Dell Chassis Management Controller Version 4 1 Quick Reference Guide 4.1 RACADM Command Line
2014-11-13
: Dell Dell-Chassis-Management-Controller-Version-4-1-Quick-Reference-Guide-118098 dell-chassis-management-controller-version-4-1-quick-reference-guide-118098 dell pdf
Open the PDF directly: View PDF
.
Page Count: 223 [warning: Documents this large are best viewed by clicking the View PDF Link!]
- Contents
- Notes, Cautions, and Warnings
- Introduction
- RACADM Subcommand Details
- Guidelines to Quote Strings Containing Special Characters When Using RACADM Commands
- "?"and "?<subcommand>"
- help and help subcommand
- arp
- chassisaction
- clearasrscreen
- closessn
- clrsel
- cmcchangeover
- config
- connect
- coredump
- coredumpdelete
- deploy
- feature
- featurecard
- fwupdate
- get
- getassettag
- getchassisname
- getconfig
- getdcinfo
- getflexaddr
- getfanreqinfo
- getioinfo
- getkvminfo
- getled
- getmacaddress
- getmodinfo
- getniccfg
- getpbinfo
- getpminfo
- getraclog
- getractime
- getredundancymode
- getsel
- getsensorinfo
- getslotname
- getssninfo
- getsvctag
- getsysinfo
- gettracelog
- getuscversion
- getversion
- hwinventory
- ifconfig
- krbkeytabupload
- lclog
- license
- netstat
- nicstatistics
- ping
- ping6
- racdump
- racreset
- racresetcfg
- raid
- remoteimage
- serveraction
- set
- setassettag
- setchassisname
- setflexaddr
- setled
- setniccfg
- setractime
- setslotname
- setsysinfo
- sshpkauth
- sslcertdownload
- sslcertupload
- sslcertview
- sslcsrgen
- sslkeyupload
- sslresetcfg
- testemail
- testfeature
- testtrap
- traceroute
- traceroute6
- usercertupload
- usercertview
- version
- vflashsd
- vflashpartition
- vmdisconnect
- iDRAC and CMC Property Database Group and Object Descriptions
- Displayable Characters
- idRacInfo
- cfgLanNetworking
- cfgNicIPv4Enable (Read/Write)
- cfgNicSelection (Read/Write)
- cfgNicVLanEnable Read or Write
- cfgNicVLanId (Read/Write)
- cfgNicVLanPriority (Read/Write)
- cfgDNSDomainNameFromDHCP (Read/Write)
- cfgDNSDomainName (Read/Write)
- cfgDNSRacName (Read/Write)
- cfgDNSRegisterRac (Read/Write)
- cfgDNSServersFromDHCP (Read/Write)
- cfgDNSServer1 (Read/Write)
- cfgDNSServer2 (Read/Write)
- cfgNicEnable (Read/Write)
- cfgNicIpAddress (Read/Write)
- cfgNicNetmask (Read/Write)
- cfgNicGateway (Read/Write)
- cfgNicUseDhcp (Read/Write)
- cfgNicMacAddress (Read Only)
- cfgRemoteHosts
- cfgRhostsFwUpdateTftpEnable (Read/Write)
- cfgRhostsFwUpdateIpAddr (Read/Write)
- cfgRhostsFwUpdatePath (Read/Write)
- cfgRhostsSmtpServerIpAddr (Read/Write)
- cfgRhostsNtpEnable
- cfgRhostsNtpServer1
- cfgRhostsNtpServer2
- cfgRhostsNtpServer3
- cfgRhostsNtpMaxDist
- cfgRhostsSyslogEnable (Read/Write)
- cfgRhostsSyslogPort (Read/Write)
- cfgRhostsSyslogServer1 (Read/Write)
- cfgRhostsSyslogServer2 (Read/Write)
- cfgRhostsSyslogServer3 (Read/Write)
- cfgRhostsSyslogPowerLoggingEnabled
- cfgRhostsSyslogPowerLoggingInterval
- cfgUserAdmin
- cfgEmailAlert
- cfgSessionManagement
- cfgSerial
- cfgSerialBaudRate (Read/Write)
- cfgSerialConsoleEnable (Read/Write)
- cfgSerialConsoleQuitKey (Read/Write)
- cfgSerialConsoleIdleTimeout (Read/Write)
- cfgSerialConsoleNoAuth (Read/Write)
- cfgSerialConsoleCommand (Read/Write)
- cfgSerialConsoleColumns
- cfgSerialHistorySize (Read/Write)
- cfgSerialCom2RedirEnable (Read/Write)
- cfgSerialSshEnable (Read/Write)
- cfgSerialTelnetEnable (Read/Write)
- cfgOobSnmp
- cfgTraps
- cfgRacTuning
- cfgRacTuneConRedirPort (Read/Write)
- cfgRacTuneRemoteRacadmEnable (Read/Write)
- cfgRacTuneCtrlEConfigDisable
- cfgRacTuneHttpPort (Read/Write)
- cfgRacTuneHttpsPort (Read/Write)
- cfgRacTuneIpRangeEnable (Read/Write)
- cfgRacTuneIpRangeAddr (Read/Write)
- cfgRacTuneIpRangeMask (Read/Write)
- cfgRacTuneIpBlkEnable (Read/Write)
- cfgRacTuneIpBlkFailCount (Read/Write)
- cfgRacTuneIpBlkFailWindow (Read/Write)
- cfgRacTuneIpBlkPenaltyTime (Read/Write)
- cfgRacTuneSshPort (Read/Write)
- cfgRacTuneTelnetPort (Read/Write)
- cfgRacTuneConRedirEnable (Read/Write)
- cfgRacTuneConRedirEncryptEnable (Read/Write)
- cfgRacTuneAsrEnable (Read/Write)
- cfgRacTuneDaylightOffset (Read Only)
- cfgRacTuneTimezoneOffset (Read Only)
- cfgRacTuneLocalServerVideo (Read/Write)
- cfgRacTuneLocalConfigDisable (Read/Write)
- cfgRacTuneWebserverEnable (Read/Write)
- cfgRacTuneVirtualConsoleAuthorizeMultipleSessions (Read/Write)
- cfgRacTunePluginType (Read/Write)
- ifcRacManagedNodeOs
- cfgRacVirtual
- cfgServerInfo
- cfgServerInfoIndex (Read Only)
- cfgServerSlotNumber (Read Only)
- cfgServerServiceTag (Read Only)
- cfgServerName (Read/Write)
- cfgServerFW (Read Only)
- cfgServerBIOS (Read Only)
- cfgServerBmcMacAddress (Read Only)
- cfgServerNic1MacAddress (Read Only)
- cfgServerNic2MacAddress (Read Only)
- cfgServerNic3MacAddress (Read Only)
- cfgServerNic4MacAddress (Read Only)
- cfgServerPriority (Read/Write)
- cfgServerNicEnable (Read/Write)
- cfgServerIPMIOverLanEnable (Read/Write)
- cfgServerPowerBudgetAllocation (Read Only)
- cfgServerDNSRegisterIMC (Read/Write)
- cfgServerDNSIMCName (Read/Write)
- cfgServerRootPassword (Write Only)
- cfgServerFirstBootDevice (Read/Write)
- cfgServerBootOnce (Read/Write)
- cfgServerPowerConsumption (Read Only)
- cfgActiveDirectory
- cfgADRacDomain (Read/Write)
- cfgADRacName (Read/Write)
- cfgADRootDomain
- cfgADEnable (Read/Write)
- cfgADSCLEnable
- cfgADSSOEnable (Read/Write)
- cfgADDomainController
- cfgADDomainController1 (Read/Write)
- cfgADDomainController2 (Read/Write)
- cfgADDomainController3 (Read/Write)
- cfgADAuthTimeout (Read/Write)
- cfgADType (Read/Write)
- cfgADSpecifyServerEnable
- cfgADGlobalCatalog
- cfgADGlobalCatalog1 (Read/Write)
- cfgADGlobalCatalog2 (Read/Write)
- cfgADGlobalCatalog3 (Read/Write)
- cfgADCertValidationEnable (Read/Write)
- cfgADDcSRVLookupEnable (Read/Write)
- cfgADDcSRVLookupbyUserdomain (Read/Write)
- cfgADDcSRVLookupDomainName (Read/Write)
- cfgADGcSRVLookupEnable (Read/Write)
- cfgADGcRootDomain (Read/Write)
- cfgLDAP
- cfgLdapEnable (Read/Write)
- cfgLdapServer (Read/Write)
- cfgLdapPort (Read/Write)
- cfgLdapBasedn (Read/Write)
- cfgLdapUserAttribute (Read/Write)
- cfgLdapGroupAttribute (Read/Write)
- cfgLdapGroupAttributeIsDN (Read/Write)
- cfgLdapBinddn (Read/Write)
- cfgLdapBindpassword (Write Only)
- cfgLdapSearchFilter (Read/Write)
- cfgLDAPCertValidationEnable (Read/Write)
- cfgLDAPNetworkTimeout
- cfgLDAPSearchTimeout
- cfgLDAPSRVLookupEnable
- cfgLDAPSRVLookupDomainName
- cfgLDAPSRVLookupServiceName (Read/Write)
- cfgLdapRoleGroup
- cfgLocation
- cfgStandardSchema
- cfgChassisPower
- cfgChassisExternalPowerManagementMode
- cfgChassisInPower (Read Only)
- cfgChassisPeakPower (Read Only)
- cfgChassisPeakPowerTimestamp (Read Only)
- cfgChassisMinPower (Read Only)
- cfgChassisMinPowerTimestamp (Read Only)
- cfgChassisPowerStatus (Read Only)
- cfgChassisRedundantState (Read Only)
- cfgChassisPowerCap (Read/Write)
- cfgChassisPowerCapF (Read/Write)
- cfgChassisPowerCapBTU (Read/Write)
- cfgChassisPowerCapFBTU (Read/Write)
- cfgChassisPowerCapPercent (Read/Write)
- cfgChassisPowerCapFPercent (Read/Write)
- cfgChassisRedundancyPolicy (Read/Write)
- cfgChassisDynamicPSUEngagementEnable (Read/Write)
- cfgChassisAllow110VACOperation (Read/Write)
- cfgChassisMaxPowerConservationMode (Read/Write)
- cfgChassisPerformanceOverRedundancy (Read/Write)
- cfgChassisInMaxPowerCapacity (Read Only)
- cfgChassisInRedundancyReserve (Read Only)
- cfgChassisInPowerServerAllocation (Read Only)
- cfgChassisInfrastructureInPowerAllocation (Read Only)
- cfgChassisTotalInPowerAvailable (Read Only)
- cfgChassisStandbyInPowerCapacity (Read Only)
- cfgChassisPowerClear (Write Only)
- cfgChassisPowerClearTimestamp (Read Only)
- cfgChassisPowerButtonEnable (Read/Write)
- cfgSystemEnergyConsumptionClear (Write Only)
- cfgIpmiSol
- cfgIpmiLan
- cfgIpmiPetIpv6
- cfgIpmiPef
- cfgIpmiPet
- cfgUserDomain
- cfgServerPower
- cfgServerPowerStatus (Read Only)
- cfgServerPowerAllocation (Read Only)
- cfgServerActualPowerConsumption (Read Only)
- cfgServerPowerCapEnable (Read/Write)
- cfgServerMinPowerCapacity (Read Only)
- cfgServerMaxPowerCapacity (Read Only)
- cfgServerPeakPowerConsumption (Read Only)
- cfgServerPeakPowerConsumptionTimestamp (Read Only)
- cfgServerPowerConsumptionClear (Write Only)
- cfgServerPowerCapWatts (Read/Write)
- cfgServerPowerCapBtuhr (Read/Write)
- cfgServerPowerCapPercent (Read/Write)
- cfgServerPowerLastHourAvg (Read Only)
- cfgServerPowerLastDayAvg (Read Only)
- cfgServerPowerLastWeekAvg (Read Only)
- cfgServerPowerLastHourMinPower (Read Only)
- cfgServerPowerLastHourMinTime (Read Only)
- cfgServerPowerLastHourMaxPower (Read Only)
- cfgServerPowerLastHourMaxTime (Read Only)
- cfgServerPowerLastDayMinPower (Read Only)
- cfgServerPowerLastDayMinTime (Read Only)
- cfgServerPowerLastDayMaxPower (Read Only)
- cfgServerPowerLastDayMaxTime (Read Only)
- cfgServerPowerLastWeekMinPower (Read Only)
- cfgServerPowerLastWeekMinTime (Read Only)
- cfgServerPowerLastWeekMaxPower (Read Only)
- cfgServerPowerLastWeekMaxTime (Read Only)
- cfgServerPowerInstHeadroom (Read Only)
- cfgServerPowerPeakHeadroom (Read Only)
- cfgServerActualAmperageConsumption (Read Only)
- cfgServerPeakAmperage (Read Only)
- cfgServerPeakAmperageTimeStamp (Read Only)
- cfgServerCumulativePowerConsumption (Read Only)
- cfgServerCumulativePowerConsumptionTimeStamp (Read Only)
- cfgServerCumulativePowerClear (Write Only)
- cfgServerPowerPCIeAllocation (Read/Write)
- cfgKVMInfo
- cfgAlerting
- cfgServerPowerSupply
- cfgIPv6LanNetworking
- cfgIPv6Enable (Read/Write)
- cfgIPv6Address
- cfgIPv6Address1 (Read/Write)
- cfgIPv6Gateway (Read/Write)
- cfgIPv6PrefixLength (Read/Write)
- cfgIPv6AutoConfig (Read/Write)
- cfgIPv6LinkLocalAddress (Read Only)
- cfgIPv6Address2 (Read Only)
- cfgIPv6Address3 (Read Only)
- cfgIPv6Address4 (Read Only)
- cfgIPv6Address5 (Read Only)
- cfgIPv6Address6 (Read Only)
- cfgIPv6Address7 (Read Only)
- cfgIPv6Address8 (Read Only)
- cfgIPv6Address9 (Read Only)
- cfgIPv6Address10 (Read Only)
- cfgIPv6Address11 (Read Only)
- cfgIPv6Address12 (Read Only)
- cfgIPv6Address13 (Read Only)
- cfgIPv6Address14 (Read Only)
- cfgIPv6Address15 (Read Only)
- cfgIPv6DNSServersFromDHCP6 (Read/Write)
- cfgIPv6DNSServer1 (Read/Write)
- cfgIPv6DNSServer2 (Read/Write)
- cfgCurrentLanNetworking (Read Only)
- cfgCurrentIPv6LanNetworking (Read Only)
- cfgIPv6URL
- cfgIpmiSerial
- cfgIpmiSerialBaudRate (Read/Write)
- cfgIpmiSerialConnectionMode (Read/Write)
- cfgIpmiSerialChanPrivLimit (Read/Write)
- cfgIpmiSerialFlowControl (Read/Write)
- cfgIpmiSerialHandshakeControl (Read/Write)
- cfgIpmiSerialLineEdit (Read/Write)
- cfgIpmiSerialEchoControl (Read/Write)
- cfgIpmiSerialDeleteControl (Read/Write)
- cfgIpmiSerialNewLineSequence (Read/Write)
- cfgIpmiSerialInputNewLineSequence (Read/Write)
- cfgSmartCard
- cfgNetTuning
- cfgSensorRedundancy
- cfgVFlashSD
- cfgVFlashPartition
- cfgLogging
- cfgRacSecurity
- Database Objects With Get and Set Commands
- System.Power
- System.Power.Status (Read Only)
- System.Power.ServerAllocation (Read Only)
- System.Power.Cap.MinThreshold (Read Only)
- System.Power.Cap.MaxThreshold (Read Only)
- System.Power.Cap.Enable (Read/Write)
- System.Power.Cap.Watts (Read Only)
- System.Power.Cap.Btuhr (Read/Write)
- System.Power.Hotspare.PrimaryPSU (Read/Write)
- System.Power.Hotspare.Enable (Read/Write)
- System.Power.PFC.Enable (Read/Write)
- System.Power.Max.Power (Read Only)
- System.Power.Max.Amps (Read Only)
- System.Power.Max.Amps.TimeStamp (Read Only)
- System.Power.Max.PowerClear Write Only
- System.Power.Avg.LastHour (Read Only)
- System.Power.Avg.LastDay (Read Only)
- System.Power.Min.LastDay.TimeStamp (Read Only)
- System.Power.Max.LastDay (Read Only)
- System.Power.Max.LastDay.TimeStamp (Read Only)
- System.Power.Avg.LastWeek (Read Only)
- System.Power.Min.LastWeek.TimeStamp (Read Only)
- System.Power.Max.LastWeek (Read Only)
- System.Power.Max.LastWeek.TimeStamp (Read Only)
- System.Power.RedundancyPolicy (Read/Write)
- System.Power.RedundancyCapabilities (Read Only)
- System.Power.RedundantState (Read Only)
- System.Power.Cap.Percent (Read/Write)
- System.Power.EnergyConsumption (Read Only)
- System.Power.EnergyConsumption.Clear Write Only
- System.Power.Max.Headroom Write Only
- System.Power.EnergyConsumption.StarttimeStamp
- System.Power.PCIeAllocation (Read/Write)
- System.Power.Supply
- System.Power.Supply.[i].MaxInputPower (Read Only)
- System.Power.Supply.[i].MaxOutputPower ((Read Only))
- System.Power.Supply.[i].Status (Read Only)
- System.Power.Supply.[i].FwVer (Read Only)
- System.Power.Supply.[i].CurrentDraw (Read Only)
- System.Power.Supply.[i].Type (Read Only)
- System.Power.Supply.[i].LineStatus (Read Only)
- System.Power.Supply.[i].PMBusMonitoring (Read Only)
- System.Location
- LifecycleController.LCAttributes
- System.LCD
- iDRAC.IMC
- System.Power
RACADM Command Line Reference Guide for iDRAC7
1.00.00 and CMC 4.1
Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your computer.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2012 Dell Inc.
Trademarks used in this text: Dell™, the Dell logo, Dell Precision™ , OptiPlex™, Latitude™, PowerEdge™, PowerVault™,
PowerConnect™, OpenManage™, EqualLogic™, Compellent™, KACE™, FlexAddress™, Force10™ and Vostro™ are trademarks of Dell
Inc. Intel®, Pentium®, Xeon®, Core® and Celeron® are registered trademarks of Intel Corporation in the U.S. and other countries. AMD®
is a registered trademark and AMD Opteron™, AMD Phenom™ and AMD Sempron™ are trademarks of Advanced Micro Devices, Inc.
Microsoft®, Windows®, Windows Server®, Internet Explorer®, MS-DOS®, Windows Vista® and Active Directory® are either trademarks
or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat® and Red Hat®
Enterprise Linux® are registered trademarks of Red Hat, Inc. in the United States and/or other countries. Novell® and SUSE® are
registered trademarks of Novell Inc. in the United States and other countries. Oracle® is a registered trademark of Oracle Corporation
and/or its affiliates. Citrix®, Xen®, XenServer® and XenMotion® are either registered trademarks or trademarks of Citrix Systems, Inc. in
the United States and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter® and vSphere® are registered trademarks or
trademarks of VMware, Inc. in the United States or other countries. IBM® is a registered trademark of International Business Machines
Corporation.
2012 - 05
Rev. A00
Contents
Notes, Cautions, and Warnings...................................................................................................2
1 Introduction................................................................................................................................17
Installing Racadm...................................................................................................................................................17
Supported RACADM Interfaces..............................................................................................................................17
RACADM Syntax Usage..........................................................................................................................................17
Local RACADM.................................................................................................................................................17
SSH or Telnet RACADM...................................................................................................................................18
Remote RACADM.............................................................................................................................................18
RACADM Command Options............................................................................................................................18
Supported RACADM Subcommands......................................................................................................................19
Other Documents You May Need...........................................................................................................................22
2 RACADM Subcommand Details..............................................................................................25
Guidelines to Quote Strings Containing Special Characters When Using RACADM Commands..........................25
"?"and "?<subcommand>" .......................................................................................................................................26
help and help subcommand....................................................................................................................................27
arp...........................................................................................................................................................................27
chassisaction..........................................................................................................................................................28
clearasrscreen.......................................................................................................................................................28
closessn..................................................................................................................................................................29
clrsel.......................................................................................................................................................................29
cmcchangeover......................................................................................................................................................30
config......................................................................................................................................................................30
connect...................................................................................................................................................................31
coredump................................................................................................................................................................31
coredumpdelete......................................................................................................................................................32
deploy.....................................................................................................................................................................33
feature.....................................................................................................................................................................34
featurecard.............................................................................................................................................................35
fwupdate.................................................................................................................................................................36
get...........................................................................................................................................................................39
getassettag.............................................................................................................................................................40
getchassisname......................................................................................................................................................40
getconfig.................................................................................................................................................................41
getdcinfo.................................................................................................................................................................42
getflexaddr..............................................................................................................................................................44
getfanreqinfo..........................................................................................................................................................46
getioinfo..................................................................................................................................................................48
getkvminfo..............................................................................................................................................................49
getled......................................................................................................................................................................49
getmacaddress.......................................................................................................................................................50
getmodinfo..............................................................................................................................................................55
getniccfg.................................................................................................................................................................56
getpbinfo.................................................................................................................................................................58
getpminfo................................................................................................................................................................59
getraclog.................................................................................................................................................................60
getractime...............................................................................................................................................................61
getredundancymode...............................................................................................................................................61
getsel......................................................................................................................................................................62
getsensorinfo..........................................................................................................................................................62
getslotname............................................................................................................................................................63
getssninfo...............................................................................................................................................................64
getsvctag................................................................................................................................................................64
getsysinfo................................................................................................................................................................65
gettracelog..............................................................................................................................................................67
getuscversion.........................................................................................................................................................67
getversion...............................................................................................................................................................68
hwinventory............................................................................................................................................................70
ifconfig....................................................................................................................................................................71
krbkeytabupload.....................................................................................................................................................72
lclog........................................................................................................................................................................73
license.....................................................................................................................................................................75
netstat.....................................................................................................................................................................77
nicstatistics.............................................................................................................................................................77
ping.........................................................................................................................................................................78
ping6.......................................................................................................................................................................78
racdump..................................................................................................................................................................79
racreset...................................................................................................................................................................81
racresetcfg.............................................................................................................................................................82
raid..........................................................................................................................................................................83
remoteimage...........................................................................................................................................................85
serveraction............................................................................................................................................................86
set...........................................................................................................................................................................87
setassettag.............................................................................................................................................................87
setchassisname......................................................................................................................................................88
setflexaddr..............................................................................................................................................................88
setled......................................................................................................................................................................89
setniccfg.................................................................................................................................................................90
setractime...............................................................................................................................................................90
setslotname............................................................................................................................................................92
setsysinfo................................................................................................................................................................92
sshpkauth................................................................................................................................................................93
sslcertdownload.....................................................................................................................................................94
sslcertupload..........................................................................................................................................................95
sslcertview..............................................................................................................................................................95
sslcsrgen................................................................................................................................................................97
sslkeyupload...........................................................................................................................................................98
sslresetcfg..............................................................................................................................................................98
testemail.................................................................................................................................................................99
testfeature..............................................................................................................................................................99
testtrap..................................................................................................................................................................102
traceroute.............................................................................................................................................................102
traceroute6...........................................................................................................................................................103
usercertupload.....................................................................................................................................................103
usercertview.........................................................................................................................................................104
version..................................................................................................................................................................104
vflashsd.................................................................................................................................................................104
vflashpartition.......................................................................................................................................................105
vmdisconnect........................................................................................................................................................107
3 iDRAC and CMC Property Database Group and Object Descriptions............................109
Displayable Characters........................................................................................................................................109
idRacInfo...............................................................................................................................................................111
idRacProductInfo (Read Only)........................................................................................................................111
idRacDescriptionInfo (Read Only)..................................................................................................................111
idRacVersionInfo (Read Only)........................................................................................................................111
idRacBuildInfo (Read Only)............................................................................................................................111
idRacName (Read Only).................................................................................................................................111
idRacType (Read Only)...................................................................................................................................112
cfgLanNetworking................................................................................................................................................112
cfgNicIPv4Enable (Read/Write).....................................................................................................................112
cfgNicSelection (Read/Write) .......................................................................................................................113
cfgNicVLanEnable Read or Write..................................................................................................................113
cfgNicVLanId (Read/Write)............................................................................................................................114
cfgNicVLanPriority (Read/Write)....................................................................................................................114
cfgDNSDomainNameFromDHCP (Read/Write)..............................................................................................115
cfgDNSDomainName (Read/Write)...............................................................................................................115
cfgDNSRacName (Read/Write)......................................................................................................................115
cfgDNSRegisterRac (Read/Write)..................................................................................................................116
cfgDNSServersFromDHCP (Read/Write).......................................................................................................117
cfgDNSServer1 (Read/Write).........................................................................................................................117
cfgDNSServer2 (Read/Write).........................................................................................................................117
cfgNicEnable (Read/Write)............................................................................................................................117
cfgNicIpAddress (Read/Write).......................................................................................................................118
cfgNicNetmask (Read/Write).........................................................................................................................118
cfgNicGateway (Read/Write).........................................................................................................................118
cfgNicUseDhcp (Read/Write)........................................................................................................................119
cfgNicMacAddress (Read Only)....................................................................................................................119
cfgRemoteHosts...................................................................................................................................................119
cfgRhostsFwUpdateTftpEnable (Read/Write)................................................................................................119
cfgRhostsFwUpdateIpAddr (Read/Write)......................................................................................................120
cfgRhostsFwUpdatePath (Read/Write)..........................................................................................................120
cfgRhostsSmtpServerIpAddr (Read/Write)....................................................................................................120
cfgRhostsNtpEnable.......................................................................................................................................120
cfgRhostsNtpServer1.....................................................................................................................................120
cfgRhostsNtpServer2.....................................................................................................................................121
cfgRhostsNtpServer3.....................................................................................................................................121
cfgRhostsNtpMaxDist....................................................................................................................................121
cfgRhostsSyslogEnable (Read/Write)............................................................................................................121
cfgRhostsSyslogPort (Read/Write)................................................................................................................122
cfgRhostsSyslogServer1 (Read/Write)...........................................................................................................122
cfgRhostsSyslogServer2 (Read/Write)...........................................................................................................122
cfgRhostsSyslogServer3 (Read/Write)...........................................................................................................122
cfgRhostsSyslogPowerLoggingEnabled........................................................................................................123
cfgRhostsSyslogPowerLoggingInterval.........................................................................................................123
cfgUserAdmin.......................................................................................................................................................123
cfgUserAdminIndex (Read Only)....................................................................................................................124
cfgUserAdminIpmiLanPrivilege (Read/Write)................................................................................................124
cfgUserAdminPrivilege (Read/Write).............................................................................................................124
cfgUserAdminUserName (Read/Write)..........................................................................................................126
cfgUserAdminPassword (Write Only)............................................................................................................126
cfgUserAdminEnable (Read/Write)................................................................................................................126
cfgUserAdminSolEnable (Read/Write)...........................................................................................................127
cfgUserAdminIpmiSerialPrivilege (Read/Write)............................................................................................127
cfgEmailAlert........................................................................................................................................................127
cfgEmailAlertIndex (Read Only).....................................................................................................................127
cfgEmailAlertEnable (Read/Write).................................................................................................................128
cfgEmailAlertAddress (Read/Write)...............................................................................................................128
cfgEmailAlertCustomMsg (Read/Write).........................................................................................................128
cfgEmailAlertEmailName...............................................................................................................................128
cfgSessionManagement.......................................................................................................................................128
cfgSsnMgtRacadmTimeout (Read/Write)......................................................................................................129
cfgSsnMgtConsRedirMaxSessions (Read/Write)..........................................................................................129
cfgSsnMgtWebserverTimeout (Read/Write).................................................................................................129
cfgSsnMgtSshIdleTimeout (Read/Write).......................................................................................................129
cfgSsnMgtTelnetIdleTimeout (Read/Write)...................................................................................................130
cfgSerial................................................................................................................................................................130
cfgSerialBaudRate (Read/Write)....................................................................................................................131
cfgSerialConsoleEnable (Read/Write)...........................................................................................................131
cfgSerialConsoleQuitKey (Read/Write)..........................................................................................................131
cfgSerialConsoleIdleTimeout (Read/Write)...................................................................................................132
cfgSerialConsoleNoAuth (Read/Write)..........................................................................................................132
cfgSerialConsoleCommand (Read/Write)......................................................................................................132
cfgSerialConsoleColumns..............................................................................................................................133
cfgSerialHistorySize (Read/Write).................................................................................................................133
cfgSerialCom2RedirEnable (Read/Write).......................................................................................................133
cfgSerialSshEnable (Read/Write)..................................................................................................................133
cfgSerialTelnetEnable (Read/Write) .............................................................................................................134
cfgOobSnmp.........................................................................................................................................................134
cfgOobSnmpAgentCommunity (Read/Write).................................................................................................134
cfgOobSnmpAgentEnable (Read/Write)........................................................................................................135
cfgTraps................................................................................................................................................................135
cfgTrapsIndex (Read Only).............................................................................................................................135
cfgTrapsEnable..............................................................................................................................................135
cfgTrapsAlertDestIpAddr...............................................................................................................................135
cfgTrapsCommunityName..............................................................................................................................136
cfgRacTuning........................................................................................................................................................136
cfgRacTuneConRedirPort (Read/Write).........................................................................................................136
cfgRacTuneRemoteRacadmEnable (Read/Write)..........................................................................................136
cfgRacTuneCtrlEConfigDisable......................................................................................................................137
cfgRacTuneHttpPort (Read/Write).................................................................................................................137
cfgRacTuneHttpsPort (Read/Write)...............................................................................................................137
cfgRacTuneIpRangeEnable (Read/Write)......................................................................................................137
cfgRacTuneIpRangeAddr (Read/Write).........................................................................................................138
cfgRacTuneIpRangeMask (Read/Write)........................................................................................................138
cfgRacTuneIpBlkEnable (Read/Write)...........................................................................................................138
cfgRacTuneIpBlkFailCount (Read/Write).......................................................................................................138
cfgRacTuneIpBlkFailWindow (Read/Write)...................................................................................................139
cfgRacTuneIpBlkPenaltyTime (Read/Write)..................................................................................................139
cfgRacTuneSshPort (Read/Write)..................................................................................................................139
cfgRacTuneTelnetPort (Read/Write)..............................................................................................................139
cfgRacTuneConRedirEnable (Read/Write).....................................................................................................140
cfgRacTuneConRedirEncryptEnable (Read/Write)........................................................................................140
cfgRacTuneAsrEnable (Read/Write)..............................................................................................................140
cfgRacTuneDaylightOffset (Read Only)..........................................................................................................140
cfgRacTuneTimezoneOffset (Read Only).......................................................................................................141
cfgRacTuneLocalServerVideo (Read/Write)..................................................................................................141
cfgRacTuneLocalConfigDisable (Read/Write)...............................................................................................142
cfgRacTuneWebserverEnable (Read/Write).................................................................................................142
cfgRacTuneVirtualConsoleAuthorizeMultipleSessions (Read/Write)...........................................................142
cfgRacTunePluginType (Read/Write).............................................................................................................143
ifcRacManagedNodeOs.......................................................................................................................................143
ifcRacMnOsHostname (Read Only)................................................................................................................143
ifcRacMnOsOsName (Read Only)..................................................................................................................143
cfgRacVirtual........................................................................................................................................................143
cfgVirMediaAttached (Read/Write)...............................................................................................................144
cfgVirtualBootOnce (Read/Write)..................................................................................................................144
cfgVirMediaFloppyEmulation (Read/Write)....................................................................................................144
cfgSDWriteProtect (Read Only) ....................................................................................................................145
cfgServerInfo........................................................................................................................................................145
cfgServerInfoIndex (Read Only).....................................................................................................................145
cfgServerSlotNumber (Read Only).................................................................................................................145
cfgServerServiceTag (Read Only)..................................................................................................................146
cfgServerName (Read/Write)........................................................................................................................146
cfgServerFW (Read Only)...............................................................................................................................146
cfgServerBIOS (Read Only)............................................................................................................................146
cfgServerBmcMacAddress (Read Only)........................................................................................................146
cfgServerNic1MacAddress (Read Only)........................................................................................................147
cfgServerNic2MacAddress (Read Only)........................................................................................................147
cfgServerNic3MacAddress (Read Only)........................................................................................................147
cfgServerNic4MacAddress (Read Only)........................................................................................................147
cfgServerPriority (Read/Write)......................................................................................................................147
cfgServerNicEnable (Read/Write).................................................................................................................148
cfgServerIPMIOverLanEnable (Read/Write)..................................................................................................148
cfgServerPowerBudgetAllocation (Read Only).............................................................................................148
cfgServerDNSRegisterIMC (Read/Write)......................................................................................................148
cfgServerDNSIMCName (Read/Write)..........................................................................................................149
cfgServerRootPassword (Write Only)............................................................................................................149
cfgServerFirstBootDevice (Read/Write)........................................................................................................149
cfgServerBootOnce (Read/Write)..................................................................................................................150
cfgServerPowerConsumption (Read Only)....................................................................................................150
cfgActiveDirectory................................................................................................................................................151
cfgADRacDomain (Read/Write).....................................................................................................................151
cfgADRacName (Read/Write)........................................................................................................................151
cfgADRootDomain..........................................................................................................................................152
cfgADEnable (Read/Write).............................................................................................................................152
cfgADSCLEnable............................................................................................................................................152
cfgADSSOEnable (Read/Write)......................................................................................................................152
cfgADDomainController.................................................................................................................................153
cfgADDomainController1 (Read/Write)..........................................................................................................153
cfgADDomainController2 (Read/Write)..........................................................................................................153
cfgADDomainController3 (Read/Write)..........................................................................................................153
cfgADAuthTimeout (Read/Write)...................................................................................................................153
cfgADType (Read/Write)................................................................................................................................154
cfgADSpecifyServerEnable............................................................................................................................154
cfgADGlobalCatalog.......................................................................................................................................154
cfgADGlobalCatalog1 (Read/Write)...............................................................................................................155
cfgADGlobalCatalog2 (Read/Write)...............................................................................................................155
cfgADGlobalCatalog3 (Read/Write)...............................................................................................................155
cfgADCertValidationEnable (Read/Write)......................................................................................................155
cfgADDcSRVLookupEnable (Read/Write)......................................................................................................155
cfgADDcSRVLookupbyUserdomain (Read/Write)..........................................................................................156
cfgADDcSRVLookupDomainName (Read/Write)...........................................................................................156
cfgADGcSRVLookupEnable (Read/Write)......................................................................................................156
cfgADGcRootDomain (Read/Write)................................................................................................................157
cfgLDAP................................................................................................................................................................157
cfgLdapEnable (Read/Write)..........................................................................................................................157
cfgLdapServer (Read/Write)..........................................................................................................................157
cfgLdapPort (Read/Write)..............................................................................................................................158
cfgLdapBasedn (Read/Write).........................................................................................................................158
cfgLdapUserAttribute (Read/Write)...............................................................................................................158
cfgLdapGroupAttribute (Read/Write).............................................................................................................158
cfgLdapGroupAttributeIsDN (Read/Write).....................................................................................................159
cfgLdapBinddn (Read/Write)..........................................................................................................................159
cfgLdapBindpassword (Write Only)...............................................................................................................159
cfgLdapSearchFilter (Read/Write).................................................................................................................159
cfgLDAPCertValidationEnable (Read/Write)..................................................................................................160
cfgLDAPNetworkTimeout...............................................................................................................................160
cfgLDAPSearchTimeout.................................................................................................................................160
cfgLDAPSRVLookupEnable............................................................................................................................160
cfgLDAPSRVLookupDomainName.................................................................................................................160
cfgLDAPSRVLookupServiceName (Read/Write)...........................................................................................161
cfgLdapRoleGroup................................................................................................................................................161
cfgLdapRoleGroupIndex (Read Only).............................................................................................................161
cfgLdapRoleGroupDN (Read/Write)...............................................................................................................162
cfgLdapRoleGroupPrivilege (Read/Write)......................................................................................................162
cfgLocation...........................................................................................................................................................162
cfgLocationDatacenter (Read/Write).............................................................................................................162
cfgLocationAisle (Read/Write).......................................................................................................................162
cfgLocationRack (Read/Write).......................................................................................................................163
cfgLocationRackslot (Read/Write).................................................................................................................163
cfgLocationDevicesize (Read Only)...............................................................................................................163
cfgStandardSchema.............................................................................................................................................163
cfgSSADRoleGroupIndex (Read Only)...........................................................................................................163
cfgSSADRoleGroupName (Read/Write).........................................................................................................163
cfgSSADRoleGroupDomain (Read/Write)......................................................................................................164
cfgSSADRoleGroupPrivilege (Read/Write)....................................................................................................164
cfgChassisPower..................................................................................................................................................164
cfgChassisExternalPowerManagementMode...............................................................................................165
cfgChassisInPower (Read Only).....................................................................................................................165
cfgChassisPeakPower (Read Only)................................................................................................................165
cfgChassisPeakPowerTimestamp (Read Only)..............................................................................................165
cfgChassisMinPower (Read Only).................................................................................................................165
cfgChassisMinPowerTimestamp (Read Only)................................................................................................166
cfgChassisPowerStatus (Read Only).............................................................................................................166
cfgChassisRedundantState (Read Only)........................................................................................................166
cfgChassisPowerCap (Read/Write)...............................................................................................................166
cfgChassisPowerCapF (Read/Write)..............................................................................................................166
cfgChassisPowerCapBTU (Read/Write)........................................................................................................167
cfgChassisPowerCapFBTU (Read/Write).......................................................................................................167
cfgChassisPowerCapPercent (Read/Write)...................................................................................................167
cfgChassisPowerCapFPercent (Read/Write).................................................................................................167
cfgChassisRedundancyPolicy (Read/Write)..................................................................................................168
cfgChassisDynamicPSUEngagementEnable (Read/Write)............................................................................168
cfgChassisAllow110VACOperation (Read/Write)...........................................................................................168
cfgChassisMaxPowerConservationMode (Read/Write)................................................................................168
cfgChassisPerformanceOverRedundancy (Read/Write)...............................................................................169
cfgChassisInMaxPowerCapacity (Read Only)...............................................................................................169
cfgChassisInRedundancyReserve (Read Only)..............................................................................................169
cfgChassisInPowerServerAllocation (Read Only).........................................................................................169
cfgChassisInfrastructureInPowerAllocation (Read Only)..............................................................................169
cfgChassisTotalInPowerAvailable (Read Only).............................................................................................170
cfgChassisStandbyInPowerCapacity (Read Only).........................................................................................170
cfgChassisPowerClear (Write Only)...............................................................................................................170
cfgChassisPowerClearTimestamp (Read Only).............................................................................................170
cfgChassisPowerButtonEnable (Read/Write)................................................................................................170
cfgSystemEnergyConsumptionClear (Write Only).........................................................................................170
cfgIpmiSol.............................................................................................................................................................171
cfgIpmiSolEnable (Read/Write)......................................................................................................................171
cfgIpmiSolBaudRate (Read/Write).................................................................................................................172
cfgIpmiSolMinPrivilege (Read/Write)............................................................................................................172
cfgIpmiSolAccumulateInterval (Read/Write).................................................................................................172
cfgIpmiSolSendThreshold (Read/Write)........................................................................................................172
cfgIpmiLan............................................................................................................................................................172
cfgIpmiLanEnable (Read/Write).....................................................................................................................172
cfgIpmiLanPrivLimit (Read/Write)..................................................................................................................173
cfgIpmiLanAlertEnable (Read/Write).............................................................................................................173
cfgIpmiLanEncryptionKey (Read/Write).........................................................................................................173
cfgIpmiLanPetCommunityName (Read/Write)...............................................................................................173
cfgIpmiPetIpv6......................................................................................................................................................173
cfgIpmiPetIPv6Index (Read Only)...................................................................................................................174
cfgIpmiPetIPv6AlertDestIpAddr.....................................................................................................................174
cfgIpmiPetIPv6AlertEnable (Read/Write).......................................................................................................174
cfgIpmiPef.............................................................................................................................................................174
cfgIpmiPefName (Read Only).........................................................................................................................174
cfgIpmiPefIndex (Read/Write)........................................................................................................................174
cfgIpmiPefAction (Read/Write)......................................................................................................................175
cfgIpmiPefEnable (Read/Write)......................................................................................................................175
cfgIpmiPet.............................................................................................................................................................175
cfgIpmiPetIndex (Read Only)..........................................................................................................................175
cfgIpmiPetAlertDestIpAddr (Read/Write)......................................................................................................175
cfgIpmiPetAlertEnable (Read/Write)..............................................................................................................176
cfgUserDomain.....................................................................................................................................................176
cfgUserDomainIndex (Read Only)..................................................................................................................176
cfgUserDomainName (Read Only).................................................................................................................176
cfgServerPower....................................................................................................................................................176
cfgServerPowerStatus (Read Only)...............................................................................................................176
cfgServerPowerAllocation (Read Only).........................................................................................................177
cfgServerActualPowerConsumption (Read Only)..........................................................................................177
cfgServerPowerCapEnable (Read/Write)......................................................................................................177
cfgServerMinPowerCapacity (Read Only).....................................................................................................177
cfgServerMaxPowerCapacity (Read Only)....................................................................................................178
cfgServerPeakPowerConsumption (Read Only)............................................................................................178
cfgServerPeakPowerConsumptionTimestamp (Read Only)...........................................................................178
cfgServerPowerConsumptionClear (Write Only)...........................................................................................178
cfgServerPowerCapWatts (Read/Write)........................................................................................................178
cfgServerPowerCapBtuhr (Read/Write)........................................................................................................179
cfgServerPowerCapPercent (Read/Write)....................................................................................................179
cfgServerPowerLastHourAvg (Read Only).....................................................................................................179
cfgServerPowerLastDayAvg (Read Only)......................................................................................................179
cfgServerPowerLastWeekAvg (Read Only)...................................................................................................179
cfgServerPowerLastHourMinPower (Read Only)..........................................................................................180
cfgServerPowerLastHourMinTime (Read Only).............................................................................................180
cfgServerPowerLastHourMaxPower (Read Only).........................................................................................180
cfgServerPowerLastHourMaxTime (Read Only)............................................................................................180
cfgServerPowerLastDayMinPower (Read Only)............................................................................................181
cfgServerPowerLastDayMinTime (Read Only)..............................................................................................181
cfgServerPowerLastDayMaxPower (Read Only)...........................................................................................181
cfgServerPowerLastDayMaxTime (Read Only).............................................................................................182
cfgServerPowerLastWeekMinPower (Read Only)........................................................................................182
cfgServerPowerLastWeekMinTime (Read Only)...........................................................................................182
cfgServerPowerLastWeekMaxPower (Read Only)........................................................................................183
cfgServerPowerLastWeekMaxTime (Read Only)..........................................................................................183
cfgServerPowerInstHeadroom (Read Only)...................................................................................................183
cfgServerPowerPeakHeadroom (Read Only).................................................................................................183
cfgServerActualAmperageConsumption (Read Only)....................................................................................184
cfgServerPeakAmperage (Read Only)...........................................................................................................184
cfgServerPeakAmperageTimeStamp (Read Only).........................................................................................184
cfgServerCumulativePowerConsumption (Read Only)..................................................................................184
cfgServerCumulativePowerConsumptionTimeStamp (Read Only)................................................................185
cfgServerCumulativePowerClear (Write Only)..............................................................................................185
cfgServerPowerPCIeAllocation (Read/Write)...............................................................................................185
cfgKVMInfo...........................................................................................................................................................185
cfgKVMAccessToCMCEnable........................................................................................................................186
cfgKVMFrontPanelEnable..............................................................................................................................186
cfgAlerting............................................................................................................................................................186
cfgAlertingEnable...........................................................................................................................................186
cfgAlertingFilterMask.....................................................................................................................................186
cfgAlertingSourceEmailName........................................................................................................................187
cfgLcdLocale..................................................................................................................................................187
cfgServerPowerSupply.........................................................................................................................................187
cfgServerPowerSupplyIndex.........................................................................................................................187
cfgServerPowerSupplyMaxInputPower (Read Only)....................................................................................188
cfgServerPowerSupplyMaxOutputPower (Read Only)..................................................................................188
cfgServerPowerSupplyOnlineStatus (Read Only)..........................................................................................188
cfgServerPowerSupplyFwVer (Read Only)....................................................................................................188
cfgServerPowerSupplyCurrentDraw (Read Only)..........................................................................................188
cfgServerPowerSupplyType..........................................................................................................................188
cfgIPv6LanNetworking.........................................................................................................................................189
cfgIPv6Enable (Read/Write)...........................................................................................................................189
cfgIPv6Address..............................................................................................................................................189
cfgIPv6Address1 (Read/Write).......................................................................................................................189
cfgIPv6Gateway (Read/Write)........................................................................................................................189
cfgIPv6PrefixLength (Read/Write).................................................................................................................190
cfgIPv6AutoConfig (Read/Write)....................................................................................................................190
cfgIPv6LinkLocalAddress (Read Only)...........................................................................................................190
cfgIPv6Address2 (Read Only).........................................................................................................................190
cfgIPv6Address3 (Read Only).........................................................................................................................191
cfgIPv6Address4 (Read Only).........................................................................................................................191
cfgIPv6Address5 (Read Only).........................................................................................................................191
cfgIPv6Address6 (Read Only).........................................................................................................................191
cfgIPv6Address7 (Read Only).........................................................................................................................191
cfgIPv6Address8 (Read Only).........................................................................................................................191
cfgIPv6Address9 (Read Only).........................................................................................................................192
cfgIPv6Address10 (Read Only).......................................................................................................................192
cfgIPv6Address11 (Read Only).......................................................................................................................192
cfgIPv6Address12 (Read Only).......................................................................................................................192
cfgIPv6Address13 (Read Only).......................................................................................................................192
cfgIPv6Address14 (Read Only).......................................................................................................................193
cfgIPv6Address15 (Read Only).......................................................................................................................193
cfgIPv6DNSServersFromDHCP6 (Read/Write)...............................................................................................193
cfgIPv6DNSServer1 (Read/Write)..................................................................................................................193
cfgIPv6DNSServer2 (Read/Write)..................................................................................................................193
cfgCurrentLanNetworking (Read Only).................................................................................................................194
cfgNicCurrentIpAddress................................................................................................................................194
cfgNicCurrentNetmask..................................................................................................................................194
cfgNicCurrentGateway..................................................................................................................................194
cfgNicCurrentDhcpWasUsed........................................................................................................................195
cfgNicCurrentVlanEnable (Read Only)...........................................................................................................195
cfgNicCurrentVlanID (Read Only)..................................................................................................................195
cfgNicCurrentVlanPriority (Read Only)..........................................................................................................195
cfgDNSCurrentServer1..................................................................................................................................195
cfgDNSCurrentServer2..................................................................................................................................195
cfgDNSCurrentDomainName.........................................................................................................................196
cfgNicCurrentIPv4Enabled.............................................................................................................................196
cfgCurrentIPv6LanNetworking (Read Only)..........................................................................................................196
cfgCurrentIPv6Enabled..................................................................................................................................196
cfgCurrentIPv6AutoConfigWasUsed..............................................................................................................197
cfgCurrentLinkLocalAddress..........................................................................................................................197
cfgCurrentIPv6Address1................................................................................................................................197
cfgCurrentIPv6Gateway ................................................................................................................................197
cfgCurrentIPv6DNSServersFromDHCP6 .......................................................................................................197
cfgCurrentIPv6DNSServer1...........................................................................................................................197
cfgCurrentIPv6DNSServer2...........................................................................................................................198
cfgIPv6URL............................................................................................................................................................198
cfgIPv6URLstring (Read Only)........................................................................................................................198
cfgIpmiSerial.........................................................................................................................................................198
cfgIpmiSerialBaudRate (Read/Write).............................................................................................................198
cfgIpmiSerialConnectionMode (Read/Write).................................................................................................199
cfgIpmiSerialChanPrivLimit (Read/Write)......................................................................................................199
cfgIpmiSerialFlowControl (Read/Write).........................................................................................................199
cfgIpmiSerialHandshakeControl (Read/Write)...............................................................................................199
cfgIpmiSerialLineEdit (Read/Write)................................................................................................................200
cfgIpmiSerialEchoControl (Read/Write).........................................................................................................200
cfgIpmiSerialDeleteControl (Read/Write)......................................................................................................200
cfgIpmiSerialNewLineSequence (Read/Write)..............................................................................................200
cfgIpmiSerialInputNewLineSequence (Read/Write).....................................................................................201
cfgSmartCard........................................................................................................................................................201
cfgSmartCardLogonEnable (Read/Write).......................................................................................................201
cfgSmartCardCRLEnable (Read/Write)..........................................................................................................201
cfgNetTuning........................................................................................................................................................201
cfgNetTuningNicSpeed..................................................................................................................................202
cfgNetTuningNicAutoneg (Read/Write).........................................................................................................202
cfgNetTuningNic100MB (Read/Write)...........................................................................................................202
cfgNetTuningNicFullDuplex (Read/Write)......................................................................................................202
cfgNetTuningNicMtu (Read/Write)................................................................................................................203
cfgSensorRedundancy.........................................................................................................................................203
cfgSensorRedundancyIndex (Read Only)......................................................................................................203
cfgSensorRedundancyPolicy (Read/Write)...................................................................................................203
cfgSensorRedundancyCapabilities (Read Only)............................................................................................204
cfgSensorRedundancyStatus (Read Only).....................................................................................................204
cfgVFlashSD..........................................................................................................................................................204
cfgVFlashSDEnable (Read/Write)..................................................................................................................205
cfgVFlashSDSize (Read Only).........................................................................................................................205
cfgVFlashSDLicensed (Read Only).................................................................................................................205
cfgVFlashSDAvailableSize (Read Only)..........................................................................................................205
cfgVFlashSDHealth (Read Only).....................................................................................................................205
cfgVFlashSDWriteProtect (Read Only)...........................................................................................................206
cfgVFlashPartition.................................................................................................................................................206
cfgVFlashPartitionIndex ReadOnly.................................................................................................................206
cfgVFlashPartitionSize ReadOnly...................................................................................................................206
cfgVFlashPartitionEmulationType (Read/Write).............................................................................................206
cfgVFlashPartitionOSVolLabel ReadOnly.......................................................................................................207
cfgVFlashPartitionFormatType (ReadOnly)....................................................................................................207
cfgVFlashPartitionAccessType (Read/Write)................................................................................................207
cfgVFlashPartitionAttachState (Read/Write).................................................................................................207
cfgLogging............................................................................................................................................................208
cfgLoggingSELOEMEventFilterEnable (Read/Write)......................................................................................208
cfgRacSecurity.....................................................................................................................................................208
cfgRacSecCsrCommonName (Read/Write)...................................................................................................208
cfgRacSecCsrOrganizationName (Read/Write).............................................................................................208
cfgRacSecCsrOrganizationUnit (Read/Write)................................................................................................208
cfgRacSecCsrLocalityName (Read/Write).....................................................................................................209
cfgRacSecCsrStateName (Read/Write).........................................................................................................209
cfgRacSecCsrCountryCode (Read/Write)......................................................................................................209
cfgRacSecCsrEmailAddr (Read/Write)..........................................................................................................209
cfgRacSecCsrKeySize (Read/Write)..............................................................................................................209
4 Database Objects With Get and Set Commands...............................................................211
System.Power.......................................................................................................................................................211
System.Power.Status (Read Only).................................................................................................................211
System.Power.ServerAllocation (Read Only).................................................................................................211
System.Power.Cap.MinThreshold (Read Only)..............................................................................................211
System.Power.Cap.MaxThreshold (Read Only).............................................................................................211
System.Power.Cap.Enable (Read/Write)........................................................................................................212
System.Power.Cap.Watts (Read Only)...........................................................................................................212
System.Power.Cap.Btuhr (Read/Write)..........................................................................................................212
System.Power.Hotspare.PrimaryPSU (Read/Write)......................................................................................212
System.Power.Hotspare.Enable (Read/Write)...............................................................................................213
System.Power.PFC.Enable (Read/Write)........................................................................................................213
System.Power.Max.Power (Read Only).........................................................................................................213
System.Power.Max.Amps (Read Only)...........................................................................................................213
System.Power.Max.Amps.TimeStamp (Read Only).......................................................................................213
System.Power.Max.PowerClear Write Only..................................................................................................214
System.Power.Avg.LastHour (Read Only)......................................................................................................214
System.Power.Avg.LastDay (Read Only)........................................................................................................214
System.Power.Min.LastDay.TimeStamp (Read Only)....................................................................................214
System.Power.Max.LastDay (Read Only).......................................................................................................214
System.Power.Max.LastDay.TimeStamp (Read Only)....................................................................................215
System.Power.Avg.LastWeek (Read Only)....................................................................................................215
System.Power.Min.LastWeek.TimeStamp (Read Only).................................................................................215
System.Power.Max.LastWeek (Read Only)....................................................................................................215
System.Power.Max.LastWeek.TimeStamp (Read Only)................................................................................216
System.Power.RedundancyPolicy (Read/Write)............................................................................................216
System.Power.RedundancyCapabilities (Read Only).....................................................................................216
System.Power.RedundantState (Read Only)..................................................................................................217
System.Power.Cap.Percent (Read/Write)......................................................................................................217
System.Power.EnergyConsumption (Read Only)...........................................................................................217
System.Power.EnergyConsumption.Clear Write Only....................................................................................217
System.Power.Max.Headroom Write Only....................................................................................................218
System.Power.EnergyConsumption.StarttimeStamp.....................................................................................218
System.Power.PCIeAllocation (Read/Write)..................................................................................................218
System.Power.Supply...........................................................................................................................................218
System.Power.Supply.[i].MaxInputPower (Read Only)..................................................................................219
System.Power.Supply.[i].MaxOutputPower ((Read Only)).............................................................................219
System.Power.Supply.[i].Status (Read Only)..................................................................................................219
System.Power.Supply.[i].FwVer (Read Only)..................................................................................................219
System.Power.Supply.[i].CurrentDraw (Read Only).......................................................................................219
System.Power.Supply.[i].Type (Read Only)....................................................................................................219
System.Power.Supply.[i].LineStatus (Read Only)...........................................................................................220
System.Power.Supply.[i].PMBusMonitoring (Read Only)..............................................................................220
System.Location...................................................................................................................................................220
System.Location.DataCenter (Read/Write)....................................................................................................220
System.Location.Aisle (Read/Write)..............................................................................................................220
System.Location.Rack.Name (Read/Write)....................................................................................................220
System.Location.Rack.Slot (Read/Write).......................................................................................................221
System.Location.DeviceSize (Read Only)......................................................................................................221
System.Location.Chassis.Name Read or Write.............................................................................................221
System.Location.Chassis.Slot Read Only.......................................................................................................221
LifecycleController.LCAttributes...........................................................................................................................221
LifecycleController.LCAttributes.CollectSystemInventoryOnRestart (Read/Write).......................................221
LifecycleController.LCAttributes.LifecycleControllerState (Read/Write)......................................................222
LifecycleController.LCAttributes.PartFirmwareUpdate (Read/Write)............................................................222
LifecycleController.LCAttributes.PartConfigurationUpdate (Read/Write).....................................................222
System.LCD...........................................................................................................................................................222
System.LCD. LCDUserString (Read/Write).....................................................................................................222
iDRAC.IMC............................................................................................................................................................223
iDRAC.IMC.AdministrativeState (Read/Write)...............................................................................................223
1
Introduction
This document provides information about the RACADM subcommands, supported RACADM interfaces, and property
database groups and object definitions for the following:
• iDRAC Enterprise or Express for Blade Servers
• iDRAC Enterprise or Express on Rack and Tower Servers
• Dell Chassis System (CMC)
Installing Racadm
For information on installing and unistalling RACADM, see the
Dell OpenManage Server Administrator Installation Guide
at support.dell.com/manuals.
Supported RACADM Interfaces
The RACADM command-line utility provides a scriptable interface that allows you to locally or remotely configure your
Remote Access Controller (RAC). The utility runs on the management station and the managed system. It is available on
the
Dell OpenManage Systems Management and Documentation
DVD or at support.dell.com.
The RACADM utility supports the following interfaces:
• Local — Supports executing RACADM commands from the managed server’s operating system. You must install
the OpenManage software on the managed server to run local RACADM commands. Only one instance of Local
RACADM can be executed on a system at a time. If the user tries to open another instance, an error message is
displayed and the second instance of Local RACADM closes immediately.
• SSH or Telnet — Also referred as Firmware racadm. Firmware RACADM is accessible by logging in to iDRAC7
using SSH or telnet. You do not have to specify the iDRAC7 IP, user name or password to run Firmware RACADM
commands. Similar to Local RACADM, after you enter the RACADM promt, directly run the commands without
the RACADM prefix.
• Remote — Supports executing RACADM commands from a remote management station such as a laptop or
desktop. You must install the DRAC Tools utility from the OpenManage software on the remote computer to run
Remote RACADM commands. To execute Remote RACADM commands, you must formulate the command like a
Local or SSH/Telnet RACADM command except that you must also use the –r –i options or the –r –u –p options.
For more information on these options, see the "RACADM Subcommand Details."
RACADM Syntax Usage
The following section describes the syntax usage for Local, SSH/Telnet, and Remote RACADM.
Local RACADM
racadm getconfig -g <groupname> [-o <objectname>]
[-i <indexnumber>]
racadm <subcommand>
17
Example
racadm getconfig -g idracinfo
racadm getsysinfo
SSH or Telnet RACADM
racadm getconfig -g <groupname> [-o <objectname>]
[-i <indexnumber>]
racadm <subcommand>
Example
racadm getconfig -g idracinfo
racadm getsysinfo
Remote RACADM
racadm -r -u -p getconfig -g <groupname> [-o
<objectname>] [-i <indexnumber>]
racadm -r -u -p <subcommand>
Example
racadm -r -u -p getconfig -g idracinfo
racadm -r -u -p getsysinfo
RACADM Command Options
Table 1‑1 lists the options for the RACADM command.
Option Description
-r
<racIpAddr>
-r
racIpAddr
:
<port number>
Specifies the controller’s remote IP address.
Use:
<port number>
if the iDRAC port number is not the
default port (443)
-u
<usrName>
Specifies the user name that is used to authenticate the
command transaction. If the -u option is used, the -p
option must be used, and the -i option (interactive) is not
allowed.
-p
<password>
Specifies the password used to authenticate the
command transaction. If the -p option is used, the -i option
is not allowed.
-S Specifies that RACADM should check for invalid
certificate errors. RACADM stops the execution of the
command with an error message if it detects an invalid
certificate.
-i
<indexnumber>
Specifies the index number for the indexed group, if
applicable.
-g
<groupname>
Specifies the group name if applicable.
18
Option Description
-o
objectname
Specifies the object name if applicable.
The following table provides the supported RACADM interfaces for iDRAC Enterprise and iDRAC Express.
iDRAC Type Local RACADM SSH/Telnet RACADM Remote RACADM
iDRAC Enterprise Yes Yes Yes
iDRAC Express Yes Yes Yes
CMC No Yes Yes
NOTE: Multiple instances of remote RACADM can be executed on a management station, while only one instance
of local RACADM can be executed on a managed node.
Supported RACADM Subcommands
The following table provides the list of RACADM subcommands and their corresponding interface support. For detailed
information of the RACADM subcommands including syntax and valid entries, see RACADM Subcommand Details.
Subcomma
nd iDRAC on Blade Servers iDRAC on Rack and Tower Servers CMC
Telnet/SSH
/Serial
Local
RACADM
Remote
RACAD
M
Telnet/SSH
/Serial
Local
RACADM
Remote
RACADM
Telnet/SSH/
Serial
Remote
RACADM
"?" and "?
<subcomma
nd>
"
No No No No No No Yes Yes
arp Yes Yes Yes Yes Yes Yes Yes Yes
chassisacti
on
No No No No No No Yes Yes
clearasrscr
een
Yes Yes Yes Yes Yes Yes No No
closessn Yes Yes Yes Yes Yes Yes Yes Yes
clrsel Yes Yes Yes Yes Yes Yes Yes Yes
cmcchange
over
No No No No No No Yes Yes
config Yes Yes Yes Yes Yes Yes Yes Yes
connect No No No No No No Yes Yes
coredump Yes Yes Yes Yes Yes Yes No No
coredumpd
elete
Yes Yes Yes Yes Yes Yes No No
deploy No No No No No Yes Yes Yes
feature No No No No No No Yes Yes
19
Subcomma
nd iDRAC on Blade Servers iDRAC on Rack and Tower Servers CMC
featurecard No No No No No No Yes Yes
fwupdate Yes Yes Yes Yes Yes Yes Yes Yes
get Yes Yes Yes Yes Yes Yes No No
getassettag No No No No No No Yes Yes
getchassisn
ame
No No No No No No Yes Yes
getconfig Yes Yes Yes Yes Yes Yes Yes Yes
getdcinfo No No No No No No Yes Yes
getfanreqinf
o
No No No No No No Yes Yes
getflexaddr No No No No No No Yes Yes
getioinfo No No No No No No Yes Yes
getkvminfo No No No No No No Yes Yes
getled Yes Yes Yes Yes Yes Yes Yes Yes
getmacaddr
ess
No No No No No No Yes Yes
getmodinfo No No No No No No Yes Yes
getniccfg Yes Yes Yes Yes Yes Yes Yes Yes
getpbinfo No No No No No No Yes Yes
getpminfo No No No No No No Yes Yes
getraclog Yes Yes Yes Yes Yes Yes Yes Yes
getractime Yes Yes Yes Yes Yes Yes Yes Yes
getredunda
ncymode
No No No No No No Yes Yes
getsel Yes Yes Yes Yes Yes Yes Yes Yes
getsensorin
fo
Yes Yes Yes Yes Yes Yes Yes Yes
getslotnam
e
No No No No No No Yes Yes
getssninfo Yes Yes Yes Yes Yes Yes Yes Yes
getsvctag Yes Yes Yes Yes Yes Yes Yes Yes
getsysinfo Yes Yes Yes Yes Yes Yes Yes Yes
gettracelog Yes Yes Yes Yes Yes Yes Yes Yes
getversion Yes Yes Yes Yes Yes Yes Yes Yes
20
Subcomma
nd iDRAC on Blade Servers iDRAC on Rack and Tower Servers CMC
getuscversi
on
Yes Yes Yes Yes Yes Yes No No
"help" and
"help
<
subcomma
nd
>
Yes Yes Yes Yes Yes Yes Yes Yes
hwinventor
y
Yes Yes Yes Yes Yes Yes No No
ifconfig Yes Yes Yes Yes Yes Yes Yes Yes
krbkeytabu
pload
Yes Yes Yes Yes Yes Yes No Yes
lclog Yes Yes Yes Yes Yes Yes No No
license Yes Yes Yes Yes Yes Yes No No
netstat Yes Yes Yes Yes Yes Yes Yes Yes
nicstatistics Yes Yes Yes Yes Yes Yes No No
ping Yes Yes Yes Yes Yes Yes Yes Yes
ping6 Yes Yes Yes Yes Yes Yes Yes Yes
racdump Yes No Yes Yes Yes Yes Yes Yes
racreset Yes Yes Yes Yes Yes Yes Yes Yes
racresetcfg Yes Yes Yes Yes Yes Yes Yes Yes
remoteimag
e
Yes Yes Yes Yes Yes Yes Yes Yes
serveractio
n
Yes Yes Yes Yes Yes Yes Yes Yes
set Yes Yes Yes Yes Yes Yes No No
setassettag No No No No No No Yes Yes
setchassisn
ame
No No No No No No Yes Yes
setflexaddr No No No No No No Yes Yes
setled Yes Yes Yes Yes Yes Yes Yes Yes
setniccfg Yes Yes Yes Yes Yes Yes Yes Yes
setractime No No No No No No Yes Yes
setslotname No No No No No No Yes Yes
setsysinfo No No No No No No Yes Yes
sshpkauth Yes Yes Yes Yes Yes Yes Yes Yes
21
Subcomma
nd iDRAC on Blade Servers iDRAC on Rack and Tower Servers CMC
sslcertdow
nload
No Yes Yes No Yes Yes No Yes
sslcertuplo
ad
No Yes Yes No Yes Yes No Yes
sslcertview Yes Yes Yes Yes Yes Yes Yes Yes
sslcsrgen Yes Yes Yes Yes Yes Yes Yes Yes
sslkeyuploa
d
No Yes Yes No Yes Yes No No
sslresetcfg Yes Yes Yes Yes Yes Yes Yes Yes
testemail Yes Yes Yes Yes Yes Yes Yes Yes
testfeature No No No No No No Yes Yes
testtrap Yes Yes Yes Yes Yes Yes Yes Yes
traceroute Yes Yes Yes Yes Yes Yes Yes Yes
traceroute6 Yes Yes Yes Yes Yes Yes Yes Yes
usercertupl
oad No Yes Yes No Yes Yes No No
usercertvie
wYes Yes Yes Yes Yes Yes No No
version No Yes Yes No Yes Yes No No
vflashsd Yes Yes Yes Yes Yes Yes No No
vflashpartiti
on Yes Yes Yes Yes Yes Yes No No
vmdisconne
ct Yes Yes Yes Yes Yes Yes No No
Other Documents You May Need
In addition to this guide, you can access the following guides available on the Dell Support website at support.dell.com/
manuals. On the Manuals page, click Software → Systems Management . Click on the appropriate product link on the
right-side to access the documents.
• The
Integrated Dell Remote Access Controller 7 (iDRAC) Enterprise for Blade Servers User Guide
provides
information about configuring and using an iDRAC for blade servers to remotely manage and monitor your
system and its shared resources through a network.
• The
Integrated Dell Remote Access Controller 7 (iDRAC) User Guide
provides complete information about
configuring and using an iDRAC for rack and tower servers to remotely manage and monitor your system and its
shared resources through a network.
• The
Chassis Management Controller Online Help
provides information about using the CMC Web interface.
• The
Chassis System (CMC) Secure Digital (SD) Card Technical Specification
provides minimum BIOS and
firmware version, installation and usage information.
• The
Dell OpenManage IT Assistant User’s Guide
provides information about IT Assistant.
• Documentation specific to your third-party management console application.
22
• The
Dell OpenManage Server Administrator’s User’s Guide
provides information about installing and using Dell
OpenManage Server Administrator.
• The
Dell Update Packages User's Guide
provides information about obtaining and using Dell Update Packages
as part of your system update strategy.
• The
Glossary
provides information about the terms used in this document.
The following system documents are also available to provide more information about the system in which CMC is
installed:
• The
Rack Installation Guide
and
Rack Installation Instructions
included with your rack solution describe how to
install your system into a rack.
• The
Hardware Owner’s Manual
provides information about system features and describes how to troubleshoot
the system and install or replace system components.
• Documentation for any components you purchased separately provides information to configure and install
these options.
• Release notes or readme files may be included to provide last-minute updates to the system or documentation
or advanced technical reference material intended for experienced users or technicians.
• For more information on IOM network settings, see the
Dell PowerConnect M6220 Switch Important Information
document and the
Dell PowerConnect 6220 Series Port Aggregator White Paper
.
Updates are sometimes included with the system to describe changes to the system, software, and/or documentation.
Always read the updates first because they often supersede information in other documents.
See the
Safety and Regulatory
information that is shipped with your system.
NOTE: Warranty information may be included within this document or as a separate document.
23
24
2
RACADM Subcommand Details
This section provides detailed descriptions of the RACADM subcommands including the syntax and valid entries.
Guidelines to Quote Strings Containing Special Characters When
Using RACADM Commands
When using strings that contain special characters, use the following guidelines:
Strings containing the following special characters must be quoted using single quotes or double quotes:
• $ (dollar sign)
• " (double quote)
• ' (single quote)
• ` (back quote)
• \ (backslash)
• ~ (tilde)
• ; (semicolon)
• | (vertical bar)
• ( (left parentheses)
• ) (right parentheses)
• & (ampersand)
• > (greater than)
• < (less than)
• # (pound)
• ASCII code 32 (space)
NOTE: The - (dash) character cannot be the first character of the string, regardless of whether the string is quoted.
There are different escaping rules for single quoting versus double quoting.
For double quoting:
The following characters must be escaped by prepending a backslash:
• $ (dollar sign)
• " (double quote)
• ' (single quote)
• ` (back quote)
• \ (backslash)
For example, use the following for a string that contains the special characters, $, ",',`and \
For single quoting:
• No character escaping is necessary.
25
• A single quote cannot be used even with a backslash escaped.
NOTE: An empty string may be specified as either "" (using double quotes) or '' (using single quotes).
"?"and "?<subcommand>"
Description Displays all the subcommands you can use with the RACADM command and a one-line
description of each subcommand.
? followed by <
subcommand
> displays the syntax for the specified command.
To use this subcommand, you must have CMC Login User privilege.
You can also use the help and help <
subcommand
> commands to obtain the same
information.
This subcommand is applicable only for CMC.
Synopsis racadm ?
racadm ? <subcommand>
Input NA
Output NA
Example for RACADM ?
The following output example shows only part of the actual output for the racadm ? command. Descriptions shown in
this example may vary slightly from the descriptions in your racadm session.
racadm ?
help -- list racadm subcommand description
help <subcommand> -- display usage summary for a subcommand
? -- list racadm subcommand description
? <subcommand> -- display usage summary for a subcommand
arp -- display the networking arp table
chassisaction -- execute chassis or switch power-up/down/cycle or
KVM powercycle
clrraclog -- clear the CMC log
clrsel -- clear the System Event Log (SEL)
cmcchangeover -- Changes the redundant state of the CMC from active
to standby and vice versa
config -- modify CMC configuration properties
...
setniccfg -- modify network configuration properties
setractime -- set the time on the CMC
setslotname -- sets the name of the slot in the chassis
setsysinfo -- set the chassis name and chassis location
sslcertview -- display a CA/server certificate in the CMC
sslcsrgen -- generate a certificate CSR from the CMC
testemail -- test CMC e-mail notifications
testfeature -- test CMC feature x
testtrap -- test CMC SNMP trap notifications
traceroute -- determine the route of a packet
traceroute6 -- determine the route of a packet
Example for RACADM ? <
subcommand
>
racadm ? getsysinfo
getsysinfo -- display general CMC and system information
Usage:
racadm getsysinfo [-d] [-c] [-A] [-4] [-6]
-----------------------------------------------------------
Valid Options:
26
-d : show CMC information
-c : show chassis information
-A : do not show headers or labels
-4 : show CMC IPv4 information
-6 : show CMC IPv6 information
help and help subcommand
Description Lists all the subcommands available to use with RACADM and provides a short description for each.
You may also type a subcommand, group, object, or FQDD alias after help, to get the syntax for the
specified keyword.
Synopsis •racadm help
•racadm help <subcommand>
•racadm help -g <groupname>
•racadm help -o <objectname>
•racadm help <keyword>
•racadm help <FQDD Alias>.<Group>
•racadm help <FQDD Alias>.<Object>
•racadm help <FQDD Alias>.<Group>.<Object>
Input None
Output • The help command displays a complete list of subcommands.
• The racadm help <
subcommand
> command displays information for the specified
subcommand only.
• The racadm help -g <
groupname
> command displays information for the specified group.
• The racadm help -o <
objectname
> command displays information for the specified object.
• The racadm help <
keyword
> command displays information for the specified keyword.
• The racadm help <
FQDD Alias
>.<
Group
>command displays information for the specified
group.
• The racadm help <
FQDD Alias
>.<
Object
> command displays information for the specified
object.
• The racadm help <
FQDD Alias
>.<
Group
>.<
Object
> command displays information for the
specified object.
Example racadm help idrac.lcd
racadm help system.power
racadm help system.power.supply
arp
Description Displays the contents of the Address Resolution Protocol
(ARP) table. ARP table entries cannot be added or deleted.
To use this subcommand, you must have Administrator
and Execute Diagnostic Commands permission.
Synopsis racadm arp
Input None
Example None
27
Output
IP Address HW Type Flags HW Address Mask Device
192.168.1.1 0x1 0x2 00:00:0C:07:AC:0F * eth0
chassisaction
Description Executes a power action on the chassis, iKVM, or a
server.
To use this subcommand, you must have Chassis Control
Administrator privilege
Synopsis racadm chassisaction [-m <module>]
<action>
Input • -m <
module
> — Module on which you want to
carry out the action. Values are:
— chassis - this is the default value if -m is not specified.
— switch-n where n=1–6
— kvm
• <
action
> — Action that you want to execute on
the specified module. Values are:
— powerdown — (Chassis only) Powers down the
chassis.
— powerup — (Chassis only) Powers up the chassis.
— powercycle — Power cycles the module.
— nongraceshutdown — (Chassis only) Shuts down the
chassis non-gracefully.
— reset — Performs a hard reset of the module.
When <
module
> = kvm or switch, <
action
> must be
powercycle or reset.
Output None
Example Perform a reset of switch-3:
racadm chassisaction -m switch-3 reset
Module power operation successful.
clearasrscreen
Description Clears the last crash (ASR) screen that is in memory.
For more information, see "
Enabling Last Crash Screen
"
section in the
iDRAC7 User’s Guide
.
This subcommand is not applicable to CMC.
NOTE: To use this subcommand, you must have Clear
Logs permission.
Synopsis racadm clearasrscreen
28
Input None
Output None
Example None
closessn
Description Closes a communication session on the device. Use
getssninfo to view a list of sessions that can be closed
using this command.
To use this subcommand, you must have Administrator
permission.
Synopsis •racadm closessn –i <session id>
•racadm closessn -a
•racadm closessn -u <username>
Input •-i<
session id
> — The session ID of the session to
close, which can be retrieved using racadm
getssninfo subcommand.
Session executing this command cannot be
closed.
•-a — Closes all sessions.
•-u
<user name>
— Close all sessions for a
particular user name.
-u option can be used in local RACADM only if the
username contains upto 16 characters. If the user
name contains more than 16 characters, use one
of the following options to close a session:
— Local RACADM: -i option
— Remote RACADM: -u option or -i option
Output None
Example •racadm closessn -i 1234
Closes the session 1234.
•racadm closessn –u root
Closes all the sessions for root user.
•racadm closessn –a
Closes all the sessions.
clrsel
Description Removes all existing records from the System Event Log (SEL).
To use this subcommand, you must have Clear Logs permission.
Synopsis racadm clrsel
29
cmcchangeover
Description Changes the state of the CMC from active to standby, or
vice versa, in a redundant CMC configuration. This
subcommand is useful for remote debugging or testing
purposes.
To use this subcommand, you must have Administrator
privilege.
NOTE: This command is valid only in redundant CMC
environments. For more information, see the
"Understanding the Redundant CMC Environment"
section of the
Dell Chassis System User Guide
.
Synopsis racadm cmcchangeover
Input None
Output CMC failover initiated successfully.
Example None
config
Description Allows you to set iDRAC configuration parameters individually or to batch them as part of a
configuration file. If the data is different, that iDRAC object is written with the new value.
Synopsis racadm config [-c|-p] -f <filename>
racadm config -g <groupName> -o <objectName> [-i
<index>] <Value>
NOTE: The configuration file retrieved using remote racadm and local racadm are not
interoperable. For the config -f <
file name
> command, use the configuration file retrieved from
the same interface. For example, for local racadm config -f <
file name
>, use the file generated
from the local racadm command getconfig -f <
file name
>.
Input NOTE: The -f and -p options are not supported for the serial/Telnet/ssh console.
•-f — The -f <
filename
> option causes config to read the contents of the file specified by
<
filename
> and configure iDRAC. The file must contain data in the format specified in the
section Parsing Rules in the
iDRAC User’s Guide
available at support.dell.com/manuals.
•-p— This option must be used with the -f option. It directs config to delete the password
entries contained in the config file -f <
filename
> after the configuration is complete.
To apply the password you must remove the preceding Read-Only marker '#' in the config
file before executing the config -f command.
•-g— The -g <
groupName
>, or group option, must be used with the -o option. The
<
groupName
> specifies the group containing the object that is to be set.
•-o — The -o <
objectName
> <
Value
>, or object option, must be used with the -g option. This
option specifies the object name that is written with the string <
value
>.
•-i — The -i <
index
>, or index option, is valid only for indexed groups and can be used to
specify a unique group. The <
index
> is a decimal integer from 1 through n, where n can
vary from 1 to maximum number of indexes a particular group supports. If -i <
index
> is not
specified, a value of 1 is assumed for groups, which are tables that have multiple entries.
The index is specified by the index value, not a named value.
30
•-c — The -c, or check option, is used with the config subcommand and allows the user to
parse the .cfg file to locate syntax errors. If errors are found, the line number and a short
description of what is incorrect are displayed. Write permission does not apply to iDRAC.
This option is a check only.
Output This subcommand generates error output for any of the following reasons:
• Invalid syntax, group name, object name, index, or other invalid database members.
• RACADM CLI failures.
This subcommand returns an indication of the number of configuration objects that were written
out of the total objects in the .cfg file.
Examples • racadm config -g cfgLanNetworking -o cfgNicIpAddress 10.35.10.100
Sets the cfgNicIpAddress configuration parameter (object) to the value 10.35.10.110. This IP
address object is contained in the group cfgLanNetworking.
• racadm config -f myrac.cfg
Configures or reconfigures iDRAC. The myrac.cfg file may be created from the getconfig
command. This file may also be edited manually as long as the parsing rules are followed.
NOTE: The myrac.cfg file does not contain passwords. To include passwords in the file, you
must enter them manually. If you want to remove password information from the myrac.cfg file
during configuration, use the -p option.
connect
Description Connects to the switch or server serial console.
Synopsis •racadm connect [-b] <server-n>
•racadm connect [-b] <switch-n>
Input -b — Connects to the switch or console using the binary mode. This is an optional argument; a
server or a switch must be present.
NOTE: If you use the -b option, reset the CMC to terminate the connect operation.
•server-nx —
where
n
=1-8 ;
x
= a,b,c,d
•switch-n — switch-n where n=
<a1 | a2 | b1 | b2 | c1 | c2>
coredump
Description Displays detailed information related to any recent critical
issues that have occurred with iDRAC. The coredump
information can be used to diagnose these critical issues.
If available, the coredump information is persistent across
iDRAC power cycles and remains available until either of
the following conditions occur:
• The coredump information is cleared with the
coredumpdelete subcommand.
31
• Another critical condition occurs on iDRAC. In this
case, the coredump information is relative to the
last critical error that occurred.
This option is applicable only for iDRAC.
To use this subcommand, you must have Execute Debug
Commands permission
See the coredumpdelete subcommand for more
information about clearing the coredump.
Synopsis racadm coredump
Input None
Output None
Example •racadm coredump
No Core Dump Data is currently available.
•racadm coredump
Feb 19 15:51:40 (none) last message repeated 5
times
Feb 19 15:52:41 (none) last message repeated 4
times
Feb 19 15:54:12 (none) last message repeated 4
times
Feb 19 15:56:11 (none) last message repeated 2
times
Feb 22 11:46:11 (none) kernel:
coredumpdelete
Description Clears any currently resident coredump data stored in the
RAC.
This option is applicable only for iDRAC.
To use this subcommand, you must have Clear Logs or
Execute Debug Commands permission.
NOTE: If a coredumpdelete command is issued and a
coredump is not currently stored in the RAC, the
command displays a success message. This behavior
is expected. See the coredump subcommand for more
information on viewing a coredump.
Synopsis racadm coredumpdelete
Input None
Output None
Example racadm coredumpdelete
Coredump request completed successfully
32
deploy
Description Configures the static IP address, subnet mask, gateway, and password for the root
user on iDRAC for the specified server.
To use this subcommand, you must have Server Administrator privilege.
NOTE: You can also use setniccfg to configure static IP address, subnet mask,
and gateway, as well as DHCP, speed, and duplex properties.
Synopsis •racadm deploy -m <module> -u root -p <password> -s
<ipaddress> <subnet> <gateway> -b <device> -o <no|
yes>
•racadm deploy -m <module> -u root -p <password> -s
-6 <ipv6Address> <prefixlen> <gateway> -b <device>
-o <no|yes>
where <
prefixlen
> must be a number between 0 and 128.
•racadm deploy -m <module> -u root -p <password> -d
[-6]
•racadm deploy -a -u root -p <password>
Input •-b <
device
> — Specifies the first boot device; must be used with -o.
• Use with -m <
module
> to specify for an individual server, or with -a for all
servers
Legal values: device=None, PXE, HDD, CD-DVD, vFDD, vCD-DVD, iSCSI, SD,
FDD, RFS
•-o <
no|yes
> — Indicates if the server should boot from the device once; must
be used with -o.
Use with -m <
module
> to specify for an individual server, or with -a for all
servers
•-a — Creates and enables an iDRAC root user if it does not already exist, and
is executed on all the existing servers in the chassis
•-u root — Indicates that the <
password
> is supplied for the root user on the
server. root is a constant parameter, the only value that is valid with the ‑u
option.
•-m <
module
> — Specifies the server you want to configure.
Legal values: server-nx where
n
=1-8 ;
x
= a,b,c,d
•-p <
password
> — Specifies the password for the root user on the server.
•-s <
ipaddress subnet gateway
> — Sets the IP address, subnet mask, and
gateway for the specified server, separated by single spaces.
– ipaddress — A string representing a valid IP address. For example,
192.168.0.20.
– subnet — A string representing a valid subnet mask. For example,
255.255.255.0.
– gateway — A string representing a valid gateway address. For
example, 192.168.0.1.
•-d — Enables DHCP for the specified server.
The -s and -d options cannot be used together in the same command.
•-6 — Enables IPv6 auto configuration (when used with -d.) Sets static IPv6
addresses (when used with -s)
Output None
33
Example • racadm deploy -m server-8 -s 192.168.0.20 255.255.255.0 192.168.0.1
The server was deployed successfully.
The deploy command generates an error when used on the extension slot of
a multi-slot server.
• racadm deploy -m server-9 192.168.0.11 255.255.255.0 192.168.0.1
ERROR: Server in slot 9 is an extension of the server in slot 1.
• racadm deploy -m server-7 -u root -p calvin -s -6 ::/64 :: 10
feature
Description Displays all active chassis features. The information displayed includes feature name, date activated,
and the serial number of the SD card used to activate the feature.
Dell Feature Cards may contain more than one feature. After any feature included on a Dell Feature
Card is activated on a chassis, any other features that may be included on that Dell Feature Card
cannot be activated on a different chassis.
NOTE: To use this subcommand to deactivate FlexAddress, you must have Chassis Configuration
Administrator privilege. A user with login privileges can view status only.
NOTE: To deactivate FlexAddress features, the chassis must be powered off.
Synopsis •racadm feature -s
•racadm feature -d -c <featurename>
•racadm feature -a -c ExtendedStorage
•racadm feature -1 -c ExtendedStorage
•racadm feature -2 -c ExtendedStorage
•racadm feature -r -c ExtendedStorage
Input •-s — Displays the status of active features.
•-d — Deactivates feature specified in -c option.
NOTE: When the FlexAddress and FlexAddressPlus feature are active, deactivating one of them
results in deactivation of the other feature also.
•-a — Activates ExtendedStorage feature.
•-1 — Configures ExtendedStorage feature for standalone use.
•-2 — Configures ExtendedStorage feature for redundant use.
•-r — Reformats damaged/unformatted ExtendedStorage media.
•
CAUTION: Using the -r switch deactivates the ExtendedStorage feature, if active; reformats the
SD media in the active CMC cardslot; and may reboot the active CMC.
•-c — <featurename> must be one of the following:
•flexaddress (with -d)
•flexaddressplus (with -d) ExtendedStorage (with -a,-d,-1,-2,
or -r)
34
featurecard
Description Verifies proper SD card installation and displays the SD
card status.
To use this subcommand, you must have Chassis
Configuration Administrator privilege.
Synopsis racadm featurecard -s
Input -s — Lists active SD card features and SD card status.
Output •No feature card inserted — Action:
Check the CMC to verify that the SD card was
properly inserted. In a redundant CMC
configuration, make sure the CMC with the SD
feature card installed is the active CMC and not
the standby CMC.
•The feature card inserted is
valid and contains the following
feature(s) FlexAddress: The
feature card is bound to this
chassis — Action: No action required.
•No features active on the chassis
— Action: Install the SD card into the CMC.
•The feature card inserted is
valid and contains the following
feature(s) FlexAddress: The
feature card is bound to another
chassis, svctag = ABC1234, SD
card SN = 01122334455
Action: Remove the SD card; locate and install the
SD card for the current chassis.
•The feature card inserted is
valid and contains the following
feature(s) FlexAddress: The
feature card is not bound to any
chassis
Action: The feature card can be moved to another
chassis, or can be reactivated on the current
chassis. To reactivate on the current chassis,
enter
racadm racreset
until the CMC module with
the feature card installed becomes active.
Example $ racadm featurecard -s
The feature card inserted is valid,
serial number TEST0123456789012345678
The feature card contains the
following feature(s):
FlexAddress: The feature is bound to this chassis
FlexAddressPlus: The feature is bound to this chassis
ExtendedStorage: The feature is bound to this chassis
35
fwupdate
Description Allows you to update the firmware on the iKVM, active CMC, standby CMC, server
iDRACs, or an IOM infrastructure device. You can:
• Check the firmware update process status.
• Update iDRAC or CMC firmware from a FTP or a TFTP server by providing an IP
address and optional path.
• Update iDRAC or CMC firmware from the local file system using Local and
Remote RACADM.
• Rollback to the standby firmware.
• This subcommand performs updates to the iDRAC firmware (if CMC firmware
version is 2.0 or later and iDRAC firmware version is 1.4) when the existing
firmware is corrupted. There can only be a single update operation in progress
at any time. In addition, the fwupdate subcommand may only update one or
more devices of a single kind at a time.
To use this subcommand for CMC you must have Chassis Configuration Administrator
privilege and for iDRAC you must have Configure iDRAC permission.
NOTE: Running the fwupdate subcommand to update the firmware on the active
CMC resets itself causing all network connections to be dropped. During update of
all other modules, including the standby CMC, the active CMC continues to run
normally without resetting.
NOTE: The fwupdate subcommand generates an error when used on the extension
slot of a multi-slot server.
Synopsis For iDRAC:
racadm fwupdate -s
racadm fwupdate -g -u -a <TFTP_Server_IP_Address>
[-d <path>]
racadm -r <iDRAC7 IP_Address> -u <username> -p <password>
fwupdate -f <ftpserver ip> <ftpserver username>
<ftpserver password> -d <path> where path is the location
on the ftp server where firming.d7 is stored.
racadm fwupdate -r
racadm fwupdate -p -u [-d <path>]
For CMC:
For local RACADM:
racadm fwupdate -g -u -a <tftp server ip address or
FQDN> -d <path> [-m <module>]
racadm fwupdate -f <ftp server ip address or FQDN>
<username> <password> -d <path> [-m
<module>]
racadm fwupdate -u -m iominf-<n>
racadm fwupdate -s [-m <module>]
racadm fwupdate -c [-m <module>]
36
For Remote RACADM:
racadm fwupdate -p -u -d <firmware image>
NOTE: iDRAC7 targets are not supported from CMC. Use the CMC GUI to update
iDRAC7 targets from CMC.
When using FTP, if you provide the full path to the image file on the CLI, then the CMC
uses that path to locate that file on the host. If you do not provide a full path, then the
CMC searches the home directory of the specified user for the file if the host system is
running Linux or another variant of UNIX. If the host system is running Windows, then a
default folder, such as C:\ftproot is searched.
NOTE: When attempting to run firmware update task using racadm fwupdate
command, if the firmware image path length is greater than 64 characters. Remote
RACADM client exits with the error message "ERROR: Specified path is too long".
Input •-u — For iDRAC: The update option performs a checksum of the firmware
update file and starts the actual update process. This option may be used along
with the -g or -p options. At the end of the update, iDRAC performs a soft reset.
For CMC: Performs the firmware update operation.
•-s— For iDRAC: The status option returns the current status of where you are
in the update process. This option is always used by itself. Lists active SD card
features and SD card status.
For CMC: Displays the current status of the firmware update.
NOTE: Use -m to display the status of the module update. Omit -m to display the
status of the active CMC update.
NOTE: The value all can only be used to obtain the status of all targets to be
updated.
•-g — For iDRAC:The get option instructs the firmware to get the firmware
update file from the TFTP server. You must also specify the -a, -u, and -d
options. In the absence of the -a option, the defaults are read from properties
contained in the group cfgRemoteHosts, using properties
cfgRhostsFwUpdateIpAddr and cfgRhostsFwUpdatePath.
For CMC: Downloads the firmware update using the TFTP server.
•-a — The IP Address option specifies the TFTP server IP address, used with -g
option.
For CMC: Specifies the TFTP server IP address or FQDN used for the firmware
image (used with -g).
•-d — For iDRAC: The -d, or directory, option specifies the directory on the TFTP
server or on iDRAC’s host server where the firmware update file resides.
For CMC: Specifies the source path where the firmware image resides.
Default: Designated TFTP default directory on that host for the file if -g option is
absent. If -g is used, it defaults to a directory configured on the TFTP server.
•-p — For iDRAC: The -p, or put, option is used to update the firmware file from
the managed system to iDRAC. The -u option must be used with the -p option.
NOTE: This option is not applicable for CMC. The -p option is supported on local and
remote RACADM and is not supported with the serial/Telnet/ssh console and on
Linux operating systems.
•-r — The rollback option is used to rollback to the standby firmware.
This option is not applicable for CMC.
•-c — Cancels the current firmware update of a module.
37
This option is applicable only for CMC.
•-m <
module
>—
Specifies the module or device to be updated. <
module
> is one of the following
values:
— cmc-active (default)
— cmc-standby
— kvm
— server-nx where
n
=1-8 ;
x
= a,b,c,d
— server-generation where generation = iDRAC or iDRAC6 only.
— iominf-n where n = 1–6
NOTE: iDRAC7 targets are not supported from CMC. Use the CMC GUI to update
iDRAC7 targets from CMC.
CMC version 3.00 accepts IPv4, IPv6, or fully qualified domain names (FQDN) for both
FTP and TFTP servers.
NOTE: You can specify the cmc-active and cmc-standby modules at the same time
along with one or more server-n modules. This enables the devices to be updated
together. This option is applicable only for CMC.
When you use the server-generation option, the CMC updates all iDRACs of that
particular generation that can be updated.
NOTE: Verify that the update applied to servers for a particular generation has been
validated for all impacted server models.
Output Displays a message indicating the operation that is being performed.
Example • Upload the firmware image from the TFTP server and start the firmware update
racadm fwupdate -g -u -a 192.168.0.100 -d
firmimg.cmc -m cmc-active TFTP firmwareate has been
initiated. This update process may take several
minutes to complete.
.
• Upload the firmware image from the FTP server and start the firmware update.
racadm fwupdate -f 192.168.0.100 fred password123 -d
firmimg.cmc -m cmc-active
• Start IOM infrastructure firmware update.
racadm fwupdate -u -m iominf-1
• Update firmware on both the CMCs.
racadm fwupdate -g -u -a 192.168.0.100 -d
firmimg.cmc -m cmc-active -m cmc-standby
• Update firmware on multiple servers.
racadm fwupdate -g -u -a 192.168.0.100 -d
firmimg.imc -m server-1 -m server-2 -m server-3
• Update firmware on servers of iDRAC generation.
racadm fwupdate -g -u -a 192.168.0.100 -d
firmimg.imc -m server-iDRAC
• Update firmware on multiple IOM infrastructure devices.
racadm fwupdate -u -m iominf-4 -m iominf-5 -m
iominf-6
• Query the current status of all firmware targets to be updated.
racadm fwupdate -s -m all
38
• Download firmware update file from a specified location on the TFTP server at
a specific IP address.
racadm fwupdate -g -u -a 143.166.154.143 -d <path>
After the image file is downloaded from the TFTP server, the update process
begins. When completed, iDRAC is reset.
• Read the current status of the firmware update.
racadm fwupdate -s
NOTE: Firmware update from local racadm (using -p -u -d options) is not supported
on linux OS.
NOTE: For CMC, these commands specifically apply to an active-CMC update.
The following table describes the firmware update method supported for each interface.
FW Update Method iDRAC on Blade Servers iDRAC on Rack and Tower
Servers
CMC
Local RACADM Yes Yes No
Local RACADM - TFTP Yes Yes No
Local RACADM - FTP Yes Yes No
Remote RACADM Yes Yes Yes
Remote RACADM-TFTP Yes Yes Yes
Remote RACADM-FTP Yes Yes Yes
Firmware RACADM-TFTP Yes Yes Yes
Firmware RACADM-FTP Yes Yes Yes
get
Description Allows the user to read the value of configuration objects on the iDRAC. The values
read are the values currently being used by the device.
To use this subcommand, you must have Configure iDRAC privilege.
This subcommand is applicable for iDRAC only.
Synopsis •racadm get -f <filename>
•racadm get < FQDD | FQDD Alias>[.<index>][.<group>]
[.<index>][.<object>]
Input •<FQDD | FQDD Alias> -
— List of FQDDs
— System.Power
— System.Power.Supply
— System.Location
— LifecycleController.LCAttributes
— System.LCD
— iDRAC.IMC
39
•<group> — Specifies the group containing the object that is to be read.
•<object> — Specifies the object name of the value to be read.
•<index> — Specifies where FQDDs, FQDD Alias's or Groups need to be
indexed.
•-f <filename> — Enables the subcommand to write the device
configuration to a file specified by <
filename
>. This option is not supported in
Firmware racadm interface.
For Indexed groups if a group is not configured then it will not be saved to the
configuration file.
•-u — Displays the group(s) associated with a specific user.
•-v - verbose — Displays additional details with the display of the
properties and is used with the -g option.
Examples Get system LCD information:
racadm get system.lcd
LCDUserString=test
getassettag
Description Displays the asset tag for the chassis.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis racadm getassettag [-m <module>]
Input -m <
module
> — Specifies the module whose asset tag
you want to view.
Legal value: chassis
Example •racadm getassettag -m chassis
•racadm getassettag
chassis 78373839–33
getchassisname
Description Displays the name of the chassis.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis racadm getchassisname
Example racadm getchassisname
PowerEdge 2955
40
getconfig
Description Retrieves iDRAC configuration parameters individually, or
all iDRAC configuration groups may be retrieved and
saved to a file.
Synopsis racadm getconfig -f <filename>
racadm getconfig -g <groupName> [-i
<index>]
racadm getconfig -u <username>
racadm getconfig -h
racadm getconfig -g <groupName> -o
<objectName>
[-i index]
Input •-f — The -f
<filename>
option directs getconfig to
write the entire iDRAC configuration to a
configuration file. This file can be used for batch
configuration operations using the config
subcommand.
•-g — The -g
<groupName>
, or group option, can
be used to display the configuration for a single
group. The groupName is the name for the group
used in the racadm.cfg files. If the group is an
indexed group, use the -i option.
•-h — The -h, or help option, displays a list of all
available configuration groups in alphabetical
order. This option is useful when you do not
remember exact group names.
•-i — The -i
<index>
, or index option, is valid only
for indexed groups and can be used to specify a
unique group. The
<index>
is a decimal integer
from 1 through n, where n can vary from 1 to
maximum number of indexes a particular group
supports. If -i
<index>
is not specified, a value of 1
is assumed for groups, which are tables that have
multiple entries. The index is specified by the
index value, not a
named
value.
•-o — The -o
<objectname>
or object option
specifies the object name that is used in the
query. This option is optional and can be used
with the -g option.
•-u — The -u
<username>
, or user name option,
can be used to display the configuration for the
specified user. The
<username>
option is the login
name for the user.
•-v — The -v option displays additional details with
the display of the properties and is used with the -
g option.
Output This subcommand generates error output upon
encountering either of the following:
• Invalid syntax, group name, object name, index, or
other invalid database members
• RACADM CLI transport failures
41
If errors are not encountered, this subcommand displays
the contents of the specified configuration.
Example •racadm getconfig -g
cfgLanNetworking
Displays all of the configuration properties
(objects) that are contained in the group
cfgLanNetworking.
•racadm getconfig -f myrac.cfg
Saves all group configuration objects from iDRAC
to myrac.cfg.
•racadm getconfig -h
Displays a list of the available configuration
groups on iDRAC in an alphabetical order.
•racadm getconfig -u root
Displays the configuration properties for the user
named root.
•racadm getconfig -g cfgUserAdmin
-i 2 -v
Displays the user group instance at index 2 with
verbose information for the property values.
getdcinfo
Description Displays general I/O module and daughter card configuration information. Only the
CMC controls daughtercards.
To use this subcommand, you must have CMC Login User privilege.
NOTE: Fabric verification for server DCs is performed only when the chassis is
powered on. When the chassis is on standby power, iDRACs on the server modules
remain powered off and thus are unable to report the server's DC fabric type. The
DC fabric type may not be reported in the CMC user interface until iDRAC on the
server is powered on.
Synopsis racadm getdcinfo
Input -n — Displays the model names for the daughter cards in servers.
Example
The example output below is for a system with multi-slot servers.
racadm getdcinfo
Group A I/O Type : Gigabit Ethernet
Group B I/O Type : Gigabit Ethernet
Group C I/O Type : 10 GbE XAUI
<IO#> <Type> <State> <Role>
switch-1 Gigabit Ethernet OK Master
switch-2 None N/A N/A
42
switch-3 Gigabit Ethernet OK Master
switch-4 None N/A N/A
switch-5 Gigabit Ethernet OK Member
switch-6 None N/A N/A
<Server#> <Presence> <DC1 Type> <DC1 State> <DC2 Type> <DC2 State>
server-1 Present None N/A None N/A
server-2 Not Present None N/A None N/A
server-3 Not Present None N/A None N/A
server-4 Present None N/A Gigabit
Ethernet
OK
server-5 Not Present None N/A None N/A
server-6 Not Present None N/A None N/A
server-7 Not Present None N/A None N/A
server-8 Present FibreChannel
4
Invalid None N/A
server-9 Extension(1) None N/A None N/A
server-10 Not Present None N/A None N/A
server-11 Not Present None N/A None N/A
server-12 Not Present None N/A None N/A
server-13 Not Present None N/A None N/A
server-14 Not Present None N/A None N/A
server-15 Not Present None N/A None N/A
server-16 Not Present None N/A None N/A
getdcinfo -n
<Server#> <Presence> <DC1 Model Name> <DC2 Model Name>
server-1 Present None None
server-2 Not Present None None
server-3 Not Present None None
server-4 Present None Broadcom M5708t
server-5 Not Present None None
43
server-6 Not Present None None
server-7 Not Present None None
server-8 Present LPe1105-M4 None
server-9 Extension(1) None None
server-10 Not Present None None
server-11 Not Present None None
server-12 Not Present None None
server-13 Not Present None None
server-14 Not Present None None
server-15 Not Present None None
server-16 Not Present None None
getflexaddr
Description Displays enabled/disabled status for the entire chassis. If
used with -i, the command displays MACs/WWN on a per
slot basis.
To use this subcommand, you must have CMC Login User
privilege.
NOTE: If FlexAddress is not activated on the chassis,
the command displays server-assigned MAC/WWN
addresses. If the slot is empty, the command leaves
the server-assigned MAC/WWN addresses blank. If
an external console controls the MAC/WWN
addresses, the command displays an externally
managed message.
Synopsis racadm getflexaddr [-i <slotNum>]
Input -i <
slotNum
> — Specifies the slot information to be
displayed. <
slotNum
> can be from 1 to 16.
Output
Example
Example
Display current flex address settings for all slots and fabrics
racadm getflexaddr
<Slot#> <Status> <Server Presence>
1 Enabled Present
44
2 Enabled Present
3 Enabled Not Present
4 Enabled Not Present
5 Enabled Present
6 Enabled Not Present
7 Enabled Not Present
8 Enabled Not Present
9 Enabled Not Present
10 Enabled Extension(2)
11 Enabled Not Present
12 Enabled Not Present
13 Enabled Extension(5)
14 Enabled Not Present
15 Enabled Not Present
16 Enabled Not Present
idrac System Disabled
Display the current flex address setting for slot 1.
racadm getflexaddr -i 1
Slot-1 server presence = Present
Slot-1 flexaddress enabled = 1
<Fabric> <Type> <Server-Assigned> <Chassis-Assigned>
slot1-A1 Gigabit Ethernet 00:1C:
23:CD:AC:D2(active)
00:1E:C9:FF:E3:21
iSCSI 00:1C:
23:CD:AC:D3(active)
00:1E:C9:FF:E3:22
slot1-A2 Gigabit Ethernet 00:1C:
23:CD:AC:D4(active)
00:1E:C9:FF:E3:23
iSCSI 00:1C:
23:CD:AC:D5(active)
00:1E:C9:FF:E3:24
slot1-B1 Gigabit Ethernet 00:1D:09:71:B3:60 00:1E:C9:FF:E3:25(a
ctive)
iSCSI 00:1D:09:71:B3:61 00:1E:C9:FF:E3:26(a
ctive)
45
slot1-B2 Gigabit Ethernet 00:1D:09:71:B3:62 00:1E:C9:FF:E3:27(a
ctive)
iSCSI 00:1D:09:71:B3:63 00:1E:C9:FF:E3:28(a
ctive)
slot1-C1 Fiber Channel 4 10:00:00:00:C9:63:5
1:0E
20:01:00:1E:C9:FF:E
3:29(active)
slot1-C2 Fiber Channel 4 10:00:00:00:C9:63:5
1:0D
20:02:00:1E:C9:FF:E
3:29(active)
getfanreqinfo
Description Displays fan speed request for Servers and Switches in percent (%).
To use this subcommand, you must have CMC Login User privilege.
This subcommand is not applicable for iDRAC.
Synopsis racadm getfanreqinfo
Input None
Output None
Example
racadm getfanreqinfo
[Ambient Temperature Fan Request %]
38
[Server Module Fan Request Table]
<Slot#> <Server
Name>
<Blade Type> <Power
State>
<Presence> <Fan Request
%>
1 SLOT-01 PowerEdgeM60
0
ON Present 33
2 SLOT-02 PowerEdgeM90
5
ON Present 35
3 SLOT-03 PowerEdgeM71
0
ON Present 44
4 SLOT-04 PowerEdgeM61
0
ON Present 46
5 SLOT-05 PowerEdgeM61
0
ON Present 46
6 SLOT-06 N/A N/A Not Present N/A
7 SLOT-07 PowerEdgeM60
5
ON Present 100
fwupdate
46
8 SLOT-08 PowerEdgeM71
0
ON Present 44
9 SLOT-09 N/A N/A Not Present N/A
10 SLOT-10 N/A Extension(2) N/A N/A
11 SLOT-11 N/A Extension(3) N/A N/A
12 SLOT-12 N/A N/A Not Present N/A
13 SLOT-13 N/A N/A Not Present N/A
14 SLOT-14 PowerEdgeM60
0
ON Present 33
15 SLOT-15 N/A N/A Not Present N/A
16 SLOT-16 N/A Extension(8) N/A N/A
Switch Module Fan Request Table
<Slot#> <Server
Name>
<Blade Type> <Power
State>
<Presence> <Fan Request
%>
1 SLOT-01 PowerEdgeM60
0
ON Present 33
2 SLOT-02 PowerEdgeM90
5
ON Present 35
3 SLOT-03 PowerEdgeM71
0
ON Present 44
4 SLOT-04 PowerEdgeM61
0
ON Present 46
5 SLOT-05 PowerEdgeM61
0
ON Present 46
6 SLOT-06 N/A N/A Not Present N/A
7 SLOT-07 PowerEdgeM60
5
ON Present 100
fwupdate
8 SLOT-08 PowerEdgeM71
0
ON Present 44
9 SLOT-09 N/A N/A Not Present N/A
10 SLOT-10 N/A Extension(2) N/A N/A
11 SLOT-11 N/A Extension(3) N/A N/A
12 SLOT-12 N/A N/A Not Present N/A
47
13 SLOT-13 N/A N/A Not Present N/A
14 SLOT-14 PowerEdgeM60
0
ON Present 33
15 SLOT-15 N/A N/A Not Present N/A
16 SLOT-16 N/A Extension(8) N/A N/A
Switch Module Fan Request Table
<IO Name> <Name> <Type> <Presence> <Fan Request%>
Switch-1 Dell Ethernet
Pass-Through
Gigabit
Ethernet
Present 30
Switch-2 Dell
PowerConnect
M6220
Gigabit
Ethernet
Present 30
Switch-3 N/A None Not Present N/A
Switch-4 N/A None Not Present N/A
Switch-5 N/A None Not Present N/A
Switch-6 N/A None Not Present N/A
getioinfo
Description Displays general information about the I/O modules on the chassis.
To use this subcommand, you must have CMC Login User privilege.
NOTE: The fabric type may be any supported I/O fabric type, such as Ethernet, Fiber Channel,
and Infiniband.
Synopsis racadm getioinfo
Example
racadm getioinfo
<IO> <Name> <Type> <Presence> <POST> <Power> <Role>
switch-1 Dell
Ethernet
Passthroug
h
Gigabit
Ethernet
Present OK ON Master
switch-2 N/A None Not
Present
N/A N/A N/A
switch-3 Brocade
4424
Fibre
Channel 4
Present OK ON Master
48
switch-4 N/A None Not
Present
N/A N/A N/A
switch-5 N/A None Not
Present
N/A N/A N/A
switch-6 N/A None Not
Present
N/A N/A N/A
getkvminfo
Description Displays iKVM module information.
To use this subcommand, you must have CMC Login User privilege.
Synopsis racadm getkvminfo
Example
racadm getkvminfo
<
module
> <
presence
> <
model
> <
FW Version
> <
status
>
KVM Present Avocent iKVM
Switch
00.05.00.04 Ready
getled
Description Displays the LED settings on a module: blinking, not
blinking, or unknown (for empty slots).
To use this subcommand, you must have Login User
privilege.
Synopsis racadm getled -m <module>
Input CMC only options:
-m <
module
> — Specifies the module whose LED settings
you want to view.
<
module
> can be one of the following:
• server-nx where n=1-8; x=a,b,c,d
• switch-n where n=1– 6
• chassis
• cmc-active
Output
Example For CMC:
•racadm getled -m server-10
<
module
> <
LED state
> server-10 Blinking
•racadm getled -m chassis
<
module
> <
LED state
> server-10 Not blinking
•racadm getled -m server-1
<
module
> <
LED state
> server-1 ON
49
•racadm getled -m server-9
<
module
> <
LED state
> server-9 Extension(1)
For iDRAC:
racadm getled
LED is blinking
getmacaddress
Description Displays the MAC/WWN addresses for all modules or for a specified module.
To use this subcommand, you must have CMC Login User privilege.
Synopsis • racadm getmacaddress [-m <
module
>] [-t iscsi] [-x]
• racadm getmacaddress [-a]
Input •-m <
module
> — Specifies the module whose MAC address you want to view.
<
module
> may be one of the following:
server-nx where
n
=1-8 ;
x
= a,b,c,d
switch-n where
n
=1–6
•-t — Displays the iSCSI MAC addresses for all servers or the specified server if used with -
m option.
•-x — Displays the extra MACs (Ethernet or iSCSI) for servers with additional LOM MACs
and must be used with -m option.
•-a — Displays the Ethernet and iSCSI MAC/WWN addresses for all iDRAC/LOMs/
mezzanine cards. When FlexAddress is enabled for a particular slot, then the chassis-
assigned MAC/WWN address is displayed.
Example
Display iSCSI MAC addresses for all servers.
racadm getmacaddress -t iscsi
Display iSCSI MAC for server-1.
racadm getmacaddress -m server-1 -t iscsi
Display extra iSCSI MACs for server-1 (if available).
racadm getmacaddress -m server-1 -t iscsi -x
Display MAC for server-1.
racadm getmacaddress -m server-1
<Name> <Presence> <BMC MAC
Address>
<NIC1 MAC
Address>
<NIC2 MAC
Address>
server-1 Present 00:11:43:FD:B7:
2A
00:11:43:FD:B7:
2A
00:11:43:FD:B7:
2B
server-9 Extension(1) N/A 00:11:43:FD:B7:
2C
00:11:43:FD:B7:
2D
Display extra MACs for server-1 (if available).
racadm getmacaddress -m server-1 -x
50
<Name> <Presence> <BMC MAC
Address>
<NIC1 MAC
Address>
<NIC2 MAC
Address>
server-1 Present 00:11:43:FD:B7:
2A
00:11:43:FD:B7:
2A
00:11:43:FD:B7:
2B
00:11:43:FD:B7:
2C
00:11:43:FD:B7:
2D
racadm getmacaddress
<Name> <Presence> <BMC MAC
Address>
<NIC1 MAC
Address>
<NIC2 MAC
Address>
CMC Present N/A 00:1E:4F:1F:3C:
58
N/A
Server-1 Present 00:1E:4F:2A:AF:
7B
00:1E:4F:
2A:D3:97
00:1E:4F:
2A:D3:99
Server-2 Present 00:22:19:D2:1E:
84
N/A N/A
Server-3 Not Present N/A N/A N/A
Server-4 Present 00:18:8B:FF:
45:2A
00:18:8B:FF:AA:
02
00:18:8B:FF:AA:
04
Server-5 Present 00:19:B9:FF:FE:
E2
00:19:B9:FF:FC:
0C
00:19:B9:FF:FC:
0E
Server-6 Present 00:22:19:D2:1D:
D4
N/A N/A
Server-7 Present 00:1E:
4F:FF:FC:DC
00:1E:
4F:FF:F0:B0
00:1E:
4F:FF:F0:B2
Server-8 Not Present N/A N/A N/A
Server-9 Not Present N/A N/A N/A
Server-10 Not Present N/A N/A N/A
Server-11 Not Present N/A N/A N/A
Server-12 Not Present N/A N/A N/A
Server-13 Present 00:18:8B:FF:
45:26
00:18:8B:FF:A9:
F2
00:18:8B:FF:A9:
F4
Server-14 Present 00:22:19:D2:1E:
A2
N/A N/A
Server-15 Extension(7) N/A 00:1E:
4F:FF:F0:B4
00:1E:
4F:FF:F0:B6
Server-16 Not Present N/A N/A N/A
51
Switch-1 Present N/A 00:00:00:00:00:
00
N/A
Switch-2 Present N/A 00:00:00:00:00:
00
N/A
Switch-3 Present N/A 00:00:00:00:00:
00
N/A
Switch-4 Present N/A 00:00:00:00:00:
00
N/A
Switch-5 Present N/A 00:05:1E:08:EB:
0B
N/A
Switch-6 Not Present N/A N/A N/A
Display Ethernet and iSCSI MACS of all LOMs/mezzanine cards.
racadm getmacaddress -a
<Name> <Type> <Presence> <BMC MAC
Address>
<NIC1 MAC
Address>
<NIC2 MAC
Address>
CMC N/A Present N/A 00:1E:4F:1F:
3C:58
N/A
Server-1-A Gigabit
Ethernet
Present 00:1E:4F:
2A:AF:7B
00:1E:4F:
2A:D3:97
00:1E:4F:
2A:D3:99
iSCSI Present 00:1E:4F:
2A:D3:98
00:1E:4F:
2A:D3:9A
Server-1-B Gigabit
Ethernet
Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-1-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-2-A Gigabit
Ethernet
Present 00:22:19:D2:
1E:84
N/A N/A
iSCSI Present N/A N/A
Server-2-B Gigabit
Ethernet
Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-2-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-3 N/A Not Present N/A N/A N/A
52
Server-4-A Gigabit
Ethernet
Present 00:18:8B:FF:
45:2A
00:18:8B:FF:
AA:02
00:18:8B:FF:
AA:04
iSCSI Present 00:18:8B:FF:
AA:03
00:18:8B:FF:
AA:05
Server-4-B Gigabit
Ethernet
Not Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-4-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-5-A Gigabit
Ethernet
Present 00:19:B9:FF:
FE:E2
00:19:B9:FF:
FC:0C
00:19:B9:FF:
FC:0E
iSCSI Present 00:19:B9:FF:
FC:0D
00:19:B9:FF:
FC:0F
Server-5-B Gigabit
Ethernet
Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-5-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-6-A Gigabit
Ethernet
Present 00:22:19:D2:
1D:D4
N/A N/A
iSCSI Present N/A N/A
Server-6-B Gigabit
Ethernet
Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-6-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-7-A Gigabit
Ethernet
Present 00:1E:
4F:FF:FC:DC
00:1E:
4F:FF:F0:B0
00:1E:
4F:FF:F0:B2
iSCSI Present 00:1E:
4F:FF:F0:B1
00:1E:
4F:FF:F0:B3
Server-7-B Gigabit
Ethernet
Present 00:1D:
09:72:01:C8
00:1D:
09:72:01:CA
Server-7-C Fibre
Channel 4
Present 21:00:00:1B:
32:0E:CF:34
21:01:00:1B:
32:2E:CF:34
Server-8 N/A Not Present N/A N/A N/A
Server-9 N/A Not Present N/A N/A N/A
53
Server-10 N/A Not Present N/A N/A N/A
Server-11 N/A Not Present N/A N/A N/A
Server-12 N/A Not Present N/A N/A N/A
Server-13-A Gigabit
Ethernet
Present 00:18:8B:FF:
45:26
00:18:8B:FF:
A9:F2
00:18:8B:FF:
A9:F4
iSCSI Present 00:18:8B:FF:
A9:F3
00:18:8B:FF:
A9:F5
Server-13-B Gigabit
Ethernet
Present 00:1D:
09:71:E0:78
00:1D:
09:71:E0:7A
iSCSI Present 00:1D:
09:71:E0:79
00:1D:
09:71:E0:7B
Server-13-C Fibre
Channel 4
Present 21:00:00:1B:
32:0E:EF:30
21:01:00:1B:
32:2E:EF:30
Server-14-A Gigabit
Ethernet
Present 00:22:19:D2:
1E:A2
N/A N/A
iSCSI Present N/A N/A
Server-14-B Gigabit
Ethernet
Present Not
Installed
Not
Installed
iSCSI Present Not
Installed
Not
Installed
Server-14-C Fibre
Channel 4
Present Not
Installed
Not
Installed
Server-15-A Gigabit
Ethernet
Extension(7) N/A 00:1E:
4F:FF:F0:B4
00:1E:
4F:FF:F0:B6
iSCSI Extension(7) N/A 00:1E:
4F:FF:F0:B5
00:1E:
4F:FF:F0:B7
Server-15-B Gigabit
Ethernet
Extension(7) N/A 00:1D:
09:71:E1:20
00:1D:
09:71:E1:22
iSCSI Extension(7) N/A 00:1D:
09:71:E1:21
00:1D:
09:71:E1:23
Server-15-C Fibre
Channel 4
Extension(7) N/A 21:00:00:1B:
32:17:3A:66
21:00:00:1B:
32:37:3A:66
Server-16 N/A Not Present N/A N/A N/A
Switch-1 None Present N/A 00:00:00:00:
00:00
N/A
Switch-2 None Present N/A 00:00:00:00:
00:00
N/A
Switch-3 None Present N/A 00:00:00:00:
00:00
N/A
54
Switch-4 None Present N/A 00:00:00:00:
00:00
N/A
Switch-5 None Present N/A 00:05:1E:
08:EB:0B
N/A
Switch-6 N/A Not Present N/A N/A N/A
getmodinfo
Description Displays configuration and status information for all modules or a specified module (server, switch,
CMC, fan unit, power supply unit, KVM, or I2C cable) in the chassis.
For CMC (only) a power state of "Primary" denotes Active CMC.
To use this subcommand, you must have CMC Login User privilege.
NOTE: The service tag field is blank for modules that do not have service tags.
Synopsis racadm getmodinfo [-m <module>] [-A]
Input •-m <
module
> — Specifies the module whose configuration and status information you want
to view. The default command (no options) displays information about all major components
in the chassis.
<module
> may be any of the following values:
server-nx where
n
=1-8 ;
x
= a,b,c,d
— switch-n where n=1–6
— CMC-n where n=1–2
— fan-n where n=1–9
— ps-n where n=1–6
— chassis
— kvm
— io-cable
— fpc-cable
•-A — Suppresses headers and labels in the output.
Example
racadm getmodinfo -m switch-1
<module> <presence> <pwrState> <health> <svcTag> Switch-1
Present ON OK CG09074
racadm getmodinfo
<module> <presence> <pwrState> <health> <svcTag>
Chassis Present ON Not OK ABC1234
Fan-1 Present ON OK
Fan-2 Present ON OK
Fan-3 Present ON OK
Fan-4 Present ON OK
Fan-5 Present ON OK
Fan-6 Present ON OK
Fan-7 Present ON OK
Fan-8 Present ON OK
Fan-9 Present ON OK
PS-1 Present Online OK
PS-2 Not Present N/A N/A N/A
55
PS-3 Present Online OK
PS-4 Not Present N/A N/A N/A
PS-5 Not Present N/A N/A N/A
PS-6 Not Present N/A N/A N/A
CMC-1 Present Primary OK N/A
CMC-2 Not Present N/A N/A N/A
Switch-1 Not Present N/A N/A N/A
Switch-2 Not Present N/A N/A N/A
Switch-3 Not Present N/A N/A N/A
Switch-4 Not Present N/A N/A N/A
Switch-5 Not Present N/A N/A N/A
Switch-6 Not Present N/A N/A N/A
Server-1 Not Present N/A N/A N/A
Server-2 Present OFF OK
Server-3 Present ON OK S YW
Server-4 Present ON OK
Server-5 Present ON OK
Server-6 Present ON OK 1234567
Server-7 Present ON OK
Server-8 Not Present N/A N/A N/A
Server-9 Not Present N/A N/A N/A
Server-10 Extension(2) N/A N/A N/A
Server-11 Not Present N/A N/A N/A
Server-12 Present ON OK
Server-13 Not Present N/A N/A N/A
Server-14 Present ON OK 0000015
Server-15 Present ON OK
Server-16 Present ON OK
KVM Present ON OK
IO-Cable Present ON OK ABC1234
FPC-Cable Present ON OK ABC1234
NOTE: For CMC (only) a power state of "Primary" denotes Active CMC.
getniccfg
Description Displays the current NIC settings.
Synopsis racadm getniccfg
Input racadm getniccfg
racadm getniccfg –m <module>
where –m must be one of the following values:
•chassis
: default state if -m is not specified
• server-n
: where n = 1 to 16
• server-nx
: where n = 1 to 8; x = a to d (lower case)
•switch-n
: where n = 1 to 6
56
Example racadm getniccfg
racadm getniccfg –m <module>
Output
The getniccfg subcommand displays an appropriate error message if the operation is not successful. Otherwise, on
success, the output is displayed in the following format:
IPv4 settings:
NIC Enabled = 1
IPv4 Enabled = 1
DHCP Enabled = 1
IP Address = 10.35.0.64
Subnet Mask = 255.255.255.0
Gateway = 10.35.0.1
IPv6 settings:
IPv6 Enabled = 0
DHCP6 Enabled = 1
IP Address 1 = ::
Gateway = ::
Link Local Address = ::
IP Address 2 = ::
IP Address 3 = ::
IP Address 4 = ::
IP Address 5 = ::
IP Address 6 = ::
IP Address 7 = ::
IP Address 8 = ::
IP Address 9 = ::
IP Address 10 = ::
IP Address 11 = ::
IP Address 12 = ::
IP Address 13 = ::
IP Address 14 = ::
IP Address 15 = ::
LOM Status:
NIC Selection = Dedicated
Link Detected = Yes
Speed = 10Mb/s
Duplex Mode = Half Duplex
57
NOTE: IPv6 information is displayed only if IPv6 is enabled in iDRAC.
NOTE: LOM Status is displayed only for iDRAC on Rack and Tower servers and is not displayed for iDRAC
Enterprise on Blade servers.
getpbinfo
Description Displays power budget status information.
To use this subcommand, you must have CMC Login User privilege.
Synopsis racadm getpbinfo
Example
racadm getpbinfo
[Power Budget Status]
System Input Power = 700 W
Peak System Power = 0 W
Peak System Power Timestamp = 01:08:23 01/27/2009
Minimum System Power = 0 W
Minimum System Power Timestamp = 20:18:30 01/27/2000
Overall Power Health = Not OK
Redundancy = No
System Input Power Cap = 7928 W
Redundancy Policy = None
Dynamic PSU Engagement Enabled = No
System Input Max Power Capacity = 0 W
Input Redundancy Reserve = 0 W
Input Power Allocated to Servers = 0 W
Input Power Allocated to Chassis Infrastructure = 51 watts
Total Input Power Available for Allocation = 0 W
Standby Input Power Capacity = 0 W
[Chassis Power Supply Status Table]
<Name> <Presence> <Power State> <Input Current> <Input Volts><Output Rating>
PS1 Online On
16.1 A 32 V 2360 W
PS2 Not Present Slot Empty
N/A N/A N/A
PS3 Not Present Slot Empty
N/A N/A N/A
PS4 Not Present Slot Empty
N/A N/A N/A
PS5 Not Present Slot
Empty N/A N/
A N/A
PS6 Not Present Slot
Empty N/A N/A
N/A
[Server Module Power Allocation Table]
<Slot#><Server Name><PowerState><Allocation><Priority><Blade Type>
1 SLOT-01 N/A N/A 5
N/A
2 SLOT-02 OFF 0 W 5 PowerEdgeM805
3 SLOT-03 ON 164 W 5 N/A
58
4 SLOT-04 ON 155 W 5
5 SLOT-05 ON 180 W 5
6 SLOT-06 ON 180 W 5 PowerEdgeM600
7 SLOT-07 ON 170 W 5
8 SLOT-08 N/A N/A 5 N/A
9 SLOT-09 N/A N/A 5 N/A
10 SLOT-10 Extension(2) N/A 5 N/A
11 SLOT-11 N/A N/A 5 N/A
12 SLOT-12 ON 125 W 5 PowerEdgeM600
13 SLOT-13 N/A N/A 5 N/A
14 SLOT-14 ON 342 W 5 N/A
15 SLOT-15 ON 140 W 5
16 SLOT-16 ON 125 W 5 N/A
getpminfo
Description Displays power management status information.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis racadm getpminfo
Example racadm getpminfo
[Real-Time Power Statistics]
System Input Power = 600
W (188 BTU/hr)
Peak System Power = 600
W (188 BTU/hr
Peak System Power Start Time =
16:02:10 01/16/2008
Peak System Power Timestamp =
06:32:55 01/26/2009
Minimum System Power = 400
W (177 BTU/hr)
Minimum System Power Start Time =
22:43:21 01/21/2008
Minimum System Power Timestamp =
06:32:55 01/26/2009
System Idle Power = 68 W
(188 BTU/hr)
System Potential Power = 68 W
(188 BTU/hr)
System Input Current Reading = 31.2
A
[Real-Time Energy Statistics]
System Energy
Consumption = 6.4 kWh
System Energy Consumption Start
Time = 16:02:10 01/16/2008
System Energy Consumption
Timestamp = 16:02:10 01/16/2008
[System Power Status]
Chassis Power State
= ON
59
Overall Power Health = OK
Redundancy = No
[System Power Policy Configuration]
System Input Power
Cap = 7928 W (7928
BTU/hr |
10%)
Surplus for Peak
Performance = 7000 W (6130
BTU/hr)
Redundancy Policy
= None
Dynamic PSU Engagement Enabled
= No
[Power Budgeting]
System Input Max Power
Capacity = 0 W
Input Redundancy
Reserve = 0 W
Input Power Allocated to
Servers = 0 W
Input Power Allocated to Chassis
Infrastructure = 51W
Total Input Power Available for
Allocation = 0 W
Standby Input Power
Capacity = 0 W
getraclog
Description The getraclog command displays RAC log entries.
On local racadm, when you run this command, the data is exposed to RACADM as a USB partition
and may display a pop up.
Synopsis racadm getraclog -i [-A]
racadm getraclog [-A] [-o] [-c count] [-s start-record] [--more]
Input •-c — Specifies the number of records to display. On local racadm, if this parameter is not
specified, by default 100 logs are retrieved.
•--more — Displays one screen at a time and prompts the user to continue (similar to the
UNIX more command).
•-A — Displays the output with no headers or labels.
•-i — Displays the number of entries in the RAC log.
•-o — Displays the output in a single line.
•-s — Specifies the starting record used for the display.
NOTE: For CMC: the -A and -o options are deprecated.
NOTE: If no options are provided, the entire log is displayed.
Output The default output display shows the record number, time stamp, source, and description. The
timestamp begins at midnight, January 1 and increases until the system boots. After the system
boots, the system’s timestamp is used.
Record: 1
Date/Time: Dec 8 08:10:11
60
Source: login[433]
Description: root login from 143.166.157.103
NOTE: For iDRAC Enterprise on Blade Servers, iDRAC Log entries for SystemBoot displayed using
the local racadm command racadm getraclog may not be correctly formatted. For example, some
extra characters may be displayed in the Description field, or the Source field may be empty.
Example racadm getraclog -s 10 -c 2
getractime
Description Displays the current iDRAC time.
Synopsis •racadm getractime [-d]
•racadm getractime [-d] [-z] [-n]
Input •-d — Displays the time in the format, yyyymmddhhmmss.mmmmmms.
•-z — Displays timezone. This option is specific to CMC only.
•-n — Displays NTP peer information. This option is specific to CMC only.
NOTE: If no options are provided, the getractime subcommand displays the time in a common
readable format.
Output •racadm getractime
Thu Dec 8 20:15:26 2005
•racadm getractime -d
20051208201542.000000
Example •racadm getractime
Thu Dec 8 20:15:26 2005
•racadm getractime -d
20051208201542.000000
getredundancymode
Description Displays the redundancy status (Redundant or Non-
Redundant) of the CMC.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis racadm getredundancymode
Example racadm getredundancymode
Redundant
61
getsel
Description Displays all sensor event log entries in the DRAC.
Synopsis • racadm getsel -i [-A]
• racadm getsel [-s <
start
>] [-c <
count
>] [-A] [-o] [-E] [-R] [--more]
If no arguments are specified, the entire log is displayed.
Input •-A — Specifies output with no display headers or labels.
•-c — Provides the number of records to be displayed.
•-o — Displays each entry in the SEL in a single line.
•-s — Specifies the starting record used for the display.
•-E — Displays RAW SEL data with the other data for each entry.
•-R — Displays only RAW SEL data for each entry.
•-i — Displays the number of entries in the SEL.
•--more — Displays one screen at a time and prompts the user to continue (similar to the
UNIX more command.)
NOTE: For CMC: the -A, -E, -o, and -R options are deprecated.
Output Record: 12
Date/Time: 11/20/2011 14:19:34
Source: system
Severity: Ok
Description: C: boot completed.
Example racadm getsel
getsensorinfo
Description Displays status for system sensors.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis racadm getsensorinfo
Examples
racadm getsensorinfo
<senType> <Num> <sensorName> <status> <reading>
<units> <lc> <uc>
FanSpeed 1 Fan-1 OK 4768 rpm 2344 14500
FanSpeed 2 Fan-2 OK 4873 rpm 2344 14500
FanSpeed 3 Fan-3 OK 4832 rpm 2344 14500
FanSpeed 4 Fan-4 OK 4704 rpm 2344 14500
FanSpeed 5 Fan-5 OK 4833 rpm 2344 14500
FanSpeed 6 Fan-6 OK 4829 rpm 2344 14500
FanSpeed 7 Fan-7 OK 4719 rpm 2344 14500
FanSpeed 8 Fan-8 Not OK 1 rpm 2344 14500
FanSpeed 9 Fan-9 OK 4815 rpm 2344 14500
<senType> <Num> <sensorName> <status> <reading> <units> <lc>
62
<uc>
Temp 1 Ambient_Temp OK 22 celcius N/A 40
<senType> <Num> <sensorName> <status> <AC-OK status>
PWR 1 PS-1 Online OK
PWR 2 PS-2 Online OK
PWR 3 PS-3 Online OK
PWR 4 PS-4 Slot Empty N/A
PWR 5 PS-5 Failed OK
PWR 6 PS-6 Slot Empty N/A
<senType> <Num> <sensorName> <status>
Cable 1 IO-Cable OK
Cable 2 FPC-Cable OK
getslotname
Description Displays the name and hostname (if available) of all 16
slots, or of a specified slot (indicated by the slot number)
in the chassis. Optionally, this command can be used to
find if the slot name or hostname is displayed in the CMC
User Interface or with the getslotname -i <
slot ID
>
command. If the hostname is not available, the static slot
name is used.
To use this subcommand, you must have CMC Login User
privilege.
Synopsis • racadm getslotname
• racadm getslotname -i <
slot ID
>
• racadm getslotname -h
Input • None -
Displays the slot name for all 16 slots in the
chassis.
• -i <
slot ID
> - specifies the ID of the slot.
Legal values: 1–16
• -h - Specifies whether to use the slot name or the
hostname (if available).
1=use hostnames, 0=use slotnames
Example
racadm getslotname
<Slot #> <Slot Name> <Host name>
1 SLOT-01
2 Webserver01 WXP-8GRB221
3 Webserver3 WXP-319QWEecet5
4 SLOT-04
5 SLOT-05
6 SLOT-06
7 SLOT-07
63
8 SLOT-08
9 SLOT-09
10 SLOT-10
11 SLOT-11
12 SLOT-12
13 SLOT-13
14 SLOT-14
15 SLOT-15
16 SLOT-16
racadm getslotname -i 1
Webserver-1
getssninfo
Description Displays a list of users that are connected to iDRAC. The following information is displayed:
• Session ID
• Username
• IP address (if applicable)
• Session type (for example, serial or Telnet)
• Login date and time in MM/DD/YYYY HH:MM:SS format
NOTE: Based on the Session ID (SSNID) or the user name (User), the iDRAC administrator
can close the respective sessions or all the sessions using the, closessn subcommand. For
more information, see closessn.
Synopsis racadm getssninfo [-A] [-u <username> | *]
Input •-A - eliminates the printing of data headers.
•-u - The -u <
username
> user name option limits the printed output to only the detail
session records for the given user name.
Examples
racadm getssninfo
SSNID Type User IP Address Login Date/Time
6 GUI root 192.168.0.10 04/07/2010 12:00:34
racadm getssninfo -A
"root" "143.166.174.19" "Telnet" "NONE"
racadm getssninfo -A -u *
"root" "143.166.174.19" "Telnet" "NONE"
"bob" "143.166.174.19" "GUI" "NONE"
getsvctag
Description Displays the service tag of the host system.
Synopsis racadm getsvctag
64
Input getsvctag
Output Y76TP0G
Example racadm getsvctag
getsysinfo
Description Displays information related to iDRAC, managed system, and watchdog configuration.
.
NOTE: The local racadm getsysinfo subcommand on Linux displays the PrefixLength on separate
lines for IPv6 Address 2 – IPv6 Address 15 and the Link Local Address.
NOTE: The Hostname and OS Name fields in the getsysinfo output display accurate information
only if Dell OpenManage Server Administrator is installed on the managed system. Else, these
fields may be blank or inaccurate. An exception to this are VMware operating system names,
which are displayed even if Server Administrator is not installed on the managed system.
Synopsis racadm getsysinfo [-d] [-s] [-w] [-A] [-c] [-4]
[-6]
Input •-4 - Displays IPv4 settings
•-6 - Displays IPv6 settings
•-c - Displays common settings
•-d - Displays iDRAC information
•-s - Displays system information
•-w - Displays watchdog information
•-A - Eliminates the printing of headers/labels
NOTE: If the -w option is not specified, then the other options are used as defaults.
Output
RAC Information:
RAC Date/Time = 10/27/2009 14:38:00
Firmware Version = 1.30
Firmware Build = 20
Last Firmware Update = 10/26/2009 16:55:08
Hardware Version = 0.01
MAC Address = 00:24:e8:2e:c5:d3
Common settings:
Register DNS RAC Name = 1
DNS RAC Name = eval710-08-r
Current DNS Domain = blr.amer.dell.com
Domain Name from DHCP = 1
IPv4 settings:
Enabled = 1
Current IP Address = 10.94.20.134
Current IP Gateway = 10.94.20.1
Current IP Netmask = 255.255.254.0
DHCP Enabled = 1
Current DNS Server 1 = 163.244.180.39
65
Current DNS Server 2 = 163.244.180.40
DNS Servers from DHCP = 1
IPv6 settings:
Enabled = 1
Current IP Address 1 = ::
Current IP Gateway = ::
Autoconfig = 1
Link Local IP Address = fe80::224:e8ff:fe2e:c5d3/255
Current IP Address 2 = ::
Current IP Address 3 = ::
Current IP Address 4 = ::
Current IP Address 5 = ::
Current IP Address 6 = ::
Current IP Address 7 = ::
Current IP Address 8 = ::
Current IP Address 9 = ::
Current IP Address 10 = ::
Current IP Address 11 = ::
Current IP Address 12 = ::
Current IP Address 13 = ::
Current IP Address 14 = ::
Current IP Address 15 = ::
DNS Servers from DHCPv6 = 0
Current DNS Server 1 = ::
Current DNS Server 2 = ::
System Information:
System Model = PowerEdge R710
System BIOS Version = 1.0.4
Service Tag = 2X2Q12S
Express Svc Code = 39059052868
Host Name = WIN-IHF5D2BF5SN
OS Name = Microsoft Windows Server 2008, Enterprise x64 Edition
System Revision = I
Power Status = ON
Embedded NIC MAC Addresses: NIC1
Ethernet = 00:24:e8:2e:c5:cb
iSCSI = 00:24:e8:2e:c5:cc
NIC2 Ethernet = 00:24:e8:2e:c5:cd
iSCSI = 00:24:e8:2e:c5:ce
NIC3 Ethernet = 00:24:e8:2e:c5:cf
iSCSI = 00:24:e8:2e:c5:d0
NIC4 Ethernet = 00:24:e8:2e:c5:d1
iSCSI = 00:24:e8:2e:c5:d2
Watchdog Information:
Recovery Action = None
Present countdown value = 15 seconds
Initial countdown value = 15 seconds
Examples
•racadm getsysinfo -A -s
"System Information:" "PowerEdge 2900" "A08" "1.0" "EF23VQ-0023"
"Hostname"
66
"Microsoft Windows 2000 version 5.0, Build Number 2195, Service Pack 2"
"ON"
•racadm getsysinfo -w -s
System Information:
System Model = PowerEdge 2900
System Revision = I
System BIOS Version = 0.2.3
BMC Firmware Version = 0.17
Service Tag = 48192
Host Name = racdev103
OS Name = Microsoft Windows Server 2003
Power Status = OFF
Watchdog Information:
Recovery Action = None
Present countdown value = 0 seconds
Initial countdown value = 0 seconds
gettracelog
Description Lists all the trace log entries in the DRAC.
Synopsis •racadm gettracelog -i [-A]
•racadm gettracelog [-s <start>] [-c <count>] [--more] [-A] [-
o]
Input •-i - Displays the number of entries in iDRAC trace log.
•--more - Displays one screen at a time and prompts the user to continue (similar to the UNIX
more command).
•-o - Displays each entry in a single line.
•-c - Specifies the number of records to display.
•-s - Specifies the starting record to display.
•-A - Does not display headers or labels.
NOTE: For CMC: the -A and -o options are deprecated.
Output The default output display shows the record number, timestamp, source, and description. The
timestamp begins at midnight, January 1 and increases until the system boots. After the system
boots, the system’s timestamp is used.
Example Record: 1
Date/Time: Dec 8 08:21:30
Source: ssnmgrd[175]
Description: root from 143.166.157.103: session timeout
sid 0be0aef4
getuscversion
Description Displays the current USC software version details in
iDRAC.
67
This option is applicable only for iDRAC.
Synopsis racadm getuscversion
Example $ racadm getuscversion
1.2.3.4
getversion
Description Displays the current software version, model and generation information, and whether or not the
target device can be updated.
To use this subcommand, you must have CMC Login User privilege.
Synopsis • racadm getversion [-b | -c] [-m <
module
>]
• racadm getversion -l [-m <
module
>] [-f <
filter
>]
• racadm getversion
Input •(none) - Displays the version information for all targets or devices.
•-m <
module
> - Specifies the module or device for which you want to retrieve the version
information.
<
module
> is one of the following:
server-nx where
n
=1-8 ;
x
= a,b,c,d
— cmc-n where n= 1 or 2. For example, cmc-2.
•-c - Displays the server's current CPLD version.
•-b - Displays the server's current BIOS version (default is iDRAC version).
•-l - Displays the firmware versions of available server components.
•-f <
filter
> - Filters the components. Must be used with -l and be one of the following values:
bios: BIOS
— idrac: iDRAC
— usc: Lifecycle Controller (Unified Server Configurator)
— diag: 32-bit Diagnostics
— drivers: OS Driver Package
– nic-x: Network Interface card. See -l output for possible values of x
— raid-x: Raid Controller. See -l output for possible values of x
NOTE: The -b, -c and -l options are not available for CMC modules.
NOTE: The -l option requires that the Lifecycle Controller service is enabled on the servers. For
version information, see the RACADM Readme available at support.dell.com/manuals.
Example •racadm getversion
•racadm getversion -f idrac
Example
racadm getversion -m server-15
<server> <iDRAC version> <model name> <Gen> <Updatable>
server-15 2.00(Build 10) PowerEdgeM605 iDRAC N
racadm getversion
68
<Server> <iDRAC Version> <Blade Type> <Gen> <Updatable>
server-2 1.50 PowerEdgeM600 iDRAC Y
server-3 2.10 PowerEdgeM610 iDRAC Y
server-4 1.50 PowerEdgeM605 iDRAC Y
<CMC> <CMC Version> <Updatable>
cmc-1 2.10.X06.200906
080825
Y
racadm getversion -c
<Server> <CPLD Version> <Blade Type>
server-1 PowerEdgeM600
server-2 PowerEdgeM805
server-5 1.0.0 PowerEdgeM710
racadm getversion -b
<Server> <BIOS Version> <Blade Type>
server-1 2.0.0 PowerEdgeM605
server-2 1.1.0 PowerEdgeM805
server-5 1.1.0 PowerEdgeM710
racadm getversion -l -m server-1
<Server> <Component> <Version> <Install Date>
server-1 BIOS 1.2.1 2010-11-22
iDRAC 3.20 2010-11-22
USC 1.5.0.667 2011-02-05
Diagnostics 5144A0 2011-02-07
OS Drivers 6.3.0.15 2010-11-22
Broadcom 5709
Emb(nic-1)
5.2.0 2011-02-02
Broadcom 5709
Emb(nic-1)
5.2.0 2011-02-02
Broadcom 5709
Emb(nic-1)
5.2.0 2011-02-02
69
Broadcom 5709
Emb(nic-1)
5.2.0 2011-02-02
PERC6 EMB (raid-2) 07.01.34.00 2011-02-02
BIOS 0.1.7 Rollback
BIOS 1.2.1 Reinstall
iDRAC 3.20 Reinstall
PERC6 Emb (raid-2) 07.01.33.00 Rollback
PERC6 Emb (raid-2) 07.01.33.00 Reinstall
racadm getversion -l -m server-1 -f bios
<Server> <Component> <Version> <Install Date>
server-1 BIOS 1.2.1 2010-11-22
hwinventory
Description Allows the user to display or export current internal hardware inventory or shipped
hardware inventory by device.
To use this subcommand, you must have Login privilege.
This subcommand is applicable for iDRAC only.
Synopsis •racadm hwinventory NIC
•racadm hwinventory NIC.Embedded.1-1-2
•racadm hwinventory NIC.Embedded.1-1-1 --stat -capa
Input
<FQDD | FQDD Alias>
- Specifies the FQDD or FQDD alias of the target device.
FQDD - NIC.Slot.1-2, CPU.Socket.1 or Disk.Virtual.0:RAID.Integrated.1.
Examples
To view all the NIC devices on managed server:
[SH7757 ~]$ racadm hwinventory NIC
NIC FQDD "NIC.Slot.5-2-1" Available
NIC FQDD "NIC.Slot.5-2-2" Available
NIC FQDD "NIC.Slot.5-2-3" Available
NIC FQDD "NIC.Slot.5-2-4" Available
NIC FQDD "NIC.Slot.5-1-1" Available
NIC FQDD "NIC.Slot.5-1-2" Available
NIC FQDD "NIC.Slot.5-1-3" Available
NIC FQDD "NIC.Slot.5-1-4" Available
To display the Standard hardware inventory verbose description for the FQDD NIC.Embedded.1-1-2
[SH7757 ~]$ racadm hwinventory NIC.Slot.5-2-2
Attributes for NIC FQDD NIC.Slot.5-2-2
Current MAC Address: B8:AC:6F:B3:BF:13
Vendor ID: 1077
Subvendor ID: 1028
Device ID: 8020
70
Subdevice ID: 045f
Perm ISCSI MAC Address:
Slot Type: b6
Data Bus Width: b
Slot Length: 4
Perm FCoE MAC Address:
PCI Bus: 3
PCI Device: 0
PCI Function: 0x0001
Update Time: 0x4d2920fe
Sync Time: 0x0000
Product Name: QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:1
Permanent MAC Address: B8:AC:6F:B3:BF:11
WWPN: ½.
Family Version: 0x00
Controller BIOS Version: 0x00
EFI Version: 0x00
Max Bandwidth: 0x64
Min Bandwidth: 0x00
Current Commit Index: 0x00
FCoE WWNN: 0x00
Vendor Name: 0x00
Ports Count: 0x00
Number PCIE Functions Supported: 0x00
Number PCIE Functions Enabled: 0x00
Link Duplex: 0x0
Link Speed: 0
Auto Negotiation: 0x0
Transmit Flow Control: 0x0
Receive Flow Control: 0x0
Media Type: 0
Status Flag: 0x0
Nic Mode: 1
FCoE Offload Mode: 0
iScsi Offload Mode: 0
reserved: 0x00
ifconfig
Description Displays the contents of the network interface table.
To use this subcommand, you must have Execute
Diagnostic Commands or Configure iDRAC permission.
Synopsis racadm ifconfig
71
Example $ racadm ifconfig
eth0 Link encap:Ethernet HWaddr
00:1D:09:FF:DA:23
inet addr:10.35.155.136
Bcast:10.35.155.255
Mask:255.255.255.0
UP BROADCAST RUNNING
MULTICAST MTU:1500
Metric:1
RX packets:2550665
errors:0 dropped:0 overruns:0
frame:0
TX packets:0 errors:0
dropped:0 overruns:0
carrier:0
collisions:0 txqueuelen:
1000
RX bytes:272532097
(259.9 MiB) TX bytes:0
(0.0 B)
krbkeytabupload
Description Uploads a Kerberos keytab file.
To use this subcommand, you must have Configure iDRAC
permission.
Synopsis racadm krbkeytabupload [-f <filename>]
<filename> is the name of the file
including the path.
Input -f — Specifies the file name of the keytab to be uploaded.
If the file is not specified, the keytab file in the current
directory is selected.
Output Returns 0 when successful and a non–zero number when
unsuccessful.
Example racadm krbkeytabupload -f c:\keytab
\krbkeytab.tab
72
lclog
Description Allows the user to export the lifecycle log history, and view the lifecycle log for a
particular device or category.
To use this subcommand, you must have Configure iDRAC permission.
This subcommand is applicable for iDRAC only.
NOTE: On Local RACADM, when you run this command, the data is exposed to
RACADM as a USB partition. This may display a pop up.
Synopsis racadm lclog view -i <nNumber of records>
-a <agent id> -c <category> -s <severity>
-b <sub-category> -q <sequence no.> -n <number of records>
-r <start timestamp> -e <end timestamp>
Input • -i — Displays the number of records present in the active log. You cannot use this
option with any other option.
• -a — The agent ID used to filter the records. Only one agent ID is accepted. The
value is case-insensitive. Valid Agent-ID values:
— UEFI_SS_USC
— CusOsUp
— UEFI_Inventory
— iDRAC
— UEFI_DCS
— SEL
— RACLOG
— DE
— WSMAN
— RACADM
— iDRAC_GUI
• -c — The category used to filter the records. Provide multiple categories using a
"," as the delimiter. The value is case-insensitive. Valid Category values:
— System
— Storage
— Worknotes
— Config
— Updates
— Audit
• -b - The subcategory used to filter the records. Provide multiple subcategories
using a as the delimiter.
• -q - The sequence number from which the records must be displayed.
• -n - Specifies the n Number of records to be displayed. On Local RACADM, if this
parameter is not specified, by default 100 logs are retrieved.
• -r - Displays events that have occurred after this time. The time format is yyyy-
mm-dd HH:MM:SS. The time stamp must be provided within double quotes.
• -e - Displays events that have occurred before this time. The time format is yyyy-
mm-dd HH:MM:SS. The time stamp must be provided within double quotes.
• -f <
filename
> - Specifies the file location and name where lifecycle log is
exported.
• -a <
name
> - Specifies the FTP Server IP address or FQDN, user name, and
password.
73
• -d <
path
> - Specifies the path to the file on the FTP server.
• -l <
location
> - Specifies the location of the network share or area on file system
where lifecycle log is exported. Two types of network shares are supported:
— SMB mounted path: //<
ipaddress or domain name
>/<
share_name
>/
<
path_to_image
>
— NFS mounted path: <
ipaddress
>:/<
path_to_image
>.
• -u <
user
> — Specifies the user name for accessing the FTP Server, or Domain
and User Name for accessing network share location.
• -p <
password
> — Specifies the password for accessing the FTP Server or Share
location.
• -s — The severity used to filter the records. Provide multiple severities using a ","
as the delimiter. The value is case-insensitive. Valid Severity values:
– 1. Warning
– 2. Critical
– 3. Info
• <
CATEGORY
>— Specifies the category of Lifecycle Log entries to view. Possible
values are
— all
— iDRAC
— Inventory
— ConfigurationService
— JobControl
— RemoteUpdate
— OsDeployment
— USC
— Other
• <
Comment
> — User comment string to be inserted in the Lifecycle Controller log
NOTE: To view or export the lifecycle log you need Login to iDRAC permission only.
Example • Display the number of records present in the Life Cycle Log:
racadm lclog view -i
• Display the records added by the iDRAC agent idrac, under the storage category
and storage physical disk subcategory, with severity set to warning:
racadm lclog view -a idrac -c storage -b pdr -s
warning
• Display the records under storage and system categories with severities set to
warning or critical:
racadm lclog view -c storage,system -s
warning,critical
• Display the records having severities set to warning or critical, starting from
sequence number 4:
racadm lclog view -s warning,critical -q 4
• Display 5 records starting from sequence number 20:
racadm lclog view -q 20 -n 5
• Display all records of events that have occurred between 2011-01-02 23:33:40 and
2011-01-03 00:32:15:
racadm lclog view -r "2011-01-02 23:33:40" -e
"2011-01-03 00:32:15"
74
• Display all the available records from the active Life Cycle Log:
racadm lclog view
license
Description Manages hardware licenses.
This subcommand is applicable for iDRAC only.
Synopsis •racadm license view
•racadm license view [-c <component>]
•racadm license import [-f <licensefile>] -
l<location> -c <component>
•racadm license export [-f <license file>] -e <ID> -
c <component>
•racadm license delete -e <ID> -l <location> [-f] -c
<component> -t <transaction ID>
•racadm license delete -t <transaction ID>
•racadm license delete -e <entitlement ID>
•racadm license delete -c <component>
•racadm license replace -t 1
•racadm license replace -u <username>-p <password> -f
<license file name> -l <NFS/CIFS share> -t
<transaction ID>
Input •view — View license information.
•import — Installs a new license.
• export — Exports a license file.
• delete — Deletes a license from the system.
• replace — Replaces an older license with the given license file.
• -l <
remote share location
> — Network share location from where the license
file must be imported.
If the file is on a share, then -u <
share user
> and -p <
share password
> must be
used.
• -f — Filename or path to the license file
• -e <
ID
> — Specifies the entitlement ID of the license file to be exported
• -t<
ID
> — Specifies the transaction ID.
• -c<
component
> — Specifies the component name on which the license is
installed.
• -o — Overides the End User License Agreement (EULA) warning and imports,
replaces or deletes the license.
NOTE: License operations the .<licensefile> name should be less then 56
Characters.
NOTE: During Remote file share, SSH/telnet supports Import and Export options.
75
NOTE: Only a user with Administrator privileges can use the import, export, delete,
and replace commands. You do not need Administrator privileges to use the view
command.
Examples
• View All License Information on System
$racadm license view
iDRAC.Embedded.1
Status = OK
Device = iDRAC.Embedded.1
Device Description = iDRAC
Unique Identifier =
License #1
Status = OK
Transaction ID = 2
License Description = iDRAC
Enterprise Evaluation License
License Type = EVALUATION
Entitlement ID = mDmiPm4dVTPFMB34r2axrNwL
Expiration = 2011-11-04T22:00:00
• Import a new license to a specific device in a known location
$racadm license import -f license.xml -l //shareip/sharename
-u <share user> -p <share user password> -c idrac.embedded.1
• Import a license from a CIFS share to a device, in this case Embedded iDRAC:
racadm license import -u admin -p passwd -f License.xml
-l //192.168.2.140/licshare -c idrac.embedded.1
• Import a license from NFS share to a device, in this case Embedded iDrac:
racadm license import -f Licen.xml -l 192.168.2.14:/share
-c idrac.embedded.1
• Import a license by overriding the EULA warning:
racadm license import -u admin -p passwd -f License.xml
-l //192.168.2.140/licshare -c idrac.embedded.1 -o
• Import a license from the local filesystem using Local RACADM:
racadm license import -f License.xml -c idrac.embedded.1
• Import a license from the local filesystem using Remote RACADM:
racadm license import -f C:\Mylicdir\License.xml -c
idrac.embedded.1
• Export a license file.
racadm license export -f <filename> -l <share location>
-u <share username> -p <share password> -c iDRAC.Embedded.1
Instead of -c, you can use -e <
ID
> OR -t <
ID
>
For remote racadm, if filename is not specified, the file(s) are exported to the directory where RACADM is
running.
76
• Export license to a NFS share using transaction ID, in this case transaction 27 :
racadm license export -f License.xml -l 192.168.2.140:/licshare
-t 27
• Export license to a CIFS share specifying the entitlement ID, in this case abcdxyz :
racadm license export -u admin -p passwd -f License.xml
-l //192.168.2.140/licshare -e abcdxyz
• Export license to a CIFS share specifying the FQDD. While using the -c option and exporting license(s) from a
device, more than one license file may be exported. Therefore if a file name is given, an index is appended to the
end of the file name such as LicenseFile0.xml, LicenseFile1.xml and so on. In this case, the device is Embedded
iDrac :
racadm license export -u root -p calvin -f LicenseFile.xml
-l //192.168.2.140/licshare -c idrac.embedded.1
• Delete a license:
$racadm license delete -e B9865F23455DC458
• Delete all licenses installed on a particular device:
$racadm license delete -c idrac.embedded.1
• Delete licenses on a particular device, in this case Embedded iDRAC:
racadm license delete -c idrac.embedded.1
• Delete license using entitlement ID, in this case xYZabcdefg:
racadm license delete -e xYZabcdefg
• Delete license using transcation ID, in this case 2:
racadm license delete -t 2
• Replace license on a device with a license file on an NFS share using transaction ID. In this case, transaction
27:
racadm license replace -f License.xml -l 192.168.2.140:/licshare
-t 27
• Replace license on a device with a license file on an CIFS share using transaction ID. In this case, transaction
27:
racadm license replace -u admin -p passwd -f License.xml
-l //192.168.2.140/licshare -t 27
netstat
Description Displays the routing table and the current connections.
To use this subcommand, you must have Execute
Diagnostic Commands permission.
Synopsis racadm netstat
nicstatistics
Description Displays the statistics for the NIC FQDD in question. FQDD maps to the NIC object keys
which racadm uses while calling the Data Manager APIs NIC objects.
This subcommand is applicable for iDRAC only.
Synopsis •racadm nicstatistics
•racadm nicstatistics <NIC FQDD>
•racadm hwinventory NIC.Integrated.1-1
77
Examples
• Displays the statistics for the NIC FQDD.
$racadm nicstatistics <NIC FQDD>
• Displays the statistics for the integrated NIC.
$ racadm nicstatistics NIC.Integrated.1-1
Total Bytes Received:0
Total Bytes Transmitted: 0
Total Unicast Bytes Received: 0
Total Multicast Bytes Received: 0
Total Broadcast Bytes Received: 0
Total Unicast Bytes Transmitted: 0
• Get the network statistics
$ racadm nicstatistics
NIC.Slot.5-2-1 : QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:10
NIC.Slot.5-2-1 : QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:11
NIC.Slot.5-2-1 : QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:12
NIC.Slot.5-2-1 : QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:13
NIC.Slot.5-2-1 : QLogic CNA Gigabit Ethernet-B8:AC:6F:B3:BF:14
ping
Description Verifies that the destination IP address is reachable from
iDRAC with the current routing-table contents. A
destination IP address is required. An ICMP echo packet
is sent to the destination IP address based on the current
routing-table contents.
To use this subcommand, you must have Execute
Diagnostic Commands or Configure iDRAC permission.
Synopsis racadm ping <ipaddress>
ping6
Description Verifies that the destination IPv6 address is reachable
from iDRAC or CMC or with the current routing-table
contents. A destination IPv6 address is required. An ICMP
echo packet is sent to the destination IPv6 address based
on the current routing-table contents.
To use this subcommand for CMC you must have
Administrator privilege for CMC and for iDRAC you must
have Execute Diagnostic Commands or Configure iDRAC
permission.
Synopsis racadm ping6 <ipv6address>
78
Example racadm iping6 10.9.72.254
IPING6 10.9.72.254 (10.9.72.254): 56
data bytes
64 bytes from 10.9.72.254: icmp_seq=0
ttl=121 time=2.9
ms
--- 10.9.72.254 ping statistics ---
1 packets transmitted, 1 packets
received, 0 percent
packet loss
round-trip min/avg/max = 2.9/2.9/2.9 ms
racdump
Description Provides a single command to get dump, status, and
general iDRAC board information.
For CMC, this subcommand displays the comprehensive
chassis status and configuration state information, as well
as historic event logs. Used for post deployment
configuration verification and during debugging sessions.
To use this subcommand for CMC you must have
Administrator privilege and for iDRAC you must have
Debug permission.
Synopsis racadm racdump
Input Racdump includes the following subsystems and
aggregates the following RACADM commands:
• General System/RAC information - getsysinfo
• Session information - getssinfo
• Sensor information - getsensorinfo
• Switches information (IO Module) - getioinfo
• Mezzanine card information (Daughter card) -
getdcinfo
• All modules information - getmodinfo
• Power budget information - getpbinfo
• KVM information - getkvminfo
• NIC information (CMC module) - getniccfg
• Redundancy information - getredundancymode
• Trace log information - gettracelog
• RAC event log - getraclog
• System event log - getsel
Output The following information is displayed when the racdump
subcommand is processed:
• General system/RAC information
• Coredump
• Session information
79
• Process information
• Firmware build information
Example
Example
racadm racdump
===============================================================================
General System/RAC Information
===============================================================================
CMC Information:
CMC Date/Time = Wed, 28 Nov 2007 11:55:49 PM
Active CMC Version = X08
Standby CMC Version = N/A
Last Firmware Update = Wed Nov 21 21:37:56 2007
Hardware Version = 2
Current IP Address = 10.35.155.160
Current IP Gateway = 10.35.155.1
Current IP Netmask = 255.255.255.0
DHCP Enabled = 1
MAC Address = 00:55:AB:39:10:0F
Current DNS Server 1 = 0.0.0.0
Current DNS Server 2 = 0.0.0.0
DNS Servers from DHCP = 0
Register DNS CMC Name = 0
DNS CMC Name = cmc-servicetag
Current DNS Domain =
Chassis Information:
System Model = PowerEdgeM1000eControlPanel
System AssetTag = 00000
Service Tag =
Chassis Name = Dell Rack System
Chassis Location = [UNDEFINED]
Power Status = ON
===============================================================================
Session Information
===============================================================================
Type User IP Address Login Date/Time
SSH root 10.9.72.252 11/28/2007 23:40:53
KVM root 169.254.31.30 11/28/2007 18:44:51
===============================================================================
Sensor Information
===============================================================================
<senType> <Num> <sensorName> <status> <reading> <units> <lc>
<uc>
FanSpeed 1 Fan-1 OK 14495 rpm 7250 14500
FanSpeed 2 Fan-2 OK 14505 rpm 7250 14500
FanSpeed 3 Fan-3 OK 4839 rpm 2344 14500
FanSpeed 4 Fan-4 OK 14527 rpm 7250 14500
FanSpeed 5 Fan-5 OK 14505 rpm 7250 14500
FanSpeed 6 Fan-6 OK 4835 rpm 2344 14500
FanSpeed 7 Fan-7 OK 14521 rpm 7250 14500
80
FanSpeed 8 Fan-8 Not OK 1 rpm 7250 14500
FanSpeed 9 Fan-9 OK 4826 rpm 2344 14500
<senType> <Num> <sensorName> <status> <reading> <units> <lc>
<uc>
Temp 1 Ambient_Temp OK 21 celcius N/A 40
<senType> <Num> <sensorName> <status> <AC-OK status>
PWR 1 PS-1 Online OK
PWR 2 PS-2 Online OK
PWR 3 PS-3 Online OK
PWR 4 PS-4 Slot Empty N/A
PWR 5 PS-5 Failed OK
PWR 6 PS-6 Slot Empty N/A
racreset
Description Issues a reset to iDRAC. The reset event is written into
iDRAC log.
To use this subcommand for CMC you must have Chassis
Administrator privilege and for iDRAC you must have
Configure iDRAC permission.
NOTE: When you issue a racreset subcommand,
iDRAC may require up to two minutes to return to a
usable state.
NOTE: You must reboot your system after performing a
hard reset of iDRAC.
Synopsis racadm racreset [hard | soft]
Input •hard - A hard reset performs a deep reset
operation on the remote access controller. A hard
reset should only be used as a last case resort of
resetting iDRAC controller for recovery purposes.
•soft - A soft reset performs a graceful reboot
operation on the RAC.
Output • racadm racreset
RAC reset operation initiated successfully. It may take up
to a minute for the RAC to come online again."
• racadm racresetcfg -
The RAC configuration has initiated
restoration to factory
defaults. Please wait for a minute for
this process to complete
before accessing the RAC again.
Example • Start the iDRAC soft reset sequence.
racadm racreset
• Start the iDRAC hard reset sequence.
racadm racreset hard
81
racresetcfg
Description This subcommand is applicable for iDRAC only.
Deletes your current iDRAC configuration and resets iDRAC and serial configuration to
the default settings. After reset, the default name and password is root and calvin,
respectively, and the IP address is 192.168.0.120. Only for iDRAC Enterprise on Blade
servers, it is IP address plus the number of the slot the server inhabits in the chassis. If
you issue racresetcfg from a network client (for example, a supported Web browser,
Telnet/ssh, or remote RACADM), you must use the default IP address. The racresetcfg
subcommand does not reset the cfgDNSRacName object.
To use this subcommand, you must have Configure iDRAC permission.
NOTE: Certain iDRAC firmware processes need to be stopped and restarted for reset
to defaults to complete. iDRAC becomes unresponsive for about 30 seconds while this
operation completes
Synopsis •racadm racresetcfg
•racadm racresetcfg -f
Input CMC Only Options
• -m <
module
> - Specifies the device to reset the configuration on <
module
>.
<
module
> must be one of the following values:
— chassis : default state if -m is not specified
server-nx where
n
=1-8 ;
x
= a,b,c,d
— kvm
iDRAC Only Options
• -f — Force resetcfg. If any VFlash partition creation or formatting is in progress
when this command is issued, iDRAC sends back a warning message indicating
the same. You can perform a force reset using this option.
Example • Reset the configuration on iDRAC
racadm racresetcfg
The RAC configuration has initiated restoration to factory defaults.
Please wait up to a minute for this process to complete before accessing the RAC
again.
• Reset the KVM configuration on CMC
racadm racresetcfg -m kvm
The configuration has initiated restoration to factory defaults.
• Reset blade 8 configuration from CMC
racadm racresetcfg -m server-8
The RAC configuration has initiated restoration to factory defaults.
Please wait up to a minute for this process to complete before accessing the RAC
again.
• Reset when vFlash Partition creation is in progress
racadm racresetcfg
A vFlash SD card partition operation is in progress. Resetting the iDRAC may
corrupt the vFlash SD card. Use -f flag to force racresetcfg.
82
raid
Description Allows you to execute commands to control RAID arrays.
To use this subcommand for CMC you must have Chassis Administartor privilege and for iDRAC
you must have Configure iDRAC permission.
Synopsis racadm raid
Example
• Monitor Health of Storage root node
racadm raid get status
Storage Root Node Status : Ok
The above command retrieves the controllers keys, (FQDDs.)
• Monitor and Inventory all Controllers connected to the server
racadm raid get controllers
racadm raid get controllers -o
The above command is an optimized version and displays the full controller objects along with their keys.
racadm raid get controllers -o -p <property names separated by comma>
The above command displays the filtered property values for all returned controller objects.
• Monitor and Inventory all batteries connected to the controller
racadm raid get batteries --refkey <controller FQDDs
separated by comma>
The above command displays all battery keys connected to the controllers referred as refkeys.
racadm raid get batteries --refkey <controller FQDD's
separated by comma > -o
The above command is an optimized version and displays all battery objects for the controller FQDD.
racadm raid get batteries --refkey <controller FQDD's
separated by comma > -o -p <property names separated by comma>
The above command is an optimized and filtered version.
racadm raid get batteries --refkey <controller FQDD's
separated by comma > -o -p <property names separated by comma>
• Monitor and Inventory all virtual disks connected to the controller
racadm raid get vdisks --refkey <controller FQDDs
separated by comma>
The above command displays all vdisk keys connected to the controllers being mentioned as refkeys.
racadm raid get vdisks --refkey <controller FQDDs
separated by comma > -o
The above command is an optimized version and displays all vdisk objects for the controller FQDD.
racadm raid get <controller > -pending
Raid.Integrated.1-1
Raid.Slot.2-1
83
• Monitor and Inventory all storage enclosures connected to the connector
racadm raid get enclosures --refkey <connector FQDDs
separated by comma>
The above command displays all enclosure keys connected to the connectors being mentioned as refkeys.
racadm raid get enclosures --refkey <connector FQDDs
separated by comma > -o optimized version.
The above command displays all enclosure objects for the connector FQDD.
racadm raid get enclosures --refkey <connector FQDD's
separated by comma > -o -p <property names separated by comma>
The above command is an optimized and filtered version.
• Monitor and Inventory all Physical Disks connected to the enclosure /Backplanes
racadm raid get pdisks --refkey <enclosure/Backplane
FQDDs separated by comma>
The above command displays all physical disk keys connected to the enclosures being mentioned as refkeys.
racadm raid get pdiks --refkey <enclosure/Backplanes
FQDDs separated by comma > -o
The above command is an optimized version and displays all disk objects for the enclosure FQDD.
racadm raid get pdisks --refkey <enclosure/Backplanes
FQDDs separated by comma > -o -p <property names separated by comma>
optimized and filtered version.
• Monitor and Inventory all Fans connected to the enclosure
racadm raid get fans --refkey <enclosure FQDDs separated
by comma>
The above command displays all fan keys connected to the enclosures referred as refkeys.
racadm raid get fans --refkey <enclosure FQDDs separated
by comma > -o optimized version.
The above command displays all fan objects for the enclosure FQDD.
racadm raid get fans --refkey <enclosure FQDDs separated
by comma > -o -p <property names separated by comma> optimized and
filtered version.
• Monitor and Inventory all EMMs connected to the enclosure
racadm raid get emms -refkeys <enclosure FQDDs separated
by comma>
The above command will return all EMM keys connected to the enclosures being mentioned as refkeys.
racadm raid get emms -refkeys <enclosure FQDDs separated
by comma > -o
The above command is an optimized version and displays all EMM objects for the enclosure FQDD.
racadm raid get emms -refkeys <enclosure FQDDs separated
by comma > -o -p <property names separated by comma>
The above command is an optimized and filtered version.
• Monitor and Inventory all Temperature Probes connected to the enclosure
racadm raid get tempprobes -refkeys <enclosure FQDDs
separated by comma>
84
The above command displays all temperature probe keys connected to the enclosures being mentioned as
refkeys.
racadm raid get tempprobes -refkeys <enclosure FQDDs
separated by comma > -o
The above command is an optimized version and displays all temperature probe objects for the enclosure FQDD.
racadm raid get tempprobes -refkeys <enclosure FQDDs
separated by comma > -o -p <property names separated by comma>
optimized and filtered version
• Monitor and Inventory all Power Supply Units connected to the enclosure
racadm raid get psus --refkey <enclosure FQDD's separated
by comma>
The above command displays all power supply units connected to the enclosures being mentioned as refkeys.
racadm raid get psus --refkey <enclosure FQDD's separated
by comma > -o
The above command is an optimized version and displays all power supply units objects for the enclosure FQDD.
racadm raid get psus --refkey <enclosure FQDD's separated
by comma > -o -p <property names separated by comma>
The above command is an optimized and filtered version.
remoteimage
Description Connects, disconnects, or deploys a media file on a remote server.
To use this subcommand, you must have Administrator permission.
Synopsis racadm remoteimage <options>
Input •-c - Connect the image.
•-d - Disconnect image.
•-u - Username to access the network share.
•-p - Password to access the network share.
•-l - Image location on the network share; use double quotes around the location.
•-s - Display current status; –a is assumed if not specified.
Example •racadm remoteimage -c -u "user" -p "pass" -l //shrloc/
foo.iso
Remote Image is now Configured
•racadm remoteimage -d - disconnect
Disable Remote File Started. Please check status using -s option to know Remote
File Share is ENABLED or DISABLED.
•racadm remoteimage -s - status
Remote File Share is Enabled
UserName
Password
ShareName //10.94.161.112/xxxx/dtk_3.3_73_Linux.iso
85
serveraction
Description Enables users to perform power management operations on the host system.
To use this subcommand, you must have Execute Server Control Commands permission.
Synopsis racadm serveraction <action>
Input • -m <
module
> -
server-nx where
n
=1-8 ;
x
= a,b,c,d
• -a - Performs action on all servers. Not allowed with the powerstatus action.
• -f - Force the action. Required for the reseat action.
• <
action
>- Specifies the action. The options for the <
action
> string are:
— graceshutdown — Performs a graceful shutdown of the server. If the operating system
on the server cannot be shutdown cleanly, then this operation will not be performed.
— hardreset — Performs a reset (reboot) operation on the managed system.
— powercycle — Issues a power-cycle operation on the managed system. This action is
similar to pressing the power button on the system’s front panel to power down and then
power up the system.
— powerdown — Powers down the managed system.
— powerup — Powers up the managed system.
— powerstatus — Displays the current power status of the server (ON or OFF).
— reseat — Performs virtual reseat of the server. This operation simulates reseating the
blade by resetting the iDRAC on that blade.
NOTE: The action powerstatus is not allowed with -a option.
Output Displays an error message if the requested operation fails, or a success message if the operation is
completed.
Example • Power Down Blade 16 from the CMC
racadm serveraction -m server-16 powerdown
Server power operation successful
• Power Down Blade from iDRAC
racadm serveraction powerdown
Server power operation successful
• Power Down Blade 16 from CMC when Power is already Off on that blade
racadm serveraction -m server-16 powerdown
Server is already powered OFF.
• Power Down Blade from iDRAC when Power is already off on that blade.
racadm serveraction powerdown
Server is already powered OFF
• Get Power Status of blade 16 on CMC
racadm serveraction -m server-16 powerstatus
ON
• Get Power Status on iDRAC
racadm serveraction powerstatus
Server Power Status: ON
• Reseat blade 2 on CMC
$ racadm serveraction -m server-2 reseat -f
86
Server power operation successful
• Explanation of Support
iDRAC Needs to support graceful shutdown
The support of address individual blades is expected on the CMC
set
Description Allows the user to set the value of configuration objects on a device.
To use this subcommand, you must have Configure privilege.
This subcommand is applicable for iDRAC only.
Synopsis •racadm set -f <filename>
•racadm set <FQDD|FQDD Alias>[.<index>][.<group>][.<index>]
[.<object>] <value>
Input • <
FQDD | FQDD Alias
• <
group
> — Specifies the group containing the object that is to be written.
• <
object
> — Specifies the object name of the value to be written.
• <
index
> — This is specified where FQDDs, FQDD Alias' or Groups need to be indexed.
• -f <
filename
> — This option enables set to configure the device from a file specified by
<
filename
>. This option is not supported in the Firmware RACADM interface.-
Output • Object value modified successfully
• Failure message indicating reason for failure.
Example • Configure the iDRAC using a file
$ racadm set -f myrac.cf
g
• Configure LCD String
$ racadm set system.lcd.LCDUserString test
Object value modified successfully
setassettag
Description Sets the N-byte ASCII asset tag for the chassis.
To use this subcommand, you must have Administrator privilege.
Synopsis racadm setassettag -m chassis <asset tag>
Input -m <
module
> — Specifies the module whose asset tag you want to set.
Legal value: chassis
You can obtain the same output if you do not include this option, as there is only one legal
value.
<
assettag
> is a maximum of 64 non-extended ASCII characters.
Example •racadm setassettag -m chassis 783839–33
87
•racadm setassettag 783839–33
The asset tag was changed successfully.
setchassisname
Description Sets the name of the chassis in the LCD.
To use this subcommand, you must have Administrator
privilege.
Synopsis racadm setchassisname <name>
NOTE: Chassisname is a maximum of 64 non-extended
ASCII characters.
Example racadm setchassisname dellchassis-1
The chassis name was set successfully.
setflexaddr
Description Enables/disables FlexAddress on a particular slot/fabric.
To use this subcommand, you must have Chassis Configuration Administrator privilege.
If the fabric type is determined to be Infiniband, the operation is canceled and the
command returns an error. If the FlexAddress feature is not activated, the command
returns an error.
NOTE: The server must be powered off to change the slot state. All servers must be
powered off to change the fabric state. The MAC/WWN addresses must be managed
locally (not by an external console) to use this command.
Synopsis racadm setflexaddr [-i <slot#> <state>]
[-f <fabricName> <state>]
<
slot#
> = 1 to 16
<
fabricName
> = A, B, C
<
state
> = 0 or 1
where 0 is disable and 1 is enable.
Input • -i <
slot#
> <
state
> — Enables/disables FlexAddress for the specified slot.
• -f <
fabricName
> <
state
> — Enables/disables FlexAddress for the specified fabric.
Example •racadm setflexaddr -i 1 0
Slot 1 FlexAddress state set successfully
•racadm setflexaddr -f A 1
Fabric A FlexAddress state set successfully
•racadm setflexaddr -f idrac 1
88
setled
Description Sets the state (blinking or not blinking) of the LED on the specified module.
To blink or unblink the chassis, I/O modules or the CMC, you must have Debug Administrator
privilege on CMC. To enable the servers to blink or unblink, you must have Server Administrator
or Debug Administrator privilege on CMC. To use this subcommand for iDRAC, you must have
Configure iDRAC permission.
Synopsis For iDRAC:
racadm setled -l <ledState>
For CMC:
racadm setled -m <module> -l <ledState>
Input • -m <
module
> - Specifies the module whose LED you want to configure.
<
module
> can be one of the following:
— server-nx where
n
=1-8 ;
x
= a,b,c,d
— switch-n where n=1–6
— cmc-active
— chassis
This option is applicable for CMC only.
• -l <
ledstate
> - Specifies whether the LED should blink.
<
ledstate
> can be one of the following:
– 0 — no blinking
– 1 — blinking
Example For CMC:
• racadm setled -m server-1 -1 1
LED state was set successfully.
NOTE: The setled command generates an error when used on the extension slot of a multi-
slot server.
• racadm setled -m server-9 -1 1
ERROR: Server in slot 9 is an extension of the server in slot 1.
For iDRAC:
racadm setled -l 1
LED state was set successfully.
89
setniccfg
Description Sets the iDRAC IP address. It displays an error message if the requested operation
could not be performed, or a success message if the operation is completed
successfully.
To use this subcommand, you must have Configure iDRAC permission.
NOTE: The terms NIC and Ethernet management port may be used interchangeably.
Synopsis •racadm setniccfg -d
•racadm setniccfg -d6
•racadm setniccfg -s <IPv4Address> <netmask> <IPv4
gateway>
•racadm setniccfg -s6 <IPv6 Address> <IPv6 Prefix
Length> <IPv6 Gateway>
•racadm setniccfg -o
Input • -d — Enables DHCP for the NIC (default is DHCP disabled.)
• -d6 — Enables AutoConfig for the NIC. It is enabled by default.
• -s — Enables static IP settings. The IPv4 address, netmask, and gateway can
be specified. Otherwise, the existing static settings are used. <
IPv4Address
>,
<
netmask
>, and <
gateway
> must be typed as dot-separated strings.
racadm setniccfg -s 192.168.0.120 255.255.255.0 192.168.0.1
• -s6 — Enables static IPv6 settings. The IPv6 address, Prefix Length, and the
IPv6 Gateway can be specified.
• -o — Enable or disable NIC.
Example •racadm setniccfg -s 192.168.0.120 255.255.255.0
192.168.0.1
•racadm setniccfg -d
•racadm setniccfg -d6
setractime
Description Sets the date and time on the CMC.
To use this subcommand, you must have Administrator
privilege.
This command is applicable only for CMC.
Synopsis • racadm setractime -d
<
yyyymmddhhmmss.mmmmmmsoff
>
• racadm setractime -l YYYYMMDDhhmmss
• racadm setractime -z {?|timezone|timezone-
prefix*}
Input • -d — Sets the time in the string
yyyymmddhhmmss.mmmmmmsoff where:
yyyy is the year
90
— mm is the month
— dd is the day
— hh is the hour
— mm is the minutes
— ss is the seconds
— mmmmmm is the number of microseconds
— s is a + (plus) sign or a - (minus) sign, which
indicates the sign of the offset
— off is the offset in minutes
NOTE: The off is the offset in minutes from GMT and
must be in 15-minute increments. The timezone is
represented as an offset from GMT, and the clock
does not automatically adjust to daylight savings time
(for '-d' option).
• -z <
zone
> - Sets the time zone by name or index,
or lists possible time zones. For example,
PST8PDT (Western United States), 294 (Seoul),
344 (Sydney). <
zone
> may be:
— <
?
> lists the major timezone names/prefixes
— <
timezone
> is the case-sensitive name of your
timezone or the index listed by '-z timezone-
prefix*'.
— <
timezone-prefix*
> is a prefix of one or more
timezones, followed by '*'.
NOTE: The timezone/daylight savings time is fully
supported for '-l' and '-z' options. Omit the '-l' option to
set the timezone only (eg. '-z US/Central').
• -l — Sets the local date and time in the string
yyymmddhhmmss where:
— yyyy is a the year
— mm is the month
— dd is the day
— hh is the hour
— mm is the minute
— ss is the second
— Setting the time using the -l and -z options is
recommended. This command format allows the
CMC to fully support local time zones, including
the ability to automatically adjust the CMC time to
the local Daylight Savings Time.
Example The setractime subcommand supports dates ranging from
1/1/1970 00:00:00 through 12/31/2030 23:59:59. To set the
local time to October 24, 2007 at 3:02:30 PM:
racadm setractime -l 20071024150230
The time was set successfully.
91
setslotname
Description Displays the name and hostname (if available) of all 16
slots, or of a specified slot (indicated by the slot number)
in the chassis. Optionally, this command can be used to
set whether the slot name or hostname is displayed in the
CMC User Interface or with the getslotname -i <
slot ID
>
command. If the hostname is not available, the static slot
name is used.
To use this subcommand, you must have Administrator
privilege.
For rules for selecting slot names, see the "Editing Slot
Names" section in the
Dell Chassis Management
Controller User Guide
.
NOTE: The OMSA server agent must be present and
running on the server to use the Display Hostname
feature. If the agent is not running, the setting is
ignored. For more information, see the
Dell
OpenManage Server Administrator User's Guide
at
support.dell.com/manuals.
Synopsis racadm setslotname -i <slotID>
<slotname>
racadm setslotname -h <enabled>
Input • <
slotID
> — Displays the location of the slot in the
chassis.
Legal values: 1–16
• <
slotname
> — The new name to be assigned to
the slot.
• <
enabled
> — Sets whether the server's hostname
is used for display purposes.
Legal values: 0, 1
Example racadm setslotname -i 3 mserver3
The slot name was set successfully.
setsysinfo
Description Sets the name or location of the chassis.
To use this subcommand, you must have Administrator
privilege.
This command is applicable only for CMC.
Synopsis racadm setsysinfo [-c chassisname|
chassislocation]
<string>
Input • <
string
> — Indicates a maximum of 64 non-
extended ASCII chassis name or location.
92
•-c — Sets the chassis name or location.
Example racadm setsysinfo -c chassisname "Dell
Rack System"
The chassis name was set successfully.
sshpkauth
Description Enables you to upload and manage up to 4 different SSH
public keys per user. You can upload a key file or key text,
view keys, or delete keys.
This command has three mutually exclusive modes—
upload, view, and delete that are determined by the
options.
Upload
The upload mode allows you to upload a keyfile or to copy
the key text on the command line. You cannot upload and
copy a key at the same time.
Local and Remote RACADM:
racadm sshpkauth -i <2 to 16> -k <1 to
4> -f <filename>
racadm sshpkauth -i <2 to 16> -k <1 to
4> -t
<key-text>
Telnet/ssh/serial RACADM:
racadm sshpkauth -i <2 to 16> -k <1 to
4> -t
<key-text>
View
The view mode allows the user to view a key specified by
the user or all keys.
racadm sshpkauth -i <2 to 16> -v -k <1
to 4>
racadm sshpkauth -i <2 to 16> -v -k all
Delete
The delete mode allows the user to delete a key specified
by the user or all keys.
racadm sshpkauth -i <2 to 16> -d -k <1
to 4>
racadm sshpkauth -i <2 to 16> -d -k all
Synopsis racadm sshpkauth
Input •-i <
user index
> - Index for the user. <
user index
>
must be between 2 to 16 on iDRAC.
•-k [<
key index
> | all] - Index to assign the PK key
being uploaded.
all
only works with the -v or -d
93
options. <
key index
> must be between 1 to 4 or
all
on iDRAC.
•-t <
PK Key Text
> - Key text for the SSH Public key.
•-f <
filename
> - File containing the key text to
upload. The -f option is not supported on
Telnet/ssh/serial RACADM.
•-v - View the key text for the index provided.
•-d - Delete the key for the index provided.
Examples
Upload an invalid key to iDRAC User 2 in the first key space using a string:
$ racadm sshpkauth -i 2 -k 1 -t "This is invalid key
Text"
ERROR: Key text appears to be corrupt
Upload a valid key to iDRAC User 2 in the first key space using a file:
$ racadm sshpkauth -i 2 -k 1 -f pkkey.key
Key file successfully uploaded.
Get all keys for User 2 on iDRAC:
$ racadm sshpkauth -v -i 2 -k all
********************* User ID 2 ******************
Key ID 1:
ssh-rsa AAAAB3NzaC1yc2EAAAABIwAAAIEAzzy+k2npnKqVEXGXIzo0sbR6JgA5YNbWs3ekoxXV
fe3yJVpVc/5zrrr7XrwKbJAJTqSw8Dg3iR4n3vUaP
+lPHmUv5Mn55Ea6LHUslAXFqXmOdlThd
wilU2VLw/iRH1ZymUFnut8ggbPQgqV2L8bsUaMqb5PooIIvV6hy4isCNJU=
1024-bit RSA, converted from OpenSSH by xx_xx@xx.xx
Key ID 2:
Key ID 3:
Key ID 4:
sslcertdownload
Description Downloads an SSL certificate from iDRAC to the client’s
file system.
To use this subcommand, you must have Configure iDRAC
permission.
Synopsis racadm sslcertdownload -t <type> [-f
<filename>]
Input •-t — Specifies the type of certificate to download,
either the CA certificate for Directory Service or
the server certificate.
1 = server certificate
2 = CA certificate for Directory Service
94
•-f — Specifies the file name of the certificate to
be downloaded.
Output Returns 0 when successful and a nonzero number when
unsuccessful.
Example racadm sslcertdownload -t 1 -f c:\cert
\cert.txt
sslcertupload
Description Uploads a custom SSL server or CA certificate for
Directory Service from the client to iDRAC.
To use this subcommand, you must have Configure iDRAC
permission.
Synopsis racadm sslcertupload -t <type> [-f
<filename>]
Input • -t — Specifies the type of certificate to upload,
either the CA certificate for Directory Service or
the server certificate.
— 1 = server certificate
— 2 = CA certificate for Directory Service
• -f — Specifies the file name of the certificate to
be uploaded.
• -e — Allows for upload of multiple certificate
format types.
– 1 = Base64
– 2 = PKCS12
The current release does not support this option.
• -p — Pin for decrypting the PKCS12 file uploaded.
If <
format type
> is selected as 2 it is mandatory to
specify -p option.
The current release does not support this option.
Output The sslcertupload command returns 0 when successful
and returns a nonzero number when unsuccessful.
Example racadm sslcertupload -t 1 -f c:\cert
\cert.txt
sslcertview
Description Displays the SSL server or CA certificate that exists on iDRAC.
To use this subcommand, you must have iDRAC Login Privilege.
Synopsis racadm sslcertview -t <type> [-A]
Input • -t - Specifies the type of certificate to view, either the CA certificate or server
certificate.
—1 = server certificate
95
—2 = CA certificate for Directory Service
•-A — Prevents printing headers/labels.
Output
racadm sslcertview -t 1
Serial Number 00
Subject Information:
Country Code (CC) US
State (S) Texas
Locality (L) Round Rock
Organization (O) Dell Inc.
Organizational Unit
(OU)
Remote Access Group
Common Name (CN) iDRAC Default certificate
Issuer Information:
Country Code (CC) US
State (S) Texas
Locality (L) Round Rock
Organization (O) Dell Inc.
Organizational Unit
(OU)
Remote Access Group
Common Name (CN) iDRAC Default certificate
Common Name (CN) iDRAC Default certificate
Valid From Jul 8 16:21:56 2005 GMT
Valid To Jul 7 16:21:56 2010 GMT
96
racadm sslcertview -t 1 -A
00
US
Texas
Round Rock
Dell Inc.
Remote Access Group
iDRAC default certificate
US
Texas
Round Rock
Dell Inc.
Remote Access Group
iDRAC default certificate
Jul 8 16:21:56 2005 GMT
Jul 7 16:21:56 2010 GMT
sslcsrgen
Description Generates and downloads a CSR file to the client’s local
file system. The CSR can be used for creating a custom
SSL certificate that can be used for SSL transactions on
iDRAC.
To use this subcommand, you must have Configure iDRAC
permission.
Synopsis racadm sslcsrgen [-g] [-f <filename>]
racadm sslcsrgen -s
Input •-g — Generates a new CSR.
•-s — Returns the status of a CSR generation
process (generation in progress, active, or none).
•-f — Specifies the filename of the location,
<
filename
>, where the CSR is downloaded.
•-t — Specifies the type of certificate to view,
either the CA certificate or server certificate.
— 1 = webserver CSR — Enables you to generate
a CSR for the webcertificate server certificate.
NOTE: If the -f option is not specified, the filename
defaults to sslcsr in your current directory.
Output If no options are specified, a CSR is generated and
downloaded to the local file system as sslcsr by default.
The -g option cannot be used with the -s option, and the -f
option can only be used with the -g option.
97
The sslcsrgen -s subcommand returns one of the
following status codes:
• CSR was generated successfully.
• CSR does not exist.
Example racadm sslcsrgen -s
or
racadm sslcsrgen -g -f c:\csr
\csrtest.txt
NOTE: Before a CSR can be generated, the CSR fields must be configured in the RACADM cfgRacSecurity group.
For example: racadm config -g cfgRacSecurity -o cfgRacSecCsrCommonName MyCompany
NOTE: In telnet/ssh console, you can only generate and not download the CSR file.
sslkeyupload
Description Uploads SSL key from the client to iDRAC.
To use this subcommand, you must have Configure iDRAC
permission.
Synopsis racadm sslkeyupload -t <type> -f
<filename>
Input •-t — Specifies the key to upload.
1 = SSL key used to generate the server certificate
•-f — Specifies the file name of the SSL key to be
uploaded.
Output Returns 0 when successful and a nonzero number when
unsuccessful.
Example racadm sslkeyupload -t 1 -f c:
\sslkey.txt
sslresetcfg
Description Restores the web-server certificate to factory default and
restarts web-server. The certificate takes effect 30
seconds after the command is entered.
To use this subcommand, you must have Chassis
Configuration Administrator privilege for CMC and
Configure iDRAC permission for iDRAC.
Synopsis racadm sslresetcfg
Example $ racadm sslresetcfg
Certificate generated successfully and
webserver restarted.
NOTE: For more information on managing SSL certificates, see the “Securing CMC Communications Using SSL and
Digital Certificates” section in the
Dell Chassis Management Controller User Guide
.
98
testemail
Description Sends a test e-mail from iDRAC to a specified destination. Prior to executing the test e-
mail command, make sure that the SMTP server is configured and the specified index in
the RACADM cfgEmailAlertgroup is enabled and configured properly. See cfgEmailAlert
for more information.
Synopsis racadm testemail -i <index>
Input -i — Specifies the index of the e-mail alert to test.
Output Success: Test e-mail sent successfully
Failure: Unable to send test e-mail
Example Commands for the cfgEmailAlert group:
• Enable the alert —
racadm config -g cfgEmailAlert -o
cfgEmailAlertEnable -i 1
1
• Set the destination e-mail address —
racadm config -g cfgEmailAlert -o
cfgEmailAlertAddress -i 1 user1@mycompany.co
m
• Set the custom message that is sent to the destination e-mail address —
racadm config -g cfgEmailAlert -o
cfgEmailAlertCustomMsg -i 1 "This is a test!"
• Make sure that the SMTP IP address is configured properly —
racadm config -g cfgRemoteHosts -o
cfgRhostsSmtpServerIpAddr 192.168.0.152
• View the current e-mail alert settings —
racadm getconfig -g cfgEmailAlert -i <index>
where <
index
> is a number from 1 to 4.
testfeature
The following tables describe the testfeature subcommand options.
99
Option Description
-f
<feature>
Specifies the feature name. testfeature supports the
following features:
• ad — Tests Active Directory configuration using
simple authentication (user name and password)
• adkrb — Tests Active Directory configuration
using Kerberos authentication
• ldap — Tests LDAP configuration and operation
(requires user name and password)
-u <
username
> The user name specified in an appropriate format for the
selected authentication method. That is, Active Directory
users are specified as user_name@domain_name.
-p <
password
> The password for the indicated user account.
-d <
bitmask
> A bitmask (specified as a hexadecimal value) to select
various diagnostic messaging levels. This option is
optional.
NOTE: -d option is not supported with the remote
racadm interface.
Subcommands
testfeature -f ad
Description Tests Active Directory configuration using simple
authentication (user name and password). Use the
optional -d switch to obtain additional diagnostic
information, as needed.
This subcommand when executed performs the following:
• Checks command syntax.
• Verifies whether the required system resources
are available.
• Validates Active Directory configuration.
• Verifies the SSL certificate and if the certificate
signing request (key) exists.
• Acquires LDAP and Global Catalog Service
records from DNS.
• Acquires user privileges from the Active Directory
server.
• Checks the time to acquire user privileges with
the allotted time to login.
NOTE: In the event of an error, the command displays
the test that failed and all the tests performed earlier
to the test that failed, including all the error messages.
Synopsis testfeature -f ad -u <username> -p
<password>
[-d <diagnostic-message-level>]
Example • testfeature –f ad –u user@domain –p secret
SUCCESSFUL: User permissions are xxxxxppp
100
The last three digits are the user's permissions.
• testfeature –f adkrb –u
user_name@domain_name
SUCCESSFUL: User permissions are 80000fff
• testfeature -f ldap -u harold -p barrel
SUCCESSFUL: User permissions are 0x00000fff
testfeature -f adkrb
Description Tests the Active Directory configuration using Kerberos
authentication (single sign-on or Smart Card login). Use
the optional -d switch to obtain additional diagnostic
information, as needed. This subcommand when executed
performs the following:
• Checks command syntax.
• Verifies if the required system resources are
available.
• Validates Active Directory configuration.
• Verifies if the SSL certificate and certificate
signing request (key) exists.
• Acquires LDAP and Global Catalog Service
records from DNS.
• Verifies if the CMC can acquire CMC, LDAP and
Global Catalog servers FQDN through reverse IP
lookups.
• Verifies that the CMC principal name matches the
principal name in the uploaded Keytab file.
• Verifies that the CMC acquires a Kerberos TGT.
• Acquires user privileges from the Active Directory
server.
• Checks the time to acquire user privileges with
the allotted time to login.
NOTE: In the event of an error, the command outputs
all tests performed up to and including the test that
failed, as well as all error messages.
Synopsis testfeature -f adkrb -u <username> [-d
<diagnostic-message-level>]
testfeature -f ldap
101
Description Tests LDAP configuration and operation, and reports
success as each stage of the authentication process
proceeds. On successful completion, this command prints
the CMC privileges assumed by the specified <
username
>.
If a failure occurs, the command terminates with an error
message that displays the required corrective action. Use
the optional -d switch to obtain additional diagnostic
information, as needed.
Synopsis testfeature -f ldap -u <username> -p
<password>
[-d <diagnostic-message-level>]
testtrap
Description Tests the RAC’s SNMP trap alerting feature by sending a test trap from iDRAC to a
specified destination trap listener on the network.
To use this subcommand, you must have Test Alerts permission.
NOTE: For iDRAC only, before you execute the testtrap subcommand, make sure that
the specified index in the RACADM cfgIpmiPet group is configured properly. The
cfgIpmiPet group is applicable only for iDRAC.
NOTE: For CMC only, before you execute the testtrap subcommand, make sure that
the specified index in the RACADM cfgAlerting group is configured properly. The
cfgAlerting group is applicable only for CMC.
Synopsis racadm testtrap -i <index>
Input -i — Specifies the index of the trap configuration to be used for the test. Valid values are
from 1 to 4.
Example Commands for the cfgIpmiPet group:
• Enable the alert
racadm config -g cfgIpmiPet -o cfgIpmiPetAlertEnable -
i 1
1
• Set the destination e-mail IP address
racadm config -g cfgIpmiPet -o
cfgIpmiPetAlertDestIpAddr -i 1 192.168.0.110
• View the current test trap settings
racadm getconfig -g cfgIpmiPet -i <index
>
where <
index
> is a number from 1 to 4
traceroute
Description Traces the network path of routers that packets take as
they are forwarded from your system to a destination IPv4
address.
102
To use this subcommand, you must have Administrator
permission.
Synopsis racadm traceroute <IPv4 address>
racadm traceroute 192.168.0.1
Input racadm traceroute 192.168.0.1
Output traceroute to 192.168.0.1
(192.168.0.1), 30 hops
max,
40 byte packets
1 192.168.0.1 (192.168.0.1) 0.801 ms
0.246 ms 0.253 ms
traceroute6
Description Traces the network path of routers that packets take as
they are forwarded from your system to a destination IPv6
address.
To use this subcommand, you must have Administrator
permission.
Synopsis racadm traceroute6 <IPv6 address>
racadm traceroute fd01::1
Output traceroute to fd01::1 (fd01::1) from
fd01::3,
30 hops
max, 16 byte packets
1 fd01::1 (fd01::1) 14.324 ms 0.26 ms
0.244 ms
usercertupload
Description Uploads a user certificate or a user CA certificate from the
client to iDRAC.
To use this subcommand, you must have Configure iDRAC
permission.
This option is applicable only to iDRAC.
Synopsis racadm usercertupload -t <type> [-f
<filename>]
-i <index>
Input •-t — Specifies the type of certificate to upload,
either the CA certificate or server certificate.
— 1 = user certificate
— 2 = user CA certificate
103
•-f - Specifies the file name of the certificate to be
uploaded. If the file is not specified, the sslcert file
in the current directory is selected.
•-i - Index number of the user. Valid values 1-16.
Output Returns 0 when successful and a nonzero number when
unsuccessful.
Example racadm usercertupload -t 1 -f c:\cert
\cert.txt
-i 6
usercertview
Description Displays the user certificate or user CA certificate that
exists on iDRAC.
To use this subcommand, you must have Configure iDRAC
permission.
This option is applicable only to iDRAC
Synopsis racadm usercertview -t <type> [-A] -i
<index>
Input •-t — Specifies the type of certificate to view,
either the user certificate or the user CA
certificate.
— 1 = user certificate
— 2 = user CA certificate
•-A — Prevents printing headers/labels.
•-I — Index number of the user. Valid values are
1-16.
version
Description Displays the RACADM version information.
This option is applicable only for iDRAC.
Synopsis racadm version
vflashsd
Description Allows you to initialize or get the status of the vFlash SD
card. The initialize operation removes all existing
partitions and resets the card. The status operation
displays the status of the last operation performed on the
card.
To use this subcommand, you must have Access Virtual
Media privilege. This option is applicable only to iDRAC.
Synopsis •racadm vflashsd initialize
•racadm vflashsd status
104
vflashpartition
Description Allows you to perform the following:
• Create an empty partition
• Create a partition using an image file
• Format a partition
• View available partitions
• Delete existing partitions
• Get the status of partitions
To use this subcommand, you must have Access Virtual Media privilege. This option is
applicable only to iDRAC
Synopsis •racadm vflashpartition create <options
>
•racadm vflashpartition delete <options
>
•racadm vflashpartition status <options
>
•racadm vflashpartition list <options>
NOTE: Create partition using image file is not supported in local RACADM.
The following table describes the vflashpartition subcommand options.
Option Description
-i <
index
>Index of the partition for which this command applies.
<
index
> must be an integer from 1 to 16.
NOTE: For the standard SD card, the index value is 1
because only one partition of size 256 MB is
supported.
Options valid only with create action
-o <
label
>Label that is displayed when the partition is mounted on
the operating system.
<
label
> must be a string up to six alphanumeric
characters.
-e
<type>
Emulation type for the partition. <
type
> must be floppy,
cddvd, or HDD.
-t <
type
> Create a partition of type <
type
>. <
type
> must be:
• empty – Create an empty partition. The following
options are valid with the empty type:
-s <
size
> – Partition size in MB.
-f <
type
> – Format type for the partition based on
the type of file system. Valid options are RAW,
FAT16, FAT32, EXT2, or EXT3.
105
NOTE: When an empty partition is created the default
Access type is always Read-Write.
• image – Create a partition using an image relative
to iDRAC. The following options are valid with the
image type:
-l <
path
> – Specifies the remote path relative to
iDRAC. The path can be on a mounted drive: SMB
path: //
<ip or domain>
/<
share_name
> /
<
path_to_image
> NFS path: <
ipaddress
>:/
<
path_to_image
>
-u <
user
> – Username for accessing the remote
image.
-p <
password
> – Password for accessing the
remote image.
NOTE: When a partition from an image is created the
default access type is always Read-Only.
Options valid only with status action
-a Displays the status of operations on all existing partitions.
Examples
• To create a 20MB empty partition:
racadm vflashpartition create -i 1 -o drive1
-t empty -e HDD -f fat16 -s 20
• To create a partition using an image file on a remote system:
racadm vflashpartition create –i 1 –o drive1
–e HDD –t image –l //myserver/sharedfolder/foo.iso –u root –p mypassword
NOTE: The image file name extension is case sensitive. If the file name extension is in upper case, for example
FOO.ISO instead of FOO.iso, then the command returns a syntax error.
• To delete a partition:
racadm vflashpartition delete -i 1
• To delete all partitions, re-initialize the vFlash SD card:
racadm vflashsd initialize
• To get the status of operation on partition 1:
racadm vflashpartition status -i 1
• To get the status of all existing partitions:
racadm vflashpartition status -a
• To list all existing partitions and its properties:
racadm vflashpartition list
• To get the partition size:
racadm getconfig –g cfgvflashpartition –o cfgvflashpartitionsize
–i 1
• To display the emulation type:
racadm getconfig –g cfgvflashpartition –I 1 –o
cfgvflashpartitionemulatiotype
• To display the label for the partition that is visible to the operating system:
racadm getconfig –g cfgvflashpartition –i 1 –o cfgvflashPartitionlabel
106
• To display the format type of the partition:
racadm getconfig –g cfgvflashpartition –i 1 –o
cfgvflashPartitionFormatType
• To change a read-only partition to read-write:
racadm config –g cfgvflashpartition –i 1 –o cfgvflashPartitionAccessType
1
• To attach a partition to the host operating system:
racadm config –g cfgvflashpartition –i 1 –o
cfgvflashPartitionAttachState 1
vmdisconnect
Description Allows a user to disconnect another user's Virtual Media
session. Once disconnected, the Web-based interface
reflects the correct connection status.
Enables an iDRAC user to disconnect all active Virtual
Media sessions. The active Virtual Media sessions can be
displayed in iDRAC Web-based interface or by using the
RACADM subcommands such as remoteimage or
getssninfo.
This option is applicable only to iDRAC.
To use this subcommand, you must have Access Virtual
Media permission.
Synopsis racadm vmdisconnect
107
108
3
iDRAC and CMC Property Database Group and
Object Descriptions
The iDRAC and CMC property database contains the configuration information for iDRAC and CMC. Data is organized by
associated object, and objects are organized by object group. The IDs for the groups and objects that the property
database supports are listed in this section for iDRAC Enterprise on Blade Servers, iDRAC Enterprise or Express on Rack
and Tower Servers and CMC.
Use the group and object IDs with the RACADM subcommands to configure iDRAC and CMC.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
NOTE: Racadm sets the value of objects without performing any functional validation on them. For example,
RACADM allows you to set the Certificate Validation object to 1 with the Active Directory object set to 0, even
though Certificate Validation can happen only if Active Directory is enabled. Similarly, the cfgADSSOEnable object
can be set to 0 or 1 even if the cfgADEnable object is 0, but it takes effect only if Active Directory is enabled.
All string values are limited to displayable ASCII characters, except where otherwise noted.
Displayable Characters
Displayable characters include the following set:
abcdefghijklmnopqrstuvwxwz
ABCDEFGHIJKLMNOPQRSTUVWXYZ
0123456789~`!@#$%^&*()_+-={}[]|\:";'<>,.?/
The following table provides an overview of the object groups applicable for iDRAC Enterprise on Blade Servers, iDRAC
on Rack and Tower Servers, and CMC.
Subcommand iDRAC on Blade Servers iDRAC on Rack and Tower
Servers
CMC
idRacInfo Yes Yes Yes
cfgLanNetworking Yes Yes Yes
cfgRemoteHosts Yes Yes Yes
cfgUserAdmin Yes Yes Yes
cfgEmailAlert Yes Yes Yes
cfgSessionManagement Yes Yes Yes
cfgSerial Yes Yes Yes
cfgOobSnmp Yes Yes Yes
cfgTraps No No Yes
cfgRacTuning Yes Yes Yes
109
Subcommand iDRAC on Blade Servers iDRAC on Rack and Tower
Servers
CMC
ifcRacManagedNodeOs Yes Yes No
cfgRacSecurity No No Yes
cfgRacVirtual Yes Yes No
cfgServerInfo No Yes Yes
cfgActiveDirectory Yes Yes Yes
cfgLDAP Yes Yes Yes
cfgLdapRoleGroup Yes Yes Yes
cfgStandardSchema Yes Yes Yes
cfgChassisPower No No Yes
cfgIpmiSol Yes Yes No
cfgIpmiLan Yes Yes No
cfgIpmiPetIpv6 Yes Yes No
cfgIpmiPef Yes Yes No
cfgIpmiPet Yes Yes No
cfgUserDomain Yes Yes No
cfgServerPower Yes Yes No
cfgKVMInfo No No Yes
cfgAlerting No No Yes
cfgServerPowerSupply No Yes No
cfgIPv6LanNetworking Yes Yes Yes
cfgCurrentLanNetworking
Read Only
No No Yes
cfgCurrentIPv6LanNetworkin
g Read Only
No No Yes
cfgIPv6URL Yes Yes No
cfgIpmiSerial No Yes No
cfgSmartCard Yes Yes No
cfgNetTuning No Yes Yes
cfgSensorRedundancy No Yes No
cfgVFlashSD Yes Yes No
cfgVFlashPartition Yes Yes No
cfgLogging Yes Yes No
110
idRacInfo
This group contains display parameters to provide information about the specifics of iDRAC or CMC being queried. One
instance of the group is allowed.
For CMC, use this object with the getconfig subcommand.
To use this object for CMC, you must have CMC Login User privilege.
The following sections provide information about the objects in the idRACInfo group.
idRacProductInfo (Read Only)
Description A text string that identifies the product.
Legal Values A string of up to 63 ASCII characters.
Default for iDRAC Integrated Dell Remote Access Controller.
Default for CMC Chassis Management Controller.
idRacDescriptionInfo (Read Only)
Description A text description of the RAC type.
Legal Values A string of up to 255 ASCII characters.
Default This system component provides a complete set of remote
management functions for Dell PowerEdge servers.
idRacVersionInfo (Read Only)
Description String containing the current product firmware version.
Legal Values A string of up to 63 ASCII characters.
Default The current version number.
idRacBuildInfo (Read Only)
Description String containing the current RAC firmware build version.
Legal Values A string of up to 16 ASCII characters.
Default for iDRAC The current iDRAC firmware build version.
Default for CMC The current CMC firmware build version.
idRacName (Read Only)
Description A user-assigned name to identify this controller.
Legal Values A string of up to 15 ASCII characters.
Default for iDRAC iDRAC
111
Default for CMC CMC
idRacType (Read Only)
Description Identifies the remote access controller type as iDRAC.
Legal Values Product ID
Default For iDRAC on Rack and Servers: 10
For iDRAC Enterprise on Blade Servers: 8
Example
racadm getconfig -g idRacInfo
# idRacType=8
# idRacProductInfo=Chassis Management Controller
# idRacDescriptionInfo=This system component provides a complete
set of remote management functions for blade servers
# idRacVersionInfo=P21
# idRacBuildInfo=200708301525
# idRacName=CMC-1
cfgLanNetworking
This group contains parameters to configure iDRAC or CMC NIC for IPv4.
One instance of the group is allowed. Some objects in this group may require iDRAC NIC to be reset, which may cause a
brief loss in connectivity. Objects that change iDRAC NIC IP address settings close all active user sessions and require
users to reconnect using the updated IP address settings.
For CMC, use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
NOTE: For any network property changes on iDRAC to be successfully executed through RACADM, you must first
enable iDRAC NIC.
The following sections provide information about the objects in the cfgLanNetworking group.
cfgNicIPv4Enable (Read/Write)
Description Enables or disables iDRAC or CMC IPv4 stack.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
112
cfgNicSelection (Read/Write)
Description Specifies the current mode of operation for the RAC
network interface controller (NIC). The table below
describes the supported modes.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers or CMC.
Legal Values • 1 = Dedicated
• 2 = LOM1
• 3 = LOM2
• 3 = LOM3
• 5 = LOM4
Default 1 = Dedicated (iDRAC Express)
The following table lists the supported cfgNicSelection modes:
Mode Description
Shared Used if the host server integrated NIC is shared with the
RAC on the host server. This mode enables configurations
to use the same IP address on the host server and the
RAC for common accessibility on the network.
Shared with Failover LOM 2 Enables teaming capabilities between host server LOM2
integrated network interface controllers.
Dedicated Specifies that the RAC NIC is used as the dedicated NIC
for remote accessibility.
Shared with Failover All LOMs Enables teaming capabilities between all LOMs on the
host server integrated network interface controllers.
The remote access device network interface is fully
functional when the host operating system is configured
for NIC teaming. The remote access device receives data
through NIC 1 and NIC 2, but transmits data only through
NIC 1.
Failover occurs from NIC 2 to NIC 3 and then to NIC 4. If
NIC 4 fails, the remote access device fails over all data
transmission back to NIC 1, but only if the original NIC 1
failure has been corrected.
cfgNicVLanEnable Read or Write
Description Enables or disables the VLAN capabilities of the RAC/
BMC.
NOTE: For iDRAC Enterprise on Blade Servers, this
object enables or disables the VLAN capabilities of
iDRAC from CMC.
This is Read only for iDRAC on Blade servers.
113
iDRAC displays only the current VLAN settings and you
cannot modify the settings from iDRAC.
All chassis management traffic, including the CMC and all
iDRACs, resides on this external VLAN when enabled. No
iDRAC configuration change is required to use this
external management network VLAN.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
Example racadm config -g cfgLanNetworking -o
cfgNicVLanEnable
1
racadm config -g cfgLanNetworking -o
cfgNicVLanEnable
0
cfgNicVLanId (Read/Write)
Description Specifies the VLAN ID for the network VLAN configuration
(in CMC for iDRAC Enterprise on Blade Servers). This
property is only valid if cfgNicVLanEnable is set to 1
(enabled).
This is Read only for iDRAC on Blade servers.
Legal Values 1 – 4000 and 4021 – 4094
Default 1
Example racadm config -g cfgLanNetworking -o
cfgNicVlanID
1
cfgNicVLanPriority (Read/Write)
Description Specifies the VLAN Priority for the network VLAN
configuration (in CMC for iDRAC Enterprise on Blade
Servers). This property is only valid if cfgNicVLanEnable is
set to 1 (enabled).
This is Read only for iDRAC on Blade servers.
Legal Values 0 - 7
Default 0
Example racadm config -g cfgLanNetworking -o
cfgNicVLanPriority 7
114
cfgDNSDomainNameFromDHCP (Read/Write)
Description Specifies that iDRAC or CMC DNS domain name should be
assigned from the network DHCP server.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
For CMC, this property is used only if cfgNicUseDhcp is set to 1 (true), or if both cfgIPv6Enable and cfgIPv6AutoConfig
are set to 1 (true).
The CMC can obtain its DNS domain name from either a DHCP or DHCPv6 server, if all of the following properties are set
to 1 (true):
• cfgNicIPv4Enable
• cfgNicUseDhcp
• cfgIPv6Enable
• cfgIPv6AutoConfig
• cfgDNSDomainNameFromDHCP
• cfgDNSDomainName (Read/Write)
The network administrator must make sure that these DHCP servers are configured to provide the same DNS domain
name to the CMC, otherwise the domain name becomes unpredictable.
cfgDNSDomainName (Read/Write)
Description This is the DNS domain name. This parameter is only valid
if cfgDNSDomainNameFromDHCP is set to 0 (FALSE).
Legal Values A string of up to 254 ASCII characters. At least one of the
characters must be alphabetic. Characters are restricted
to alphanumeric, '-', and '.'.
NOTE: Microsoft Active Directory only supports Fully
Qualified Domain Names (FQDN) of 64 bytes or fewer.
Default <
blank
>
cfgDNSRacName (Read/Write)
Description Displays the iDRAC or CMC name, which is rac-service
tag by default. This parameter is only valid if
cfgDNSRegisterRac is set to 1 (TRUE).
Legal Values A string of up to 63 ASCII characters. At least one
character must be alphabetic.
NOTE: Some DNS servers only register names of 31
characters or fewer.
115
Default For iDRAC: idrac-<
service tag
>
For CMC: cmc-<
service tag
>
cfgDNSRegisterRac (Read/Write)
Description Registers the iDRAC or CMC name on the DNS server.
When you set this parameter, the CMC registers its DNS
name for its IPv4 and IPv6 addresses with the DNS server.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
NOTE: For IPv6, only the DHCPv6 address or static address is registered.
Example:
racadm getconfig -g cfgLanNetworking
cfgNicEnable=1
cfgNicIPv4Enable=1
cfgNicIpAddress=192.168.22.101
cfgNicNetmask=255.255.255.0
cfgNicGateway=192.168.22.101
cfgNicUseDhcp=1
# cfgNicMacAddress=00:00:00:00:00:01
cfgNicVLanEnable=0
cfgNicVLanID=1
cfgNicVLanPriority=0
cfgDNSServersFromDHCP=1
cfgDNSServer1=192.168.0.5
cfgDNSServer2=192.168.0.6
cfgDNSRacName=cmc-frankly
cfgDNSDomainName=fwad.lab
cfgDNSDomainNameFromDHCP=1
cfgDNSRegisterRac=1
116
cfgDNSServersFromDHCP (Read/Write)
Description Specifies if the DNS server IPv4 addresses should be
assigned from the DHCP server on the network.
For CMC, this property is used only if cfgNicUseDhcp is
set to 1 (true).
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgDNSServer1 (Read/Write)
Description Specifies the IPv4 address for DNS server 1. This property
is only valid if cfgDNSServersFromDHCP is set to 0
(FALSE).
NOTE: cfgDNSServer1 and cfgDNSServer2 may be set
to identical values while swapping addresses.
Legal Values String representing a valid IPv4 address. For example:
192.168.0.20.
Default 0.0.0.0
cfgDNSServer2 (Read/Write)
Description Retrieves the IPv4 address for DNS server 2. This
parameter is only valid if cfgDNSServersFromDHCP is set
to 0 (FALSE).
NOTE: cfgDNSServer1 and cfgDNSServer2 may be set
to identical values while swapping addresses.
Legal Values String representing a valid IPv4 address. For example:
192.168.0.20.
Default 0.0.0.0
cfgNicEnable (Read/Write)
Description Enables or disables iDRAC or CMC network interface
controller. If the NIC is disabled, the remote network
interfaces to iDRAC or CMC are no longer accessible and
iDRAC or CMC are only available through the local or
serial RACADM interface.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
117
cfgNicIpAddress (Read/Write)
Description Specifies the static IPv4 address to be assigned to the
RAC or CMC.
NOTE: This parameter is only configurable if the
cfgNicUseDhcp parameter is set to 0(FALSE.)
Legal Values String representing a valid IPv4 address. For example:
192.168.0.20.
Default • For iDRAC on Rack and Tower Servers:
192.168.0.120
• For iDRAC Enterprise on Blade Servers:
192.168.0.
n,
where
n
is 120 plus the server slot
number.
• For CMC: 192.168.0.120
cfgNicNetmask (Read/Write)
Description The subnet mask used for iDRAC or CMC IP address.
This property is only valid if cfgNicUseDhcp is set to 0 (FALSE).
NOTE: This parameter is only configurable if the cfgNicUseDhcp parameter is set
to 0 (FALSE).
Legal Values String representing a valid subnet mask. For example: 255.255.255.0.
Default 255.255.255.0
cfgNicGateway (Read/Write)
Description iDRAC or CMC gateway IPv4 address.
The gateway IPv4 address used for static assignment of the RAC IP address. This
property is only valid if cfgNicUseDhcp is set to 0 (FALSE).
NOTE: This parameter is only configurable if the cfgNicUseDhcp parameter is set
to 0 (FALSE).
Legal Values String representing a valid gateway IPv4 address. For example: 192.168.0.1.
Default 192.168.0.1
118
cfgNicUseDhcp (Read/Write)
Description Specifies whether DHCP is used to assign the iDRAC or
CMC IPv4 address. If this property is set to 1 (TRUE), then
iDRAC or CMC IPv4 address, subnet mask, and gateway
are assigned from the DHCP server on the network. If this
property is set to 0 (FALSE), the user can configure the
cfgNicIpAddress, cfgNicNetmask, and cfgNicGateway
properties.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgNicMacAddress (Read Only)
Description The iDRAC or CMC NIC MAC address in the format:
dd:dd:dd:dd:dd:dd, where d is a hexadecimal digit in range
0 - 9, A - F
Legal Values String representing iDRAC or CMC NIC MAC address.
Default The current MAC address of iDRAC or CMC NIC. For
example, 00:12:67:52:51:A3.
cfgRemoteHosts
This group provides properties that allow configuration of the SMTP server for e-mail alerts.
For CMC, this group enables/disables and configures firmware updates, NTP, remote syslogging, and SMTP email
alerting. Use the -m option to apply this setting to iDRAC.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
The following sections provide information about the objects in the cfgRemoteHosts group.
cfgRhostsFwUpdateTftpEnable (Read/Write)
Description Enables or disables iDRAC or CMC firmware update from a
network TFTP server.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
119
cfgRhostsFwUpdateIpAddr (Read/Write)
Description Specifies the network TFTP server IPv4 or IPv6 address
that is used for TFTP iDRAC or CMC firmware update
operations.
Legal Values A string representing a valid IPv4 or IPv6 address. For
example, 192.168.0.61
Default For IPv4, it is 0.0.0.0
cfgRhostsFwUpdatePath (Read/Write)
Description Specifies TFTP path where iDRAC or CMC firmware image
file exists on the TFTP server. The TFTP path is relative to
the TFTP root path on the TFTP server.
NOTE: The server may still require you to specify the
drive (for example, C:).
Legal Values A string with a maximum length of 255 ASCII characters.
Default <
blank
>
cfgRhostsSmtpServerIpAddr (Read/Write)
Description The IPv4 or IPv6 address of the network SMTP server. The
SMTP server transmits e-mail alerts from iDRAC or CMC if
the alerts are configured and enabled.
Legal Values A string representing a valid SMTP server IPv4 or IPv6
address. For example: 192.168.0.55.
Default • For iDRAC: For IPv4, it is 0.0.0.0
• For CMC: localhost.localdomain
cfgRhostsNtpEnable
Description Enables or disables the use of the Network Time Protocol (NTP) for date and time
synchronization.
This object is applicable only for CMC.
Legal Values • 1 (true)
• 0 (false)
Default 0
cfgRhostsNtpServer1
Description Specifies the first of three possible NTP servers.
120
This object is applicable only for CMC.
Legal Values A string representing a valid NTP server. For example,
ntp1.ntp.net. At least one NTP server must be specified
and duplicate entries are not allowed.
Default Null
cfgRhostsNtpServer2
Description Specifies the second of three possible NTP servers.
This object is applicable only for CMC.
Legal Values A string representing a valid NTP server. For example,
ntp2.ntp.net. At least one NTP server must be specified
and duplicate entries are not allowed.
Default Null
cfgRhostsNtpServer3
Description Specifies the third of three possible NTP servers.
This object is applicable only for CMC.
Legal Values A string representing a valid NTP server. For example,
ntp3.ntp.net. At least one NTP server must be specified
and duplicate entries are not allowed.
Default Null
cfgRhostsNtpMaxDist
Description Specifies the NTP maximum distance parameter used to
aid in NTP configuration.
This object is applicable only for CMC.
Legal Values 1 – 128
Default 16
cfgRhostsSyslogEnable (Read/Write)
Description Enables or disables remote syslog to allow the RAC and
SEL logs to be written to up to three remote syslog
servers.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
121
cfgRhostsSyslogPort (Read/Write)
Description Remote syslog port number to use for writing the RAC and
SEL logs to a remote syslog server.
For CMC, this setting takes effect only if the
cfgRhostsSyslogEnable parameter is set to 1 (enabled).
Legal Values 10 — 65535
NOTE: For CMC, the following port numbers are
reserved and cannot be used: 21, 68, 69, 123, 161, 546,
801, 4096, 5988, 5989, 6900, 9000, 60106.
Default 514
cfgRhostsSyslogServer1 (Read/Write)
Description Specifies the first of three possible remote syslog servers
to store the RAC and SEL logs.This property is only valid if
cfgRhostsSyslogEnable is set to 1 (enabled).
Legal Values • For iDRAC: String from 0 to 63 characters.
• For CMC: Valid hostname or IPv4 or IPv6 address.
Default <
blank
>
cfgRhostsSyslogServer2 (Read/Write)
Description Specifies the second of three possible remote syslog
servers to store the RAC and SEL logs.. This property is
only valid if cfgRhostsSyslogEnable is set to 1 (enabled).
Legal Values • For iDRAC: String from 0 to 63 characters.
• For CMC: Valid hostname or IPv4 or IPv6 address.
Default <
blank
>
cfgRhostsSyslogServer3 (Read/Write)
Description Specifies the third of three possible remote syslog servers
to store the RAC and SEL logs.This property is only valid if
cfgRhostsSyslogEnable is set to 1 (enabled).
Legal Values • For iDRAC: String from 0 to 63 characters.
• For CMC: Valid hostname or IPv4 or IPv6 address.
Default <
blank
>
122
cfgRhostsSyslogPowerLoggingEnabled
Description Enables or disables power consumption logging to remote
syslog servers.
This object is applicable only for CMC.
NOTE: Remote syslog must be enabled and one or
more remote syslog servers must be configured for
power consumption to be logged.
Legal Values • 1 (enabled)
• 0 (disabled)
Default 0
cfgRhostsSyslogPowerLoggingInterval
Description Specifies the power consumption collection/logging interval.
This object is applicable only for CMC.
NOTE: This object is applicable only for CMC.
Legal Values 1 - 1440 (minutes)
Default 5
Example
racadm getconfig -g cfgRemoteHosts [-m server-<n>]
cfgRhostsFwUpdateTftpEnable=1
cfgRhostsFwUpdateIpAddr=0.0.0.0
cfgRhostsFwUpdatePath=
cfgRhostsSmtpServerIpAddr=localhost.localdomain
cfgRhostsNtpEnable=0
cfgRhostsNtpServer1=
cfgRhostsNtpServer2=
cfgRhostsNtpServer3=
cfgRhostsNtpMaxDist=16
cfgRhostsSyslogEnable=0
cfgRhostsSyslogPort=514
cfgRhostsSyslogServer1=
cfgRhostsSyslogServer2=
cfgRhostsSyslogServer3=cfgRhostsSyslogPowerLoggingEnabled=1
cfgRhostsSyslogPowerLoggingInterval=5
cfgUserAdmin
This group provides configuration information about the users who are allowed to access iDRAC or CMC through the
available remote interfaces.
Up to 16 instances of the user group are allowed. Each instance represents the configuration for an individual user.
123
NOTE: In the current CMC firmware version, the objects cfgUserAdminEnable and cfgUserAdminPrivilege are
interrelated; changing the value of one property causes the value of the other property to change. For example, if a
user does not have login privilege, the user is disabled by default. When you enable the user by changing the value
of UserAdminEnable to 1, the right most digit of the UserAdminPrivilege also becomes 1. On the other hand, if you
change the right most digit of the UserAdminPrivilege to 0, the value of UserAdminEnable becomes 0.
Use this object with the config or getconfig subcommands. You must supply an index group number to use these
commands as follows: -i <index group>
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgUserAdmin group.
cfgUserAdminIndex (Read Only)
Description The unique index of a user.
For CMC, the index number is used to specify a unique
group name. Only valid for indexed groups.
Legal Values • For iDRAC: This parameter is populated based on
the existing instances.
• For CMC: The parameter is specified by a decimal
integer from 1–16.
Default <
index of the instance
>
cfgUserAdminIpmiLanPrivilege (Read/Write)
Description The maximum privilege on the IPMI LAN channel.
This object property is specific to iDRAC.
Legal Values • 2 (User)
• 3 (Operator)
• 4 (Administrator)
• 15 (No access)
Default • 4 (User 2)
• 15 (All others)
cfgUserAdminPrivilege (Read/Write)
Description This property specifies the role-based authority privileges allowed for the user. The
value is represented as a bit mask that allows for any combination of privilege values.
The table below describes the user privilege bit values that can be combined to
create bit masks.
Legal Values • For iDRAC: 0x00000000 to 0x000001ff, and 0x0
• For CMC: 0x0000000-0x0000fff, and 0x0
124
Default 0x00000000
Example
racadm getconfig -g cfgUserAdmin -i 1
# cfgUserAdminIndex=1
cfgUserAdminEnable=1
cfgUserAdminUserName=root
# cfgUserAdminPassword=******** (Write-Only)
cfgUserAdminPrivilege=0x00000fff
The following table lists the bit masks for user priveleges.
iDRAC Specific User Privilege Privilege Bit Mask
Login to iDRAC 0x00000001
Configure iDRAC 0x00000002
Configure Users 0x00000004
Clear Logs 0x00000008
Execute Server Control Commands 0x00000010
Access Virtual Console 0x00000020
Access Virtual Media 0x00000040
Test Alerts 0x00000080
Execute Debug Commands 0x00000100
CMC Specific User Privilege
CMC Login User 0x0000001
Chassis Configuration Administrator 0x0000002
User Configuration Administrator 0x0000004
Clear Logs Administrator 0x0000008
Chassis Control Administrator 0x0000010
Super User 0x0000020
Server Administrator 0x0000040
Test Alert User 0x0000080
Debug Command Administrator 0x0000100
Fabric A Administrator 0x0000200
Fabric B Administrator 0x0000400
Fabric C Administrator 0x0000800
Examples
The following table provides sample privilege bit masks for users with one or more privileges.
User Privilege(s) Privilege Bit Mask
The user is not allowed to access iDRAC or CMC. 0x00000000
The user may only login to iDRAC or CMC and view iDRAC or
CMC and server configuration information.
0x00000001
125
The user may login to iDRAC or CMC and change configuration. 0x00000001 + 0x00000002 = 0x00000003
The user may login to iDRAC, access Virtual Media, and Virtual
Console.
0x00000001 + 0x00000040 + 0x00000080 = 0x000000C1
cfgUserAdminUserName (Read/Write)
Description The name of the user for this index. The user index is
created by writing a string into this name field if the index
is empty. Writing a string of double quotes ("") deletes the
user at that index. You cannot change the name. You must
delete and then recreate the name. The string cannot
contain / (forward slash), \ (backslash), . (period), @ (at
symbol) or quotation marks.
NOTE: This property value must be unique among user
names.
Legal Values A string of up to 16 ASCII characters.
Default • root (User 2)
• <
blank
> (All others)
cfgUserAdminPassword (Write Only)
Description The password for this user. User passwords are encrypted and cannot be seen or
displayed after the property is written.
Legal Values A string of up to 20 ASCII characters.
Default ********
cfgUserAdminEnable (Read/Write)
Description Enables or disables an individual user.
NOTE: You can enable a user for a given index, only if you set the password for
the same user.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default • For iDRAC: 1 (User 2), 0 (All others)
• For CMC: 0
126
cfgUserAdminSolEnable (Read/Write)
Description Enables or disables Serial Over LAN (SOL) user access for
the user.
This object property is specific to iDRAC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgUserAdminIpmiSerialPrivilege (Read/Write)
Description The maximum privilege on the IPMI LAN channel.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers or CMC.
Legal Values • 2 (User)
• 3 (Operator)
• 4 (Administrator)
• 15 (No access)
Default • 4 (User 2)
• 15 (All others)
cfgEmailAlert
This group contains parameters to configure iDRAC or CMC e-mail alerting capabilities. Up to four instances of this
group are allowed.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privileges.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgEmailAlert group.
cfgEmailAlertIndex (Read Only)
Description The unique index of an alert instance.
Legal Values 1-4
Default <
instance
>
127
cfgEmailAlertEnable (Read/Write)
Description Enables or disables the alert instance.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgEmailAlertAddress (Read/Write)
Description Specifies the destination email address for email alerts,
for example, user1@company.com.
Legal Values E-mail address format, with a maximum length of 64 ASCII
characters.
Default <
blank
>
cfgEmailAlertCustomMsg (Read/Write)
Description Specifies a custom message that forms the subject of the
alert.
This object property is specific to iDRAC.
Legal Values A string of up to 32 characters
Default <
blank
>
cfgEmailAlertEmailName
Description Specifies name or other identifier associated with the
destination e-mail address. The e-mail name can refer to
an individual, group, location, department, and so on.
This object property is specific to CMC.
Legal Values A string of up to 32 characters
Default <
blank
>
Example
racadm getconfig -g cfgEmailAlert -i 2
# cfgEmailAlertIndex=1
cfgEmailAlertEnable=1
cfgEmailAlertAddress=kfulton@dell.com
cfgEmailAlertName=Kevin Fulton
cfgSessionManagement
This group contains parameters to configure the number of sessions that can connect to iDRAC. One instance of the
group is allowed. Displays current settings for and configures idle timeout properties for Web server, Telnet, SSH, and
128
RACADM sessions. Changes to idle timeout settings take effect at the next login. To disable idle timeout for a
connection, set this property to 0. Use the -m option to apply this setting to iDRAC.
The following sections provide information about the objects in the cfgSessionManagement group.
cfgSsnMgtRacadmTimeout (Read/Write)
Description Defines the idle timeout in seconds for the Remote RACADM interface. If a remote RACADM session
remains inactive for more than the specified sessions, the session closes.
Legal Values 10 –1920
Default iDRAC - 60
CMC - 30
Example
racadm getconfig -g cfgSessionManagement cfgSsnMgtWebserverTimeout=0
cfgSsnMgtTelnetIdleTimeout=0
cfgSsnMgtSshIdleTimeout=300
cfgSsnMgtRacadmTimeout=0
cfgSsnMgtConsRedirMaxSessions (Read/Write)
Description Specifies the maximum number of Virtual Console
sessions allowed on iDRAC.
This object is applicable only for iDRAC.
Legal Values 1 - 4
Default 4
cfgSsnMgtWebserverTimeout (Read/Write)
Description Defines the Web server time-out. This property sets the amount of time (in
seconds) that a connection is allowed to remain idle (there is no user input). The
session is cancelled if the time limit set by this property is reached. Changes to
this setting do not affect the current session. You must log out and log in again to
make the new settings effective.
An expired Web server session logs out the current session.
Legal Values 60 – 10800
Default 1800
cfgSsnMgtSshIdleTimeout (Read/Write)
Description Defines the secure shell idle time-out. This property sets the amount of time (in
seconds) that a connection is allowed to remain idle (there is no user input). The
session is cancelled if the time limit set by this property is reached. Changes to this
setting do not affect the current session; you must log out and log in again to make the
new settings effective.
An expired secure shell session displays the following error message:
• In case of iDRAC on Rack and Tower Servers: Connection timed out
129
• In case of iDRAC Enterprise on Blade Servers: Session timed out.
Closing the session.
After the message is displayed, the system returns to the shell that generated the
Secure Shell session.
Legal Values • 0 (No timeout)
• 60 – 10800
NOTE: If 0 (no timeout), the network connection does not send keep alive packets
to probe the client. Otherwise, keep alive packets are sent to guarantee that the
client is responding.
Default • For iDRAC on Rack and Tower Servers: 300
• For iDRAC Enterprise on Blade Servers and CMC: 1800
cfgSsnMgtTelnetIdleTimeout (Read/Write)
Description Defines the Telnet idle timeout. This property sets the amount of time in seconds that a
connection is allowed to remain idle (there is no user input). The session is cancelled if the
time limit set by this property is reached. Changes to this setting do not affect the current
session (you must log out and log in again to make the new settings effective.)
An expired Telnet session displays the following error message:
• In case of iDRAC on Rack and Tower Servers: Connection timed out
• In case of iDRAC Enterprise on Blade Servers: Session timed out.
Closing the session.
After the message is displayed, the system returns you to the shell that generated the Telnet
session.
Legal Values For iDRAC:
• 0 (No timeout)
• 60– 10800
NOTE: If 0 (no timeout is specified), the network connection does not send keep alive
packets to probe the client. Otherwise, keep alive packets are sent to guarantee that the
client is responding.
Default • For iDRAC on Rack and Tower Servers: 300
• For iDRAC Enterprise on Blade Servers and CMC: 1800
cfgSerial
This group contains configuration parameters for iDRAC or CMC services. One instance of the group is allowed.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
The following sections provide information about the objects in the cfgSerial group.
NOTE: The cfgSerial object group is applicable for iDRAC Enterprise on Blade Servers for only two properties—
cfgSerialTelnetEnable=1 and cfgSerialSshEnable=1.
130
cfgSerialBaudRate (Read/Write)
Description Sets the baud rate on iDRAC or CMC serial port.
Legal Values • For iDRAC: 9600, 28800, 57600, 115200
• For CMC: 2400, 4800, 9600, 19200, 28800, 38400,
57600,115200
Default • For iDRAC: 57600
• For CMC: 115200
cfgSerialConsoleEnable (Read/Write)
Description Enables or disables the RAC or CMC serial console interface.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default • For iDRAC: 0
• For CMC: 1
cfgSerialConsoleQuitKey (Read/Write)
Description For iDRAC:
This key or key combination terminates Virtual Console
text for iDRAC when using the console com2 command.
The cfgSerialConsoleQuitKey value can be represented by
one of the following:
• Decimal value — For example, 95
• Hexadecimal value — For example, 0x12
• Octal value — For example, 007
• ASCII value — For example, ^a
ASCII values may be represented using the
following Escape Key codes:
^ followed by any alphabet (a-z, A-Z) ^ followed by the
listed special characters: [ ] \ ^ _
For CMC:
This key specifies the character that aborts the serial text
console connect (or racadm connect) command.
NOTE: The CTRL key is represented by using the ^
(carat) character.
131
NOTE: The CTRL key does not generate a character by
itself, but must be struck simultaneously with another
key to generate a character.
For example, striking both the CTRL key and the \ key
simultaneously (rather than sequentially) is denoted as ^\.
Configuration options: The value must start with the ^
character, and be followed by one of the characters— a-
z, A-Z, [, ], \
Legal value: String of up to 4 characters
Default: • For iDRAC: <
Ctrl
><
\
>
• For CMC: ^\
NOTE: For information on using RACADM commands
for special characters, see Guidelines to Quote Strings
Containing Special Characters When Using RACADM
Commands.
cfgSerialConsoleIdleTimeout (Read/Write)
Description The maximum number of seconds to wait before an idle
serial session is disconnected.
Legal Values • 0 = No timeout
• 60 – 1920
Default • For iDRAC: 300
• For CMC: 1800
cfgSerialConsoleNoAuth (Read/Write)
Description Enables or disables the RAC or CMC serial console login
authentication.
Legal Values • 0 (enables serial login authentication)
• 1 (disables serial login authentication)
Default 0
cfgSerialConsoleCommand (Read/Write)
Description Specifies a serial command that is executed after a user
logs into the serial console interface.
Legal Values • For iDRAC: A string of up to 128 characters.
• For CMC: A string representing a valid serial
command. For example, connect server-1.
132
Default <
blank
>
cfgSerialConsoleColumns
Description Specifies the number of columns in the terminal window
command line connected to the serial port. You must log
out, then log in again for the changes to take effect.
This object property is applicable only for CMC.
NOTE: The prompt counts as two characters.
NOTE: The terminal emulator must be configured with
the line wrap mode ON, if a terminal emulator is used.
Legal Values 0 – 256
Default 0 (equivalent to 80)
cfgSerialHistorySize (Read/Write)
Description Specifies the maximum size
of the serial history buffer.
Legal Values 0 – 8192
Default 8192
cfgSerialCom2RedirEnable (Read/Write)
Description Enables or disables the console for COM 2 port
redirection.
The cfgSerialCom2RedirEnable object property is
applicable only for iDRAC on Rack and Tower Servers. It is
not applicable for iDRAC Enterprise on Blade Servers and
CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgSerialSshEnable (Read/Write)
Description Enables or disables the
secure shell (SSH) interface
on iDRAC or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
133
Example
racadm getconfig -g cfgSerial
cfgSerialBaudRate=115200
cfgSerialConsoleEnable=1
cfgSerialConsoleQuitKey=^\
cfgSerialConsoleIdleTimeout=1800
cfgSerialConsoleNoAuth=0
cfgSerialConsoleCommand=
cfgSerialConsoleColumns=0
cfgSerialHistorySize=8192
cfgSerialTelnetEnable=0
cfgSerialSshEnable=1
cfgSerialTelnetEnable (Read/Write)
Description Enables or disables the Telnet console interface on iDRAC
or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgOobSnmp
This group contains parameters to configure the SNMP agent and trap capabilities of iDRAC or CMC. One instance of
the group is allowed.
The CMC SNMP agent supports the standard RFC1213 mib-2, and the Dell enterprise-specific MIB.
This group is not applicable for iDRAC on Rack and Tower Servers.
For CMC, use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgOobSnmp group.
cfgOobSnmpAgentCommunity (Read/Write)
Description Specifies the SNMP Community Name (identical to
community string) used for SNMP traps. The community
string acts as a password shared between different hosts
over the network. This community string value must match
with that of the other hosts for any kind of communication
through SNMP.
Legal Values A string of up to 31 characters.
Default public
134
Example
racadm getconfig -g cfgOobSnmp
cfgOobSnmpTrapsEnable=1
cfgOobSnmpAgentCommunity=public
cfgOobSnmpAgentEnable (Read/Write)
Description Enables or disables the SNMP agent in iDRAC or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgTraps
This group displays information for and configures delivery of SNMP traps for a specific user.
This object property is applicable only to CMC. Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
cfgTrapsIndex (Read Only)
Description Indicates the unique index of an alert instance.
Legal Values 1 - 4
Default 1
cfgTrapsEnable
Description Enables or disables event traps on the CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default None
cfgTrapsAlertDestIpAddr
Description Sets the IP address that receives the alert.
Legal Values A string representing a valid IP address. For example,
192.168.0.20.
Default None
135
cfgTrapsCommunityName
Description Sets the community string (identical to the community
name) used for authentication. The community string acts
as a password shared between different hosts over the
network. This community string value must match with
that of the other hosts for any kind of communication
through SNMP.
Legal Values A string representing the community name.
Default None
Example
racadm getconfig -g cfgTraps -i 2
# cfgTrapsIndex=2
cfgTrapsEnable=1
cfgTrapsAlertDestIpAddr=
cfgTrapsCommunityName=public
cfgRacTuning
This group is used to configure various iDRAC or CMC configuration properties, such as valid ports and security port
restrictions.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
Use the -m option to apply this setting to iDRAC.
The following sections provide information about the objects in the cfgRacTuning group.
cfgRacTuneConRedirPort (Read/Write)
Description Specifies the port to be used for keyboard, mouse, video,
and Virtual Media traffic to iDRAC.
This object is applicable only to iDRAC.
Legal Values 1024 – 65535
Default 5900
cfgRacTuneRemoteRacadmEnable (Read/Write)
Description Enables or disables the Remote RACADM interface in
iDRAC or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
136
Default 1
cfgRacTuneCtrlEConfigDisable
Description Enables or disables the ability of the local user to
configure iDRAC from the BIOS POST option-ROM.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgRacTuneHttpPort (Read/Write)
Description Specifies the port number to use for HTTP network
communication with iDRAC or CMC.
Legal Values 10 – 65535
NOTE: For CMC, the following port numbers are
reserved and cannot be used: 21, 68, 69, 123, 161, 546,
801, 4096, 5988, 5989, 6900, 9000, 60106.
Default 80
cfgRacTuneHttpsPort (Read/Write)
Description Specifies the port number to use for HTTPS network
communication with iDRAC or CMC.
Legal Values 10 – 65535
NOTE: For CMC, the following port numbers are
reserved and cannot be used: 21, 68, 69, 123, 161, 546,
801, 4096, 5988, 5989, 6900, 9000, 60106.
Default 443
cfgRacTuneIpRangeEnable (Read/Write)
Description Enables or disables the IPv4 Address Range validation
feature of iDRAC or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
137
cfgRacTuneIpRangeAddr (Read/Write)
Description Specifies the acceptable IPv4 address bit pattern in
positions determined by the "1"s in the range mask
property (cfgRacTuneIpRangeMask).
For CMC, a login from the incoming IP address is allowed
only if the following are identical:
• cfgRacTuneIpRangeMask bit-wise and with
incoming IP address
• cfgRacTuneIpRanbeMask bit-wise and with
cfgRacTuneIpRangeAddr
Legal Values An IPv4 address formatted string, for example,
192.168.0.44.
Default 192.168.1.1
cfgRacTuneIpRangeMask (Read/Write)
Description Standard IP mask values with left-justified bits. For
example, 255.255.255.0.
For CMC, a login from the incoming IP address is allowed
only if both of the following are identical:
• cfgRacTuneIpRangeMask bit-wise and with
incoming IP address
• cfgRacTuneIpRanbeMask bit-wise and with
cfgRacTuneIpRangeAddr
Legal Values An IPv4 address formatted string, for example,
255.255.255.0.
Default 255.255.255.0
cfgRacTuneIpBlkEnable (Read/Write)
Description Enables or disables the IPv4 address blocking feature of
iDRAC or CMC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgRacTuneIpBlkFailCount (Read/Write)
Description The maximum number of login failures to occur within the
window (cfgRacTuneIpBlkFailWindow) before login
attempts from the IP address are rejected.
Legal Values 2 – 16
138
Default 5
cfgRacTuneIpBlkFailWindow (Read/Write)
Description Defines the time span in seconds that the failed attempts
are counted. When failure attempts age beyond this limit,
they are dropped from the count.
Legal Values • For iDRAC: 10 – 655356
• For CMC: 2 – 655356
Default 60
cfgRacTuneIpBlkPenaltyTime (Read/Write)
Description Defines the time span in seconds that session requests
from an IP address with excessive failures are rejected.
Legal Values • For iDRAC: 10 – 655356
• For CMC: 2 – 655356
Default 300
cfgRacTuneSshPort (Read/Write)
Description Specifies the port number used for iDRAC or CMC SSH
interface.
Legal Values • For iDRAC: 1 – 65535
• For CMC: 10 – 65535
Default 22
cfgRacTuneTelnetPort (Read/Write)
Description Specifies the port number used for iDRAC or CMC Telnet
interface.
NOTE: For CMC, the following port numbers are
reserved and cannot be used: 21, 68, 69, 123, 161, 546,
801, 4096, 5988, 5989, 6900, 9000, 60106.
Legal Values • For iDRAC: 1 – 65535
• For CMC: 10 – 65535
Default 23
139
cfgRacTuneConRedirEnable (Read/Write)
Description Enables or disables Virtual Console.
This object property is applicable only to iDRAC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgRacTuneConRedirEncryptEnable (Read/Write)
Description Encrypts the video in a Virtual Console session.
This object property is applicable only to iDRAC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgRacTuneAsrEnable (Read/Write)
Description Enables or disables iDRAC last crash screen capture
feature.
This object property is applicable only to iDRAC and
requires an iDRAC reset before it becomes active.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgRacTuneDaylightOffset (Read Only)
Description Specifies the daylight savings offset (in minutes) to use for the RAC Time. This value is 0 if the
time zone is not a Daylight Saving time zone.
Legal Values 0 – 60
Default 0
Example
racadm getconfig -g cfgRacTuning [-m server-<n>] -o
<object name> <object value>
cfgRacTuneRemoteRacadmEnable=1
cfgRacTuneWebserverEnable=1
cfgRacTuneHttpPort=80
cfgRacTuneHttpsPort=443
cfgRacTuneTelnetPort=23
cfgRacTuneSshPort=22
cfgRacTuneIpRangeEnable=0
140
cfgRacTuneIpRangeAddr=192.168.1.1
cfgRacTuneIpRangeMask=255.255.255.0
cfgRacTuneIpBlkEnable=0
cfgRacTuneIpBlkFailCount=5
cfgRacTuneIpBlkFailWindow=60
cfgRacTuneIpBlkPenaltyTime=300
# cfgRacTuneTimezoneOffset=-18000
# cfgRacTuneDaylightOffset=3600
cfgRacTuneTimezoneOffset (Read Only)
Description Specifies the time zone offset (in minutes) from Greenwich Mean Time (GMT)/Coordinated Universal
Time (UTC) to use for the RAC Time. Some common time zone offsets for time zones in the United
States are:
• –480 (PST—Pacific Standard Time)
• –420 (MST—Mountain Standard Time)
• –360 (CST—Central Standard Time)
• –300 (EST—Eastern Standard Time)
For CMC: This object property is read only. Specifies the difference in number of seconds, from the
UTC/GMT. This value is negative if the current time zone is west of Greenwich.
Legal Values –720 – 7800
Default 0
Example
racadm getconfig -g cfgRacTuning
cfgRacTuneRemoteRacadmEnable=1
cfgRacTuneWebserverEnable=1
cfgRacTuneHttpPort=80
cfgRacTuneHttpsPort=443
cfgRacTuneTelnetPort=23
cfgRacTuneSshPort=22
cfgRacTuneIpRangeEnable=0
cfgRacTuneIpRangeAddr=192.168.1.1
cfgRacTuneIpRangeMask=255.255.255.0
cfgRacTuneIpBlkEnable=0
cfgRacTuneIpBlkFailCount=5
cfgRacTuneIpBlkFailWindow=60
cfgRacTuneIpBlkPenaltyTime=300# cfgRacTuneTimezoneOffset=-18000#
cfgRacTuneDaylightOffset=3600
cfgRacTuneLocalServerVideo (Read/Write)
Description Enables or disables the local server video.
NOTE: This object property is applicable only to iDRAC.
Legal Values • 1 (TRUE - Enables)
• 0 (FALSE- Disables)
Default 1
141
cfgRacTuneLocalConfigDisable (Read/Write)
Description Disables write access to iDRAC configuration data.
NOTE: Access can be disabled using the local
RACADM or iDRAC Web interface; however, once
disabled, access can be re-enabled only through
iDRAC Web interface.
This object property is applicable only to iDRAC.
Legal Values • 0 (TRUE-Enables)
• 1 (FALSE-Disables)
Default 0
cfgRacTuneWebserverEnable (Read/Write)
Description Enables or disables iDRAC or CMC web server. If this
property is disabled, iDRAC or CMC is not accessible
using client web browsers. This property has no effect on
the Telnet/SSH or RACADM interfaces.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgRacTuneVirtualConsoleAuthorizeMultipleSessions (Read/Write)
Description If a first user is already using the Virtual Console, the
value of this object effects the privileges granted to the
subsequent user’s shared request after the timeout of 30
seconds.
This object property is applicable only to iDRAC.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers.
NOTE: To modify this property, you must have
Configure iDRAC permission. This object can be used
only with remote or firmware (SSH or Telnet) RACADM
and not with local RACADM or with earlier DRAC
products.
Legal Values 0 (If the user of the first session has not responded for
session sharing request by subsequent user, the next
session user gets an access denied error after the default
timeout value of 30 seconds.)
1 (If the user of the first session has not responded for
session sharing request by subsequent user, the next
142
session user gets a read only access after the default
timeout value of 30 seconds.)
2 (If the user of the first session has not responded for
session sharing request by subsequent user, the next
session user gets administrator access after default
timeout value of 30 seconds.)
Default 0
cfgRacTunePluginType (Read/Write)
Description Specifies the plug-in type to use when running virtual
console from browser.
This object property is applicable only to iDRAC.
Legal Values • 0 = Use Active X /Native Plugin
• 1 = Use Java Plugin
Default 0 = Active X /Native Plugin
ifcRacManagedNodeOs
This group contains properties that describe the managed server operating system. One instance of the group is
allowed.
This object is applicable only to iDRAC.
The following sections provide information about the objects in the ifcRacManagedNodeOs group.
ifcRacMnOsHostname (Read Only)
Description The host name of the managed server.
Legal Values A string of up to 255 characters.
Default <
blank
>
ifcRacMnOsOsName (Read Only)
Description The operating system name of the managed server.
Legal Values A string of up to 255 characters.
Default <
blank
>
cfgRacVirtual
This group contains parameters to configure the iDRAC Virtual Media feature. One instance of the group is allowed.
This object is applicable only to iDRAC.
The following sections provide information about the objects in the cfgRacVirtual group.
143
cfgVirMediaAttached (Read/Write)
Description This object is used to attach virtual devices to the system
via the USB bus. When the devices are attached, the
server recognizes valid USB mass storage devices
attached to the system. This is equivalent to attaching a
local USB CDROM/floppy drive to a USB port on the
system. When the devices are attached, they can be
connected to the virtual devices remotely using iDRAC
Web interface or the CLI. Setting this object to 0 causes
the devices to detach from the USB bus.
Legal Values • 0 = Detach
• 1 = Attach
• 2 = Auto-Attach
Default 0
cfgVirtualBootOnce (Read/Write)
Description Enables or disables the Virtual Media Boot Once feature
of iDRAC.
If this property is enabled when the host server is
rebooted, this feature attempts to boot from the virtual
media devices—if the appropriate media is installed in the
device.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgVirMediaFloppyEmulation (Read/Write)
Description When set to 0, the virtual floppy drive is recognized as a
removable disk by Windows operating systems. Windows
operating systems assigns a drive letter that is C: or higher
during enumeration. When set to 1, the Virtual Floppy drive
is seen as a floppy drive by Windows operating systems.
Windows operating systems assigns a drive letter of A: or
B:.
NOTE: Virtual Media has to be reattached (using
cfgVirMediaAttached) for this change to take effect.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
144
cfgSDWriteProtect (Read Only)
Description Displays if the physical write protect latch on the SD card
is enabled or disabled.
NOTE: This command is deprecated from iDRAC 1.5
and CMC 3.0 releases onwards. The functionality of
this command is now covered by
cfgVFlashSDWriteProtect. While execution of
the cfgSDWriteProtect command is successful,
it is recommended to use the
cfgVFlashSDWriteProtect command. For
more information, see "cfgVFlashSDWriteProtect" on
page 132.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgServerInfo
For iDRAC this group allows you to select the BIOS first boot device and provides the option to boot the selected device
only once.
For CMC, this group allows you to displays information for and configure a server in the chassis.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option
The following sections provide information about the objects in the cfgServerInfo group.
cfgServerInfoIndex (Read Only)
Description Displays the index name of the server.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerSlotNumber (Read Only)
Description Specifies the location of the specified server (1–16) in the
chassis.
This object is applicable only to CMC.
Legal Values None
145
Default None
cfgServerServiceTag (Read Only)
Description Displays the service tag of the specified server.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerName (Read/Write)
Description Displays the name of the specified server.
This object is applicable only to CMC.
Legal Values Maximum of 15 non-extended ASCII characters, (ASCII codes 32 through 126). For
more information, see Guidelines to Quote Strings Containing Special Characters
When Using RACADM Commands.
Default SLOT - <
slot number
>
cfgServerFW (Read Only)
Description Displays the server's iDRAC management firmware
revision.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerBIOS (Read Only)
Description Displays the server's BIOS revision.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerBmcMacAddress (Read Only)
Description Displays the BMC MAC address of the specified server.
This object is applicable only to CMC.
Legal Values None
Default None
146
cfgServerNic1MacAddress (Read Only)
Description Displays the MAC address of the server NIC 1.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerNic2MacAddress (Read Only)
Description Displays the MAC address of the server NIC 2.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerNic3MacAddress (Read Only)
Description Displays the MAC address of the server NIC 3.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerNic4MacAddress (Read Only)
Description Displays the MAC address of the server NIC 4.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerPriority (Read/Write)
Description Sets the priority level allotted to the server in the chassis
for power budgeting purposes.
This object is applicable only to CMC.
Legal Values 1–9 in descending priority, where 1 holds the highest
priority
Default 1
147
cfgServerNicEnable (Read/Write)
Description Enables or disables LAN channel.
This object is applicable only to CMC.
Legal Values • 1 (Enable)
• 0 (Disable)
Default None
cfgServerIPMIOverLanEnable (Read/Write)
Description Enables or disables IPMI LAN channel.
This object is applicable only to CMC.
Legal Values • 1 (enable)
• 0 (disable)
Default None
cfgServerPowerBudgetAllocation (Read Only)
Description Displays the current power allocation for the server.
This object is applicable only to CMC.
Legal Values • 1 (Enable)
• 0 (Disable)
Default None
cfgServerDNSRegisterIMC (Read/Write)
Description Enables or disables DNS name registration for the
Integrated System (iDRAC).
This object is applicable only to CMC.
Legal Values • 1 (enable)
• 0 (disable)
Default None
148
cfgServerDNSIMCName (Read/Write)
Description Displays the DNS domain name for the integrated Remote
Access Controller (iDRAC.)
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerRootPassword (Write Only)
Description Displays the password for iDRAC as a series of asterisks (*). It cannot be seen or
displayed after this property is written.
This object is applicable only to CMC.
Legal Values None
Default None
cfgServerFirstBootDevice (Read/Write)
Description Sets or displays the first boot device.
For iDRAC, you can also set a vFlash partition that is attached as a bootable device. For
more information, see cfgVFlashPartitionOSVolLabel ReadOnly
For CMC, this object is Write only.
NOTE: For a vFlash Partition to be configured as First Boot Device, it has to be attached
first. When a detached / non-existent VFlash partition or a non-standard boot device is
configured as first boot device, the following error message is displayed:
Invalid object value
Legal Values • No-Override
• PXE
• HDD
• DIAG
• CD-DVD
• BIOS
• vFDD
• VCD-DVD
• iSCSI
• VFLASH partition label
• FDD
• SDe
• RFS (Remote File Share)
Default No-Override
149
cfgServerBootOnce (Read/Write)
Description Enables or disables the server boot once feature.
For CMC, this object is Write only.
Legal Values • 1 = TRUE
• 0 = FALSE
Default 0
cfgServerPowerConsumption (Read Only)
Description Displays the current power consumption for a server.
This object is applicable only to CMC.
Legal Values None
Default None
Example
racadm getconfig -g cfgServerInfo -i 8
# cfgServerInfoIndex=8
# cfgServerSlotNumber=8
# cfgServerServiceTag=
cfgServerName=SLOT-08
# cfgServerFW=3.0
# cfgServerBIOS=
# cfgServerBmcMacAddress=00:21:9B:FE:5F:58
# cfgServerNic1MacAddress=00:0D:56:B8:69:63
170 CMC Property Database Group and Object Definitions
# cfgServerNic2MacAddress=00:0D:56:B8:69:65
# cfgServerNic3MacAddress=00:0D:56:B8:69:CB
# cfgServerNic4MacAddress=00:0D:56:B8:69:CD
cfgServerPriority=1
cfgServerNicEnable=1
cfgServerIPMIOverLANEnable=1
# cfgServerPowerBudgetAllocation=0
cfgServerDNSRegisterIMC=0
cfgServerDNSIMCName=iDRAC-
# cfgServerRootPassword=******** (Write-Only)
# cfgServerFirstBootDevice=******** (Write-Only)
# cfgServerBootOnce=******** (Write-Only)
# cfgServerPowerConsumption=0
racadm getconfig -g cfgServerInfo -i 1
# cfgServerInfoIndex=1
# cfgServerSlotNumber=1
150
# cfgServerServiceTag=1S0M0G1
cfgServerName=SLOT-01
# cfgServerFW=1.40 (Build 12)
# cfgServerBIOS=4.0.2
# cfgServerBmcMacAddress=00:18:8B:FF:41:43
# cfgServerNic1MacAddress=00:1A:A0:FF:D9:F4
# cfgServerNic2MacAddress=00:1A:A0:FF:D9:F6
cfgServerPriority=1
cfgServerNicEnable=1
cfgServerIPMIOverLANEnable=1
# cfgServerPowerBudgetAllocation=0
cfgServerDNSRegisterIMC=0
cfgServerDNSIMCName=iDRAC-1S0M0G1
# cfgServerRootPassword=******** (Write-Only)
# cfgServerFirstBootDevice=******** (Write-Only)
# cfgServerBootOnce=******** (Write-Only)
# cfgServerPowerConsumption=0
cfgActiveDirectory
This group contains parameters to configure iDRAC or CMC Active Directory feature.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgActiveDirectory group.
cfgADRacDomain (Read/Write)
Description Active Directory Domain in which iDRAC or CMC resides.
Legal Values Any printable text string of up to 254 characters, with no
white space.
Default <
blank
>
cfgADRacName (Read/Write)
Description Name of iDRAC or CMC as recorded in the Active
Directory forest.
Legal Values Any printable text string of up to 254 characters, with no
white space.
Default <
blank
>
151
cfgADRootDomain
Description Specifies the root domain of the domain forest.
This object is applicable only to CMC.
Legal Values Any printable text string of up to 254 characters, with no
white space.
Default <
blank
>
cfgADEnable (Read/Write)
Description Enables or disables Active Directory user authentication
on iDRAC or CMC.
If this property is disabled on iDRAC, only local iDRAC
authentication is used for user logins. If this property is
disabled for CMC, either local CMC or LDAP
authentication may be used for user logins.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgADSCLEnable
Description Enables you to log on to the CMC without enabling the
Smart Card login.
NOTE: This object is applicable only to CMC.
Legal Values • 1 (Enable)
• 0 (Disable)
Default 0
cfgADSSOEnable (Read/Write)
Description Enables or disables Active Directory single sign-on
authentication on iDRAC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
152
cfgADDomainController
Description Specifies the AD server from which you want the CMC to
obtain user names. Must be used with
cfgADSpecifyServerEnable.
This object is applicable only to CMC.
Legal Values Valid IP address or fully qualified domain name (FQDN).
Default None
cfgADDomainController1 (Read/Write)
Description Specifies the LDAP server from which you want the iDRAC
to obtain user names .
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADDomainController2 (Read/Write)
Description Specifies the LDAP server from which you want the iDRAC
to obtain user names .
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADDomainController3 (Read/Write)
Description Specifies the LDAP server from which you want the iDRAC
to obtain user names .
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADAuthTimeout (Read/Write)
Description Specifies the number of seconds to wait for Active Directory authentication requests to
complete before timing out.
NOTE: To modify this property, you must have Configure iDRAC permission.
Legal Values 15 – 300 seconds
153
Default 120
cfgADType (Read/Write)
Description Determines the schema type to use with Active Directory.
Legal Values • 1 (Enables Active Directory with the extended
schema)
• 2 (Enables Active Directory with the standard
schema)
Default 1
cfgADSpecifyServerEnable
Description Allows you to enable or disable and specify an LDAP
server or a global catalog server. Use
cfgADDomainController or cfgADGlobalCatalog to specify
the IP address.
This object is applicable only to CMC.
Legal Values • 1 (enabled)
• 0 (disabled)
Default 0
cfgADGlobalCatalog
Description Specifies the Global Catalog server from which you want
the CMC to obtain user names. Must be used with
cfgADSpecifyServerEnable.
This object is applicable only to CMC.
Legal Values Valid IP address or FQDN
Default None
Example
racadm getconfig -g cfgActiveDirectory
cfgADEnable=1
cfgADSCLEnable=0
cfgADSSOEnable=0
cfgADRacDomain=
cfgADRootDomain=help
cfgADRacName=
cfgADRacAuthTimeout=300
cfgADType=0x4
cfgADSpecifyServerEnable=1
cfgADDomainController=192.168.1.1
cfgADGlobalCatalog=127.0.0.1
154
cfgADGlobalCatalog1 (Read/Write)
Description Specifies the Global Catalog server from which you want
the iDRAC to obtain user names.
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADGlobalCatalog2 (Read/Write)
Description Specifies the Global Catalog server from which you want
the iDRAC to obtain user names.
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADGlobalCatalog3 (Read/Write)
Description Specifies the Global Catalog server from which you want
the iDRAC to obtain user names.
This object is applicable only to iDRAC.
Legal Values A string of up to 254 ASCII characters representing a valid
IP address or a fully qualified domain name (FQDN).
Default None
cfgADCertValidationEnable (Read/Write)
Description Enables or disables Active Directory certificate validation as a part of the Active
Directory configuration process.
This object is applicable only to iDRAC.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgADDcSRVLookupEnable (Read/Write)
Description Configures iDRAC to use pre‑configured domain
controllers or to use DNS to find the domain controller. If
using pre‑configured domain controllers, then the domain
controllers to use are specified under
cfgAdDomainController1, cfgAdDomainController2, and
155
cfgAdDomainController3. iDRAC does not fail over to the
specified domain controllers when DNS lookup fails or
none of the servers returned by the DNS lookup works.
This object is applicable only to iDRAC.
Legal Values • 1 (TRUE)—use DNS to look up domain controllers
• 0 (FALSE)—use pre‑configured domain controllers
Default 0
cfgADDcSRVLookupbyUserdomain (Read/Write)
Description Chooses the way the user domain is looked up for Active Directory.
This object is applicable only to iDRAC.
Legal Values • 1 (TRUE)—use user domain as the search domain to look up DCs. The user
domain is chosen from the user domain list or entered by the login user.
• 0 (FALSE)—use the configured search domain cfgADDcSrvLookupDomainName
to look up DCs.
Default 1
cfgADDcSRVLookupDomainName (Read/Write)
Description This is the Active Directory Domain to use when
cfgAddcSrvLookupbyUserDomain is set to 0.
This object is applicable only to iDRAC.
Legal Values String. Maximum length = 254
Default Null
cfgADGcSRVLookupEnable (Read/Write)
Description Determines how the global catalog server is looked up. If
using pre‑configured global catalog servers, then iDRAC
uses the values cfgAdGlobalCatalog1,
cfgAdGlobalCatalog2, and cfgAdGlobalCatalog3.
This object is applicable only to iDRAC.
Legal Values • 0(FALSE)—use pre‑configured Global Catalog
Servers (GCS)
• 1(TRUE)—use DNS to look up GCS
Default 0
156
cfgADGcRootDomain (Read/Write)
Description The name of the Active Directory root domain used for
DNS look up, to locate Global Catalog servers.
This object is applicable only to iDRAC.
Legal Values String. Maximum length = 254
Default Null
cfgLDAP
This group allows you to configure settings related to the Lightweight Directory Access Protocol (LDAP).
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgLDAP group.
cfgLdapEnable (Read/Write)
Description Turns LDAP service on or off.
If this property is disabled, local CMC authentication is
used for user logins.
NOTE: For CMC, enabling this option turns off
cfgADEnable.
Legal Values • 1 (TRUE)— Enable
• 0 (FALSE)— Disable
Default 0
cfgLdapServer (Read/Write)
Description Configures the address of the LDAP Server. IPv4 and IPv6
are supported.
NOTE: You can specify multiple servers by separating
each server with a comma. For example,
example.com, sub1.example.com
Legal Values String.
• For iDRAC: Maximum length = 1024
• For CMC: Maximum length = 254
Default Null
157
cfgLdapPort (Read/Write)
Description Port of LDAP over SSL. Non-SSL port is not supported.
Legal Values 1 - 65535
Default 636
cfgLdapBasedn (Read/Write)
Description The Domain Name of the branch of the directory where all
searches should start from.
Legal Values String. Maximum length = 254
Default Null
cfgLdapUserAttribute (Read/Write)
Description Specifies the user attribute to search for. It is
recommended to be unique within the chosen baseDN,
otherwise a search filter must be configured to make sure
the uniqueness of the login user. If the userDN cannot be
uniquely identified, login fails with error.
Legal Values String. Maximum length = 254
Default Null
uid
if not configured.
cfgLdapGroupAttribute (Read/Write)
Description Specifies which LDAP attribute is used to check for group
membership. This should be an attribute of the group
class. If not specified, then iDRAC or CMC uses the
member and unique member attributes.
Legal Values String. Maximum length = 254
Default Null
158
cfgLdapGroupAttributeIsDN (Read/Write)
Description For iDRAC: When it is set to 1, iDRAC compares the
userDN retrieved from the directory to compare to the
members of the group; if it is set to 0, the user name
provided by the login user is used to compare to the
members of the group. This does not impact the search
algorithm for the bind. iDRAC always searches the userDN
and uses the userDN to bind.
For CMC: If enabled, the CMC performs DN matching,
otherwise the CMC uses the user name provided at login
for matching.
Legal Values • 1 (TRUE)—Use the
userDN
from the LDAP Server
• 0 (FALSE)—Use the
userDN
provided by the login
user
Default 1
cfgLdapBinddn (Read/Write)
Description The distinguished name of a user used to bind to the
server when searching for the login user's DN. If not
provided, an anonymous bind is used. This is optional but
is required if anonymous bind is not supported.
NOTE: If cfgLDAPBindDN is [null] and
cfgLDAPBindPassword is [null], then the CMC
attempts an anonymous bind.
Legal Values String. Maximum length = 254
Default Null
cfgLdapBindpassword (Write Only)
Description A bind password to use in conjunction with the bindDN. The bind password is
sensitive data, and should be protected. This is optional but is required if anonymous
bind is not supported.
Legal Values String. Maximum length = 254
Default Null
cfgLdapSearchFilter (Read/Write)
Description A valid LDAP search filter. This is used if the user attribute
cannot uniquely identify the login user within the chosen
baseDN. The search filter only applies to userDN search
and not the group membership search.
Legal Values • For iDRAC: String of maximum length = 254
characters
159
• For CMC: String of maximum length = 1024
characters
Default (objectclass=*)
Searches for all objects in tree.
cfgLDAPCertValidationEnable (Read/Write)
Description Controls certificate validation during SSL handshake.
Legal Values • 1 (TRUE)—iDRAC or CMC uses the CA certificate
to validate the LDAP server certificate during SSL
handshake.
• 0 (FALSE)—iDRAC or CMC skips the certificate
validation step of SSL handshake.
Default 1
cfgLDAPNetworkTimeout
Description Configures the network timeout in seconds.
This object is applicable only to CMC.
Legal Values Positive integer
Default 30 seconds
cfgLDAPSearchTimeout
Description Configures the search timeout in seconds.
This object is applicable only to CMC.
Legal Values Positive integer
Default 120 seconds
cfgLDAPSRVLookupEnable
Description Configures the CMC to query a DNS server for SRV
records.
This object is applicable only to CMC.
Legal Values • 1 (true)
• 0 (false)
Default 0
cfgLDAPSRVLookupDomainName
Description Configures the domain name to be used in the SRV lookup.
160
This object is applicable only to CMC.
Legal Values String of maximum length of 254 alphanumeric characters
and hyphens. The string must begin with a letter.
Default [null]
cfgLDAPSRVLookupServiceName (Read/Write)
Description Configures the service name to be used in the SRV lookup.
This object is applicable only to CMC.
Legal Values String of maximum length of 254 characters.
Default ldap
cfgLdapRoleGroup
For iDRAC, this group allows the user to configure role groups for LDAP.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
For CMC, this group configures Generic LDAP Role group descriptions and defines the CMC privileges that LDAP-
authenticated users are granted.
cfgLDAPRoleGroup is indexed, containing instances numbered from 1 to 5. Each object instance consists of a pair of
properties:
•cfgLDAPRoleGroupDN: an LDAP distinguished name (DN)
•cfgLDAPRoleGroupPrivilege: a CMC privilege map
Each LDAP-authenticated user assumes the total set of CMC privileges assigned to the matching LDAP distinguished
names that the user belongs to.
That is, if the user belongs to multiple role group DNs, the user receives all associated privileges for those DNs.
The following sections provide information about the objects in the cfgLdapRoleGroup group.
cfgLdapRoleGroupIndex (Read Only)
Description This is the index value of the Role Group Object.
This object is applicable only for iDRAC.
Legal Values An integer between 1 and 5
Default <
instance
>
161
cfgLdapRoleGroupDN (Read/Write)
Description This is the Domain Name of the group in this index.
For CMC, configure the LDAP distinguished name (DN) for
the role group instance.
Legal Values String. Maximum length = 1024
Default None
Example
racadm getconfig -g cfgLDAPRoleGroup -o cfgLDAPRoleGroupDN
-i 1 cn=everyone,ou=groups,dc=openldap,dc=com
cfgLdapRoleGroupPrivilege (Read/Write)
Description A bit–mask defining the privileges associated with this
particular group.
Legal Values 0x00000000 to 0x000001ff
Default 0x000
Example
racadm getconfig -g cfgLDAPRoleGroup -o cfgLDAPRoleGroupPrivilege
-i 1 0x0
cfgLocation
This group defines objects that support physical location properties.Use this object with the config or getconfig
subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
This group is applicable to CMC only.
cfgLocationDatacenter (Read/Write)
Description Indicates DataCenter name.
Legal Values String of up to 128 ASCII characters
Default 0
cfgLocationAisle (Read/Write)
Description Indicates aisle where server is located.
Legal Values String of up to 128 ASCII characters
Default 0
162
cfgLocationRack (Read/Write)
Description Indicates rack where server is located.
Legal Values String of up to 128 ASCII characters
Default 0
cfgLocationRackslot (Read/Write)
Description Indicates slot where server is located.
Legal Values Values from 1 - 255 (1 Byte)
Default 0
cfgLocationDevicesize (Read Only)
Description Indicates server chassis size.
Legal Values Values from 1 - 255
Default 0
cfgStandardSchema
This group contains parameters to configure the Active Directory standard schema settings.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: For CMC, you can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
The following sections provide information about the objects in the cfgStandardSchema group.
cfgSSADRoleGroupIndex (Read Only)
Description Index of the Role Group as recorded in the Active
Directory.
Legal Values An integer between 1 and 5
Default <
instance
>
cfgSSADRoleGroupName (Read/Write)
Description Name of the Role Group as recorded in the Active
Directory forest.
Legal Values Any printable text string of up to 254 characters with no
white space.
Default <
blank
>
163
cfgSSADRoleGroupDomain (Read/Write)
Description Active Directory Domain in which the Role Group resides.
Legal Values Any printable text string of up to 254 characters, with no
white space.
Default <
blank
>
cfgSSADRoleGroupPrivilege (Read/Write)
Description Use the bit mask numbers listed in the table below to set role-based authority privileges
for a Role Group.
Legal Values • For iDRAC: 0x00000000 to 0x000001ff
• For CMC: 0x00000000 – 0x00000fff
Default
<blank>
Example
racadm getconfig -g cfgStandardSchema -i 1
# cfgSSADRoleGroupIndex=1
cfgSSADRoleGroupName=blsys-1
cfgSSADRoleGroupDomain=
cfgSSADRolGroupPrivilege=3081
The following table displays the bit masks for Role Group privileges:
Role Group Privilege Bit Mask
Login to iDRAC 0x00000001
Configure iDRAC 0x00000002
Configure Users 0x00000004
Clear Logs 0x00000008
Execute Server Control Commands 0x00000010
Access Virtual Console 0x00000020
Access Virtual Media 0x00000040
Test Alerts 0x00000080
Execute Debug Commands 0x00000100
cfgChassisPower
This group is applicable only to CMC and contains parameters to display or configure power for the chassis.
Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege.
NOTE: You can configure any setting that is not preceded by the hash sign (#) in the output. To modify a
configurable object, use the -o option.
164
The following sections provide information about the objects in the cfgChassisPower group.
cfgChassisExternalPowerManagementMode
Description Allows to enable or disable External Power Management.
When this mode is enabled:
• The chassis power capacity is set to maximum
value.
• The server power priorities are set to 1.
• These properties cannot be changed by racadm
or GUI.
When the external power management mode is disabled,
the power capacity and server power priorities are
preserved.
Legal Values
Default
cfgChassisInPower (Read Only)
Description Indicates the cumulative input power consumption data (in watts and BTU/hr)
captured from all healthy and functional PSUs in the chassis.
Legal Values None
Default None
cfgChassisPeakPower (Read Only)
Description The maximum system input power consumption (in watts)
since the value was last cleared by a user.
Legal Values
Default
cfgChassisPeakPowerTimestamp (Read Only)
Description The timestamp recorded when the peak input power
consumption value occurred.
Legal Values
Default
cfgChassisMinPower (Read Only)
Description The minimum system input power consumption value (in watts) over the time since
the value was last cleared.
Legal Values None
165
Default None
cfgChassisMinPowerTimestamp (Read Only)
Description The timestamp recorded when the minimum system power occurred.
Legal Values None
Default None
cfgChassisPowerStatus (Read Only)
Description Indicates the power status of the chassis.
Legal Values • 1 (other)
• 2 (unknown)
• 3 (OK)
• 4 (non-critical)
• 5 (critical)
• 6 (non-recoverable)
Default None
cfgChassisRedundantState (Read Only)
Description Enables or disables power redundancy for the chassis.
Legal Values • 0 (none)
• 1 (full)
Default None
cfgChassisPowerCap (Read/Write)
Description Indicates the maximum power consumption limit (in watts)
for the entire chassis. The command generates an error if
server throttling is necessary to achieve the power goal
based on the value for this setting.
Legal Values 2715 – 16685 watts
Default 16685 watts
cfgChassisPowerCapF (Read/Write)
Description Indicates the maximum power consumption limit (in watts)
for the entire chassis. Use cfgChassisPowerCapF when
power consumption is to be changed regardless of
whether server throttling is required. This command
generates an error if the value for this setting is lower
166
than the minimum power required for the chassis
configuration.
Legal Values 2715 – 16685 watts
Default 16685 watts
cfgChassisPowerCapBTU (Read/Write)
Description Indicates the maximum power consumption limit (in
BTU/hr) for the entire chassis. The command generates an
error if server throttling is necessary to achieve the power
goal based on the value for this setting.
Legal Values 9264 - 56931 BTU/hr
Default 43221 BTU/hr
cfgChassisPowerCapFBTU (Read/Write)
Description Indicates the maximum power consumption limit (in
BTU/hr) for the entire chassis. Use cfgChassisCapFBTU
when power consumption is to be changed regardless of
whether server throttling is required. The command
generates an error if the value for this setting is lower
than the minimum power required for the chassis
configuration.
Legal Values 9264 - 56931 BTU/hr
Default 56931 BTU/hr
cfgChassisPowerCapPercent (Read/Write)
Description Indicates the power consumption limit as a percentage.
The percentage is computed mathematically as the
minimum power + (percent * (maximum power - minimum
power)). The command generates an error if server
throttling is necessary to achieve the power goal based on
the value for this setting.
Legal Values 16 -100
Default 100
cfgChassisPowerCapFPercent (Read/Write)
Description Indicates the power consumption limit as a percentage.
The percentage is computed mathematically as the
minimum power + (percent * (maximum power - minimum
power)). Use cfgChassisPowerCapFPercent when power
consumption is to be changed regardless of whether
server throttling is required.
Legal Values 16 - 100
Default 100
167
cfgChassisRedundancyPolicy (Read/Write)
Description Sets the redundancy policy of the chassis.
Legal Values • 0 (no redundancy)
• 1 (AC redundancy)
• 2 (power supply redundancy)
Default 0 (no redundancy)
cfgChassisDynamicPSUEngagementEnable (Read/Write)
Description Enables or disables dynamic engagement.
Legal Values • 0 (disabled)
• 1 (enabled)
Default 0 (disabled)
cfgChassisAllow110VACOperation (Read/Write)
Description Enables or disables normal chassis power allocations
when any power supply unit is connected to 110V AC
service. If disabled and 110V power supplies are detected,
all subsequent server power allocation requests are
denied. In this mode additional servers cannot be
powered on, regardless of server priority.
Legal Values • 0 (disabled)
• 1 (enabled)
Default 0 (disabled)
cfgChassisMaxPowerConservationMode (Read/Write)
Description Enables or disables maximum power conservation mode. When enabled, all servers
are immediately reduced to their minimum power levels, and all subsequent server
power allocation requests are denied. In this mode, performance of powered on
servers may be degraded, and additional servers cannot be powered on, regardless
of server priority.
Legal Values • 0 (disabled)
• 1 (enabled)
Default 0 (disabled)
168
cfgChassisPerformanceOverRedundancy (Read/Write)
Description Enables or disables server performance over power
redundancy. When enabled, this option favors server
performance and server powerup, over maintaining power
redundancy. When disabled, the system favors power
redundancy over server performance. When disabled,
then if the power supplies in the chassis do not provide
sufficient power, both for redundancy, as well as full
performance, then some servers may not be granted
sufficient power for full performance, or may not be
powered on, in order to maintain redundancy.
Legal Values • 0 (disabled)
• 1 (enabled)
Default 1 (enabled)
cfgChassisInMaxPowerCapacity (Read Only)
Description Indicates the total chassis power budget (in watts) available for chassis operation.
Legal Values None
Default None
cfgChassisInRedundancyReserve (Read Only)
Description Indicates the amount of redundant power (in watts) in reserve that can be utilized in
the event of an AC grid or PSU failure. This value is 0 if the Redundancy Policy is set to
0 (no redundancy).
Legal Values 0 (disabled)
1 (enabled)
Default None
cfgChassisInPowerServerAllocation (Read Only)
Description Indicates (in watts) the cumulative power allocated to servers. There is no default as
this parameter is very specific to the particular customer configuration.
Legal Values None
Default None
cfgChassisInfrastructureInPowerAllocation (Read Only)
Description Indicates the estimated cumulative DC output power consumption (in watts),
determined from a field replaceable unit (FRU) on the hardware modules in the chassis.
Legal Values None
169
Default None
cfgChassisTotalInPowerAvailable (Read Only)
Description Indicates the amount of power (in watts) available for use by the chassis.
Legal Values None
Default None
cfgChassisStandbyInPowerCapacity (Read Only)
Description Indicates the amount of power (in watts) available for powering up any hardware
modules that are either added to the chassis or powered up (if they are already
present in the chassis).
Legal Values None
Default None
cfgChassisPowerClear (Write Only)
Description Resets cfgChassisMinPower and cfgChassisMaxPowerCapacity, when set to 1.
Legal Values None
Default None
cfgChassisPowerClearTimestamp (Read Only)
Description Time stamp when cfgChassisMinPower and cfgChassisMaxPowerCapacity were
reset.
Legal Values None
Default None
cfgChassisPowerButtonEnable (Read/Write)
Description Indicates if the chassis power button is enabled or
disabled.
Legal Values • 0 (disabled)
• 1 (enabled)
Default None
cfgSystemEnergyConsumptionClear (Write Only)
Description Resets energy statistics when set to 1.
Legal Values None
170
Default None
Examples
•racadm getconfig -g cfgChassisPower
# cfgChassisInPower=0 W | 0 BTU/hr
# cfgChassisPeakPower=0 W
# cfgChassisPeakPowerTimestamp=06:32:55 01/26/2009
# cfgChassisMinPower=0 W
# cfgChassisMinPowerTimestamp=06:32:55 01/26/2009
# cfgChassisPowerStatus=5
# cfgChassisRedundantState=0
cfgChassisPowerCap=16685 W
cfgChassisPowerCapF=16685 W
cfgChassisPowerCapBTU=56931 BTU/hr
cfgChassisPowerCapFBTU=56931 BTU/hr
cfgChassisPowerCapPercent =100%
cfgChassisPowerCapFPercent =100%
cfgChassisRedundancyPolicy=0
cfgChassisDynamicPSUEngagementEnable=0
# cfgChassisInMaxPowerCapacity=0 W
# cfgChassisInRedundancyReserve=0 W
# cfgChassisInPowerServerAllocation=0 W
# cfgChassisInfrastructureInPowerAllocation=51 W
# cfgChassisTotalInPowerAvailable=0 W
# cfgChassisStandbyInPowerCapacity=0 W
# cfgChassisPowerClear=******** (Write-Only)
# cfgChassisPowerClearTimestamp=18:00:00 12/31/1969
cfgChassisServerBasedPowerMgmtMode=0
cfgChassisPowerButtonEnable=1
cfgChassisAllow110VACOperation=0
cfgChassisMaxPowerConservationMode=0
cfgChassisPerformanceOverRedundancy=1
# cfgSystemEnergyConsumptionClear = ****(Write-Only)
cfgChassisServerBasedPowerMgmtMode=0
•racadm config -g cfgChassisPower ‑o cfgChassisPowerClear 1
Clears cfgChassisMinPower and cfgChassisPeakPower.
cfgIpmiSol
This group is applicable only for iDRAC and is used to configure the Serial Over LAN (SOL) capabilities of the system.
The following sections provide information about the objects in the cfgIpmiSol group.
cfgIpmiSolEnable (Read/Write)
Description Enables or disables SOL.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
171
cfgIpmiSolBaudRate (Read/Write)
Description Specifies baud rate for serial communication over LAN.
Legal Values 9600, 19200, 57600, 115200
Default 115200
cfgIpmiSolMinPrivilege (Read/Write)
Description Specifies the minimum privilege level required for SOL
access.
Legal Values • 2 (User)
• 3 (Operator)
• 4 (Administrator)
Default 4
cfgIpmiSolAccumulateInterval (Read/Write)
Description Specifies the typical amount of time that iDRAC waits
before transmitting a partial SOL character data packet.
This value is 1-based 5ms increments.
Legal Values 1 – 255
Default 10
cfgIpmiSolSendThreshold (Read/Write)
Description Specifies the SOL threshold limit value and the maximum
number of bytes to buffer before sending an SOL data
packet.
Legal Values 1 – 255
Default 255
cfgIpmiLan
This group is applicable only for iDRAC and is used to configure the IPMI over LAN capabilities of the system.
The following sections provide information about the objects in the cfgIpmiLan group.
cfgIpmiLanEnable (Read/Write)
Description Enables or disables the IPMI over LAN interface.
Legal Values • 1 (TRUE)
172
• 0 (FALSE)
Default 0
cfgIpmiLanPrivLimit (Read/Write)
Description Specifies the maximum privilege level allowed for IPMI
over LAN access.
Legal Values • 2 (User)
• 3 (Operator)
• 4 (Administrator)
Default 4
cfgIpmiLanAlertEnable (Read/Write)
Description Enables or disables global e-mail alerting. This property
overrides all individual e-mail alerting enable/disable
properties.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgIpmiLanEncryptionKey (Read/Write)
Description Specifies the IPMI encryption key.
Legal Values A string of hexadecimal digits from 0 to 40 characters with
no spaces. Only an even amount of digits is allowed.
Default 0000000000000000000000000000000000000000
cfgIpmiLanPetCommunityName (Read/Write)
Description Specifies the SNMP community name for traps.
Legal Values A string of up to 18 characters.
Default public
cfgIpmiPetIpv6
This group is applicable only for iDRAC and is used to configure IPv6 platform event traps on the managed server.
The following sections provide information about the objects in the cfgIpmiPetIpv6 group.
173
cfgIpmiPetIPv6Index (Read Only)
Description Unique identifier for the index corresponding to the trap.
Legal Values 1 – 4
Default <
index value
>
cfgIpmiPetIPv6AlertDestIpAddr
Description Configures the IPv6 alert destination IP address for the
trap.
Legal Values IPv6 address
Default <
blank
>
cfgIpmiPetIPv6AlertEnable (Read/Write)
Description Enables or disables the IPv6 alert destination for the trap.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgIpmiPef
This group is applicable only for iDRAC and is used to configure the platform event filters available on the managed
server.
The event filters can be used to control policy related to actions that are triggered when critical events occur on the
managed server.
The following sections provide information about the objects in the cfgIpmiPef group.
cfgIpmiPefName (Read Only)
Description Specifies the name of the platform event filter.
Legal Values A string of up to 255 characters.
Default The name of the index filter.
cfgIpmiPefIndex (Read/Write)
Description Specifies the index of a specific platform event filter.
Legal Values • For iDRAC on Rack and Tower Servers: 1 – 22
• For iDRAC Enterprise on Blade Servers: 1 - 9
174
Default The index value of a platform event filter object.
cfgIpmiPefAction (Read/Write)
Description Specifies the action that is performed on the managed
server when the alert is triggered.
NOTE: For iDRAC on Rack and Tower servers, this
object is read-only for indexes 20, 21, and 22.
Legal Values • 0 (None)
• 1 (Power Down)
• 2 (Reset)
• 3 (Power Cycle)
Default 0
cfgIpmiPefEnable (Read/Write)
Description Enables or disables a specific platform event filter.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 1
cfgIpmiPet
This group is applicable only for iDRAC and is used to configure platform event traps on the managed server.
The following sections provide information about the objects in the cfgIpmiPet group.
cfgIpmiPetIndex (Read Only)
Description Unique identifier for the index corresponding to the trap.
Legal Values 1 - 4
Default The index value of a specific platform event trap.
cfgIpmiPetAlertDestIpAddr (Read/Write)
Description Specifies the destination IPv4 address for the trap
receiver on the network. The trap receiver receives an
SNMP trap when an event is triggered on the managed
server.
Legal Values A string representing a valid IPv4 address. For example,
192.168.0.67.
Default 0.0.0.0
175
cfgIpmiPetAlertEnable (Read/Write)
Description Enables or disables a specific trap.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgUserDomain
This group is applicable only for iDRAC and is used to configure the Active Directory user domain names. A maximum of
40 domain names can be configured at any given time.
The following sections provide information about the objects in the cfgUserDomain group.
cfgUserDomainIndex (Read Only)
Description Represents a specific domain.
Legal Values 1 – 40
Default The index value.
cfgUserDomainName (Read Only)
Description Specifies the Active Directory user domain name.
Legal Values A string of up to 60 ASCII characters
Default <
blank
>
cfgServerPower
This group provides several power management features.
The following sections provide information about the objects in the cfgServerPower group.
cfgServerPowerStatus (Read Only)
Description Represents the server power state, either ON or OFF.
This object is applicable only for iDRAC.
Legal Values • 1 (ON)
• 0 (OFF)
Default 0
176
cfgServerPowerAllocation (Read Only)
Description Represents the available allocated power supply for
server usage.
NOTE: In case of more than one power supply, this
object represents the minimum capacity power supply.
NOTE: This object is applicable only for iDRAC
Enterprise on Rack and Tower Servers and not for
iDRAC on Blade Servers or CMC.
Legal Values A string of up to 32 characters
Default <
blank
>
cfgServerActualPowerConsumption (Read Only)
Description Represents the power consumed by the server at the
current time.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default <
blank
>
cfgServerPowerCapEnable (Read/Write)
Description Enables or disables the user specified power budget
threshold.
This object is Read only for iDRAC Enterprise on Blade
Servers.
Legal Values • 0 - Disables the user specified power budget
threshold
• 1 - Enables the user specified power budget
threshold
Default 1
cfgServerMinPowerCapacity (Read Only)
Description Represents the minimum server power capacity on a
blade based on the current component inventory.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default <
blank
>
177
cfgServerMaxPowerCapacity (Read Only)
Description Represents the maximum server power capacity based on
the current component consumption. This object is
applicable only for iDRAC.
Legal Values Not applicable
Default <
blank
>
cfgServerPeakPowerConsumption (Read Only)
Description Represents the maximum power consumed by the server
until the current time.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default <
current server peak power consumption
>
cfgServerPeakPowerConsumptionTimestamp (Read Only)
Description Specifies time when the maximum power consumption
was recorded.
This object is applicable only for iDRAC.
Legal Values A string of up to 32 characters.
Default Maximum power consumption timestamp.
cfgServerPowerConsumptionClear (Write Only)
Description Clears the current recorded power statistics.
This object is applicable only for iDRAC.
Legal Values 1 — Clears the Power Consumption Statistics
Default None
cfgServerPowerCapWatts (Read/Write)
Description Represents the server power threshold in Watts.
This object is applicable only for iDRAC.
NOTE: This value is applicable only if
cfgServerPowerCapEnable is set to 1.
Legal Values None
Default Server power threshold in Watts.
178
cfgServerPowerCapBtuhr (Read/Write)
Description Represents the server power threshold in BTU/hr.
This object is applicable only for iDRAC.
NOTE: This value is applicable only if
cfgServerPowerCapEnable is set to 1.
Legal Values None
Default Server power threshold in BTU/hr.
cfgServerPowerCapPercent (Read/Write)
Description Represents the server power threshold in percentage.
This object is applicable only for iDRAC.
NOTE: This value is applicable only if
cfgServerPowerCapEnable is set to 1.
Legal Values None
Default Server power threshold in percentage.
cfgServerPowerLastHourAvg (Read Only)
Description Displays the average power value during the last hour.
This object is applicable only for iDRAC.
Legal Values None
Default Average power value during the last hour.
cfgServerPowerLastDayAvg (Read Only)
Description Displays the average power value during the last day.
This object is applicable only for iDRAC.
Legal Values None
Default Average power value during the last day.
cfgServerPowerLastWeekAvg (Read Only)
Description Displays the average power value during the last week.
This object is applicable only for iDRAC.
Legal Values None
Default Average power value during the last week.
179
cfgServerPowerLastHourMinPower (Read Only)
Description Displays the minimum power value during the last hour.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Minimum power value during the last hour.
cfgServerPowerLastHourMinTime (Read Only)
Description Displays the timestamp of minimum power value during
the last minute.
This object is applicable only for iDRAC.
Legal Values Time in the format: DD MM Date HH:MM:SS YYYY
cfgServerPowerLastHourMinTime=Mon Sep 26 19:10:56
2011
where,
• DD= Day of the week
• MM= Month
• Date=Date
• YYYY = Year
• HH = hour
• MM=Minutes
• SS = Seconds
Default Minimum power value during the last minute.
cfgServerPowerLastHourMaxPower (Read Only)
Description Displays the maximum power value during the last hour.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Maximum power value during the last hour.
cfgServerPowerLastHourMaxTime (Read Only)
Description Displays the timestamp of maximum power value during
the last hour.
This object is applicable only for iDRAC.
Legal Values Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD= Day of the week
• MM= Month
• Date=Date
180
• YYYY = Year
• HH = hour
• MM=Minutes
• SS = Seconds
Default Maximum power value during the last hour.
cfgServerPowerLastDayMinPower (Read Only)
Description Displays the minimum power value during the last day.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Minimum power value during the last day.
cfgServerPowerLastDayMinTime (Read Only)
Description Displays the timestamp of minimum power value during
the last day.
This object is applicable only for iDRAC.
Legal Values Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM = Month
• Date = Date
• YYYY = Year
• HH = hour
• MM = Minutes
• SS = Seconds
Default Minimum power value during the last day.
cfgServerPowerLastDayMaxPower (Read Only)
Description Displays the maximum power value during the last day.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Maximum power value during the last day.
181
cfgServerPowerLastDayMaxTime (Read Only)
Description Displays the timestamp of maximum power value during
the last day.
This object is applicable only for iDRAC.
Legal Values Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM = Month
• Date = Date
• YYYY = Year
• HH = hour
• MM = Minutes
• SS = Seconds
Default Maximum power value during the last day.
cfgServerPowerLastWeekMinPower (Read Only)
Description Displays the minimum power value during the last week.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Minimum power value during the last week.
cfgServerPowerLastWeekMinTime (Read Only)
Description Displays the timestamp of minimum power value during
the last week.
This object is applicable only for iDRAC.
Legal Values A string of up to 32 characters.
Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM = Month
• Date = Date
• YYYY = Year
• HH = hour
• MM = Minutes
• SS = Seconds
Default Minimum power value during the last week
182
cfgServerPowerLastWeekMaxPower (Read Only)
Description Displays the maximum power value during the last week.
This object is applicable only for iDRAC.
Legal Values None
Default Maximum power value during the last week.
cfgServerPowerLastWeekMaxTime (Read Only)
Description Displays the timestamp of maximum power value during
the last week.
This object is applicable only for iDRAC.
Legal Values A string of up to 32 characters.
Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM= Month
• Date = Date
• YYYY = Year
• HH = hour
• MM = Minutes
• SS = Seconds
Default Maximum power value during the last week.
cfgServerPowerInstHeadroom (Read Only)
Description Displays the difference between the available power and
the current power consumption.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers.
Legal Values Not applicable
Default Difference between the available power and the current
power consumption.
cfgServerPowerPeakHeadroom (Read Only)
Description Displays the difference between the available power and
the peak power consumption.
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers or CMC.
Legal Values None
183
Default Difference between the available power and the peak
power consumption.
cfgServerActualAmperageConsumption (Read Only)
Description Displays the current power consumption.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Current power consumption.
cfgServerPeakAmperage (Read Only)
Description Displays the current peak power consumption.
Legal Values Not applicable
Default Current peak power consumption.
cfgServerPeakAmperageTimeStamp (Read Only)
Description Displays the timestamp of the current peak power
consumption.
This object is applicable only for iDRAC.
Legal Values A string of up to 32 characters.
Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM = Month
• Date = Date
• YYYY = Year
• HH = hour
• MM = Minutes
• SS = Seconds
Default Timestamp of the current peak power consumption.
cfgServerCumulativePowerConsumption (Read Only)
Description Displays the cumulative power consumption.
This object is applicable only for iDRAC.
Legal Values Not applicable
Default Cumulative power consumption.
184
cfgServerCumulativePowerConsumptionTimeStamp (Read Only)
Description Displays the timestamp of the cumulative power
consumption.
This object is applicable only for iDRAC.
Legal Values A string of up to 32 characters.
Time in the format: DD MM Date HH:MM:SS YYYY
where,
• DD = Day of the week
• MM= Month
• Date=Date
• YYYY = Year
• HH = hour
• MM=Minutes
• SS = Seconds
Default Timestamp of the cumulative power consumption.
cfgServerCumulativePowerClear (Write Only)
Description Clears the cfgServerCumulativePowerConsumption and
cfgServerCumulativePowerConsumptionTimeStamp values.
This object is applicable only for iDRAC.
Legal Values 1
Default None
cfgServerPowerPCIeAllocation (Read/Write)
Description Amount of power allocated to the PCIe cards.
This object is applicable for iDRAC Enterprise only for
specific Blade Servers and not for iDRAC on Rack and
Tower Servers or CMC.
You must have Administrator privileges to modify the value
for this object.
Legal Values 0W: For platforms that do not support PCIe cards.
100W - 500W: For platforms that support PCIe cards.
Default 0: For platforms that do not support PCIe cards.
500W: For platforms that support PCIe cards.
cfgKVMInfo
This group is used to display information for and configure the iKVM. This object is applicable only for CMC.
Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege.
185
cfgKVMAccessToCMCEnable
Description Enables or disables the Dell CMC Console access on the
iKVM.
Legal Values • 1 (enable)
• 0 (disable)
Default None
cfgKVMFrontPanelEnable
Description Enables or disables front panel access on the iKVM.
Legal Values • 1 (enable)
• 0 (disable)
Default None
Example
racadm getconfig -g cfgKVMInfo
cfgKVMAccessToCMCEnable=1
cfgKVMFrontPanelEnable=1
cfgAlerting
This group is enables or disables SNMP event trap alerting and sets the event filter.
This object is applicable only for CMC.
Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege.
cfgAlertingEnable
Description Enables or disables event traps on the CMC.
Legal Values • 1 (true)
• 0 (false)
Default None
cfgAlertingFilterMask
Description Sets the event filter.
Legal Values Hex values 0x0 – 0x1fffffff
Default 0x17ff8db
186
cfgAlertingSourceEmailName
Description Specifies e-mail address used to send e-mail notifications when an event occurs.
Legal Values None
Default None
Examples
racadm getconfig -g cfgAlerting -o cfgAlertingSourceEmailName
racadm config -g cfgAlerting -o cfgAlertingSourceEmailName user@home.com
Object value modified successfully.
cfgLcdLocale
Description Specifies the Language (locale) for the Blade Chassis LCD interface.
Legal Values de, fr, en, es, ja, zh-cn.
Default en
Example racadm config -g cfgLcdInfo -o cfgLcdLocale en
Object value modified successfully.
cfgServerPowerSupply
This group is applicable only for iDRAC and contains information related to the power supplies. The following sections
provide information about the objects in the cfgServerPowerSupply group.
The cfgServerPowerSupply object group is applicable only for iDRAC on Rack and Tower Servers and not for iDRAC
Enterprise on Blade Servers.
NOTE: The getconfig subcommand always shows eight cfgServerPowerSupply indexes, even if two power supplies
are installed in the system or the system supports a maximum of two power supply units. For the uninstalled and
unsupported units, all the objects in the cfgServerPowerSupply group displays a value of 0.
cfgServerPowerSupplyIndex
Description Specifies index of the power supply unit.
NOTE: Indexes from 1 – 8 are supported to support up
to 8 power supply units. If any power supply unit is not
present, cfgServerPowerSupplyOnlineStatus is absent
and for all the other properties, it is 0.
Legal Values Integer from 1 - 8
Default None
187
cfgServerPowerSupplyMaxInputPower (Read Only)
Description Displays the AC input rated power in Watts.
Legal Values A string of up to 32 characters.
Default 0
cfgServerPowerSupplyMaxOutputPower (Read Only)
Description Displays the AC output rated power in Watts.
Legal Values A string of up to 32 characters.
Default 0
cfgServerPowerSupplyOnlineStatus (Read Only)
Description Displays the status of the power supply unit.
Legal Values • 0 - Present
• 1 - Absent
• 2 - Failure
• 3 - Predictive failure
Default 0
cfgServerPowerSupplyFwVer (Read Only)
Description Displays the firmware version of the power supply unit, in
the format x.xx.xxx.
Legal Values A string up to 8 characters.
Default Null
cfgServerPowerSupplyCurrentDraw (Read Only)
Description Displays the instantaneous current consumption in 0.1
Amps.
Legal Values A string of up to 32 characters.
Default 0
cfgServerPowerSupplyType
Description Displays whether the power supply is AC or DC.
Legal Values A string of up to 32 characters.
Default 0
188
cfgIPv6LanNetworking
This group is used to configure the IPv6 over LAN networking capabilities.
Use this object with the config or getconfig subcommands.
To use this object property for CMC, you must have Chassis Configuration Administrator privilege.
NOTE: Use the -m option to apply this setting to iDRAC.
The following sections provide information about the objects in the cfgIPv6LanNetworking group.
cfgIPv6Enable (Read/Write)
Description Enables or disables iDRAC or CMC IPv6 stack.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgIPv6Address
Description Assigns a static IPv6 address to the CMC. This property is used only if
cfgIPv6AutoConfig is set to 0 (false).
NOTE: This object is applicable only for CMC.
Legal Values A string representing a valid IPv6 address. For example,
2001:DB8:1234:5678:9ABC:DE11:C00C:BEEF
Default ::
cfgIPv6Address1 (Read/Write)
Description Specifies iDRAC or CMC IPv6 address.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Gateway (Read/Write)
Description iDRAC or CMC gateway IPv6 address.
NOTE: For CMC, this property is used only if
cfgIPv6AutoConfig is set to 0 (false.)
Legal Values Specifies string representing a valid IPv6 entry.
Default ::
189
cfgIPv6PrefixLength (Read/Write)
Description Specifies the prefix length for iDRAC or CMC IPv6 address.
NOTE: For CMC, this property is used only if
cfgIPv6AutoConfig is set to 0 (false)
Legal Values For iDRAC: 1 - 128 For CMC: 0 - 128
Default 64
cfgIPv6AutoConfig (Read/Write)
Description Enables or disables the IPv6 Auto Configuration option.
NOTE: If this value is set to 0, the CMC disables auto
configuration and statically assigns IPv6 addresses. If
this value is set to 1, the CMC obtains address and
route information using stateless auto configuration
and DHCPv6.
NOTE: The CMC uses its MAC address for its DUID
(DUID-LL) when communicating with a DHCPv6 server.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default • For iDRAC: 0
• For CMC: 1
cfgIPv6LinkLocalAddress (Read Only)
Description The iDRAC IPv6 link local address.
This object is applicable only for iDRAC.
Legal Values Specifies a string representing a valid IPv6 entry.
Default ::
cfgIPv6Address2 (Read Only)
Description The iDRAC IPv6 second address.
This object is applicable only for iDRAC.
Legal Values A string representing a valid IPv6 entry.
Default ::
190
cfgIPv6Address3 (Read Only)
Description The iDRAC IPv6 third address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address4 (Read Only)
Description The iDRAC IPv6 fourth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address5 (Read Only)
Description The iDRAC IPv6 fifth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address6 (Read Only)
Description The iDRAC IPv6 sixth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address7 (Read Only)
Description The iDRAC IPv6 seventh address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address8 (Read Only)
Description The iDRAC IPv6 eighth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
191
Default ::
cfgIPv6Address9 (Read Only)
Description The iDRAC IPv6 ninth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address10 (Read Only)
Description The iDRAC IPv6 tenth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address11 (Read Only)
Description The iDRAC IPv6 eleventh address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address12 (Read Only)
Description The iDRAC IPv6 twelfth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address13 (Read Only)
Description The iDRAC IPv6 thirteenth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
192
cfgIPv6Address14 (Read Only)
Description The iDRAC IPv6 fourteenth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6Address15 (Read Only)
Description The iDRAC IPv6 fifteenth address.
This object is applicable only for iDRAC.
Legal Values String representing a valid IPv6 entry.
Default ::
cfgIPv6DNSServersFromDHCP6 (Read/Write)
Description Specifies whether cfgIPv6DNSServer1 and
cfgIPv6DNSServer2 are static or DHCP IPv6 addresses.
NOTE: This property is used only if cfgIPv6AutoConfig
is set to 1 (true).
Legal Values 1 (TRUE) 0 (FALSE)
Default For iDRAC: 0 For CMC: 1
cfgIPv6DNSServer1 (Read/Write)
Description Specifies the IPv6 DNS server address.
NOTE: This property is used only if
cfgIPv6DNSServersFromDHCP6 is set to 0 (false).
Legal Values A string representing a valid IPv6 entry. For example,
2001:DB8:1234:5678:9ABC:DE11:C00C:BEEF
Default ::
cfgIPv6DNSServer2 (Read/Write)
Description Specifies the IPv6 DNS server address.
NOTE: This property is only valid if cfgIPv6DNSServersFromDHCP6 is set to 0
(false).
Legal Values A string representing a valid IPv6 entry. For example,
2001:DB8:1234:5678:9ABC:DE11:C00C:BEEF
193
Default ::
Example
$ racadm getconfig -g cfgIPv6LanNetworking
cfgIPv6Enable=1
cfgIPv6AutoConfig=1
cfgIPv6Address=::
cfgIPv6PrefixLength=64
cfgIPv6Gateway=::
cfgIPv6DNSServersFromDHCP6=1
cfgIPv6DNSServer1=::
cfgIPv6DNSServer2=::
If both IPv4 and IPv6 are enabled on the CMC, IPv6 DNS servers take priority. The order of preference for DNS servers
is:
• cfgIPv6DNSServer1
• cfgIPv6DNSServer2
• cfgDNSServer1
• cfgDNSServer2
cfgCurrentLanNetworking (Read Only)
This group displays the current CMC NIC properties.
This object property is applicable only for CMC. Use this object with the getconfig subcommand.
To use this object property, you must have CMC Login User privilege.
Synopsis
racadm getconfig -g cfgCurrentLanNetworking
cfgNicCurrentIpAddress
Description Displays the static IP address to the CMC.
Legal Values
Default
cfgNicCurrentNetmask
Description Displays the static subnet mask for the CMC IP address
Legal Values
Default
cfgNicCurrentGateway
Displays the static gateway for the CMC IP address.
194
Description Displays the static gateway for the CMC IP address.
Legal Values
Default
cfgNicCurrentDhcpWasUsed
Description Indicates whether DHCP is used to configure the NIC.
Legal Values 0 – address is static.
1– address was obtained from the DHCP server.
Default None
cfgNicCurrentVlanEnable (Read Only)
Description Indicates whether the VLAN is enabled.
Legal Values 0- VLAN is disabled
1- VLAN is enabled
Default None
cfgNicCurrentVlanID (Read Only)
Description Indicates the Current Virtual Lan ID
Legal Values Integer
Default None
cfgNicCurrentVlanPriority (Read Only)
Description Indicates the Current Virtual Lan Priority.
Legal Values Integer
Default None
cfgDNSCurrentServer1
Description Displays the IP address for DNS server 1.
Legal Values A Valid IPv4 DNS IP
Default None
cfgDNSCurrentServer2
Description Displays the IP address for DNS server 2.
Legal Values
195
Default
cfgDNSCurrentDomainName
Description Displays the DNS domain name.
Legal Values
Default
cfgNicCurrentIPv4Enabled
Description Indicates whether IPv4 is enabled on the CMC. If the
current property value is set to 0 (false), the remote
network interfaces to the CMC are not accessible over
IPv4.
Legal Values
Default
Example
racadm getconfig -g cfgCurrentLanNetworking
# cfgNicCurrentIPv4Enabled=1
# cfgNicCurrentIpAddress=143.166.152.116
# cfgNicCurrentNetmask=255.255.255.0
# cfgNicCurrentGateway=143.166.152.1
# cfgNicCurrentDhcpWasUsed=0
# cfgNicCurrentVlanEnable=0
# cfgNicCurrentVlanID=1
# cfgNicCurrentVlanPriority=0
# cfgDNSCurrentServer1=192.168.0.5
# cfgDNSCurrentServer2=192.168.0.6
# cfgDNSCurrentDomainName=MYDOMAIN
cfgCurrentIPv6LanNetworking (Read Only)
This group displays the current CMC IPv6 properties.
This object property is applicable only for CMC. Use this object with the getconfig subcommand.
To use this object property, you must have CMC Login User privilege.
cfgCurrentIPv6Enabled
Description Indicates whether IPv6 is enabled on the CMC. If the
current property value is set to 0 (false), the remote
network interfaces to the CMC are not accessible over
IPv6.
Legal Values
Default
196
cfgCurrentIPv6AutoConfigWasUsed
Description Indicates whether auto configuration is used to obtain
IPv6 settings, including stateless IPv6 address(es) and
gateway.
Legal Values 0 (static addressing is used)
1 (address is obtained from the DHCPv6 server and/or
stateless auto configuration)
Default None
cfgCurrentLinkLocalAddress
Description Displays the current IPv6 link-local address of the CMC.
Legal Values
Default
cfgCurrentIPv6Address1
Description Displays the current IPv6 addresses. This property
displays up to 15 global IPv6 addresses, including stateful
and stateless addresses.
Legal Values
Default
cfgCurrentIPv6Gateway
Description Displays the current IPv6 gateway.
Legal Values
Default
cfgCurrentIPv6DNSServersFromDHCP6
Description Indicates whether the DNS server addresses are assigned
from the DHCPv6 server.
Legal Values
Default
cfgCurrentIPv6DNSServer1
Description Displays the IPv6 address for DNS server 1.
Legal Values
197
Default
cfgCurrentIPv6DNSServer2
Description Displays the IPv6 address for DNS server 2.
Legal Values None
Default None
Example
racadm getconfig -g cfgCurrentIPv6LanNetworking
# cfgCurrentIPv6Enabled=1
# cfgCurrentIPv6AutoConfigWasUsed=1
# cfgCurrentLinkLocalAddress=fe80::21e:4fff:fe1f:5371/64
# cfgCurrentIPv6Address1=2009:123::e48f:9dd8:6f51:a669/64
# cfgCurrentIPv6Address2=fd88:1::21e:4fff:fe1f:5371/64
# cfgCurrentIPv6Address3=fd88:2::21e:4fff:fe1f:5371/64
# cfgCurrentIPv6Gateway=fe80::21c:23ff:fe77:6215
# cfgCurrentIPv6DNSServersFromDHCP6=1
# cfgCurrentIPv6DNSServer1=2009:123::1
# cfgCurrentIPv6DNSServer2=::
cfgIPv6URL
This group specifies properties used to configure iDRAC IPv6 URL.
The following sections provide information about the objects in the cfgIPv6URL group.
cfgIPv6URLstring (Read Only)
Description The iDRAC IPv6 URL.
Legal Values A string of up to 80 characters.
Default <
blank
>
cfgIpmiSerial
This group specifies properties used to configure the IPMI serial interface of the BMC.
It is applicable only for iDRAC on Rack and Tower Servers and not for iDRAC Enterprise on Blade Servers or CMC.
cfgIpmiSerialBaudRate (Read/Write)
Description Specifies the baud rate for a serial connection over IPMI.
Legal Values 9600, 19200, 57600, 115200
Default 57600
198
cfgIpmiSerialConnectionMode (Read/Write)
Description When the iDRAC cfgSerialConsoleEnable property is set to
0 (disabled), the iDRAC serial port becomes the IPMI serial
port. This property determines the IPMI defined mode of
the serial port.
In Basic mode, the port uses binary data with the intent of
communicating with an application program on the serial
client. In Terminal mode, the port assumes that a dumb
ASCII terminal is connected and allows very simple
commands to be entered.
Legal Values • 0 (Terminal)
• 1 (Basic)
Default 1
cfgIpmiSerialChanPrivLimit (Read/Write)
Description Specifies the maximum privilege level allowed on the IPMI
serial channel.
Legal Values • 2 (User)
• 3 (Operator)
• 4 (Administrator)
Default 4
cfgIpmiSerialFlowControl (Read/Write)
Description Specifies the flow control setting for the IPMI serial port.
Legal Values • 0 (None)
• 1 (CTS/RTS)
Default 1
cfgIpmiSerialHandshakeControl (Read/Write)
Description Enables or disables the IPMI terminal mode handshake
control.
Legal Values • 0 (FALSE)
• 1 (TRUE)
Default 1
199
cfgIpmiSerialLineEdit (Read/Write)
Description Enables or disables line editing on the IPMI serial
interface.
Legal Values • 0 (FALSE)
• 1 (TRUE)
Default 1
cfgIpmiSerialEchoControl (Read/Write)
Description Enables or disables echo control on the IPMI serial
interface.
Legal Values • 0 (FALSE)
• 1 (TRUE)
Default 1
cfgIpmiSerialDeleteControl (Read/Write)
Description Enables or disables delete control on the IPMI serial
interface.
Legal Values • 0 (FALSE)
• 1 (TRUE)
Default 0
cfgIpmiSerialNewLineSequence (Read/Write)
Description Specifies the newline sequence specification for the IPMI
serial interface.
Legal Values • 0 (None)
• 1 (CR-LF)
• 2 (NULL)
• 3 (<
CR
>)
• 4 (<
LF-CR
>)
• 5 (<
LF
>)
Default 1
200
cfgIpmiSerialInputNewLineSequence (Read/Write)
Description Specifies the input newline sequence specification for the
IPMI serial interface.
Legal Values • 1 (ENTER)
• 2 (NULL)
Default 1
cfgSmartCard
This group specifies properties used to support access to iDRAC using a smart card. This group is applicable only for
iDRAC.
The following sections provide information about the objects in the cfgSmartCard group.
cfgSmartCardLogonEnable (Read/Write)
Description Enables, disables, or enables with Remote RACADM
support for access to iDRAC using a smart card.
NOTE: Enabling with remote RACADM is only
applicable for iDRAC on Rack and Tower Servers.
Legal Values • 0 (Disabled)
• 1 (Enabled)
• 2 (Enabled with Remote RACADM) - This is not
applicable for iDRAC Enterprise on Blade Servers.
Default 0
cfgSmartCardCRLEnable (Read/Write)
Description Enables or disables the Certificate Revocation List (CRL).
This object is applicable only for iDRAC on Rack and
Tower Servers and not for iDRAC Enterprise on Blade
Servers.
Legal Values • 1 (TRUE)
• 0 (FALSE)
Default 0
cfgNetTuning
This group enables users to configure the advanced network interface parameters for the RAC NIC or CMC. When
configured, the updated settings may take up to a minute to become active.
The following sections provide information about the objects in the cfgNetTuning group.
201
This group is applicable only for iDRAC on Rack and Tower Servers and not for iDRAC Enterprise on Blade Servers.
CAUTION: Use extra precaution when modifying properties in this group. Inappropriate modification of the
properties in this group can result in your RAC NIC become inoperable.
cfgNetTuningNicSpeed
Description Specifies the speed for the CMC NIC. This property is used
only if cfgNetTuningNicAutoNeg is set to 0.
Legal Values 10, 100, or 1000
Default 100
cfgNetTuningNicAutoneg (Read/Write)
Description Enables autonegotiation of physical link speed and duplex.
If enabled, autonegotiation takes priority over other values
set in this group.
Legal Values • 0 = Auto Negotiation is Disabled
• 1 = Auto Negotiation is Enabled
Default 1
Example
racadm getconfig -g cfgNetTuning
cfgNetTuningNicSpeed=100
cfgNetTuningNicFullDuplex=1
cfgNetTuningNicMtu=1500
cfgNetTuningNicAutoneg=1
cfgNetTuningNic100MB (Read/Write)
Description Specifies the speed to use for the RAC NIC. This property
is not used if cfgNetTuningNicAutoNeg is set to 0
(disabled).
Legal Values • 0 (10 MBit)
• 1 (100 MBit)
• 2 (1000 MBit)
Default 1
cfgNetTuningNicFullDuplex (Read/Write)
Description Specifies the duplex setting for the RAC or CMC NIC. This
property is used only if the cfgNetTuningNicAutoNeg is
set to 0 (disabled).
Legal Values • 0 (Half Duplex)
202
• 1 (Full Duplex)
Default 1
cfgNetTuningNicMtu (Read/Write)
Description The size in bytes of the maximum transmission unit used
by iDRAC or CMC NIC.
Legal Values 576 – 1500
Default 1500
NOTE: IPv6 requires a minimum MTU of 1280. If IPv6 is enabled, and cfgNetTuningMtu is set to a lower value, the
CMC uses an MTU of 1280.
cfgSensorRedundancy
This group is used to set the power supply redundancy. This group is applicable only for iDRAC.
The following sections provide information about the objects in the cfgSensorRedundancy group.
This group is applicable only for iDRAC on Rack and Tower Servers and not for iDRAC Enterprise on Blade Servers.
cfgSensorRedundancyIndex (Read Only)
Description Specifies index for the sensor redundancy group being
read. Only power supply redundancy is supported.
Legal Values 1
Default None
cfgSensorRedundancyPolicy (Read/Write)
Description Sets the power supply redundancy policy.
Legal Values • 2 - N/A, for sytems that are not supported
• 3 - Non Redundant
• 4 - 1+1 Redundant
• 4 - 2+1 Redundant
• 16 - 2+2 Redundant
Default Any legal value at that particular execution instance.
203
cfgSensorRedundancyCapabilities (Read Only)
Description Returns the redundancy capabilities in the form of a
bitmask. This bitmask allows the user to know which
values can be set for cfgSensorRedundancyPolicy.
Legal Values A bit mask. More than 1-bit can be set at a time to indicate
multiple redundancy support.
• 0- N/A, for sytems that are not supported
• 1- Non Redundant
• 2- 1+1 - Redundant
• 4- 2+1 - Redundant
• 8- 2+2 - Redundant
Default 0
cfgSensorRedundancyStatus (Read Only)
Description Indicates the redundancy status. The status is N/A on
platforms that does not support the power supply sensor
redundancy.
Legal Values String:
• N/A
• Full
• Lost
• Degraded
Default None
cfgVFlashSD
This group is used to configure the properties for the Virtual Flash SD card. This group is applicable only for iDRAC.
NOTE: If the vFlash card is present but is not enabled, the query for any property under this group displays:
ERROR: vFlash is not enabled.
To view the properties of this group, enable the vFlash using the command:
racadm config -g cfgvFlashSD -o cfgvFlashSDEnable 1
The following sections provide information about the objects in the cfgVFlashSD group.
204
cfgVFlashSDEnable (Read/Write)
Description Enables or disables the vFlash SD card.
NOTE: Disabling vFlashPartition by setting
cfgVFlashSDEnable to 0 does not require a license.
Legal Values • 0 (Disable)
• 1 (Enable)
Default 1
cfgVFlashSDSize (Read Only)
Description Displays the size of the vFlash SD card in megabytes (MB).
Legal Values A string of upto 64 characters.
Default <
card size
>
cfgVFlashSDLicensed (Read Only)
Description Displays whether a SD card or vFlash SD card is inserted.
The vFlash SD card supports the new enhanced vFlash
features and the SD card supports only the limited vFlash
features.
Legal Values • 0 (SD card is inserted)
• 1 (vFlash SD card is inserted)
Default None
cfgVFlashSDAvailableSize (Read Only)
Description Displays the available space (in MB) on the vFlash SD
card that can be used to create new partitions.
Legal Values A string of up to 64 characters.
Default If the card is not initialized, default is 0. If initialized,
displays the unused space on the card.
cfgVFlashSDHealth (Read Only)
Description Displays the current health status of the vFlash SD card.
Legal Values String:
• OK
• Warning
• Critical
205
• Unknown
Default OK
cfgVFlashSDWriteProtect (Read Only)
Description Displays whether the physical write-protect latch on the
vFlash SD card is enabled or disabled.
Legal Values • 0 (vFlash is not write-protected)
• 1 (vFlash is write-protected)
Default None
cfgVFlashPartition
This group is used to configure properties for individual partitions on the vFlash SD Card. Up to 16 partitions are
supported, indexed from 1 to 16. This group is applicable only for iDRAC.
NOTE: For SD cards, the index value is limited to 1 because only a single partition of size 256 MB is allowed.
The following sections provide information about the objects in the cfgVFlashPartition group.
cfgVFlashPartitionIndex ReadOnly
Description The index value of the partition.
Legal Values Integer from 1-16
Default None
cfgVFlashPartitionSize ReadOnly
Description Displays the size of the partition.
Legal Values 1 MB to 4 GB
Default None
cfgVFlashPartitionEmulationType (Read/Write)
Description Displays the emulation type for the partition.
Legal Values String:
• HDD
• Floppy
• CDROM
Default None
206
cfgVFlashPartitionOSVolLabel ReadOnly
Description Displays the label for the partition that is visible to the
operating system.
Legal Values An alphanumeric string of up to six characters.
Default None
cfgVFlashPartitionFormatType (ReadOnly)
Description Displays the format type of the partition.
Legal Values String:
• FAT16
• FAT32
• EXT2
• EXT3
• CD
• RAW
Default None
cfgVFlashPartitionAccessType (Read/Write)
Description Indicates the partition access permissions. It configures
the access type to read-write.
Legal Values • 0 (Read-only)
• 1 (Read-write)
Default 0
cfgVFlashPartitionAttachState (Read/Write)
Description Displays whether the partition is attached or detached.
NOTE: Detaching the vFlashPartition by setting
cfgVFlashPartitionAttachState to 0 does not require a
license.
Legal Values • 1 (Attached)
• 0 (Detached)
Default 0
207
cfgLogging
This group contains parameters to enable or disable the OEM event log filtering. This group is applicable only for iDRAC.
The following section provide information about the objects in the cfgLogging group:
cfgLoggingSELOEMEventFilterEnable (Read/Write)
Description Enables or disables the SEL Log filtering.
Legal Values • 0 (Disable)
• 1 (Enable)
Default 0
cfgRacSecurity
This group is used to configure settings related to CMC SSL certificate signing request (CSR) feature. The properties in
this group must be configured before generating a CSR from CMC.
Use this object with the config or getconfig subcommands.
To use this object property, you must have Chassis Configuration Administrator privilege. This object property is specific
to CMC only.
For iDRAC this group is replaced with cfgRacSecurityData.
For more information on generating certificate signing requests, see the subcommand "sslcsrgen."
The following sections provide information about the objects in the cfgRacSecurity group.
cfgRacSecCsrCommonName (Read/Write)
Description Specifies the CSR Common Name (CN) that must be an IP
or CMC name as given in the certificate.
Legal Values A string of up to 254 characters.
Default <
blank
>
cfgRacSecCsrOrganizationName (Read/Write)
Description Specifies the CSR Organization Name (O).
Legal Values A string of up to 254 characters.
Default <
blank
>
cfgRacSecCsrOrganizationUnit (Read/Write)
Description Specifies the CSR Organization Unit (OU).
Legal Values A string of up to 254 characters.
208
Default <
blank
>
cfgRacSecCsrLocalityName (Read/Write)
Description Specifies the CSR Locality (L).
Legal Values A string of up to 254 characters.
Default <
blank
>
cfgRacSecCsrStateName (Read/Write)
Description Specifies the CSR State Name (S).
Legal Values A string of up to 254 characters.
Default <
blank
>
cfgRacSecCsrCountryCode (Read/Write)
Description Specifies the CSR Country Code (CC).
Legal Values A string of 2 alphabet country code.
Default US
cfgRacSecCsrEmailAddr (Read/Write)
Description Specifies the CSR email address.
Legal Values A string of up to 254 characters.
Default <
blank
>
Example
racadm config -g cfgRacSecurity
cfgRacSecCsrKeySize=1024
cfgRacSecCommonName=
cfgRacSecOrganizationName=
cfgRacSecOrganizationUnit=
cfgRacSecLocalityName=
cfgRacSecStateName=
cfgRacSecCountryCode=
cfgRacSecEmailAddr=
cfgRacSecCsrKeySize (Read/Write)
Description Specifies the SSL asymmetric key size for the CSRs.
Legal Values 512, 1024, 2048
Default 1024
209
210
4
Database Objects With Get and Set Commands
These groups and object names must be used with the get and set commands.
When addressing these objects they must begin with either a FQDD or FQDD Alias.
These groups and objects are not applicable for CMC.
System.Power
This group provides information on power management features for iDRAC.
The following section provides information about the objects in the System.Power group.
System.Power.Status (Read Only)
Description Represents the device power state, either ON or OFF.
Legal Values • 0 - Server is off
• 1 - Server is on.
Default None
System.Power.ServerAllocation (Read Only)
Description Indicates the power allocated to running blades. This
value is displayed in both watts and BTU/h units.
Legal Values 0 - 7928
Default None
System.Power.Cap.MinThreshold (Read Only)
Description This is the lowest calculated power consumption of the
device. This is based on the current component inventory.
Legal Values None
Default None
System.Power.Cap.MaxThreshold (Read Only)
Description This is the highest calculated power consumption of the
device. This is based on the current component inventory.
Legal Values None
211
Default None
System.Power.Cap.Enable (Read/Write)
Description Enables Server Capping.
NOTE: This value is read only on Blade servers
because CMC controls the capping.
Legal Values • 0 - Disable
• 1 - Enable
Default 0
System.Power.Cap.Watts (Read Only)
Description Represents the Maximum Power in Watts a device is
allowed to consume. The device may throttle in order to
meet this capacity.
NOTE: This value is applicable only if
System.Power.Cap.Enable is set to 1.
Legal Values None
Default None
System.Power.Cap.Btuhr (Read/Write)
Description Represents the maximum power in BTU/Hr a device is
allowed to consume. The device may throttle in order to
meet this capacity.
NOTE: This value is applicable only if
System.Power.Cap.Enable is set to 1.
Legal Values String up to 32 characters.
Default None
System.Power.Hotspare.PrimaryPSU (Read/Write)
Description Represents the primary PSU selection.
NOTE: This value is supported only on iDRAC on Rack
and Tower servers.
Legal Values Integer values 1 - 2
Default 1
212
System.Power.Hotspare.Enable (Read/Write)
Description Enables RapidOn feature for the primary PSU selection.
NOTE: This value is supported only on iDRAC on Rack
and Tower servers.
Legal Values 0 - Disable
1- Enable
Default 0
System.Power.PFC.Enable (Read/Write)
Description Enables the power factor correction feature.
NOTE: This value is supported only on iDRAC on Rack
and Tower servers.
NOTE: This value is applicable only if
System.Power.Cap.Enable is set to 1.
Legal Values • 0 - Disable
• 1 - Enable
Default 0
System.Power.Max.Power (Read Only)
Description This is the device Peak Power Consumption since this
value was last cleared.
Legal Values String up to 32 characters.
Default None
System.Power.Max.Amps (Read Only)
Description Specifies the device Peak Power Consumption since this
value was last cleared.
Legal Values String up to 32 characters.
Default None
System.Power.Max.Amps.TimeStamp (Read Only)
Description Specifies the timestamp recorded for the Peak Power
Consumption since this value was last cleared.
Legal Values String up to 32 characters.
213
Time in the format Day Month Date HH:MM:SS Year
• HH = hour
• MM=Minutes
• SS = Seconds
• OO = Month
• DD = Day
• YYYY = Year
Default None
System.Power.Max.PowerClear Write Only
Description Clears the current recorded power statistics.
Legal Values 0 - Do not clear
1 - Clear the Power Consumption Statistics
Default None
System.Power.Avg.LastHour (Read Only)
Description Displays the average power value during the last hour.
Legal Values Integer > 0
Default None
System.Power.Avg.LastDay (Read Only)
Description Displays the average power value during the last day.
Legal Values Integer > 0
Default 0
System.Power.Min.LastDay.TimeStamp (Read Only)
Description Displays the minimum power value during the last day.
Legal Values Integer > 0
Default 0
System.Power.Max.LastDay (Read Only)
Description Displays the maximum power value during the last day.
Legal Values Integer > 0
Default 0
214
System.Power.Max.LastDay.TimeStamp (Read Only)
Description Displays the timestamp of maximum power value during
the last day.
Legal Values Time in the format Day Month Date HH:MM:SS Year
• HH = hour
• MM=Minutes
• SS = Seconds
• OO = Month
• DD = Day
• YYYY = Year
Default 0
System.Power.Avg.LastWeek (Read Only)
Description Displays the average power value during the last week.
Legal Values Integer > 0
Default 0
System.Power.Min.LastWeek.TimeStamp (Read Only)
Description Displays the timestamp of minimum power value during
the last week.
Legal Values Time in the format Day Month Date HH:MM:SS Year
• HH = hour
• MM=Minutes
• SS = Seconds
• OO = Month
• DD = Day
• YYYY = Year
Default 0
System.Power.Max.LastWeek (Read Only)
Description Displays the maximum power value during the last week.
Legal Values Integer > 0
Default 0
215
System.Power.Max.LastWeek.TimeStamp (Read Only)
Description Displays the timestamp of maximum power value during
the last week.
Legal Values Time in the format Day Month Date HH:MM:SS Year
• HH = hour
• MM=Minutes
• SS = Seconds
• OO = Month
• DD = Day
• YYYY = Year
Default 0
System.Power.RedundancyPolicy (Read/Write)
Description Sets the redundancy policy of the system.
NOTE: This object is not applicable on iDRAC on Blade
servers. iDRAC on Blade servers does not control
power supplies.
Legal Values • 0 - No Redundancy
• 1 - AC redundancy
• 2 - Power supply redundancy (DC Redundancy)
Default 0
System.Power.RedundancyCapabilities (Read Only)
Description Returns the redundancy capabilities in the form of a
bitmask. This bitmask indicates the values that are set by
cfgSensorRedundancyPolicy.
NOTE: This object is not applicable on iDRAC on Blade
servers.
Legal Values A Bit Mask.
More than 1 bit can be set at a time to indicate multiple
redundancy support.
• 0 - not applicable
• 1 - Non Redundant
• 2 - 1+1 Redundant
• 4 - 2+1 Redundant
• 8 - 2+2 Redundant
• 16 - 3+x Redundant
• 32 - 4+x Redundant
216
• 64 - 5+x Redundant
Default 0
System.Power.RedundantState (Read Only)
Description Retrieves the redundancy state for the chassis.
Legal Values • 0 - None
• 1 - Full
Default 0
System.Power.Cap.Percent (Read/Write)
Description Represents the maximum power as a percentage of total
power that a device is allowed to consume. The device
may throttle in order to meet this cap.
NOTE: This value is applicable only if
System.Power.Cap.Enable is set to 1.
Legal Values String up to 32 characters.
Default None
System.Power.EnergyConsumption (Read Only)
Description Represents the power being consumed by the blade or
system.
Legal Values String upto 32 characters.
Default None
System.Power.EnergyConsumption.Clear Write Only
Description Resets energy statistics, when set to 1.
Legal Values Write Only field accepts 1 as input, all other values are
invalid.
Default None
217
System.Power.Max.Headroom Write Only
Description Displays the difference between the available power and
the current power consumption.
NOTE: This object is not applicable on iDRAC on Blade
servers.
Legal Values Integer > 0
Default 0
System.Power.EnergyConsumption.StarttimeStamp
Description Displays the Start time for the Power Consumption.
Legal Values Time in the format Day Month Date HH:MM:SS Year
• HH = hour
• MM=Minutes
• SS = Seconds
• OO = Month
• DD = Day
• YYYY = Year
Default None
System.Power.PCIeAllocation (Read/Write)
Description Specifies the amount of power allocated to the PCIe card.
NOTE: This object only applies to servers that support
PCIe Card.
Legal Values • 0
• 100
• 500
Default • 0 on non expansler/scalpel systems
• 500 on expansler/scalpel systems
System.Power.Supply
This group provides information relating to the Power Supplies.
This group is indexed from 1 to 4. If there are less than 4 power supplies on the server, then some of the last indexes of
this group are not applicable. This group is not applicable on iDRAC on Rack and Tower servers.
The following section provides information about the objects in the <System>.Power.Supply group.
218
System.Power.Supply.[i].MaxInputPower (Read Only)
Description Displays the AC input rated power in Watts.
Legal Values Integer > 0
Default 0
System.Power.Supply.[i].MaxOutputPower ((Read Only))
Description Displays the DC output rated power in Watts.
Legal Values Integer > 0
Default 0
System.Power.Supply.[i].Status (Read Only)
Description Displays the status of the power supply unit.
Legal Values • 0 - absent
• 1 - present and OK
• 2 - failure
• 3 - predictive failure
Default 0
System.Power.Supply.[i].FwVer (Read Only)
Description Displays the FW version of the PSU, in the format x.xx.xxx.
Legal Values String up to 8 characters.
Default 0
System.Power.Supply.[i].CurrentDraw (Read Only)
Description Displays the instantaneous current consumption in 0.1
Amps.
Legal Values Integer > 0
Default 0
System.Power.Supply.[i].Type (Read Only)
Description Displays whether the power supply is AC or DC. This is an
indexed group and the square brackets are only place-
holders, and do not form a part of command syntax.
Legal Values String upto 32 characters.
219
Default None
System.Power.Supply.[i].LineStatus (Read Only)
Description Specifies if this power supply is powered off or on.
Legal Values Integer > 0
Default None
System.Power.Supply.[i].PMBusMonitoring (Read Only)
Description Specifies if this PMBus is present or not.
Legal Values Integer > 0
Default 0
System.Location
This group provides information on the server's physical location characteristics.
This group is not applicable for iDRAC.
The following section provides information about the objects in the <System>.Location group.
System.Location.DataCenter (Read/Write)
Description Indicates DataCenter name.
Legal Values String of up to 128 ASCII characters
Default 0
System.Location.Aisle (Read/Write)
Description Indicates aisle where server is located.
Legal Values String of up to 128 ASCII characters
Default 0
System.Location.Rack.Name (Read/Write)
Description Indicates rack where server is located.
Legal Values String of up to 128 ASCII characters
Default 0
220
System.Location.Rack.Slot (Read/Write)
Description Indicates the slot where server is located.
Legal Values 1- 255 (1 Byte)
Default 0
System.Location.DeviceSize (Read Only)
Description Indicates server chassis size.
Legal Values 1- 255
Default 0
System.Location.Chassis.Name Read or Write
Description Indicates chassis name.
Legal Values String of up to 127 ASCII characters
Default 0
System.Location.Chassis.Slot Read Only
Description Indicates chassis slot.
Legal Values 1- 255
Default 0
LifecycleController.LCAttributes
This group provides information on the Lifecycle Controller Configuration.
This group is not applicable for CMC.
The following section provides information about the objects in the LifecycleController.LC Attributes group.
LifecycleController.LCAttributes.CollectSystemInventoryOnRestart (Read/Write)
Description Enables or disables Collect System Inventory On Restart.
Legal Values • 0 - Disable
• 1 - Enable
Default 1
221
LifecycleController.LCAttributes.LifecycleControllerState (Read/Write)
Description Configures the lifecycle controller state.
Legal Values • 0 - Disable
• 1 - Enable
• 2 - Recovery mode
Default 2
LifecycleController.LCAttributes.PartFirmwareUpdate (Read/Write)
Description Configures the Part Firmware Update.
Legal Values • 0 - Disable
• 1 - Allow version upgrade only.
• 2 - Match firmware of replaced part.
Default 0
LifecycleController.LCAttributes.PartConfigurationUpdate (Read/Write)
Description Configures the Part Configuration Update.
Legal Values • 0 - Disable
• 1 - Apply always.
• 2 - Apply only if firmware match.
Default 0
System.LCD
This group provides information on the lcd string set by the user.
The following section provides information about the objects in the System.LCD group.
NOTE: The System.LCD get and set command works on iDRAC on Blade Server, even if the LCD is not present on
the server.
System.LCD. LCDUserString (Read/Write)
Description Indicates the lcd string set by the user.
Legal Values String of up to 62 ASCII characters
Default 0
222
iDRAC.IMC
This group provides information on managing the administrative state of the Internal Management Communication
(IMC.)
iDRAC.IMC.AdministrativeState (Read/Write)
Description Manage the administrative state of the IMC.
Legal Values String of up to 62 ASCII characters
• 0 - Disable
• 1 - Enable
Default 0
