Specifications
Copyright © 2014 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
2014 ‑ 09 Rev. A01
Regulatory model: P53G | Type: P53G001
Computer model: Inspiron 14‑3442
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
3000 Series
Inspiron 14
1 Power and battery‑status light
Indicates the power state and battery state of the
computer.
White light Battery is getting charged.
Amber Battery is low or critical.
Off • Computer is plugged in and
the battery is fully charged.
• Computer is running on battery and
battery has more than 10% charge.
1
Views
Specifications
Front
Left
Right
Base
Display
Front
1 Security‑cable slot
Connect a security cable to prevent unauthorized
movement of your computer.
2 Power‑adapter port
Connect a power adapter to provide power to your
computer and charge the battery.
3 HDMI port
Connect a TV or another HDMI‑in enabled device.
Provides video and audio output.
4 Network port
Connect an Ethernet (RJ45) cable from a router or a
broadband modem for network or internet access.
5 USB 2.0 port
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to
480 Mbps.
6 USB 3.0 port
Connect peripherals such as storage devices, printers,
and so on. Provides data transfer speeds up to 5 Gbps.
7 Headset port
Connect a headphone, a microphone, or a headphone
and microphone combo (headset).
1 2 43 5 6 7
Views
Specifications
Front
Left
Right
Base
Display
Left
1 Power button
Press to turn on the computer if it is turned off or in
Sleep state.
Press to put the computer in Sleep state if it is turned on.
Press and hold for 10 seconds to force shut‑down the
computer.
NOTE: You can customize the power‑button behavior in
Power Options. For more information, see
Me and My Dell at dell.com/support.
2 Right‑click area
Press to right click.
3 Touchpad
Move your finger on the touchpad to move the mouse
pointer. Tap to left‑click.
4 Left‑click area
Press to left click.
1
234
Views
Specifications
Front
Left
Right
Base
Display
Base
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Dimensions and Weight
Height:
Touch 26.6 mm (1.04 in)
Non‑touch 25.4 mm (1 in)
Width 346 mm (13.62 in)
Depth 246 mm (9.68 in)
Weight (maximum):
Touch 2.11 kg (4.65 lb)
Non‑touch 2.01 kg (4.43 lb)
NOTE: The weight of your laptop varies depending on the configuration ordered
and the manufacturing variability.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
System Information
Computer model Inspiron 14‑3442
Processor • 4th Generation Intel Core i3 Processor (U‑Processor Line)
• 4th Generation Intel Core i5 Processor (U‑Processor Line)
• 4th Generation Intel Core i7 Processor (U‑Processor Line)
• Intel Pentium Dual Core
• Intel Celeron
Chipset Integrated in processor
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Memory
Slot One SODIMM slot
Type DDR3L
Speed 1600 MHz
Configurations supported 2 GB, 4 GB, and 8 GB
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Ports and Connectors
External:
Network One RJ45 port
USB • One USB 3.0 port
• Two USB 2.0 ports
Audio/video • One HDMI port
• One headphone and microphone combo (headset) port
Internal:
Mini‑card One mini‑card slot for Wi‑Fi and Bluetooth combo card
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Communications
Ethernet 10/100 Mbps Ethernet controller integrated on systemboard
Wireless • 802.11 b/g/n
• Bluetooth 4.0
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Video
Controller:
Integrated • Intel HD Graphics 4400 — Intel Core i3/i5/i7
• Intel HD Graphics — Intel Pentium Dual Core/Celeron
Discrete nVidia GeForce 820M
Memory:
Integrated Shared system memory
Discrete Up to 2 GB DDR3L
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Audio
Controller Realtek ALC3234 High‑Definition Audio Codec with Waves MaxxAudio
Speakers Two
Output:
Average 2 watt
Peak 2.5 watt
Microphone Digital microphone
Volume controls Media‑control shortcut keys
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Storage
Interface SATA 6 Gbps
Hard drive One 2.5‑inch drive
Optical drive One 9.5 mm DVD+/‑RW drive
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Media‑card reader
Type One 3‑in‑1 slot
Cards supported • SD card
• SD High‑Capacity (SDHC) card
• SD Extended Capacity (SDXC) card with UltraHigh Speed (UHS)
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Display
Type 14.0‑inch HD
Resolution (maximum) 1366 x 768
Dimensions:
Height 205.6 mm (8.09 in)
Width 320.9 mm (12.63 in)
Diagonal 355.6 mm (14 in)
Refresh rate 60 Hz
Operating angle 0 degrees (closed) to 135 degrees
Pixel pitch 0.2265 mm
Controls Brightness can be controlled using shortcutkeys.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Keyboard
Shortcut keys Some keys on your keyboard have two symbols on them. These keys can be
used to type alternate characters or to perform secondary functions. To type
the alternate character, press Shift and the desired key. To perform secondary
functions, press Fn and the desired key.
NOTE: You can define the primary behavior of the shortcut keys by changing
Function Key Behavior in System Setup.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Camera
Resolution:
Still image 0.92 megapixel
Video 1280 x 720 HD @ 30 FPS
Diagonal viewing angle 74 degrees
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Touchpad
Resolution:
Horizontal
Vertical
1207 dpi
1702 dpi
Dimensions:
Width 102.4 mm (4.03 in)
Height 57.4 mm (2.25 in)
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Battery
Type 4‑cell “smart” lithium ion (40 WHr)
Dimensions:
Width 272.40 mm (10.72 in)
Depth 46.30 mm (1.82 in)
Height 20.00 mm (0.79 in)
Weight (maximum) 0.26 kg (0.57 lb)
Voltage 14.80 VDC
Charging time when the
computer is off (approximate)
4 hours
Operating time Varies depending on operating conditions and can significantly reduce under
certain power‑intensive conditions.
Life span (approximate) 300 discharge/charge cycles
Temperature range:
Operating 0°C to 35°C (32°F to 95°F)
Storage –40°C to 65°C (–40°F to 149°F)
Coin‑cell battery CR‑2032
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Power Adapter
Type 65 W
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Input current (maximum) 1.50 A/1.60 A/1.70 A/2.50 A
Output current (continuous) 3.34 A/4.62 A
Rated output voltage 19.50 VDC
Temperature range:
Operating 0°C to 40°C (32°F to 104°F)
Storage –40°C to 70°C (–40°F to 158°F)
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight
Computer
Environment
Storage
Touchpad Power AdapterCamera
Communications
Battery
Video Audio
Display
Media‑Card
Reader Keyboard
Computer Environment
Airborne contaminant level G1 as defined by ISA‑S71.04‑1985
Operating Storage
Temperature range 0°C to 40°C (32°F to 104°F) –40°C to 65°C (–40°F to 149°F)
Relative humidity (maximum) 10% to 90% (non‑condensing) 0% to 95% (non‑condensing)
Vibration (maximum)*0.66 GRMS 1.30 GRMS
Shock (maximum) 110 G†160 G‡
* Measured using a random vibration spectrum that simulates user environment
† Measured using a 2 ms half‑sine pulse when the hard drive is in use.
‡ Measured using a 2 ms half‑sine pulse when the hard‑drive head is in parked position.
