Dell Wyse Windows 10 IoT Enterprise for Wyse
5060 thin client
Administrator’s Guide
Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2018 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2017 - 05
Rev. A00
Contents
1 Introduction....................................................................................................................................................6
Dell Wyse technical support..............................................................................................................................................6
Dell Wyse online community............................................................................................................................................. 6
2 Getting started.............................................................................................................................................. 7
Logging On..........................................................................................................................................................................7
Automatic and manual login........................................................................................................................................ 7
Using Your Desktop............................................................................................................................................................8
Using the Start Menu..................................................................................................................................................9
Using the search box................................................................................................................................................... 9
Using Action Center................................................................................................................................................... 10
Grouping Applications into Desktops........................................................................................................................10
Before conguring your thin clients................................................................................................................................10
Working with Unied Write Filter utility................................................................................................................... 10
Brief introduction about NetXClean utility................................................................................................................11
Connecting to a printer or an external device................................................................................................................11
Connecting to monitor......................................................................................................................................................11
Power state........................................................................................................................................................................11
3 Accessible Applications................................................................................................................................ 12
Browsing the internet with Internet Explorer 11............................................................................................................ 12
Using the Dell Thin Client Application............................................................................................................................ 13
Conguring Citrix receiver session services..................................................................................................................14
Conguring remote desktop connection session services.......................................................................................... 15
Using VMware Horizon Client to connect to virtual desktop......................................................................................16
Conguring vWorkspace connection............................................................................................................................. 16
Conguring vWorkspace Farm..................................................................................................................................17
Using Ericom Connect and WebConnect client............................................................................................................18
Using Ericom PowerTerm Terminal Emulation...............................................................................................................19
C-A-D tool......................................................................................................................................................................... 19
Wyse Device Agent.......................................................................................................................................................... 19
Citrix HDX RealTime Media Engine................................................................................................................................ 19
Microsoft Lync VDI 2013 plug-in ...................................................................................................................................20
Adobe Flash Player.......................................................................................................................................................... 20
Windows Media Player....................................................................................................................................................20
Windows Defender Advanced Threat Protection........................................................................................................ 20
4 Admin specic features................................................................................................................................ 21
Using Administrative tools............................................................................................................................................... 21
Conguring component services..............................................................................................................................21
Managing the services.............................................................................................................................................. 22
Using TPM and BitLocker...............................................................................................................................................22
Conguring Bluetooth connections............................................................................................................................... 23
Contents 3
Conguring wireless local area network settings.........................................................................................................23
Using custom elds..........................................................................................................................................................24
Conguring the RAMDisk Size....................................................................................................................................... 24
Enabling auto logon......................................................................................................................................................... 25
System shortcuts.............................................................................................................................................................25
Viewing and conguring SCCM components.............................................................................................................. 26
System Center Conguration Manager Client LTSB 2016....................................................................................26
Devices and printers........................................................................................................................................................ 26
Adding printers........................................................................................................................................................... 26
Adding devices............................................................................................................................................................27
Conguring dual monitor display.................................................................................................................................... 27
Managing audio and audio devices................................................................................................................................ 27
Using sound dialog box..............................................................................................................................................27
Using the Realtek HD audio manager......................................................................................................................28
Setting region................................................................................................................................................................... 28
Managing user accounts.................................................................................................................................................28
Using Windows Defender............................................................................................................................................... 29
5 Additional administrator utility and settings information.............................................................................. 30
Automatically launched utilities...................................................................................................................................... 30
Utilities aected by log o, restart, and shut down.................................................................................................... 30
Unied Write Filter............................................................................................................................................................31
Running Unied Write Filter command–line options................................................................................................... 32
Enabling and disabling the Write Filter using the desktop icons................................................................................ 33
Setting Write Filter controls............................................................................................................................................33
NetXClean utility.............................................................................................................................................................. 34
Saving les and using local drives..................................................................................................................................35
Mapping network drives................................................................................................................................................. 35
Participating in domains.................................................................................................................................................. 36
Using the Net and Tracert utilities................................................................................................................................. 37
Managing Users and Groups with User Accounts....................................................................................................... 37
Creating user accounts..............................................................................................................................................37
Editing user accounts................................................................................................................................................38
Conguring user proles........................................................................................................................................... 38
Changing the computer name of a thin client..............................................................................................................38
6 System Administration.................................................................................................................................39
Accessing thin client BIOS settings...............................................................................................................................39
Accessing thin client boot menu.................................................................................................................................... 39
Restoring BIOS default settings.....................................................................................................................................39
Unied Extensible Firmware Interface (UEFI) and secure boot.................................................................................39
Booting from a DOS USB key ................................................................................................................................. 40
Booting from a UEFI USB key.................................................................................................................................. 40
Creating a Boot disk UEFI USB key ........................................................................................................................40
WDM software for remote administration....................................................................................................................40
Conguring and using peripherals...................................................................................................................................41
TightVNC—server and viewer....................................................................................................................................... 41
4Contents
TightVNC—Pre-requisites.............................................................................................................................................. 41
Using TightVNC to shadow a thin client ......................................................................................................................42
Conguring TightVNC server properties on the thin client .......................................................................................42
7 Network architecture and server environment............................................................................................. 44
Understanding how to congure your network services............................................................................................ 44
Using Dynamic Host Conguration Protocol................................................................................................................ 44
DHCP options...................................................................................................................................................................45
Using Domain Name System.......................................................................................................................................... 46
About Citrix Studio.......................................................................................................................................................... 46
About VMware Horizon View Manager........................................................................................................................ 46
Contents 5
Introduction
Dell Wyse thin clients running Microsoft Windows 10 IoT Enterprise provide access to applications, les, and network resources. It is made
available on machines hosting Citrix Receiver, Microsoft Remote Desktop Connection, the VMware Horizon client session and Dell Wyse
vWorkspace services. Other locally installed software permits remote administration of the thin clients and provides local maintenance
functions. More add-ons are available that support a wide range of specialty peripherals and features for environments needing a secure
Windows user interface with 64-bit Windows compatibility. Your thin client device supports Microsoft Silverlight, Microsoft Lync VDI 2013
plug-in, and Microsoft .Net Framework 4.6 or later versions. For more information, see www.microsoft.com.
Session and networks services available and accessed on enterprise networks, a direct intranet connection or from a remote location using
a secure gateway from Citrix, Microsoft, VMware, or Dell Wyse vWorkspace.
Dell Wyse technical support
To access technical resources self-service portal, knowledge base, software downloads, registration, warranty extensions/ RMAs, reference
manuals, and so on, visit dell.support.com. For Customer Support, visit www.dell.com/support/contents/us/en/19/article/Contact-
Information/International-Support-Services/international-contact-center?ref=contactus , and phone numbers for Basic and Pro Support
are available at www.dell.com/supportcontacts .
NOTE: Before proceeding, verify if your product has a Dell service tag. For Dell service tagged products, go to www.dell.com/
support/contents/us/en/19/article/Product-Support/Dell-Subsidiaries/wyse.
Dell Wyse online community
Dell Wyse maintains an online community where users of our products can seek and exchange information about user forums. Visit the Dell
Wyse online community forums at: en.community.dell.com/techcenter/enterprise-client/wyse_general_forum/.
1
6 Introduction
Getting started
This section describes the activities that you can perform to start using your thin client device. You can also nd information related to the
available desktop features. When you boot your thin client device for the rst time, the user desktop is displayed by default. You can log in
to the thin client device as a user or an administrator. An administrator can congure a user account to log on automatically or manually by
entering the login credentials.
To get started using your thin client device, see:
Automatic and manual Logon
Before conguring your thin clients
Using the Start Menu
Using the Search Box
Using Action Center
Grouping applications into desktops
Connecting to a printer or an external device
Power state
Logging On
Whatever we view during the turn on or during the reboot of thin client device depends on the administrators conguration. After creating
user account, an administrator can congure a user account to log on automatically or require manual logon with user credentials.
For more information, see Managing Users and Groups with User Accounts.
NOTE:
Be sure to disable the Unied Write Filter (UWF) before you change a password on the thin client, and then enable the UWF after
your change. For more information, see Before conguring your thin clients.
To change the password, hold CTRL+ALT+DEL key combination, and then click Change a password. However, this feature is not
applicable for User accounts.
Automatic and manual login
What you see when a thin client turns on or reboots depends on the administrator’s conguration. After creating a user account, an
administrator can congure the account to log in automatically or manually with user credentials.
For more information, see Managing Users and Groups with User Accounts.
NOTE:
Ensure that you disable the Unied Write Filter (UWF) before you change a password on the thin client, and then enable UWF after
your change. For more information, see Before conguring your thin clients.
To change the password, press Ctrl+Alt+Delete, and then click Change a password. However, this feature is not applicable for
User accounts.
When you start the thin client, you will automatically log in to the user desktop by default.
2
Getting started 7
NOTE: The Windows icon on the taskbar is the start menu button.
To log in as a dierent user or administrator:
1 Go to Start > User icon > Sign Out to log out from the current desktop.
2 Click anywhere on the lock screen to view the login window.
3 You can view the user accounts list on the screen. Click the preferred user account and then enter the login credentials.
AdministratorsThe default user name is Admin and the default case-sensitive password is DellCCCvdi.
UsersThe default user name is User and default case-sensitive password is DellCCCvdi.
Customized User—Log in to your thin client by entering the user credentials which you have set for the customized user
account.
If automatic login is not enabled, the login window displays when you boot the thin client device. You can log in using the options mentioned
in step 2 and step 3.
Using Your Desktop
Based on admin congurations, you are able to view the thin client desktop after logging on.
The Thin Client Admin Desktop typically consists of the following:
Admin Taskbar — It includes,
The Start Menu button
The Search box
Quick Launch Bar icons
Task View
Notication area in the extreme right of the taskbar
NOTE: On the extreme right of the task bar, click the New notications icon to open the Action Center window. For more
information about the Action Center, see Using Action Center.
Standard Desktop Icons — It includes
Citrix Receiver
Dell Thin Client Application
Ericom Connect WebConnect Client
Internet Explorer
PowerTerm Terminal Emulation
Remote Desktop Connection
VMware Horizon Client
• vWorkspace
Dell Wyse WF Disable
Dell Wyse WF Enable
In addition to the Standard Desktop Icons, an extended set of resources for conguring user preference settings and system administration
is included in the administrator Control Panel. To open Control Panel, click Start Menu > Control Panel. For more information, see Admin
Specic Features.
8Getting started
Using the Start Menu
The Start Menu helps you to access all programs, folders, and settings on your thin client. It contains a list of applications that are installed
on your thin client. To open the Start Menu, do the following:
1 Log in as an administrator.
2 Click the Start Menu button.
NOTE: You can also open the Start Menu by pressing the Windows logo key on your keyboard.
3 From the Start Menu, you can use the following options to navigate through the available applications or congure the settings:
Settings—Use this option to open the Settings window, and congure common Windows settings. The available settings are:
SystemTo congure the display, notications, applications, and power settings
DevicesTo congure the bluetooth, printer, camera, and other peripheral settings
Network and InternetTo congure the Wi-Fi, airplane mode, Ethernet, and VPN settings
PersonalizationTo congure the background, lock screen, and colors settings
AccountsTo congure your account settings
Time and LanguageTo congure the speech, region, and date settings
Ease of AccessTo congure the narrator, magnier, and high contrast settings
PrivacyTo congure the location and camera settings
Update and SecurityTo congure the Windows update settings
PowerYou can sleep, restart, or turn o your thin client. For more information, see Power State.
List of applications—Click the Start Menu button to view full list of your applications and programs.
NOTE: On the Start Menu, you can view the list of frequently used applications under Most Used.
Using the search box
Use the search box on the taskbar to look for applications, les, or settings.
To use the search box:
1 Type what you are searching for in the search box on the taskbar.
You can nd results for les, applications, or settings across your thin client. The suggestions and results related to your searched item
are displayed in the Home window.
2 Click the result to open the application or le you searched for.
NOTE: To search for a particular le on your thin client, apply any of the following lters available in the lower pane of the Home
window, and then search for your desired le:
Applications lter
Settings lter
Documents lter
Folders lter
Photos lter
Videos lter
Musics lter
Getting started 9
Using Action Center
Action center displays important notications from Windows and your applications on the taskbar, along with quick actions, which get you
to your most-used settings and applications instantly.
To view your notications and quick actions, click the Action Center icon on the taskbar. You can also press Windows logo key+A.
Notications at a glanceWhen a notication appears on your desktop or when you view it in Action Center, expand it to read more
or take action without having to open the related application. You can also clear the notication by selecting and dragging it o the
screen to the right, or by clicking the Close button.
Quick Action icons—Quick Action icons allow you to access All Settings and applications that you use often, such as Bluetooth to
VPN. Select the Expand option to see the settings and applications such as location, the quiet hours, brightness, bluetooth, VPN, the
battery saver, project, and connect.
The following are the Quick Action options in the Action Center:
Tablet ModeTablet mode makes Windows easier and more intuitive to use with touch on devices such as 2–in–1s, or when you
do not want to use a keyboard and mouse. To turn on tablet mode, click the Action Center icon on the taskbar, and then select
Tablet Mode.
Connect—Use this option to connect to your wireless and bluetooth devices.
All Settings—Use this option to congure windows settings. For more information, see Using the Start Menu.
Airplane mode—Use this option to turn o the wireless transmission functions on your device and enable Airplane mode.
Grouping Applications into Desktops
Create virtual desktops, to group your applications together. In the taskbar, click the Task View icon, and then in the New Desktop, open
the applications you need.
To move applications between virtual desktops, click Task View, and then drag the application you want from one desktop to another.
Before conguring your thin clients
Unied Write Filter Utility and NetXClean Utility are meant to protect your thin clients. If you want to retain certain prole congurations
such as printers, monitors and other peripherals, you can congure NetXClean to refrain from cleaning up explicitly declared proles. These
utilities also prevent undesired ash memory writes, and clean-up extraneous information from being stored on the local disk.
However, there are instances where administrators can retain the changed congurations after you log out and restart the thin client.
NOTE: To congure and manage multiple thin clients, see Dell Cloud Client Computing.
Working with Unied Write Filter utility
Unied Write Filter (UWF) is a sector-based write lter that you must use to protect your storage media. UWF intercepts all write attempts
to a protected volume and redirects those write attempts to a virtual overlay.
WARNING: Failure to keep the Write Filter turned on (except for regular maintenance or Application/Driver installs or upgrades)
will prematurely wear out your Flash/ SSD storage and invalidate your warranty.
For more information about UWF, browse Unied Write Filter on www.microsoft.com.
The Dell Wyse Write Filter (WF) guidelines are given below:
1 Log in as an administrator.
If automatic logon to a user desktop is enabled, log o from the user desktop and log in as an administrator.
2 To disable the Unied Write Filter, double-click the Dell Wyse WF Disable icon on the desktop.
10 Getting started
This icon disables the lter and reboots the system.
3 Congure the thin client device as per your requirements.
4 After you congure the thin client device, to enable the Unied Write Filter, double-click the Dell Wyse WF Enable icon on the
desktop.
This icon enables the lter and reboots the system. Your congurations on the thin client device are now saved, and they will persist
after a thin client device reboot.
For more information, see Using the Unied Write Filter (UWF).
Brief introduction about NetXClean utility
NetXClean is a clean-up utility that runs in the background and removes extraneous information from the RAM drive before it can be
ushed to local storage. If you want to retain certain prole congurations such as printers, monitors and other peripherals, be sure to
congure NetXClean in order to refrain from cleaning up explicitly declared proles.
For more information, see Understanding the NetXClean utility.
Connecting to a printer or an external device
You can connect USB interfaced printers or a USB-to-parallel adapter interfaced printer to your thin client device using a USB port. Follow
your printer's USB installation instructions before connecting to a USB port.
To connect to the printer, add the printer to the thin client device by using the Add Printer wizard. For more information, see Adding
printers.
If you want to connect to an external device, add the device to the thin client device. For more information, see Adding devices.
Connecting to monitor
Depending on your thin client device model, with proper monitor cables, splitters, or adapters you can connect to a monitor using the
following:
A Display(digital) port
For more information on conguring a dual monitor display, see Conguring Dual Monitor Display.
NOTE: You can calibrate and customize the settings for a touch screen monitor connected to, or integrated with the thin client.
Each touch screen can have its own requirements for drivers such as Microsoft touch drivers.
Power state
You can change the power state options of the thin client device by following the steps mentioned here:
1 On the taskbar, click the Start Menu button.
2 Click Power on the start menu, and select any of the options:
SleepThis mode uses little power, your thin client device starts up faster.
Shut down—Preferred for closing all your open programs, and to shut down your operating system.
RestartThe thin client device is turned o and turned on instantly.
To use the power state options press ALT+F4, and then select your preferred option from the drop-down list.
NOTE: If automatic login is enabled, the thin client immediately logs in to the default user desktop.
Getting started 11
Accessible Applications
When you log in to your thin client as an Administrator or a User, the Windows desktop displays certain notable extended features in the
Start menu.
You can perform the following activities:
To browse the Internet, use Internet Explorer, see Browsing the Internet with Internet Explorer.
View client information, see Using the Dell Thin Client Application.
Congure Citrix Receiver session services, see Conguring Citrix Receiver Session Services.
Congure remote desktop connections, see Conguring Remote Desktop Connection Session Services.
Conguring the VMware Horizon Client, see Using VMware Horizon Client to connect to a Virtual Desktop.
Use Ericom–Powerterm Terminal Emulation, see Using Ericom PowerTerm Terminal Emulation.
Use Ericom Connect-WebConnect Client, see Using Ericom Connect-WebConnect Client.
Congure vWorkspace connections, see Conguring a vWorkspace Connection.
CAD tool, see CAD tool.
Wyse Device Agent (WDA), see Wyse Device Agent.
Citrix HDX RealTime media engine, see Citrix HDX RealTime media engine.
Microsoft Lync Vdi 2013 plug-in, see Microsoft Lync Vdi 2013 plug-in.
Adobe ash player, see Adobe ash player.
Windows media player, see Windows media player
Windows defender Advanced Threat Protection (ATP), see Windows defender Advanced Threat Protection (ATP)
NOTE: Keyboard Caps Lock Indicator Application — Dell Keyboard driver software (KM632) is included in this release. This
software provides Caps Lock status indication on the desktop. After you log in to your thin client, when you press the Caps Lock
key to enable the Caps Lock feature, the lock symbol is displayed on the desktop. Again, if you press the Caps Lock key to
disable the Caps Lock feature, the unlock symbol is displayed on the desktop.
Browsing the internet with Internet Explorer 11
To open Internet Explorer 11, do either of the following:
Go to Start > Windows Accessories > Internet Explorer.
Double-click the Internet Explorer icon on the desktop.
NOTE:
To limit writing to the disk, Internet Explorer settings are set at the factory. These settings prevent the usage of limited amount of
disk space available, and you should not modify these settings.
The protected mode status of the Internet Explorer is O as the User Access Control (UAC) is enabled by default. However, UAC
noties that you require administrator-level permission before changes are made to your client. The Unied Write Filter (UWF) in
the build continues to protect your system. For more information, see Before conguring your thin clients.
Internet Explorer cache settings are 100 MB. Temporary internet les, cache, history locations are set to drive C instead of drive Z
to support Internet Explorer 11 completely.
3
12 Accessible Applications
Using the Dell Thin Client Application
Use the Dell Thin Client Application to view the general information about the thin client device, Custom elds, RAM Disk, Auto Logon,
System Shortcuts, and Support information.
To access the Dell Thin Client Application page:
On the Admin/User desktop, click Start menu > Dell Thin Client Application to open the page. You can also access the Dell Thin Client
Application by clicking the Dell Thin Client Application icon on the desktop.
In the left navigation bar, click the following tabs:
Client Information— Displays the following thin client device information.
Under the Product Info category, the following attributes are listed:
Product Name
Product ID
Model Name
Product Version
Windows Embedded Version
• Manufacturer
Hardware Rev
OS Name
Serial Number
• Website
Localized Language
Product Activation Status
Under the CPU category, the following attributes are listed:
• Name
• Speed
Address Width
Data Width
Under the Memory/Storage category, the following attributes are listed:
RAM Memory
• Flash
System Partition
Under the BIOS category, the following attributes are listed:
• Version
• Manufacturer
Under the Network category, the following attribute is listed:
MAC (IP Address)
Under the User category, the following attributes are listed:
• User
Accessible Applications 13
• Domain
QFE— Displays the list of Microsoft QFEs (previously known as hot xes) applied to the thin client device.
Installed Products — Displays the list of applications that are installed on the thin client device.
WDM Packages — Displays the list of WDM Packages that have been applied to the thin client. For more information, see WDM
software for Remote Administration .
Copyrights/Patents — Displays copyrights and patents information.
When logged in as an administrator, you can view the tabs such as Custom Fields, RAM disk, Auto Logon, System Shortcuts, and About
and Support on the Dell Thin Client Application page. For more information about using these options, see Admin Specic Features. In the
About and Support tab, you can view the information related to the Application Version, Support Directory, Export support data and HTML
view.
NOTE: The information shown in the dialog box varies for dierent thin client devices and software releases.
When you log in as a user, only few tabs such as Client Information, QFE, Installed Products, WDM Packages, Copyrights/Patents
and About and Support are displayed.
Conguring Citrix receiver session services
Citrix Receiver is a server-based computing technology that separates the logic of an application from its user interface. The Citrix
Receiver client software installed on the thin client device allows you to interact with the application GUI, while all the application processes
run on the server.
Citrix Receiver session services are available on the network using Windows Server 2008 or Windows Server 2012 with Terminal Services
and one of the following installed:
XenDesktop 7.5
XenDesktop 7.6
XenDesktop 7.8
XenDesktop 7.9
XenDesktop 7.11
NOTE:
If you use a Windows Server 2003, Windows Server 2008, or Citrix XenApp 5.0 with Windows Server 2008, a Terminal Services Client
Access License (TSCAL) server must also be accessible on the network. The server grants a temporary license, which expires after
120 days. After the temporary license expires, purchase and install the TSCALs on the server. You cannot establish a connection
without a temporary or permanent license.
To congure a Citrix Receiver session, do the following:
1 Log in as an administrator.
2 Access the Citrix Server using one of the following options:
From the Start Menu, click Citrix Receiver.
Double-click the Citrix Receiver icon on the desktop.
After you log in to the Citrix server, the Add Account window is displayed.
3 In the Add Account window, enter the server IP address.
4 Click Next.
For secure connections, enter Fully Qualified Domain Name (FQDN).
For non-secure connections, enter the IP address.
5 Enter the user credentials, and click Log on.
You can add an account by providing the IP address, and you can view the details of the Citrix Receiver.
6 Click Yes, and then click Next.
The virtual desktop of the Citrix receiver is displayed.
14 Accessible Applications
7 In the virtual desktop window, go to Add Apps (+) > All Applications.
You can select or clear the application check box. The selected applications are displayed on the virtual desktop.
8 On the virtual desktop, click Settings to refresh, add or delete server account, and log o.
Conguring remote desktop connection session
services
Remote desktop connection is a network protocol that provides a graphical interface to connect another computer over a network
connection.
NOTE: If you use a Windows Server 2003, Windows Server 2008, or Citrix XenApp 5.0 with Windows Server 2008, a Terminal
Services Client Access License (TSCAL) server must also be accessible on the network. The server grants a temporary license,
which expires after 120 days. After the temporary license expires, purchase and install the TSCALs on the server. You cannot
establish a connection without a temporary or permanent license.
To congure a remote desktop connection:
1 Log in as a user or an administrator.
2 From the Start menu, click Remote Desktop Connection, or double-click the Remote Desktop Connection icon on the desktop.
The Remote Desktop Connection window is displayed.
3 In the Computer box, enter the computer or the domain name.
4 For advanced conguration options, click Show Options.
a In the General tab, you can enter the login credentials, edit or open an existing RDP connection, or save a new RDP connection
le.
b In the Display tab, manage the display and the color quality of your remote desktop.
Move the slider to increase or decrease the size of your remote desktop. To use full screen, move the slider all the way to the
right.
Select the color quality of your preference for your remote desktop from the drop-down list.
Select or clear the Display the connection bar when I use the full screen check box to display or hide the connection bar in
full screen mode.
c In the Local Resources tab congure audio, keyboard, or local devices and resources for your remote desktop.
In the Remote audio section, click Settings for advanced audio settings options.
In the Keyboard section, choose when and where to apply keyboard combinations.
In the Local devices and resources section, select devices and resources that you want to use in your remote session. Click
More for more options.
d In the Experience tab optimize the performance of your remote session based on the connection quality.
NOTE:
If the Unied Write Filter cache is full, you can disable the Bitmap caching in the Experience tab after clicking Show Options
in the window.
e In the Advanced tab, select the action to be taken when the server authentication fails and congure settings for connection
through Remote Gateway.
5 Click Connect.
6 To connect to the remote session, enter the login credentials in the Security dialog box.
The remote desktop is displayed with the connection bar on the top if you select the Display the connection bar.
Accessible Applications 15
Using VMware Horizon Client to connect to virtual
desktop
VMware Horizon Client is a locally installed software application that communicates between View Connection Server and thin client
operating system. It provides access to centrally hosted virtual desktops from your thin clients.
VMware session services can be made available on the network after you install the VMware Horizon 6. It provides virtualized or hosted
desktops and applications through a single platform to end users.
To connect to a virtual desktop, use the VMware Horizon Client window.
To open and use the VMware Horizon Client window:
1 Log in as a user or an administrator.
2 Access the VMware Horizon Client window using one of the following options:
From the Start Menu, click VMware > VMware Horizon Client.
Double-click the VMware Horizon Client icon on the desktop.
The VMware Horizon Client window is displayed.
3 In the VMware Horizon Client window, use the following guidelines:
a To add a new server connection, either click the New Server option or double-click the Add Server icon in the VMware Horizon
Client window.
The VMware Horizon Client dialog box is displayed.
b In the VMware Horizon Client dialog box, type a host name or an IP address of a VMware Horizon Connection Server in the
connection server box.
c Click Connect.
d In the Login dialog box, enter the user name and login password in the respective boxes.
e From the Domain drop-down list, select the domain where the server is located.
f Click Login.
The VMware Horizon Client connects to the selected desktop. After connection is established, the list of published desktops is
displayed.
g Right-click the particular application or the desktop icon, and then click Launch to connect to that application or desktop.
For more information on VMware Horizon Client, see www.vmware.com.
NOTE:
Certicate checking mode—Certicate checking mode determines how the client proceeds when the client cannot verify that
your connection to the server is secure. Dell recommends that you do not change this setting unless instructed by your system
administrator.
To access the certicate checking mode, click the icon on the upper-right corner of the window, and then click Congure SSL
from the drop-down list. In the VMware Horizon Client SSL conguration dialog box, select from any of the following options
based on your requirements:
Never connect to untrusted servers
Warn before connecting to untrusted servers
Do not verify server identify certicates
Conguring vWorkspace connection
vWorkspace is a concept in which the desktop environment of a computer is separated from the physical computer and hosted as a virtual
workspace on multiple environments, such as a virtual desktop infrastructure (VDI), terminal servers, and/or blade PCs running in a data
center.
Workspace virtualization helps group and deliver a list of applications or desktops together as a single complete virtual workspace. It
isolates and centralizes an entire computing workspace. vWorkspace provides exible, location, and platform independent access by
delivering virtual workspace from multiple virtualization platforms.
16 Accessible Applications
To congure a vWorkspace connection:
1 Log in as a user or an administrator.
2 Go to Start > Dell Wyse vWorkspace, or double-click the vWorkspace icon on the desktop.
The vWorkspace window is displayed.
3 In the vWorkspace window, enter the vWorkspace server IP, or your registered email address or website address.
4 Press Enter.
5 To retrieve your connector conguration from vWorkspace server, provide the username, password, and the domain credentials.
6 Select the Save Credentials (encrypted) check box if you want to save your login credentials.
7 Select your preferred vWorkspace farm location from the following options:
Inside Oce
Outside Oce
8 Click Connect.
9 To connect to the vWorkspace farm, enter the following credentials in the Login Credentials dialog box:
• Username
• Password
• Domain
The vWorkspace Farm screen is displayed.
For more information about managing your vWorkspace connection, go to support.quest.com.
Conguring vWorkspace Farm
After you log in to the vWorkspace Farm by using the login credentials, the vWorkspace Farm page is displayed. Use this page to congure
the vWorkspace Farm.
1 Click vWorkspace Farm to view the conguration options available.
If you are successfully connected to the vWorkspace Farm, then the status of the connection is displayed in green color.
2 Click the Settings icon to congure your vWorkspace Farm settings.
a Select the Automatically connect to this conguration on startup check box to allow auto-connect to the specied
conguration upon startup.
b From the drop-down list, select your location where you want to deploy the vWorkspace Farm. The available options are:
Always prompt for location
Use Location Inside Oce
Use Location Outside Oce
c Under the Display settings section, the following options can be congured.
From the Screen resolution drop-down list, select your preferred screen resolution for your vWorkspace session.
Select the following check boxes as per your requirements:
Use all my monitors for the remote session
Display connection bar
Pin connection bar
d Under the Device settings section, the following options can be congured.
Select the following check boxes as per your requirements:
Play audio
Use USB devices
Use microphone
Click More Devices to select additional devices and resources on your computer that you want to use in your remote
session.
3 Click OK to save your settings.
Accessible Applications 17
4 Click the Delete icon, if you want to delete the congured vWorkspace Farm.
5 Click the Info icon to view the Name, Type, and Timestamp of your vWorkspace Farm.
The applications available on your vWorkspace Farm are listed in the My Applications area.
Additional conguration icons are displayed in the upper pane of the vWorkspace page.
1 Click the Log O icon, if you want to log out from the vWorkspace Farm.
2 Click the + icon to add a new vWorkspace Farm.
3 Click the Refresh icon to refresh the application set.
4 Click the Change Password icon, if you want to change the password for your vWorkspace Farm.
5 Click the Options icon to access the following options:
Search (Ctrl+F)
Status Bar
Always on top
Hide when minimized
• About
Using Ericom Connect and WebConnect client
Ericom Connect and WebConnect client provides you with remote access to Windows desktops and applications from any compatible
phone or tablet. It is dedicated for managed broker access. Ericom Connect and PowerTerm WebConnect connections use the Secure
Gateway as the address. You can access the Ericom Connect-WebConnect client either as a stand-alone application or on a network.
To access the Ericom Connect and WebConnect client as a stand-alone application:
1 Log in as a user or an administrator.
2 Go to Start > Ericom Connect-WebConnect client > Ericom Connect-WebConnect client or double-click the Ericom Connect-
WebConnect client icon on the desktop.
The Ericom AccessPad login window is displayed.
3 In the Ericom AccessPad login window, enter your credentials, and click Login.
The DELL – Ericom Application Zone window is displayed.
NOTE: By default, the Ericom AccessPad login window is displayed. To set the UI to your preferred language, click the
Globe icon in the lower-right corner of the window, and select your preferred language from the drop-down list.
4 In the DELL – Ericom Application Zone window, published applications such as the Blaze demo server, RDP demo server, the
Ericom server, and Paint are displayed.
Double-click any of the applications to access them.
You can also add your own applications from the server site.
5 To create a shortcut on your desktop, click Options > Create a shortcut on Desktop in the DELL – Ericom Application Zone window.
6 To log out, click File > Logout in the DELL- Ericom Application Zone window.
To access the Ericom Connect-WebConnect client through the web browser:
1 Double-click the Internet Explorer icon.
The Internet Explorer web page is displayed.
2 Enter http://serverIP/FQDNWebConnect6.0/AppPortal/Index.asp URL to access the Ericom Power Term Emulation.
The PowerTerm WebConnect Application Portal page is displayed.
3 In the PowerTerm WebConnect Application Portal page, enter the credentials and the domain name.
4 Click Login.
5 After you log in, the published desktops and applications such as the Blaze demo server, RDP demo server, and Paint are displayed.
Double-click any of the applications to access them on a new web page.
18 Accessible Applications
You can also add your own applications from the server sit.
6 Click Logout on the left side of the PowerTerm WebConnect Application Portal page to end the Ericom Power Term WebConnect
session.
Using Ericom PowerTerm Terminal Emulation
To manage your connections using Ericom PowerTerm Terminal Emulation, do the following:
1 Open the TELNET : PowerTerm InterConnect for thin clients window, using one of the following options mentioned:
Double-click the PowerTerm Terminal Emulation icon on the desktop.
From the Start Menu, click Ericom PowerTerm Terminal Emulation > PowerTerm Terminal Emulation.
2 In the Connect dialog box, go to Session Type > TELNET to congure the connection of your choice.
For more information, see Ericom-PowerTerm documentation at Dell Wyse Support Site.
C-A-D tool
The C-A-D tool allows administrators to map the Ctrl+Alt+Del key combination of VDI applications to display the Ctrl+Alt+Del screen of the
VDI application. If the C-A-D tool is enabled, you can use Ctrl+Alt+Del key combination for all VDI applications.
The following are the mapped keys for dierent VDI applications supported by C-A-D tool:
• Citrix—Ctrl+F1
Dell vWorkspace—Ctrl+Alt+End
• RDP—Ctrl+Alt+End
NOTE: The C-A-D tool does not work for Xen Desktop in a Citrix session, but works only for the Citrix Xen applications.
The C-A-D tool is disabled by default in this build. To enable the C-A-D tool, do the following:
1 Log in as an administrator.
2 Disable the Write Filter.
3 Launch Command Prompt in elevated mode.
4 Enter cd c:\windows\system32
5 Run DWKBFilterMon.exe and, reboot.
6 Enable the Write Filter.
Wyse Device Agent
Wyse Device Agent (WDA) is a unied agent for all thin client management solutions. Installing WDA on a thin client makes it manageable
by Dell Wyse Device Manager (WDM), and Dell Cloud Client Manager (CCM). For more information, see the latest Dell Wyse Device Agent
Release Notes at support.dell.com/manuals.
Citrix HDX RealTime Media Engine
Citrix HDX RealTime Optimization Pack for Microsoft Lync provides highly scalable solution for delivering real-time audio-video
conferencing and the VoIP enterprise telephony through Microsoft Lync in the XenDesktop and XenApp environments to users on Linux,
Mac, and the Windows devices. HDX RealTime Optimization Pack applies your existing Microsoft Lync infrastructure and inter operates
with other Microsoft Lync endpoints running natively on devices.
For more information, see Citrix documentation.
Accessible Applications 19
Microsoft Lync VDI 2013 plug-in
Microsoft Lync VDI 2013 plug-in enables you to experience audio, and video in peer-to-peer calls and conference calls, when using
Microsoft Lync 2013 in a Virtual Desktop Infrastructure (VDI) environment.
For more information, see www.technet.microsoft.com/en-us/library/jj204683.aspx.
Adobe Flash Player
Adobe Flash Player is the standard for delivering high-impact, and rich web content. The designs, animation, and application user interfaces
are deployed immediately across all the browsers, and platforms to ensure a rich web experience.
For more information, go to www.adobe.com/software/ash/about/.
Windows Media Player
Windows Media Player provides an intuitive, and easy-to-use interface to play digital media les. It organizes your digital media collection,
and you can burn CDs of your favorite music, extract music from CDs, sync digital media les to a portable device, and shop for digital
media content from online stores. For more information, see Windows media player documentation at support.microsoft.com/.
Windows Defender Advanced Threat Protection
Windows Defender Advanced Threat Protection (ATP) is a new service that helps enterprises to detect, investigate, and respond to
advanced attacks on their networks.
Windows Defender ATP works with existing Windows security technologies on endpoints, such as Windows Defender, AppLocker, and
Device Guard. It also works with third-party security solutions, and anti-malware products. For more information, see the Windows
Defender Advanced Threat Protection documentation at docs.microsoft.com
20 Accessible Applications
Admin specic features
Admin is a default user prole created for the user who is a member of the Administrator group.
To log in as an Admin, see Automatic and Manual Logon. When you log in to your thin client device as an Admin, you can access certain
notable extended features in the Control Panel.
To access Control Panel, on the taskbar, click Start Menu > Control Panel.
You can perform the following functions as an Admin:
Use the Administrative Tools. See Using the Administrative Tools.
Use the BitLocker Drive Encryption. See Using TPM and BitLocker.
Use custom elds. See Using Custom Fields.
Congure the RAM Disk size. See Conguring RAMDisk Size.
Enabling Auto Logon. See Enabling Auto Logon.
Accessing System Shortcuts. See Using System Shortcuts.
View and congure SCCM components. See Viewing and conguring SCCM components.
Add Devices and Printers. See Adding Devices and Adding Printers.
Congure Dual Monitor Display. See Conguring Dual Monitor Display.
Manage audio and audio devices. See Using the Sound Dialog Box and Using the Realtek HD Audio Manager
Select language preferences. See Setting Region and Language preferences.
Manage User Accounts. See Managing Users and Groups with User Accounts.
Scan and protect your computer against spyware and malware. See Using Windows Defender.
Using Administrative tools
To access the Administrative Tools window, click Start > Control Panel > Administrative Tools.
You can use the Administrative tools window to perform the following tasks:
Conguring the component services
Managing the services
Conguring component services
To access and congure the component services, event viewer, and local services use the Component Services console.
1 Log in as an administrator.
2 Go to Start > Control Panel > Administrative Tools.
3 From the Administrative Tools list, select Component Services.
4 In the Component Services console, select component services, event viewer, and local services from the Console Root tree and
congure.
4
Admin specic features 21
Managing the services
To view and manage the services installed on the thin client device, use the Services window. To open the Services window, go to Start >
Control Panel > Administrative Tool Services.
1 In the Component Services console, click the Services icon from the console tree.
The list of services is displayed.
2 Right-click the service of your choice. You can perform Start, Stop, Pause, Resume, and Restart operations.
You can select the Startup type from the drop-down list:
Automatic (Delayed Start)
• Automatic
• Manual
• Disabled
NOTE: Ensure that the Write Filter is disabled while managing the services.
Using TPM and BitLocker
A TPM is a microchip designed to provide basic security-related functions, primarily involving encryption keys. BitLocker Drive Encryption
(BDE) is a full disk encryption feature which is designed to protect data by providing encryption for entire volumes. By default, it uses the
AES encryption algorithm in CBC mode with a 128 bit key, combined with the Elephant diuser for additional disk encryption-specic
security not provided by AES.
Windows 10 IoT Enterprise does not support sysprep on a BitLocker encrypted device. Due to this limitation, you cannot encrypt the
device, perform a sysprep, and pull the image. To overcome this issue, you must add or modify the TPM related script that handles TPM.
The device must not be encrypted before sysprep (pull). The device encryption is handled by the post push script that uses the
TPM_enable.ps1 script located at C:\Windows\setup\tools\. This script must be included before enabling the UWF and after sysprep
scripts. The PIN used to encrypt the client must be passed to the script as an argument.
To use TPM and BitLocker, do the following:
1 Enable TPM from the BIOS menu.
2 Modify the TPM related part of the script, based on the imaging solution.
3 Uncomment the below lines and update the pin for TPM encryption in the Custom FICore imaging method in C:\Windows\Setup
\CustomSysprep\Modules\Post_CustomSysprep.psm1
#cd C:\windows\setup\Tools\TPM\
#.\TPM_enable.ps1 -pin 1234
4 Uncomment the below lines and update the pin for TPM encryption for SCCM push in C:\Windows\Setup\CongMgrSysprep
\Modules\Admin_CongMgrSysprep.psm1
#cd C:\windows\setup\Tools\TPM\
#.\TPM_enable.ps1 -pin 1234
5 Uncomment the below lines and update the pin for TPM encryption in Non-Factory environment (WDM,WSI, USB Imaging solution) in
Post_CustomSysprep.psm1
#cd C:\windows\setup\Tools\TPM\
#.\TPM_enable.ps1 -pin 1234
If the client is encrypted previously, then do the following to clear the TPM:
1 Enter the BIOS mode.
2 In the TPM conguration, set Change TPM Status to Clear, and then apply the settings.
3 Reboot the device, and enter the BIOS mode again.
22 Admin specic features
4 Set Change TPM Status to Enable and Activate.
Conguring Bluetooth connections
You can use your thin client device with other Bluetooth enabled devices, if it has Bluetooth capability.
NOTE:
To retain your settings, disable the Unied Write Filter (UWF) and congure NetXClean. For more information, see Before Conguring
your thin clients.
To congure your thin client for Bluetooth connections:
1 Log in as an administrator.
2 Go to Start > Control Panel > Device Manager.
The Device Manager window is displayed.
3 Expand Bluetooth Radios, and double-click any Bluetooth icon.
For example, double-click Generic Bluetooth Radio to manage the existing Bluetooth device. You can also update the drivers in the
Update tab.
To add another Bluetooth enabled device to the thin client device, use the Add a Device wizard.
a To open the Devices and Printers window, click the Devices and Printers icon in the Control Panel.
b Click Add a Device.
The Add a Device wizard is displayed.
4 See the device documentation and follow the instructions to turn on Bluetooth on a Bluetooth-enabled device. When the device is
discovered by the thin client device, select the device.
5 Click Next, and follow the wizard.
Conguring wireless local area network settings
To congure the wireless local area network settings, use Setup a new connection or network window, if wireless support is allowed on
the thin client device.
To congure the wireless local area network settings, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > Network and Sharing Center > Setup a new connection or network. You can also select the Open
network, and sharing session on the taskbar that appears on the Thin Client Administrator Desktop.
3 In the Setup a new connection or network window, select Manually Connect to Wireless Network.
4 Click Next.
5 In the dialog box, enter the following:
Network Name
Security type
Encryption type
Security key
NOTE: Depending on the authentication, enter the security key.
6 Select the Start this connection automatically check box.
7 On the taskbar, select the Open network and sharing session and the name of the network which you entered.
8 Select Connect.
NOTE: You can also view the network available and directly connect from the Open network and sharing session on the
taskbar of the Thin Client Administrator Desktop.
Admin specic features 23
Using custom elds
To enter conguration strings for use by the Wyse Device Manager (WDM) software, use the Custom Fields dialog box. The conguration
strings can contain information such as location, user, administrator, and so on.
To enter the information that can be used by the WDM server, do the following:
1 Log in as an administrator.
2 Go to Start > Dell Thin Client Application.
The Dell Thin Client Application window is displayed.
3 On the left navigation bar, click Custom Fields.
4 Enter the custom eld information in the custom eld boxes, and click Apply.
The custom eld information is transferred to the Windows registry which is then available to the WDM server.
CAUTION:
To permanently save the information, ensure that you disable/enable the Unied Write Filter (UWF). For more information, see
Before Conguring your thin clients.
NOTE:
For details about the custom eld information, see the WDM documentation at www.dell.com/
support.
Conguring the RAMDisk Size
RAM Disk is a volatile memory space used for temporary data storage. It makes up the Z drive in the My Computer window. It can also be
used for temporary storage of other data according to administrator discretion. For more information, see Saving Files and Using Local
Drives
The following items are stored on RAM Disk:
Browser web page cache
Browser history
Browser cookies
Browser cache
Temporary internet les
Print spooling
User/system temporary les
To congure the RAM Disk size:
1 Log in as an Administrator.
2 On the Start menu, click Dell Thin Client Application
The Dell Thin Client Application window is displayed.
3 On the left navigation bar, click RAM Disk.
4 In the RAM Disk size box, type or select the RAM Disk size you want to congure, and then click Apply.
If you change the size of the RAM Disk, you are prompted to restart the system for the changes to take eect.
NOTE:
To permanently save the information, make sure you disable the Unied Write Filter (UWF). For more information, see Before
Conguring your thin clients.
24 Admin specic features
NOTE:
For thin clients with 4 GB RAM, the RAM disk size is set to 100 MB in the Write Filter enabled state, and set to 512 MB in the
Write Filter disabled state. For thin clients with RAM greater than 4 GB, the RAM disk size is set to 512 MB in both Write Filter
enabled state and Write Filter disabled state.
Enabling auto logon
Automatic logon to a user desktop is enabled by default on the thin client device. To enable or disable auto logon, and to change the default
user name, password, and domain for a thin client, use the auto logon feature.
To enable/disable auto logon:
1 Log in as an administrator.
2 Go to Start > Dell Thin Client Application.
The Dell Thin Client Application window is displayed.
3 On the left navigation bar, click Auto Logon.
4 To start with the admin logon page, enter Admin in the Default User Name eld.
NOTE: By default, the Enable Auto Logon check box is selected.
5 If you want to start with the Logon window with default administrator and user selections and other accounts, clear the Enable Auto
Logon check box.
CAUTION: To permanently save the information, disable/enable the Unied Write Filter (UWF). For more information, see
Before Conguring your thin clients.
NOTE:
If auto login is enabled and you log o from your current desktop, the lock screen is displayed. Click anywhere on the lock screen
to view the Logon window. Use this window to log in to your preferred administrator or user account.
System shortcuts
The System shortcuts page allows you to directly access some applications, directory, les, and folders without navigating through the
Start menu or control panel.
1 Log in as an administrator.
2 Go to Start > Dell Thin Client Application.
The Dell Thin Client Application window is displayed.
3 On the left navigation bar, click System Shortcuts.
The following shortcuts are listed in the System Shortcuts area:
Administrative Tools
All Control Panel Items
System Directory
Program Files
Temporary Folder
My Documents
Recent Accessed Files
Dell Thin Client Application Folder
Application Data Folder
4 Click any of the shortcuts to access the respective folders/les/applications.
Admin specic features 25
Viewing and conguring SCCM components
To view and congure the SCCM components installed on your thin client device, use the Conguration Manager Properties dialog box.
To open the Conguration Manager Properties dialog box:
1 Log in as an administrator.
2 Go to Start > Control Panel > Conguration Manager.
The Conguration Manager Properties dialog box is displayed.
For more information on how to use the Conguration Manager Properties dialog box, see Managing Windows-based Dell Wyse Thin
Clients using System Center Conguration Manager Administrator’s Guide at support.dell.com/manuals.
System Center Conguration Manager Client LTSB 2016
Microsoft System Center Conguration Manager (SCCM) helps you to empower devices and applications which needs to be productive,
while maintaining corporate compliance and control. It accomplishes the corporate compliance and control with a unied infrastructure that
gives a single pane of glass to manage physical, virtual, and mobile clients.
It also provides tools and improvements that makes easier for you to do the jobs. With SP1, it provides integration with Windows Intune to
manage PCs and mobile devices, both from the cloud and on-premise, from a single administrative console. For more information, see
Managing Windows-based Dell Wyse Thin Clients using System Center Conguration Manager Administrator’s Guide at support.dell.com/
manuals.
Devices and printers
To add devices and printers, use the Devices and Printers window.
CAUTION: To refrain from cleaning up your settings, disable/enable the Unied Write Filter (UWF) and congure NetXClean. For
more information, see Before Conguring your thin clients.
To add a device or a printer to the thin client, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > Devices and Printers.
The Devices and Printers window is displayed.
Adding printers
To add a printer to the thin client:
1 Click the Devices and Printers icon in Control Panel.
The Devices and Printers window is displayed.
2 To open and use the Add a Printer wizard, click Add a Printer.
The Add a Printer wizard session starts.
A Dell Open Print Driver is installed on the thin client along with other built-in print drivers. To print full text and graphics to a local
printer, install the driver provided by the manufacturer according to the instructions.
Printing to network printers from Citrix Receiver, Remote Desktop Connection or VMware Horizon Client applications can be
achieved through printer drivers on the servers.
26 Admin specic features
Printing to a local printer from Citrix Receiver, Remote Desktop Connection or VMware Horizon Client application using the printer
drivers of the server produces full text and graphics functionality from the printer. Install the printer driver on the server, and the text
only driver on the thin client using the following procedure:
a Click Add a local printer, and click Next.
b Click Use an existing port, select the port from the list, and then click Next.
c Select the manufacturer and model of the printer, and click Next.
d Enter a name for the printer and click Next.
e Select Do not share this printer and click Next.
f Select whether to print a test page and click Next.
g Click Finish to complete the installation.
A test page will print after installation if this option was selected.
Adding devices
To add a device to the thin client:
1 Click the Devices and Printers icon in Control Panel and open the Devices and Printers window.
2 To open and use the Add a Device wizard, click Add a Device.
The Add a Device wizard session starts. You can use the wizard to add a device of your choice to the thin client.
Conguring dual monitor display
You can use the Screen Resolution window to congure dual monitor settings on your dual-monitor capable thin client device.
To open the Screen Resolution window, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > Display > Change Display Settings.
The Screen Resolution window is displayed. For detailed instructions on how to congure the screen resolution, go to
www.microsoft.com.
For information about setting up multiple monitors, see the How to Set up Multiple Monitors in Windows 10 at support.dell.com.
Managing audio and audio devices
To manage your audio and audio devices, use the Sound dialog box.
To manage audio and audio devices, log in as an administrator, and open the Sound dialog box.
Using sound dialog box
To manage your audio devices, use the Sound dialog box.
To open the Sound dialog box:
1 Go to Start > Control Panel > Sound.
The Sound dialog box is displayed.
2 Use the following tabs, and congure the sound related settings:
Playback—Select a playback device and modify the settings.
Recording—Select a recording device and modify the settings.
Sounds—Select an existing or modied sound theme for events in Windows or programs.
Communications—Click an option to adjust the volume of dierent sounds when you are using your thin client to place or receive
telephone calls.
3 Click Apply, and click OK.
Admin specic features 27
NOTE:
Dell recommends powered speakers.
You can also adjust the volume using the Volume icon in the notication area of the taskbar.
Using the Realtek HD audio manager
To manage your audio and audio devices, use the Realtek HD Audio Manager window.
To open the Realtek HD Audio Manager:
1 On the Start Menu, click Control Panel > Realtek HD Audio Manager.
The Realtek HD Audio Manager window is displayed.
In the Speakers tab, move the rst slider to balance the volume of the left and right sound channel. To increase or decrease the
volume, move the second slider.
On the Speaker Conguration tab, you can congure the settings of your designated speakers. After conguring, you can preview
the sound by clicking the Auto Test command button.
Using the Sound Eects tab, you can congure the settings for environment and equalizer for an enhanced experience.
On the Default Format tab, you can select the sample rate and bit depth from the drop-down list.
You can click CD Format or DVD Format buttons to choose the default best quality for that format on the device.
2 Click OK to save the settings.
NOTE:
We recommend powered speakers.
You can also adjust the volume using the Volume icon in the notication area of the taskbar.
Setting region
To select your regional formats including keyboard and the Windows display languages, use the Region dialog box.
To select your regional formats, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > Region.
The Region dialog box is displayed.
3 In the Formats tab, select the language, date, and time.
To customize the formats, do the following:
a Click Additional Settings.
The Customize Format window is displayed.
b Customize the settings, and click OK.
4 Click Apply, and then click OK.
5 In the Location tab, select a particular location to display additional information such as news and weather.
6 In the Administrative tab, change the language to be displayed in programs that do not support Unicode, and copy the settings.
Managing user accounts
To manage users and groups, use the User Accounts window.
To open the User Accounts window, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > User Accounts.
28 Admin specic features
For more information on using the User Accounts window, see Managing Users and Groups with User Accounts.
Using Windows Defender
To scan your computer and protect against spyware and malware, use the Windows Defender dialog box.
To open the Windows Defender window, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > Windows Defender.
The Windows Defender window is displayed. In the Home tab, select a scan option, and click Scan Now.
To congure and manage your thin client device, you can use anti-malware software settings in the Settings tab.
Windows Defender is anti-spyware software that is included with Windows and runs automatically when you turn on your thin client. Using
anti-spyware software, helps you to protect the device against spyware and other potentially unwanted software. Spyware can be installed
on your device without your knowledge any time you connect to the internet, and it can infect your computer when you install some
programs using a CD, DVD, or other removable media. Spyware can also be programmed to run at unexpected times, not just when it is
installed.
NOTE: Windows Defender updates automatically at 1:00 AM on second Sunday of every month.
Admin specic features 29
Additional administrator utility and settings
information
This section provides additional information about utilities and settings available for administrators.
Automatically launched utilities
Utilities aected by log O, restart, and shut down
Using Unied Write Filter
Understanding the NetXClean utility
Saving les and using local drives
Mapping network drives
Participating in domains
Using the Net and Tracert utilities
Managing users and groups with user accounts
Changing the computer name of a thin client
Automatically launched utilities
The following utilities start automatically after you turn on the system, or after you log in to the thin client:
Unied Write Filter—After you turn on the system, the Unied Write Filter utility starts automatically. The icon in the notication area
of the taskbar indicates the active or inactive status of the Unied Write Filter. For more information, see Using the Unied Write Filter
(UWF).
NOTE: While the Dell Wyse Write Filter icons and functionality are currently supported, Dell recommends you to use the UWF
as described in the Microsoft documentation available at www.microsoft.com, and navigate to the Unied Write Filter
documentation.
NetXClean Utility—After you turn on the system, the NetXClean utility starts automatically. NetXClean is a clean-up utility that keeps
extraneous information from being stored on the local disk. If you want to keep certain prole congurations such as for printers, be
sure to congure NetXClean to refrain from cleaning up any number of explicitly declared proles. For more information, see
Understanding the NetXClean Utility.
VNC Server—After you log in to your thin client, the Windows VNC Server utility starts automatically. VNC allows a thin client desktop
to be accessed remotely for administration and support. For more information, see Using Tight VNC to Shadow a thin client.
Utilities aected by log o, restart, and shut down
The following utilities are aected by logging o, restarting, and shutting down the thin client device:
Unied Write Filter—After you turn on the system, the Unied Write Filter utility starts automatically. Dell recommends you to use the
UWF as described in the Microsoft documentation. For more information, see www.microsoft.com, and navigate to the Unied Write
Filter documentation.
NetXClean Utility—NetXClean is a clean-up utility that keeps extraneous information from being stored on the ash memory. Clean-up
is triggered automatically on restart, shut-down, or user log-o. If you want to keep certain prole congurations, for example, printers,
5
30 Additional administrator utility and settings information
congure the NetXClean to refrain from cleaning up any number of explicitly declared proles. For more information about NetXClean,
see Before conguring your thin clients, and Understanding the NetXClean utility.
Power Management—A Monitor Saver turns o the video signal to the monitor, allowing the monitor to enter a power-saving mode
after a designated idle time. To access the power settings, go to Start > Control Panel > Power Options.
Wake-on-LANThis feature discovers all thin clients connected to your LAN, and enables you to wake them by clicking a button. For
example, to perform image updates and remote administration functions on devices that have been shut down or are on standby. To
use this feature, the thin client power must be turned on.
Unied Write Filter
After system start-up, the Unied Write Filter (UWF) utility is automatically started.
UWF File Folder exclusions:
C:\Users\Admin\AppData\LocalLow
C:\Users\User\AppData\LocalLow
C:\Program Files\Windows Defender
C:\Program Files (x86)\Windows Defender
C:\Windows\WindowsUpdate.log
C:\Windows\Temp\MpCmdRun.log
C:\windows\system32\spp
C:\ProgramData\Microsoft\Windows Defender
C:\program les\Wyse\WDA\Cong
C:\Users\Public\Documents\Wyse
C:\Wyse\WCM\CongMgmt
C:\Wyse\WCM
C:\Wyse\WDA
UWF Registry exclusions:
HKLM\SYSTEM\CurrentControlSet\Control\WNT\DWCADTool
HKLM\Software\Wyse\CongMgmt
HKLM\SOFTWARE\Microsoft\Windows Defender
HKLM\SYSTEM\CurrentControlSet\Control\WNT\UWFSvc
HKLM\SOFTWARE\Microsoft\Windows\CurrentVersion\HomeGroup
HKLM\SOFTWARE\Microsoft\Windows NT\CurrentVersion\NetworkList
HKLM\SYSTEM\WPA
Unied Write Filter (UWF) details—Use Unied Write Filter (UWF) to protect your storage media. UWF intercepts all write attempts to a
protected volume and redirects the write attempts to a virtual overlay. This UWF improves the reliability and stability of your device and
reduces the wear on write-sensitive media, such as ash memory media like solid-state drives. In UWF, an overlay is a virtual storage space
that saves changes made to the underlying protected volumes. UWF intercepts all modications to any sector on a protected volume. A
sector is the smallest unit that can be changed on a storage volume. Any time the le system attempts to modify a protected sector, UWF
instead copies the sector from the protected volume to the overlay, and then modies the overlay instead. If an application attempts to
read from that sector, UWF returns the data from the overlay instead, so that the system maintains the appearance of having written to
the volume, while the volume remains unchanged.
CAUTION:
Dell recommends you to enable write lter during normal use of thin clients. It can be disabled only by an administrator while making
necessary changes. Extended use with write lters disabled can reduce the life of your ash drive. It is a good practice to enable
write lter to ensure device security.
Additional administrator utility and settings information 31
Running Unied Write Filter command–line options
There are several command lines you can use to control the Unied Write Filter. Command–line arguments cannot be combined.
Use the following guidelines for the command–line option for the Unied Write Filter. You can also use the commands if you open the
command prompt window with elevated privilege by entering command in the Run box.
Command-line options Description
uwfmgr This command-line tool congures and retrieves settings for Unied
Write Filter (UWF). If there are no command-line options available,
it displays the command help.
uwfmgr lter enable This command-line enables the Unied Write Filter after the next
system restart. The Unied Write Filter status icon is green when
the Unied Write Filter is enabled.
uwfmgr lter disable This command-line option disables the Unied Write Filter after the
next system restart. The Unied Write Filter status icon remains red
while disabled.
uwfmgr le commit C: <le_path> This command-line commits changes to a specied le to overlay
for a Unied Write Filter-protected volume. Administrator-level
permissions are required to use this command.
The <le> parameter must be fully qualied, including the volume
and path. uwfmgr.exe uses the volume specied in
the <le> parameter to determine which volume contains the le
exclusion list for the le. There is a single space between volume
name and le_path. For example, to commit a le C:\Program Files
\temp.txt the command would be uwfmgr commit C:
\Program Files\temp.txt.
uwfmgr le add-exclusion C: <le_or_dir_path> This command-line adds the specied le to the le exclusion list of
the volume protected by Unied Write Filter. Unied Write Filter
starts excluding the le from ltering after the next system restart.
For example, to add a registry directory HKLM\SYSTEM\WPA, the
command is UWFmgr.exe registry add-exclusion HKLM
\SYSTEM\WPA.
uwfmgr le remove-exclusion C: <le_or_dir_path> This command-line removes the specied le from the le exclusion
list of the volume protected by Unied Write Filter. Unied Write
Filter stops excluding the le from ltering after the next system
restart.
uwfmgr overlay get-cong This command-line displays conguration settings for the Unied
Write Filter overlay. Displays information for both the current and
the next session.
uwfmgr registry /? This command-line displays conguration settings for exclusions of
registry keys.
NOTE: If you open a command prompt window and enter uwfmgr ? or uwfmgr help, all available commands are displayed.
For information on a command, use uwfmgr help <command>. For example, for information on the command, volume, enter
uwfmgr help volume.
CAUTION:
Administrators should use le security to prevent unwanted usage of these commands.
Do not attempt to ush the data to the disk while another ush operation is in progress.
32 Additional administrator utility and settings information
Enabling and disabling the Write Filter using the
desktop icons
The Unied Write Filter can also be enabled or disabled using the Write Filter Enable/Disable desktop icons. The icon in the notication area
of the taskbar indicates the active or inactive status of the Unied Write Filter by the colors green and red respectively.
Dell Wyse WF Enable Icon (Green)—Double-clicking this icon enables the Unied Write Filter. This utility is similar to running the
uwfmgr lter enable command-line. However, double-clicking this icon immediately restarts the system and enables the Unied Write
Filter. The Unied Write Filter status icon in the notication area of the taskbar is green when the Unied Write Filter is enabled.
Dell Wyse WF Disable Icon(Red)—Double-clicking this icon disables the Unied Write Filter. This utility is similar to running the
uwfmgr lter disable command-line option. However, double-clicking this icon restarts the system immediately. The Unied Write Filter
status icon in the notication area of the taskbar remains red if the Unied Write Filter is disabled.
Setting Write Filter controls
To view and manage UWF control settings, use the Unied Write Filter Control dialog box. To open the dialog box, double-click the UWF
icon in the notication area of the administrator taskbar.
When you congure UWF control settings, some of the elds are unavailable. You can select from the list of available elds during
conguration.
The Dell Wyse Unied Write Filter Control dialog box includes the following:
UWF status
Current Status—Shows the status of the Unied Write Filter. The status may either be Enabled or Disabled.
Boot Command—Shows the status of the Boot Command. UWF_ENABLE means that the UWF is enabled for the next session;
and UWF_DISABLE means that the UWF is disabled for the next session.
RAM used by UWF—Shows the amount of RAM allocated to the Unied Write Filter in Mega bytes (MB) and Percentage. If
Current Status is disabled, RAM allocated to UWF is always zero (0).
Amount of RAM used for UWF Cache—Shows the amount of RAM allocated to the Unied Write Filter cache for the current
session in Megabytes (MB).
Warning #1 (%)—Shows the UWF cache percentage value at which a Low Memory warning message is displayed to the user for
the current session.
Warning #2 (%)—Shows the UWF cache percentage value at which a Critical Memory warning message is displayed to the user.
UWF Cache settings
Amount of RAM to be used for UWF Cache—Shows the amount of RAM that is to be used as the Unied Write Filter cache for
the next session in MB. This value should be in the range of 256 MB to 2048 MB. There is an extra check to ensure that this value
does not exceed 50% of Total Available RAM.
UWF Warning settings
Warning #1 (%)—Shows the UWF cache percentage value at which a Low Memory warning message is displayed to the user
(Default value = 80, Minimum value = 50, Maximum value = 80).
Warning #2 (%)—Shows the UWF cache percentage value at which a Critical Memory warning message is displayed to the user.
Once the memory level crosses the warning level 2, system automatically restarts. (Default value = 90, Minimum value = 55,
Maximum value = 90)
Enable UWF—Allows you to enable the Unied Write Filter and prompts you to restart the thin client device. To save the changes,
restart the thin client. After the system restarts to enable the Unied Write Filter, the Unied Write Filter status icon in the desktop
notication area turns green.
Additional administrator utility and settings information 33
Disable UWF—Allows you to disable the Unied Write Filter and prompts you to restart the thin client device. To save the changes,
restart the thin client. After disabling the Unied Write Filter, the Unied Write Filter status icon in the desktop notication area turns
red and the Unied Write Filter remains disabled after the system restarts.
Defaults—Allows you to reset the UWF Cache Settings area, and the UWF Warning Settings area to their default values.
File Commit area
File Path—Allows you to add, remove, and commit les to the underlying media. The system does not restart the thin client device.
The changes are committed immediately.
NOTE: Delete a le path from the list, if the le is not
committed.
Current Session Exclusion List
File/Directory Path
Allows you to add and remove a le or directory, to or from the exclusion list for the next session. This retrieves the list of les or
directories that are written through in the current session and the title of the pane is shown as Current Session Exclusion List. The
Next Session retrieves the list of les or directories that are written through for the next session and the title of the pane is shown
as Next Session Exclusion List. The system will not restart the thin client, and the changes are not committed until an administrator
restarts the thin client device manually.
NetXClean utility
NetXClean is a clean-up utility that keeps extraneous information from being stored on the local disk. When multiple users have logon rights
to a system, the disk space is used by the proles stored locally. NetXClean helps to reclaim disk space from latent proles and can be used
to automatically clean-up directories used for temporary caching of information. clean-up is triggered on either service startup or user
logo. It does the clean-up invisibly to the user and is completely congurable.
NetXClean is a Windows utility built to run as a service. It is a standalone utility that uses a conguration le to determine which directories
and les to purge, and which proles to not purge. The utility can be congured to:
Delete any number of directories and their contents
Delete just the contents of any number of directories
Delete any number of les declared explicitly
Delete any number of les matching wild-character le names
Refrain from cleaning up any of the proles
Refrain from cleaning up any number of explicitly declared proles
Refrain from cleaning up any number of the most recently used proles
Perform the directory clean-up on service start event, user logo event, or both events.
Perform the le clean-up on service start event, user logo event, or both events.
Perform the prole clean-up on service start event, user logo event, or both events.
NetXClean does not clean-up the following directories or any parent to these directories:
Windows directory
Windows System directory
The current directory where the service is installed in
NetXClean does not delete the following proles:
• Administrator
• skinnynt
• totalcontrol
34 Additional administrator utility and settings information
• Default_User
• Default_user
The prole of the last user to logon
NOTE:
NetXClean purge selections are made by the manufacturer and should not be changed without manufacturer supervision.
NetXClean Utility does not have any dependency on Unied Write Filter (UWF).
Saving les and using local drives
Thin clients use an embedded operating system with a xed amount of disk space. Dell recommends you to save les that you want to keep
on a server rather than on a thin client.
CAUTION: Be careful of application settings that write to the drive C, which resides in disk space. By default, these applications
write cache les to the drive C on the local system. If you must write to a local drive, change the application settings to use the
drive Z. The default conguration settings mentioned in Managing Users and Groups with User Accounts minimize writing to the
drive C for factory-installed applications.
drive Z
drive Z is the on-board volatile memory (Dell Wyse RAM Disk) of the thin client. It is recommended that you do not use this drive to save
data that you want to retain.
For information about using the Z drive with roaming proles, see Participating in Domains.
drive C
Drive C is the on-board non-volatile ash memory. Dell recommends that you avoid writing to drive C. Writing to drive C reduces the free
disk space. If the free disk space on drive C is reduced under 3 MB, the thin client will become unstable.
NOTE: Dell recommends that 3 MB of disk space is left unused. If the free disk space is reduced to 2 MB, the thin client image
will be irreparably damaged and it will be necessary for you to contact an authorized service center to repair the thin client.
Enabling the Unied Write Filter protects the disk from damage and presents an error message if the cache is overwritten. However, if this
message occurs you will be unable to ush les of the Unied Write Filter cache and any thin client conguration changes still in cache is
lost. Items that are written to the Unied Write Filter cache or directly to the disk if the Unied Write Filter is disabled during normal
operations include:
• Favorites
Created connections
Delete/edit connections
For information on the role of NetXClean in keeping the disk space clean, see Understanding the NetXClean Utility.
Mapping network drives
Administrators can map network drives. However, to retain the mappings after the thin client device is restarted, do the following:
1 Log in as an administrator.
2 On the taskbar, click the search icon, and then enter This PC.
This PC desktop application is displayed in the Best Match area on the result page.
3 Right-click This PC, and then click Map network drive.
The Map Network Drive dialog box is displayed.
4 Select the drive letter from the Drive drop-down list, and type or browse for the folder you want to connect.
5 Select the Reconnect at logon check box.
6 Empty the les of the Unied Write Filter cache during the current system session.
Additional administrator utility and settings information 35
Since a user login account cannot ush the les of the Unied Write Filter cache, the settings can be retained by logging o from the
user account, and logging in using an administrator account. Also, remove the les of the cache. Do not shut down, or restart the
system.
NOTE: A remote home directory can also be assigned by using a user manager utility or by other means known to an
administrator.
7 Click Finish to complete the network drive mapping.
Participating in domains
You can participate in domains by joining the thin client device to a domain or by using roaming proles.
To join a domain, do the following:
1 Log in as an administrator.
2 Go to Start > Control Panel > System.
The System window is displayed.
3 In the Computer name, domain and workgroup settings section, click Change Settings.
The System Properties dialog box is displayed.
4 Click Change option to change the domain or workgroup.
a Click Domain.
The Computer Name/Domain Changes dialog box is displayed.
b Enter the domain of your choice.
c Click OK.
5 To join a thin client device to a domain, click Network ID.
The Join a Domain or Workgroup wizard is displayed. On the rst page of the wizard, select the option that describes your network.
Business Network—Click this option if your thin client is a part of business network and you use it to connect to other clients at
work.
1 Click Next.
2 Select the option according to your company’s network availability on a domain.
If you select the option Network with a domain, then enter the following information:
User name
• Password
Domain name
If you select the option Network without a domain, then enter Workgroup, and then click Next.
NOTE: You can click Next even if you do not know the workgroup name.
3 To apply the changes, you must restart the computer. Click Finish.
NOTE: Before restarting your computer, save any open les and close all
programs.
Home Network—Click this option if your thin client is a home client and it is not a part of a business network. To apply the
changes, you must restart the computer. Click Finish.
CAUTION: Exercise caution when joining the thin client device to a domain as the prole downloaded at logon could
overow the cache or ash memory.
When joining the thin client device to a domain, the Unied Write Filter should be disabled so that the domain information can be
permanently stored on the thin client device. The Unied Write Filter should remain disabled through the next restart as information is
written to the thin client on the restart after joining the domain. This UWF is important when joining an Active Directory domain. For
details on disabling and enabling the Unied Write Filter, see Before Conguring your Thin Client.
36 Additional administrator utility and settings information
To make the domain changes permanent, complete the following:
a Disable the Unied Write Filter.
b Join the domain.
c Restart the thin client.
d Enable the Unied Write Filter.
NOTE:
If you use the Write Filter Enable icon to enable the Write Filter, the restart happens automatically. By default, the
NetXClean utility purges all but selected proles on the system when the thin client device starts up or when the user logs
o. For information on the NetXClean utility, see NetXClean Utility.
Using Roaming Proles
You can participate in domains by writing roaming proles to the C drive. The proles must be limited in size, and it is not retained when the
thin client device is restarted. For successful downloading and proper functioning, there must be sucient disk space available for roaming
proles. Sometimes, it may be necessary to remove software components to free space for roaming proles.
Using the Net and Tracert utilities
Net and Tracert utilities are available for administrative use. For example, determining the route took by packets across an IP network.
For more information on these utilities, go to www.microsoft.com.
Managing Users and Groups with User Accounts
To create and manage user accounts and groups, and congure advanced user prole properties, use the User Accounts window. By
default, a new user is only a member of the Users group and is not locked down. As an administrator, you can select the attributes and
prole settings for users.
This section provides quick-start guidelines on:
Creating User Accounts
Editing User Accounts
Conguring User Proles
NOTE: For detailed information on using the User Accounts window, click the Help icon and examples links provided throughout
the wizards. For example, you can use the Windows Help and Support window to search for items such as user proles and user
groups. Obtain links to detailed steps on creating and managing these items.
Creating user accounts
Only administrators can create user accounts locally or remotely through VNC. However, due to local ash or disk space constraints, the
number of additional users on the thin client device should be kept minimum.
CAUTION: To permanently save the information, ensure that you disable the Unied Write Filter (UWF).
1 Log in as an administrator.
2 Go to Start > Control Panel > User Accounts.
3 On the User Accounts window, click Manage another account.
The Manage Accounts window is displayed.
4 Click Add new user in PC settings.
The PC settings wizard starts. Use this wizard to create a user account.
5 After creating the standard users and administrators, these users will appear in the Manage Accounts window. See Step 3.
Additional administrator utility and settings information 37
Editing user accounts
Open the User Accounts window as described in Managing User Accounts.
To edit the default settings of a standard user or administrator account:
1 On the User Accounts window, click Manage another account.
The Manage Accounts window is displayed.
2 To change as required, select User.
The Change an Account window is displayed. Now make the desired changes using the links provided.
Conguring user proles
Open the User Accounts window as described in Managing User Accounts.
CAUTION:
By default, all application settings are set to cache to C drive. Dell recommends that you cache to the RAM Disk Z drive as is preset
in the account proles to avoid overowing the Unied Write Filter cache.
It is recommended that other applications available to new and existing users be congured to prevent writing to the local le
system because of the limited size of the disk space. It is recommended that care be exercised when changing conguration
settings of the factory-installed applications.
To congure the default admin and user proles stored on the thin client:
1 On the User Accounts window, click Congure Advanced User Prole Properties.
The User Proles dialog box is displayed.
2 Use the command buttons such as Change Type, Delete, and Copy to as described in the Microsoft documentation provided
throughout the wizards.
Changing the computer name of a thin client
Administrators can change the computer name of a thin client. The computer name information and the Terminal Services Client Access
License (TSCAL) are preserved regardless of the Unied Write Filter state (enabled or disabled). This maintains the specic computer
identity information and facilitates the image management of the thin client.
To change the computer name of a thin client device:
1 Log in as an administrator.
2 Go to Start > Control Panel > System.
The System window is displayed.
3 In the Computer name, domain, and workgroup settings section, click Change Settings.
The System Properties dialog box is displayed.
4 Click Change to rename the computer name.
5 In the Computer Name window, type the name for the thin client device in the Computer name eld, and click OK.
6 In the Conrmation dialog box, click OK to restart for applying the changes.
7 Click Close, and then click Restart Now to apply the changes.
38 Additional administrator utility and settings information
System Administration
To maintain your thin client device environment, you can perform local and remote system administration tasks. The tasks include:
Accessing Thin Client BIOS Settings
Restoring BIOS default settings
Unied Extensible Firmware Interface (UFEI) and Secure Boot
WDM Software for Remote Administration
Conguring and Using Peripherals
Using Tight VNC (Sever and Viewer) to Shadow a Thin Client
Accessing thin client BIOS settings
To access the thin client BIOS settings, do the following:
1 During the start-up, press the Delete key.
The BIOS Settings dialog box is displayed.
2 Change the BIOS Settings as required.
Accessing thin client boot menu
To access the thin client boot menu, do the following:
1 During the start-up, press the P key.
The Boot menu is displayed.
2 Select the desired option and press Enter.
Restoring BIOS default settings
You can use the Basic Input Output System (BIOS) to restore values for all the items in the BIOS setup utility.
To restore the default settings on the thin client device, press F9.
Press F10 to save the restored values.
For more information, see Accessing Thin Client BIOS Settings
Unied Extensible Firmware Interface (UEFI) and
secure boot
Unied Extensible Firmware Interface (UEFI) is a standard rmware interface designed to improve software interoperability and address
limitations of BIOS. UEFI is designed to replace Basic Input Output System (BIOS).
6
System Administration 39
Secure Boot is a feature on UEFI- based clients that helps increase the security of a client by preventing unauthorized software from
running on a client during the boot sequence. It checks whether each software has a valid signature, including the operating system (OS)
that is being loaded during booting.
The thin client device comes enabled with UEFI and Secure Boot. Due to this feature, you cannot boot from USB keys unless you enter the
BIOS, disable Secure Boot, change the boot mode to Legacy, and enable the Boot from USB option.
Booting from a DOS USB key
To boot from a DOS USB Key:
1 Enter the BIOS Settings.
2 Set the Secure Boot to DISABLED.
3 Set the Boot Mode to LEGACY.
4 Set the Boot from USB to ENABLED.
5 Save the changes and exit.
6 During start up, press P and then select USB stick in boot menu.
NOTE: WIE 10 x64 does not boot when Boot Mode is set to LEGACY.
Booting from a UEFI USB key
To boot from a UEFI USB key:
1 Enter the BIOS settings.
2 Set the Secure Boot to DISABLED.
3 Set the Boot from USB to ENABLED.
4 Save the changes and Exit.
5 In the Pop-up Menu, select USB Stick and Boot as NORMAL.
NOTE:
Windows 10 IoT Enterprise (WIE10) x64 boots, if secure boot is set to DISABLED. However for security purposes, this is not
recommended.
To boot from non Microsoft OS, disable the secure boot option. Secure boot option is not trusted in BIOS.
Creating a Boot disk UEFI USB key
1 Obtain a UEFI shell executable. You can download the unsigned reference shell from: Sourceforge Download Center.
2 Save the le as: bootx64.e
3 Format the USB Stick with FAT 32
4 In the USB Key, create the directory: \e\boot
5 Copy the le bootx64.e to the directory \e\boot on the USB Key.
WDM software for remote administration
WDM software enables you to congure, monitor and manage Dell Wyse endpoint devices.
WDM provides the following important features:
Remote shadow
• Reboot
40 System Administration
• Shutdown
• Boot
Automatic device check-in support
• Wake-On-LAN
Change device properties
From a single console, you can easily issue software images, patches, updates and add-ons and manage all aspects of remote cloud clients
to ensure peak user productivity.
Conguring and using peripherals
The thin client device has many ports available on it such as:
USB Port— 6
DisplayPort — 2
To provide the services through the ports, install the appropriate software for the thin client device.
NOTE:
1 You can install other services and add-ins that are available from the Dell website for free or for a licensing fee.
For more information, see Dell support website.
2 You can congure the thin client device to use Bluetooth- enabled Peripherals. For more information, see Conguring Bluetooth
Connections.
TightVNC—server and viewer
To congure or reset a thin client device from a remote location, use TightVNC—server and viewer. TightVNC is primarily intended for
support and troubleshooting purposes.
Install TightVNC locally on the thin client device. After installation, it allows the thin client to be shadowed, operated and monitored from a
remote device.
TightVNC Server starts automatically as a service upon thin client device restart. The initialization of TightVNC Server can also be
controlled by using the Services window by this procedure.
To open TightVNC Server window:
1 Log in as an Administrator.
2 Click Start Menu > TightVNC > TightVNC Server.
NOTE:
TightVNC Viewer is available from TightVNC website.
TightVNC is included in WDM software as a component.
TightVNC Viewer must be installed on a shadowing or remote machine before use.
If you want to permanently save the state of the service, ensure that you ush the les of the Unied Write Filter during the
current system session.
TightVNC—Pre-requisites
Before TightVNC server installation on a remote machine, to access a thin client device you must know the following:
IP address or valid DNS name of the thin client device to shadow, operate or monitor.
Primary password of the thin client device to shadow, operate or monitor.
System Administration 41
NOTE:
To obtain the IP address of the thin client device, move the pointer over the TightVNC icon in the taskbar,
To congure TightVNC server, the default password is DELL.
Using TightVNC to shadow a thin client
TightVNC Server starts automatically as a service upon thin client startup. The TightVNC Server service can also be stopped and started
by using the Services window.
1 Log in as an administrator.
2 Go to Start > Control Panel > Administrative Tools > Services, and then select TightVNC Server.
3 You may also use the TightVNC Server features in Start > TightVNC.
To shadow a thin client from a remote machine:
a On a remote machine on which TightVNC Viewer is installed, open the New Tight VNC Connection dialog box.
b Enter the IP address or valid DNS name of the thin client that is to be shadowed or operated or monitored.
c Click OK.
The VNC Authentication dialog box is displayed.
d Enter the Password of the thin client that is to be shadowed; this is the Primary Password of the thin client that is to be
shadowed.
e Click OK.
The thin client that is to be shadowed or operated or monitored is displayed for the administrator in a separate window on the remote
machine. Use the mouse and keyboard on the remote machine to operate the thin client just as you would if you were operating it
locally.
Conguring TightVNC server properties on the thin
client
1 To open the TightVNC Server Conguration (oine) dialog box, go to Start > TightVNC > TightVNC Server — Oine
Conguration.
The TightVNC Server Conguration (oine) dialog box is displayed.
2 In the Server tab, set the Primary password. Use this password while shadowing the thin client. Default primary password is Wyse.
3 In the Server tab, select the following check boxes:
Accept incoming connections
Require VNC authentication
Enable le transfers
Hide desktop wallpaper
Show icon in the notication area
Serve Java Viewer to web clients
Use mirror driver if available
Grab transparent windows
4 Retain the following check boxes blank:
Block remote input events
Block remote input on local activity
No local input during client sessions
5 In the Main server port box, select or type 5900.
6 In the web access port box, select or type 5800.
7 In the Screen poling cycle box, select or type 1000.
8 Click OK.
42 System Administration
NOTE: For security purposes, Dell recommends that the primary password be changed immediately upon receipt of the thin
client and it is for administrator use only.
System Administration 43
Network architecture and server environment
This section contains information about the network architecture and enterprise server environment needed to provide network and
session services for your thin client. It includes:
Understanding how to congure your network services
Using Dynamic Host Conguration Protocol (DHCP)
DHCP Options
Using Domain Name System (DNS)
About Citrix Studio
About VMware Horizon View Manager Services
Understanding how to congure your network
services
Network services provided to thin clients can include DHCP, FTP le services, and DNS. You can congure, design, and manage your
network services depending on the availability in your environment.
You can congure your network services using:
Dynamic Host Conguration Protocol (DHCP)
Domain Name System (DNS)
Using Dynamic Host Conguration Protocol
A thin client is initially congured to obtain its IP address and network congurations from a Dynamic Host Conguration Protocol (DHCP)
server. A DHCP server provides the IP address or DNS name of the FTP server and the FTP root-path location of software in
Microsoft.msi form to access the IP address and network congurations through the DHCP upgrade process.
DHCP is recommended to congure and upgrade thin clients as it saves time and eorts needed to complete these processes locally on
multiple thin clients. If a DHCP server is not available, xed IP addresses can be assigned and it must be entered locally for each device.
A DHCP server can also provide the IP address of the WDM server. For more information, see WDM software for Remote Administration.
7
44 Network architecture and server environment
DHCP options
The DHCP options listed in the following table are accepted by the thin clients.
Table 1. DHCP options
Option Description Notes
1 Subnet Mask Required
3 Router Optional but recommended. It is not
required unless the thin client must interact
with servers on a dierent subnet.
6 Domain Name Server (DNS) Optional but recommended
12 Hostname Optional
15 Domain Name Optional but recommended
43 Vendor Class Specic Information Optional
50 Requested IP Required
51 Lease Time Required
52 Option Overload Optional
53 DHCP Message Type Required
54 DHCP Server IP Address Recommended
55 Parameter Request List Sent by thin client
57 Maximum DHCP Message Size Optional (always sent by thin client)
58 T1 (renew) Time Required
59 T2 (rebind) Time Required
61 Client identier Always sent
155 Remote Server IP Address or name Optional
156 Logon User Name used for a connection Optional
157 Domain name used for a connection Optional
158 Logon Password used for a connection Optional
159 Command Line for a connection Optional
160 Working Directory for a connection Optional
163 SNMP Trap server IP Address list Optional
164 SNMP Set Community Optional
165 Remote Desktop Connection startup
published applications
Optional
168 Name of the server of the virtual port Optional
186 WDM sever IP IP addresses of WDM Server. If tag 194 is
specied, then dening this tag is not
necessary.
Network architecture and server environment 45
Option Description Notes
190 WDM secure port Optional number, word, or two-bytes array.
Species to use HTTPS to communicate
with WDM instead of HTTP
192 WDM server port Species HTTP (non-secure)
communication with WDM.
194 WDM server FQDN Optional. If this tag is specied, then
dening tag 186 is not mandatory.
NOTE: For more information on conguring a DHCP server, see www.microsoft.com.
Using Domain Name System
Thin client devices accept valid Domain Name System (DNS) names registered on a DNS server available to the enterprise intranet. The
thin client device sends a query to DNS server on the network to translate the name into the corresponding IP address. DNS allows hosts
to be access by their registered DNS names rather than their IP address.
Every Windows DNS server in Windows Server 2000 and later includes Dynamic DNS (DDNS) and every server registers dynamically with
the DNS server. For DHCP entry of DNS domain and server location information, see Using Dynamic Host Conguration Protocol (DHCP).
About Citrix Studio
Citrix Studio is a software program that enables you to congure and manage your personalized desktops and applications. It provides an
easy end-user computing experience across all devices and networks while delivering optimal performance, better security, and improved
personalization.
NOTE: For more information about installing and conguring the Citrix Studio, go to Citrix Website.
Citrix Studio consists of various wizards that allows you to perform the following tasks:
Publish virtual applications
Create groups of server or desktop operating systems
Assign applications and desktops to users
Grant user access to resources
Assign and transfer permissions
Obtain and track Citrix licenses
Congure StoreFront
All available Virtual Desktop Applications (VDA) are listed in the Studio. From the VDA list, select the application you would like to publish.
Information displayed in the Studio is received from the Broker Service in the Controller.
About VMware Horizon View Manager
VMware View is an enterpriseclass virtual desktop manager that securely connects authorized users to centralized virtual desktops. It
provides a complete, endtoend solution that improves control and manageability and provides a familiar desktop experience. Client
software securely connects users to centralized virtual desktops, back-end physical systems, or terminal servers.
NOTE: For more information, on installing and conguring View Manager, go to VMware Website.
VMware View includes the following key components:
View Connection Server—A software service that acts as an intermediate for client connections by authenticating and then directing
incoming remote desktop user requests to the appropriate virtual desktop, physical desktop, or terminal server.
46 Network architecture and server environment
View Agent—A software service that is installed on all guest virtual machines, physical systems, or terminal servers. View Manager
manages this software. The agent provides features such as the Remote Desktop Connection monitoring, virtual printing, remote USB
support, and single sign-on.
View Client—It is a locally installed software application that communicates with View Connection Server, to allow users to connect to
their desktops using Microsoft Remote Desktop Connection.
View PortalThis component is similar to View Client but provides a View user interface through a web browser. It is supported on
multiple operating systems and browsers.
View AdministratorThis component provides the View administration through a web browser. View administrators use it to do the
following:
Manage conguration settings.
Manage virtual desktops and entitlements of desktops of the Windows users and groups.
View Administrator also provides an interface to monitor log events and is installed with View Connection Server.
View ComposerTo allow View Manager to rapidly deploy multiple linked clone desktops from a single centralized base image, View
Composer software service is installed on the Virtual Center server.
Network architecture and server environment 47

Navigation menu
