Reference Guide

Dell Wyse ThinOS Release 8.3.1 – INI Files

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

© 2016 - 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other

trademarks may be trademarks of their respective owners.

2016 - 12

Rev. A03

Contents

Summary of Revisions.................................................................................................................................. 0

1 Introduction....................................................................................................................................................6

About this Guide.................................................................................................................................................................6

2 Getting Started: Learning INI File Basics........................................................................................................7

Downloading and Using Sample INI Files.........................................................................................................................7

Supported INI Files you can Construct......................................................................................................................7

Rules and Recommendations for Constructing the INI Files........................................................................................9

System Variables.........................................................................................................................................................10

Placing the INI Files into the Folder Structure on the Server...................................................................................... 11

3 Parameters for WNOS INI Files Only............................................................................................................ 13

General Settings for WNOS.INI Files Only.....................................................................................................................13

Peripheral Settings for wnos.ini Files Only.....................................................................................................................19

Connection Settings for wnos.ini Files Only..................................................................................................................19

4 Parameters for WNOS INI, {username} INI, and $MAC INI Files.................................................................. 40

General Settings for wnos.ini Files, {username} INI, and $MAC INI Files..................................................................41

Peripheral Settings for wnos.ini Files, {username} INI, and $MAC INI Files............................................................. 54

Connection Settings for wnos.ini Files, {username} INI, and $MAC INI Files........................................................... 61

A Connect Parameter: Options....................................................................................................................... 83

ICA Connect Options.......................................................................................................................................................83

ICA Connect: Options................................................................................................................................................84

RDP Connect Options.....................................................................................................................................................89

RDP Connect Options...............................................................................................................................................89

B TimeZone Parameter: Values....................................................................................................................... 95

TimeZone Parameter: Values..........................................................................................................................................95

C Best Practices: Troubleshooting and Deployment Examples...................................................................... 100

Troubleshooting INI Files................................................................................................................................................100

Examples: Basic Deployments...................................................................................................................................... 100

Contents 3

Summary of Revisions

The following changes and enhancements have been made to this document since Dell Wyse ThinOS release 8.3.

Reference Description

Device=bluetooth

[Disable={yes, no}]

New parameters added in Peripheral Settings for wnos.ini Files,

username INI and MAC INI Files.

DisableButton={yes, no}

[DisableRestart={yes, no}]

New parameters added in Connection Settings for wnos.ini Files

Only.

Fastconnect={yes, no}

[Key={F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, Pause/

Break}]

[Ctrl={yes, no}]

[Alt={yes, no}]

[Connect={ICA, RDP, PCoIP}]

[List={*|app1|server1;app2}]

[Title={*_seamless_window_title*]

New parameters added in Connection Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

Language=code

[ManualOverride={yes, no}]

New parameters added in General Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

Language INI

Czech (Qwerty) — Cz_q

New parameters added in General Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

MultiLogon={yes, no}

[SequentialDomain={yes, no}]

New parameters added in Connection Settings for wnos.ini Files

Only.

Printer={LPD1, LPD2, LPD3, LPD4, LPD5-LPD36} New parameters added in Peripheral Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

PRIVILEGE=[None, Low, High]

[TrapReboot={yes, no}]

[EnableCancel={yes, no}]

New parameters added in General Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

reboot | shutdown={yes, no} New parameters added in Connection Settings for wnos.ini Files

Only.

SecureMatrixServer=Securematrix_Server

[EnableSelectTable]

New parameters added in Connection Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

Service=snmpd disable={yes, no}

[communityReadOnly= [encrypt={yes, no}]]

[servers=server_list]

New parameters added in Connection Settings for wnos.ini Files

Only.

4 Summary of Revisions

Reference Description

SessionCong=ICA

[PasswordExpireNotify={yes, no}]

[RefreshPopupNotice={yes, no}]

New parameters added in Connection Settings for wnos.ini Files,

{username} INI, and $MAC INI Files.

TerminalName=name

[reboot={yes, no}]

[Capital={yes, no}]

New parameters added in Connection Settings for wnos.ini Files

Only.

Summary of Revisions 5

Introduction

Thin clients running Dell Wyse ThinOS rmware are designed solely for optimal thin client security and performance. These extremely

ecient purpose-built thin clients are virus and malware-resistant and oer ultra-fast access to applications, les, and network resources

within Citrix, Microsoft, VMware and Dell vWorkspace environments, and other leading infrastructures. ThinOS-based thin clients are self-

managed, go from power-on to fully productive in seconds, and with no published API, locally accessible le system or browser, require no

local antivirus software or rewall to protect against viruses or malware.

About this Guide

This guide is intended for administrators of Dell Wyse thin clients running ThinOS. It provides the detailed information you need to help you

understand and use the ThinOS INI les. It contains information on the dierent INI les you can use and the rules for constructing the les.

It also provides the parameter details your INI les with working examples.

Finding the Information You Need in this Guide

You can use either the Search window or Find toolbar to locate a word, series of words, or partial word in an active PDF document. For

detailed information on using these features, refer to the Help in your PDF reader.

1

6 Introduction

Getting Started: Learning INI File Basics

In this chapter you will learn how to construct and use the supported INI les.

It includes:

•Downloading and Using Sample INI Files

•Supported INI Files You can Construct

•Rules and Recommendations for Constructing the INI Files

•Placing the INI Files into the Folder Structure on the Server

After you become familiar with the INI le basics, you can refer to the parameter details you need in the other chapters and appendixes of

this guide.

Topics:

• Downloading and Using Sample INI Files

• Rules and Recommendations for Constructing the INI Files

• Placing the INI Files into the Folder Structure on the Server

Downloading and Using Sample INI Files

ThinOS Sample INI les are available from Dell and can be modied to suit the individual connection prole needs for your users. These

sample les are annotated to allow you to use them as a starter set that you can modify to get your le server up and running.

To download and use the les:

1 From the le server machine on which you want to load the INI les for use, go to the Knowledge Base at www.dell.com/wyse/

knowledgebase.

2 On the Knowledge Base page, type sample.ini in the search text box, and then click Go.

3 In the resulting solutions Title list, click the reference guide link for the ThinOS version you are using.

4 In the resulting attachments Name list, click the Sample User INI link for the zip le you want to open, for example,

Sample_User_INI_August2011.zip, and use the File Download dialog box.

After downloading the self-extracting sample INI le to the le server you want, double-click the Sample_ini.exe le, and then modify

the le using an ASCII text editor as needed for your use.

Supported INI Files you can Construct

The INI les contain the parameters and its associated options and values necessary for the various functionality you want.

NOTE:

For examples of parameters commonly used for basic deployments, see Examples: Basic Deployments.

You can construct the following INI les:

• wnos.ini le, see Working with wnos.ini Files.

• {username}.ini le, see Working with {username}.ini Files.

• $MAC.ini le, see Working with $MAC.ini Files.

2

Getting Started: Learning INI File Basics 7

IMPORTANT: The INI le processing hierarchy is as follows:

•Scenario 1 — WNOS.ini exists. The WNOS.ini le is processed and if the Include=$MAC.ini (or Include={username}.ini) statement is

included, then the relative MAC.ini (or {username}.ini) le is processed.

•Scenario 2 — WNOS.ini exists and {username}.ini exists. The WNOS.ini le is processed and if the Include=$MAC.ini statement is

included, then the MAC.ini le is processed. Once the credentials are provided, the {username}.ini le is processed.

•Scenario 3 — WNOS.ini exists and MAC.ini exists. The WNOS.ini le is processed and if the Include={username}.ini statement is

included, then the {username}.ini le is processed. Once the credentials are provided, the MAC.ini le is processed.

•Scenario 4 — No ini les exist. Local conguration is applied.

Working with wnos.ini Files

A wnos.ini le contains the global parameters you want that will aect all thin clients accessing the server. Parameters in both Table 4:

Connection Settings: wnos.ini les only, and Table 7: Connection Settings: wnos.ini les, {username} INI, and $MAC INI Files can be used in

a wnos.ini le.

NOTE:

Parameters in Table 4 can only be used in a wnos.ini le; they cannot be used in a {username}.ini le.

Working with $MAC.ini Files

A $MAC.ini le can be used for device-specic congurations. If the thin client locates a wnos.ini le, then the wnos.ini le is processed and

if the Include=$MAC.ini statement is included, then the $MAC.ini le is processed. The $MAC.ini le is stored in the same directory as a

wnos.ini le if you are not using a WNOS.INI le, otherwise the les should be stored in the INC directory.

NOTE:

The placement of the include=$MAC.ini parameter within the wnos.ini le will dictate which value will take priority for a same specic

parameter that is contained in both the wnos.ini le and the $MAC.ini le but is dened dierently, that is dierent values for the same

parameter.

For example, if the wnos.ini le has parameterA=valueRED, and the $MAC.ini le has the same parameterA=valueBLUE, then:

• If the include=$MAC.ini parameter is included in the wnos.ini le before the parameterA=valueBLUE statement, then the $MAC.ini

parameterA=valueRED is discarded and parameterA=valueBLUE from the wnos.ini le is the nal value used.

• If the include=$MAC.ini parameter is included in the wnos.ini le after the parameterA=valueBLUE statement, then the $MAC.ini

parameterA=valueBLUE is discarded and parameterA=valueRED from the wnos.ini le is the nal value used.

Working with {username}. ini Files

A {username}.ini le contains the user-specic or user prole parameters you want that will comprise the connection prole for an

individual user. These parameters will aect only the user you specify. Parameters in Table 5: General Settings for wnos.ini Files, {username}

INI, and $MAC INI Files

8Getting Started: Learning INI File Basics

NOTE:

User prole parameters found in the {username}.ini le, generally override the identically named global parameters found in the

wnos.ini le, however, some global parameters do not allow this. For hierarchical precedence of one variable over another, refer to the

parameter descriptions in Table 7: Connection Settings: wnos.ini les, {username} INI, and $MAC INI Files can be used in a

{username}.ini le.

If both PNAgent/PNLite and a user prole are being used in the environment, the username must be dened in the Windows domain,

and the password used must be the same for both the Windows domain and the user.

Rules and Recommendations for Constructing the INI

Files

In general, ThinOS INI les follow currently accepted standard INI le formatting conventions. The INI les consist of Wyse parameters. If

you are using an INI le, the only parameter you must use is the Connect parameter, see Connect in Table 5: General Settings for wnos.ini

Files, {username} INI, and $MAC INI Files. Any of the rest of the parameters can be used if you desire, but are not necessary unless you

want changes from client and other defaults, for example, other can be the default resolution of your monitor.

Every parameter (and their options) has a name and a value, with the name appearing to the left of the equals sign (name=value). All

parameters with the same name in the various INI les have the same meaning that is, a parameter named WyseXYZ in a wnos.ini le and

named WyseXYZ in a {username}.ini le will have the same meaning.

Number signs (#) indicate the start of a comment. Comments can begin anywhere on a line. Everything between the # and the End of Line

is ignored. Along with these general formatting conventions, use the following guidelines when constructing the INI les:

1Global Connect Parameters First

Global connect parameters should be listed before other connect parameters in a wnos.ini le.

2Connect is the Only Required Parameter

As stated earlier, if you are using an INI le, the only parameter you must use is the Connect parameter. Any of the rest of the

parameters can be used if you desire, but are not necessary unless you want changes from client and other defaults.

3Continue Lines by using a Space and Backslash

Placing a space and backslash ( \) at the end of a line indicates line continuation; that is, the backslash means that the line and the

following line are, for the purposes of reading code, the same line. No white space can appear after the backslash; the requirement of

white space between parameter entries is maintained by the use of the space before the backslash. In addition, starting all parameters

at the left margin and placing at least one leading space or tab at the beginning of all (and only) continuation lines makes an INI le

easier to read.

NOTE:

When you require string concatenation, you can use a backslash without a space before or after it to concatenate with the rst

set of characters from the previous line; for example the strings snow and ball may be concatenated to give snowball.

4Blank Lines Make Files Easy to Read

Using blank lines is recommended for making code easier to read.

5Comment by using a # Sign

Number signs (#) indicate the start of a comment. Comments can begin anywhere on a line. Everything between the # and the End

of Line is ignored.

6Values with White Spaces Require Quotation Marks

Getting Started: Learning INI File Basics 9

Values of parameters containing white spaces must be placed inside quotation marks. We recommend you use common-practice

nesting rules.

7Separate Lists by using Semicolons or Commas

Use semicolons or commas for list separators.

8{username}.ini Files must be Write-Enabled

All {username}.ini les must be write-enabled to allow the thin client to place the encrypted user passwords in the les.

9Use the wnos.ini File to Set the Maximum Number of Connection Entries Allowed

The combined number of connection entries dened in a {username}.ini le and a wnos.ini cannot exceed a dened total maximum

number of connections. The maximum number of connections has a default limit of 216, but can be set from 100 to 1000 using the

wnos.ini le.

10 Use of the {username}.ini and {mac}.ini Parameters

The {username}.ini and {mac}.ini parameters can appear in the wnos.ini le. However, these parameters must be below the include=

$un.ini parameter or the include=<$mac.ini or {username}> parameter in the wnos.ini le. Although not required, We recommend that

these parameters end with the parameter Exit=all.

NOTE:

No parameter should ever be executed twice. Some ThinOS hardware conguration parameters require a reboot to become

active, and if the same parameters are dened more than once, the thin client may then go into an innite reboot cycle.

IMPORTANT:

We recommend you place the include=<$mac.ini or {username}> statement on the last line of the wnos.ini le to verify that all

parameters are processed properly for terminal-specic settings.

11 Use of System Variables with Some Options of the Connect Parameter

Some options of the Connect parameter can use the system variables shown in Table 1: System Variables to map the string. All

combinations of the variables are supported. For options that support use of system variables, see Connect Parameters Options.

System Variables

Table 1 contains the System Variables you can use with some options of the Connect Parameter:

Table 1. System Variables

Option Value

$SN Serial number used.

$MAC MAC address used.

$IP IP Address used.

$TN Terminal name.

$PF Platform name—The rst part of image name xxx_wnos, for

example, R10L.

$UN Sign-on name used.

$PW Sign-on password used.

$DN Sign-on domain name used.

10 Getting Started: Learning INI File Basics

$FIP IP address used in xed format with 3 digits between separators,

for example, 010.020.030.040.ini. Using it in conjunction with the

left/right modier helps to dene policy for subnet.

For example, include=&Left($FIP,11).ini is specied to include le

010.020.030.ini for subnet 010.020.030.xxx.

$WPUN PEAP/MSCHAPv2 username used (802.1x dependent).

$WPPW PEAP/MSCHAPv2 password used (802.1x dependent).

$WPDN PEAP/MSCHAPv2 domain used (802.1x dependent).

&Right($xx, i) or &Left($xx, i) Species whether the variable is to be read from left or right. The

$xx is any of the above parameters. The parameter i species left

or right oset digits.

Placing the INI Files into the Folder Structure on the

Server

If you have set up your environment to provide your thin clients running ThinOS with automatic updates and congurations as described in

Administrators Guide: Wyse ThinOS , you can use the following folder structure on your server under the C:/inetpub/ftproot folder, for

FTP or C:/inetpub/wwwroot folder, for HTTP or HTTPS and place your INI les and other necessary les inside the structure as noted.

This list describes the folder structure, starting with the root directory.

/wyse/ (Required) The root directory. It stores the wnos folder.

/wyse/wnos (Required) The main INI conguration folder. It stores the wnos.ini

le, {username}.ini le, $MAC.ini le, rmware, and the following

optional folders:

• bitmap folder

• cacerts folder

• font folder

• inc folder

• ini folder

• locale folder

• trace folder

/wyse/wnos/bitmap (Optional) The folder where you can place custom images you plan

to use.

/wyse/wnos/cacerts (Optional) The folder where you can place the CA certicates that

can be imported to a thin client.

NOTE:

Use the AddCerticate INI parameter in the wnos.ini le to

import the certicates to thin clients.

/wyse/wnos/font (Optional) The folder where you can place font les for languages

such as Chinese Simplied, Chinese Traditional, Japanese, and

Korean that require the le.

/wyse/wnos/inc (Optional) The folder where you can place the mac.ini les.

Getting Started: Learning INI File Basics 11

NOTE: The use of parameter Include=$mac.ini will load /

wnos/inc/mac-address.ini so that you can use inc in the

folder structure and use $MAC.ini.

/wyse/wnos/ini (Optional) The folder where you can place the {username}.ini les

and {group} folder.

/wyse/wnos/trace (Optional) The folder where you can place the trace les that you

can capture and play back.

IMPORTANT: Be sure to enable the parameter,

EnableTrace=yes.

12 Getting Started: Learning INI File Basics

Parameters for WNOS INI Files Only

This chapter provides the supported parameters that you can use in a wnos.ini le.

NOTE:

For information to help you construct and use the supported INI les, see Getting Started Learning INI File Basics.

Parameters in Table 4 can only be used in a wnos.ini le; they cannot be used in a {username}.ini le.

To increase usability such as relation to thin client dialog box equivalents, the supported parameters are separated into the following

categories:

•General Settings for wnos.ini Files Only

•Peripheral Settings for wnos.ini Files Only

•Connection Settings for wnos.ini Files Only

IMPORTANT:

The underlined value for a parameter is the default value. Some parameters also have options shown within brackets [ ]. If an option

has an underlined default value, that option and default value will automatically be used with the parameter; options without underlined

values can also be used if you want to, but are not automatically used with the parameter.

In addition, when using parameters and options, you can leave the default value or change it to another value shown. For example, in

the following case where:

ParameterX={yes, no}

[Option1={0, 1}]

[Option2={1, 2, 3, 4}]

If you use ParameterX, then Option1 and its default value 0 will automatically be used as Option1 has an underlined default value of 0.

You can still use Option2 if you want to, however, Option2 is not automatically used with the parameter as Option2 does not have an

underlined default value.

Topics:

• General Settings for WNOS.INI Files Only

• Peripheral Settings for wnos.ini Files Only

• Connection Settings for wnos.ini Files Only

General Settings for WNOS.INI Files Only

Table 2 contains the parameters used for conguring general settings. The underlined values are default values.

3

Parameters for WNOS INI Files Only 13

Table 2. General Settings: wnos.ini les only

Parameter Description

AutoLoad={0, 1, 2, 101, 102, 201, 202}

[LoadPkg={0, 1, 2}]

[AddPkg={pkg1_name, pkg2_name, …}]

[DelPkg={pkg1_name, pkg2_name, …}]

AutoLoad — Default is 1. Species the rmware update mode. The

following are the values and associated actions:

0 — Disables checking for image.

1— Enables forced rmware upgrade/downgrade process. This is

the default value.

2 — Enables comparison/non-forced upgrade process only.

101 — Enables rmware upgrade/downgrade process, but displays

a window with OK or Cancel button before the process with a note

of the version to downgrade or upgrade; displays a status complete

window.

102 — Enables rmware upgrade, but displays a window with OK

or Cancel button before the process with a note of the version to

upgrade; displays a status complete window.

201 — Enables rmware upgrade or downgrade process, but

displays a window with OK button before the process; displays a

status complete window.

202 — Enables rmware upgrade only, but displays a window with

OK button before the process; displays a status complete window.

The option LoadPkg species how to update the external packages.

If set to 0, this disables checking for packages. If set to 1 it enable

packages upgrade/downgrade process, and if set to 2, it enables

upgrade only.

If LoadPkg is not in the statement, it will inherit the value of

AutoLoad. For example, if the value is 0, and if AutoLoad=0, 1, and if

AutoLoad=1, 101 or 201, and 2 if AutoLoad=2, 102 or 202.

For example, if you set AutoLoad=1 LoadPkg=0, the rmware is

checked, but the packages are not checked. From ThinOS 8.3, the

external packages update mechanism is changed.

Some packages are default, and loaded according to value

of LoadPkg. For example RTME.

Some packages need additional parameter AddPkg to add. For

example, FR and TCX.The option AddPkg is for adding packages. It

depends on the value of LoadPkg.

The packages check comes after rmware check. The option

DelPkg is for deleting packages. It does not depend on the value of

LoadPkg. The packages specied in DelPkg are always deleted

when loading the ini le.

The value of AddPkg and DelPkg is one package name or a

package name list. For example, AutoLoad=1 AddPkg="FR, TCX"

DelPkg=RTME

NOTE: The AddPkg and DelPkg options depend on

platforms which supports external packages. So far only

Z/D and U class support it. The other legacy platforms

does not support it.

AutoPower={yes, no} Default is no.

14 Parameters for WNOS INI Files Only

or

Device=cmos AutoPower=(yes, no)

Yes/no option on how the system starts when the power is rst

applied to the thin client.

If set to yes, then the system starts itself without waiting for users

to press the power button. In cases where power was lost

unexpectedly and if the thin client was shut down properly before

power was lost unexpectedly, when the power is restored, the thin

client will be powered. This setting is useful in a kiosk environment.

Once an AutoPower statement is processed, it alters the behavior

of the thin client until a countermanding statement is processed.

The eect of an AutoPower=yes statement continues even if the

statement is removed from the INI le in which it was found.

Use of the AutoPower option does not interfere with performing a

user directed shutdown.

CCMEnable={yes, no}

[CCMServer=<server_address>]

[GroupPrex=<prex>]

[GroupKey=<hashkey>]

[MQTTServer=<mqtt_address>[:<mqtt_port>]]

[AdvancedCong={no, yes}]

[CCMDefault={no, yes}]

[Override={no, yes}]

Default is no.

CCMEnable — Yes/no option to enable the Cloud Client Manager

Agent.

CCMServer — Species a IP address or URL address for the

Cloud Client Manager server. Once specied, it is saved in the non-

volatile memory.

GroupPrex and GroupKey — The options GroupPrex and

GroupKey compose the Group Registration Key of the Cloud Client

Manager server. Once specied, it is saved in the non-volatile

memory.

NOTE:

The numbers before the dash on the Group Registration key

is the GroupPrex value and the characters to the right of

the Group Registration Key is the GroupKey value.

MQTTServer — Species a IP address or URL address for the

MQTT server and MQTT port after the : (colon). Once specied, it

is saved in the non-volatile memory.

AdvancedCong — Default is no. Yes/no option to enable the

Cloud Client Manager server and MQTT server elds in the GUI. If

AdvancedCong=yes is specied, the Cloud Client Manager server

and MQTT server elds in the Cloud Client Manager UI will be

enabled. See also PRIVILEGE parameters in General Settings for

wnos.ini Files, {username} INI, and $MAC INI Files.

CCMDefault — Default is no. Yes/no option to enable the

Congure Cloud management dialog will display during boot up. If

CCMDefault=yes is specied and both the CCMServer and

GroupKey are NULL, the Congure Cloud management dialog will

display during boot up. Input group code to connect to the default

Cloud Client Manager server and default MQTT server. The default

CCM server is https://us1.cloudclientmanager.com and default

MQTT server is us1-pns.cloudclientmanager.com.

Override — Default is no. Yes/no option to allow a groupkey from

the INI le to override the previous groupkey. If Override=yes is

specied, the groupkey from the INI le will override the previous

groupkey. The Groupkey can technically be applied in many places.

You can congure the group key in order of priority, that is, if #1 is

dened it will override #2. Groupkey priority policy is listed below:

1 Local GUI conguration or groupkey received from CCM in a

Group Change command

2Dened in INI le "ccmenable=yes groupkey=xxxx"

Parameters for WNOS INI Files Only 15

3 DHCP Option Tag #199

NOTE:

The Groupkey assigned in DCHP option #199 and INI

parameter are only used for rst time deployment, that is,

they only take eect if CCM is currently disabled or if CCM

is enabled but group-key is NULL.

If DCHP is dened and CCM is enabled or not NULL: The

CCM Group key in the DHCP is ignored since it is congured

manually in local UI or from CCM group change.

If INI is dened and CCM is enabled or not NULL: The CCM

Group key in the INI is ignored since it is congured manually

in local UI or from CCM group change.

IMPORTANT:

There is an exception in the logic above when the

'override=yes' option is used in INI le. This will make #2 take

priority over #1.

For example,

CCMEnable=yes CCMServer=xxx:8080

GroupPrefix=wlab GroupKey=TC-TEST-ENG

MQTTServer=xxx:1883 AdvancedConfig=yes

Override=yes

NOTE:

For detailed instructions on how to congure CCM in a

wnos.ini le to enable the CCM Agent on supported ThinOS

clients, refer to Knowledge Base Solution #23875, go to the

Knowledge Base at www.dell.com/wyse/knowledgebase and

search for 23875.

DefaultUser={username, $SYS_VAR} Species the default sign-on user. See Table 1: System Variables for

a list of system variables for $SYS_VAR.

DisableButton={no, yes}

[DisableRestart={yes, no}]

Default is no.

Yes/no option to disable the power button.

If you set the option DisableRestart=yes, the radio button Restart

the system in shutdown window is disabled. These settings are

saved permanently and the default value is no.

EnableCacheIni IMPORTANT: Supported on Wyse 3010 thin client with

ThinOS (T10) and Wyse 3020 thin client with ThinOS

(T10D) only.

EnableCacheIni is no longer supported and cannot be used on

platforms other than the Wyse 3010 thin client with ThinOS (T10).

On platforms other than the Wyse 3010 thin client with ThinOS

(T10), EnableCacheIni is replaced by the MirrorFileServer

parameter, see MirrorFileServer parameter in Table 2: General

Settings for wnos.ini Files Only. Use EnableCacheIni on Wyse 3010

thin client with ThinOS platform (T10) only. This is because there is

no local ash on Wyse 3010 thin client with ThinOS (T10) platform,

and the MirrorFileServer parameter is not supported on it.

EnableGKey={yes, no} Default is yes.

16 Parameters for WNOS INI Files Only

Yes/no option to enable G key reset. G key reset is supported for

Privilege=High in the NVRAM.

Exit={yes, no, all} Default is yes.

Species the INI le processing.

yes — Processing returns to the prior INI le on the next line after

$include.

no — There is no operation.

all — All INI le processing is exited.

Include=<$mac.ini le or {username}.ini le> <$MAC.ini> Loads /wnos/inc/mac-address.ini.

NOTE:

The le name does not include the symbol : in the mac

address. See also the Exit parameter for information on how

to terminate Include. <{username}.ini> Loads /wnos/inc/

{username}-address.ini.

The le name does not include the symbol : in the

{username} address. See also the Exit parameter for

information on how to terminate Include.

MirrorFileServer={no, yes} Default is no.

Yes/no option to enable the cache all server les functionality. This

enables the cache all server les such as INI les, wallpaper, bitmap,

font, local messages and so on to the local ash when les are

changed in the le server. ThinOS would use the cached les when

les on the le server are unavailable.

IMPORTANT: S10 is not supported

RootPath=<le server root path> This le server root path is entered into thin client local setup (non-

volatile memory). The thin client immediately uses this path to

access les. The directory name \wnos will be appended to the le

server root path entry before use.

TerminalName=<name>

[reboot={no, yes}]

TerminalName — Name of the client comprising a 15-character

string. It can also be congured with system variables. Basically all

the variables can be used except $TN (recursive), $UN, $PW, $DN.

However, these are not yet available when parsing wnos.ini.

Additionally combinations like xy$mac, sz$tnxyz etc are supported.

reboot — Default is no. Yes/no option to reboot the thin client if

the terminal name is changed.

TimeZone=<zone value>

[ManualOverride={no, yes}]

[daylight={no, yes}]

[start=MMWWDD end=MMWWDD]

[TimeZoneName=<timezonename>]

[DayLightName=<daylightname>]

TimeZone — Species the time zone if the zone is unspecied on

the thin client or is used with ManualOverride. Supported zone

values s are listed in the System Preference dialog box on the thin

client and in TimeZone Parameter: Values.

NOTE:

The TimeZone parameter is dependent on the

TimeServer=parameter. If a time server is not dened, the

client CMOS/BIOS internal clock will be used as a reference.

ManualOverride — Default is no. Yes/no option to override the

thin client System Preference Menu setting with this TimeZone

Parameters for WNOS INI Files Only 17

setting. TimeZone settings in the wnos.ini le will be saved into

NVRAM if EnableLocal=yes is set in the wnos.ini le.

Daylight — Default is no. Yes/no option to enable daylight saving

time; MMWWDD is a 6 digit number to specify the start and the

end of daylight saving time.

IMPORTANT: The Start and End options are in the

MMWWDD format, where:

MM = Month of the year. Values are 01 to 12 for the months

of the year from January to December. For example, 01 =

January, 12 = December

WW = Week of the Month. Values are 01 to 05 for the week

of the month, 05 is the last week. For example, 01 = 1st

week, 05 = the last week of the month.

DD = Day of the week. Values are 01 to 07 for the day in the

week from Monday to Sunday. For example, 01 = Monday, 07

= Sunday.

NOTE:

For the 2013 year, DST dates are Sunday, March 10, 2:00am

and ends Sunday, November 3, 2:00am.

TimeZoneName — Display name sent to the ICA/RDP

session such as Eastern Standard Time.

DayLightName — Display name for daylight saving time. If

daylight saving time is enabled, DayLightName should be

named something similar to Eastern Daylight Time, otherwise

it should be the same as TimeZoneName.

NOTE:

To congure daylight saving time for an RDP session, you

must enable the Allow Time Zone Redirection function. Use

the following guidelines:

1 Run gpedit.msc to open the Group Policy dialog box.

2 Click Computer Conguration in the Local Computer

Policy tree, and expand the Administrative Templates

folder.

3 Expand the Windows Components folder, and then

expand the Terminal Services folder.

4 Click Client/Server data redirection to open the

Setting list.

5 Right-click Allow Time Zone Redirection and select

Properties to open the Allow Time Zone Redirection

Properties dialog box.

6 Select the Enabled option, and then click OK.

7 Close the Group Policy dialog box.

Overall Example:

TimeZone="GMT – 08:00"

ManualOverride=yes Daylight=Yes

Start=030107 End=110107

TimeZoneName="Pacific Standard Time"

DayLightName="Pacific Daylight Time"

18 Parameters for WNOS INI Files Only

Peripheral Settings for wnos.ini Files Only

Table 3 contains the parameters used for conguring peripheral settings such as keyboard, monitor, mouse, and printer. The defaults values

are underlined.

Table 3. Peripheral Settings: wnos.ini les only

Parameter Description

DEVICE_SECURITY=white_list/black_list

vid_pid=[vvvv,pppp]

class=name/[cc,ss,pp]

1 When DEVICE_SECURITY=white_list is set, the security is in

high level, and you need to add all the devices (on board

devices including Wyse 3020 thin client with ThinOS (T10D)'s

netcard, and internal hub) to the list that you want to use, and

all other devices are denied when the device is plugged-in.

2 When DEVICE_SECURITY=black_list is set, the security is

mid-level, and customer can add the device which is not

present in the list.

3 About key value: all the value are hex, and vid_pid =

0xvvvvpppp, class value is =0xccsspp; where,

• vvvv=device vendor id

• pppp=device product id

• cc= device interface class

• ss=device interface subclass

• pp=device interface protocol

4 Class name is abbreviation for the dened class. Valid names

are listed here:{Audio, CDC_control, HID, Pysical, Image,

MASS_STORAGE, Hub, CDC_Data, Smart_Card,

Content_Security, Video, Personal_Healthcare,

AudioVideo, Billboard, Diagnostic_Device,

Wireless, Miscellaneous, Application, VendorSpecic}. For

detailed information, refer: www.usb.org/developers/

dened_class.

5 The max number of devices/class table is 16.

For Example:

DEVICE_SECURITY=white_list class=HID class=Audio

class=Video

DEVICE_SECURITY=black_list vid_pid=0x0B0E2000

class=0x030101.

PrinterMap=a text le name or possibly URL. A text le to be included to dene printer mappings. Each line in the

le is of format Printer Identication=Printer Driver Name. For

example: HL-1240 Series=HP LaserJet.

ThinPrintEnable={no, yes}

[Port=port number]

Default is yes.

ThinPrintEnable — Yes/no option to enable the thinprint client.

port—The TCP port of the thinprint client. The default port

number value is 4000. The port number value must be less than

65535.

Connection Settings for wnos.ini Files Only

Table 4 contains the parameters used for conguring the connection settings. The default values are underlined.

Parameters for WNOS INI Files Only 19

Table 4. Connection Settings: wnos.ini les only

Parameter Description

AddCerticate=lename

password={plain text password}

Password-enc={encrypted password}

AddCerticate — Species a certicate le residing in the

subfolder cacerts under the wnos folder to load on platforms with

nand ash, or on the memory. The length of the lename, including

the trailing period and the le extension, is limited to 64 characters.

AddCerticate must be used when conguring the Citrix Secure

Gateway PNAgent Interface (PNAgent/Lite servers) in the

Network Setup dialog box.

Adding certicates are required if the user CSG environments use

certicate agents that are not covered by the built-in certicates.

The certicates are used to validate server identities by the thin

client. Supported les include .crt le on ICA CSG; .cer and .pfx in

802.1x. Password and Password-Enc are specially used with PFX

les.

CaradigmServer=vip list

[EGPGroup=group name]

[EnableLogO={yes,no}]

[SecurityMode={default, full, warning, low}]

CaradigmServer=vip list contains a list of VIP addresses with

optional TCP port number of Caradigm servers. EGPGroup denes

the user group name. If EnableLogO=yes is specied, the user is

logged o from the session before system signs o. Otherwise the

session is disconnected. The logged o user has a timeout value

which can be set using SessionCong parameter

SessionLogOTimeout.

The default timeout value is 1, if no SessionLogOTimeout is

specied.

SecurityMode species the SSL certication validation policy.

If set to default, it applies the SecurityPolicy setting.

If set to full, the SSL connection needs to verify server certicate.

If it is untrusted, drop the connection.

If set to warning, the SSL connection needs to verify server

certicate.

If it is untrusted, it is up to you to continue or drop the connection.

If set to low, the server certicate is not checked. The value is

persistent, the default value of the setting is default.

Community=community

[Encrypt={yes, no}]

Species the SNMP community name. A string up to 31 characters

are allowed. After the value is specied, it is saved in the non-

volatile memory.

If encrypt=yes, an encrypted string is used as a community name.

The default value is set to no.

NOTE: Use our Windows Password_Gen tool or built-in

tool to generate the encrypted string.

ConnectionBroker={default, VMware, Microsoft, Quest, AWS}

[IgnoreProle={yes, no,}]

[SecurityMode={Default,Low,Warning,Full}]

[EnableVWGateway]={yes, no}

Default value is default. Species the type of VDI broker to use.

Default is a 3rd party VDI broker.

AWS is Amazon Workspace broker. It is only available with PCoIP

build.

IgnoreProle — Default value is no.

20 Parameters for WNOS INI Files Only

[VWGateway]=url

[ConnectionType]={Default, All, RDP, PCoIP}

Set IgnoreProle=yes to disable parsing the global setting from the

VDI broker. It is only valid in the case of ConnectionBroker=default.

SecurityMode — SecurityMode species the security mode for

the VMware broker and Amazon Workspace (AWS) broker. It is only

valid in case of ConnectionBroker=VMware or

ConnectionBroker=AWS. The details is as follows:

• Set SecurityMode=Full to have the Client verify the server's

certicate in highest security mode; if any relevant checks error,

it will fail to connect to the server.

• Set SecurityMode=Warning to have the Client allow connection

continuation in the following two specic exceptions where full

verication would fail:

aCerticate is self-signed.

bCerticate has an invalid time.

• Set SecurityMode=Low to indicate that Client allows

connection without any certicate verication.

• Set SecurityMode=Default to indicate that Client follows the

SecurityPolicy setting to verify the certicate.

NOTE:

For Dell vWorkspace broker, ConnectionBroker=Quest is

recommended.

EnableVWGateway and VWGateway are used to set the

vWorkspace gateway.

For VMware broker, ConnectionBroker=VMware is

recommended. ConnectionBroker=VDM is still supported but

deprecated.

The option ConnectionType species the display protocol that you

want to use when launching a session in VMware broker. If this

parameter is set, then the desktops that meet the specied

protocol are listed after broker sign on.

This setting is only valid in case of PCoIP feature is supported.

• Set ConnectionType=Default, only the desktops with the

default protocol congured in broker server are listed (this is the

default value for this setting).

• If you set ConnectionType=All, both PCoIP and RDP desktops

are listed.

• If you set ConnectionType=RDP, only RDP desktops are listed.

• If you set ConnectionType=PCoIP, only PCoIP desktops are

listed.

DelCerticate={lename, all, builtin} lename — Removes the named le from the nand ash or from

the memory.

all — Removes all certicates except built-in certicates included

by default.

builtin — Removes all certicates including the public certicates

included by default.

DesktopColorDepth={16, 32}

[RGB565={no, yes}]

DesktopColorDepth — Sets the desktop color to 16 or 32 bits. If

DesktopColorDepth=16, the default color is 15 bits.

Parameters for WNOS INI Files Only 21

RGB565 — Default isno. Applies only if the desktop color is using

16 bits.

IMPORTANT:

If the RBG565 parameter value is changed to yes, the thin

client will require a reboot.

DHCPExpire={reboot, shutdown} Default is reboot.

When a DHCP lease expires, a message noties the user as follows:

DHCP Expired, you must reboot.

reboot — After 5 seconds, the system reboots.

shutdown — After 5 seconds, the system shuts down.

DHCPOptionsRemap={no, yes}

[DisableOption12={no, yes}]

[FileServer={128 to 254}]

[RootPath={128 to 254}]

[FtpUserName={128 to 254}]

[FtpPassWord={128 to 254}]

[RapportServer={128-254}]

[RapportPort={128-254}]

[WDMServer={128 to 254}]

[WDMPort={128 to 254}]

[PnliteServer={128 to 254}]

[DomainList={128 to 254}]

[VDIBroker-{248 to 254}]

[RapportSecurePort={128-254}]

[Discover={yes, no}]

[WDMSecurePort={128 to 254}]

[WDMFQDN={128-254}]

[CCMGroupKey={128-254}]

[CCMServer={128-254}]

[CCMMQTTServer={128-254}]

Default is no.

DHCPOptionsRemap — Species whether or not the following

options can be set.

The value for each option must be from 128 to 254. Values for the

options must be dierent for each option. These options are used

to congure DHCP server tags for thin client booting.

The option DisableOption12 sets if the option tag 12 in DHCP is

accepted or not. As default, DHCP option 12 sets the hostname

and domain name of the terminal. For example, the information of

option 12 is terminal name.wyse.com, the terminal name will be set

as terminalname and the domain name will be set as wyse.com.

If you set dierent value for DisableOption12 from the value in

NVRAM, the system will automatically reboot to make the value

valid. (CIR36891)

RapportSecurePort— Species the HTTPS port of WDM server.

It is in 6.3 to support WDM4.7.

Discover—If Discover=yes, the device fetches Wyse DHCP

options from DHCP server, otherwise, it prevents the device from

fetching those information. Default value is yes. If the device

receives FileServer/WDMServer information through the DHCP

server, then the associate User interface is protected.

NOTE:

WDMSecurePort is the specied HTTPS port of the WDM

server.

WDMSecurePort—Species the HTTPS port of WDM server.

WDMFQDN — Species the Fully Qualied Domain Name (FQDN)

of the WDM server.

NOTE: The CCMGroupKey, CCMServer and

CCMMQTTServer options are specied to remap the tags

for CCM conguration.

DHCPUserClassID=class_id

[ParseVendorInfo={no, yes}]

DHCPUserClassID — Species the UserClassID used for DHCP.

ParseVendorInfo — Default is yes. Yes/no option to specify

whether or not ThinOS will interpret DHCP option 43.

22 Parameters for WNOS INI Files Only

This is a vendor-specic information. If ParseVendorInfo is set to no

and the DHCPVendorID is also used with this parameter, you must

set ParseVendorInfo=yes and then reboot the thin client twice.

Maximum of 26 characters are allowed in a string.

DHCPVendorID=vendor

[ParseVendorInfo={no, yes}]

DHCPVendorID — Species the VendorID used for DHCP.

ParseVendorInfo — Default is yes. Yes/no option to specify

whether or not ThinOS will interpret DHCP option 43.

This is a vendor-specic information. If ParseVendorInfo is set to no

and the DHCPVendorID is also used with this parameter, you must

set ParseVendorInfo=yes and then reboot the thin client twice.

Maximum of 26 characters are allowed in a string.

DisableDomain={no, yes} Default is no.

Yes/no option to disable the drop-down domain list in the

PNAgent/PNLite Sign-on dialog box.

DNSIPVersion={ipv4, ipv6}

[DNSServer=server_list]

[DNSDomain=dns_domain_url]

Species the DNS server and domain. Default IP version is ipv4.

The DNSServer is an IP list separated by ; or ,. The maximum size

of this list is 16. For example: 10.200.5.53;192.168.100.1;192.168.200.8

IMPORTANT: There is no space after the ;.

DNSTTL={0-3600} Species the Time to Live (TTL) of DNS name caching; the default

is from DNS server settings.

NOTE:

If DNSTTL=0, the DNS hostname in a connection always

queries the DNS server to get the IP.

DomainList=List of NT domain names A list of domain names that will appear in the thin client Sign-on

dialog box as options to help users in selecting the domain to sign-

on to PNAgent/PNLite servers. Once specied, it is saved in non-

volatile memory.

NOTE:

Be sure to enclose in quotation marks if spaces are included.

For example: DomainList=North_America, SQA, test-domain

Dualhead={no, yes}

[ManualOverride={no, yes}]

[Mainscreen={1, 2}]

[Orientation={hort, vert}]

[Align={Top|Left, Center, Bottom|Right}]

[Taskbar={wholescreen, mainscreen}]

[MonitorAutoDetect={yes,no}]

[Swap={no, yes}]

Default is no.

Dualhead — Yes/no option to support a dual-monitor display.

Default no sets monitors to mirror mode; yes sets monitors to span

mode.

ManualOverride — Default is no. Yes/no option to allow the local

client to override display dualhead settings received from central

conguration.

If reset to factory defaults, it will once again take server settings for

dualhead. This is helpful for scenarios where you have a mixture of

dual head and single head deployments.

Parameters for WNOS INI Files Only 23

For example:

Dualhead=yes

ManualOverride=yes Mainscreen=1 \

Orientation=hort

Taskbar=mainscreen

NOTE:

If using, be sure the ManualOverride option is the rst option

used after the Dualhead parameter position in the statement.

Mainscreen — Sets which screen is used as the main screen.

When using a DVI to DVI and VGA cable, the DVI connected

monitor will be the default mainscreen=1.

Orientation — Default is hort. Sets which style is used for display.

Hort means horizontal and vert means vertical.

Align — Sets how screens are aligned: Top means screens are top

aligned in hort orientation. Left means screens are left aligned in

vert orientation.

Center means screens are center aligned. Bottom means screens

are bottom aligned in hort orientation. Right means screen are right

aligned in vert orientation.

Taskbar — Default is wholescreen. Sets which style is used for the

taskbar: wholescreen places the taskbar at the bottom of the entire

screen; mainscreen places it at the bottom of the main screen. This

is only when SysMode=Classic and has no eect on VDI mode.

MonitorAutoDetect — Determines whether or not the system will

detect how many monitors are connected. If only one monitor is

connected, Span mode will be transferred to Mirror mode.

Swap — Default is no. Yes/no option to use with older ThinOS 7.x

builds to swap dual monitors when Mainscreen=2 is set. Swap=yes

puts monitor 2 on the left or top of monitor 1 according to the

orientation.

For example, if you want a standard dual screen layout you would

use:

DualHead=Yes \

Mainscreen=1 \

Orientation=Hort \

Taskbar=Mainscreen \

Align=Center

Screen=1 Resolution=DDC Refresh=60 Rotate=None

Screen=2 Resolution=DDC Refresh=60 Rotate=None

EnableRAVE={yes, no} Default is yes.

Yes/no option to enable the client to use Citrix Multimedia

Acceleration (RAVE) to play supported media les residing on an

ICA server. This is a global parameter for all ICA connections.

EnableRAVE=yes is default.

24 Parameters for WNOS INI Files Only

NOTE:

If EnableRAVE=no or this parameter is not present, the TCX

Multimedia will be used for all media les. If

EnableRAVE=yes, RAVE will be used only for media les it

supports.

EnableRAVE=yes is ignored unless a valid TCX Multimedia

license is used.

FileServer=List of {IP address, DNS name}

[Username=username]

[Password=password]

[SecurityMode={Low, Warning, Full, default}]

FileServer — Species the FTP or Web (http://) server IP address

or DNS name that is entered into thin client local setup (non-volatile

memory); the thin client immediately uses this server to access

les.

Username — Species the username of the le server.

Password — Species the password of the le server.

NOTE:

The target le server must support access using the same

user credentials used in the INI les.

The optional keyword Username and Password specify the

username/password of the le server. When the client fetches the

WNOS.INI le from a HTTPS server, ThinOS supports dierent

security modes. The default follows SecurityPolicy and may be one

of the three modes. The option SecurityMode species these

security modes.

SecurityMode — Species the security level for the le server

during client verication of the server certicate. This option is only

valid when connecting to an https le server.

When conguring the https le server, the Username and

Password options of the FileServer parameter can be omitted. Use

the following guidelines:

• Set SecurityMode=Full to have the client verify the server

certicate in highest security mode; if any error occurs during

verication, the client will not connect to the server and a pop-

up message is displayed.

• Set SecurityMode=Warning to have the client provide a

warning when the client cannot verify the server certicate, but

still allow the user to select to continue client connection to the

server.

• Set SecurityMode=Low to indicate that the client allows

connection without any certicate verication.

• Set SecurityMode=Default to indicate that the client follows

SecurityPolicy settings to check certicate.

• Default value of the setting is Default. If the settings are factory

default or if you are upgrading to ThinOS 8.3 for the rst time,

the value is temporarily set to None. After loading any INI, it

goes to default.

• If the security mode value in WNOS.INI is not the same as the

one saved in Client NVRAM, client shows a reboot dialog box.

Parameters for WNOS INI Files Only 25

NOTE: Security process includes:

1Verication that certicate has a valid date

2Verication that Issuer is valid and correct

3Certicate verication passes

4 CN and SAN on the certicate matches the DNS

naming

For Example: FileServer=https://10.151.122.66:444

SecurityMode=warning

FormURL=URL to a le Species the URL to the name of a bitmap le (.ico, .bmp, .jpg,

or .gif), to be displayed in the sign-on window, residing under the

thin client home directory. The length of the path, including the

home directory and the le, is limited to 128 characters. If auto dial-

up is enabled, this statement is invalid.

INACTIVE=minutes

[NoSessionTimer=minutes]

Default is 0. There is no Idle timeout. The range is 0 minutes to 480

minutes.If the value given is bigger than 480, 480 is set instead. If

the value given is smaller than 0, 0 is set instead.

When the system idle is time out in the congured minutes, the

system will automatically sign o, reboot or shutdown which are

based on the setting of AutoSigno.

The parameter NoSessionTimer has the same range as INACTIVE

and it is valid only if INACTIVE value is not 0. If there is a session

use the value of Inactive, otherwise use the value of

NoSessionTimer, if NoSessionTimer is congured.

If AutoSigno=yes Shutdown=yes is congured, then this

statement can work before signon.

If AutoSigno=yes Reboot=yes is congured, this statement can

work before signon.

LongApplicationName={no, yes} Default is no.

Yes/no option to display all 38 characters in a desktop icon name. If

LongApplicationName=no, then icons will display up to 19

characters; any over 19 characters and the last three characters will

be “…”.

MaxVNCD={0, 1}

[VNCD_8bits={yes,no}]

[VNCD_Zlib={yes, no}]

Default is 0.

Option to enable VNC shadowing. Default value is 0 means VNC

shadowing is disabled. Set to 1 to enable shadowing.

NOTE:

Only one VNC client session is allowed and a password is

required.

See also VNCPrompt in Table 7: Connection Settings: wnos.ini les,

{username} INI, and $MAC INI Files to enable a VNC shadowing

prompt to a user.

See also VncPassword in Table 4: Connection Settings: wnos.ini

les only to specify a string of up to 8 characters as the password

used for shadowing.

VNCD_8bits — Default is yes. Yes/no option to force the VNC

server to send out images with 8-bits-per-pixel; if set to no, the

26 Parameters for WNOS INI Files Only

VNC server will send out images with the current system color

depth.

VNCD_Zlib — Default is no. Yes/no option to allow the VNC server

to send data with Zlib compression.

MMRCong={VIDEO}

[ashingHW={0, 1}]

This parameter species whether to show the “HW” label at the

top left corner of video or not when HDX is hardware decoded. The

default value is 0. Set ashingHW to 0, if you want to hide HW. Set

ashingHW to 1, if you want to show HW.

Multifarm={no, yes} Default is no.

Yes/no option to support Citrix multifarm functionality for the

wnos.ini les. If Multifarm=yes, PNAgent/PNLite users are able to

authenticate to more than one Citrix farm.

MultiLogon={no, yes}

[SequentialDomain={yes, no}]

Default is no.

Yes/no option to support multiple log ons. If MultiLogon=yes, the

PNAgent/PNLite sign-on authenticating window can input a

dierent username, password, and domain while signing on to

dierent PNAgent/PNLite servers.

For backward compatibility, the following format is supported:

MultiLogon=yes

PNAgentServer=10.1.1.30;10.2.2.60

The SelectServerList statement is also supported:

MultiLogon=yes

SelectServerList=pna \

description=store host=http://proper-storefront-url.ctx.com

description="Floor 3" host=10.1.1.30 \

description=""Floor 1" host=10.2.2.60 \

description="All Users" host=10.3.3.90

NOTE:

The SelectServerList takes precedence over

PNAgentServer. The PNA server description or name can be

displayed on the signon window so that the user knows

which and what server is logging on. See also

SelectServerList={PNA, VDI} in Table 4: Connection Settings

for wnos.ini Files Only.

If SequentialDomain=yes is specied, the domain congured in

DomainList statement is selected in order.

For example, set the following ini:

DomainList="xen;wyse" multilogon=yes sequentialdomain=yes

pnagentserver=10.151.134.23; https://csg-cn.wyse.com.

When you logon to the rst server 10.151.134.23, the domain xen is

selected. Then logon to the second server https://csg-

cn.wyse.com and the domain wyse is selected.

Parameters for WNOS INI Files Only 27

NoticeFile=lename

[Resizable={no, yes}]

[Timeout={0, 10 to 600}]

[Title="notice_title"]

[ButtonCaption="button_caption"]

NoticeFile — Species a legal notication le residing in the home

directory folder. The le is displayed in a dialog box and the user is

prompted to accept it before the sign-on process continues.

Resizable — Default is no. Yes/no option to resize the dialog box

to t the text size.

Timeout — Default is 0. After the notice is accepted, if Timeout is

specied in seconds, and if no mouse or keyboard is used, then the

dialog box will display again after the seconds set. 0 means no

timeout.

Title and ButtonCaption — Species the notication window title

and button that can be customized. For example,

NoticeFile=filename Title=Problem

ButtonCaption=Ok

OneSignServer=onesign_server

[DisableBeep={yes,no}]

[KioskMode=yes,no}]

[TapToLock={0,1,2}]

[EnableWindowAuthentication={yes,no}]

[AutoAccess={VMW,XD,XA,LOCAL}]

[NetBIOSDomainName={yes,no}]

[SuspendAction={0, 1}]

[DisableHotKey={yes,no}]

Loglevel=0/1/2/3

[DisablePromptToEnroll={yes,no}]

[SecurityMode={default, full, warning, low}]

A list of host names or IP addresses with optional TCP port number

or URLs of Imprivata OneSign servers. It should use https

protocol. If OneSignServer="" is dened, then only imprivata virtual

channel can work.If DisableBeep is set to yes, then Rdeas reader

can be set to mute when a card is tapped. Default is no.

If KisokMode is set to yes, then dierent OneSign user can unlock

the client desktop. Default is no. Optional keyword TaptoLock is

only active when KioskMode=yes.

• If TapToLock=0, then tap a card to lock terminal is disabled.

• If TapToLock=1(Tap to lock), then use the proximity card to lock

the terminal.

• If TapToLock=2(Tap over), then lock the terminal and log in as a

dierent user. Default is 2.

If EnableWindowAuthentication is set to yes and OneSign signon

fails, then continue to sign-on with windows credential to pre-

dene broker. Default is yes.

If AutoAccess is dened, then auto launch the corresponding type

of broker. Otherwise, get the broker type from the Imprivata Server

setting of computer and user policy. If none of them is dened,

then launch the rst available broker server from the Imprivata

server.

If AutoAccess=LOCAL is set, then launch the broker from the

ThinClient setting; the broker getting from the Imprivata Server is

ignored.

NOTE: AutoAccess can be set in [username].ini and

wnos.ini. The wnos.ini has priority over [username].ini.

If NetBIOSDomainName is set to yes, then Imprivata domain list will

show NetBIOS domain name and card user will authenticate to the

broker server using NetBIOS domain name. Default is no.

If SuspendAction is set to 0, then lock the terminal when you tap

the card or press the hotkey. If set to 1, then signo the terminal. If

‘no’ is dened, then lock the terminal in KioskMode and sign-o the

terminal in none KioskMode.

If DisableHotKey is set to yes, then no action when you press the

hotkey dened in Imprivata Server. Only WebAPI 4 and later

versions support the hotkey function.

Loglevel—While conguring the Imprivata server, user can view the

OneSign logs on ThinOS by enabling the Agent Logging feature. An

28 Parameters for WNOS INI Files Only

ini conguration is needed correspondingly. Default value is 0. If set

to 0, logs are not displayed.

If DisablePromptToEnroll is set to yes, then ThinOS does not

prompt you to enroll their security answers after OneSign sign-on.

Default value is yes.

SecurityMode species the SSL certication validation policy. If set

to default, it applies SecurityPolicy setting. If set to full, the SSL

connection needs to verify server certicate. If it is untrusted, drop

the connection. If set to warning, the SSL connection needs to

verify server certicate. If it is untrusted, it is up to you to continue

or drop the connection. If set to low, the server certicate is not

checked. The value is persistent, and the default value of the

setting is default.

PasswordServer=password_server

[AccountSelfService={yes, no}]

[connect={ica, rdp}]

[encryption={Basic, 40, 56, 128,

Login-128, None}]

Specify an ica/rdp server that can be used to log on to modify

password when you sign-on with password timeout.

The PasswordServer statement can specify the connection

parameters as described in the Connect statement. If no parameter

is specied, it connects with ICA protocol.

AccountSelfService — Yes/no option to dene the password

server as an Account Self Service server.

If AccountSelfService=yes follows PasswordServer, click the icon

on the signon window to do account self-service.

If Connect parameters do not follow AccountSelfService=yes, this

password server will be the account self-service server of Citrix

and clicking the icon will use Citrix protocol to unlock or change

password for an account.

If Connect parameters follow AccountSelfService=yes, clicking the

icon launches a session to change password for an account.

PCoIP_Logging={yes, no}

[Broker_Logging_Level={0,1,2,3,4}]

[Session_Logging_Level={0,1,2,3,4}]

The option PCoIP_Logging can enable and disable the PCoIP client

logs output in Trouble Shooting. If you set the value to yes, then it

is same as selecting the Trouble Shooting Capture Export PCoIP

Log radio button to persistent and no to none.

The option Broker_Logging_level and Session_Logging_Level

accord to PCoIP broker log level and PCoIP session log level. The

default value is 0 which means critical log, 1 means log severity

error, 2 means log severity info, 3 means log severity debug, and 4

means log severity unrestrained.

PlatformCong=all

[EncryptFS=yes]

Encrypts local ash, specically cached INI les and credentials that

are stored, if using signon=yes.

NOTE:

Event log will display new statements stating that FileSystem

encryption has been enabled.

PlatformCong=”C/V/S/R/T Class”

[Firmware={Firmware lename}]

[BIOS={BIOS lename}]

[ECFirmware={EC lename}]

If a specic platform is specied by the PlatformCong parameter,

then ThinOS will attempt to load the Firmware and BIOS whose

lenames are specied by the Firmware and BIOS parameters.

If the written Firmware and BIOS are valid on le server, they will be

loaded by default; if the written Firmware and BIOS are invalid on

le server, ThinOS will load the platform default Firmware and BIOS

instead.

Parameters for WNOS INI Files Only 29

For example: If you re-name the Wyse 3010 thin client with ThinOS

(T10) rmware le from DOVE_boot to DOVE_boot_8.0_037., then

you must use platformcong-="T Class", then add

Firmware=DOVE_boot_8.0_037.

ThinOS will look on the le server for this exact rmware name. If

that dened rmware name is not found, then ThinOS will fall back

to the default logic and look for the DOVE_boot rmware.

ECFirmware is only used for Wyse 3010 thin client with ThinOS

(T10)/X10J/X10CJ to update EC rmware, it is not supported on

other platforms.

C: C10LE V: VL10

S: S10 R: R10L

Wyse 3010 thin client with ThinOS (T10)

If the ECFirmware le name is not specied, device will look for EC

with default name: T10: T10_EC.bin

Proxy={yes, no}

AppList={ccm;fr}

[Type={Global, http, https, socks5}]

[Server=_host_port_]

[User=_user_name]

[Password=_password_]

[Encrypt={yes, no}]

Species the proxy settings which are saved in non-volatile

memory. If Proxy=no, all proxy settings are cleared and all

the followed options are ignored.

If Proxy=yes, the option AppList must be followed. It species

which applications are applied to connect via proxy. Both CCM and

FR are supported. The application name is separated with

semicolon.

The following options are used to congure one or several proxy

server setting. The option Type species the proxy protocol

including http, https and socks5. The option Server species the url

of the proxy server. The option User and Password specify the

credentials of this proxy server. The option Encrypt species if the

password is encrypted or not.

The option User and Password can support system variables.

Because CCM runs before sign on, it is not appropriate to use $UN

and $PW.

If Type=Global, the proxy settings are saved into http proxy setting,

and the https and socks5 proxy settings use the same setting as

http proxy. And the followed proxy settings will be ignored.

For example,

Proxy=yes AppList=fr \

Type=http Server=server1:1234 user=$UN password=$PW

(OR)

Proxy=yes AppList=ccm \

Type=http Server=server1:1234 user=abc password=xyz \

Type=socks5 Server=server2:4321 user=abc password=1234

(OR)

Proxy=yes AppList=ccm;fr \

Type=Global Server=server_global user=user_global

password=password_global_encrypted Encrypt=yes

30 Parameters for WNOS INI Files Only

RapportDisable={yes, no}

[DHCPinform={yes, no}]

[DNSLookup={yes, no}]

[QuickMode={yes, no}]

[Discover={yes, no}]

[SecurityMode={default, full, warning, low}]

Set to yes to disable the Rapport agent.

If RapportDisable=no, the Rapport agent is enabled and you can

discover the WDM server by the following ways:

1 The DHCP option tag values received from standard or WDM

proxy DHCP service for vendor class RTIAgent

2 DNS service location record "_wdmserver._tcp"

3 DNS host name lookup "wdmserver"

If RapportDisable=no, set DHCPinform=yes to perform the WDM

server discovery as mentioned in number 1; set DNSLookup=yes to

perform the WDM server discovery as mentiomned in number 2

and 3.

If QuickMode=yes is specied, rapport agent will not block any

other process during ThinOS boot up, and boot time of ThinOS will

speed up.

NOTE: If le server is changed by WDM server, device will

reboot automatically to make sure all settings from WDM

server take eect. Default is yes.

Discover— If Discover=yes is specied, rapport discovers the

WDM server information from DHCP option tag, DNS service

location record and DNS host name. If the WDM server is

discovered, the WDM server User Interface (UI) is protected on the

device. The default value is yes.

SecurityMode species the SSL certication validation policy. If set

to default, SecurityPolicy setting is applied.

If set to full, the SSL connection needs to verify server certicate.

If it is untrusted, drop the connection.

If set to warning, the SSL connection needs to verify server

certicate. If it is untrusted, it is up to you to continue or drop the

connection.

If set to low, the server certicate is not checked. The value is

persistent, and the default value of the setting is default.

If the settings are factory default or if you are upgrading to ThinOS

8.3 for the rst time, the value is temporarily set to low. After

loading any INI, it goes to Default value.

RapportServer=server_list

[Retry=]

IMPORTANT:

DISCONTINUED. DO NOT USE. Use WDMServer

parameter, see WDMServer=<server_list> in Table 4:

Connection Settings for wnos.ini Files Only.

Reboot | shutdown={no, yes} Time=hh:mm

[-hh:mm]

[Wday={Sunday, Monday, Tuesday, Wednesday, Thursday, Friday,

Saturday}]

[Idle=minutes]

Reboot — Yes/no option to enable automatic daily reboot of all

ThinOS devices.

Time — Species the time to reboot and must be in a 24-hour

format. For example: Reboot=Yes Time=17:30 will reboot all ThinOS

devices at 5:30 P.M. daily.

If you set time as hh:mm-hh:mm, a random time during the

congured time period is selected.

Wday— The option Wday species the week day of scheduled

reboot.

Parameters for WNOS INI Files Only 31

Idle— The option Idle species the idle minutes. After the

scheduled reboot time is reached, the unit reboots, if there is no

session or the terminal is idle for specied idle minutes. If the

session is still active, the reboot is delayed till the idle time is

reached or log o the sessions.

For example,

If you set Reboot=yes time=20:30, the unit reboots on local time

20:30. If you set Reboot=yes time=20:30-4:30, the unit reboots on

random time through 20:30 to 4:30.

If you set Reboot=yes time=23:00 Wday=Friday,Monday, the unit

reboots on local time 23:00 of Friday and Monday.

If you set Reboot=yes time=1:00 Idle=10, the unit reboots on 1:00, if

there are no sessions. If there is any active session, the reboot

happens only if the unit is idle for 10 minutes or the system logs out

from the session.

Since 8.3_012 or later, scheduling a shutdown at a given time is

supported. The options are same as schedule a reboot as above.

For example, Set Shutdown=yes time=20:30, the unit shuts down

at local time 20:30.

RegisterWINS=yes Forces the thin client to register itself with a Microsoft WINS

server.

SelectServerList={PNA, VDI}

[Default=default_desc]

list of servers {Server1; Server2; ...ServerN}

Allows users to select one PNA or VDI server during logon. For

server use the format:

description = <server’s description> host = <server’s

url> [ <options>]

NOTE: There must be “description” and “host” key words

on each server.

For PNA server options, use the options of the PnliteServer

parameter in Table 7 Connection Settings: wnos.ini les, {username}

INI, and $MAC INI Files.

PNA example:

SelectServerList=PNA; Default=test3;

description = test1; host =

192.168.0.10; autoconnectlist

=*; reconnectfrombutton=0; description =

test2; host = HostName2.wyse.com; TimeOut=200;

descriprion = test3 host = https://

server3.wyse.com

For a VDI server: If you want to use a VDI broker, specify

ConnectionBroker in wnos.ini. Otherwise the VDI broker’s type is

default.

VDI example:

ConnectionBroker=VDM

SelectServerList=VDI; Default=test5

description = test4; host = 192.168.0.11;

description = test5; host = host2.wyse.com

The Default option following "SelectServerList={PNA, VDI}" can

specify the default server. The value is one of server description

dened after that. After one selects another server and sign o,

32 Parameters for WNOS INI Files Only

this default server is selected. If default option is not specied, the

last selected server is selected in the next sign on.

Service={snmpd, thinprint, vncd, wdm,

vda <port number>} disable={no, yes}

Service — Species the services you can enable or disable; there

are dierent syntaxes for the dierent services.

disable — Default is no. Yes/no option to disable the services.

Disable must follow the Service parameter.

Service=snmpd disable={no, yes}

[community=<snmp_community> [encrypt={yes, no}]]

[communityReadOnly=<snmp_community_read_only>

[encrypt={yes, no}]]

[servers=server_list]

Default is no.

Service=snmpd disable — Yes/no option to disable the snmpd

service.

community — The option community is same as the statement

Community. encrypt option is same as that in the statement

community.

communityReadOnly— This option is to set community only has

snmp get and get_next privileges.

The following encrypt option is only for indicating, if value of

communityReadOnly is encrypted.

Servers option, if set, limits the valid snmp management site to the

IP addresses in the server_list parameter, which contains 1 to 4

IPv4 IP addresses currently. If not, all the set IP addresses seen as

valid.

Service=thinprint disable={no, yes}

[port=<port number>]

[PkSize={0-64000}]

Default is no.

Service=thinprint disable — Yes/no option to disable the thinprint

service.

port — Same as the statement ThinPrintEnable={no, yes}

port=portnumber.

PkSize — Species the default packet size that will be sent to the

server when negotiating with the thinprint server. The value 0 will

rely on the server default setting, 64000 in ThinPrint 7.6 and 32000

in previous ThinPrint versions.

ThinOS only allocates a buer of 64K, so if the default packet size

of the server is above 64000, this setting must be set or printing

will fail.

Service=vncd disable={no, yes} Default is no.

Yes/no option to disable the vncd service, same as MaxVncd={0,

1}.

Service=wdm disable={no, yes} Default is no.

Yes/no option to disable the WDM service, same as

RapportDisable={no, yes}.

Service=<port number> disable={no, yes} Default is no.

Yes/no option to disable the service with this port number. The 80

port is an exception because the WDM is always started before

loading the global prole (wnos.ini le).

SecurityPolicy={full, warning, low} Species the global security mode for SSL connection. If

application SecurityMode is default, application applies the setting.

Parameters for WNOS INI Files Only 33

[SecuredNetworkProtocol={yes, no}]

[TLSMinVersion]={1,2,3}]

[TLSMaxVesion={1,2,3}]

[DNSFileServerDiscover={yes, no}]

If set to full, the SSL connection needs to verify server certicate.

If it is untrusted, connection is dropped.If set to warning, the SSL

connection needs to verify server certicate. If it is untrusted, it is

up to you to continue or drop the connection. If set to low, the

server certicate is not checked.

The value is persistent, and the default value is warning. For those

SSL connections with their own security policy, this does not

impact.

For example,

File server, VMware View and AWS broker follows the global

SecurityPolicy. Citrix broker, RDS broker and SECUREMATRIX are

forced to high security mode.

If the optional SecuredNetworkProtocol=yes is set, the unsecure

protocols including ftp, http and tftp are disabled. The value is

persistent, and the default value is no.

Option TLSMinVersion and TLSMaxVersion allows you to congure

the SSL connection. ThinOS supports SSLs from TLSMinVersion

onwards. TLSMaxversion is the latest version of SSL supported by

ThinOS.

If no value is set then TLSMinVersion then the default value is set

to TLS1.0 and TLSMaxVersion to TLS1.2. The value 1, 2, 3

corresponds to TLS1.0, TLS1.1, TLS1.2 respectively.

In classic mode, a DNS name wyseftpfbc4tc is resolved to discover

the le server, if the global INI le in remote le server and local

cache cannot be loaded. If the optional DNSFileServerDiscover=no

is set, the function is disabled. The value is persistent, and the

default value is yes.

SignOn={yes,no, NTLM}

[MaxConnect=max]

[ConnectionManager={maximize, minimize, hide}]

[EnableOK={no, yes}]

[DisableGuest={no, yes}]

[DisablePassword={no, yes}]

[LastUserName={no, yes}]

[RequireSmartCard={no, yes}]

[SCRemovalBehavior= {-1, 0, 1}]

[SaveLastDomainUser={yes, no, user, domain}]

[DefaultINI=lename]

[IconGroupStyle={default, folder}]

[IconGroupLayout={Vertical, Horizontal}]

[PasswordVariables={yes, no}

[LockTerminal={yes, no}]

[ExpireTime={0, 1 - 480}]

SignOn — Default is yes. Yes/no/NTLM option to enable the sign-

on process. If set to NTLM, a user can be authenticated with an

NTLM protocol.

The user must be a domain user and the same sign-on user

credentials must be available in the ftp://~/wnos/ini/ directory.

MaxConnect — Default is 216. Maximum number of connections

allowed to be specied in the wnos.ini le and {username}.ini le

added together. The range allowed for MaxConnect is 100 to 1000.

The default maximum is 216 entries.

ConnectionManager — Default is minimize. State of the Connect

Manager during sign-on.

EnableOK — Default is no. Yes/no option to show the OK and

Cancel the command buttons in the Sign-on dialog box.

DisableGuest — Default is no. Yes/no option to disable the guest

sign-on.

DisablePassword — Default is no. Yes/no option to disable the

password text box and password check box in the Sign-on dialog

box.

LastUserName — Default is no. Yes/no option to display the last

sign-on username after the user logs o.

RequireSmartCard — Default is no. Yes/no option to force logon

with smartcard.

34 Parameters for WNOS INI Files Only

[UnlockRefresh={yes, no}]

[SCShowCNName={yes,no}]

[SCSecurePINEntry={no, yes}]

[AutoConnectTimeout={10–300}]

[DisableEditDomain={yes, no}]

[AdGroupPrex=adgrpnameprex]

SCRemovalBehavior — Default is 0. Species what happens after

a smart card is removed.

-1 — If smartcard is removed then client has no action. Whether

the session can be used or not totally depend on the server

policVNCD

0 — System logs o.

1 — System locks and can be unlocked only when the same

certicate is used with the smart card.

SaveLastDomainUser — Yes/no option to save the username and

domain into NVRAM once signon is successful. On next reboot, the

username and domain saved in the NVRAM will be displayed in

signon server as the default username and domain if no

DefaultUser is set in the wnos.ini le.

The size of username/domain is limited to 32 characters, and if

larger than 32, it will rst be truncated and then saved into

NVRAM.

DefaultINI — The optional DefaultINI congures a le name which

is in the default folder of the username ini les. If the {username}.ini

is not found, this le will be loaded as default.

IconGroupStyle — The optional IconGroupStyle congures the

icon group style on the desktop. PNAgent published applications

can be congured with the client folder in the PNA server.

If set IconGroupStyle=folder, the PNAgent published applications

which are specied to display on the desktop will display with the

folder.

After clicking the folder icon, the subfolder or applications in this

folder will display on the desktop. In this case, there is an Up to 1

Level icon on top. Clicking the icon will display the up one level

folder contents.

IconGroupLayout — Default is vertical. Congures the direction of

the icongroup on the desktop.

PasswordVariables — Default is no. Yes/no option to support

variable mapping ($TN, $UN etc) for a password.

LockTerminal — Default is yes. Yes/no option to lock the terminal.

If set LockTerminal=no, the function of locking terminal is disabled.

It disables the Lock Terminal from a Right Click on the desktop or

from clicking the Shutdown option > Lock Terminal. It also disables

lock terminal even if set ScreenSaver=minutes; LockTerminal=yes.

ExpireTime — Species the signon expiration time. The range is 0

to 480 minutes. The default is 0 which means no expiration.

If the value is larger than 480, then 480 is set instead. If the value is

smaller than 0, then 0 is set instead.

After system signon or starting a connection, the expiration time

starts counting. Once the expiration time is reached, starting a

connection by clicking the icon, menu or connection manager, will

bring up a pop up message box to enter the password. Only if the

password is same as the original signon password, the session

starts.

If the terminal is locked and unlocked with the password, the signon

expiration time starts counting again.

Parameters for WNOS INI Files Only 35

UnlockRefresh — Default is yes. Yes/no option to species the

refresh action after unlocking the system in classic mode.

Yes — While unlocking, the system will refresh the PNA list to

verify the password.

No — Disables refresh.

SCShowCNName — Default is yes. Yes/no option to force the use

of the CN name of the certicate as the user name when using

smartcard signon. The default uses the UPN name as the user

name.

SCSecurePINEntry — Default is no. Yes/no option to enable

Secure PIN entry function for pkcs15 smart card with Cherry

keyboard.

AutoConnectTimeout— Default is 30 seconds.

This option sets the timeout for auto connect published

application. The range is 10 seconds to 300 seconds.

DisableEditDomain— The optional keyword DisableEditDomain, is

set to yes to stop typing in the domain box manually. Typing the

character @ or \ as in the format domain\user and user@domain in

the username box are not allowed.

AdGroupPreFix— The option AdGroupPreFix is only valid, when

you congure SignOn=NTLM. If the option is congured, then the

thin client veries the names of all AD groups to which a sign-on

user belongs, to get the rst group name so that its prex matches

adgrpnameprex, and load

adgroup/"the_whole_ad_group_name".ini, if the conguration le

exists, before loading the user specic INI.

For example, if the sign on user is user_111 in a domain, and the

user_111 belongs to group domain user and group tc_grp1_ad, the

option is congured as AdGroupPrex=tc_grp1. If the conguration

le adgroup/tc_grp1_ad.ini is available, it will be loaded.

Speedbrowser={on, o} Default is on.

On/o option to enable the ICA Speedscreen Browser Acceleration

Function.

SwitchApplication IMPORTANT: DISCONTINUED. DO NOT USE.

SysMode={classic, vdi}

[toolbardisable={no, yes}]

[toolbardisablemouse={no, yes}]

[toolbarclick={no, yes}]

[toolbardelay={0-4}]

[toolbar_no_conmgr={no, yes}]

[toolbar_no_minimizeall={no, yes}]

[toolbardisablehotkey={no, yes}]

[ToolbarEnableOneSession={no, yes}]

SysMode — Species the Zero interface optimized for VDI or the

Classic interface. This value will be remembered across reboots until

changed. If not dened and an INI is present, Classic mode is the

default. If no INI is present, VDI mode is the default.

Classic mode has full taskbar, desktop and connection manager and

is recommended for a terminal server environment and for

backward compatibility with WTOS 6.x.

VDI mode (Zero interface) has a new launchpad-style interface

optimized for full-screen sessions that is Desktops. Everything you

need is accessed through an always available overlay interface. The

following options allow you to congure if and when the Zero

toolbar will display under VDI mode:

Toolbardisable — Default is no. Yes/no option to disable the Zero

toolbar from displaying; if set to yes, this option overrules other

toolbar display options.

36 Parameters for WNOS INI Files Only

[ToolbarAutoQuit={yes, no}]

[ToolbarStay={1~20}]

[EnableLogonMainMenu={no, yes}}

Toolbardisablemouse — Default is no. Yes/no option to disable the

Zero toolbar from automatically displaying once you pause the

mouse pointer on the left side of the screen for a specied amount

of time.

toolbarclick — Default is no. Yes/no option to pop up the toolbar

only if clicking on the left-most side of the screen.

toolbardelay — Species the seconds to delay before displaying

the toolbar after pausing the mouse pointer on the left-most side of

the screen. The value 0 will have no delay. The other values 1, 2, 3,4

will delay 0.5, 1, 1.5 and 2 seconds respectively.

toolbar_no_conmgr — Default is no. Yes/no option to hide the

Home button.

toolbar_no_minimizeall — Default is no. Yes/no option to hide the

Home button thus aecting the ability to minimize displayed list of

connections.

toolbardisablehotkey — Default is no. Yes/no option to disable the

CTR+ALT+UP ARROW keyboard shortcut that allows the toolbar to

instantly display without a timer.

ToolbarEnableOneSession — Default is no. Yes/no option to

enable the toolbar when only one session is available.

ToolbarAutoQuit — Default is yes. ToolbarAutoQuit=no prevents

the sub-window from being closed. The toolbar will auto-hide after

a certain amount of time after user pause the mouse pointer away

from the toolbar.

ToolbarStay — ToolbarStay={1~20} controls the auto-hide

duration, 0.5s per value. Thus if ToolbarStay=1, the Toolbar will

auto-hide after 0.5 second; If ToolbarStay=10, the Toolbar will auto-

hide after 5 seconds.

EnableLogonMainMenu — Default is no. Yes/no option to enable

the main menu if you click the mouse button on the desktop prior

to logon in Zero mode.

SysName IMPORTANT: DISCONTINUED. DO NOT USE.

TcpTimeOut={1 , 2} Default is 1.

Species the timeout value of a TCP connection. The number of 30

seconds for the timeout value of a TCP connection. The value must

be 1 or 2 which means the connection timeout value is from 1x30=

30 seconds to 2x30= 60 seconds.

Values of 3-255 are recognized only for backwards compatibility

that is >2 = 60 seconds, however, these values should not be used

and the value should be set to 2.

TCXLicense IMPORTANT: DISCONTINUED. DO NOT USE.

VncPassword=<password>

[encrypt={no, yes}]

VncPassword — Species a string of up to 8 characters as the

password used for shadowing.

encrypt — Default is no. Yes/no option to set according to

whether or not the vncpassword you are using is encrypted.

Parameters for WNOS INI Files Only 37

IMPORTANT: To use VNC Shadow, you must set

MaxVNCD=1 and dene a password; The MaxVNCD

default is 0 and this disables VNC. If you are using an

encrypted password, you must set encrypt to yes. For

example:

VncPassword=<encoded password> encrypt=yes

If you are using a plain text password, you must set

encrypt to no. For example:

VncPassword=<plain text> encrypt=no

See also MaxVNCD in Table 4: Connection Settings: wnos.ini

les only to enable VNC shadowing.

See also VNCPrompt in Table 7: Connection Settings:

wnos.ini les, {username} INI, and $MAC INI Files to enable a

VNC shadowing prompt to a user.

WarnUnlinkDisabled={yes, no} Default is no.

Yes/no option to disable the pop-up warning message when a

network has no link for an ICA/RDP session.

WDAService=yes

[Priority ={WDM, CCM, “WDM;CCM”, “CCM;WDM”}]

WDA Service always runs in the background.If priority is available,

WDA discovers the protocol according to it.

There are only two protocols available now - WDM, and CCM. For

example, if priority=WDM; CCM, WDA tries to discover WDM

server and tries to check-in, and if it fails to check-in to WDM

server, it tries to check-in the device to CCM server.

WDMFlash=ash_size The specied value will be saved into NVRAM, and then reports to

the WDM server. This statement ensures that all the units would

function with DDC regardless of ash size.

This statement is valid for all platforms and replaces the previous

S10 WDM Flash statement.

WDMService={yes, no}

[DHCPinform={no, yes}]

[DNSLookup={no, yes}]

[QuickMode={yes, no}]

[Discover={yes, no}]

[SecurityMode={default, full, warning, low}]

Default is yes.

WDMService — Yes/no option to disable the WDM agent.

Discovering the WDM server is supported by the following:

1 DNS host name lookup wdmserver

2 DNS service location record _wdmserver._tcp

3 DHCP option tag values received from standard or WDM

proxy DHCP service for vendor class RTIAgent

DHCPinform — Default is no. Yes/no option to use DHCP

information.

DNSLookup — Default is no. Yes/no option to use DNSLookup.

For Example: If WDMService=yes, setting DHCPinform=yes will do

number 3, setting DNSLookup=yes will do numbers 1 and 2.

If QuickMode=yes is specied, rapport agent will not block any

other process during ThinOS boot up, and boot time of ThinOS will

speed up.

38 Parameters for WNOS INI Files Only

NOTE: If le server is changed by WDM server, device will

reboot automatically to make sure all settings from WDM

server take eect. Default is yes

Discover— If Discover=yes is specied, rapport discovers the

WDM server information from the DHCP option tag, DNS service

location record and DNS host name. If the WDM server is

discovered, the WDM server User Interface (UI) is protected on

device. The default value is yes.

SecurityMode species the SSL certication validation policy.

If set to default, it will apply SecurityPolicy setting.

If set to full, the SSL connection needs to verify server certicate.

If it is untrusted, then drop the connection.

If set to warning, the SSL connection needs to verify server

certicate. If it is untrusted, it's up to you to continue or drop the

connection.

If set to low, the server certicate is not checked. The value is

persistent, and the default value of the setting is default. If the

settings are factory default, or if you are upgrading to ThinOS 8.3

for the rst time, the value is temporarily set to low. After loading

any INI, it goes to default value.

WDMServer=<server_list>

[Retry=<retry number value>]

WDMServer — Species a list of IP addresses or DNS names

separated by using a comma for the WDM servers. Once specied,

it is saved in non-volatile memory.

Retry — Determines the number of attempts to retry a contact to

WDM servers.

WINSServer=server_list Species the WINS server address. The WINSserver is an IP list

separated by ";" or ",", with a maximum list size of 2.

Parameters for WNOS INI Files Only 39

Parameters for WNOS INI, {username} INI, and

$MAC INI Files

This chapter provides the supported parameters that you can use in a wnos.ini le, a {username}.ini le, and in a $MAC.ini le. For

information to help you construct and use the supported INI les, see Getting Started: Learning INI File Basics

To increase usability such as relation to thin client dialog box equivalents, the supported parameters are separated into the following

categories:

•General Settings for wnos.ini Files, {username} INI, and $MAC INI Files

•Peripheral Settings for wnos.ini Files, {username} INI, and $MAC INI Files

•Connection Settings for wnos.ini Files username INI and MAC INI Files

IMPORTANT:

The underlined value for a parameter is the default value. Some parameters also have options shown within brackets [ ]. If an option

has an underlined value (default), that option and default value will automatically be used with the parameter. The options without

underlined values can also be used if you want to, but are not automatically used with the parameter. In addition, when using

parameters and options, you can leave the default value or change it to another value shown.

For example, in the following case where:

ParameterX={yes, no}

[Option1={0, 1}]

[Option2={1, 2, 3, 4}]

If you use ParameterX, then Option1 and its default value 0 will automatically be used as Option1 has an underlined value (default of 0).

You can still use Option2 if you want to, however, Option2 is not automatically used with the parameter as Option2 does not have a

default (underlined) value.

NOTE:

User prole parameters found in the {username}.ini le generally override the identically named global parameters found in the

wnos.ini le, however, some global parameters in Tables 5, 6, and 7 noted with * do not allow this. Thus, if the parameters in Tables 5,

6, and 7 noted with * are used in both a {username}.ini le and in a wnos.ini le, the noted parameters in the wnos.ini le will override

the same noted parameters in the {username}.ini le.

For example, if the parameter Resolution=1024x768 is used in the {username}.ini le and the same parameter Resolution=1280x1024 is

used in the wnos.ini le, the Resolution=1280x1024 in the wnos.ini le will override the Resolution parameter in the {username}.ini le.

Therefore, if you want the parameter Resolution=1024x768 in the {username}.ini le to be used, you must not use the Resolution

parameter in the wnos.ini le.

NOTE:

Parameters in Tables 5, 6, and 7 noted with ** that are used in a {username}.ini le or $MAC.ini le will return to the values set for

those parameters in the wnos.ini le after a user sign-o.

For example, if your {username}.ini le contains the parameter MouseSwap=1—so that the mouse buttons are swapped for your left-

hand use and you log o the thin client, then the MouseSwap value will return to the original default value of 0 (MouseSwap=0)

contained in the wnos.ini le—so that others who log in can use their own user prole; assuming the administrator has not changed

the default values in the wnos.ini le.

4

40 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Topics:

• General Settings for wnos.ini Files, {username} INI, and $MAC INI Files

• Peripheral Settings for wnos.ini Files, {username} INI, and $MAC INI Files

• Connection Settings for wnos.ini Files, {username} INI, and $MAC INI Files

General Settings for wnos.ini Files, {username} INI,

and $MAC INI Files

Table 5 contains the parameters used for conguring general settings. The underlined values are defaults.

Table 5. General Settings: wnos.ini les, {username} INI, and $MAC INI Files

Parameter

* Global overrides identically-named user prole

** After sign o, user prole returns to global value

Description

AdminMode={no, yes}

[admin-username=<encrypted_ username>]

[admin-password=<encrypted_ password>]

[Username=<username>]

[Password=<password>]

[Enc-username=encrypted_username]

[Enc-password=encrypted_password]

AdminMode — Default is no. Yes/no option to use the username

and the password to obtain a high thin client conguration when

the privilege parameter level is set to high (Privilege=high).

admin-username — Species if admin-

username=encrypted_username, then encrypted strings are used

for admin-username; no minimum length; maximum length is 30

characters—15 characters convert to 30 characters encrypted.

admin-password — Species if admin-

password=encrypted_password, then encrypted strings are used

for admin-password; no minimum length; maximum length is 30

characters—15 characters convert to 30 characters encrypted.

Enc-username — Species if the username is encrypted, and

encrypted strings are used for the Enc-username.

Enc-password — Species if the password is encrypted, and

encrypted strings are used for the Enc-password.

NOTE:

The AdminMode items are on the right-click menu.

username — Species the username; no minimum length;

maximum length is 15 characters.

password — Species the password; no minimum length;

maximum length is 15 characters.

BootOrder={PXE, HardDisk, USB} BootOrder — Sets the boot order for the BIOS. The boot order

must follow these rules:

1 The boot order is a list of these three options separated by a

semi-colon (;) or a comma (,).

2 Every option must be used.

3 The options must be dierent.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 41

For example, the following settings are valid:

BootOrder=PXE;HardDisk;USB

BootOrder=HardDisk;PXE;USB

BootOrder=USB;PXE;HardDisk

However, the following settings are invalid:

BootOrder=PXE;HardDisk

BootOrder=PXE;PXE;USB

BootOrder=PXE;HardDisk;USB;PXE

If the rst boot order is not HardDisk, the system restart will boot

from the BIOS setting.

BootpDisable={no, yes} Default is no.

BootpDisable — Yes/no option to disable BOOTP requests.

ThinOS supports both DHCP and BOOTP to obtain the network

congurations. In the rst two attempts, only DHCP is requested.

Then, both DHCP and BOOTP are requested.

For some environments, BOOTP requests will delay obtaining the IP

from the DHCP server. Set BootpDisable=yes will only perform a

DHCP request. This setting is only valid after the next reboot.

CmosPassword=<password>

[encrypt={no, yes}]

CmosPassword — Species the BIOS password on supported

platforms; string up to 8 characters (Wyse 5010 thin client with

ThinOS (D10D), Wyse 5010 thin client with PCoIP (D10DP), Wyse

5060 thin client with ThinOS, Wyse 5060 thin client with PCoIP,

and Wyse 7010 thin client with ThinOS (Z10D).

encrypt — Default is yes. If encrypt=yes, an encrypted string is

used as a password and the password is encoded by Dell Wyse

encrypt tool.

CustomInfo={yes, no}

[Custom1=custom1_str]

[Custom2=custom2_str]

[Custom3=custom3_str]

[Location=location_str]

[Contact=contact_str]

Yes/no option to congure or store custom information. If

CustomInfo=yes, the custom information congured by the

following options will be stored into NVRAM. If CustomInfo=no, the

custom information in NVRAM will be cleared.

For example:

CustomInfo=yes custom1=11 custom2=2 custom3=3

location=wyse contact=peter

NOTE: Maximum length is 32 characters.

**DeskColor=”rrr ggg bbb” Default is “16 100 36”; where DeskColor =“16 100 36” (green) is

the default.

Species the desktop background color in RGB string format that

must be enclosed in quotes, where rrr, ggg, and bbb are decimal

numbers in the rage of 0 to 255. When using this parameter in a

wnos.ini le, it will be saved to NVRAM if EnableLocal is set to yes

in the wnos.ini le.

NOTE:

The MirrorFileServer parameter also supports the DeskColor

parameter.

**Desktop=bitmap le

[Layout={center, tile, stretch}]

Desktop — Species a bitmap le to be used as wallpaper for the

local desktop. This le could be a 4-bit, 8-bit, or 24-bit BMP le or a

standard GIF le or a standard JPEG le. The le must be located in

42 Parameters for WNOS INI, {username} INI, and $MAC INI Files

[IconTextColor="rrr ggg bbb"] the FTP server wnos\bitmap directory. Default is Wyse wallpaper.

To disable the parameter, leave value blank (Desktop=wysedefault).

Layout — Default is stretch. Species the arrangement on the

desktop background of the bitmap le specied by the Desktop

parameter, if auto dial-up is set, Layout is invalid.

For center, the image is placed in the center of the desktop without

image size change. For tile, the image is replicated across the

desktop. For stretch, the image is modied to ll the desktop.

NOTE:

In dual-monitor mode, the wallpaper is replicated and

specied separately for each monitor, instead of being shared

by the two monitors.

IconTextColor — Species the icon text color in RGB string format

that must be enclosed in quotes, where rrr, ggg and bbb are

decimal numbers in the range of 0 to 255.

Device=cmos

[Action={extract, restore}]

[Password=password]

[encrypt={no, yes}]

[BootOrder={PXE, HardDisk, USB}]

[WakeOnLan={yes, no}]

[AutoPower={yes, no}]

[BootFromUSB={yes, no}]

[USBController={yes, no}]

[COMController={yes, no}]

[PopupMenu={yes, no}]

[OnboardAudio={yes, no}]

[Bluetooth={yes, no}]

CMOS management (extract and restore cmos settings).

Extract — For extract action, CMOS content is saved to the le:

$PF_cmos.$VER .

NOTE:

$PF - Is the name of the platform, including C10, C00, R10,

R00, and VL10.

$VER - Is the version of the BIOS, such as

1.0B_SPC001(1.0B_SPC001-0407), 1.0B-0407(Zilch),

1.0H_SPC-0T51(R10, R00), 1.19R(VL10).

Wyse ThinOS log: "CMOS: extract to $PF_cmos.$VER"

Restore — For restore action, CMOS content is updated from the

le:

$PF_cmos.$VER

Wyse ThinOS log: "CMOS: restore from $PF_cmos.$VER"

When using this feature, there should be a special INI user name

such as cmos. The associated ini/cmos.ini should include one line as

Device=cmos Action=extract.

NOTE: Do not include Device=cmos Action=extract in a

global INI le such as wnos.ini, as it will take no eect if it

is included in the global INI le.

After the administrator congures the CMOS on a template unit,

the administrator should sign on to the cmos account on ThinOS to

have the CMOS content saved to the cmos le on a writable File

Server wnos directory.

Then, the wnos.ini should be congured with Device=CMOS

action=restore, so that all target units will be updated with the

same CMOS setting as the template unit after reboot.

Once the restore action is nished, both the Device=cmos

Action=extract and Device=CMOS action=restore should be

removed from the related INI les.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 43

The usage of other settings is self-explanatory. The only condition

to use the settings is the BIOS GUI should have such settings.

DEVICE=UsbTrace

vid_pid={device vid/pin hex format}

[max_len=500]

Specify the WTOS to trace USB device data to ftp or USB disk. For

"vid_pid", device Vendor ID and Product ID hex value, and VID is

high 16 bit while Product ID is low 16 bit.

Allows to trace maximum of eight devices at one time. For

"max_len", set a max len for capturing each USB transfer data.

Default value is 128. After you set this, you need to set option in

Trouble shooting to start tracing the USB device data.

FactoryDefault={no, yes} Default is no.

Yes/no option to reset the system settings to factory default. This

parameter, when set to yes, is only initialized once for each

rmware change; however, you can set to no and then reboot so

the option will be initialized again.

NOTE:

If the FactoryDefault parameter value is changed to yes, the

thin client will reboot without notice to the user.

*Include=path/lename For {username}.ini le only. Species to include another INI le at

the position of this parameter. Only one level of including is allowed

(no nesting) and only for a {username}.ini le.

KeySequence={no, yes}

[Ctrl+Alt+Del={no, yes}]

[Ctrl+Alt+Up={no, yes}]

[Ctrl+Alt+Down={no, yes}]

[Ctrl+Alt+Left={no, yes}]

[Ctrl+Alt+Right={no, yes}]

[Win+L={no,yes}]

KeySequence — Yes/no option to enable the following supported

combined keys options.

KeySequence=yes enables all of these options, each having a

default of yes or no as noted that you can change individually to the

setting desired.

KeySequence=no disables all of these options regardless of the

individual settings.

Ctrl+Alt+Del — Default is no. Yes/no option to enable Ctrl+Alt+Del

to lock the thin client if the user is logged in with a password. If the

user is logged in without a password, this key sequence does not

work.

Ctrl+Alt+Up — Default is yes. Yes/no option to enable Ctrl+Alt+Up

to toggle a session between fullscreen and window mode.

Ctrl+Alt+Down — Default is yes. Yes/no option to enable Ctrl+Alt

+Down to toggle between task selections.

Ctrl+Alt+Left — Default is yes. Yes/no option to enable Ctrl+Alt

+Left Arrow to lock the thin client if the user is logged in with a

password. If the user is logged in without a password, this key

sequence does not work.

Ctrl+Alt+Right — Default is yes. Yes/no option to enable Ctrl+Alt

+Right Arrow to lock the thin client if the user is logged in with a

password. If the user is logged in without a password, this key

sequence does not work.

Win+L — Default is no. Yes/no option to enable use of Win+L key

to lock the client.

**Language=code

[ManualOverride={yes,no}]

Language — Species the keyboard language to use. Once

specied in a wnos.ini le, it is saved in non-volatile memory. The

code used must be exactly the same as the character string shown

in the keyboard language list below.

44 Parameters for WNOS INI, {username} INI, and $MAC INI Files

[Charset={ISO-8859-1, ISO-8859-2, ISO-8859-5, ISO-8859-7}]

[ImageSux={us, fr, de, gb, b5, jp, ko, la, default]

ManualOverride— If you set ManualOverride=yes, all the

parameters are only valid in factory default. It is helpful to congure

keyboard setting manually in case of multiple nationalities within a

company. This option must be following Language=code statement.

Charset — Species which ISO option to use:

ISO-8859-1— This is Default. Supports part 1 of the standard

character encoding of the Latin alphabet.

ISO-8859-2 — Supports the Czech, Hungarian, Polish, Romanian,

and Slovenian languages on the desktop display.

ISO-8859-5 — Supports Cyrillic characters on the desktop display.

ISO-8859-7 — Supports the Greek language on the desktop

display.

Keyboard Language List — Description and Code

Arabic (Saudi Arabia) — Ar_sau

Arabic (Iraq) — Ar_ira

Arabic (Egypt) — Ar_egy

Arabic (Libya) — Ar_lib

Arabic (Algeria) — Ar_alg

Arabic (Morocco) — Ar_mor

Arabic (Tunisia) — Ar_tun

Arabic (Oman) — Ar_oma

Arabic (Yemen) — Ar_yem

Arabic (Syria) — Ar_syr

Arabic (Jordan) — Ar_jor

Arabic (Lebanon) — Ar_leb

Arabic (Kuwait) — Ar_kuw

Arabic (U.A.E.) — Ar_uae

Arabic (Bahrain) — Ar_bah

Arabic (Qatar) — Ar_qat

Brazilian — Br

Canadian Multilingual — ca_ml

Chinese (Simplied) — Gb

Chinese (Traditional) — b5

Croatian — Croat

Czech — Cz

Czech (Qwerty) — Cz_q

Danish — Dk

Parameters for WNOS INI, {username} INI, and $MAC INI Files 45

Dutch — Nl

Dutch (Belgian) — Nl_be

Dutch (Belgian Comma) — Nl_be_c

English (3270 Australian) — au3270

English (Australian) — Au

English (New Zealand) — Nz

English (United Kingdom) — Uk

English (United States) (default) — Us

Estonian (Estonia) — Et_ee

Finnish — Fi

French (Belgian) — fr_be

French (Belgian Comma) — fr_be_c

French (Canadian) — fr_ca

French (France) — Fr

French (Swiss) — fr_sf

German — De

German (IBM) — de_ibm

German (Swiss) — de_sg

Greek — el

Hungarian — Hu

Icelandic — Is

Italian — It

Italian (Swiss) — it142

Latvian (Latvia) — lv_lv

Latvian (Qwerty) — lv_lv_q

Lithuanian (Standard) — lt_lt

Lithuanian (IBM) — lt_lt_i

Lithuanian (MS) — lt_lt_m

Japanese — Jp

Japanese_109a — Jp_109a

Korean — Ko

Korean (MS-IME2002) — ko_ime

Norwegian — No

Polish (214) — Pl

46 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Polish Programmers — pl_prog

Portuguese — Pt

Portuguese (Brazil) — Pt2

Romanian — Ro

Russian — Ru

Slovakian — Slovak

Slovakian (Qwerty) — sk_q

Slovenian — Sloven

Spanish — Es

Spanish (Mexican) English — La(us)

Spanish (Mexican) Localized — La

Swedish — Se

Turkish — Turk

Turkish (QWERTY) — turk_q

U.S. International — us_int

NOTE:

Japanese refers to Japanese Input system (MS-IME2000),

not JP. Russian keyboard is supported for server input; it is

not supported to input locally.

ImageSux — Localization builds have dierent suxes according

to the keyboard language as follows:

jp (Japanese)

gb (Simplied Chinese)

b5 (Traditional Chinese)

ko (Korean)

la (Spanish Mexican)

By default, with the above keyboard languages, the system will

update the standard image according to the suxes with the

language code. With other keyboard languages, the system will

update the standard image without the sux specied.

For example, if you set Language=jp, the system will update the

image named C10_wnos.jp which is the Japanese localization build.

If you set Language=us, the system will update the image named

C10_wnos. The option ImageSux can specify the sux of the

image name when you do not want the default behavior.

Locale=<value>

[load={yes | no}]

Locale — Species the system language. Locale changes the

language for the user logon-experience screens only displayed

during boot-up and logon and not the conguration or administrator

screens.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 47

Values include: English, us, French, fr, German, de, Chinese

Simplied, gb, Chinese Traditional, b5, Japanese, jp, Korean, ko,

Latin, la.

load=yes/no species whether or not to load the language le. The

language le must end with the locale name and be placed under

the folder wnos/locale in the le server.

NOTE:

For example, if you want to specify French and load the

localized messages, you must place a le named French.msg

under the folder wnos/locale in the le server, and then add

Locale=French load=yes in the INI le. You can use Local=fr

instead of Locale=French.

NOTE:

For Chinese Simplied, Chinese Traditional, Japanese, and

Korean localization, a font le must also be placed under the

folder wnos/font in the le server.

For example, if you want to specify the system language to

be Japanese, you must place a le named Japanese.msg

under the folder wnos/locale in the le server, place a le

named Japanese.fnt under the folder wnos/font in the le

server, and then add Locale=Japanese load=yes in the INI

le.

If you are under a Wyse maintenance contract, you can

download .fnt and .msg les from your My Downloads page

in the Self-Service Center.

If you are not under maintenance and wish to gain access to

these les, you must complete a product registration.

LocaleList=<value> LocaleList — Species a list of locale, so that a user can switch

the system language as needed.

Values include: English, us, French, fr, German, de, Chinese

Simplied, gb, Chinese Traditional, b5, Japanese, jp, Korean, ko,

Latin, la.

All the values will be displayed in the GUI. To view the GUI, click

System Preference > General > Locale. Be sure to place the

necessary les, for example German.msg, Japanese.msg,

Japanese.fnt, and so on under the correct folders as described in

the Locale parameter description.

**Password=<sign-on password>

[encrypt={no, yes}]

Species the password as the sign-on password; no minimum

length; maximum length is 64 characters.

In a wnos.ini le — If set to the default password, the system will

sign on automatically and not wait for username, password, and

domain entries.

In a [username].ini le — Be sure it is the encrypted password of

the user or the system will fail to sign on. This can be changed by a

user, if allowed, in the Sign-on dialog box.

encrypt — Default is no. Yes/no option to use an encrypted string

for a password in the INI le instead of clear text. If encrypt=yes,

the password in the INI is an ecrypted string instead of cleartext .

For example:

Password=wyseatc@123

48 Parameters for WNOS INI, {username} INI, and $MAC INI Files

or

Password=NCAONIBINMANMLCOLKCNLL \ encrypt=yes

** PRIVILEGE=[None, Low, High]

[LockDown= {no, yes}]

[HideSysInfo={no, yes}]

[HidePPP={no, yes}]

[HidePN={no, yes}]

[HideConnectionManager={no, yes}]

[EnableNetworkTest={no, yes}]

[EnableTrace={no, yes}]

[ShowDisplaySettings={no, yes}]

[EnableKeyboardMouseSettings={no, yes}]

[KeepDHCPRequestIP={no, yes}]

[SuppressTaskBar={no, yes, auto}]

[EnablePrinterSettings={no, yes}]

[CoreDump={ide, disabled]

[EnableNetworkSetup={yes, no}]

[DisableNetworkOptions={yes, no}]

[EnableSystemPreferences={yes,no}]

[DisableTerminalName={yes, no}]

[DisableSerial={yes, no}]

[DisableRotate={yes, no}]

[DisableChangeDateTime={yes, no}]

[EnableVPNManager={yes, no}]

[TrapReboot={yes, no}]

[EnableCancel={yes, no}]

Default is high.

Privilege controls operator privileges and access to thin client

resources. See also CCMEnable={yes, no}.

None — This level of access is typical for kiosk or other restricted-

use deployment. The System Setup selection on the desktop menu

is disabled and the Setup submenu is not displayed. The Connect

Manager is disabled by default.

The Connect Manager can be enabled by using the

HideConnectionManager=no option, however, the user cannot

create a new connection or edit an existing connection. The user

cannot reset the thin client to factory defaults.

Low — This access level is assigned to a typical user. The Network

selection on the Setup submenu is disabled and the Network Setup

dialog box cannot be opened. The user cannot reset the thin client

to factory defaults.

High — Administrator access level allows all thin client resources to

be available with no restrictions. A user can reset to factory

defaults.

NOTE:

If None or Low is used, the Network Setup dialog box is

disabled. If it is necessary to access this dialog box and the

setting None or Low is not saved into NVRAM, remove the

network connector and reboot.

LockDown — Default isno. Yes/no option to allow lockdown of the

thin client. If yes is specied, the system saves the privilege level in

ash. If no is specied, the system clears the privilege level from

ash to the default unlocked state.

NOTE:

If the thin client is set to LockDown without a High privilege

level, it will disable the G key reset on power-up.

LockDown can be used to set the default privilege of the thin

client. For example

• If LockDown=yes, then the privilege is saved in

permanent registry.

• if LockDown=no, then the privilege level is set to the

default high in the permanent registry.

That is, the system has a default high privilege level,

which is stored in the permanent registry.

• If you do not specify a privilege in either the wnos.ini le

or the {username}.ini le or the network is unavailable,

the setting of LockDown will take eect. It can be

modied by a clause.

For example, privilege=<none|low|high>lockdown=yes in

a wnos.ini le or a {username}.ini le sets the default

privilege to the specied level.

HideSysInfo — Default is no. Yes/no option to hide the System

Information from view.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 49

HidePPP — Default is no. Yes/no option to hide the Dialup

Manager, PPPoE Manager, and PPTP Manager from view.

HidePN — Default is no. Yes/no option to hide the PNAgent or

PNLite icon from view on the taskbar.

HideConnectionManager — Default is no. Yes/no option to hide

the Connect Manager window from view.

NOTE:

As stated earlier, although the Connect Manager is disabled

by default if Privilege=none, the Connect Manager can be

enabled by using HideConnectionManager=no; however, the

user cannot create a new connection or edit an existing

connection.

EnableNetworkTest — Default is no. Yes/no option to enable the

Network Test.

EnableTrace — Default is no. Yes/no option to enable trace

functionality. The active items are added to the desktop right-click

menu in Privilege=Highlevel.

ShowDisplaySettings — Default is no. Yes/no option to enable the

Display Settings in a popup menu.

EnableKeyboardMouseSettings. Yes/no option to enable the

keyboard and mouse conguration preferences.

KeepDHCPREquest — Default is no. Yes/no option to keep the

same IP address that is requested from the DHCP server after a

request fails and does not invoke the Network Setup dialog box.

SuppressTaskBar — Default is no. Yes/no/auto option to hide the

taskbar. If set to auto the taskbar will automatically hide/display the

taskbar.

When using this parameter in a wnos.ini le, it will be saved to

NVRAM if EnableLocal is set to yes in the wnos.ini le.

EnablePrinterSettings — Default isno. Yes/no option to enable

printer congurations when a user Privilege=None.

CoreDump — The option CoreDump=disabled will disable the core

dump function.

EnableNetworkSetup — This option is used to enable and disable

the network setup.

DisableNetworkOptions — This option is used to enable and

disable the network options.

EnableSystemPreferences — This option is used to enable and

disable the system preferences.

DisableTerminalName— This option is used to enable and disable

the terminal name.

DisableSerial — This option is used to enable and disable the serial

table in peripherals.

DisableRotate — If the optional DisableRotate=yes is set, the

rotate setting in the display setup will be disabled. This is only valid

for C class clients because the rotation performance in C class may

not be desirable.

50 Parameters for WNOS INI, {username} INI, and $MAC INI Files

NOTE:

If the optional EnableNetworkSetup=yes is set with

Privilege={none, low}, the network setup will be enabled.

If the optional DisableNetworkOptions=yes is set at the same

time, the Options table will be disabled.

If the optional EnableSystemPreferences=yes is set with

Privilege={none, low}, the system preferences setup will be

enabled.

If the optional DisableTerminalName=yes is set at the same

time, the terminal name eld will be disabled.

If the optional DisableSerial=yes is set with Privilege={none,

low}, the serial table in peripherals setup will be enabled.

DisableChangeDateTime— If the optional

DisableChangeDateTime is set, the function of changing date and

time locally will be disabled. For example, if you right-click the time

label in taskbar, nothing is displayed. The Change Date and Time

button in System Preference will be invisible.

EnableVPNManager—If the optional EnableVPNManager=yes is

set with Privilege={none, low}, the VPN Manager setup is enabled.

TrapReboot— If the optional TrapReboot=yes is set, client reboots

after the execution of the trap.

EnableCancel— If the optional EnableCancel=yes is set with

Privilege={none, low}, the counter down window for reboot or

shutdown can be cancelled. The default value is no.

For example, set the following ini,

Inactive=1

AutoSigno=yes Shutdown=yes

ShutdownCounter=30

Privilege=none EnableCancel=yes.

After no mouse and keyboard input in 1 minute, the system will pop

up a counter down window to shut down in 30 seconds. You can

cancel it.

**ScreenSaver=value{0, 1, 5, 10, 15, 30}

[LockTerminal={0, 1, 2, 3}]

[Type={0, 1, 2, 3}]

[Image=imagele]

[PictureTimer={2-60}]

[PictureOrder=random]

[PictureCheck=always]

[PictureLayout={stretch, tile, center}]

[Sleep={0-180}]

Screensaver— Species to put the thin client in a screensaver

state when the time limit for inactivity is reached, that is delay

before starting is reached.

Default value is 10. Value and delay before starting the screensaver:

0 — Disabled

1 — 1 Minute

5 — 5 Minutes

10 — 10 Minutes

15 — 15 Minutes

30 — 30 Minutes

Parameters for WNOS INI, {username} INI, and $MAC INI Files 51

The default screen saver value is 10 minutes and the maximization

value is 30 minutes.

LockTerminal— This is an optional parameter and species to put

the thin client in LOCK state when the screen saver is activated.

Default is 0.

0 — Disabled.

1 — Puts the thin client in a LOCK state when the screen saver is

activated. The user is prompted with an unlock dialog box to enter

the sign-on password to unlock the thin client. LockTerminal

settings are saved into NVRAM if LockTerminal=1 and

EnableLocal=yes is set in the wnos.ini le.

2— Puts the thin client in a LOCK state when the screen saver is

activated, however, the unlock dialog box cannot be viewed and

the desktop uses Blank the Screen as the screensaver.

3— Puts the thin client in a LOCK state when the screen saver is

activated, and the username and password are needed to unlock

the terminal. The Password eld in the Unlocking window is

invisible.

When you click OK or press the Return key, a message box pops up

to input the username and password to unlock the terminal.

NOTE:

The user must be signed on with a password for a Lock

action to take eect. If set in KeySequence, users can lock

the thin client at any time by pressing Ctrl+Alt+Left Arrow or

Ctrl+Alt+Right Arrow.

Type — Species which type of screensaver to use.

0 — Blank the Screen

1 — Flying Bubbles

2 — Moving Image

3 — Showing Pictures

Imagele — This is an optional parameter and species an image

le residing in the bitmap sub-folder under the home folder to be

used as a Moving Image screensaver.

If Type is set to 2 and no image le is present then the default Dell

Wyse logo is used.

If Type is set to 3, pictures residing in picture subfolder under the

home folder are displayed.

If SelectGroup=yes, then the pictures residing in the picture

subfolder under the group folder are displayed. For example,

/wnos/ini/{group_dir}/picture

If group pictures do not exist, global pictures are used. Supported

formats include JPG, GIF, PNG and BMP.

PictureTimer — Species the interval to wait in seconds to display

another picture. Default value is 6 seconds.

52 Parameters for WNOS INI, {username} INI, and $MAC INI Files

PictureOrder — Species the order of picture les to display. The

default is to use the order of sort from A to Z. If set to random,

pictures are displayed randomly.

PictureCheck — Species whether to check for picture les

servers or not.

NOTE:

If set to always, the picture les in le servers are checked

when the screen saver starts every time. By default, the

system checks for picture les only when the screen saver

starts for the rst time to decrease network trac.

PictureLayout— The optional parameteris used to specify the

arrangement on the desktop when pictures are displayed. For the

tile selection, the image is replicated across the desktop. For the

center selection, the image is placed at the center of the desktop

without any image size change. For the stretch selection, the image

is either expanded or shrinked to ll the desktop. The default value

is stretch.

Sleep—The optional parameter is used to specify the interval

minutes to stop soft screen saver and turn o monitor. After the

specied minutes, since software screen saver starts up, the

software screen saver is stopped and turns o the monitor until

screen saver is o. The value range is 0 to 180. The value 0 is

default which disables this function.

Shutdown={standby, turno} Default is standby.

Species the system state when shutting down the unit. If set to

standby, the ThinOS system is suspended. When the unit starts up,

it is resumed. It does not go to the BIOS and thus turns on quickly.

If set to turno, the system is turned o. When the unit starts up, it

rst starts the BIOS then ThinOS.

**ShutdownCount={0 to 60} (seconds)

or

**ShutdownCounter={0 to 60} (seconds)

ShutdownCount or ShutdownCounter — Species the number of

seconds to count down before the shutdown sequence starts upon

using the thin client power button when there are active sessions.

The default value is 10, however, to commence shutdown

immediately and prevent the display of the countdown dialog box,

set the value to 0.

ShutdownInfo={no, yes} Yes/no option to display various information such as System

Version, Terminal Name, IP Address, and MAC Address in shutdown

window.

S10WDMFlash=ash size Species the ash size. This value will be saved into NVRAM and

then eported to the WDM server.

NOTE:

This statement guarantees that all S10 thin clients function

with DDC regardless of ash size.

TimeServer=server_list

[TimeFormat={24-hour format, 12-hour format}]

[DateFormat={yyyy/mm/dd, mm/dd/yyyy, dd/mm/yyyy}]

TimeServer — Species the SNTP time servers to use for time

retrieval. If a time server is not dened, the client CMOS/BIOS

internal clock will be used as a reference.

TimeFormat — Default is24-hour format. Species the time

format to use.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 53

[GetBiosDT={no, yes}] DateFormat — Default is yyyy/mm/dd. Species the date format

to use.

NOTE:

The TimeFormat and DateFormat settings in a wnos.ini le

will be saved into NVRAM if EnableLocal=yes is set in the

wnos.ini le.

GetBiosDT — Default isno. Yes/no option to obtain time from

BIOS/CMOS when the timeserver is not available or cannot be

contacted.

For Example:

TimeServer=time.nist.com\TimeFormat=24-hour

formatDateFormat=mm/dd/yyyy

or

TimeServer=time.nist.gov\

TimeFormat=24-hour format\

DateFormat=mm/dd/yyyy

WakeOnLAN={yes, no} Default is yes.

Wake-on-LAN allows a thin client to be turned on or woken up by a

network message.

If WakeOnLAN=yes, ThinOS will respond for the Wake-On-LAN

packet for a remote wake up.

If WakeOnLAN=no, ThinOS will not respond for the Wake-On-LAN

packet.

NOTE:

To use the WakeOnLAN parameter with a C10, the C10 must

use BIOS version 1.0B_SPC001 or later.

Peripheral Settings for wnos.ini Files, {username} INI,

and $MAC INI Files

Table 6 contains the parameters used for conguring peripheral settings such as keyboard, monitor, mouse, printers and bluetooth devices.

The underlined values are default values.

Table 6. Peripheral Settings for wnos.ini Files, {username} INI, and $MAC INI Files

Parameter

* Global overrides identically-named user prole

** After sign o, user prole returns to global value

Description

DefaultPrinter={LPD1, LPD2, LPD3, LPD4, COM1, COM2, LPT1,

LPT2, SMB1, SMB2, SMB3, SMB4}

Species the default printer. Be sure the printer set as default is

enabled or the setting will be invalid.

Device=audio

volume={low, middle, high} or {0 to 25}

Species the local thin client audio volume.

volume — Default is middle. Species the volume level.

high — maximum volume

54 Parameters for WNOS INI, {username} INI, and $MAC INI Files

mute={0, 1, 2, 3}

[mic_vol={high, middle, low} or {0-25}]

[mic_mute={0, 1}]

[min_cache={1-50}]

[EnableSpeaker={yes, no}][

middle — medium volume

low — minimum volume

Values of 0-25 provide more exact volume level

mute — Default is 0. Option to enable/disable mute.

0 — no mute

1 — mutes audio

2 — mutes audio and system beep

3 — mutes system beep

mic_vol — Default is medium. Option to set volume levels to high,

middle or low.

high — maximum volume

middle — medium volume

low — minimum volume

Values of 0-25 provide more exact volume level.

mic_mute — Default is 0.

0 — no mute

1 — mutes audio

min_cache — Default is 1. This option is for conguring ThinOS

audio playback minimum buering amount in ten millisecond units.

This can be used when network bandwidth is not large enough to

play audio smoothly.

In such cases, set min_cache higher, so that ThinOS will buer

more audio data before playing the audio.

1 – ThinOS will buer at least 10 ms of audio data when playing

audio.

...

50 – ThinOS will buer at least 500 ms (0.5s) of audio data when

playing audio.

EnableSpeaker — Default is yes. Yes/no option to enable the

internal loud speaker.

Device=bluetooth

[Disable={yes, no}]

Set the parameter to disable bluetooth devices. The default value is

no. The value is stored into NVRAM. If you set Disable=yes, the

bluetooth devices are not initialized.

Device=camera

[format=raw]

[width={camera supported width}]

[height={camera supported height}]

[fps={camera supported fps}]

Specify the ThinOS local camera settings.

format — Support only for raw video type; format=raw is xed.

width — The width of the resolution that the local camera

supports.

height — The height of the resolution that the local camera

supports.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 55

[samplerate={0, 1, 2, 3, 4, 5}]

[optimize={no, yes}]

[Disable={yes, no}]

fps — The frame per second (fps) of the resolution that the local

camera supports.

samplerate — The software level sample rate based on fps to

optimize the performance, where the frame per second for the

camera is actually equal to the fps value multiplied by the

samplerate value. Samplerate values mean the following sample

rates:

0 — 1/1

1 — 1/2

2 — 1/3

3 — 1/4

4 — 1/5

5 — 1/6

optimize — Default is no. Yes/ no option to optimize the width,

height, and fps at 320 x 240 at 10 fps. That is, if optimize=yes, then

320 x 240 at 10 fps will be used for the local camera settings

regardless of the individual settings in width, height, and fps; as

long as the camera supports the 320 x 240 at 10 fps.

If optimize=yes and the camera does not support the 320 x 240 at

10 fps settings, an error will be present in the Event Log of ThinOS.

If optimize=no then the individual settings in width, height, and fps

will be used as long as the camera supports them.

Disable— When you specify Disable=yes, the device is disabled.

For example, the Camera tab in peripherals setting is disabled, the

Exclude video devices option in Global Connection Settings is

disabled. The device cannot be accessed at local and remote

sessions.

**Device=keyboard

[numlocko={no, yes}]

[repeatrate={0, 1, 2}]

[repeatdelay={0, 1, 2, 3, 4, 5, 6, 7}]

Device — Species the local keyboard.

numlocko — Default is no. Yes/no option to turn o the

NumLock of the keyboard.

repeatrate — Default is 1. Species the keyboard repeat rate.

0 — Slow

1 — Medium

2 — Fast

repeatdelay — Default is 2. Species the keyboard delay in

seconds, before repeat.

0 — 1/5

1 — 1/4

2 — 1/3

3 — 1/2

4 — 3/4

5 — 1

56 Parameters for WNOS INI, {username} INI, and $MAC INI Files

6 — 2

7 — No Repeat

NOTE:

These settings in a wnos.ini le will be saved into NVRAM if

EnableLocal=yes is set in the wnos.ini le.

Device=Rdeas

[DisableBeep={yes, no}]

[DisableKeystroke={yes, no}]

[SetCardType={yes, no} Conguration1={*} Conguration2={*} ]

[DisableInitialization={yes, no}]

[DisableLed={yes, no}

Device=Rdeas — Species the local Rdeas readers.

DisableBeep — Default is yes. Option disables the beep sound

when the card is read.

DisableKeyStroke — Default is yes. Option disables the keyboard

movements and key strokes.

SetCardType — Default is no. Used only for pcProx Plug readers.

• If set to yes, then the Conguration #1 initializes to HID Prox

608x compatibility and Conguration #2 initializes to RDR-758x

Equivalent.

• If set to no, then the card type remains unchanged.

DisableInitialization — Default is no. Option disables congurations

to the card reader.

DisableLed—If set to yes, then LED is turned o. If set to no, then

LED is controlled by Reader. The default value is not set.

Device=UsbSerial

[start=com{1~4}]

[com{1~4}=com{5~8}]

Species the rst COM port number that can be used by USB-

serial port.

For example, the rst USB-Serial port on a VL10 thin client is

COM2 by default, but it can be changed to COM3 with the INI le

Device=UsbSerial Start=COM3.

1 Without any ini setting: The COM number registered is related

with USB port number. Since USB port number is hardware

property, it is always mounted in the same order, and there is

no relation with the plug sequence.

2 If Device=UsbSerial start=COMx is set, then rule 1

does not work, the COM number is set by "x", and "x" range is

1-4, since ThinOS only supports maximum of four COM.

3 If COMx=COMy is set, the range for x is 1 - 4, and the real

name in ThinOS is considered. The range for "y" is 5 - 8, since

ICA running on ThinOS only supports maximum of eight COM.

NOTE: The INI [com{1~4}=com{5~8}] is applicable for

ICA connections only.

**DisableMouse={no, yes}

or

MouseDisable={no, yes}

DisableMouse — Default is no. Yes/no option to disabled mouse

pointer so that it is shown on the screen. The pointer is enabled if

any mouse activity occurs.

or

MouseDisable — Default is no. Yes/no option to disabled mouse

pointer so that it is shown on the screen. The pointer is enabled if

any mouse activity occurs.

LpdSpool={0-50} Species the size of spool to buer all the data before sending

them to the LPD printer. The range of value is 0 to 10, that is, 0 MB

Parameters for WNOS INI, {username} INI, and $MAC INI Files 57

to 10 MB. If the specied value is above the range, then the value is

set to 5.

The range of value is extended to 50.

In build 8.2_001 or later builds, the LPD data is spooled to a le in a

ram disk instead of a buer. So the value of the parameter will not

be related to the spool size as before.

If LpdSpool=0, the function is disabled, otherwise the function is

enabled.

LPTPortBind={yes, no} LPTPortBind — Default is Yes. Species the LPT bind to the USB

Port Policy.

If set to Yes, then the registered port follows the following binding

policy: LPT1 from USB ports 1/3/5/7 and LPT2 from USB posts

2/4/6.

If set to No, then the LPT port plugged in rst is LPT1 followed by

LPT2, and so on.

MicBoost={no, yes} Default is no.

Yes/no option to enable on-board microphone boost.

**MouseNewSpeed={1-9} Default is 6.

Value species the mouse speed within a range of 1 through 9,

where 1 is slowest and 9 is fastest. This parameter is the

replacement of MouseSpeed from build 7.0.1_07.

**MouseSwap={0, 1} 0/1 option to swap the mouse buttons. For example, for left-

handed use.

0 — No

1 — Yes

NetworkPrinter=host/queue

[PrinterID=Window driver name]

[Enabled={no, yes}]

NetworkPrinter — Species the conguration for the network

(LPD) printer in the same way as described for the Printer Setup

dialog box in the Dell Wyse ThinOS Administrator’s Guide. The host

and queue parameters dene the IP address and queue name of

the printer.

PrinterID — Species the Windows printer driver name.

Enabled — Default is yes. Yes/no option to enable the network

(LPD) printer.

Printer={COM1, COM2, LPT1, LPT2}

[Name=<name>]

[PrinterID=window_driver]

[Class=classname]

[Enabled={no, yes}]

[EnableLPD={no, yes}]

Default is COM1.

Printer — Species the local printer to congure.

Name — Species the name of the printer. This option must be

used.

PrinterID — If not specied, the default Generic/Text Only is used.

Class — Used in ThinPrint print for TPAutoconnect; the ThinPrint

technology of mapping the printer from the client side. It can group

printers to use the same template on the ThinPrint server side. The

strings PCL5, PS, and TXT are pre-dened classes. Class can be a

string with 7 characters.

58 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Enabled — Default is yes. Yes/no option to enable the printer.

EnableLPD — Default is no. Yes/no option to enable the LPD

service.

NOTE: The parameters must be specied in the order

shown.

Printer={LPD1, LPD2, LPD3, LPD4, LPD5-LPD36}

[LocalName=name]

[Host= host]

[Queue=queue]

[PrinterID=window_driver]

[Class=classname]

[Enabled={no, yes}]

Default is LPD1.

Printer — Species the LPD printer to congure.

LocalName — Species the name of the printer. If LocalName is

not specied, the Queue name is used.

Host — Species the host name of the printer.

Queue — Species the queue name of the printer.

PrinterID — Species the windows driver to use for the printer. If

not specied, the default Generic/Text Only is used.

Class — Used in ThinPrint print for TPAutoconnect; the ThinPrint

technology of mapping the printer from the client side. It can group

printers to use the same template on the ThinPrint server side. The

strings PCL5, PS, and TXT are pre-dened classes. Class can be a

string with 7 characters.

Enabled — Default is yes. Yes/no option to enable the printer.

These settings in a wnos.ini le will be saved into NVRAM if

EnableLocal=yes is set in the wnos.ini le.

NOTE:

The parameters must be specied in the order shown. For

backward compatibility, LPD is accepted as LPD1.

LPD2 – LPD4 are new in the 5.1. For WT1200 platform where Local

ash is absent, locally congured LPD2-LPD4 and SMB1 to SMB4

disappear on power cycle.

Printer={SMB1, SMB2, SMB3, SMB4}

[LocalName=name]

[Host=\[domain]\host]

[Name=share_name]

[PrinterID=window_driver]

[Class=classname]

[Enabled={no, yes}]

[EnableLPD={no, yes}]

[Username=username]

[Password=password]

[Domain=domain name]

Default is SMB1.

Printer — Species the shared Microsoft network printer to

congure.

LocalName — Species the name of the shared printer.

Host — Species the host name of the shared printer specied as

\domain\host when the host is congured within a Microsoft

domain, otherwise, host can be specied as \\host.

Name — Species the shared name of the shared printer.

PrinterID — Species the windows driver to use for the printer. If

not specied, the default Generic/Text Only is used.

Class — Used in ThinPrint print for TPAutoconnect; the ThinPrint

technology of mapping the printer from the client side. It can group

printers to use the same template on the ThinPrint server side. The

strings PCL5, PS, and TXT are pre-dened classes. Class can be a

string with 7 characters.

Enabled — Default is yes . Yes/no option to enable the printer.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 59

EnableLPD — Default is no. Yes/no option to enable the LPD

printer.

Username — Species the username of a user who can use the

SMB printer.

Password — Species the password of a user who can use the

SMB printer.

Domain — Species the domain name of the SMB printer.

**RepeatDelay={0, 1, 2, 3, 4, 5, 6, 7} Default is 2. Species the keyboard delay before repeat in seconds.

0 — 1/5

1 — 1/4

2 — 1/3

3 — 1/2

4 — 3/4

5 — 1

6 — 2

7 — No Repeat

**RepeatRate={0, 1, 2} Default is 1. Species the keyboard repeat rate.

0 — Slow

1 — Medium

2 — Fast

*Resolution=[DDC, 640X480, 800X600,

1024X768, 1152X864, 1280X720,

1280X768, 1280X1024, 1360X768,

1366X768, 1368X768, 1400X1050,

1440X900, 1600X900, 1600X1200,

1680X1050, 1920X1080, 1920X1200]

[Refresh=60, 75, 85}

[rotate={right}]

Default is DDC.

Resolution — Species the local display resolution. Option DDC

can be specied to select default display resolution.

NOTE:

When using the Wyse Y Cable, DDC will properly work on

both monitors by default. However, if connected to R10L/

R00x clients and you are using Dual DVI, then you must add

the following DualHead INI parameter and DualHead option

for DDC to properly work on both monitors:

Parameter: DualHead=yes

Option: ManualOverride=yes

Refresh — Species the local display refresh rate.

NOTE:

If the Resolution or Refresh parameter values are changed,

the thin client will reboot without notice to the user.

60 Parameters for WNOS INI, {username} INI, and $MAC INI Files

rotate — Rotate allows you to rotate monitors for viewing in

Portrait mode. For example:

screen=1 resolution=1280x1024 refresh=60

rotate=none

NOTE:

Due to processing power requirements, rotate is not

recommended and supported on the C class platforms at

this time.

IMPORTANT:

The Screen parameter must be placed before the Resolution

parameter. For example:

screen=1 resolution=1280x1024 refresh=60

rotate=none

*Screen={1,2} Default is 1.

Screen — Species the monitor for the Resolution parameter. You

can congure each monitor with its own resolution; the specic

monitor is set with the Screen= option.

NOTE:

The Screen parameter must be placed before the Resolution

parameter. For example:

screen=1 resolution=1280x1024 refresh=60

rotate=none

Connection Settings for wnos.ini Files, {username}

INI, and $MAC INI Files

Table 7 contains the parameters (and their options) used for conguring connection settings.

Table 7. Connection Settings: wnos.ini les, {username} INI, and $MAC INI Files

Parameter

* Global overrides identically-named user prole

** After sign o, user prole returns to global value

Description

**AltCacheDisable={no, yes} Default is no.

Yes/no option to disable the new cache mechanism allowing more

memory to be available to a user. This is developed with Citrix

Presentation Server 4.0 and Windows Server. If set to no, the new

cache mechanism is enabled.

**Alternate={no, yes} Default is no.

Yes/no option to use an alternate IP address returned from an ICA

master browser to get through rewalls. This setting in a wnos.ini

le will be saved into NVRAM if EnableLocal=yes is set in the

wnos.ini le.

AutoDetectNetwork={yes, no} RDP Only.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 61

Default is yes.

Yes/no option to enable RDP auto detect network feature. When

this option is set to yes the Optimize for low speed link and the

Desktop Experience options are disable by default.

**AutoSigno={no, yes}

[Shutdown={no, yes}]

[Reboot={no, yes}]

Default is no.

AutoSigno —Yes/no option to automatically sign-o a user when

the last opened session is closed.

Shutdown — Default is no. Yes/no option to shut down the thin

client. If shutdown is set to yes, the ShutdownCounter value is used

to control the count-down before the system is turned o.

Reboot — Default is no. Yes/no option to reboot the thin client. If

Reboot is set to yes, the ShutdownCounter value is used to control

the count down before the system is rebooted.

ClearLicense={no, yes} Default is no.

Yes/no option to clear the TSCAL license stored in the non-volatile

memory. It can be replaced by FixLicense=clean.

Connect={ICA, RDP} Connect — Connection protocol. Follow the ICA option list, see

Table 8: ICA Connect Options or RDP option list, see Table 9: RDP

Connect Options. Any options you use for your connection must be

on the same logical line; \can be used for line continuation, see

Rules and Recommendations for Constructing the INI Files.

ConnectionBroker={default, Microsoft, Quest, VMware} Default is default.

Species the Connection Broker type. Select VMware to enable

VDM XML support. If you enter VMware, the VMware logo appears

on the login screen.

For Dell vWorkspace broker, ConnectionBroker=Quest is

recommended.

*Device=Ethernet

[Speed={Auto, 10M HD, 10M FD, 100M HD,

100M FD, or 1000M}

[MTU=mtu]

[KeepAlive={1-600}]

[Warning={no, yes}]

[StaticIPWaitFileServer={0-255}]

Device — Species to use an Ethernet.

Speed — Default is auto. Species the ethernet speed to either

Auto, 10MHD, 10M FD, 100M HD, 100M FD, or 1000M. If Speed is

set in a wnos.ini le, the Speed statement in the {username}.ini le

will be disabled.

NOTE:

Device and Speed parameters can be replaced by the

EthernetSpeed parameter.

MTU — A maximum transmission unit value between 500 to 1500.

KeepAlive — Species a time value in seconds between 1 and 600

to keep an idle connection alive.

Warning — Default is no. Yes/no option to warn about an idle

connection. In the seconds of the specied KeepAlive, if the tcp

connection is idle and Warning=yes, one log will be printed for the

session. For example:

device=ethernet keepalive=20 warning=yes

62 Parameters for WNOS INI, {username} INI, and $MAC INI Files

StaticIPWaitFileServer — Default is 0. Species the timeout

threshold in seconds for cases of static IP.

NOTE: The default 0 turns o this parameter and allows

the system to wait the system default 120 seconds.

If the Speed parameter value is changed, the thin client

requires a reboot.

Device=vusb

[ForceRedirect=DeviceID]

[ForceLocal=DeviceID]

[Type={TCX, HDX}]

[InterfaceRedirect={no, yes}]

Device — Species the ID of a local USB device that is not

redirected by default.

ForceRedirect — Species a forced redirect of the local USB

device to the server. This parameter has priority over ForceLocal.

ForceLocal — Species that the local USB device should not be

redirected to the server. The DeviceID can be found in the event

log. For example, if you nd TCX USB: Local Device

(0x04f2,0x0112,0x03,0x01,0x01), set the parameter as:

Device=vusb

ForceRedirect=0x04f2,0x0112,0x03,0x01,0x01

Type —For Citrix Environments Only. This option allows you to

force the usage of HDX for USB virtualization instead of TCX. For

example:

Device=vusb Type=HDX

NOTE:

To use the TCX option, TCX Suite must be install on the

target server.

InterfaceRedirect — Default is no. Yes/no option to enable part of

a composite device to run locally and part of the device to run on a

remote session.

Device=Wireless

[Mode={Infrastructure, AdHoc}]

[SSID=ssid Channel={1-14}]

[WepKey={None, 1-4}]

[Key1=k1]

[Key2=k2]

[Key3=k3]

[Key4=k4]

[Key1Enc=key1 encrypted]

[Key2Enc=key2 encrypted]

[Key3Enc=key3 encrypted]

[Key4Enc=key4 encrypted]

[RoamSensitive={high, medium, low}]

[Algorithm={Open, SharedKey}]

Device — Denes the wireless Ethernet device remotely and saves

to the local NVRAM. Not all options are needed. For example, you

can dene Key1 to have a key of k1 and leave out Key2 through

Key4.

NOTE: See also IEEE8021X={yes, no}.

General example:

device=wireless SSID=THINOS RoamSensitive=low

k1 to k4 are any real values of 5 to 13 characters or 10 to 26 Hex

digits. Encrypted keys will overwrite unencrypted keys. Thus, if Key1

and Key1Encare both congured, then Key1Enc will overwrite Key1.

RoamSensitive — Denes the sensitivity level of wireless roaming

with respect to launching the Roaming daemon:

high - signal lower than -60 dBm

medium - signal lower than -70 dBm

low - signal lower than -80dBm

The RoamSensitive parameter is also used to enable wireless

roaming. If it is not congured in the INI le, roaming will never be

launched even if the signal is lower than -80dbm, unless it totally

loses a wireless signal.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 63

[DisableBand={None, 2.4G, 5G}]

[PreferBand={None, 2.4G, 5G}]

[Priority=ssid_list]

[DisableN={no, yes}]

[DisableWlan={yes, no, EnetUp}]

Algorithm — Species the authentication method of WEP

between ThinOS and the access point. If set to Open, open

authentication will be selected. If set to ShareKey, shared key

authentication will be selected.

DisableBand — Default is None. Use to disable 2.4G or 5G 802.11

band.

PreferBand —This parameter is used to set the priority of wireless

connection band, and select the 2.4G or 5G access point to

connect. Default is None.

Priority — sets the priority of wireless proles. The ssid list is

separated by a semicolon or comma and the priority is from high to

low.

DisableN — Default is no. Yes/no option to disable 802.11n Wi-Fi

wireless networking.

DisableWlan— Used to disable the wireless connection. If

DisableWlan=EnetUp, and the Ethernet is on while booting, the

wireless connection is disabled.

Device=Wireless Mode=Infrastructure

SSID=ThinIsIn

IEEE8021X=yes network=wireless

profile=ThinIsIn access=WPA2-ENT

eap=yes eaptype=EAP-PEAP peapeap=EAP-MSCHAPV2

Device=Wireless Mode=Infrastructure

SSID=wtos_95 roamsensitive=high

IEEE8021X=yes network=wireless profile=wtos_95

access=WPA2-ENT

eap=yes eaptype=EAP-PEAP peapeap=EAP-MSCHAPV2

Device=Wireless Mode=Infrastructure

SSID=wtos_11n

IEEE8021X=yes network=wireless

profile=wtos_11n access=WPA2-PSK

wpa2pskpwd=2wsx3edc

Device=Wireless

Priority="wtos_11n,wtos_95,ThinIsIn"

DISABLETSGW IMPORTANT: DISCONTINUED. DO NOT USE. See

TSGWENABLE

**EnableLocal={no, yes}

[HideDefault={no, yes}]

Default is no.

Yes/no option to enable locally congured entries to show in the

Connect Manager list. When connections dened in local NV-RAM

are displayed in the Connect Manager, they are marked with an

asterisk.

If EnableLocal=yes is in a wnos.ini le, then the global information

will be saved into NVRAM.

NOTE: The global information includes: SEAMLESS,

ALTERNATE, Reconnect, icaBrowsing, LowBand,

NoReducer, Time settings, and Printer settings in

awnos.ini le.

HideDefault — Default is no. Yes/no option to hide the default ICA

and RDP connections that are present on the devices.

ENABLETSGWSAMEINFO IMPORTANT: DISCONTINUED. DO NOT USE.

64 Parameters for WNOS INI, {username} INI, and $MAC INI Files

*EthernetSpeed={Auto, 10M HD, 10M FD, 100M HD, 100M FD,

1000M}

Default is auto.

EthernetSpeed — Species the Ethernet Speed to either Auto,

10M HD, 10M FD, 100M HD, or 100M FD. Once specied, it is saved

in the non-volatile memory. This parameter can be replaced by the

Device and Speed parameters.

NOTE:

If the EthernetSpeed parameter value is changed, the thin

client will require a reboot.

Fastconnect={yes, no}

[Key={F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, Pause/

Break}]

[Ctrl={yes, no}]

[Alt={yes, no}]

[Connect={ICA, RDP, PCoIP}]

[List={*|app1|server1;app2}]

[Title={*_seamless_window_title*]

If you set the parameter to yes, press the special key to launch

specied desktop or published application. If the desktop or

published application is available, pressing the key brings it to the

foreground.

If you set to no, the followed options are ignored and disables fast

connect functions. The followed options need to be congured to

one or several fast connect setting.

The option Key species the fast connect key.

The option Ctrl species whether the Control key is combined or

not, for fast connect key.

The option Alt species whether the Alt key is combined or not, for

fast connect. The option Connect species the protocol of fast

connecting session.

The option List species the connecting list of the desktop or

published application. It supports wildcards * to match the session

host/application or description. Also it supports a list separated by ;

or ,.

The option Title species the seamless window name. It supports

wildcards * to match the window name. For a seamless window, it

is needed because seamless windows share session. It uses List

option to match session and uses the option Title to match the

seamless window.

For example,

fastconnect=yes \

key=F1 ctrl=no alt=no connect=ica list="Excel 2013" title="*Excel*"

\

key=F2 ctrl=yes alt=no connect=ica list="XA76-2008R2*".

When you press F1, the application Excel 2013 is launched. If there

is a seamless window which matches the title *Excel* in this

session, the seamless window is brought to the foreground, else it

is launched.

When you press Ctrl+F2, the desktop XA76-2008R2* is launched.

If the desktop is available, it is brought to the foreground.

FastDisconnect={yes, no, Signo}

[CtrlKey={yes, no}]

[AltKey={yes, no}]

[PowerButton=signo]

Default value is no.

If the value is set to yes, pressing the F12 (default) key or the key

dened in FastDiconnectKey= statement will close the active

window of the session. If the active window is a seamless window,

the action will only close the window. If the window is not a

seamless window, then the session will be disconnected.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 65

If the option CtrlKey and/or AltKey is set to yes, then the function

key should be combined with Ctrl key and/or Alt key.

For PCoIP session, press Ctrl+Alt+F12 key combination to

disconnect the session unless FastDisconnect=no is congured.

This combined disconnect key is compatible with other platforms

such as P25 and Linux.

If the value is set to Signo, pressing the F12 (default) or the key

dened in FastDisconnectKey= statement will disconnect all

sessions and return to the signon window.

If PowerButton is set to signo, pressing the power button of the

unit after you sign on will disconnect all sessions and return to the

logon window. Otherwise, the unit will shutdown normally.

FastDisconnectKey={F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12,

Pause\Break}

Species the disconnect key that will close the active window from

the session.

FixLicense={Factory, clean, yes, no, OldFormat} Default is no.

Species the option to replace the TSCAL license stored in the

non-volatile memory.

NOTE:

The OldFormat value species to keep the same license

format as version 5.2.x.

HideIP={no, yes} Default is no.

Yes/no option to hide the information of the connection host or IP.

Some examples include:

- When moving a mouse cursor over the connection icons on the

desktop, a balloon help pop-up displays ‘…’ instead of the host

name.

- When a Reconnect to a connection message or an ICA error

message window displays, the connection description displays

instead of host name.

- When moving a mouse cursor over the PN icon, the connected

PN servers do not display.

Hosts=<hosts le name> Species the le name of the hosts. This le is a simple text le

that associates IP addresses with hostnames, one line per IP

address. The length of the le name is limited to 63 characters.

The le must be placed in le server and can be cached if set

MirrorFileServer=yes in the wnos.ini.

When resolving a host name, the system will initially look in the le

and if not found, will search DNS, WINS, and so on. The following is

an example of format in the hosts le:

10.151.122.1 gateway.ctx.com

10.151.122.123 myvm.ctx.com

**icaBrowsing={udp, http}Default is http.

Establishes the default browsing protocol. This setting can be

overridden by the parameter HttpBrowsing in each connection

66 Parameters for WNOS INI, {username} INI, and $MAC INI Files

property. The method of browsing selected must match the

method provided by the server(s) being accessed.

This setting in a wnos.ini le will be saved into NVRAM, if

EnableLocal=yes is set in the wnos.ini le.

IEEE8021X={yes, no}

network={wired, wireless}

[Prole=ssid]

[access={WPA-PSK, WPA2-PSK, WPA-ENT, WPA2-ENT}]

[eap={yes, no}]

[servervalidate={yes, no}]

[servercheck={yes, no}]

[servername={"servername for EAP-TLS, EAP-PEAP, EAP-FAST"}]

[eaptype={None, EAP-LEAP, EAP-TLS, EAP-PEAP, EAP-FAST}]

[leapun={username for EAP-LEAP}]

[leappwd={password for EAP-LEAP}]

[leappwdEnc={password encrypted for EAP-LEAP}]

[tlsauthtype={user, machine}]

[tlsclntcert={client certicate lename for EAP-TLS}]

[tlsclntprikey={lename of certicate with private key for EAP-

TLS}]

[tlsclntprikeypwd={password for private key}]

[tlsclntprikeypwdEnc={password encrypted for private key}]

[peapeap={EAP-MSCHAPV2, EAP-GTC}]

[peapidentity={identity/username for PEAP}]

[peapmschapun={username for EAP-PEAP/ EAP-MSCHAPV2}]

[peapmschappwd={password for EAP-PEAP/EAP-MSCHAPV2}]

[peapmschappwdEnc={password encrypted for EAP-PEAP/EAP-

MSCHAPV2}]

[peapmschapdm={domain for EAP-PEAP/ EAP-MSCHAPV2}]

[peapmschaphidedm={yes,no}]

[peapsinglesignon={yes, no}]

[peapgtcun={username for EAP-PEAP/ EAP-GTC}]

[peapgtcpwd={password for EAP-PEAP/ EAP-GTC}]

[peapgtcpwdEnc={password for encrypted for EAP-PEAP/EAP-

GTC}]

[wpapskpwd={passphrase for WPA-PSK}]

1If IEEE8021X is set to no, then all parameters following it is

ignored.

2 If network is not congured, the conguration is ignored.

3 The key left of equal is case sensitive, and the value right of

equal case is not case sensitive except for credential

information; for example username, password or certicate

lename.

4 If two entries exist in an INI le, one each for wired and

wireless, both will take eect; for example IEEE8021X=yes

network=wired EAP=yes … IEEE8021X=yes network=wireless

access=WPA-ENT …

5 All EAP credential information is stored whatever the eaptype

setting.

6 The default values are underlined.

7 All passwords here should be encrypted.

8 The wildcard server include three entries in INI le. If both the

servervalidate entry and servercheck entry are set to yes, the

servername entry is valid.

9 Server certicate validation is mandatory in EAP-TLS

authentication. If the eaptype entry is set to EAP-TLS, the

servercheck entry must be set to yes.

10 Server list must be included in double quotation marks. For

example IEEE8021X=yes Network=wireless access=WPA2-

ENT eap=yes servervalidate=yes servercheck=yes

servername=";test.com;wireless98; test.com" eaptype=eap-

peap peapeap=eap-mschapv2 peapmschapun=administrator

peapmschappwd=password

.

11 Additional option timeoutretry species the retry times when

8021x authentication times out, which means that it is only

validated when the optional network type is wired. For

example, timeoutretry=3 allows you to retry thrice after 8021x

authentication times out.

12 Additional option Prole species the type of ssid

authentication to be congured. When we support multiple

ssid wireless settings, the statement ieee8021x must be after

the statement device=wireless, and one additional prole

parameter is needed to identify the type of ssid authentication

which is congured. For example,

#ThinIsIn

Device=Wireless Mode=Infrastructure

SSID=ThinIsInIEEE8021X=yes network=wireless

prole=ThinIsIn access=WPA2-ENT eap=yes eaptype=EAP-

PEAP peapeap=EAP-MSCHAPV2 peapmschapdm=wyse

#wtos_95

Device=Wireless Mode=Infrastructure

SSID=wtos_95IEEE8021X=yes network=wireless

prole=wtos_95 access=WPA2-ENT eap=yes eaptype=EAP-

PEAP peapeap=EAP-MSCHAPV2

Parameters for WNOS INI, {username} INI, and $MAC INI Files 67

[wpapskpwdEnc={passphrase encrypted for WPA-PSK}]

[wpa2pskpwd={passphrase for WPA2-PSK}]

[wpa2pskpwdEnc={passphrase encrypted for WPA2-PSK}]

[encryption={TKIP|CCMP}]

[fasteap={EAP-MSCHAPV2, EAP-GTC}]

[fastidentity={Identity for EAP_FAST}]

[fastmschapun={username for EAP-FAST/EAP-MSCHAPV2}]

[fastpmschappwd={password for EAP-FAST/EAP-MSCHAPV2}]

[fastmschappwdEnc={password encrypted for EAP-FAST/EAP-

MSCHAPV2}]

[fastmschapdm={domain for EAP-FAST/EAP-MSCHAPV2}]

[fastmschaphidedm={yes,no}]

[fastsinglesignon={yes, no}]

[fastgtcun={username for EAP-FAST/EAP-GTC}]

[fastgtcpwd={password for EAP-FAST/EAP-GTC}]

[fastgtcpwdEnc={password for encrypted for EAP-FAST/EAP-

GTC}]

Example: IEEE8021X=yes network=wireless access=wpa-ent

eap=yes eaptype=eap-tls tlsclntcert=user.cer

tlsclntprikey=user.pfx tlsclntprikeypwd=12345678

OR

IEEE8021X=yes network=wireless access=wpa-ent eap=yes

eaptype=eap-tls tlsclntcert=user.cer tlsclntprikey=user.pfx

tlsclntprikeypwd=12345678 leapun=user1 password=1234

peapmschapun=user1 peapmschappwd=12345

peapmschapdm=wyse.com

IEEE8021X=yes network=wired eap=yes eaptype=eap-tls

tlsclntcert=user.cer tlsclntprikey=user.pfx

tlsclntprikeypwd=12345678

By default, peapidentity is same as peapmschapun.If

peapmschaphidedm is set to yes, the domain will use saved

peap MSCHAP domain name and the prompts dialog will not

include the domain eld when you perform ieee8021x

authentication.

The following example describes wildcard server validation:

IEEE8021X=yes network=WIRED access=WPA2-ENT

servervalidate=yes eap=yes eaptype=EAP-PEAP

servercheck=yes servername=w2k8-

ACS-64.sqawirelsess.com peapmschapdm=EAP-MSCHAPV2

peapgtcun=sqawirless2 peapmschappwd=123!@#qwe

The username of ieee8021x (fastmschapun, peapmschapun,

peapgtcun, leapun) can be congured as system variables like

$mac, $sn etc. By default, fastidentity is same as

fastmschapun.

If fastmschaphidedm is set to yes, the domain uses saved

EAP_FAST MSCHAP domain name, and the prompts dialog

does not include the domain eld when you perform ieee8021x

authentication.

The following example describes wildcard server

validation:IEEE8021X=yes network=WIRED access=WPA2-

ENT servervalidate=yes eap=yes eaptype=EAP-FAST

servercheck=yes servername=w2k8-

ACS-64.sqawirelsess.com fastmschapdm=EAP-MSCHAPV2

fastgtcun=sqawirless2 fastmschappwd=123!@#qwe

**Inactive={0, to 480} (minutes)

[NoSessionTimer=0-480]

Default is 0.

Species that if there is no keyboard or mouse use in the

congured time in minutes, it will sign o or shutdown or reboot

depending on AutoSigno= …

If NoSessionTimer is set, then when there is an active sessions, use

this timer to replace the Inactive value.

The following controls whether to reboot or shutdown or sign o.

AutoSignoff=yes [Shutdown=yes] [Reboot=yes]

IPProto=ICMP

[DisableTStamp={yes, no}]

[DisableEcho={yes, no}]

Congures the ICMP protocol.

DisableTStamp — If DisableTStamp=yes, the system will not

reect the ICMP timestamp (13) request.

68 Parameters for WNOS INI, {username} INI, and $MAC INI Files

DisableEcho — If DisableEcho=yes, the system will not reect the

ICMP echo (8) request. In this case, the unit cannot be pinged.

**LowBand={no, yes} Default is no.

Yes/no option to enable optimization for low speed connections,

such as reducing audio quality or decreasing protocol-specic

cache size or both.

This setting in a wnos.ini le will be saved into NVRAM, if

EnableLocal=yes is set in the wnos.ini le.

MMRCodecCong=AUDIO

[disableac3={no, yes}]

[disablempeg={no, yes}]

[disablewma1={no, yes}]

[disablewma2={no, yes}]

[disablewma3={no, yes}]

[disablemp3={no, yes}]

[disablepcm={no, yes}]

MMRCodecCong — Only for platforms with TCX Multimedia.

Species the audio to allow the disabling of the various codec

options when playing audio.

disableac3 — Default is no. Yes/no option to disable the ac3 codec

when playing audio.

disablempeg — Default is no. Yes/no option to disable the mpeg

codec when playing audio.

disablewma1 — Default is no. Yes/no option to disable the wma1

codec when playing audio.

disablewma2 — Default is no. Yes/no option to disable the wma2

codec when playing audio.

disablewma3 — Default is no. Yes/no option to disable the wma3

codec when playing audio.

disablemp3 — Default is no. Yes/no option to disable the mp3

codec when playing audio.

disablepcm — Default is no. Yes/no option to disable the pcm

codec when playing audio.

MMRCodecCong=VIDEO

[disablempeg1={no, yes}]

[disablempeg2={no, yes}] [disablejpeg={no, yes}]

[disablewmv1={no, yes}]

[disablewmv2={no, yes}]

[disablewmv3={no, yes}]

MMRCodecCong — Only for platforms with TCX Multimedia.

Species the video to allow the disabling of the various codec

options when playing video.

disablempeg1 — Default is no. Yes/no option to disable the mpeg1

codec when playing video.

disablempeg2 — Default is yes. Yes/no option to disable the

mpeg2 codec when playing video.

disablejpeg — Default is no. Yes/no option to disable the jpeg

codec when playing video.

disablewmv1 — Default is no. Yes/no option to disable the wmv1

codec when playing video.

disablewmv2 — Default is no. Yes/no option to disable the wmv2

codec when playing video.

disablewmv3 — Default is no. Yes/no option to disable the wmv3

codec when playing video.

**NoReducer={no, yes} Default is no — Enables compression.

Yes/no option to turn o compression. To turn o compression,

enter yes. Used here this parameter is a global statement for all

connections. It sets the default value of NoReducer.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 69

NOTE:

By default both the ICA and RDP protocols compress their

data to minimize the amount of data that needs to traverse

the network.

This compression can be as much as 50 percent for text-

based applications such as Microsoft Word and 40 percent

less for graphics applications than the uncompressed data

streams.

OneSignServer=onesign_server

[DisableBeep={no, yes}

[KioskMode={no, yes}]

[EnableFUS={no, yes}]

[TapToLock={0, 1, 2}]

[EnableWindowAuthentication={yes,no}]

[AutoAccess={VMW,XD,XA}]

[NetBIOSDomainName={no, yes}]

Species a list of host names or IP addresses with optional TCP

port number or URLs of Imprivata OneSign servers.

IMPORTANT: An https protocol must be used.

OneSign virtual desktop access oers a seamless authentication

experience and can be combined with single sign-on for no click

access to desktops and applications in a virtual desktop

environment.

The following inputs are acceptable values:

https://ip

or

https://FQDN

DisableBeep — Default is no. Yes/no option to set the Rdeas

reader to mute when a card is tapped.

KisokMode — Default is no. Yes/no option to allow the OneSign

user to share the client desktop.

EnableFUS — Default is no. Yes/no option to set the Citrix client

to remain running when switch users.

TaptoLock — Default is 2. Only active when KioskMode=yes.

Species tap to lock.

If TapToLock=0, then tap a card to lock terminal is disabled. If

TapToLock=1 (Tap to lock), then use the proximity card to lock the

terminal.

If TapToLock=2 (Tap over), then lock the terminal and log in a

dierent user.

EnableWindowAuthentication — Default is yes. Yes/no option to

sign-on with the user’s Windows credentials to pre-dened broker

if the OneSign sign-on fails.

AutoAccess — Species the corresponding type of broker to

automatically start. If not dened, the broker type is obtained from

the Imprivata Server setting of the computer and user policy. If

none of them is dened, then the rst available broker server from

the Imprivata server is started.

NOTE:

AutoAccess can be set in [username].ini and wnos.ini,

however, the wnos.ini, has priority over [username].ini.

NetBIOSDomainName — Default is no. Yes/no option to enable

the authentication to the broker server using the NetBIOS domain

70 Parameters for WNOS INI, {username} INI, and $MAC INI Files

name. If set to yes, the Imprivata domain list will show NetBIOS

domain name and the card user will authenticate to the broker

server using the NetBIOS domain.

PnliteServer=<List of {IP address, DNS names, or URLs} >

[ReconnectAtLogon={0, 1, 2}]

[ReconnectFromButton={0, 1, 2}]

[AutoConnectList={*/ appname1;appname2; appname3...}]

[timeout=5…300]

[CAGRSAAuthMethod={LDAP, RSA}]

[CAGAuthMethod={LDAP, RSA}]

[CAGAuthMethod={LDAP+RSA, RSA+LDAP}]

[RequestIconDataCount={0-65535}]

[DefaultSettings={XenApp, XenDesktop}]

[SmartcardPassthrough={yes, no}]

[StoreFront={no, yes}]

PnliteServer=List of {IP address, DNS names, or URLs}

PnliteServer — Species the list of IP addresses or host names

with optional TCP port number or URLs of PNAgent/PNLite

servers. The list is empty by default.

Each entry with optional port is specied as Name-or-IP:port,

where port is optional; if not specied, port 80 is used as the

default.

If a port other than 80 is used, the port number must be specied

explicitly with the server location in the form IP:port or name:port.

Once specied, it is saved in the non-volatile memory.

The statement PNAgentServer and Web interface for Citrix

MetaFrame Server is equal to this statement.

NOTE:

PnliteServer and the DomainList parameters can be used in a

{username}.ini le, but generally are used only in a wnos.ini

le.

The PNAgent/PNLite server list and associated domain list

optionally can be entered in DHCP server options 181 and

182, respectively. If entered in both places, the entries from

the Table 7: Connection Settings: wnos.ini les, {username}

INI, and $MAC INI Files will take precedence. However, the

{username}.ini le will override the wnos.ini le if the identical

parameters with dierent values exist in the {username}.ini

le.

NOTE:

When Multifarm=yes, use # to separate failover servers, and

use a comma (,) or a semicolon (;) to separate servers that

belong to dierent farms.

ReconnectAtLogon — Species the reconnection function at log

in.

Default is 0 — disables the option.

1 — reconnects to disconnected sessions only.

2 — reconnects to active and disconnected sessions.

ReconnectFromButton — Species the reconnection function

from the reconnect command button.

Default is 0 — disables the option.

1 — reconnects to disconnected sessions only.

2 — reconnects to active and disconnected sessions.

AutoConnectList — Species the PNA applications that will be

automatically started when using PNA to sign on. If

AutoConnectList=*, then all the PNA applications will be

automatically connected.

The autoconnectlist is the connection description of application or

host name which can use the wildcard * to match the string.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 71

IMPORTANT: Appname values are case sensitive.

Timeout — Species the time in seconds where a client will try to

establish a connection before reporting that it is unreachable.

CAGRSAAuthMethod or CAGAuthMethod — CAGAuthMethod

option is used for CAG authentication conguration.

NOTE: This option replaces CAGRSAAuthMethod. If

CAGAuthMethod=RSA which is same as the prior

CAGRSAAuthMethod=RSASecurid, an extra passcode

eld needs to be input except username/password/

domain. If CAGAuthMethod=LDAP, no passcode eld is

needed.

• CAGAuthMethod={LDAP+RSA, RSA+LDAP} — Used for CAG

authentication conguration.

• If CAGAuthMethod = LDAP+RSA, an extra passcode eld

needs to be input except username/password/domain. If the

CAG server is congured for a double authentication policy, this

ini corresponds to the rst auth LDAP and second auth RSA.

• If CAGAuthMethod = RSA+LDAP, it has the same result with

CAGAuthMethod = RSA, compared to LDAP+RSA. If CAG

server congure double authentication policy, this ini

correspond to First auth RSA and Second auth LDAP.

RequestIconDataCount — RequestIconDataCount is used for

requesting 32-bit color icons. It is a counter which means that only

the count of the icons will be requested. The default number is 10.

For example, if set RequestIconDataCount=0, no icon data will be

requested. If set RequestIconDataCount=5, only 5 icons are

requested.

DefaultSettings — Species the default settings for XenApp or

XenDesktop.

Xen App Default Settings:

1 SignOn=Yes

2 PnliteServer= RequestIconDataCount=20

3 desktopcolordepth=32

4 LongApplicationName=yes

5sessioncong=ica progressivedisplay=yes ondesktop=yes

6 device=audio volume=high

7 Seamless=yes FullscreenReserved=yes

8sessioncong=all mapdisks=yes

9 Enabled by default: Disks, Serials, Sound

10 Disabled by default: USB, Printers, Smart Cards

Xen Desktop Default Settings:

1 SignOn=Yes

2 sysmode=vdi toolbarclick=yes toolbardelay=3

3sessioncong=ica progressivedisplay=yes

4 PnliteServer=

5AutoSigno=yes

6 Enable by default: Printers, Serials, USB, Sound

7 Disabled by default: Disk, Smart Cards

72 Parameters for WNOS INI, {username} INI, and $MAC INI Files

SmartcardPassthrough — Default is yes. Yes/no option to enable/

disable the smartcard pass through mode.

StoreFront — Default is no. Yes/no option to support Citrix

StoreFront Authentication. The value will be saved into NVRAM.

RTPTosDscp={Default/CS1/CS2/CS3/CS4/CS5/CS6/CS7/AF11/

AF12/AF13/AF22/AF23/AF31/AF32/AF33/AF42/AF43}

Sets RTP/UDP audio channel in the TOS elds.

SaveSysinfo={ftp, usb} Recommended for use under Customer Support direction for

troubleshooting purposes. Species where the ThinOS event logs

will be saved.

NOTE:

Be sure that the Privilege parameter level is set to high

(Privilege=high) and that the EnableTrace option for

Privilege is set to yes (EnableTrace=yes).

•FTP — If you specify SaveSysinfo=ftp, the ThinOS

event logs will be saved to an FTP server.

The FTP server must have read/write permissions, and

that event log les saved remotely are overwritten each

time the client is booted unless the append=yes option is

present.

The syntax for this command is as follows:

SaveSysInfo=ftp://<host>/wyse/wnos/

trace/$mac-log.txt

SaveSysInfo=ftp://<host>/wyse/wnos/

trace/$mac-log.txt append=yes

•USB — SaveSysinfo=usb species that the ThinOS

event logs will be saved.into the last mounted USB disk.

The le used for saving Event log information is named

WTOS_log.txt and is located at the root path of the USB

disk.

IMPORTANT:

By default, smart card Context log (0x1), Handle log

(0x2), Status log (0x4), and Transfer log (0x8) data

is not displayed in the event log. However, there are

occasions where this information can be useful in

debugging Smart Card related issues.

The following INI le option (ScardLog) to the

SaveSysInfo command can be used to enable the

logging of this data to the event log.

SaveSysInfo=usb ScardLog=0xF

**Seamless={no, yes}

[HideTaskbar={0, 1, 2, 3}]

[FullscreenReserved={no, yes}]

Seamless — Default is no. Yes/no option to set the default

resolution for ICA published applications to Seamless for ICA

connection parameters.

HideTaskbar — Default is 0. Species the status of the taskbar

when maximizing the seamless window.

0 — Do not hide the taskbar.

1 — Taskbar will be hidden when maximizing the seamless window

to full screen. Moving the mouse over the lowest bottom of the

screen will display the taskbar. This setting excluding the

Parameters for WNOS INI, {username} INI, and $MAC INI Files 73

FullscreenReserved parameter in a wnos.ini le will be saved into

NVRAM if EnableLocal=yes is set in the wnos.ini le.

NOTE:

• When set Seamless=yes HideTaskbar=2, it removes the

auto-hide taskbar function but it reports the full

resolution to the ICA server in a similar way to

HideTaskbar=1.

• When set Seamless=yes HideTaskbar=3, the maximized

size does not cover the taskbar, but the session size on

the server side is reported as the full-screen size.

• When set Seamless=yes FullscreenReserved and the

applications are congured for fullscreen mode, they will

be launched in fullscreen mode, not seamless mode.

SecureMatrixServer=<SecureMatrix Server

Host name or IP address/FQDN or URL>

[EnableSelectTable]

Species the Host name or IP address/FQDN or URL of the Secure

Matrix server. Http or https protocol usage is decided by the server

conguration. If SecureMatrixServer is dened, the user must pass

authentication with the Secure Matrix server rst, and then there is

a seamless log in to the brokers if the server can provide the

correct broker credentials, if not, the user must enter broker

credentials to log in.

For Example: SecureMatrixServer=https://gsb01.bjqa.com

NOTE:

Before using this parameter, use the Secure Matrix

documentation to set up the Matrix Server. Also, be sure you

import the relevant GSB Server Certicate le when using

https.

EnableSelectTable enables you to select the table type (3 or 4 tabs)

when you change the password (SMXBridge server 3.9 start

supports this feature). Default value is No.

SelectGroup={no, yes}

[Default=default_desc]

description=group1

[groupname=name1]

[description=group2]

[groupname=name2]

Default is no.

SelectGroup — Yes/no option to allow a user to select from a

group list on the Log on dialog box during a log in. If yes, the

description will display in the group list box.

groupname — The group name is used to identify the group

including the directory and le name. If not dened, the description

will become the group name.

The Default option following "SelectGroup=yes" can specify the

default group. The value is one of group description dened after

that. After you select another group and sign o, this default group

will be selected.

If default option is not specied, the last selected group will be

selected in the next sign on.

For example:

SelectGroup=yes \

default="Sus team" \

description="Dev team" groupname=dev \

description="Sus team" \

description="SQA team" groupname=sqa \

description="guest"

74 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Group 1: Description="Dev team" groupname=dev

The le \wnos\ini\dev\dev.ini must be created in the le server. In

the dev.ini, the broker, domain list, or connections can be dened

for the dev team.

Group 2: .Description="Sus team"

The le \wnos\ini\Sus team\Sus team.ini must be created in the

le server. In the Sus team.ini, the broker, broker list, or connections

can be dened for the Sus team.

Group3...4...n...and so on.

After a user selects a group, the system will load the group ini le

rst, and then load the \wnos\ini\{group_name}\username.ini. If

the username.ini in the group directory is not found, it will attempt

to load \wnos\ini\username.ini as before.

Because the group list may dene dierent brokers, the

SelectServerList statement will be invalid if set SelectGroup=yes.

Serial={COM1, COM2, COM3, COM4}

[Baud={1200, 2400, 4800, 9600, 19200,

38400, 57600, 115200}]

[Parity={None, Even, Odd}]

[Stop={1, 1.5, 2}]

[Size={5, 6, 7, 8}]

[Flow={None, XON/XOFF, CTS/RTS, Both}]

[Touch={no, yes}]

[Touch_XYReverse={no, yes}]

[Touch_type={elo, microtouch, fastpoint}]

Serial — Default is COM1. Species the local serial ports

conguration.

Baud — Species the local serial port baud rate.

Parity — Species the local serial port parity.

Stop — Species the local serial port stop.

Size — Species the local serial port size.

Flow — Species the local serial port ow.

Touch — Default is no. Yes/no option to denote that a serial touch

screen is attached.

Touch_XYReverse — Default is no. Yes/no option to denote a

reversal of the X and Y coordinates which are needed for some

touch screens.

Touch_type — Default is elo. Species the type of touchscreen

being used.

NOTE: Options must be specied in the order shown.

9035366678

**SessionCong=ALL

[unmapprinters={no, yes}]

[unmapserials={no, yes}]

[smartcards={no, yes}]

[mapdisks={no, yes}]

[disablesound={no, yes}]

[unmapusb={no, yes}]

[DisksReadOnly={no, yes}]

[MouseQueueTimer={0–99}]

SessionCong — Species the default settings of the optional

connection parameters for all sessions.

unmapprinters — Default is no. Yes/no option to un-map printers.

unmapserials — Default is no. Yes/no option to un-map serials.

smartcards — Default is no. Yes/no option to use smartcards.

mapdisks — Default is no. Yes/no option to map disks.

disablesound — Default is no. Yes/no option to disable sound.

unmapusb — Default is no. Yes/no option to un-map USBs.

DisksReadOnly — Default is no. Yes/no option to mount mass

storage disks as read-only.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 75

[WyseVDA={no, yes}]

[WyseVDA_PortRange=startPort, endPort]

[UnmapClipboard={no, yes}]

[DefaultColor={0,1,2}]

[VUSB_DISKS={yes, no}]

[VUSB_AUDIO={yes, no}]

[VUSB_VIDEO={yes, no}]

[VUSB_PRINTER={yes, no}]

[FullScreen={no, yes}]

[Resolution={default, vga_resolution}]

[DisableResetVM={no, yes}]

[WyseVDAServerPort=serverPort]

[FontSmoothing={yes, no}]

[AutoConnect={yes, no}]

[MultiMonitor={yes, no}]

[EnableImprivataVC={yes,no}]

[Locale=LocaleID]

[SessionLogoTimeout=seconds]

[GroupSession={yes,no}]

MouseQueueTimer — Species the default queue timer of a

mouse event in an ICA or RDP session (in 1/100 of a second). It can

be used to adjust the bandwidth of a network.

WyseVDA — Default is no. Yes/no option to enable Virtual Desktop

Accelerator for all ICA and RDP sessions.

WyseVDA_PortRange — Sets the ThinOS VDA client port range.

The port range must follow these rules:

1 The port range is a list of start port and end port separated by

a semicolon (;) or a comma (,).

2 Both ports must be between 1 and 65535.

3 The end port must be greater than start port.

For example, WyseVDA_PortRange=3000,3010, the start port is

3000, the end port is 3010.

UnmapClipboard — Default is no. Yes/no option to disable

clipboard redirection for all sessions. For ICA and RDP, species if

redirecting the clipboard. This setting in wnos.ini will be saved into

nvram, if EnableLocal parameter is set to yes in wnos.ini.

DefaultColor — Species the default color depth to use for the

session 0=256, 1=High color, 2=True Color.

VUSB_DISKS, VUSB_AUDIO, VUSB_VIDEO, and

VUSB_PRINTER — Default no. Species if these USB devices will

be redirected to the server using TCX Virtual USB or ICA or RDP

USB redirection. By default, these devices are set as local devices.

NOTE: For example, if you want to use USB disks as a

network disk, you can set SessionCong=all

mapdisks=yes VUSB_DISKS=no.

If you want to use USB disks as server side device, you can

set SessionCong=all mapdisks=no VUSB_DISKS=yes. The

devices are displayed in device manager of the session.

FullScreen — Default is no. Species the default screen mode.

When using FullScreen in a Dual Screen mode, the session will be

displayed in Span mode

Resolution — Default is default. Species the session resolution.

For example, 640 x 480 and other supported resolutions.

Default will set the resolution to the native resolution of the

monitor. Setting the resolution to a value smaller than the native

resolution of the monitor, will allow the session in Windowed mode.

The resolution value cannot be higher than the native resolution.

DisableResetVM — Default is no. Set DisableResetVM=yes to

disable Reset VM function. As default, this function is controlled by

the server side is enabled including VMware View or Citrix PNA.

WyseVDAServerPort — Sets Wyse VDA Server Port for a ThinOS

VDA client. The default port is 3471. The port range must be from

1029 to 40000. For example, WyseVDAServerPort=3000, sets VDA

server port to 3000 and the client will connect to the VDA server

using this port.

FontSmoothing — Default is yes. Set no to disable font

smoothing.

AutoConnect — Default is yes. Set no to disable auto connect

function.

76 Parameters for WNOS INI, {username} INI, and $MAC INI Files

MultiMonitor — Default is yes. Sets a multiple monitor layout. Set

MultiMonitor=no to disable multiple monitor layout function. The

session has the same desktop width and height with local virtual

desktop size, spanning across multiple monitors, if necessary.

EnableImprivataVC— Default is yes. If set to no, the Imprivata

Virtual Channel is disabled. The user can use vusb redirect instead

of Imprivata Virtual Channel mode to use the Rdeas or nger print

device in session as server side remote device.

[Locale=LocaleID]— Set Locale=LocaleID to set Locale in session

for localization conguration to work. For information about

LocaleID, refer to link msdn.microsoft.com/en-us/library/windows/

desktop/dd318693(v=vs.85).aspx.

SessionLogoTimeout—Setting SessionLogoTimeout value

forces all sessions to logo when user signs o from the broker.

The default value is 0 which retains the same behavior as before,

and also disconnects the sessions. If you set a value, for example

30 seconds, broker sign-o waits for 30 seconds for all sessions to

nish logo, then, automatically session logs o. Broker sign-o will

continue. During the waiting process, one notice prompts for user

to check whether the session stops working if something is not

saved. This feature currently supports Citrix Xen broker sessions

and View Broker sessions only.

GroupSession=yes— Set to enable the function of grouping

sessions and the menu item of Group Sessions is checked when

you right click on the desktop. The default value is no and the

original state of Group Sessions is unchecked.

**SessionCong=ICA

[desktopmode={fullscreen, window}]

[mapdisksunderz] : DISCONTINUED. DO NOT USE.

[TosIpPrecedence={0–5}]

[TosDscp={Default/CS1/CS2/CS3/CS4/CS5/CS6/CS7/AF11/

AF12/AF13/AF22/AF23/AF31/AF32/AF33/AF42/AF43}]

[DiskMapTo=a character sequence]

[SysMenu={remote, local}]

[SessionReliability={no, yes}]

[WarnPopup={yes, no}]

[ondesktop={no, yes, all, none, desktops, applications}]

[AudioQuality={default, high, medium, low}]

[USBRedirection={TCX, ICA|HDX}]

[ZLKeyboardMode={0, 1, 2}]

[ZLMouseMode={0, 1, 2}]

[SucConnTimeout=seconds]

[HDXFlashUseFlashRemoting={Never,Always}]

[HDXFlashEnableServerSideContentFetching={Disabled,Enabled}]

SessionCong — Species the ICA default settings of the optional

connection parameters for all ICA sessions.

desktopmode — Default is fullscreen. Species the display mode

of an ICA published desktop when using an ICA PNAgent logon; the

default is fullscreen mode for a PNA desktop application.

mapdisksunderz — DISCONTINUED. DO NOT USE.

TosIpPrecedence — Allows you to set IP Precedence in the TOS

elds.

TosDscp — Sets IP DSCP in the TOS elds.

DiskMapTo — Species to map disks to a character sequence.

NOTE:

A sequence of characters can be used by DiskMapTo, with

each letter mapped to one disk in order. For example, if

RTNM is the sequence, R is mapped to the rst disk (in

ThinOS, it will be D:/), T is mapped to the second disk (in

ThinOS, it will be E:/), and so on. Only the letters “a” through

“y” and “A” through “Y” are accepted; All lowercase letters

are changed to uppercase, other characters will be skipped,

and duplicate characters will be omitted.

For example, #GGefZzedAF1JaE will be mapped to GEFDAJ.

The number of disks mapped to the session depends on the

number of valid letters provided. If no letter is provided, all

disks will be mapped to the session using default driver

letters.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 77

[EnableRTME={Yes, No}]

[FlipByTimer={0, 1}]

[RefreshTimeOut={dd:hh:mm}]

[Timeout={Yes, No}]

[PasswordExpireNotify={yes, no}]

[RefreshPopupNotice={yes, no}]

SysMenu — Default is local. Species the system menu mode

when right-clicking the taskbar button of a seamless window. If it is

remote, the system menu will come from the remote server;

otherwise, it will be the local menu.

SessionReliability — Default is no. Yes/no option to enable session

reliability.

WarnPopup— If WarnPopup=no, the option can disable the

warning message when session reliability happens in order to

decrease the administrative support calls.

ondesktop — Default is no. Species options for displaying

connection icons on the desktop:

1 If AutoConnectList is set in the PNLiteServer statement, all

connections congured in AutoConnectList parameter will

display on the desktop.

2 Default is no and means that the property of ondesktop will be

controlled by the server. However, the connections are still

always added to the Connect Manager list and PNA menu list.

3 In cases other than no, the connection is controlled by the

local thin client. If set so that the connection icon does not

display on the desktop, the connection icon will not be added

to the Connect Manager list and the PNA menu list.

all — same as yes, display all connections on desktop.

none — do not display any connections.

desktops — only display connections on desktop.

applications — only display applications, the connections will be

handled as an ondesktop_list. For example, if you set

ondesktop=word; excel, then only the applications word and excel

will be displayed.

AudioQuality — Default is default. Species the audio quality of

ICA sessions.

NOTE: Medium quality is recommended for Speech

scenarios. For example: SessionCong=ICA

AudioQuality=high

USBRedirection — Default is ICA|HDX. Option to select the

channel of usb devices redirection. This option is recommended to

replace the older setting device=vusb type={TCX, HDX}.

ZLKeyboardMode — Species to accelerate the display of the

input text on the client device over a high latency connection.

0=o, 1=on, 2=auto

ZLMouseMode — Species to accelerate the visual feedback for

mouse-clicks on the client device over a high latency connection.

0=o, 1=on, 2=auto

SucConnTimeout— This option will enhance the seamless session

share. During the rst session logon, immediately start second or

later sessions, which will wait for the time set with

SucConnTimeout (or the logon success) to make sure new

applications share with the rst logon session.

HDXFlashUseFlashRemoting— Default is Always, which means

the HDX is enabled always. The value Never is to disable HDX.

HDXFlashEnableServerSideContentFetching— Default is

Disabled, which means the server side fetching content is not

enabled. The value enabled is to enable this function.

78 Parameters for WNOS INI, {username} INI, and $MAC INI Files

EnableRTME— This option controls the launch of RTME service.

The default value is enabled.

FlipByTimer— This option selects the screen refresh method. For

some old server, there is no EndOfFrame transferred to the client.

Then we can use this option to x such issues.

RefreshTimeOut—RefreshTimeOut triggers auto-refresh which

updates ICA applications automatically. The value format dd:hh:mm,

indicate days&&hours&&minutes as the auto-refresh interval. The

default value is 0, that disables auto-refresh.

Timeout– This option controls the credential prompt after ICA

broker logon was timeout. Session ticket is invalid now. If yes, users

have to enter their credential to re-login to launch session, if no,

ThinOS will use the default credential to do login in background.

The default is yes.

NOTE: Other Citrix INI parameters are not listed here.

However, these Citrix INI parameters are supported on

ICA connection by using INI SessionConfig=ICA.

PasswordExpireNotify —This option enables the password expire

notication, which should congure in storefront server side,

Authentication, password change set as At any time. Then before

the password expires, logon prompts a message displaying the

number of days after which the password will expire and let you

change the password. The option WarnPopup=no can disable the

warning message when session reliability happens to decrease the

administrative support calls.

RefreshPopupNotice — This option enables or disables the popup

notice during refresh in progress. The default value is yes.

SessionCong=PCoIP

[USBRedirection={PCoIP, TCX}]

[ShowDisconnectMessage={yes, no}]

[ShowReconnectMessageTime=seconds]

[ResumeTimeout=seconds]

SessionCong — Species the PCoIP default settings of the

optional connection parameters for all PCoIP sessions.

USBRedirection — Default is PCoIP. Species the channel of USB

devices redirection.

ShowDisconnectMessage — Default is yes. Yes/no option to

display a disconnect message when a session is disconnected. If set

to yes, the message is displayed; if set to no, the message will only

show in the Event Log.

ShowReconnectMessaageTime— This option species the

number of seconds to show the session reconnect message box

after the session detects the network congest. The default value is

50 seconds.

ResumeTimeout—The option ResumeTimeout species the

number of seconds to wait after the reconnection dialog box

prompts, and before the session successfully reconnects. If timeout

value is reached then the session is closed. The default value is

1200 seconds.

**SessionCong=RDP

[MaxBmpCache={128 to 1024}]

[DefaultColor={0,1,2}]

[EnableNLA]={no, yes}]

[ForceSpan={no, yes}]

SessionCong — Species the RDP default settings of the

optional connection parameters for all RDP sessions.

MaxBmpCache — Species the maximum bitmap cache number.

This impacts the memory usage of an RDP session.

DefaultColor — Species auto (0), 16-bit (1), and 32-bit (2)

options.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 79

[EnableTSMM={yes, no}]

[EnableGFX]={yes, no}]

[EnableVOR={yes, no}]

[EnableRdpH264]={yes, no}]

[EnableRecord={yes, no}]

[EnableRFX={yes, no}]

[USBRedirection={TCX, RDP}]

[RDPScreenAlign4={yes,no}]

[WallPaper={yes, no}]

[Dragging={yes, no}]

[Animation={yes, no}]

[Theme={yes, no}]

[TosIpPrecedence={0-5}]

[TosDscp={Default/CS1/CS2/CS3/CS4/

CS5/CS6/CS7/AF11/AF12/AF13/AF22/AF23/

AF31/AF32/AF33/AF42/AF43}]

[AutoDetectNetwork={yes, no}]

[TSGWEnable={yes, no}]

EnableNLA — Default is yes. Yes/no option to utilize the Network

Level Authentication feature in RDP 7.

ForceSpan — Default is no. Yes/no option to disable RDP Multi

Monitor feature.

EnableTSMM — Default is yes . Yes/no option to enable RDP7

Multi-media redirect.

EnableGFX —The option when set to yes, enables RDP8 Pipelined

Graphics feature. Default is yes for all platforms other than Wyse

3010 thin client with ThinOS (T10). If this option is congured as

no, the option EnableVOR and option EnableRdpH264 will be

internally set to no despite of the settings in INI.

EnableVOR — Default is yes. H.264. Yes/no option to enable

RDP8 Video Optimized Redirect.

NOTE: The EnableVOR parameter is supported on Wyse

5010 thin client with ThinOS (D10D), Wyse 5010 thin

client with PCoIP (D10DP), Wyse 5060 thin client with

ThinOS, Wyse 5060 thin client with PCoIP, R10L, Wyse

3010 thin client with ThinOS (T10), and Wyse 3020 thin

client with ThinOS (T10D). This is not supported on C or V

class.

EnableRdpH264— Default is yes. This option enables RDP8.1 h.

264 graphics feature. This option is internally set to no if the option

EnableGFX is set to no manually or by default.

EnableRecord — Default is yes . Yes/no option to enable RDP

feature of recording from local.

EnableRFX — Default is yes. Yes/no option to enable Bitmap

Codec RemoteFX. Supported on R10L, Wyse 5010 thin client with

ThinOS (D10D), Wyse 5010 thin client with PCoIP (D10DP), Wyse

5060 thin client with ThinOS, and Wyse 5060 thin client with

PCoIP.

USBRedirection — Default is TCX . Option to select the channel

of USB devices redirection.

RDPScreenAlign4 — Default is no. RDPScreenAlign4=yes can

force RDP session width to 4 pixels aligned.

For example:

SessionConfig=RDP MaxBmpCache=1024

DefaultColor=1 EnableNLA=yes ForceSpan=yes

EnableTSMM=no EnableRecord=yes EnableRFX=no

RDPScreenAlign4=no

The options WallPaper, Dragging, Animation and Theme can set the

RDP experience. Default is yes.

TosIpPrecedence — Allows you to set IP Precedance in the TOS

elds.

TosDscp — Sets IP DSCP in the TOS elds.

AutoDetectNetwork —Default is yes. Yes/no option to enable an

RDP session to adapt its data transfer to band width of network.

TSGWEnable — Default is yes. Yes/no option to obtain/enable TS

gateway for the applications and desktops from Microsoft RDS

broker server. The default value is yes which means that the TS

80 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Gateway setting is automatically obtained or enabled from the

Microsoft RDS broker server.

TcpMaxRetransmission={2~12} Congures the retransmission of a TCP connection. The default

value of this option is 5.

TerminalName=name

[reboot={yes, no}]

[Capital={yes, no}]

User can set a string up to 15 characters as terminal name. It can

be congured as system variable like $MAC, $SN or $IP etc.

If reboot is set to yes and the terminal name is changed, the

terminal will reboot.If "TerminalName=$DNS" is set, the system will

do reverse DNS lookup to congure the terminal name. For

example, if the DNS server congures the terminal IP as reverse

dns name p12345.wysespt.com, the terminal name will be

congured as p12345. If you set Capital=yes, the terminal name is

capitalized.

**UniSession={no, yes} Yes/no option to launch the connection only once at a time.

VDIBroker=vdi_broker_url

[AutoConnectList={*|host1;host2;host3…}]

VDIBroker — Species the VDI broker server; supports both http

and https.

If the vdi_broker_url does not start with http or https, the default

protocol used is http. For an https connection, only one URL is

accepted.

NOTE:

If the VDIBroker parameter value is changed, the thin client

will reboot without notice to the user so it can reconnect to

the new server.

AutoConnectList — Species the VDI or VDM host which will be

automatically started when using VDI or VDM sign-on. If the value

is *, all of the VDI or VDM hosts will automatically be connected.

The autoconnectlist is the connection description which can use

the wildcard * to match the string.

VirtualCenter=virtual_center_url Species the Virtual Center Server that supports both http and

https. If the virtual_center_url does not start with http or https, the

default protocol used is http.

NOTE:

If a VirtualCenter in an INI le is dierent from the original

URL, the thin client will reboot for the new URL to take

eect.

Only this setting can enable the Virtual Center functions.

**VNCPrompt={no, yes}

[{Accept, Reject}={10 to 600} (seconds)]

[ViewOnly={no, yes}]

[ActiveVisible={no, yes}]

Default is yes.

VNCPrompt — Yes/no option to enable a VNC shadowing prompt

to a user. VNCPrompt set to yes means the user will always be

prompted before shadowing starts and the user will then decline or

accept VNC shadowing;

VNCPrompt set to no means the user will not be able to decline or

accept shadowing. See also MaxVNCD in Table 4 : Connection

Settings for wnos.ini les only to enable VNC shadowing.

See also VncPassword in Table 4: Connection Settings for wnos.ini

Files Only to specify a string of up to 8 characters as the password

used for shadowing.

Parameters for WNOS INI, {username} INI, and $MAC INI Files 81

Accept, Reject — Default is 10. Species the amount of time (in

seconds) a user has to accept or reject the VNC shadowing prompt

before the client desktop is shadowed.

ViewOnly — Default is no. Yes/no option to specify that the

desktop being shadowed can only be viewed by the person who is

shadowing; no keyboard or mouse events are allowed to interfere

with the thin client being shadowed.

ActiveVisible — Default is no. Yes/no option to display a VNC

session-end notice after the VNC session ends.

VPN=openconnect

[Description=string_description]

[Server=server_ip_or_name]

[Username=username_string]

[Password=password_string]

[Autoconnect={yes, no}]

The INI parameter openconnect enables you to connect to Cisco

AnyConnect VPN servers, that use standard TLS protocols for data

transport.

Description— Species the session name. The length of the string

is limited to 21 characters.

Server— Species the VPN server IP or the VPN server name.

The length of the string is limited to 63 characters.

Username— Species the login username. The length of the string

is limited to 31 characters.

Password— Species the login password. The length of the string

is limited to 31 characters.

Autoconnect— Species the option to enable or disable auto-

connect on system startup.

82 Parameters for WNOS INI, {username} INI, and $MAC INI Files

Connect Parameter: Options

This appendix provides the supported options for the Connect parameter in the following supported connections:

• ICA Connect Options

• RDP Connect Options

Topics:

• ICA Connect Options

• RDP Connect Options

ICA Connect Options

Table shown here contains the supported options used for ICA connections (after you use the Connect=ICA parameter/selection).

IMPORTANT:

If an option has an underlined value (default), that option and default value will automatically be used with Connect=ICA; options

without underlined values can also be used if you want to, but are not automatically used with Connect=ICA. In addition, when using

options, you can leave the default value or change it to another value shown.

For example, in the following case where:

Connect=ICA

[Option1={0, 1}]

[Option2={1, 2, 3, 4}]

Since you are using Connect=ICA, then Option1 and its default value 0 will automatically be used as Option1 has an underlined value

(default of 0). You can still use Option2 if you want to, however, Option2 is not automatically used with the parameter as Option2 does

not have a default value.

NOTE:

Any option in Table 8: ICA Connect Options that is used in a {username}.ini le will return to the default value set for that option in the

wnos.ini le after a user sign-o. For example, if your {username}.ini le contains the option Reconnect=yes so that a lost connection

will restart 20 seconds after disconnection; and you sign o the thin client, then the Reconnect value will return to the original default

value of no (Reconnect=no) contained in the wnos.ini le—so that others who sign in can use their own user prole; assuming the

administrator has not changed the default values in the wnos.ini.

A

Connect Parameter: Options 83

ICA Connect: Options

Table 8. ICA Connect: Options

Option Description

Alternate=[no, yes] Default is no.

Yes/no option to use an alternate IP address returned from an ICA

master browser to get through rewalls.

AudioQualityMode={0, 1, 2, 3} Default is 0.

Species the audio quality of a session.

0 – Default

1 – High Quality

2 – Medium Quality

3 – Low Quality

Autoconnect={0 to 99} Default is 0.

Use for automatically starting a session after you sign in, if sign-on

is enabled.

The value of 0 – 99 is the delay in seconds before auto-starting the

session.

AppendUsername=1 This enhancement allows user names to display in the title bar of an

ICA session at the client side.

Browserip=list of browsers List of IP addresses or DNS registered names to specify ICA

browsers. List items must be separated by semicolons or commas.

Colors={256, 32k, 64k or high, 16m, true} Default is high.

Session color mode. For faster display performance, use 256 colors

for the session.

• 256 is 8-bits

• 32k is 15-bits

• 64k or high is 16-bits

• 16m is 24-bits

• true is 32-bits

NOTE:

• 64k is the same value as high.

• 16m — 24-bits over ICA is only supported by Windows

XP and Windows 2003 server. It is not supported by

Windows Server 2008 or newer.

• true — 32-bit remote connections are not supported by

Windows XP or Windows 2003 server. It requires

Windows Vista, Windows Server 2008, or newer with

ICA.

84 Connect Parameter: Options

Command=start command A string of commands to be executed after logging on to the

server. This entry is limited to 127 characters.

Description=string description Connection description. Enclose the string description in quotation

marks if there are embedded blanks or single quotes. For quotation

marks, use common-practice nesting rules. Maximum of 38

characters are allowed.

Directory=working directory A directory to be used as the working directory after logging on to

the server. Maximum of 63 characters are allowed.

Disablesound={no, yes, 2} or {0, 1, 2} Default is no.

Species whether or not to disable remote sound upon connection

start.

Domainname={domain name,$DN} Domain name to use in a Windows network. $DN species that the

thin client sign-on domain name is used. Maximum of 19 characters

are allowed.

Encryption={None, Basic, 40, 56, 128, Login-128} Default is Basic.

Connection security encryption level. The highest level is 128-bit

security (Login-128 option is 128 bit encryption for login only).The

lowest is None.

NOTE:

The server must support the specied level of encryption or

the connection will fail.

Fullscreen={no, yes} Default is no.

Yes/no option to run the session in full screen. If Fullscreen=no

then the session runs in a windowed screen.

Host=[name, IP, $SYS VAR]

or

Application=published application

Host — A list of server hostnames or IP addresses to which the

thin client will attempt to connect. The next server on the list is

attempted if the previous one failed. List items must be separated

by semicolons or commas.

NOTE:

$UN (see Table 1) species that the sign-on user name is

used and should be set in a {username}.ini le. If set to

Host=$UN in a {username}.ini le, the hostname will display

as the sign-on user name. If set to Host=$UN in a wnos.ini

le, the hostname will display as the default start.

Application — Denes the published application to launch.

Application is required if no host is specied.

HttpBrowsing={no, yes} Default is no.

Yes/no option to select an http browsing protocol. Use

HttpBrowsing=no for User Datagram Protocol (UDP).

Connect Parameter: Options 85

NOTE:

This option is used to override the default method of

browsing established in the ICABrowsing parameter. For

information, see Table 7: Connection Settings: wnos.ini les,

{username} INI, and $MAC INI Files.

Icon={default, bitmap le} Species an icon to appear on the thin client desktop for a

connection. Use Icon=default to display a system default icon for a

connection.

To use an icon other than the default icon, enter the name with

extension of the bitmap le; ensure that the le is located in the

FTP server wnos\bitmap directory. If Icon= is not specied and the

icon is not specied by a PNAgent/PNLite server, no icon is

displayed for a connection.

KeepAlive={0 to 127} Species the number of minutes to keep a session connected after

the session is inactive. During this period, one dummy packet will be

sent to the server if network trac is lost. Default is 10.

LocalCopy={no, yes} Default is no.

Yes/no option to save the connection to the local NVRAM.

The connection description of the Description option is used as the

index key into the local connection table. If a match is found, then

the entry is updated. Otherwise, a new entry is created.

Maximum total of local entries is 16.

Logon_mode={local-user, smartcard, user-specied} Default is local-user.

Species how users authenticate to the selected application set or

ICA connection.

Lowband={no, yes} Default is no.

Yes/no option to enable optimization for low speed connections

such as reducing audio quality and/or decreasing protocol-specic

cache size.

Mapdisks={no, yes} Default is no.

Yes/no option to auto-connect and map any connected USB ash

drive upon connection start.

Mapdisksunderz IMPORTANT: : DISCONTINUED. DO NOT USE

.

[NO_FontSmoothing={no, yes}] Default is no.—font smoothing is enabled by default.

Yes/no option to disable font smoothing. If set to yes, the font

smoothing is disabled.

NoReducer={no, yes} Default is no.

Yes/no option to turn o compression. Default is no, which enables

compression. To turn o compression, enter yes.

86 Connect Parameter: Options

Used here is an option of the Connect statement. It sets the value

of NoReducer only for this specied connection.

NOTE:

By default the ICA protocol compresses the data to minimize

the amount of data that needs to traverse the network. This

compression can be as much as 50 percent for text-based

applications such as Microsoft Word and 40 percent less for

graphics applications than the data streams that are not

compressed.

Password={password, $SYS_VAR} Password to log-in to the application server. Either a conventional

login password or a variable can be used. Maximum of 19

characters are allowed.

The value of password is a conventional login password.

The value of $SYS_VAR is a system variable found in Table: System

variables.

IMPORTANT:

The application server password is not encrypted; it is

strongly recommended not to specify it. The user will be

prompted to enter the password when the connection is

made. This application server password directive never starts

a line, so it can be distinguished from the thin client user

sign-on password which does starts a line.

NOTE:

The Password option is not written into a {username}.ini le

by a user. When the New Password check box is selected,

the system writes the new, changed password into the

{username}.ini le with encryption. This password is then

checked against the sign-on password with encryption to

determine whether sign-on is successful.

Password-enc=an encrypted password Species an encrypted string as a password for a connection.

Reconnect={no, yes, 1 to 3600 (seconds)} Default is no.

Controls automatic reconnection to an application after a server

disconnection.

yes — Use to restart the connection; the default delay time for yes

reconnect is 20 seconds.

no — Use to prevent reconnection after a disconnect.

1 to 3600 — Use an integer value of 1 to 3600 seconds to restart

the connection after the delay you want. For example, use 50 and

the automatic reconnection to an application will occur after 50

seconds.

Resolution=[default, Seamless, <monitor resolution>] Default is default.

Species the connection display resolution.

default — Starts the connection using the current desktop display

setting with no window frame and border.

Connect Parameter: Options 87

Seamless — Available for use if the connection is to a published

application. For Seamless connections, the MetaFrame hosts select

the best-t connection window for applications.

<monitor resolution> — Resolution values you can use in the form

X x Y depending on your client. Example for monitor resolution:

1024 x 768. See the Release Notes of your client.

SessionReliability={no, yes} Default is no.

Yes/no option to enable session reliability.

NOTE:

ThinOS thin clients do not support UDP browsing to obtain a

new conguration about session reliability on the server. The

thin client always connects to the default port.

UniSession={no, yes} Default is no.

Yes/no option to use a unisession. The connection will launch only

once at a time.

UnmapClipboard={no, yes} Default is no.

Yes/no option to disable clipboard redirection for an ICA session if

redirecting the clipboard.

UnmapPrinters={no, yes} Default is no.

Yes/no option to not auto-connect to local printers when the

connection starts.

UnmapSerials={no, yes} Default is no.

Yes/no option to not auto-connect to local serials when the

connection starts.

UnmapUSB={no, yes} Default is no.

Yes/no option to not auto-connect to local USB devices (Virtual

USB) when the connection starts.

Username=[username, $SYS_VAR] Username to log-in to the application server. Either a conventional

login username or a variable can be used. Maximum of 31

characters are allowed.

The value of username is a conventional login username.

The value of $SYS_VAR is a system variable found in Table 1:

System variables.

NOTE:

The combination of all the variables such as $IP@$DN are

also supported.

Username-enc=an encrypted username Species an encrypted string as a username for a connection.

[WyseVDA={no, yes}] Default is no.

Yes/no option to enable Wyse Virtual Desktop Accelerator for all

ICA sessions.

88 Connect Parameter: Options

RDP Connect Options

Table shown here contains the supported options used for RDP connections after you use the Connect=RDP parameter/selection.

IMPORTANT:

If an option has an underlined value (default), that option and default value will automatically be used with Connect=RDP; options

without underlined values can also be used if you want to, but are not automatically used with Connect=RDP. In addition, when using

options, you can leave the default value or change it to another value shown.

For example, in the following case where:

Connect=RDP

[Option1={0, 1}]

[Option2={1, 2, 3, 4}]

Since you are using Connect=RDP, then Option1 and its default value 0 will automatically be used as Option1 has an underlined value

(default of 0). You can still use Option2 if you want to, however, Option2 is not automatically used with the parameter as Option2 does not

have a default (underlined) value.

NOTE:

Any option in Table 9: RDP Connect Options that is used in a {username}.ini le will return to the default value set for that option in the

wnos.ini le after a user sign-o.

For example, if your {username}.ini le contains the option Reconnect=yes (so that a lost connection will restart 20 seconds after

disconnection) and you sign o of the thin client, then the Reconnect value will return to the original default value of no

(Reconnect=no) contained in the wnos.ini le—so that others who sign in can use their own user prole assuming the administrator

has not changed the default values in the wnos.ini le.

RDP Connect Options

Table 9. RDP Connect Options

Option Description

Autoconnect={0 to 99} Default is 0.

Use for automatically starting a session after sign-on, if sign-on is

enabled.

The value of 0-99 is the delay in seconds before auto-starting the

session.

Colors={256, 32k, 64k or high, 16m, true} Default is high.

Session color mode. For faster display performance, use 256 colors

for the session.

• 256 is 8-bits

• 32k is 15-bits

• 64k or high is 16-bits

• 16m is 24-bits

• true is 32-bits

Connect Parameter: Options 89

NOTE:

• 64k is the same value as high.

• 16m — 24-bits over RDP is only supported by Windows

XP and Windows 2003 server. It is not supported by

Windows Server 2008 or newer.

• true — 32-bit remote connections are not supported by

Windows XP or Windows 2003 server. It requires

Windows Vista, Windows Server 2008, or newer with

RDP.

Command=start command A string of commands to be executed after logging on to the

server. This entry is limited to 127 characters.

Console={no, yes} Default is no.

Yes/no option to login to a session in Console mode.

NOTE:

If Console=yes is set behind the RDP connection, the

TimeZone redirection feature will be disabled.

Description=string description Connection description. Enclose the string description in quotation

marks if there are embedded blanks or single quotes. For quotation

marks, use common-practice nesting rules. Maximum of 38

characters are allowed.

Directory=working directory A directory to be used as the working directory after logging on to

the server. Maximum of 63 characters are allowed.

Disablesound={no, yes, 2} or {0, 1, 2} Default is no. or Default is 0.

Species whether or not to disable remote sound upon connection

start.

NOTE:

Disablesound=2 only works in RDP sessions and indicates

that the remote computer sound should be disabled at the

remote computer.

Domainname={domain name,$DN} Domain name to use in a Windows network. $DN species that the

thin client sign-on domain name is used. Maximum of 19 characters

are allowed.

Fullscreen={no, yes} Default is no.

Yes/no option to run the session in full screen. If Fullscreen=no

then the session runs in a windowed screen.

NOTE:

Fullscreen=Yes and DualHead=Yes will result in Span Mode

when connecting to a Windows server 2003 or a Windows

XP Pro Client.

Fullscreen=Yes and DualHead=Yes will result in Extended

mode when connecting to a Windows Server 2008 (any

version) and to a Windows 8 or above desktop.

90 Connect Parameter: Options

Host=[name, IP, $SYS VAR] Host — A list of server host names or IP addresses to which the

thin client will attempt to connect; the next server on the list is

attempted if the previous one failed. List items must be separated

by semicolons or commas.

NOTE:

$UN species that the sign-on user name is used and should

be set in a {username}.ini le. , see Table 1: System Variables.

If set to Host=$UN in a {username}.ini le, the hostname will

display as the sign-on user name. If set to Host=$UN in a

wnos.ini le, the hostname will display as the default Start.

Icon={default, bitmap le} Species an icon to appear on the thin client desktop for a

connection. Use Icon=default to display a system default icon for a

connection.

To use an icon other than the default icon, enter the name with

extension of the bitmap le; ensure that the le is located in the

FTP server wnos\bitmap directory. If Icon= is not specied and the

icon is not specied by a PNAgent/PNLite server, no icon is

displayed for a connection.

KeepAlive={0 to 127} Default is 10.

Species the number of minutes to keep a session connected after

the session is inactive. During this period, one dummy packet will be

sent to the server if network trac is lost.

LocalCopy={no, yes} Default is no.

Yes/no option to save the connection to the local NVRAM.

The connection description of the Description option is used as the

index key into the local connection table. If a match is found, then

the entry is updated. Otherwise, a new entry is created.

Maximum total of local entries is 16.

Logon_mode=prompt Species one dialog box will pop up to allow a user to enter

username, password, and domain before connecting to the RDP

session. This can prevent the need to input credentials twice in

some cases of server redirection (load balancing).

Lowband={no, yes} Default is no.

Yes/no option to enable optimization for low speed connections

such as reducing audio quality and/or decreasing protocol-specic

cache size.

Mapdisks={no, yes} Default is no. Yes/no option to auto-connect and map any

connected USB ash drive upon connection start.

NoReducer={no, yes} Default is no — Enables compression.

Yes/no option to turn o compression. To turn o compression,

enter yes. Used here is an option of the Connect statement. It sets

the value of NoReducer only for this specied connection.

Connect Parameter: Options 91

NOTE:

By default the RDP protocol compresses the data to

minimize the amount of data that needs to traverse the

network. This compression can be as much as 50 percent for

text-based applications such as Microsoft Word and 40

percent less for graphics applications than the

uncompressed data streams.

Password={password, $SYS_VAR} Password to log-in to the application server. Either a conventional

login password or a variable can be used. Maximum of 19

characters are allowed.

The value of password is a conventional login password.

The value of $SYS_VAR is a system variable found in Table 1:

System Variables.

IMPORTANT:

The application server password is not encrypted; we

strongly recommend not to specify it. The user will be

prompted to enter the password when the connection is

made. This application server password directive never starts

a line, so it can be distinguished from the thin client user

sign-on password which does starts a line.

NOTE:

The Password option is not written into a {username}.ini le

by a user. When the New Password check box is selected,

the system writes the new password into the {username}.ini

le with encryption.

This password is then checked against the sign-on password

with encryption to determine whether sign-on is successful.

Password-enc=an encrypted password Species an encrypted string as a password for a connection.

RDPAudioQualityMode NOTE: DISCONTINUED. DO NOT USE.

RDPAudioRecord={no, yes} Default is no.

Yes/no option to specify whether users can record audio to the

server. This requires a Windows 7 Server.

Rdp_No_Animation={no, yes} Default is no.

Yes/no option to disable the Menu and Window animation feature;

use yes to disable the feature.

Rdp_No_Dragging={no, yes} Default is no.

Yes/no option to disable the Show content when dragging a

window feature; use yes to disable the feature.

Rdp_No_Fontsmoothing={no, yes} Default is no.

Yes/no option to disable the Font smoothing feature; use yes to

disable the feature.

Rdp_No_Theme={no, yes} Default is no.

92 Connect Parameter: Options

Yes/no option to disable the Theme feature; use yes to disable the

feature.

Rdp_No_Wallpaper={no, yes} Default is no.

Yes/no option to disable the Wallpaper feature; use yes to disable

the feature.

Reconnect={no, yes, 1 to 3600 (seconds)} Default is no.

Controls automatic reconnection to an application after a server

disconnection.

yes — Use to restart the connection; the default delay time for yes

reconnect is 20 seconds.

no — Use to prevent reconnection after a disconnect.

1 to 3600 — Use an integer value of 1 to 3600 seconds to restart

the connection after the delay you want. For example, use 50 and

the automatic reconnection to an application will occur after 50

seconds.

Resolution=[default, <monitor resolution>] Default is default.

Species the connection display resolution.

default — Starts the connection using the current desktop display

setting with no window frame and border.

<monitor resolution> — Resolution values you can use in the form

XxY. For example: 1024x768 depend on your client. See the Release

Notes for your client.

NOTE:

If Using DualHead=Yes and setting this resolution value to

Default will start the RDP session in Span Mode. If you want

to use only the fullscreen of one monitor use

Resolution=DDC. This option is ignored if Fullscreen=Yes

Smartcards={no, yes} Default is no.

Yes/no option to use a smart card login server when the

connection starts.

TSGWDomainName=[domain] Species the TS Gateway Domain for RDP session.

TSGWENABLE={no, yes} Default is no.

Yes/no option to enable TS gateway.

TSGWNAME=[hostname] Species the TS Gateway host address.

TSGWPassword=[password] Species the TS Gateway Password for the RDP session.

TSGWPassword-enc=[encrypted-password] Species the encrypted TS Gateway Password for RDP session.

TSGWSERVER=[hostname] Species the TS Gateway host address.

TSGWUsername=[username] Species the TS Gateway Username for RDP session.

TSGWUsername-enc=[encrypted-username] Species the encrypted TS Gateway Username for RDP session.

TSGWUSESAMEINFO={no, yes} Default is no.

Connect Parameter: Options 93

Yes/no option to apply RDP connection credential to Gateway

credential.

UniSession={no, yes} Default is no.

Yes/no option to use a unisession—a connection will launch only

once at a time.

UnmapClipboard={no, yes} Default is no.

Yes/no option to disable clipboard redirection for an RDP session if

redirecting the clipboard.

UnmapPrinters={no, yes} Default is no.

Yes/no option to not auto-connect to local printers when the

connection.

UnmapSerials={no, yes} Default is no.

Yes/no option to not auto-connect to local serials when the

connection.

UnmapUSB={no, yes} Default is no.

Yes/no option to not auto-connect to local USB devices (Virtual

USB) when the connection starts.

Username=[username, $SYS_VAR] Username to log-in to the application server. Either a conventional

login username or a variable can be used. Maximum of 31

characters are allowed.

The value of username is a conventional log-on username.

The value of $SYS_VAR is a system variable found in Table: System

variables.

NOTE:

The combination of all the variables such as $IP@$DN are

also supported.

Username-enc=an encrypted username Species an encrypted string as a username for a connection.

[WyseVDA={no, yes}] Default is no.

Yes/no option to enable Wyse Virtual Desktop Accelerator for all

RDP sessions.

94 Connect Parameter: Options

TimeZone Parameter: Values

Using the TimeZone parameter, Table “TimeZone Parameter: Values” contains the zone value options that can be used.

For Example:

TimeZone="GMT - 08:00" ManualOverride=Yes Daylight=Yes \

Start=030207 End=110107 TimeZoneName=Pacific \

DaylightName=Pacific

Remember to use quotation marks (" ") since the option includes spaces. The example above uses the " \" to break a single continuous line

into multiple likes for easier reading with no" \" on the last line of the parameter.

NOTE:

The Start and End options are in the MMWWDD format, where:

MM = Month of the year. Values are 01 to 12 for the months of the year from January to December.

For example, 01 = January, 12 = December

WW = Week of the Month. Values are 01 to 05 for the week of the month, 05 is the last week.

For example, 01 = 1st week, 05 = the last week of the month.

DD = Day of the week. Values are 01 to 07 for the day in the week from Monday to Sunday.

For example, 01 = Monday, 07 = Sunday

U.S. Only:

For the 2013 year, DST dates are Sunday, March 10, 2:00am and ends Sunday, November 3, 2:00am.

Start=030207 End=110107

For the 2014 year, DST dates are Sunday, March 9, 2:00am and ends Sunday, November 2, 2:00am.

Start=030207 End=110107

TimeZone Parameter: Values

Table 10. TimeZone Parameter: Values

Geographic Time Zones Time Zones Name

(GMT-12:00) International Date Line West Dateline

(GMT-11:00) Coordinated Universal Time-11 UTC-11

B

TimeZone Parameter: Values 95

Geographic Time Zones Time Zones Name

(GMT-10:00) Hawaii Hawaiian

(GMT-09:00) Alaska Alaskan

(GMT-08:00) Pacic Time (US & Canada) Pacic

(GMT-07:00) Arizona" US Mountain

(GMT-07:00) Chihuahua, La Paz, Mazatlan Mountain (Mexico)

(GMT-07:00) Mountain Time (US & Canada) Mountain

(GMT-06:00) Central America" Central America

(GMT-06:00) Central Time (US & Canada) Central

(GMT-06:00) Guadalajara, Mexico City, Monterrey Central (Mexico)

Geographic time zones Time zones name

(GMT-06:00) Saskatchewan Canada Central

(GMT-05:00) Bogota, Lima, Quito, Rio Branco SA Pacic

(GMT-05:00) Chetumal Eastern (Mexico)

(GMT-05:00) Eastern Time (US & Canada) Eastern

(GMT-05:00) Indiana (East) US Eastern

(GMT-04:30) Caracas Venezuela

(GMT-04:00) Asuncion Paraguay

(GMT-04:00) Atlantic Time (Canada) Atlantic

(GMT-04:00) Cuiaba Central Brazilian

(GMT-04:00) Georgetown, La Paz, Manaus, San Juan SA Western

(GMT-03:30) Newfoundland Newfoundland

(GMT-03:00) Brasilia E. South America

(GMT-03:00) Cayenne, Fortaleza SA Eastern

(GMT-03:00) City of Buenos Aires Argentina

(GMT-03:00) Greenland Greenland

(GMT-03:00) Montevideo Montevideo

(GMT-03:00) Salvador Bahia

96 TimeZone Parameter: Values

Geographic Time Zones Time Zones Name

(GMT-03:00) Santiago Pacic SA

(GMT-02:00) Coordinated Universal Time-02 UTC-02

(GMT-01:00) Azores Azores

(GMT-01:00) Cape Verde Is. Cape Verde

(GMT) Casablanca Morocco

(GMT) Coordinated Universal T+A35:A98ime UTC

Geographic time zones Time zones name

(GMT) Dublin, Edinburgh, Lisbon, London GMT

(GMT) Monrovia, Reykjavik Greenwich

(GMT+01:00) Amsterdam, Berlin, Bern, Rome, Stockholm, Vienna W. Europe

(GMT+01:00) Belgrade, Bratislava, Budapest, Ljubljana, Prague Central Europe

(GMT+01:00) Brussels, Copenhagen, Madrid, Paris Romance

(GMT+01:00) Sarajevo, Skopje, Warsaw, Zagreb Central European

(GMT+01:00) West Central Africa W. Central Africa

(GMT+01:00) Windhoek Namibia

(GMT+02:00) Amman Jordan

(GMT+02:00) Athens, Bucharest GTB

(GMT+02:00) Beirut Middle East

(GMT+02:00) Cairo Egypt

(GMT+02:00) Damascus Syria

(GMT+02:00) E. Europe E. Europe

(GMT+02:00) Harare, Pretoria South Africa

(GMT+02:00) Helsinki, Kyiv, Riga, Soa, Tallinn, Vilnius FLE

(GMT+02:00) Istanbul Turkey

(GMT+02:00) Jerusalem Israel

(GMT+02:00) Kaliningrad (RTZ 1) Russia TZ 1

(GMT+02:00) Tripoli Libya

TimeZone Parameter: Values 97

Geographic Time Zones Time Zones Name

(GMT+03:00) Baghdad Arabic

(GMT+03:00) Kuwait, Riyadh Arab

(GMT+03:00) Minsk Belarus

(GMT+03:00) Moscow, St. Petersburg, Volgograd (RTZ 2) Russia TZ 2

(GMT+03:00) Nairobi E. Africa

(GMT+03:30) Tehran Iran

(GMT+04:00) Abu Dhabi, Muscat Arabian

(GMT+04:00) Baku Azerbaijian

(GMT+04:00) Izhevsk, Samara (RTZ 3) Russia TZ 3

(GMT+04:00) Port Louis Mauritius

(GMT+04:00) Tbilisi Georgian

(GMT+04:00) Yerevan Caucasus

(GMT+04:30) Kabul Afghanistan

(GMT+05:00) Ashgabat, Tashkent West Asia

(GMT+05:00) Ekaterinburg (RTZ 4) Russia TZ 4

(GMT+05:00) Islamabad Karachi Pakistan

(GMT+05:30) Chennai, Kolkata, Mumbai, New Delhi India

(GMT+05:30) Sri Jayawardenepura Sri Lanka

(GMT+05:45) Kathmandu Nepal

(GMT+06:00) Astana Central Asia

(GMT+06:00) Dhaka Bangladesh

(GMT+06:00) Novosibirsk (RTZ 5) Russia TZ 5

(GMT+06:30) Yangon Rangoon Myanmar

(GMT+07:00) Bangkok, Hanoi, Jakarta SE Asia

(GMT+07:00) Krasnoyarsk (RTZ 6) Russia TZ 6

(GMT+08:00) Beijing, Chongqing, Hong Kong, Urumqi China

(GMT+08:00) Irkutsk (RTZ 7) Russia TZ 7

98 TimeZone Parameter: Values

Geographic Time Zones Time Zones Name

(GMT+08:00) Kuala Lumpur, Singapore Singapore

(GMT+08:00) Perth W. Australia

(GMT+08:00) Taipei Taipei

(GMT+08:00) Ulaanbaatar Ulaanbaatar

(GMT+08:30) Pyongyang North Korea

(GMT+09:00) Osaka, Sapporo, Tokyo Tokyo

(GMT+09:00) Seoul Korea

(GMT+09:00) Yakutsk (RTZ 8) Russia TZ 8

(GMT+09:30) Adelaide Cen. Australia

(GMT+09:30) Darwin AUS Central

(GMT+10:00) Brisbane E. Australia

(GMT+10:00) Canberra, Melbourne, Sydney AUS Eastern

(GMT+10:00) Guam, Port Moresby West Pacic

(GMT+10:00) Hobart Tasmania

(GMT+10:00) Magadan Magadan

(GMT+10:00) Vladivostok, Magadan (RTZ 9) Russia TZ 9

(GMT+11:00) Chokurdakh (RTZ 10) Russia TZ 10

(GMT+11:00) Solomon Is., New Caledonia Central Pacic

(GMT+12:00) Anadyr, Petropavlovsk-Kamchatsky (RTZ 11) Russia TZ 11

(GMT+12:00) Auckland, Wellington New Zealand

(GMT+12:00) Coordinated Universal Time+12 UTC+12

(GMT+12:00) Fiji Fiji

(GMT+13:00) Nuku'alofa Tonga

(GMT+13:00) Samoa Samoa

(GMT+14:00) Kiritimati Island Line Islands

TimeZone Parameter: Values 99

Best Practices: Troubleshooting and Deployment

Examples

This appendix contains the following best practices information:

• Troubleshooting INI Files

• Examples: Basic Deployments

Topics:

• Troubleshooting INI Files

• Examples: Basic Deployments

Troubleshooting INI Files

General recommendations when encountering INI parameter usage problems and errors include:

• Check for spelling and format mistakes.

• Use the following process:

a Restart the thin client.

b Check thin client system information: for example, the Event log.

c Search the Event log to see if there is an invalid statement.

Examples: Basic Deployments

To help you get started, the following sections provide examples of parameters commonly used for basic deployments.

Citrix XenDesktop Broker Deployment

Autoload=1

Privilege=High

Timeserver=NTPserver.whatever.com timeformat="12-hour format" Dateformat=mm/dd/yyyy

TimeZone='GMT - 05:00' ManualOverride=no Daylight=yes Start=030207 End=110107

TimeZoneName=Eastern DayLightName=Eastern

SignOn=Yes

PNliteServer=https://XenDesktopDDC

Domainlist=yourdomain

Sysmode=VDI

Citrix Presentation Server/XenApp Deployment (with Optional Published Application)

Autoload=1

Signon=no

Seamless=yes

Connect=ICA \

BrowserIP=IPaddress \

Application="application" \

Description="name" \

C

100 Best Practices: Troubleshooting and Deployment Examples

Icon=default \

Domainname=Domain \

LocalCopy=no

Microsoft Broker Deployment

Autoload=1

Signon=yes

ConnectionBroker=Microsoft Host=ipadress

Domainlist=

Privilege=

VMware View Broker Deployment

Autoload=1

ConnectionBroker=VMware

VDIBroker=https://ViewServerAddress

TimeServer=IPAddress TimeFormat="12-hour format" DateFormat=mm/dd/yyyy

TimeZone='GMT - 05:00' ManualOverride=No Daylight=Yes Start=030207 End=110107

TimeZoneName=Eastern DaylightName=Eastern

Microsoft Terminal Services/Remote Desktop Service Deployment

Autoload=1

Signon=no

Seamless=yes

Connect=RDP \

Host=IP or Name of MS RDS server \

Description="Description" \

Username=Username \

Domainname=Domain \

Password=Password \

LocalCopy=no

Quest

ConnectionBroker=Quest

Signon=no

Domainlist=

Best Practices: Troubleshooting and Deployment Examples 101
