Specifications
Copyright © 2015 Dell Inc. All rights reserved. This product is protected by U.S. and international copyright and
intellectual property laws. Dell and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.
2015 ‑ 07 Rev. A00
Regulatory model: D05S | Type: D05S003
Computer model: Alienware X51 R3
Alienware X51
NOTE: The images in this document may differ from your computer
depending on the configuration you ordered.
1 Power button
Press to turn on the computer if it
is turned off or in sleep state.
Press to put the computer in sleep
state if it is turned on.
Press and hold for 6 seconds to
force shut‑down the computer.
NOTE: You can customize
the power‑button behaviour
in Power Options. For more
information, see Me and My Dell
at www.dell.com/support/
manuals.
2 Optical-drive eject button
Press to open or close the
optical‑drive tray.
3 Optical drive (optional)
Reads from and writes to
CDs and DVDs.
4 Microphone port
Connect an external microphone to
provide sound input.
5 Headphone port
Connect a headphone orspeakers.
6 USB 3.0 ports (2)
Connect peripherals such as
storage devices, printers, and so
on. Provides data transfer speeds
up to 5 Gbps.
Front
6
5
4
1
2
3
Views
Specifications
Front
Back
Back panel
1 Back panel
Connect USB, audio, video, and other devices.
2 Hard-drive activity light
Turns on when the computer reads from or writes to the
hard drive.
3 Power-adapter port
Connect a power adapter to provide power to your
computer.
4 Discrete graphics card
Connect external display devices to the discrete graphics
card.
5 Security-cable slot
Connect a security cable to prevent unauthorized
movement of your computer.
Back
1
2
5
4
3
Views
Specifications
Front
Back
Back panel
Back panel
1 HDMI port
Connect a TV or another HDMI‑in
enabled device. Provides video and
audio output.
NOTE: If your computer shipped
with a discrete graphics card, the
HDMI port is covered.
2 USB 3.0 ports (2)
Connect peripherals such as
storage devices, printers, and so
on. Provides data transfer speeds
up to 5 Gbps.
3 USB 2.0 ports (2)
Connect peripherals such as
storage devices, printers, and so
on. Provides data transfer speeds
up to 480 Mbps.
4 External graphics port
Connect an Alienware Graphics
Amplifier.
5 USB 3.1 ports (2)
Connect peripherals, such as
storage devices, printers, and
soon. Provides data transfer
speeds up to 10 Gbps.
6 Line-out port
Connect audio‑output devices such
as speakers, amplifiers, and so on.
In a 5.1 speaker channel setup,
connect the front‑left and ‑right
speakers.
7 Center/Subwoofer LFE port
Connect the subwoofer.
NOTE: For more information
about the speaker setup, refer
the documentation that shipped
with the speakers.
8 Side L/R surround port
Connect the side‑left and ‑right
speakers or surround sound
speakers.
9 Network port
Connect an Ethernet (RJ45) cable
from a router or a broadband
modem for network or internet
access.
The two lights next to the
connector indicate the connectivity
status and network activity.
9
7
8
1
2
3
4
5
6
Views
Specifications
Front
Back
Back panel
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Dimensions and weight
Height
Front 343 mm (13.50 inches)
Back 318.50 mm (12.53 inches)
Width 95 mm (3.74 in)
Depth 318 mm (12.52 in)
Weight (maximum) 5.49 kg (12.10 lbs)
NOTE: The weight of your desktop varies depending on the configuration ordered
and the manufacturing variability.
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
System information
Computer model Alienware X51 R3
Processor • 6th Generation Intel Core i7 Processor
• 6th Generation Intel Core i5 Processor
Chipset Intel Z170 chipset
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Memory
Slot Two internally‑accessible DDR4 DIMM socket
Capacities of each slot 4 GB, 8 GB, and 16 GB
Type DDR4 SDRAM (Non‑ECC)
Speed 2133 MHz
NOTE: The memory is over‑clocked to 2400 MHz or 2667 MHz
Configurations supported 4 GB, 8 GB, 16 GB, and 32 GB
Minimum 4 GB
Maximum 32 GB
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Ports and connectors
Back‑panel ports:
Network One RJ45 port
USB • Two USB 2.0 ports
• Two USB 3.0 ports
• Two USB 3.1 ports
Audio • One Line‑out port
• One Rear L/R surround port
• One Center/Subwoofer LFE port
Video One HDMI port
NOTE: If your computer shipped with a discrete graphics card, the HDMI port on the
back panel of your computer is covered.
Front‑panel ports:
USB Two USB 3.0 ports
Audio • One audio output/headphone port
• One audio input/microphone port
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Video
Controller:
Integrated Intel HD Graphics 530
Discrete PCI Express x 16, single‑/dual‑width video cards
Memory:
Discrete 2‑GB Graphics DDR5
NOTE: The video memory of your desktop will vary depending on the configuration
ordered.
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Storage
Interface • SATA 3 Gbps for optical drive
• SATA 3 Gbps for hard drive
Hard drive • One 3.5‑inch drive
• two 2.5‑inch drives
Optical drive One 5.25‑inch DVD+/‑RW drive (optional)
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Power adapter
Type 180 W, 240 W, or 330 W
Input voltage 100 VAC–240 VAC
Input frequency 50 Hz–60 Hz
Input current 12.3 A/16.9 A
Output current:
180 9.23 A
240 12.31 A
330 16.09 A
Rated output voltage 19.50 VDC
Temperature range:
Operating 0°C to 40°C (32°F to 104°F)
Storage –40°C to 70°C (–40°F to 158°F)
Specifications
Views
System
information Memory Ports and
connectors
Dimensions and
weight StorageCommunications Video Audio
Power adapter Computer
environment
Computer environment
Airborne contaminant level G2 or lower as defined by ISA‑S71.04‑1985
Relative humidity (maximum) 20% to 80% (noncondensing)
Operating Storage
Temperature range 10°C to 35°C (50°C to 95°F) –40°C to 65°C (–40°F to 149°F)
Vibration (maximum)*0.25 GRMS 2.20 GRMS
Shock (maximum) 40 G for 2 ms with a change
in velocity of 20 in/s (51 cm/s)†
50 G for 26 ms with a change
in velocity of 320 in/s (813 cm/s)‡
Altitude (maximum) –15.24 m to 3048 m
(–50 ft to 10,000 ft)
–15.24 m to 10,668 m
(–50 ft to 35,000 ft)
* Measured using a random vibration spectrum that simulates user environment.
† Measured using a 2 ms half‑sine pulse when the hard drive is in use.
‡ Measured using a 2 ms half‑sine pulse when the hard‑drive head is in parked position.
