Dell Wyse ThinLinux 2.0

INI Guide

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other

trademarks may be trademarks of their respective owners.

2017 - 12

Rev. A00

Contents

1 Introduction....................................................................................................................................................4

About this Guide.................................................................................................................................................................4

Dell Technical Support....................................................................................................................................................... 4

Related Documentation and Services........................................................................................................................4

Dell Online Community................................................................................................................................................ 5

2 Getting Started: Learning INI File Basics........................................................................................................6

Supported INI Files you can construct............................................................................................................................ 6

Working with wlx.ini Files............................................................................................................................................ 6

Working with MAC.ini Files......................................................................................................................................... 6

Rules and Recommendations for Constructing the INI Files........................................................................................ 7

System Variables.......................................................................................................................................................... 7

Placing the INI Files into the Folder Structure on the Server.......................................................................................8

3 General Settings Parameter Options............................................................................................................ 10

4 Peripheral Settings Parameter Options.........................................................................................................17

5 Connection Settings Parameter Options...................................................................................................... 21

6 Custom GNOME Settings Parameter Options............................................................................................. 30

7 Connect Parameter Options.........................................................................................................................33

Browser Connect Options.............................................................................................................................................. 33

Custom Connect Options............................................................................................................................................... 34

Citrix Connect Options....................................................................................................................................................35

RDP Connect Options.....................................................................................................................................................40

SSH Connect Options.....................................................................................................................................................45

VMware View Connect Options.................................................................................................................................... 46

VNC Viewer Connect Options ...................................................................................................................................... 50

Ericom PowerTerm Connect Options............................................................................................................................52

8 Printer Parameters Option...........................................................................................................................55

Printer................................................................................................................................................................................55

JetDirectPrinter................................................................................................................................................................56

NetworkPrinter................................................................................................................................................................ 56

PrinterURI......................................................................................................................................................................... 57

SMBPrinter.......................................................................................................................................................................58

9 TimeZone Parameter: Values....................................................................................................................... 59

10 Keyboard.layouts Parameter: Values...........................................................................................................62

Contents 3

Introduction

Dell Wyse ThinLinux from Dell simplies the user management paradigm with elegant application icons and comes with a single built-in user

to enhance user experience along with having the benets of a single-operating system. ThinLinux software combines the security,

exibility and market-leading usability of Linux Enterprise with Dell’s thin computing optimizations in management. It is ideal for

organizations that want to run server-based, Web-based or local applications including legacy applications without the deployment and

security concerns of a nonstandard Linux distribution.

Dell Wyse ThinLinux (INI) les are plain-text les that you can construct to contain the conguration information you want for your thin

clients running on Dell Wyse ThinLinux for both global level and individual user level. For example, these INI les can be used by applications

to save information about a user’s preferences and operating environment.

NOTE: Information and procedures presented in this guide are intended for use by system administrators and should not be used

by untrained persons.

Topics:

• About this Guide

• Dell Technical Support

About this Guide

This guide is intended for administrators of Dell thin clients running Dell Wyse ThinLinux. It provides the detailed information you need to

help you understand and use the Dell Wyse ThinLinux INI les. It contains information on the dierent INI les you can use and the rules for

constructing the les. It also provides the parameter details you need with the working examples to get the most out of your INI.

Finding the Information You Need in this Guide

You can use either the Search window or Find toolbar to locate a word, series of words, or partial word in an active PDF document. For

detailed information on using these features, refer to the Help in your PDF reader.

Dell Technical Support

To access Dell Wyse technical resources, visit www.dell.com/support/contents/us/en/19/article/Product-Support/Dell-Subsidiaries/wyse.

For more information, you can submit cases to Dell TechDirect for online case submission and self service dispatch or contact our Support

phone queue.

Related Documentation and Services

Fact Sheets containing features of the hardware products are available on the Dell Wyse website. Go to www.dell.com/wyse and select

your hardware product to locate and download the Fact Sheet.

To get support for your Wyse product, check your product Service Tag or serial number.

• For Dell service tagged products, nd knowledge base articles and drivers on the Dell Wyse product pages.

• For Non-Dell Service Tagged Products, nd all the support needed by accessing the Dell Wyse support domain.

1

4 Introduction

Dell Online Community

Dell maintains an online community where users of our products can seek and exchange information about user forums. Visit the Dell Online

Community forums at: http://en.community.dell.com/techcenter/enterprise-client/wyse_general_forum/.

Introduction 5

Getting Started: Learning INI File Basics

In this chapter you can learn how to construct and use the supported INI les.

It includes the following details:

•Supported INI Files You can Construct.

•Rules and Recommendations for Constructing the INI Files.

•Placing the INI Files into the Folder Structure on the Server.

After you become familiar with the INI le basics, you can refer to the parameter details you need in the other chapters and appendixes of

this guide.

Topics:

• Supported INI Files you can construct

• Rules and Recommendations for Constructing the INI Files

• Placing the INI Files into the Folder Structure on the Server

Supported INI Files you can construct

The INI les contains the parameters, associated options, and values necessary for the various functionalities you want.

IMPORTANT: The INI le processing hierarchy is as follows:

• Scenario 1 — MAC.ini exists. The MAC.ini le is processed and if the Include=WLX.ini statement is included, then the WLX.ini le is

processed.

• Scenario 2 — wlx.ini exists. The WLX.ini le is processed.

• Scenario 3— No ini les exist. Local conguration is applied.

Working with wlx.ini Files

A wlx.ini le contains the global parameters that aects all thin clients accessing the server. Parameters in Table Connection Settings

Parameter Options can be used in mac.ini and wlx.ini les.

Working with MAC.ini Files

A MAC.ini le can be used instead of a wlx.ini le for device-specic congurations. If the thin client locates a MAC.ini le that is stored in

the same directory as a wlx.ini le, then the wlx.ini le is not accessed, unless you use the include =wlx.ini parameter.

NOTE: The placement of the include =wlx.ini parameter within the MAC.ini le will dictate which value will take the priority for a

same specic parameter that is contained in both the wlx.ini le and the MAC.ini le but is dened for dierent values for the

same parameter.

For example, if the wlx.ini le has parameter A= value B, and the MAC.ini le has the same parameter A= value C, then:

• If the include =wlx.ini parameter is included in the MAC.ini le before the parameter A= value C statement, then the wlx.ini parameter

A= value B is discarded and parameter A= value C from the MAC.ini le is the nal value used.

2

6 Getting Started: Learning INI File Basics

• If the include =wlx.ini parameter is included in the MAC.ini le after the parameter A= value C statement, then the MAC.ini parameter

A= value C is discarded and parameter A= value B from the wlx.ini le is the nal value used.

Rules and Recommendations for Constructing the INI

Files

In general, Dell Wyse ThinLinux les follow currently accepted standard INI le formatting conventions. The INI les consist of Dell Wyse

parameters. You can have totally empty INI le or an INI le that has other parameters, and rest of the parameters can be used if you desire,

but are not necessary unless you want changes from client and other defaults for example, other can be the default resolution of your

monitor. Every parameter and their options have a name and a value, with the name appearing to the left of the equals sign (name=value).

Number signs (#) indicate the start of a comment. Comments can begin anywhere on a line. Everything between the # and the End of Line

is ignored. Along with these general formatting conventions, use the following guidelines when constructing the INI les.

1Global Connect Parameters First.

Global connect parameters should be listed before other connect parameters in a wlx.ini le.

2Connect is used for creating the VDI connection and is not mandatory.

As stated earlier, You can totally have empty INI le or an INI le that has other parameters. Any of the rest of the parameters can be

used if you desire, but are not necessary unless you want changes from client and other defaults.

3Continue Lines by using a Space and Backslash.

Placing a space and backslash (\) at the end of a line indicates line continuation. No white space can appear after the backslash; the

requirement of white space between parameter entries is maintained by the use of the space before the backslash. In addition,

starting all parameters at the left margin and placing at least one leading space or tab at the beginning of all and only continuation

lines makes an INI le easier to read.

In circumstances where you require string concatenation, you can use a backslash without a space before or after concatenating with

the rst set of characters from the previous line; for example the strings snow and ball may be concatenated to give snowball.

4Blank Lines Make Files Easy to Read.

Using blank lines is recommended for making code easier to read.

5Comment by using a # Sign.

As stated earlier, number signs (#) indicate the start of a comment. Comments can begin anywhere on a line. Everything between the

# and the End of Line is ignored.

6With White Spaces Require Quotation Marks.

Values of parameters and their options containing white spaces must be placed inside quotation marks, use common-practice nesting

rules.

7Separate the lists by using Semicolons or Commas.

Use semicolons or commas for list separators.

8Use the wlx.ini File to Set the Maximum Number of Connection Entries Allowed.

The number of connection entries dened in a wlx.ini les cannot exceed a dened total maximum number of connections. The

maximum number of connections has a default limit of 216, but can be set from 100 to 1000 using the wlx.ini le.

9Use System Variables with Some Options of the Connect Parameter.

Some options of the Connect parameter can use the system variables shown in Table 1 to map the string. All combinations of the

variables are supported. For options that supports the use of system variables, see Connect Parameter Options.

10 The parameters described in square brace [ ].

The parameters described in square brace [ ] are dependant parameters and does not work individually.

11 Default values are made bold.

If a parameter has a default value, the default value is considered if the parameter is not mentioned with a specic cases.

System Variables

The following table provides details about the System Variables:

Getting Started: Learning INI File Basics 7

Table 1. System Variables

Option Value

$SN Serial number used.

$MAC MAC address used.

$IP IP Address used.

$DN Sign-on domain name used.

$UN Sign-on name used.

$PW Sign-on password used.

$TN Terminal name.

$PLATFORM Model of the thin client.

NOTE: If Auto Login in enabled then $PW returns null, so with auto logins enabled do not use $PW as value for any parameter.

Placing the INI Files into the Folder Structure on the

Server

You must need an FTP server to download your INI les and the path to download is specied in the INI page on the thin client. Under the

C:/ inetpub/ftproot folder for FTP or C:/inetpub/wwwroot folder for HTTP/HTTPS and place your INI les. Other necessary les inside

the structure as noted that this list describes the folder structure, starting with the root directory.

ThinLinux will set the default path as /wlx2 instead of traditional /wlx because some of the INI parameters are not compatible with old INI

parameters from the older Linux Clients. The default path to search is /wlx2 rst, if /wlx2 directory is not found then you can search

for /wlx directory.

NOTE: There is no mixed path of /wlx2 and /wlx.

/wyse/ The root directory. It stores the wlx2 folder and the addons folder

It also stores the following les, which are used for imaging and

updating devices:

• thin-linux-<version>.raw

• thin-linux.info

/wyse/wlx2 The main INI conguration folder. It stores the following:

• wlx.ini le or MAC.ini le

• bitmap folder

• certs folder

• ini folder

/wyse/wlx2/bitmap The folder where you can place custom images you plan to use.

/wyse/wlx2/certs The folder where you can place the CA certicates that can be

imported to a thin client.

8 Getting Started: Learning INI File Basics

NOTE: To import the certicates to the thin clients, use

the Certs and ImportCerts INI parameters.

/wyse/addons The folder where you can place the add-ons you want to use. It

also stores the directory le and the *.deb packages available to be

installed on the thin client. The directory le should list all available

add-ons. The directory le is required in the addons folder to

guarantee that add-ons are properly located.

NOTE: If you want to do an update with the Preserve

changes option enabled, ensure that your addons folder

includes a copy of your current add-ons. The system may

require two reboots to fully update the rmware and add-

ons while preserving local changes.

Getting Started: Learning INI File Basics 9

General Settings Parameter Options

The following table contains parameters used for conguring the general settings where default values are in bold.

Table 2. General Settings Parameter Options.

Parameter Description

ActiveDirectoryServer= <string> Active Directory Server IP used for Domain Login to the clientDomain

Login of the client.

For example, ActiveDirectoryServer=10.150.244.105

AddtoEtcHosts= "ip1 FQDN1 aliases1; ip2 FQDN2 aliases2; ..." Default is none

Adds entries to the /etc/hosts le where aliases are an optional

space-separated list of host names.

AudioMute= {Yes, no} Default is no

Mutes the volume

AudioPlayback= hdmi If AudioPlayback is set to hdmi, HDMI sound device will have higher

priority compared to other internal analog device.

AudioVolume=<0 – 100> Determines the volume level.

AutoLogin={yes, no} Default is yes

To disable or enable thinuser auto-login.

Browser.ClearBrowserData={yes, no} Browser.ClearBrowserData option clears out or persists the browser

history across dierent client users.

yes - Clears out the browser data across dierent user log-ins.

no - Persists the browser data across dierent user log-ins.

Browser.Homepage=<URL> If the browser add-on is installed, this is the URL to the home page

for the browser.

Browser.SecModules=<string> For ICA only

This parameter is used to support smart card authentication through

the browser.

For Example, =/usr/lib/libIDPrimePKCS11.so for Gemalto Dot Net

card

EnableBanner={true, false}

BannerMsg=<string>

EnableBanner: Default is false

EnableBanner provides a banner description.

3

10 General Settings Parameter Options

Parameter Description

BannerMsg—BannerMsg text must be enclosed in double quotation

marks if it contains spaces or punctuation characters.

CertName=<string>

[URL=<string>

ChallengePassword=<string>

CADN=<string>

AutoEnroll={yes, no}]

CertName — Name of certicate to be enrolled. A folder with same

name will be created in /etc/scep/ folder in the thinclient.

URL — SCEP server URL ,which will be contacted for certicate

enrollment.

ChallengePassword — Certicate Enrollment Challenge Password, it

can be obtained from the SCEP Server.

CADN — CA Distinguished Name(Unique name to identify the CA).

AutoEnroll — To enable Automatic enrollment of certicates.

For example,

SCEPCLIENTCERTSETTINGS=CertName=2OFDZERTIFIKATE

URL=http://10.150.196.61/certsrv/mscep/mscep.dll

ChallengePassword=379132065CB03920A6801D67C159A26C

CADN=dot1x.local

AutoEnroll=yes

CCMEnable={yes ,no}

CCMServer=<CCM server URL>

GroupRegistrationKey=<tenant code-group code>

CCMEnable. Default is Yes.

It is used to enable or disable the Wyse Device agent.

CCMServer

Enter the URL of the CCM server you want to connect to.

MQTTServer

Enter the IP Address or the FQDN of the MQTT server.

GroupRegistrationKey

Enter your Group Registration Key to manage the thin client device.

For Example: CCMEnable=yes

CCMServer=https://autostratus2.wyselab.com:443

GroupRegistrationKey=linx-01012005

ChangeRootPassword=<string> Default is base-64 encoded.

Species the new password for the root user.

ChangeThinUserPassword=<string> Default is base-64 encoded.

Species the new password for the thin client user.

CitrixThemeConnectionType={pnagent, storefront} For Citrix Desktop Appliance Mode (Power On To Power O Citrix

Theme), use pnagent to connect to the Program of Neigborhood

Agent servers, and storefront to connect to the store front servers

General Settings Parameter Options 11

Parameter Description

DelayedUpdate.Enable={true, false, yes, no} Default is true

DelayedUpdate.Enable parameter enables or disables the updatings.

DelayedUpdate.Mode={image} Default is

image – updates the image only.

DeskColor=<Primary color> [{solid | horizontal-gradient | vertical-

gradient}<Secondary color>]

Species the desktop background color where <primary color> and

<secondary color> can be one of the following values:

• RGB color specication in the form commonly used in HTML

(rrggbb).

• A color name from the /usr/share/X11/rgb.txt le. These names

are case-sensitive.

• Three integers in the range of 0-255 representing the amount of

red, green and blue, respectively, for example: 0 119 255.

NOTE: The text must be enclosed in double quotation

marks if it contains spaces or punctuation characters.

These characters are not allowed: and ‘ “ $? ! |; ( ) [ ] { }

\

• This form is deprecated. It is available for backwards compatibility

only.

An optional shading can be specied as solid, horizontal-gradient,

vertical- gradient.

The <primary color> is the primary color, and the one which is used if

no shading is specied or if the shading is solid. The optional

<secondary color> is the secondary color, when shading is specied.

for example:Deskcolor=”DarkGoldenrod horizontal-gradient

LightGoldenrod”

The primary color in this example DarkGoldenrod appears on the left

(horizontal) or top (vertical) edge with a smooth transition to the

secondary color in this example LightGoldenrod on the opposite

edge.

Desktop={<image le>, <default>}

[Layout={Center, Tile, Stretch, Scale, Zoom, Span}]

Desktop: Species an image le to be used as wallpaper for the local

desktop. The le must be located in the server wlx2 bitmap directory.

The image le can be PNG, and JPG. The lename is case sensitive.

Setting the Image le name to <default>...., sets the wall paper to

Dell default wall paper.

Layout : Species the arrangement of the specied image le on the

desktop. The tile option replicates the image across the desktop, the

stretch option adjusts the image to ll the screen, the scale option

enlarges the image to ll either the screen width or height, theZoom

option stretches (or reduces) the image keeping proportions, so the

background is completely lled, when the image and the screen have

dierent proportions it will cut o the extra bands that cannot be

tted (top and bottom or left and right depending on the image), and

Span option is used to span the image across multiple monitors.

DesktopAppliance={ none, citrix} You can disable or enable the thinuser specic VDI KIOSK theme.

Desktop.KeyBinding.Minimize=<string> Default is disabled

Desktop.KeyBinding.Move=<string> Default is disabled

12 General Settings Parameter Options

Parameter Description

Desktop.KeyBinding.Resize=<string> Default is disabled

Desktop.KeyBinding.ShowDesktop=<string> Default is <Control><Alt>Down

Desktop.KeyBinding.SwitchWindows=<string> Default is <Alt>Down

Desktop.KeyBinding.ToggleFullscreen=<string> Default is <Control><Alt>Up

Desktop.KeyBinding.ToggleMaximized=<string> Default is <Alt>F10

Desktop.KeyBinding.UnMaximize=<string> Default is disabled

Desktop.KeyBinding.DisablePrintScreen={true, false} Default is true.

DHCP.VendorID=<String> Default is wyse-5000.

Species the desired HDCP Vendor ID string.

DisableXRender={yes, no} Default is no

Used for disabling XRender extension of X11

Display.SleepDisplay={0, 60, 120, 180, 240, 300, 480, 600, 720,

900} or SleepDisplay

Default is 240 for 4 minutes.

These are values for seconds, corresponding to 1, 2, 3, 4, 5, 8, 10, 12,

15 minutes possible values; 0 and other values corresponds to never.

Display.LockScreenTimeout={Time in seconds} Default is 120 seconds

EnableGKey={true, false} Default is true

EnableGKey option is used to enable G key reset.

EnableSsh={yes, no} Default is no, SSH server disabled. You can enable or disable SSH

server.

IcaDisableWIFS={yes, no} Default is no.

IcaDisableWIFS option is used to disable the Citrix Firefox plug-in

feature that sends the option -WI_is_FS to its receiver.

If Firefox is in fullscreen mode, which makes Citrix receiver ignore

window size conguration, disabling the feature allows you to resize

their Citrix session when you are using Firefox Kiosk mode.

IdleAction.Enable={enable/disable}

[IdleAction.Timeout=<value of 1 to 60>]

[IdleAction.Action=<Any valid Command>]

IdleAction.Enable: Default is disable. Once enabled, Timeout should

be specied. If not specied, default timeout is 1 minute.

IdleAction.Timeout: To set the idle action timeout value in minutes.

IdleAction.Action: The String of commands to be executed. For

example, /usr/sbin/reboot. The default action is reboot.

ImportCerts ={yes, no}

[Certs=<String>]

ImportCerts:Default is no

It enables certicate import from the server.

Certs: certs is a list of certicate names (the names must be

separated by a semicolon).

General Settings Parameter Options 13

Parameter Description

For example, Certs=Cert1.cer;Cert2.crt;Cert3.pem;Cert4.der

NOTE: Certicates must be placed in the certs sub-

directory.

ImportCong.FileURI=<string> Default is none

It species the complete URI (server URL and le full path) of the

conguration les to import.

ImportCong.UID=<string> Default is none.

It is the User ID used when importing the congurations le from an

FTP server.

ImportCong.Password=<string> Default is none

It is the password used when importing the congurations le from

an FTP server.

MerlinUpdate.Username=<string> The username used to login the server.

MerlinUpdate.Password=<string> Default is base-64 encryption. The password is used to login the

server.

MerlinUpdate.URL=<string> The URL to the Merlin base. Macro $PLATFORM is automatically

appended for Merlin imaging.

MicMute={yes, no} Default is no

If MicMute is set to yes, then it mutes the microphone volume.

MicVolume=<0-100> Determines the microphone volume level.

MgmtDiscoveryMethod= {SRV, HOSTNAME, CNAME, STATIC,

ALL, DHCP }

Default is ALL .

The Discovery method used for nding WDM server.

NTP.Enable={yes, no} Default is no.

It Species that the NTP daemon should be enabled and started.

NOTE: NTP server will not be started if an NTP.TimeServer

parameter is not specied and the thin client does not have

one previously set.

NTP.TimeServer=<NTP Server IP or FQDN> [;<NTP Server IP or

FQDN>;....}

Default is None.

It species one or more NTP server IP Addresses or FQDNs.

PermitSshRootLogin={yes, no} Default is no, It used to prohibit the root SSH login. You can enable

or disable the root login through SSH. It works only if SSH is enabled.

PowerButtonAction ={interactive, reboot, restart, halt, shutdown,

none, nothing}

Default is interactive

It species system behavior when the power button is pressed.

none or nothing: Power button is ignored, that is no action.

Interactive: An optional window is presented to you.

14 General Settings Parameter Options

Parameter Description

halt or shutdown: Shuts down the devices.

reboot or restart: Reboots the devices.

ProgressUpdateInterval=<10–60> Default is 20

The interval specied for sending image upgrade status to WDM

server. Value less than 10 will be rounded to 10 and Value greater than

60 will be rounded to 60.

PasswordEncryptionCode={0, 1, 2} Default value is 1

Species the desired password encryption algorithm in INI. This

parameter must be place at least before the rst password used in

the wlx.ini le.

0: Plain Text

1: Base64 encoded

2: AES encoded

RootPath=<string> Default is /wyse

This path is used to access INI les on the server.

IMPORTANT: If root path is not provided, /wyse is the

default. The directory name /wlx2 is appended to the root

path entry before use, if /wlx2 folder is not available

then /wlx will be the fall back default.

SshIdleTimeout=<integer 1 to 60> Default is 0, which is disabled. Set the SSH connection idle timeout

in minutes. when the client idle timeout reaches, SSH connection will

be terminated automatically from SSH Server. This works only if SSH

is enabled.

ServerBusyCounter=<1 – 24> Default is 5.

The number of retries when server is busy. There is no hard limit

enforced as this was designed as adhoc measure till wdm server

provides the counter value during checkin.

ServerBusyTimeout=<byte 10 – 360> Default is 30

The interval before Hagent goes for retry. There is no hard limit

enforced as this was designed as adhoc measure till wdm server

provides the timeout value during checkin.

System.Language=<string>

System.Language={en_US, fr_FR, es_ES, de_DE, nl_NL, pt_PT,

zh_CN, ko_KR, ja_JP}

System.Language — The value species the UI language and the

locality where it will be used. For example, System.Language =

en_US.

System.Language – Default is en_US. It species only one language

in INI.

NOTE:

Do not specify any encoding.

TimeFormat=<String> Default is 12h

Species the system time format.

General Settings Parameter Options 15

Parameter Description

The following are the formats:

• 24, 24h, 24-hour, 24-hour format.

• 12, 12h, 12-hour, 12-hour format.

VNCServer.DisableVNC={yes, no} Default is yes

You can disable or enable the VNC Server.

VNCServer.UsePasswd={yes, no} Default is no

You can use password to authenticate VNC connections.

VNCServer.VncPasswd=<string> This parameter is used to set the new VNC password from default.

Maximum length is 8 characters. If the VncPassword is not set, then

default password is Wyse.

NOTE: Password string must not contain single quote

character.

VNCServer.VncPrompt={yes, no} Default is no

This parameter is used to enable a popup dialog asking for accepting

the incoming VNC connection request. The dialog has the followings:

Yes and No button to select. If you do not click on anything, default

will be No after Timeout is reached in 120 seconds by default.

VNCServer.VNCWarning={yes, no} Default is yes.

You can enable or disable a warning icon on the taskbar, when new

VNC connection is connected. The icon remains on the taskbar until

the VNC connection is terminated.

InstallAddons=<name of addon> This parameter species the add-ons to be updated. Use comma

separated add-on names.

NOTE: NewAddons=<name of addons>. This parameter

species the new add-ons to be installed. Use comma

separated add-on names.

RemoveAddons=<name of addon> This parameter species the add-ons to be uninstalled. Use comma

separated add-on names.

TransparentKeyPassThrough={Local, Remote, FullScreenOnly} Default is FullScreenOnly. This parameter enables the keyboard

shortcut sequences dened by the local Windows manager in the

session.

• FullScreenOnly — key event is processed locally except in

Fullscreen mode.

• Local — key event is processed locally in order to use ICA hot

keys.

• Remote — key event is forwarded to the server so that ICA hot

keys do not work.

16 General Settings Parameter Options

Peripheral Settings Parameter Options

The following table contains parameters used for conguring peripheral settings such as keyboard, monitor, mouse, and printer.

Table 3. Peripheral Settings Parameter Options

Parameter Description

DisplaySettings=MON1<resolution=1920x1080>

MON2<resolution= 1024x768> MON3<resolution= 1024x768>

or

MON1 <resolution=1920x1080@60> MON2

<resolution=1024x768@60>

MON3 <resolution=1920x1080@60> MON2

<resolution=1024x768@60>

MON3 <resolution=1920x1080@60>

MON1<resolution=1024x768@60>

The string value is in the format of white space separated string

construct. The values keywords are case sensitive. The following are the

rules:

1 MON1/MON2: mandatory constant values for monitor1 and

monitor2, if specic resolutions or placement are to be set for each

individual monitors.

2 To specify resolutions: use 1920x1080 format, resolution numbers

with delimiter x (lowercase) after MON1/MON2 value keyword.

Resolutions are optional. If not specied, DDC (optimal) resolutions

are used.

For Example : DisplaySettings=MON1 1920x1080 MON2

1920x1200 MON3 1920x1200

3 To specify resolutions with refresh rate: use 1920x1080@60

format, refresh rate is optional. If not specied, the optimal refresh

rate is used automatically.

For Example: DisplaySettings=MON1 1920x1080@60 MON2

1920x1200@60 MON3 1920x1200@60

MON1 primary 1920x1080 MON2 1920x1200:

Used for the specied conguration of primary monitor that is retained

previously. Primary monitor is where the taskbar and app icons are

present. It species monitor as the primary monitor, use the value

keyword primary, which is optional.

For Example: Set MON1 as primary : DisplaySettings=MON1 primary

1920x1080 MON2 1920x1200 MON3 1920x1200

Set MON2 as primary : DisplaySettings=MON1 1920x1080 MON2

primary 1920x1200 MON3 1920x1200

Set MON3 as primary : DisplaySettings=MON1 1920x1080 MON2

1920x1200 MON3 primary 1920x1200

MON1 primary on-left 1920x1080, MON2 on-right 1920x1200

To specify monitors in horizontal placement and on the left or right, use

the legacy value keywords on-left and on-right after MON1/MON2 to

arrange monitors left/right placement. You can use these options in pair.

MON1 primary on-above 1920x1080, MON2 on-below 1920x1200

To specify monitors in vertical placement and on the top or bottom, use

the legacy value keywords on-above and on-below after each MON1

MON2 and MON3to arrange monitors top/bottom placement. You can

use these options in pair.

MON1 primary rotate-left 1920x1080 MON2 1920x1200 MON3

1920x1200

4

Peripheral Settings Parameter Options 17

Parameter Description

rotate-left, rotate-normal, and rotate-right are supported as legacy

parameters. These parameters rotate the framebuer for monitors that

do not actually support rotation. Specifying these parameters requires

monitors to be physically rotated. For monitors that support rotation,

these parameters are not necessary.

<default>

This key value is to reset both monitors to default settings. (Optimal

resolutions in horizontal placement and MON1 on the left as primary

display).

DDC

Resets all the monitors to default layout and default resolutions – The

default layout is all in HORIZONTAL placement, Primary is MON1 and

resolutions are optimal.

Horizontal

For Example: DisplaySettings=Horizontal (which is equal to

DisplaySettings= <default>) OR DisplaySettings=Horizontal MON1

primary 1920x1080 MON2 1920x1200 MON3 1920x1200

This single Horizontal (with capital H) key value without any parameter

is used to reset both the monitors to DDC mode as it is in default

settings. There can be parameters as in MON1 MON2 and MON3 format

as described above. The result is to set the monitors in horizontal

placements with specied individual parameters.

Vertical

For Example: DisplaySettings=Vertical (which is equal to

DisplaySettings= <default>) OR DisplaySettings=Vertical MON1 primary

1920x1080 MON2 1920x1200 MON3 1920x1200

This single Vertical (with capital V) key value is used to set both

monitors to DDC resolutions, but in vertical placement with default

MON1 on the top.

MON3...MON2 … MON1…

With individual monitor with their specic parameters in place, but swaps

the MON2 at the beginning of the string, followed by MON1 will be

placed MON2 on the left and MON1 on the right. This is equivalent of

MON1 on-right MON2 on-left. For Example: MON2 MON1 = MON1 on-

right MON2 and MON3on-left

Mirror <rotate{normal, left, right, inverted}, {resolution}>

It sets the monitors in mirror mode with given resolution and rotation.

JetDirectPrinter=<printer address> For Example: JetDirectPrinter=<printer address> <options>

For parameter options used in the command line, see JetDirectPrinter

in Printer Parameters Options.

Mouse.MouseSpeed={value 0 to 6 and <default>} It Species the speed when you are moving the mouse.

0 – Slowest

6 – Fastest

Default: Set to system default by using <default> in INI le.

18 Peripheral Settings Parameter Options

Parameter Description

NOTE: On default check system registry

Mouse.MotionAccleration is 2 and MotionThreshold value is 1

Mouse.MouseSwap={yes, no} It swaps left and right handed mouse buttons.

no: Is left handed mouse

Mouse.DoubleClick={100 to 1000, and <default>} Double click species the length of double click in milliseconds.

100 - fastest

1000 - slowest

NetworkPrinter= < LPD> For Example: NetworkPrinter=LPD <Option>

For parameter options used in the command line, see NetworkPrinter in

Printer Parameters Options.

Keyboard.Repeat={true, false} Default is true. Keyboard repeat is enabled. If you press key, it will be

repeated.

Keyboard.RepeatDelay={<default>, 0 to 7 or 100 to 2000} Initial Key Repeat Delay is 100 to 2000 according to new SLES standard.

For backward compatibility 0 is minimum 7 is maximum. This setting is

valid only when Keyboard.Repeat is enabled (true).

Keyboard.RepeatRate={<default>, 0 to 2 or 9 to 2000} 9 is fast and 2000 is slowest according to new SLES standard. For

backward compatibility Key Repeat Interval, delay between repeats.

0 is slow

1 is medium

2 is fast

This setting is valid only when Keyboard.Repeat is enabled (true).

Keyboard.layouts=<value of Keyboard.layouts> For example: Keyboard.layouts= ara (for Arabic(South Sudan))

Keyboard.layouts= ru (for Russia)

Printer={USB <options> or URI} Species the USB for local USB printer. Only one USB printer can be

supported. The USB printer will not be congured if it is not attached.

For other types of printers, URI needs to be provided, such as

parallel:/dev/lpunit or serial:/dev/ttySunit?baud=speed.

For parameter options used in the command line, see Printer in Printer

Parameters Options.

PrinterURI=<uri> For Example:

PrinterURI=[ipp://[user[:password]@host[:port]/path

[http://[user[:password]@host[:port]/path

[socket://host[:port]

[lpd://host/queue

[smb://[user[:password]@[workgroup/]

Peripheral Settings Parameter Options 19

Parameter Description

server[:port]/sharename

[usb:/dev/usb/lpunit

[parallel:/dev/lpunit [serial:/dev/ttySunit?baud=speed <Option>

SMBPrinter=<host address> For Example:

SMBPrinter=<host address>

[username=<username>] [password=<base64-encoded password>]

[domain=<Windows domain>] <options>

For parameter options used in the command line, See SMBPrinter in

Printer Parameters Options.

view.enableMMR={TRUE, FALSE} Enables multimedia redirection (MMR).

The default value is FALSE.

GFXSettings=<layout> [resolution=<resolution>] The Wyse 5070 Extended thin client devices use this parameter to

dene the display settings. The INI parameter is saved persistently and

you to restart the device after it is applied. If this INI parameter is not

available, the settings that was saved are applied. The layout parameter

is mandatory and the valid values are:

• Horizontal

• Vertical

• Twoper row

• Threeperrow

The resolution is optional, and the default value is DDC. The resolution

options are:

• DDC

• 2560x1600

• 2560x1440

• 1920x1200

• 1920x1080

• 1680x1050

• 1600x1200

• 1600x900

• 1440x900

• 1366x768

• 1280x1024

For example, GFXSettings=Vertical [resolution=1280x1024]

20 Peripheral Settings Parameter Options

Connection Settings Parameter Options

The following table contains parameters used for conguring connection settings where default values are in bold.

Table 4. Connection Settings Parameter Option.

Parameter Description

Connect={BROWSER, Custom, Citrix, RDP, SSH,

VMWARE_VIEWCLIENT, VNC_VIEWER,

Ericom_Powerterm}

Connection protocol. Connect Parameter Options section describes these

connect options:

• BROWSER, see Browser Connect Options

• Custom, see Custom Connect Options

• Citrix, see Citrix Connect Options

• RDP, see RDP Connect Options

• SSH, see SSH Connect Options

• VMWARE_VIEWCLIENT, see VMware View Connect Options

DomainList=< String values separated by semicolon> A list of domain names that will appear in the login dialog box as options to

help users in selecting the domain to log in to PNAgent or Active Directory

servers. Be sure to enclose in quotation marks if spaces are included.

For example: DomainList = dell; SQA; wyse

DisableDomain={ True, False} DisableDomain parameter is used to disable the display of a Domain eld.

The default value depends on the value of the Domain List option. When

the Domain List is empty, DisableDomain defaults to yes. Otherwise, it

defaults to no. The Domain eld does not appear either of the cases.

EthernetSpeed={ Auto, 100M-F, 100M-H, 10M-F, 10M-H} Default is Auto

Species the device speed:

Auto: auto-negotiates speed with peer

100M-F: 100 Mbps Full Duplex 100M-H: 100 Mbps Half Duplex

10M-F: 10 Mbps Full Duplex

10M-H: 10 Mbps Half Duplex

FileServer=<protocol://><hostaddress> Default is specied by DHCP server(INI le server’s URL). If no protocol is

specied, FTP is assumed for example, 192.168.0.1 is understood as ftp://

192.168.0.1.

FileServerUsername=<username> Species the username for File server.

NOTE: An anonymous (unauthenticated access) is assumed if

FileServerUsername parameter is not specied.

FileServerPassword=<Password> Species the Base-64 encrypted password for File server.

HDXH264CaptureBin=<string> For ICA only.

5

Connection Settings Parameter Options 21

Parameter Description

Default is Null. It species the name of the customized H264 CaptureBin.

HDXH264InputEnabled={yes, no} For ICA only.

Default is no

This is used to enable H264 compression from client to server. This will

enable h264 encoding for media packets sent from client to server. This

enables better performance for multimedia redirection and webcam

redirection.

HDXWebCamDevice={ Valid path of the webcam device} For ICA only.

Default is /dev/video0.

Selects the webcam device. This parameter can be used when there are

multiple webcam present.

HDXWebCamFramesPerSec=<integer value> For ICA only.

Default is 15.

Sets the preferred frame rate for webcam.

HDXWebCamHeight=<integer value>

HDXWebCamWidth=<integer value>

For ICA only.

These settings control the resolution parameters for webcam.

The defaults are HDXWebCamWidth = 352 and HDXWebCamHeight =

288.

H264Enabled={yes, no} For ICA only.

Default is yes .

You can enable H264 compression from server to client. This will enable

h264 encoding for media packets which are received from server. This

enables the better performance for multimedia redirection and webcam

redirection.

ICABrowsing={ udp, http, https} For ICA only.

Default is http.

Species the default browsing protocol. This setting can be overridden by

the HttpBrowsing= {yes, no, ssl} in each connection property.

ICAComports= <ICAComports=COMx= {COMy,

USBSERz}, COMx=...>

For ICA only.

Maps serial devices on the server to serial devices on the thin client, where

x=1 to 4, if COMy maps to serial port on the thin client and USBSERz maps

to that USB serial port.

For Example: ICACOMports=COM1=USBSER1

ICADenyUSB=

vid=<hexnumber><space>pid=<hexnumber>…

For ICA only.

Species the USB devices that are excluded from ICA session.

22 Connection Settings Parameter Options

Parameter Description

NOTE: When you are using the ICADenyUSB parameter, a user

candenyredirectionof the device using class/suclass also along

with vid/pid. ICADenyUSB=class=01 subclass=01 to deny USB

Audio family.

IMPORTANT: You can use vendor IDs and product IDs together

as shown; or also use only the vendor IDs that are not use the

product IDs if you want to exclude the same vendor ID group of

devices regardless of their product ID.

The format must be the

following:ICADEnyUSB=vid=<hexnumber><space>pid=<hexnumber> or

ICADEnyUSB=vid=<hexnumber>

For example, ICADenyUSB=vid=1234 pid=5678,vid=1234 pid=9876

This example excludes two USB devices. There is a space between vid and

pid and each device is separated with a comma. or

ICADenyUSB=vid=1234,vid=5678 This example excludes all USB devices

that have the same vendor ID regardless of their product ID.

NOTE: While the ICAAllowUSB parameter exists, it is highly

recommended that it not be used as by default all USBs are

allowed.

ICADesktopApplianceMode={yes, no} For ICA only.

Default is no.

ICADesktopApplianceMode parameter is used to enable Citrix HDX USB

start up for Desktop Appliance Mode ,for any USB devices that are already

plugged in the device will start up provided the device is not disallowed

with a deny rule in the USB policies on either the server (registry entry) or

the client (policy rules conguration le). This parameter requires two thin

client reboots.

ICADrives=<drive letter>= {device name}, {rw, ro}, basedir

[drive letter=...]

For ICA only.

To map drives on the server to USB mass storage devices attached to the

thin client, where:

drive letter= A to Z

device name= usbstorage-x and cdrom-x, where x=0,1,2 and so on.

rw= read/write

ro= read only

basedir= an optional directory on the USB device to use.

ICADynamicDriveMapping={yes, no} For ICA only.

To enable or disable mapping of a single device based on the device name

Default value is no.

ICADynamicFolderMapping={yes, no} For ICA only.

To enable or disable mapping of all the devices listed in the standard mount

point. For example, /run/media. Hence it allows the user to enable or

disable PAM login.

Connection Settings Parameter Options 23

Parameter Description

Default value is no.

ICADynamicMapping={yes, no} For ICA only.

To enable or disable le system mapping for ICA session.

Default value is yes.

ICAFullscreen={yes, no} For ICA only.

Default is no.

Enables to run the session at full screen not in a window.

ICAhotkey={yes, no}[<hotkey name>=<supported value>] For ICA only.

Default is yes.

Yes/no option to enable and allow mapping of the hotkeys.

For example:

ICAhotkey=yes

Hotkey1Char=F1 Hotkey1Shift=Shift

Hotkey2Char=F3

Hotkey2Shift=Shift Hotkey3Char=F2

Hotkey2Shift=Shift Hotkey3Char=F2

Hotkey11Char=plus Hotkey11Shift=Ctrl

NOTE: All hotkey options must be on one line.

ICAMMAudio={yes, no} For ICA only.

ICAMMAudio is used to enable Citrix HDX Multimedia audio. This

parameter requires two thin client reboots. If this parameter is set, then

audio will be played by using client encoding and decoding capabilities.

ICAMMVideo={yes, no} For ICA only.

Default is yes.

ICAMMVideo option is used to enable Citrix HDX Multimedia video.

This parameter requires two thin client reboots. If this parameter is

set ,then video is extracted by using the client rendering

capabilities(encoding and decoding).

ICAMultistream={True, False, yes, no} To enable multiple streams to be used when connecting to a multistream

ICA enabled server, you must ensure this parameter is set to True or Yes.

Default is False or No

ICAProxyHost=< IP address> For ICA only.

Species the rewall server address for the ICA connection. When

conguring an alternate address for rewalls and HTTP, SOCKS is used for

ICAProxyType, you must provide the proxy server IP address and port.

24 Connection Settings Parameter Options

Parameter Description

Each entry with optional port is specied as host:port, where :port is

optional. If not specied, port depends on the browsing protocol.

ICAProxyType={ None, HTTP, SOCKS} For ICA only.

It denes the proxy type for the ICA connection. When conguring an

alternate address for rewalls, you can select the proxy type of None,

HTTP, or SOCKS.

ICAResolution={ default, seamless, 640x480, 800x600,

1024x768, 1280x1024, 1600x1200}

For ICA only.

Default is default.

Species the connection display resolution. The default value starts the

connection using the current desktop display setting. If the connection is to

a published application, the seamless selection is available. Seamless option

applicable only for Published Application and Storefront connections.

Default option will start the connection using the current desktop display

setting.

ICAShowAllApps= {yes, no} Default is no. This parameter makes it possible to display all applications on

desktop if PAM login is enabled.

ICAStoreName=< Store name specied in the xenapp or

xendesktop server>

For ICA only.

Species the Global ICA Store name which is used for PNAgent Login.

IniFileSource={ cache, local, server, none} Default is cache.

Species the source of the INI le to use:

• Selecting the local species that the local is the ini le created from

settings made on the client GUI.

• cache is the cached/saved/used-at least-once ini le originally from a

le server. For example, a GUI initially set up by an administrator.

NOTE: If a le server is available, the cache valueallow the

client to rst look to a le server for the latest ini available on

the server to use. However, if a le server is not found, for

example, the le server is down, the client uses the cached/

saved/used-at least-once ini le.

• Selecting the server species that the server is the ini le only from the

le server such as an FTP server. The server value will not allow the

client to use a cached ini le.

MouseSendsControlV={yes, no} For ICA only.

Default is no.

MouseSendsControlV allows you to control the mouse button action in a

Unix environment.

The following are the values:

yes: In a Unix environment, a middle mouse performs the same paste

function as the Ctrl+V keystroke combination in the Windows.

no: Disables the middle button paste, when used in the wlx.ini le with ICA

v.10.

NETWORK.ETH0.MTU={ Any positive integer} Default is System assigned automatically Species the network card’s

maximum transmission unit size.

Connection Settings Parameter Options 25

Parameter Description

PAMLoginEnabled={yes, no} For ICA only.

PAMLoginEnabled option allows the user to set /reset the domain value

and allows the user to enable or disable PAM login.

Default value is no.

PNAgentServer=<host address or URL>[:<port>][;<host

address or URL> [:<port>]]

Species a list of PNAgent servers or complete URL. If not specied, port

depends on the browsing protocol. If multiple servers are mentioned, they

should be separated by ;.

RapportSecurePort=<443> Default is 443

The secure port number of the WDM service.

RapportServer=< WDMServer-IP or FQDN> Default is none Only IPV4 is supported.

Seamless={yes, no} For ICA only.

Default is no.

Seamless option is used to set the default resolution for ICA-published

applications to seamless. This parameter is recommended to use for

launching applications, not recommended for launching desktop

connections.

TimeoutDelayLoginForNetwork=<integer from 1 to30> Sets the delay (wait) time before performing the authentication due to

network delay.

UDPAudioPortHigh={yes, no} For ICA only.

Default is 16509.

This parameter is used to congure UDP port range for real time audio data

packet exchange.

UDPAudioPortLow={yes, no} For ICA only.

Default is 16500.

This parameter is used to congure UDP port range for real time audio data

packet exchange.

UseLastDomainName={true, false} Default is False

If this ini parameter is set, then in the GDM login window, the username

eld is populated with the previous logged in domain username value. This

ini parameter is valid only for domain login and not for local user login.

UseLastLoginName={True, False} Default is False.

If this ini parameter is set, then in the GDM login window, the username

eld is populated with the previous logged in domain username value. This

ini parameter is valid only for domain login and not for local user login.

VMWareView.ImageCacheSize=< a number value from 50

to 1024>

Species the VMware View client's image cache size A larger cache size

reduces bandwidth usage, but requires more memory on the client. A

smaller cache size requires more bandwidth usage. Valid values for this INI

parameter option are between 50 and 1024. If it is set to a value less than

26 Connection Settings Parameter Options

Parameter Description

50, the system automatically uses a value of 50. If it is set to a value more

than 1024, the system automatically uses a value of 1024.

VMWareView.ShowImageCacheHits={no, yes}

VMWareViewExcludeUSBFamily=<storage>

VMWareViewExcludeUSBID=<vidpid>

VMWareViewIncludeUSBFamily=<storage>

VMWareViewIncludeUSBID=<vidpid>

INI Parameter Description

VMWareViewExcludeUSBFamily=<storage> Used to

exclude USB Family. It can be storage/printer/bluetooth

VMWareViewIncludeUSBFamily=<storage> Used to include

USB Family. It can be storage/printer/bluetooth

VMWareViewExcludeUSBID=<vidpid> Used to exclude a

specic USB device.

VMWareViewIncludeUSBID=<vidpid> Used to include a

specic USB device.

Default is no.

Yes/no option to display a visual indication that the image cache in VMware

View client is working. If enabled, the user sees rectangles around every

32x32 tile in the established session. Set the value on this INI parameter to

yes to see the visual eect.

WLAN=<wlan connection name>

[SSID=<SSID Name>]

[Security={NONE, WEP40/128-BITKEY, WEP128-

BITPASSPHRASE,LEAP, WPA&WPA2PERSONAL,

WPA&WPA2ENTERPRISE, DYNAMICWEP}]

[Mode={Infrastructure, AdHoc}]

[Username=<username>]

[Password=<password>]

[AuthType={OpenSystem, SharedKey, TLS, LEAP, TTLS,

PEAP}]

[Wep-Key1=<wep key1>]

[Wep-Key2=<wep key2>]

[Wep-Key3=<wep key3>]

[Wep-Key4=<wep-key4>]

[WepKeyIndex=<Key Index number>]

[InnerAuth={MSCHAPv2, MD5,GTC}]

[PeapVersion={Auto, 0, 1}]

[CACerticate=<certicate path>

Wireless LAN can be congured through this INI parameter and the

options.

Security Notes: Supported wireless security types:

Open

WEP 40/128 bit key

WEP 128-bit Passphrase

LEAP

WPA & WPA2 Personal

LEAP in WPA & WPA2 Enterprise

The following security types are not supported:

All WPA & WPA2 Enterprise authentications except a LEAP which does not

require a certicate Dynamic WEP (802.1x).

NONE — OPEN Security type

WEP40/128-BITKEY — WEP 40/128-bit Key

WEP128-BITPASSPHRASE — WEP 128-bit Passphrase

LEAP — leap

WPA&WPA2PERSONAL — WPA and WPA2 personal

WPA&WPA2ENTERPRISE — WPA and WPA2 Enterprise

DYNAMICWEP — Dynamic WEP (802.1x)

AuthType Notes:

Connection Settings Parameter Options 27

Parameter Description

AuthType should be OpenSystem or SharedKey when Security is

WEP40/128-BITKEY or WEP128-BITPASSPHRASE; For other enterprise

securities, AuthType should be 'TLS/LEAP/TTLS/PEAP'. For WPA &

WPA2 Enterprise security, only the LEAP authentication type is supported.

WEP-KEY Notes:

WEP-KEY1 through WEP-KEY4 are optional. WEPKEYINDEX=<key index

number> is optional.

IMPORTANT:

If not specied, by default it is set to the key

corresponding to WEP-KEY1.

InnerAuth — Species the second EAP type inside the PEAP tunnel. Used

only in cases of PEAP authentication.

PeapVersion - Default is Auto. Species the PEAP protocol version.

CACerticate - Root CA certicate name for authentication.

For Examples:

Security type OPEN example: WLAN=wlan1 SSID=XYZ\ Security=none

Mode=Infrastructure.\

Security type WEP 40/128-bit key example:

WLAN=wlan2 SSID=XYZ \

Security=wep40/128-bitkey \

Mode=Infrastructure Wep Key1=1234567890\

WepKeyIndex=1\

AuthType=OpenSystem type\

WEP 128-bit Passphrase example:

WLAN=wlan3 SSID=ABCD \

Security=wep128-bitpassphrase \

Mode=Infrastructure

Wep-key1=1111111111 \

Wep-Key2=2222222222 \

WepKeyIndex=2 \

Authtype=OpenSystem\

Security type WPA & WPA2 Personal example:

WLAN=wlan4 SSID=WPA2 \

Security=wpa&wpa2personal \

Mode=Infrastructure Password=12345678\

28 Connection Settings Parameter Options

Parameter Description

Security type LEAP example:

WLAN=wlan5

SSID=Wyse Security=leap \

Mode=Infrastructure \

Username=admin \

Password=1234567890 \

AuthType LEAP example:

WLAN=wlan6 SSID=ACS \

Security=wpa&wpa2enterprise \

Mode=Infrastructure \

AuthType=leap \

Username=linux\

Password=linux\

AuthType PEAP example:

WLAN=W2EN \

SSID=W2EN \

Security=wpa&wpa2enterprise \

Username=peap \

Password=peap \

AuthType=peap \

InnerAuth=mschapv2 \

PeapVersion=Auto \

CACerticate=/etc/certicate/rootcer.cer\

Connection Settings Parameter Options 29

Custom GNOME Settings Parameter Options

The following table contains parameters used for conguring Custom GNOME settings where default values are underlined.

Table 5. Custom GNOME Settings Parameter Options

Parameter Description

Custom.Menus=<Display:both,Time and Date:admin> The value of Custom.Menus is a non-quoted string. The menu item

which appears in the Settings App (in English) is used as the NAME.

The value must be with , separated items and : delimiter for privilege

level: {NAME1: privilege, NAME2: privilege …} or <default>

Do not useor for any string. There cannot be white space between the :

delimiter. The NAME is case sensitive and must be same for the menu

item name.

Example 1:

The following INI settings sets Display menu to be available for both

admin and user modes, Time and Date menu is available in admin mode

only, and add-ons menu will not be available either in user or in admin

mode.

Custom.Menus=Display:both, \

Time and Date:admin, \

Add-ons:none

Example 2:

The following INI resets all privilege to default.

Custom.Menus =<default>

Custom.PowerButton.AllowPowerO={yes,no} Default is yes

Customizes the Power O option to be available from Power Button in

user mode.

yes: allows Power O in user mode.

no: disable Power O option in user mode.

Custom.PowerButton.AllowRestart={yes, no} Default is yes

Customizes the Restart option to be available from Power Button in

user mode.

yes: allows restart in user mode.

no: disables restart option in user mode.

Custom.PowerButton.Default=<yes> Reset the Power Button customization back to factory default.

6

30 Custom GNOME Settings Parameter Options

Parameter Description

Custom.Taskbar.AllowActivitiesIcon={yes, no} Default is yes

Customize the Activities icon to be enabled or disabled in user mode.

yes: Activities icon is enabled on Taskbar in user mode.

no: Activities icon is disabled on Taskbar in user mode.

Custom.Taskbar.AllowAudioIcon={yes, no} Default is yes

Customizes the Audio Volume icon to be enabled or disabled in user

mode.

yes: Audio Volume icon is enabled on Taskbar in user mode.

no: Audio Volume icon is disabled on Taskbar in user mode.

Custom.Taskbar.AllowDateTimeIcon={yes, no} Default is yes

Customizes the Date and Time icon to be enabled or disabled in user

mode.

yes: Date and Time icon is enabled on Taskbar in user mode.

no: Date and Time icon is disabled on Taskbar in user mode.

Custom.Taskbar.AllowKeyboardIcon ={yes, no} Default is yes

Customizes the Keyboard icon to be enabled or disabled in user mode.

yes: Keyboard icon is enabled on Taskbar in user mode.

no: Keyboard icon is disabled on Taskbar in user mode.

Custom.Taskbar.AllowNetworkIcon ={yes, no} Default is yes

Customizes the Network icon to be enabled or disabled in user mode.

yes: Network icon is enabled on Taskbar in user mode.

no: Network icon is disabled on Taskbar in user mode

Custom.Taskbar.AllowPowerIcon ={yes, no} Default is yes

Customizes the Power icon to be enabled or disabled in user mode.

yes: Power icon is enabled on Taskbar in user mode.

no: Power icon is disabled on Taskbar in user mode.

Custom.Taskbar.AllowSystemInformationIcon ={yes, no} Default is yes

Customizes the System Information icon to be enabled or disabled in

user mode.

yes: System Information icon is enabled on Taskbar in user mode

no: System Information icon is disabled on Taskbar in user mode.

Custom.Taskbar.Default =<Yes> Reset the Taskbar Icon customization back to factory default.

Custom GNOME Settings Parameter Options 31

Parameter Description

Custom.Taskbar.Hide={no, yes} Default is no

Hides the entire Taskbar in user mode.

yes: hides the Taskbar completely in user mode.

no: show Taskbar

32 Custom GNOME Settings Parameter Options

Connect Parameter Options

This section provides the options that you can use for the Connect parameter in the following supported connections:

•Browser Connect Options

•Custom Connect Options

•Citrix Connect Options

•RDP Connect Options

•SSH Connect Options

•VMware View Connect Options

•VNC Viewer Connect Options

•Ericom PowerTerm Connect Options

Topics:

• Browser Connect Options

• Custom Connect Options

• Citrix Connect Options

• RDP Connect Options

• SSH Connect Options

• VMware View Connect Options

• VNC Viewer Connect Options

• Ericom PowerTerm Connect Options

Browser Connect Options

The following table contains the supported options you can use for Browser connections where default are in bold:

Example: Browser connect options

CONNECT=BROWSER \

Description="XenDesktop" \

URL=http://10.140.155.31 \

Resolution=FullScreen \

AutoConnect=1 \

Mode=kiosk \

LocalCopy=no

Table 6. Browser Connect Parameter Options

Option Description

AutoConnect={no, yes} Default is no.

7

Connect Parameter Options 33

Option Description

You can start a connection automatically at sign-on.

Description=<string description> Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION: The text must be enclosed in double quotation

marks if it contains spaces or punctuation characters.

These characters are not allowed: &‘"$?!|;()[]{}\

Icon=<image le> Species an icon to appear on the local desktop or Connection

Manager. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed except in the

case of a published application. A PNG, JPEG or GIF may be used.

XPM is permitted for backward compatibility.

LocalCopy={no, yes} Default is no.

You can use the local copy of the ini le.

Mode={kiosk, normal} Default is normal.

It launches refox in kiosk or normal mode.

Reconnect={no, yes} Default is no.

It is used to display the Enable Auto Reconnect check box to

control automatic reconnection to an application server after a

disconnection.

Option Values and actions:

yes or 1 — Enables the Enable Auto Reconnect check box.

no or 0 — (default) Disables the Enable Auto Reconnect check

box.

ReconnectSeconds=<value in seconds> Default is 30.

Species the amount of time in seconds (default is 30) to wait

before automatic reconnection to an application server after a

disconnection. Requires Reconnect = yes or 1

Resolution={ default, maximized,640x480, 800x600, 1024x768,

1280x1024, 1600x1200}

Default is default.

Species the connection window size.

URL=<URL> Species the starting URL.

Custom Connect Options

The following table contains the supported options you can use for Custom connections where default values are in bold:

Example:

CONNECT=Custom \

Description="Custom_Connection" \

AutoConnect=Yes \

34 Connect Parameter Options

Reconnect=Yes \

ReconnectSeconds=100 \

Command=/usr/bin/xterm

Table 7. Custom Connect Parameter Options

Option Description

AutoConnect={no, yes} Default is no

AutoConnect option is used to start a connection automatically at

sign-on.

Command=<String> Default is none

Species a command to execute. For xterms, it is recommended to

use the -ls option, because it is a login shell.

Description=<String> Default is none

Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION:

The text must be enclosed in quotation marks, if it contains spaces

or punctuation characters. These characters are not allowed &

‘ “ $ ? ! | ; ( ) [ ] { } \

Icon=<image le> Species an icon to appear on the local desktop or Connection

Manager. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed except in the

case of a published application. A PNG, JPEG or GIF may be used.

XPM is permitted for backward compatibility.

LocalCopy={no, yes} Default is no

LocalCopy option is used to save the connection in the local

permanent registry.

Reconnect={no, yes} Default is no

Reconnect option is used to automatically reconnect to an

application server after a disconnection.

ReconnectSeconds=<value in seconds> Default is 30

Species the amount of time in seconds to wait before automatic

reconnection to an application server after a disconnection. It

requires, Reconnect= yes or 1.

Runinterminal= {yes, no} Default is no.

This option can be used to customize connection with the terminal.

Citrix Connect Options

The following table contains the supported options you can use for Citrix connections where default values are in bold:

Example: Server connection

Connect Parameter Options 35

CONNECT=ICA \

Host=192.168.1.2 \

Description="ICA_Desktop " \

AutoConnect=Yes \

Reconnect=Yes \

Encryption=128 \

Colors=16m \

Fullscreen=No \

Resolution=800x600 \

Username=$UN \

Password=$PW \

Domainname=$DN \

Alternate=Yes \

LowBand=Yes \

LocalCopy=no

Example: Published application connection

connectionCONNECT=ICA \

BrowserIP=192.168.1.2 \

Application="Desktop" \

Description="ICA_Desktop " \

AutoConnect=Yes \

Reconnect=Yes \

Encryption=128 \

Colors=16m \

Fullscreen=No \

Resolution=800x600 \

Username=$UN \

Password=$PW \

Domainname=$DN \

Alternate=Yes \

LowBand=Yes \

36 Connect Parameter Options

LocalCopy=no

Example: Storefront Connection:

Connect=ICA \

Application="win81" \

Browserip=hostname.domain.com \

Description="Store-Xendesk7" \

AutoConnect=no \

HttpBrowsing=ssl \

StoreName=Store \

StoreFront=yes \

FullScreen=yes \

AutoConnect=no \

Reconnect=10

Example — Smart Card Enabled to Storefront connection when smart card enabled:

Connect=ICA \

Application=win7 \

StoreName=Store \

StoreFront=Yes\

BrowserIP=192.168.1.2 \

Description=smartcard_test \

Username=$UN \

DomainName=$DN\

SmartCard=yes \

HTTPBrowsing=ssl \

smartcardtype=GEMALTODOTNET

Table 8. Citrix Connect Parameter Options

Options Description

Application= <Application name of type string > Species the name of the published application to be launched. The

names of the applications to be published can be congured by the

administrator. It is a mandatory option for launching PA and

Storefront connections.

For Example: Notepad

AutoConnect={yes, no} Default is no.

Connect Parameter Options 37

Options Description

Enable this parameter for a specic connection ,to automatically

trigger the connection to xenapp or xendesktop server after user

log-on.

BrowserIP = <Comma separated value of type string. Each value

should be a valid IP address or full qualied host name. To separate

Items on the list, use semicolons or commas>

Each address in the list will be tried in the order listed until a

successful connection is established. Once successful connection is

established , remaining entries will not be tried.

It is a mandatory parameter for both PA and storefront

connections.

Colors={256, 64k, 16m} Default is 64k.

Species the session color mode. For faster display performance,

use 256 colors.

Description=<string> Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION: The text must be enclosed in double quotation

marks, if it contains spaces or punctuation characters.

These characters are not allowed: &‘ “ $?!|;()[]{}\

DomainName=<domain name or $DN> This parameter species the domain name. $DN species that the

thin client sign-on domain name is used.

Encryption={ Basic, 40, 56, 128, Login-128} Default is Basic.

Species the connection security level. The highest level is 128-bit

security and the lowest level is Basic.

For v7.x VDI agent will support only 128 bit, for Citrix.

FullScreen={yes, no} Default is no.

In order to run the session in full screen not in a window, you can

set this parameter to yes.

Host=<string> This is a mandatory parameter for server connection. This is

applicable only for Server connections. Use comma separated list of

IP address. To separate the list of items, use semicolon or comma.

HttpBrowsing= {no,yes,ssl} Designates the browsing protocol.

Icon=<image le> Species an icon to appear on the local desktop or Connection

Manager. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed except in the

case of a published application. A PNG, JPEG or GIF may be used.

XPM is permitted for backward compatibility.

LocalCopy={yes, no} Default is no

Enable this parameter for a specic connection if the setting

parameter pertaining to that connection needs be stored in the

registry permanently, if enabled the settings parameter will be

stored across system reboot.

LowBand={yes, no} Default is no.

38 Connect Parameter Options

Options Description

To enable optimization for low-speed connections, such as reducing

audio quality or decreasing protocol-specic cache size.

NoReducer={yes, no} Default is yes.

You can enable or disable the compression during the session.

Password={base-64 encoded password string , $SN, $MAC, $IP,

$DN, $UN, $PW, $TN}

Species the password required to log in to the application server.

Either a base-64 encoded login password or a variable can be used.

password — base-64 encoded login password

Variable and Description:

$SN — Serial number

$MAC — MAC address

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

$TN — Terminal name

NOTE: The application server password is not encrypted.

The user is prompted to enter the password when the

connection is made. This application server password

directive never starts a line, so it can be distinguished

from the thin client user sign-on password which starts a

line.

Ping={yes, no} Default is yes.

This option is used to enable ping. For non published application

connections, a ping (ICMP) is sent to the host server prior for

connecting, to verify that the host is reachable.

Reconnect={ no, yes, value of 1 to 3600} Default is no.

It controls the automatic reconnection to an application server after

a disconnection.

Option Value and action:

yes — Immediately restarts the connection in 30 seconds after a

disconnect. Default for reconnect is 30 seconds.

no — (default) Does not reconnect after a disconnect.

1...3600 — (integer) Species the interval to wait in seconds

before automatically restarting the connection after a

disconnection. Valid range is 1–3600.

Resolution={ default, seamless, 640x480, 800x600, 1024x768,

1280x1024, 1600x1200}

Default is default, which starts the connection using the current

desktop display setting.

Species the connection display resolution. The default value starts

the connection using the current desktop display setting. Seamless

Connect Parameter Options 39

Options Description

option is applicable only for Published Application and Storefront

connections.

SmartCard={ Yes,no} Default is no.

When set to yes, this option enables logging into the Citrix Server

with a Smart Card PIN. This parameter is not applicable for PA

connections.

SmartCardType={ GEMALTODOTNET, CAC, PIV} Species the type of the smart card you are using to make the

connection to the Storefront Server.

To enable smart card login, set parameter SmartCard=yes and

parameter smartcardtype to type of smart card.

NOTE: It is applicable only for storefront server.

StoreFront={yes, no} The option to have the connection attempt to connect to the

Storefront server. There is no default value. If set to no, the

connection attempts to connect to the PNAgent server.

StoreName=< Name of the Store> It species the name of the Store through which the connection for

Storefront server is established.

Username={<username>, $SN, $MAC, $IP, $DN, $UN, $PW, $TN} Species the name required to log in to the application server.

Either a conventional login name or a variable can be used.

Variable and Description:

username — Conventional login name

$SN — Serial number

$MAC — MAC address

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

$TN — Terminal name

RDP Connect Options

The following table contains the supported options you can use for RDP connections where default values are in bold:

Example:

CONNECT=RDP \

Host=192.168.1.2 \

Description="RDP_Server" \

AutoConnect=yes \

Colors=16m \

40 Connect Parameter Options

username=$UN \

Password=$PW \

Domainname=$DN \

Resolution=800x600 \

Reconnect=no \

Drives=J=disk \

Drives=k=floppy \

Sound=off \

LocalCopy=Yes \

UseRDGateway=Yes \

RDServer=192.168.1.2 \

SameLoginForRD= Yes \

RDUserName=$UN \

RDPassword=$PW\

RDDomainName=$DN

Table 9. RDP Connect Parameter Options

Options Description

Application=<Remote App Name> Species the remote application that you want to launch through

RDP

AutoConnect={no, yes} Default is no

This option is used to start a connection automatically at sign-on.

Colors={ 4b,32k,64k,16m } Default is 4b.

Species the session color mode. For faster display performance,

use 256 colors.

Command=<start command> Default is none

Species a command to execute remotely. For xterms, it is

recommended that the -ls option to be used because it is a login

shell

Description=<string description> Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION: The text must be enclosed in quotation marks

if it contains spaces or punctuation characters. These

characters are not allowed & ‘ “ $ ? ! | ; ( ) [ ] { } \

Directory=<working directory> Species a directory to be used as the working directory after log

on to the server. The maximum is 63 characters.

Connect Parameter Options 41

Options Description

DomainName={<domainname>, $DN} This parameter species the domain name. $DN species that the

thin client sign-on domain name is used.

Drives=<drive letter>= <drive_name> [,basedir] It maps drives on the server to USB mass storage devices attached

to the thin client, where

drive letter= A to Z

drive_name = usbstorage-x and cdrom-x, where x=0,1,2 and so on.

basedir=an optional directory on the USB device to use.

NOTE:

• Drives = WyseUSB = all, use this parameter to enable

RDP drive mapping.

• Make sure each drive command is separated by a space.

Encryption= {none, normal} If the value is none, then no encryption is used.

NOTE: Use this option when connecting to a server with

data encryption between the communication of the server

and the client.

EnableH264={yes,no} Default is Yes.

EnableUDP={Yes,No} Default is Yes.

ForwardPrinters={yes, no} Default is yes.

Yes/no option to enable the forwarding and use of all available

printers to or with the RDP session. Any direct RDP connection is

supported (not supported through VMware View broker).

FullScreen={no, yes} Default is no

Runs the session at full screen.

Host=<host server name or IP address> Species the server name or IP address to connect.

NOTE: This option is mandatory.

Icon=<bitmap le> Species an icon to appear on the thin client desktop for this

connection. The le must be an XPM le located in the FTP server

wlx2/bitmap directory. If not specied, the default icon is displayed.

LocalCopy={no, yes} Default is no

The LocalCopy option is used to save this connection in the local

permanent registry.

LowBand={no, yes} Default is no

LPTports=LPTx={LPTy,USBLPz},LPTx=... It maps parallel devices on the server to make devices parallel on

the thin client, where x=1 to 4; if LPTy, map to that parallel port on

the thin client; if USBLPz, map to that USB parallel port.

NOTE: Make sure each serial device command is

separated by a comma and space, and Windows 2000

servers do not support LPT port mapping.

42 Connect Parameter Options

Options Description

NLA={yes,no} Default is no.

NLA option is used to enable Network Level Authentication for RDP

sessions.

NotifyDisconnect={yes,no} Default is no.

It Noties the Disconnection.

NoGrabKeyboard={no, yes} Default is no.

NoGrabKeyboard option is used to enable the keyboard event

grabbing in any direct RDP connection session (not supported

through VMware View broker).

Password={<base-64 encodedpassword>, $SN, $MAC, $IP, $DN,

$UN, $PW, $TN}

Species the password required to log in to the application server.

Either a base-64 encoded log-in password or a variable can be

used.

password — base-64 encoded log-in

password Variable and Description:

$SN — Serial number

$MAC — MAC address

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

$TN — Terminal name

Ping={yes,no} Default is no.

Ping option is used to enable ping. For non-published application

connections, a ping (ICMP) is sent to the host server prior to

connecting to verify that the host is reachable.

RDDomainName=<RD Domain name> Species the RD Domain name to use for the RD Gateway Login.

RDPassword=<RD Password> Species the RD Password to use for the RD Gateway login. This

parameter should be base-64 encrypted.

RdpClipboard={yes,no} Default is yes

RdpClipboard option is used to enable the clipboard in an RDP

session.

RDServer=<RDServer address> Species the RD Gateway host address

RDUsername=<RD UserName> Species the RD Username to use for RD Gateway Login

Reconnect={no, yes} Default is no

Connect Parameter Options 43

Options Description

Reconnect option is used to automatically reconnect to an

application server after a disconnection.

ReconnectSeconds=<1 to 3600> Default is 30

Species the amount of time in seconds (default is 30) to wait

before automatic reconnection to an application server after a

disconnection. Requires Reconnect=yes or 1.

Resolution= {default, 640x480, 800x600, 1024x768, 1280x1024,

1600x1200}

Default value is default, which starts the connection using the

current desktop display setting.

Species the connection display resolution. The default value starts

the connection using the current desktop display setting.

SameLoginForRD={yes,no} Default is yes.

SameLoginForRD option is used to enable Smart Card

Authentication.

SocketRecvTimeout=<timeout in seconds> If the RDP client is unable to connect to the server in 120 seconds,

the connection times out. Using this parameter you can specify a

custom value other than 120 seconds.

Sound= {o, local, remote} Default is local.

You can enable or disable the sound eect using the Sound

parameter.

o - disable sound

local - enable sound to local machine (default)

remote - enable sound to remote machine

UseRDGateway={yes,no} Default is yes.

UseRDGateway option is used to enable RD gateway.

Username={<username>, $SN, $MAC, $IP, $DN, $UN, $PW, $TN} Default is none.

Species the name required to log in to the RDP server.

Either a conventional login name or a variable can be used. Variable

and Description:

username — Conventional log-in name

$SN — Serial number used

$MAC — MAC address used

$IP — IP Address used

$DN — Sign-on domain name

$UN — Sign-on name used

$PW — Sign-on password used

$TN — Terminal name

44 Connect Parameter Options

Options Description

Smartcard={no, yes} Default is no.

Yes/no option is used to enable Smart Card Authentication.

Speed_level={Broadband/LAN/Modem/Custom} Default value is LAN.

Handles the performance based on bandwidth.

SSH Connect Options

The following table contains the supported options you can use for SSH connections where defaults values are in bold:

Example:

CONNECT=SSH \

Description="SSH_Connection" \

Host=192.168.1.2 \

Reconnect=yes \

ReconnectSeconds=100 \

Username=root \

Command=/usr/X11R6/bin/xterm\ \

LocalCopy=no

Table 10. SSH Connect Parameter Options

Option Description

AutoConnect={no, yes} Default is no

AutoConnect option is used to start a connection automatically at

sign-on.

Command=<command > Default is none

Species a command to execute remotely. For xterms, it is

recommended that the -ls option be used, because it is a login shell

Description=<string description> Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION: The text must be enclosed in quotation marks

if it contains spaces or punctuation characters. These

characters are not allowed & ‘ “ $ ? ! | ; ( ) [ ] { } \

Host=<host server name or IP address> Default is none

Species the server name or IP address to connect.

NOTE: This option is mandatory.

Icon=<bitmap le> Default is none

Connect Parameter Options 45

Option Description

Species an icon to appear on the thin client desktop for this

connection. The le must be an XPM le located in the FTP server

wlx2/bitmap directory. If not specied, the default icon is displayed.

LocalCopy={no, yes} Default is no.

LocalCopy option is used to save the connection in the local

permanent registry.

Reconnect={no, yes} Default is no

Reconnect option is used to automatically reconnect to an

application server after a disconnection.

ReconnectSeconds=<value in seconds> Default is 30

Species the amount of time in seconds (default is 30) to wait

before automatic reconnection to an application server after a

disconnection. Reconnect=yes or 1 is required.

Username={<username>, $SN, $MAC, $IP, $DN, $UN, $PW, $TN} Default is none.

Species the name required to log in to the SSH server.

Either a conventional log-in name or a variable can be used.

Variable and Description:

username — Conventional log-in name

$SN — Serial number used

$MAC — MAC address used

$IP — IP Address used

$DN — Sign-on domain name

$UN — Sign-on name used

$PW — Sign-on password used

$TN — Terminal name

VMware View Connect Options

The following table contains the supported options you can use for VMware View Client connections where default values are in bold:

Example:

CONNECT=VMWARE_VIEWCLIENT \

Description="VMviewadmin" \

Host=192.168.1.2 \

useSSL=Yes \

Interactive=No \

Securemode=donotverify \

46 Connect Parameter Options

Fullscreenmode=Yes \

Disableconnectonce=Yes \

Username=$UN \

Password=$PW \

Domainname=$DN \

Ping=Yes \

Protocol=PCoIP \

Application=Calculator

Table 11. VMware View Connect Parameter Options

Option Parameter

Application=<application name> Use the published application name in non-interactive mode.

AutoConnect={no, yes} Default is no

AutoConnect option is used to start a connection automatically at

sign-on.

Description=<string description> Default is none

Connection description provides a connection name for the

Desktop icon and the Connection Manager.

CAUTION: The text must be enclosed in quotation marks

if it contains spaces or punctuation characters. These

characters are not allowed & ‘ “ $ ? ! | ; ( ) [ ] { } \

Desktop=<desktop name> Use the published desktop name in non-interactive mode.

Desktopsize={ fullscreen, largewindow, smallwindow,

useallmonitors, 1024x768, 800x600, 640x480 }

Default is fullscreen.

Species the desktop size either fullscreen, largewindow,

smallwindow or use exact size in the form XxY.

Disableconnectonce={no, yes} Default is no.

This option disables the listing of View desktops after session logs

out when an error occurs.

Disableviewmenubar={no, yes} Default is no.

This option helps you to disable top full screen drop-down menu

bar.

DomainName=<string> Species the domain name in a Windows network where the

VMware server is located.

EnableNLA={yes,no} Default is no.

This option initiates the authentication and prompts you to enter

the login credentials when you try to add a new VMware

connection.

Connect Parameter Options 47

Option Parameter

EnableUDP={yes,no} Species whether UDP networking should be enabled in the

session. Default is yes.

EnableH264={yes,no} Species whether H.264 decoding should be enabled in the

session. Default is yes.

Fullscreenmode={no, yes} Default is no.

This option enables full screen mode and when selected it disables

the Desktopsize option.

EnableMMR={yes,no} Default is no.

Enable/disable MMR in VMWare View connection settings.

Host=<host server name or IP address> Default is none

Species the server name or IP address to connect.

NOTE: This option is mandatory.

Icon=<image le> Species an icon to appear on the local desktop or Connection

Manager. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed except in the

case of a published application. A PNG, JPEG or GIF may be used.

XPM is permitted for backward compatibility.

Interactive={yes, no} Default is yes.

Interactive option is used to enable interactive connection mode.

LockServerURLField={yes,no} Default is yes.

This option enables the New Server option when you try to add a

new VMware connection.

Monitors=<numbered list> Enter a value to specify which subset of the monitors to use.

For Example : Monitors= 2,3 If you specify the numbered list as 2, 3

in a conguration where four monitors are set next to each other

horizontally, the windows session will be displayed in the 2nd and

3rd monitors only and local session will be available in 1st and 4th

monitors.

Password={base-64 encoded password string , $SN, $MAC, $IP,

$DN, $UN, $PW, $TN} Species the password required to log in to the application server.

Either a base-64 encoded login password or a variable can be used.

password — base-64 encoded login password.

Variable and Description: $SN — Serial number

$MAC — MAC address

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

48 Connect Parameter Options

Option Parameter

$TN — Terminal name

NOTE: The application server password is not encrypted;

not specifying it is recommended. The user is prompted to

enter the password when the connection is made. This

application server password directive never starts a line,

so it can be distinguished from the thin client user sign-on

password which starts a line.

Ping={yes, no} Default is yes.

You can enable the ping using Ping parameter. For non-published

application connections, a ping (ICMP) is sent to the host server

prior to connect, to verify that the host is reachable.

Port=<port number> Default is 443. Species a dierent port number other than default

443 for SSL connection.

Protocol={PCOIP, RDP, Blast} Default is PCoIP.

Species the protocol to use.

Reconnect={no, yes} Default is no.

Reconnect option is used to automatically reconnect to an

application server after a disconnection.

ReconnectSeconds=<value in seconds> Default is 30.

Species the amount of time in seconds (default is 30) to wait

before automatic reconnection to an application server after a

disconnection. Reconnect=yes is required.

SecureMode={neverconnect, warnbefore, donotverify} Default is warnbefore.

Species how to control the connection security mode preferences.

Value and Description:

neverconnect — Never connect to untrusted servers.

warnbefore — Warn before connecting to untrusted servers.

Username={<username>, $SN, $MAC, $IP, $DN, $UN, $PW, $TN} Species the name required to log in to the application server.

Either a conventional login name or a variable can be used.

Variable and Description:

username — Conventional login name

$SN — Serial number

$MAC — MAC address

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

Connect Parameter Options 49

Option Parameter

$TN — Terminal name

UsbAutoConnectOnInsert= {yes, no} Species whether the USB should be automatically connected in

session on inserting the USB. Default is yes.

UsbAutoConnectAtStartup= {yes, no} Species whether the USB should be automatically connected in

session on Session Startup. Default is yes.

view.sslCipherString Congures the cipher list to restrict the use of certain

cryptographic algorithms before establishing an encrypted SSL

connection. The default value for Horizon Client 3.5 and later is !

aNULL:kECDH+AES:ECDH+AES:RSA+AES:@STRENGTH.

The default value for Horizon Client 3.4 and earlier is AES:!

aNULL:@STRENGTH.

view.sslProtocolString Congures the cipher list to restrict the use of certain

cryptographic protocols before establishing an encrypted SSL

connection.

The default value for Horizon Client 3.5 and later is

TLSv1.0:TLSv1.1:TLSv1.2.

The default value for Horizon Client 3.4 and earlier is

TLSv1.0:TLSv1.1.

VNC Viewer Connect Options

The following table contains the supported options you can use for VNC Viewer connections where default values are in bold:

Example:

CONNECT=VNC_VIEWER \

Description="VNC_Connection" \

Host=192.168.0.2 \

Color=True_Color \

AutoConnect=Yes \

Password=xyz \

Fullscreen=Yes \

LocalCopy=No

Table 12. VNC Viewer Connect Parameter Options

Options Description

AutoConnect={yes, no} Default is no.

It starts the connection automatically at sign-on, if AutoConnect is

set to yes.

Colors ={True_Color, 0, 1, 2, 16, 24} Default is True_Color

50 Connect Parameter Options

Options Description

Species how many colors to display. True_Color species full

color, 0 species 8 colors, 1 species 64 colors, and 2 species

256 colors.

For backward compatibility, 16 and 24 values are also accepted. In

these cases, 16 is mapped to 1 (that is 64 colors) and 24 is mapped

to 2 (that is 256 colors).

Compression=<integer{1 to 6}> Default is 2

Sets compression level to the specied value, where 0 = Low and 6

= High.

Description=< String> Default is none.

Connection name. Provides a connection name for the Desktop

icon and the Connection Manager.

CAUTION: The must be enclosed in double quotation

marks if it contains spaces or punctuation characters. The

following characters are not allowed: & ‘ “ $ ? ! | ; ( ) [ ]

{ } \

FullScreen={ yes, no} Default is no.

VNC session will run at full screen, if FullScreen is set to yes.

Host= <host address>[;<host

address>...]

Default is none

Species a host or lists of host values. The thin client attempts to

connect to the next server on the list if the current one fails. The

list items must be separated by semicolons or commas.

NOTE: This parameter is mandatory.

Icon=<image le> Species an icon to appear on the local desktop or Connection

Manager. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed except in the

case of a published application. A PNG, JPEG or GIF may be used.

XPM is permitted for backward compatibility.

JpegQuality=<integer{0 - 9}> Default is 8

JPEG Quality levels are,

0 = Low and 9 = High.

LocalCopy= {yes, no} Default is no.

LocalCopy saves the connection in the local permanent registry, if

LocalCopy parameter is set to yes.

Password=<base-64 encoded password> Species the password required to log in to the VNC server. Either

a base-64 encoded login password or a variable can be used.

password — base-64 encoded login password

$SN — Serial number

$MAC — MAC address

Connect Parameter Options 51

Options Description

$IP — IP Address

$DN — Sign-on domain name

$UN — Sign-on name

$PW — Sign-on password

$TN — Terminal name

NOTE:

The VNC server password is not encrypted; not specifying it is

recommended. The user is prompted to enter the password when

the connection is made. This VNC server password directive never

starts a line, so it can be distinguished from the thin client user

sign-on password which starts a line.

Shared= {yes, no} Default is no

When a connection is shared, other viewers are not disconnected

when a new connection is established.

ViewOnly= {yes, no} Default is no.

VNC connection will be created in view only mode when this

parameter is set to Yes, which means mouse and keyboard input to

the remote machine will be disabled.

Ericom PowerTerm Connect Options

The following table contains the supported options you can use for Ericom PowerTerm Connect, where default values are in bold:

Example:

CONNECT=Ericom_Powerterm \

Description="Ericom_Test" \

Host=192.168.0.2 \

AutoConnect=Yes \

Reconnect=Yes \

ReconnectSeconds=30 \

Filename=RemoteCongurationFileName \

Filepath=wyse/WLX2/RemoteCongurationFilePath \

Terminal=WY50 \

TermName=Wyse 50 terminal \

Resolution=800x600 \

Fullscreen=No \

DeviceID=Wyse50 \

52 Connect Parameter Options

Echo=No \

UICong=menu

Table 13. Ericom PowerTerm Connect Parameter Options

Options Description

AutoConnect={no, yes} Default is no.

Yes/no option allows you to start a connection automatically at

sign-on.

Description=<string> Connection description, provides a connection name for the

Desktop icon and the Connection Manager.

NOTE: The text must be enclosed in double quotation

marks if it contains spaces or punctuation characters.

These characters are not allowed: &‘“$?!;()[]{}\

DeviceID=<string> Species the terminal identication string, that is sent as a

response when a request for identication is requested to the

terminal.

Echo={no, yes} For serial connection only.

Default is no.

Yes/no option allows you to set the local echo option on the serial

port.

FileName=<name> FileName option provides the list of conguration le names that

you want to use.

FilePath=<le location> Species the location of the conguration les on the server.

FullScreen={no, yes} Default is no.

Yes/no option allows you to run the session at full screen (not in a

window).

Host=<host address> [; <host address>.....] Mandatory option

Species the host. The thin client attempts to connect to the next

server on the list if the current one fails. To separate the list items,

use semicolons or commas.

Icon=<image le> Species an icon to appear on the thin client desktop for this

connection. The le must be located in the server wlx2/bitmap

directory. If not specied, the default icon is displayed. A PNG,

JPEG, or GIF may be used. XPM is permitted for backward

compatibility.

LocalCopy={no, yes} Default is no.

LocalCopy option allows you to save the connection in the local

permanent registry.

Phone=<phone number> For serial connection only.

Species the modem dial-up number.

Connect Parameter Options 53

Options Description

Port= {COM1, COM2...} For serial connection only.

Default is COM1.

Designates the connection serial port.

Reconnect={no, yes} Default is no.

Yes option allows you to automatically reconnect to an application

server after a disconnection.

ReconnectSeconds=<value in seconds> Default is 30.

Species the amount of time in seconds to wait before automatic

reconnection to an application server after a disconnection.

Resolution={default, 640x480, 800x600, 1024x768, 1280x1024,

1600x1200, Full Screen, <width>x<height>

Default is default.

which starts the connection using the current desktop display

setting with no window frame or border. Species the connection

display resolution. The default value starts the connection using the

current desktop display setting with no window frame or border.

Arbitrary widthxheight values are accepted.

{TerminalType, TerminalID ,Terminal} =<emulationtype> Default is Wyse50.

Species the terminal emulation type.

Termname=<terminal ID string> Species the terminal identication string that is sent as a response

when a request for identication is requested to the terminal.

UIcong={menu, toolbar, status, buttons} Default is no.

Opens the connection window with the menu, toolbar, status bar,

or buttons displayed.

For Example, UIcong=menu

54 Connect Parameter Options

Printer Parameters Option

This appendix provides the options that you can use for the following supported printer parameters:

•Printer

•JetDirectPrinter

•NetworkPrinter

•PrinterURI

•SMBPrinter

Topics:

• Printer

• JetDirectPrinter

• NetworkPrinter

• PrinterURI

• SMBPrinter

Printer

The following table contains the supported options you can use for the Printer parameter, where defaults values are underlined.

NOTE: The Printer command line denes a locally attached printer connected through the noted interface.

Table 14. Printer Parameter Options

Options Description

Default={yes, no} Default is yes

Description=<string> Not used internally.

Enable={yes, no} Default is yes

ModelID={<linux driver name>} Identies the printer for the purpose of choosing a Linux printer

driver

For example, Dell B5465dnf Laser MFP.

Name=<printer name> Provides both the name that is given in the local printers list and

the internal name of the local print queue. The name must be

between 1 and 16 characters, starting with a letter and composed

entirely of letters, digits, underscores, and dashes.

NOTE: This parameter is mandatory

PPD=<PPD name> It directly species a Postscript Printer Denition lename for use,

as a local printer driver.

8

Printer Parameters Option 55

Options Description

PrinterID= <Windows driver> Identies the printer for the purpose of choosing a Windows printer

driver

For example, Brother MFC-420CN Printer. Specify this parameter if

you are forwarding the printer access to a Citirx or RDESKTOP

connection.

JetDirectPrinter

The Following Table contains the supported options you can use for the JetDirectPrinter parameter where defaults are in bold:

NOTE: The JetDirectPrinter command line denes a printer served an HP JetDirectprint server.

Table 15. JetDirectPrinter Parameter Options

Options Description

Default={yes, no} Default is yes

Description=<string> Not used internally.

Enable={yes, no} Default is yes

ModelID= <linux driver name> Identies the printer for the purpose of choosing a Linux printer

driver.

For example, Dell B5465dnf Laser MFP.

Name=<printer name> It provides both the name that is given in the local printers list and

the internal name of the local print queue. The name must be

between 1 and 16 characters, starting with a letter and composed

entirely of letters, digits, underscores, and dashes.

NOTE: This parameter is mandatory

PPD=<PPD name> Directly species a Postscript Printer Denition lename for use, as

a local printer driver.

PrinterID=<Windows driver> Identies the printer for the purpose of choosing a Windows printer

driver.

For example, Brother MFC-420CN Printer

Specify this parameter if you are forwarding the printer access to a

Citirx or RDESKTOP connection.

NetworkPrinter

The following table contains the supported options you can use for the NetworkPrinter parameter default values are in bold:.

56 Printer Parameters Option

Table 16. NetworkPrinter Parameter Options

Options Description

Default={yes ,no} Default is yes

Description=<string> Not used internally.

Enable={yes, no} Default is yes

Host=<host address> It provides host of the printer server.

ModelID=<linux driver name> Identies the printer for the purpose of choosing a Linux printer

driver.

For example, Dell B5465dnf Laser MFP.

Name=<printer name> It provides both the name that is given in the local printers list and

the internal name of the local print queue. The name must be

between 1 and 16 characters, starting with a letter and composed

entirely of letters, digits, underscores, and dashes.

NOTE: This parameter is mandatory

PPD=<PPD name> It directly species a Postscript Printer Denition lename for use,

as a local printer driver.

PrinterID=<Windows driver> Identies the printer for the purpose of choosing a Windows printer

driver.

For example, Brother MFC-420CN Printer.

Specify this parameter if you are forwarding the printer access to a

Citirx or RDESKTOP connection.

Queue=<printer queue> It provides printer queue on the server.

PrinterURI

The following table contains the supported options you can use for the PrinterURI parameter where defaults values are in bold:

Table 17. PrinterURI Parameter Options

Option Description

Default={yes ,no} Default is yes

Description=<string> Not used internally.

Enable={yes, no} Default is yes

ModelID=<linux driver name> It identies the printer for the purpose of choosing a Linux printer

driver.

For example, Dell B5465dnf Laser MFP.

Name=<printer name> It provides both the name that is given in the local printers list and

the internal name of the local print queue. The name must be

Printer Parameters Option 57

Option Description

between 1 and 16 characters, starting with a letter and composed

entirely of letters, digits, underscores, and dashes.

NOTE: This parameter is mandatory

PPD=<PPD name> It directly species a Postscript Printer Denition lename for use,

as a local printer driver.

PrinterID=<Windows driver> It identies the printer for the purpose of choosing a Windows

printer driver.

For example, Brother MFC-420CN Printer.

Specify this parameter if you are forwarding the printer access to a

Citirx or RDESKTOP connection.

SMBPrinter

The following table contains the supported options you can use for the SMBPrinter parameter where default values are in bold:

Table 18. SMBPrinter Parameter Options

Option Description

Default={yes ,no} Default is yes

Description=<string> Not used internally.

domain= string<domain> It provides domain to SAMBA server.

Enable={yes, no} Default is yes

ModelID=<linux driver name> It identies the printer for the purpose of choosing a Linux printer

driver.

For example, Dell B5465dnf Laser MFP.

Name=<printer name> It provides both the name that is given in the local printers list and

the internal name of the local print queue. The name must be

between 1 and 16 characters, starting with a letter and composed

entirely of letters, digits, underscores, and dashes.

NOTE: This parameter is mandatory

Password=<base64-encoded password> It provides the password to SAMBA server.

PPD=<PPD name> It directly species a Postscript Printer Denition lename for use,

as a local printer driver.

PrinterID=<Windows driver> It identies the printer for the purpose of choosing a Windows

printer driver.

For example, Brother MFC-420CN Printer.

Specify this parameter if you are forwarding the printer access to a

Citirx or RDESKTOP connection.

Username=<username> It provides the username to SAMBA server.

58 Printer Parameters Option

TimeZone Parameter: Values

The following table contains the supported values that you can use for the TimeZone parameter.

Table 19. TimeZone Parameter Options

Option Values

Date_time.TimeZone=<string>

Or TimeZone

Africa

The following values must be preceded with Africa/.

For example, Africa/Abidjan is the value for the Abidjan time zone.

Abidjan, Accra, Algiers, Bissau, Cairo, Casablanca, Ceuta, El_Aaiun,

Johannesburg, Khartoum, Lagos, Maputo, Monrovia, Nairobi, Ndjamena,

Tripoli, Tunis, Windhoek.

America

The following values must be preceded with America/. For example,

America/Adak is the value for the Adak time zone.

Adak, Anchorage, Araguaina, Argentina/Buenos_Aires, Argentina/

Catamarca, Argentina/Cordoba, Argentina/Jujuy, Argentina/La_Rioja,

Argentina/Mendoza, Argentina/Rio_Gallegos, Argentina/Salta, Argentina/

San_Juan, Argentina/San_Luis, Argentina/Tucuman, Argentina/Ushuaia,

Asuncion, Atikokan, Bahia, Bahia_Banderas, Barbados, Belem, Belize, Blanc-

Sablon, Boa_Vista, Bogota, Boise, Cambridge_Bay, Campo_Grande, Cancun,

Caracas, Cayenne, Cayman, Chicago, Chihuahua, Costa_Rica, Creston,

Cuiaba, Curacao, Danmarkshavn, Dawson, Dawson_Creek, Denver, Detroit,

Edmonton, Eirunepe, El_Salvador, Fortaleza, Fort_Nelson, Glace_Bay,

Godthab, Goose_Bay, Grand_Turk, Guatemala, Guayaquil, Guyana, Halifax,

Havana, Hermosillo, Indiana/Indianapolis, Indiana/Knox, Indiana/Marengo,

Indiana/Petersburg, Indiana/Tell_City, Indiana/Vevay, Indiana/Vincennes,

Indiana/Winamac, Inuvik, Iqaluit, Jamaica, Juneau, Kentucky/Louisville,

Kentucky/Monticello, La_Paz, Lima, Los_Angeles, Maceio, Managua,

Manaus, Martinique, Matamoros, Mazatlan, Menominee, Merida, Metlakatla,

Mexico_City, Miquelon, Moncton, Monterrey, Montevideo, Nassau,

New_York, Nipigon, Nome, Noronha, North_Dakota/Beulah, North_Dakota/

Center, North_Dakota/New_Salem, Ojinaga, Panama, Pangnirtung,

Paramaribo, Phoenix, Port-au-Prince, Port_of_Spain, Porto_Velho,

Puerto_Rico, Rainy_River, Rankin_Inlet, Recife, Regina, Resolute,

Rio_Branco, Santa_Isabel, Santarem, Santiago, Santo_Domingo, Sao_Paulo,

Scoresbysund, Sitka, St_Johns, Swift_Current, Tegucigalpa, Thule,

Thunder_Bay, Tijuana, Toronto, Vancouver, Whitehorse, Winnipeg, Yakutat,

Yellowknife.

The following values must be preceded with US/. For example, US/Alaska is

the value for the Alaska time zone:

Alaska, Aleutian, Arizona, Central, East-Indiana, Eastern, Hawaii, Indiana-

Starke, Michigan, Mountain, Pacic, Samoa.

Antarctica

The following values must be preceded with Antarctica/. For example,

Antarctica/Casey is the value for the Casey time zone.

9

TimeZone Parameter: Values 59

Option Values

Casey, Davis, DumontDUrville, Macquarie, Mawson, Palmer, Rothera,

Syowa, Troll, Vostok.

Asia

The following values must be preceded with Asia/. For example, Asia/

Amman is the value for the Amman time zone.

Almaty, Amman, Anadyr, Aqtau, Aqtobe, Ashgabat, Baghdad, Baku,

Bangkok, Beirut, Bishkek, Brunei, Chita, Choibalsan, Colombo, Damascus,

Dhaka, Dili, Dubai, Dushanbe, Gaza, Hebron, Ho_Chi_Minh, Hong_Kong,

Hovd, Irkutsk, Jakarta, Jayapura, Jerusalem, Kabul, Kamchatka, Karachi,

Kathmandu, Khandyga, Kolkata, Krasnoyarsk, Kuala_Lumpur, Kuching,

Macau, Magadan, Makassar, Manila, Nicosia, Novokuznetsk, Novosibirsk,

Omsk, Oral, Pontianak, Pyongyang, Qatar, Qyzylorda, Rangoon, Riyadh,

Sakhalin, Samarkand, Seoul, Shanghai, Singapore, Srednekolymsk, Taipei,

Tashkent, Tbilisi, Tehran, Thimphu, Tokyo, Ulaanbaatar, Urumqi, Ust-Nera,

Vladivostok, Yakutsk, Yekaterinburg, Yerevan.

Atlantic

The following values must be preceded with Atlantic/. For example,

Atlantic/Azores is the value for the Azores time zone.

Azores, Bermuda, Canary, Cape_Verde, Faroe, Madeira, Reykjavik,

South_Georgia, Stanley.

Australia

The following values must be preceded with Australia/. For example,

Australia/Adelaide is the value for the Adelaide time zone.

Adelaide, Brisbane, Broken_Hill, Currie, Darwin, Eucla, Hobart, Lindeman,

Lord_Howe, Melbourne, Perth, Sydney.

Europe

The following values must be preceded with Europe/. For example, Europe/

Amsterdam is the value for the Amsterdam time zone.

Amsterdam, Andorra, Athens, Belgrade, Berlin, Brussels, Bucharest,

Budapest, Chisinau, Copenhagen, Dublin, Gibraltar, Helsinki, Istanbul,

Kaliningrad, Kiev, Lisbon, London, Luxembourg, Madrid, Malta, Minsk,

Monaco, Moscow, Oslo, Paris, Prague, Riga, Rome, Samara, Simferopol,

Soa, Stockholm, Tallinn, Tirane, Uzhgorod, Vienna, Vilnius, Volgograd,

Warsaw, Zaporozhye, Zurich.

Indian

The following values must be preceded with Indian/. For example, Indian/

Christmas is the value for the Christmas time zone.

Chagos, Christmas, Cocos, Kerguelen, Mahe, Maldives, Mauritius, Reunion.

Pacic

The following values must be preceded with Pacic/. For example, Indian/

Apia is the value for the Apia time zone.

Apia, Auckland, Bougainville, Chatham, Chuuk, Easter, Efate, Enderbury,

Fakaofo, Fiji, Funafuti, Galapagos, Gambier, Guadalcanal, Guam, Honolulu,

Kiritimati, Kosrae, Kwajalein, Majuro, Marquesas, Nauru, Niue, Norfolk,

Noumea, Pago_Pago, Palau, Pitcairn, Pohnpei, Port_Moresby, Rarotonga,

Tahiti, Tarawa, Tongatapu, Wake, Wallis.

60 TimeZone Parameter: Values

TimeZone Parameter: Values 61

Keyboard.layouts Parameter: Values

The following table contains the values that you can use for the Keyboard.layouts parameter to designate the keyboard type.

Table 20. Keyboard.layouts Parameter: Values

Language Keyboard layout Values

Albanian (Albania) al

Albanian (Macedonia, Republic of) Arabic

(Algeria) Arabic ara

Albanian (Macedonia, Republic of) al

Arabic ara

Arabic (azerty) ara+azerty

Arabic (Algeria)

Arabic (Bharain)

Arabic (Egypt)

Arabic (India)

Arabic (Iraq)

Arabic (Jordan)

Arabic (Kuwait)

Arabic (Lebanon)

Arabic (Libya)

Arabic (Morocco)

Arabic (Oman)

Arabic (Qatar)

Arabic (Saudi Arabia)

Arabic (South Sudan)

Arabic (Sudan)

Arabic (Syrian Arab Republic )

Arabic (Tunisia)

Arabic (United Arab Emirates)

Arabic (Yemen)

Iraqi

Arabic

Iq

ara

10

62 Keyboard.layouts Parameter: Values

Language Keyboard layout Values

Austrian Austrian(Spain, with bottom-dotH and

bottom-dot l)

Iq

es+ast

es

Bangla bd

Bangla(India_ Baishakhi inscript) in+ben_inscript

Belarusian (Belarus) Bengali(Bangladesh) Bangla(India)

Bangla(India, Baishaki inscript)

Bangla(India Baishaki)

Bangla(India Bornona)

Bangla(India Probhat)

Bangla(India Uni Gitanjali)

by

bd

in+ben_inscript

in+ben_baishaki

in+ben_borana

in+ben_probhat

in+ben_gitanjali

Bengali(India) Bangla(India)

Bangla

Bangla(India, Baishaki inscript)

Bangla(India Baishaki)

Bangla(India Bornona)

Bangla(India Probhat)

in+ben

bd

in+ben_inscript

in+ben_baishaki

in+ben_borana

in+ben_probhat

Bulgarian Bulgarian

Bulgarian(traditional phonetic)

bg

Bg+phonetic

Catalan(Andorra) Catalan(Spain, with middle dot L) es+cat

Catalan(France) Catalan(Spain, with middle dot L) es+cat

Catalan(Italy) Catalan(Spain, with middle dot L) es+cat

Catalan(Spain) Catalan(Spain, with middle dot L) es+cat

Chinese(China) Pinyin cn

Chinese(Hong Kong) Pinyin cn

Chinese (Taiwan) Pinyin cn

Croatian hr

Czech cz

Keyboard.layouts Parameter: Values 63

Language Keyboard layout Values

Danish dk

Dutch(Aruba) Belgian

Dutch

be

nl

Dzongkha

English (Antigua and Barbuda)

English (Australia)

English-Cameroon Multilingual (qwerty)

English-Cameroon

English-Ghana

English-India, with Rupee Sign

English-Mail, US Macintosh

English -Mail, US international

English- Nigeria

English- South Africa

English- UK

English- US

Filipino

Irish

Serbo-Croatian(us)

bt

cm+qwerty

cm

gh

in+eng

mt+us-mac

ml+us-int

ng

za

gb

gb

ph

le

us+hbs

English (Belgium) English-Cameroon Multilingual (qwerty)

English-Cameroon

English-Ghana

English-India, with Rupee Sign

English-Mail, US Macintosh

English -Mail, US international

English- Nigeria

English- South Africa

English- UK

English- US

Filipino

Irish

gb

us+hbs

cm+qwerty

cm

gh

in+eng

mt+us-mac

ml+us-int

ngbza

gb

gb

ph

le

English (United States) English

English-Cameroon Multilingual (qwerty)

us

cm+qwerty

64 Keyboard.layouts Parameter: Values

Language Keyboard layout Values

English-Cameroon

English-Ghana

English-India, with Rupee Sign

English-Mail, US Macintosh

English -Mail, US international

English- Nigeria

English- South Africa

Filipino

Irish

Serbo-Croatian(us)

Spanish-Latin America

cm

gh

in+eng

mt+us-mac

ml+us-int

ng

za

ph

le

us+hbs

latam

Estonian ee

Finnish 

French (France) French-Alternative

French(

French- Belgian

French- English-International AltGR

Deadkey

French- Canada

French- Doemocratic Republic of the

Congo

French- Guinea

French- Mali, alternative

French- Morocco

French- Switzerland, Macintosh

French- Switzerland, Sun dead keys

French- Switzerland, Eliminate dead keys

fr+oss

fr

be

altgr+intl

ca

cd

gn

ml+fr-oss

ma+French

ch+fr_mac

ch+fr_sunddeadkeys

ch+fr_nodeadkeys

Galician Spanish Es

German (Germany) German

Belgian

English(International AltGr dead keys)

German- Austria

de

be

us+altgr-intl

at

ch

Keyboard.layouts Parameter: Values 65

Language Keyboard layout Values

German- Switzerland

Greek Greek (Modern 1453 Cyprus)

Greek (Modern 1453 Greece)

gr

Gujarati Hindi Hindi

Hindi(Bolnagari)

Hindi(Wx)

In+gu

In+hin

In+bolnagri

In+hin-wx

Hebrew Il

Hungarian hu

Icelandic Is

Iraqi ara

Irish Clogaelach Ie+Clogaelach

Italian Italian(Switzerland)

Italian(Italy)

it

it

Kannada Kannada

Kannada(KaGapPa phonetic)

in+kan

in+kan_kagaph

Kazakh Kazakh

Kazakh (with Russian)

Russian (Kazakhstan with Kazakh )

kz

kz+kazrus

rus+kaz

Korean Hangul ko

Latvian lv

Lithuanian lt

Macedonian mk

Marathi (KaGapPa phonetic) in+mar_kagaph

Malayalam(KaGapPa phonetic) in+mal_lalittha

Norwegian no

Punjabi(India)

Punjabi(Pakistan)

Punjabi(Gurmukhi Jhelum) in+jhelum

Pakistan Urdu pk

66 Keyboard.layouts Parameter: Values

Language Keyboard layout Values

Persian ir

Polish pl

Portuguese(Brazil) br

Portuguese Romanian Moldavian

Romanian (Germany)

Romanian (Germany- eliminate dead keys)

pt

md

de+ro

de+ro_nodeadkeys

Russia (Russian Federation) Russian

Russian-Georgia

Russian-Kazhagstan with Kazhag

Russian-Potland, phonetic Dvorak

Russian-Sweden, eliminate dead keys

Russian-US ponetic

Serebian-Russia

ru

ge+ru

kz+ruskaz

pl+ru_phonetic_dvorak

se+rus_nodeadkeys

us+rus

ru+srp

Russian(Ukraine) Russian

Russian-Georgia

Russian-Kazhagstan with Kazhag

Russian-Potland, phonetic Dvorak

Russian-Sweden, eliminate dead keys

Russian-US ponetic

Serebian-Russia

ru

ge+ru

kz+ruskaz

pl+ru_phonetic_dvorak

se+rus_nodeadkeys

us+rus

ru+srp

Serbian( Serbia) rs

Slovak sk

Slovenian si

Spanish (Spain) Spanish

Spanish-Latin America

es

latam

Spanish (Argentina)

Spanish (Bolivia)

Spanish (Chile)

Spanish (Colombia)

Spanish

Spanish(Latin America)

es

latam

Keyboard.layouts Parameter: Values 67

Language Keyboard layout Values

Spanish (Costa Rica)

Spanish (Cuba)

Spanish (Dominican Republic)

Spanish (Ecuador)

Spanish (El Salvador)

Spanish (Guatemala)

Spanish (Honduras)

Spanish (Mexico)

Spanish (Nicaragua)

Spanish (Panama)

Spanish (Paraguay)

Spanish (Peru)

panish (Puerto Rico)

Spanish (United States)

Spanish (Uruguay)

Spanish (Venezuela)

Swedish (Finland) se

Swedish(Sweden) se

Tamil (India) Tamil

Tamil(keyboard with numerals)

in+tam

in+tam_keyboard_with_numerals

Tamil (Sri Lanka) Tamil in+tam

Telugu Telugu

Telugu(Kagapa phonetic)

in+tel

in+tel-kagapa

Thai th

Turkish tr

Uighur cn+ug

Ukrainian un

Uyghur cn+ug

Uzbek uz

Uzbek(Latin) uz+latin

68 Keyboard.layouts Parameter: Values

Language Keyboard layout Values

Uzbek(Afghanistan) af+uz-olpc

Vietnamese vn

Yoruba ng+yoruba

Yakut ru+sah

Wolof sn

Keyboard.layouts Parameter: Values 69
