Users manual
CM-10 / LT-100
STEREO FM TRANSMITTER
INSTRUCTION MANUAL
CANADA
‘’ Operation of this device is subject to the following two conditions:
(1) This device may not cause interference and (2) this device must accept
any interference, including interference that may cause undesired operation
of the device.’’
USA
“This device complies with Part 15 of the FCC rules. Operation of this device
is subject to the following two conditions:(1) this device may not cause
harmful interference; and (2) this device must accept any interference
received, including interference that may cause undesired operation.’’
200903-100
DECADE
2
2
Introduction
Thank you for purchasing one of the fine products made by DECADE
transmitters. Before using it, please read this manual carefully in order to obtain
the best possible results from your transmitter.
Description
The CM-10 / LT-100 is a consumer grade low power FM transmitter operating
in the commercial FM band (88.1 - 107.5 MHz). It is especially designed for in-
house broadcasting, gyms and fitness centres and small rooms for a variety of
entertainment, hearing assistance, translation, and information applications. Its
excellent RF and audio performances, small size and ease of use make the
CM-10 / LT-100 stand out from all the other consumer grade FM transmitters
on the market.
Operation
1 - Extend the telescopic antenna.
2 - Connect a line level audio source to the line input, or a microphone to the
microphone input.
3 - Use the Up and Down push buttons to select transmitting frequency.
4 - Using an FM receiver tuned to the transmitting frequency, adjust the line
level or microphone level in order to obtain a good sound on the receiver.
The sound level at the receiver should be loud enough, but not too loud to
avoid disortion.
Warranty
The CM-10 / LT-100 transmitter comes with a one (1) year warranty that covers
parts replacement and labour required to repair any defects resulting from the
manufacturing process. All claims must be authorized by DECADE prior to
shipment of a faulty unit for repair. Shipping fees are assumed by the client and
DECADE will pay for the return of the repaired unit.
Warning
Any changes or modifications to the software or equipment that are not expressly
approved by Decade Transmitters Inc. could void the manufacturer’s warranty,
and could void the user’s authority to operate the equipment.
3
3
Decade Transmitters inc. is not responsible for any financial loss or violation of
local laws resulting in the utilisation of their transmitters.
This transmitter operates on the 88.1 MHz - 107.5 MHz commercial FM broadcast
band, so signals transmitted can be received on any standard FM receiver. Thus,
some care should be taken in the use made out of this transmitter.
The FCC legislate the use of FM transmitters in USA and the CRTC (Canadian
Radio-television and Telecommunications Commission) and IC (Industry Canada)
legislate the use of FM transmitters in Canada. No licence is required for the use
of this FM transmitter in Canada and USA.
Technical specifications
• Modulation : FM, 75 kHz deviation
• Frequency selection : 88.1 - 107.5 MHz
• Frequency tolerance : ±0.005% max.
• RF power : 250 µV/m@3m (FCC Part 15 and IC RSS-210)
• Spurious rejection : 35 dB min.
• Frequency response : 20 - 15 kHz (line input)
• Harmonic distortion : 0.5% max.
• Signal-to-noise ratio : : 55 dB min., 60 dB typ.
• Stereo separation : 30 dB min., 35 dB typ.
• Audio input connector : stereo 1/8’’
• Power supply : 115 VAC in, 12 VDC out
• Dimensions : 3.50" W x 5.75" D x 2.00" H
• Weight : 2 lb. (total)
• Accessories : 6 feet audio cable with 1/8’’ stereo plug to 2 RCA plugs
DECADE TRANSMITTERS Inc.
3232 Richard street, unit 4, Sherbrooke, Quebec, Canada, J1L 1Y2
tel.: 819-563-4323, fax.: 819-563-3244
www.decade.ca
