Strong IT Foundation

The Dell PowerEdge R610 is a key building block for today’s data

center. Designed for versatility and high performance, it provides

many of the virtualization, system management, and energy-

eciency features you need now and the scalability necessary

to change as your business grows. This general purpose Intel®

processor-based 2-socket 1U server is ideal for corporate data

centers and remote sites that require a dense, highly available

single- or dual-processor server at an excellent value.

Purposeful Design

The PowerEdge R610 follows the 11th generation PowerEdge

portfolio specifications and features the same system design

commonality and reliability true to the entire portfolio. All 11th

generation servers are designed to make the experience easier.

We put all external ports, power supplies, LCD screens, and LED

lights in the same location for familiar experience as well as easy

installation and deployment.

Robust, metal hard drive carriers and organized cabling are

designed to help improve component access and airflow across

the server. The PowerEdge R610 provides an interactive LCD

screen or LED display positioned on the front of the server for ease

of monitoring and troubleshooting condition of the server.

Enhanced Virtualization

Featuring Intel® Xeon® processor-based architecture, embedded

hypervisors, and expanded memory footprint and I/O, the Dell

PowerEdge R610 delivers exceptional overall system performance

and significant virtual machine-per-server capacity versus the

previous generation. With optional factory-integrated virtualization

capabilities, you get tailored solutions—built with the latest

technologies from Dell and our trusted partners—which allow

you to streamline deployment and simplify virtual infrastructures.

Choose your hypervisor from market leaders such as VMware®,

Citrix®, and Microsoft®, and enable virtualization with a few mouse

clicks.

Energy-Optimized Technologies

Dell’s advanced thermal control helps optimize performance

while minimizing system power consumption, ultimately driving

energy eciency across our latest core data center servers.

These enhancements, over previous generations, include ecient

power supply units right-sized for system requirements, improved

system-level design eciency, policy-driven power and thermal

management, and highly ecient standards-based Energy Smart

components. Dell’s advanced thermal control is designed to

deliver optimal performance at minimum system and fan power

consumption resulting in our quietest mainstream 1U servers to

date.

Simplified Systems Management

With the optional advanced embedded systems management

capabilities of Lifecycle Controller, Dell provides comprehensive

enterprise class manageability already on the motherboard.

Lifecycle Controller is delivered as part of the optional iDRAC

Express or iDRAC Enterprise in the PowerEdge R610. The Lifecycle

Controller helps to simplify administrator tasks by performing

a comprehensive set of provisioning functions such as system

deployment, system updates, hardware configuration and

diagnostics from a single intuitive interface called Unified Server

Configurator (USC) in a pre-OS environment. This helps eliminate

the need to use and maintain multiple pieces of disparate CD/DVD

media.

Also part of the Dell OpenManage™ portfolio is the Dell

Management Console which is included with every Dell server

and provides IT administrators with a consolidated console view of

their IT infrastructure.

Dell Services

Dell Services can help reduce IT complexity, lower costs, and

eliminate ineciencies by making IT and business solutions work

harder for you. The Dell Services team takes a holistic view of your

needs and designs solutions for your environment and business

objectives while leveraging proven delivery methods, local talent,

and in-depth domain knowledge for the lowest TCO.

Dell PowerEdge R610

Inspired by customer

feedback, the Dell

PowerEdge R610 server

is engineered to simplify

data center operations,

improve energy

eciency, and lower

total cost of ownership.

The Dell™ PowerEdge™ R610 oers simplified management, purposeful design, and energy eciency

combined in a rack server that can help you better manage your enterprise.

March 2011

Learn more at Dell.com/PowerEdge

© 2011 Dell Inc. All rights reserved. Dell, the DELL logo, the DELL badge, PowerEdge, and OpenManage are trademarks of Dell Inc. Other trademarks and trade

names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the

marks and names of others. This document is for informational purposes only. Dell reserves the right to make changes without further notice to any products

herein. The content provided is as is and without express or implied warranties of any kind.

Feature Technical Specification

Form Factor 1U rack

Processors Quad-core or six-core Intel® Xeon® processors 5500 and 5600 series

Processor Sockets 2

Front Side Bus or

HyperTransport Intel® QuickPath Interconnect (QPI)

Cache 4MB and 8MB

Chipset Intel® 5520

Memory1Up to 192GB (12 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3 up to 1333MHz

I/O Slots

2 PCIe G2 slots + 1 storage slot:

Two x8 slots

One storage x4 slot

RAID Controller

Internal:

PERC H200 (6Gb/s)

PERC H700 (6Gb/s) with 512MB battery-backed cache;

512MB, 1GB Non-Volatile battery-backed cache

SAS 6/iR

PERC 6/i with 256MB battery-backed cache

External:

PERC H800 (6Gb/s) with 512MB of battery-backed cache;

512MB, 1GB Non-Volatile battery-backed cache

PERC 6/E with 256MB or 512MB of battery-backed cache

External HBAs (non-RAID):

6Gbps SAS HBA

SAS 5/E HBA

LSI2032 PCIe SCSI HBA

Drive Bays Internal hard drive bay and hot-plug backplane.

Up to six 2.5” SAS, or SSD Drives

Maximum Internal Storage Up to 12TB

Hard Drives1Hot-plug Hard Drive Options:

2.5” SAS SSD, SATA SSD, SAS (10K, 15K), nearline SAS (7.2K), SATA (7.2K)

Communications

Two dual port embedded Broadcom® NetXtreme® II 5709c Gigabit Ethernet NIC with failover and load balancing. Optional

1GBe and 10GBe add-in NICs

Broadcom® NetXtreme® II 57711 Dual Port Direct Attach 10Gb Ethernet PCI-Express Network Interface Card with TOE and

iSCSI Ooad

Intel® Gigabit ET Dual Port Server Adapter and Intel® Gigabit ET Quad Port Server Adapter

Dual Port 10GB Enhanced Intel Ethernet Server Adapter X520-DA2 (FCoE Ready for Future Enablement)

Brocade® CNA Dual-port adapter

Emulex® CNA iSCSI HBA stand up adapter OCE10102-IX-D

Emulex® OCE10102-IX-DCNA iSCSI HBA stand-up adapter

Optional Add-In HBA’s:

Brocade® 8 GB HBAs

Power Supply

Two hot-plug high-ecient 502W Energy Smart PSU or two hot-plug 717W High Output PSUs

Uninterruptible Power Supplies:

1000W-5600W

2700W-5600W High Eciency Online

Extended Battery Module (EBM)

Network Management Card

Availability

DDR3 memory; ECC; hot-plug hard drives; optional hot-plug redundant power supplies; dual embedded NICs with

failover and load balancing support; optional PERC6/i integrated daughtercard controller with battery-backed cache; hot-

plug redundant cooling; tool-less chassis; fibre and SAS cluster support; validated for Dell/EMC SAN

Video Integrated Matrox® G200, 8MB shared video memory

Remote Management iDRAC6 Enterprise (optional)

Systems Management Dell™ OpenManage™

Embedded Hypervisor Optional Embedded SD Media

Rack Support ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for

threaded hole racks); ReadyRails™ static rails for 2-post and 4-post racks

Operating Systems

Microsoft® Windows® Small Business Server 2011

Microsoft®Windows®Small Business Server 2008

Microsoft® Windows Server® 2008 SP2, x86/x64 (x64 includes Hyper-V™)

Microsoft® Windows Server® 2008 R2, x64 (includes Hyper-V™ v2)

Microsoft® Windows® HPC Server 2008 R2

Novell® SUSE® Linux® Enterprise Server

Red Hat® Enterprise Linux®

Oracle® Solaris™

Virtualization Options:

Citrix® XenServer™

VMware® vSphere™ 4.1 (including VMware ESX® 4.1 or VMware ESXi™ 4.1)

For more information on the specific versions and additions, visit www.dell.com/OSsupport.

Featured Database

Applications

Microsoft® SQL Server® solutions (see Dell.com/SQL)

Oracle® database solutions (see Dell.com/Oracle)

1 GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.

OEM Ready Models Available

OEM Ready platforms are grab-and-go products for OEM customers delivering a fast and simple

path to a custom-branded solution. For more information, please visit dell.com/OEM.
