The Dell
Precision™ M6400
The Dell Precision™ M6400 Mobile Workstation ignores
rules and breaks new ground in mobile workstation
performance. Intel® Core™2 Duo Extreme Edition
Quad-Core Processors combine with massive
memory scalability and NVIDIA® OpenGL® graphics
technology in a stunning 17" chassis to target the
ultimate in certified application performance.
iT’s noT jusT DesigneD To MeeT your neeDs —
iT’s DesigneD To exceeD your exPecTaTions
The Dell Precision M6400 features the next generation
NVIDIA® Quadro® FX 2700M and FX 3700M1 graphics
processors with 512MB or 1GB of dedicated graphics memory.2
This highly advanced new mobile workstation was designed from the ground up to deliver world-
class graphics and CPU performance for running highly complex professional applications. It is a
certified mobile workstation that will manipulate complex, creative designs with ease. The M6400
brings high-end mobile workstation performance to a new level with a stunning, high resolution,
bright display that will bring your creative work to life. Work at the speed of thought.
•Numbercrunchinghorsepowerwithnext-generationIntelCore2DuoProcessorsand
Intel Core 2 Duo Extreme Edition Quad-Core Processors
•Upto16GB3 of high bandwidth dual-channel 1066MHz DDR3 memory
•Highperformance,optionalRAID,andstorageupto1TB4 with dual internal hard drive bays
•
Sleek aluminum chassis with optional edge-to-edge glass with 100% Adobe® color gamut support
Taking advantage of the Intel® Q43 chipset technology enables excellent system scalability and
performance. All of this in a mobile workstation starting at just 8.54 lb.5 (3.88kg) helps deliver
stunning desktop replacement performance in a mobile package.
coMPaTible anD robusT
The latest Dell Precision Mobile Workstations are part of the Dell™ E-Family product line. The
Dell Precision Mobile Workstations are compatible with all E-Family accessories, including port
replicators, notebook stands, display and monitor stands, and external storage modules. The
E-Family product line also oers DisplayPort technology, allowing the user to connect to a variety
of dierent display devices with a single DisplayPort. The Dell Precision product line is built tough
with magnesium-alloy chassis and display backs that meet rigorous standards for durability.
Optional features include fingerprint reader, 2-megapixel camera, dual array microphones, jog
shuttle, and solid state drives.
Peace of MinD Through isV aPPlicaTion cerTificaTion
Dell is the world’s leading workstation vendor6 and partners with strategic Independent Software
Vendors (ISVs) to certify system and application compatibility so that your applications can run
gracefully on Dell Precision Workstations. Through rigorous testing, Dell also targets guaranteed
compatibility and optimized performance in demanding work environments such as Computer
Aided Design (CAD), animation, engineering, and architecture, making the M6400 an exceptional
platform for extremely demanding workstation users who need to be mobile.
FEATURES Dell PrecisionTM M6400 Mobile Workstation
Processors
Intel® CoreTM2 Duo and Intel® Core 2 Duo Extreme Edition processors with 1066MHz front side bus and up to 12MB
shared cache. Up to X9100 (3.06GHz, 1066MHz, 6M L2 Cache) dual-core or QX9300 (2.53GHz, 1066MHz, 12M L2 Cache)
quad-core
Chipset Intel® Q43 Express Chipset
Memory2
Dual-channel DDR3 1066MHz SDRAM; up to 16GB3 dual-channel DDR3 1066MHz SDRAM; DIMMs up to 4GB3 at 1066MHz
Wide Aspect Display Choice of Dell Ultrasharp™ 17" WUXGA RGBLED Edge to Edge (1920x1200), Dell Ultrasharp 17" WUXGA RGBLED
(1920x1200), Dell Ultrasharp 17" WUXGA AntiGlare (1920x1200), Dell Ultrasharp 17" WXGA+ AntiGlare (1440x990)
Graphics2NVIDIA® Quadro™ FX 2700M 512MB dedicated memory, or NVIDIA® Quadro™ FX 3700M 1GB dedicated memory2
Networking Broadcom® NetXtreme™ 57xx Gigabit Controller
Wireless A choice of one of the following: Dell Wireless 1397 802.11g Mini-Card, Dell Wireless 1510 802.11a/g/Draft n/ Mini-Card, Intel
Wireless 5100 802.11a/g/Draft n Mini-Card, or Intel Wireless 5300 802.11a/g/Draft n Mini-Card
Bluetooth Dell Wireless 370 Bluetooth® Mini-Card or (US Only) a Dell Wireless 410 BT +UWB Mini-Card
Mobile Broadband7Dell Wireless 5530 (HSDPA) Mini-Card, Dell Wireless 5720 (EVDO) Rev A Verizon US, Dell Wireless 5720 (EVDO)
Rev A Sprint US, Dell Wireless 5720 (EVDO) Rev A Telus Canada. Availability varies by region.
Slots and Ports 54mm Express Card slot, PC Card Slot, E-Family docking connector, DisplayPort, VGA, 4 USB 2.0 including e-SATA, IEEE
1394 6-pin powered, headphone/speaker out, 8-in-1 memory card reader, and RJ-45
Battery 9-cell/85WHr Smart Lithium Ion battery featuring ExpressCharge™
Operating Systems
Genuine Windows Vista® Ultimate 32-bit and 64-bit; Genuine Windows Vista Business – 32Bit and 64Bit; Genuine Windows
Vista Ultimate Downgrade, XP Professional and XP Professional x64 Edition; Genuine Windows Vista Business Downgrade,
XP Professional and XP Professional x64 Edition; Red Hat® Enterprise Linux® WS v.5.1 64-bit Factory installed, Novell®
SUSE/SLED Linux (China), FreeDOS
Docking Docking E/APR, E/SPR, E/Legacy Port, E/View Notebook Stand, E/Monitor Stand
Dimensions 393 x 285.5 x 34.5-38.5mm (15.4" x 11.2" x 1.35"-1.5")
Weight Starting At 8.54 lbs (3.88kg)5 with a 9-cell battery, optional solid state drive, and NVIDIA® graphics
Warranty 3-year Limited Hardware Warranty8 with On-Site Service after Remote Diagnosis9
Peripherals
Monitors Performance flat-panel displays, Dell UltraSharp™ widescreen and standard flat-panel displays from 17" viewable
to 30" viewable
Keyboard Dell Enhanced QuietKey™ USB; Enhanced Multimedia USB; Smart Card keyboard USB
Mouse Dell USB two-button mouse and Dell USB optical two-button scroll mouse
Optional Speakers Internal chassis speaker; Dell two- and three-piece stereo system; Dell sound bar for all flat-panel displays
Storage Devices
Optional Removable Storage
CD-RW/DVD Combo, DVD-ROM, DVD+/-RW slot load, USB Floppy Drive, USB media card reader
Hard Drives4
SATA Solid State HDD 2.5mm: Ultra Performance 32GB, 64GB & 128GB; SATA 7200RPM: up to 320GB; SATA 5400RPM:
up to 500GB ; e-SATA connection enables Intel® Rapid Recover Technology when used in conjunction with an external
SATA drive; Support for one or two HDDs with optional RAID 0 or RAID 1 configuration
Security
Integrated Smart Card reader, Contactless Smart Card reader (optional), Trusted Platform Module 1.2 (TPM 1.2 where
available); Setup/BIOS Password; I/O Interface Security, optional swipe or FIPS fingerprint readers
Environmental and Regulatory
Standards BSMI, C-TICK, CE, FCC, IRAM, NEMKO, NFPA 99, SABBS, SASO, TUV, UL, VCCI, USB 2.0, WEEE
Lead Free Environmentally conscious design is RoHS Compliant/Lead Free
1. Available in September 2008
2. Significant system memory may be used to support graphics, depending on system memory size and other factors.
3. Up to 1GB may not be available with 32-bit operating systems due to system resource requirements.
4. For hard drives, GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and
will be less.
5. Dell Precision M6400 Weight: Preliminary starting weight of 8.54lb/3.88kg with 17" WXGA+ panel, DVD/CDRW, 2.5" Ultra Performance SSD Drive,
Discrete graphics, and 9-cell battery. Weights vary depending on configurations and manufacturing variability.
6. Source: IDC Worldwide Quarterly Workstation Tracker, August 2008
7. Subject to wireless provider’s broadband subscription and coverage area; additional charges apply.
8. For copy of Ltd Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX 78682 or visit DELL.COM/Warranty
9. Remote Diagnosis: Determination by online/phone technician of cause of issue; may involve customer access to inside of system and multiple or
extended sessions. If issue is covered by Limited Hardware Warranty and not resolved remotely, technician and/or part will be dispatched, usually
within 1 business day following completion of Remote Diagnosis. Availability varies. Other conditions apply.
Intel and Intel Core are registered trademarks of Intel Corporation. Microsoft, Windows and Windows Vista are trademarks or registered trademarks of
Microsoft Corporation in the U.S. and other countries.
Dell’s Terms and Conditions of Sales and Service apply and are available upon request. Dell cannot be held responsible for errors in typography
or photography.
SIMPLIFY YOUR WORKSTATION AT DELL.COM/Precision
