Specifications
3647
Copyright © 2013–2014 Dell Inc. All rights reserved. This product is protected by U.S. and international
copyright and intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States
and/or other jurisdictions. All other marks and names mentioned herein may be trademarks of their respective
companies.
2014 ‑ 06 Rev. A02
Regulatory model: D09S | Type: D09S001
Computer model: Inspiron 3647
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
Front I/O-panel door (open)
Covers the Front I/O‑panel.
Media-card reader
Reads from and writes to media cards.
Headphone port
Connect a headphone orspeakers.
Hard-drive activity light
Turns on when the computer reads from
or writes to the hard drive.
Power button
Press to turn on the computer if it is
turned off or in Sleep state.
Press to put the computer in Sleep state if
it is turned on.
Press and hold for 10 seconds to force
shut‑down the computer.
NOTE: You can customize the
power‑button behaviour in Power
Options. For more information, see
Me and My Dell at dell.com/support.
Optical-drive cover
Covers the optical drives.
Microphone port
Connect an external microphone to
provide sound input.
USB 2.0 ports (2)
Connect peripherals such as storage
devices, printers, and so on. Provides data
transfer speeds up to 480 Mbps.
Optical-drive eject button
Press to open or close the optical drive
tray.
Front
Headphone port
USB 2.0 ports (2)
Front I/O-panel door (open)
Media-card reader
Hard-drive activity light
Power button
Microphone port
Optical-drive eject button
Optical-drive cover
Views
Specifications
Front
Back
Back panel
Security-cable slot
Connect a security cable to prevent unauthorized movement of
your computer.
Power cable port
Connect a power cable to provide power to your computer.
Power supply light
Indicates power availability of the power supply.
Expansion-card slots
Provide access to connectors on any installed PCI Express cards.
Back panel
Connect USB, audio, video, and other devices.
Back
Security-cable slot
Back panel
Expansion-card slots
Power cable port
Power supply light
Views
Specifications
Front
Back
Back panel
Line-in port
Connect recording or playback devices such as a microphone or
CD player.
Network port
Connect an Ethernet (RJ45) cable from a router or a broadband
modem for network or internet access.
The two lights next to the connector indicate the connectivity
status and network activity.
Line-out port
Connect speakers.
Microphone port
Connect an external microphone to provide sound input.
VGA port
Connect an external display or a projector.
HDMI-out port
Connect to HDMI‑out enabled devices. Provides video and
audio output.
USB 3.0 ports (2)
Connect peripherals such as storage devices, printers, and soon.
Provides data transfer speeds up to 5 Gbps.
USB 2.0 ports (4)
Connect peripherals, such as storage devices, printers, and
soon. Provides data transfer speeds up to 480 Mbps.
Back panel
USB 3.0 ports (2)
HDMI-out port
VGA port
USB 2.0 ports (4)
Network port
Microphone port
Line-in port
Line-out port
Views
Specifications
Front
Back
Back panel
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Dimensions and Weight
Height 265 mm (10.43 in)
Width 100 mm (3.94 in)
Depth 347.8 mm (13.70 in)
Weight (maximum) 6.0 kg (13.22 lb)
NOTE: The weight of your desktop varies depending on the configuration ordered
and the manufacturing variability.
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
System Information
Computer model Inspiron 3647
Processor • Intel Core i3 (4th Generation)
• Intel Core i5 (4th Generation)
• Intel Core i7 (4th Generation)
• Intel Celeron
• Intel Pentium
L3 cache up to 8 MB
Chipset Intel H81 PCH
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Memory
Connector Two internally‑accessible DDR3 DIMM sockets
Type DDR3
Speed 1600 MHz
Configurations supported 2 GB, 4 GB, 8 GB, 12 GB, and 16 GB
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Ports and Connectors
Network One RJ45 port
USB • Six USB 2.0 port
• Two USB 3.0 ports
HDMI One HDMI‑out port
Audio • One headphone port
• Two microphone ports
• One line‑out port
• One line‑in port
Video • One 15‑hole VGA port
• One 19‑pin HDMI port
Media Card Reader One 8‑in‑1 card slot
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Communications
Ethernet 10/100/1000 Mbps Ethernet controller integrated on systemboard
Wireless Dell Wireless‑N 1705 and Bluetooth 4.0
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Video
Controller:
Integrated • Intel HD Graphics
• Intel HD Graphics 4400/4600
Discrete • NVIDIA GeForce GT 625
• NVIDIA GeForce GT 635
Memory:
Integrated Shared system memory
Discrete 1024 MB
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Storage
Externally accessible One 5.25‑inch drive bay for a Blu‑ray Disc combo (optional),
Blu‑ray Disc writer (optional), or DVD+/‑RW
Internally accessible One 3.5‑inch drive bay for SATA hard drives (includes hybrid)
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Media-card reader
Type One 8‑in‑1 slot
Cards supported • Secure Digital (SD)
• SD Extended Capacity Card (SDXC)
• High Capacity SD (SDHC)
• Memory Stick (MS)
• Memory Stick PRO (MS PRO)
• Multimedia Card (MMC)
• Multimedia Card Plus (MMC+)
• xD‑Picture Card (XD)
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Power Ratings
Type 220 W
Input voltage • 100 VAC‑127 VAC
• 200 VAC‑240 VAC
Input frequency 50 Hz–60 Hz
Input current (maximum) 6 A/3 A
Specifications
Views
System
Information Memory Ports and
Connectors
Dimensions and
Weight StorageCommunications Video Audio
Power Ratings
Media‑card
reader
Computer
Environment
Computer Environment
Airborne contaminant level G2 or lower as defined by ISA‑S71.04‑1985
Relative humidity (maximum) 20% to 80% (noncondensing)
Operating Storage
Temperature range 10 °C to 35 °C (50 °F to 95 °F) –10 °C to 45 °C (–14 °F to 113 °F)
Vibration (maximum)*0.25 GRMS 2.20 GRMS
Shock (maximum)†40 G for 2 ms with a change
in velocity of 20 in/s (51 cm/s)
50 G for 26 ms with a change
in velocity of 320 in/s (813 cm/s)
Altitude (maximum) –15.2 m to 3048 m
(–50 ft to 10,000 ft)
–15.2 m to 10,668 m
(–50 ft to 35,000 ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured with hard drive in operating status and a 2‑ms half‑sine pulse for operating. Also measured with hard drive in head‑parked position and a 2‑ms
half‑sine pulse for storage.
