obtain Canadian
information on RF exposure and compliance.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Le dispositif rencontre l'exemption des limites courantes
d'évaluation dans la section 2.5 de RSS 102 et les utilisateurs
peuvent obtenir l'information canadienne sur l'exposition et la
conformité de rf.
Canadian Representative as seen below:
Name: DYNASTREAM INNOVATIONS INC.
Address: 228 River Avenue, Cochrane, Alberta, T4C 2C1, Canada
Tel: 403 932-9292
