Regulatory Model: P11E | Type: P11E002

Computer Model: M17x R4

Specifications

M17x R4

Dimensions

Height (front and back) 44.5 mm (1.75 inches)

Width 410.0 mm (16.14 inches)

Depth 304.3 mm (11.98 inches)

Weight with 9-cell battery

and optical drive

(starting at)

4.26 kg (9.39 lb)

NOTE: The weight of your laptop will vary depending

on the configuration ordered and the manufacturing

variability

System information

Computer Model M17x R4

Processor Intel Core i7 (2nd and 3rd generation)

L2 cache 256 KB

L3 cache up to 8 MB

Bus clock 100 Mhz

System chipset Mobile Intel HM77 Express Chipset

SDRAM bus width one or two 64-bit channels of DDR3 memory up to

1600 MHz

Processor address bus

width

32 bits

Processor data width 64 bits

BIOS EPROM 32 Mbit

Graphics bus PCIe x16 Gen2 and Gen3

Memory

Connectors four internally-accessible DDR3 using JEDEC

SODIMM sockets

Capacities 2 GB, 4 GB, and 8 GB

Memory type up to 1600 MHz, unbuffered non-ECC, single-channel

and dual-channel DDR3 configuration

Memory configurations

supported

4 GB, 6 GB, 8 GB, 12 GB, 16 GB, 24 GB, and 32 GB

Hard drive

Interface • SATA 2.0 (3 Gb/s) or SATA 3.0 (6 Gb/s)

• Solid-State Drive (SSD)

• mSATA

Number of hard drives two

Hard drive • two 2.5-inch SATA 2.0 (3Gb/s) or SATA 3.0 (6Gb/s)

hard drives

• two solid-state drives

Communications

Wireless • one half Mini-Card slot

• one full Mini-Card slot

• Bluetooth

• Wireless Display (optional)

• WirelessHD (optional)

Network adapter • one RJ45 port

• 10/100/1000 Mbps Ethernet LAN on system board

Ports and connectors

Network adapter one RJ45 port

USB four 4-pin USB 3.0-compliant ports

eSATA/USB combo one 7-pin/4-pin eSATA/USB 2.0-compliant combo

port with PowerShare and Windows debugging

HDMI input one 19-pin port

HDMI output one 19-pin port

Mini DisplayPort one 20-pin port

VGA one 15 hole port

Audio • one stereo headphones/speakers port

• one microphone/speakers port

• one headphones/microphone/speakers

comboport

S/PDIF one S/P DIF port

Media Card Reader one 9-in-1 slot

Audio

Controller Intel High-Definition 5.1 surround sound audio

Speaker dual 8-ohms speakers in both the left and right

speaker assembly

Internal speaker amplifier up to 5 W per channel; up to 10 W total power

Internal microphone

support

dual array digital microphone in camera assembly

Volume controls program menus and keyboard media control keys

Video

Video controller

Integrated • Intel HD Graphics 3000

• Intel HD Graphics 4000

Discrete • NVIDIA GeForce GTX 660M

• NVIDIA GeForce GTX 675M

• AMD Radeon HD 7970M

Video memory

Integrated 512 MB dedicated video memory (for total system

memory greater than 4 GB)

Discrete 2 GB

External display support HDMI 1.4, Mini DisplayPort 1.2, and Intel Wireless

Display (optional)

Media Card Reader

Cards supported • Secure Digital (SD) memory card

• Secure Digital Input/Output (SDIO) card

• Secure Digital Extended Capacity (SDXC) card

• MultiMedia Card (MMC)

• MultiMedia Card plus (MMC+)

• Memory Stick

• Memory Stick PRO

• xD-Picture Card (type - M and type - H)

• Hi Density-SD (SDHD)

• Hi Capacity-SD (SDHC)

Touchpad

X/Y position resolution

(graphics table mode)

742 cpi / 1166 cpi

Size

Height 54 mm (2.13 inches) sensor-active area

Width 100 mm (3.94 inches) rectangle

Backlit keyboard

Number of keys 101 (Korea, U.S., and Canada)

102 (Europe)

104 (Japan)

Backlight color RGB; colors can be changed by invoking the AlienFX

software in the Alienware Command Center

Display

Type • 17.3-inch FHD+ WLED

• 17.3-inch FHD TL 120 Hz WLED with NVIDIA

3Dvisionsupport

• 17.3-inch HD+ WLED

Maximum resolution 1920 x 1080

Dimensions

Height 215 mm (8.46 inches)

Width 382 mm (15.04 inches)

Diagonal 439 mm (17.28 inches)

Refresh rate 60 Hz

Operating angle 0° (closed) to 140°

Pixel pitch 0.2550 mm

Controls brightness can be controlled through keyboard

shortcuts

Camera

Camera resolution 2.1 megapixel

Video resolution 1920 x 1080

Diagonal viewing angle 66 °

AC adapter connector

Type 240 W

Input voltage 100-240 VAC

Input current (maximum) 3.50 A

Input frequency 50-60 Hz

Output current 12.30 A (continuous)

Output power 250 W

Rated output voltage 19.5 VDC

Temperature range

Operating 0° to 40°C (32° to 104°F)

Storage –40° to 70°C (–40° to 158°F)

Connector types

DC connector 3-pin, 7.4 mm plug

AC connector 3-pin – C13 (240 W)

Battery

9-cell “smart” lithium ion (90 Whr)

Height / Width 22 mm (0.87 inches) / 233 mm (9.17 inches)

Depth 90 mm (3.54 inches)

Weight 0.52 kg (1.14 lb)

Voltage 11.10 VDC

Operating time battery operating time varies depending on

operating conditions and can be significantly

reduced under certain power-intensive conditions

Life span (approximate) 300 discharge/charge cycles

Temperature range

Operating 0° to 50°C (32° to 122°F)

Storage –20° to 60°C (–4° to 140°F)

Coin-cell battery CR-2032

Computer environment

Temperature range

Operating 0° to 35°C (32° to 95°F)

Storage –40° to 65°C (–40° to 149°F)

Relative humidity (maximum)

Operating 10% to 90% (non-condensing)

Storage 10% to 95% (non-condensing)

Maximum vibration (using a random vibration spectrum that simulates user

environment)

Operating 0.66 GRMS

Storage 1.3 GRMS

Maximum shock (Measured with hard drive in operating status and a 2-ms

half-sine pulse for operating. Also measured with hard drive in head-parked

position and a 2-ms half-sine pluse for storage)

Operating 110 G

Storage 160 G

Altitude (maximum)

Operating –15.2 to 3048 m (–50 to 10,000 ft)

Storage –15.2 to 10,668 m (–50 to 35,000 ft)

Airborne contaminant

level

G2 or lower as defined by ISA-S71.04-1985
